SDE Lighting Sixty Scan User manual

1
SDE Lighting –www.sdelighting.com –Sixty Scan
SDE Lighting Sixty Scan
1. GETTING STARTED
What’s In The Box?
SDE Lighting Sixty Scan
5ft IEC power cable
User Manual
Congratulations on your purchase of the future of lighting!
Now that you have a Sixty Scan you should carefully unpack the box and
check the contents to ensure that all pieces are present and in good
condition. If anything looks as if it has been damaged in transit, notify the
shipper immediately and keep the packing material for inspection.
Powering Up
All fixtures must be powered directly from a switched circuit and cannot be
run off a rheostat (variable resistor) or dimmer circuit, even if the rheostat
or dimmer channel is used solely for a 0% to 100% switch.
All fixtures must be connected to circuits with a working Ground.
SAFETY PRECAUTIONS
• ALWAYS make sure that you are connecting to the proper voltage.
• This product is intended for indoor use only. To prevent risk of fire or
shock, do not expose fixture to rain or moisture.
•Make sure there are no flammable materials close to the unit while
operating.
• ALWAYS disconnect from the power source before replacing fuse and be
sure to replace with same fuse size and type.
•ALWAYS secure fixture using a safety chain. NEVER carry the fixture by its
cord. Use its carrying handles.
• DO NOT operate at ambient temperatures higher than 113°F (45°C).
• In the event of a serious operating problem, stop using the unit
immediately. NEVER try to repair the unit by yourself.
• NEVER connect the device to a dimmer pack.
• Avoid direct eye exposure to the light source while it is on.
ATTENTION There are no user serviceable parts in the unit. Do not open
the housing or attempt any repairs yourself. In the event your unit may
require service, please contact SDE Lighting at [email protected].
Fuse Replacement
With a flat head screwdriver, wedge the fuse holder out of its housing.
Remove the blown fuse from its holder and replace with exact same type
fuse. Insert the fuse holder back in its place and reconnect power.

2
SDE Lighting –www.sdelighting.com –Sixty Scan
2. The Sixty Scan
FEATURES
High Performance Mobile DMX Scanner with 1 60W LED Source
7 Colors + White
7 Rotating Gobos + Open
9 DMX Channels
3- Button Menu System with LED Display
3 Operating Modes: DMX, Master/Slave, Sound Active
Sound Sensitivity Knob and microphone
Built in Lighting Programs
Manual Focusing Lens
Gobo Shake effect
Strobe effect in every color
13-degree beam angle
Dual-Fan cooled
Hanging Bracket Included
Safety Rope Eyelet
3. SETUP
To run light shows you can use a DMX-512 controller or run shows on two or
more fixtures set to master/slave operating mode. The combined number of
channels required by all the fixtures on a link determines the number of
fixtures that can be supported.
Fixtures on a DMX link must be daisy chained in one single line. Connecting
more than 32 fixtures may result in deterioration of the digital DMX signal.
The maximum recommended cable-run distance is 1640 ft.
The maximum recommended number of fixtures on a single link is 32.
To link fixtures together you’ll need DMX cables. You should always use data
grade cables that can carry a high quality signal and are less prone to
interference.
Standard microphone XLR cables will work, but are not designed for data
transmission, and could cause continuity issues.
OVERHEAD RIGGING requires extensive experience, including calculating
working load limits, installation material being used, and periodic safety
inspection of all installation material and the device. If you lack these
qualifications do not attempt the installation yourself, but instead use a
professional structural rigger.
Before rigging make sure the installation area can hold a minimum point
load of 10 times the device’s weight. Mount the device using an appropriate
clamp and always install a safety-rope that can hold at least 12 times the
weight of the fixture.

3
SDE Lighting –www.sdelighting.com –Sixty Scan
4. OPERATING FEATURES
Menu
When you first power up the fixture rSt will display as the fixture goes
through a self-test mode. Pressing the MENU button changes through the
various Menu options. Up and Down is used to change the options within the
separate menu settings.
Master/Slave
The master/slave operation enables several fixtures to be synchronized and
controlled by one master device.
1.) Use standard DMX cables to daisy chain your units together via the DMX
connector on the rear of the units
2.) Choose a unit to function as the Master. Select d-1- for sound active,
d-2- for slow room scan, d-3- for use with a remote (sold separately). The
master unit must be the first unit. Finally, chain the units together using
DMX cable.
3.) Select slave units by using the <UP>/<DOWN> keys to reach S-1- in
the Slave menu for identical movement, S-2- for reverse pan, S-3- for
reverse pan and tilt, S-4- for reverse tilt, and they will react with the
Master.
DMX Mode:
The Sixty Scan will automatically detect whether DMX 512 data is received.
If the data is received the display will show A.001 If there is no data it will
show A001
1.) DMX mode appears as A001 on the LED Readout. Use the <UP> and
<DOWN> buttons to choose a channel between A001 and A512.
Fixtures with the same DMX channel will operate similarly.
MENU
DMX Address A001
Slave Mode S-1-
Master Mode d-1-
Pan Mode P--1
Tilt Mode t--1
LED Display d--1
UP
DOWN

4
SDE Lighting –www.sdelighting.com –Sixty Scan
Other Settings (Applies in all modes):
Pan Reverse:
Select P--0from the control panel, to have the mirror pan in reverse.
Tilt Reverse:
Select t--0from the control panel, to have the mirror tilt in reverse.
LED Display:
Select d--0from the control panel, the LED menu display will turn off
after approximately 5 seconds.
DMX Channels
Channel 1 –Pan (Horizontal Movement)
Value –0-255, 128 –Center Gradual mirror adjustment from left to right
Channel 2 –Tilt (Vertical Movement)
Value –0-255, 128 –Center Gradual mirror adjustment from up to down
Channel 3 –Color
Value
Color
0
15
White (Open)
16
31
Dark Blue
32
47
Orange
48
63
Yellow
64
79
Pink
80
95
Light Blue
96
111
Green
112
127
Magenta
128
255
Rainbow Effect(Slow –Fast)
Channel 4 –Gobo
Value
Gobo
0
7
Open
8
15
Gobo 1 “Broken Glass”
16
23
Gobo 2 “Star”
24
31
Gobo 3 “Pinwheel”
32
39
Gobo 4 “Small Circles”
40
47
Gobo 5 “Sun”
48
55
Gobo 6 “Target”

5
SDE Lighting –www.sdelighting.com –Sixty Scan
56
63
Gobo 7 “3 Large Circles”
64
71
Open Shake
72
79
Gobo 1 Shake
80
87
Gobo 2 Shake
88
95
Gobo 3 Shake
96
103
Gobo 4 Shake
104
111
Gobo 5 Shake
112
119
Gobo 6 Shake
120
127
Gobo 7 Shake
128
255
Gobo Wheel Rotation (Slow –Fast)
Channel 5 –Gobo Rotation
Value
Feature
0
15
No Rotation
16
135
Clockwise Gobo Rotation (Slow –Fast)
136
255
Counter-Clockwise Gobo Rotation (Fast –Slow)
Channel 6 –Shutter/Strobe
Value
Feature
0
7
Blackout
8
15
Shutter Open
16
131
Strobe (Slow –Fast)
132
139
Shutter Open
140
180
Shutter (Slow Open –Fast Close)
181
189
Shutter Open
190
231
Shutter (Fast Open –Slow Close)
232
239
Reset
240
247
Random Strobe
248
255
Shutter Open
Channel 7 –Dimmer
Value 0-255 Dimmer Control (0% - 100%)
Channel 8 –Built-in Macro Movement
Value
Feature
0
7
No Movement
8
25
Movement 1
26
43
Movement 2
44
61
Movement 3
62
79
Movement 4
80
97
Movement 5
98
115
Movement 6

6
SDE Lighting –www.sdelighting.com –Sixty Scan
116
133
Movement 7
134
151
Movement 8
152
169
Movement 9
170
187
Movement 10
188
205
Movement 11
206
223
Movement 12
224
241
Movement 13
242
255
Movement 14
Channel 9 –Macro Movement Speed
Value 0-255 Movement Speed (Slow-Fast)
5. APPENDIX
Keeping Your Sixty Scan As Good As New
The Sixty Scan you’ve received is well tested and road worthy, and as long
as you take care of it, it will last. You should always keep the fixture clean,
especially if you are using it in an environment with a lot of dust and dirt.
Cleaning the manual focus lens exterior routinely with a suitable glass
cleaner will help improve the quality of light output. Please use a moist lint-
free cloth.
In transit, keep the Sixty Scan in a case to minimize wear and tear.
Returns
Like any complex piece of equipment designed and built by humans,
manufacturing errors can cause a problem. If you find yourself with a fixture
that isn’t behaving like it should, you’ll need to obtain a Return Merchandise
Authorization (RMA).
Just send an email to [email protected], and we’ll issue you an RMA.
Then, you’ll need to send the unit to us using a pre-paid shipping method
that can be tracked. We suggest USPS or UPS.
Make sure you carefully pack the fixture for transit, and when possible, use
the original box & packing for shipping.
When returning your fixture for service, be sure to include the following:
1.) Your contact information (Name, Address, Phone, Email address).
2.) The RMA# issued to you
3.) A brief description of the problem/symptoms.
We will, at our discretion, repair or replace the fixture. Please know that any
shipping damage that occurs in transit to us is the customer’s responsibility.

7
SDE Lighting –www.sdelighting.com –Sixty Scan
Technical Specs
Weight & Dimensions
Length
16 inches (410 mm)
Width
8 inches (200 mm)
Height
6 inches (150 mm)
Weight
17 lbs (7 kg)
Power
Operating Voltage
120VAC, 60 Hertz
Fuse
4A 125V
Power Consumption
90W
Light Source
LED
1 x 60w White LED, 50k Hours
Optical
Beam Angle
13 degrees
Luminous Intensity
9,200 Lux @ 1m
Thermal
Max. Operating Temp.
113 degrees F (45 degrees C)
Control
Protocol
DMX-512
DMX Channels
9
Input
3-pin XLR Male
Output
3-pin XLR Female
Other Operating
Modes
Standalone, Master/Slave, Sound Active
Warranty
1-year limited warranty; does not cover
malfunction caused by user damage.
