Fun Generation PicoBeam 30 Quad LED User manual

PicoBeam 30
Quad LED
moving head
user manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Deutschland
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
20.11.2017, ID: 372682

Table of contents
1 General information................................................................................................................................. 5
1.1 Further information........................................................................................................................... 6
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 8
2 Safety instructions.................................................................................................................................. 11
3 Features....................................................................................................................................................... 16
4 Installation.................................................................................................................................................. 17
5 Starting up.................................................................................................................................................. 21
6 Connections and operating elements........................................................................................... 23
7 Operating.................................................................................................................................................... 26
7.1 Starting the device........................................................................................................................... 26
7.2 Function selection........................................................................................................................... 27
7.2.1 DMX menu...................................................................................................................................... 28
7.2.2 Scene menu.................................................................................................................................... 31
7.2.3 Programme menu........................................................................................................................ 35
Table of contents
PicoBeam 30 Quad LED
3

7.3 Settings menu................................................................................................................................... 36
7.4 Functions in 3-channel DMX mode (8-bit).............................................................................. 43
7.5 Functions in 8-channel DMX mode (16-bit)........................................................................... 43
7.6 Functions in 13-channel DMX mode (16-bit)......................................................................... 46
8 Remote control......................................................................................................................................... 49
9 Technical specifications....................................................................................................................... 52
10 Plug and connection assignments.................................................................................................. 53
11 Troubleshooting...................................................................................................................................... 54
12 Cleaning....................................................................................................................................................... 56
13 Protecting the environment.............................................................................................................. 57
Table of contents
moving head
4

1 General information
This manual contains important instructions for the safe operation of the unit. Read and follow
the safety instructions and all other instructions. Keep the manual for future reference. Make
sure that it is available to all those using the device. If you sell the unit please make sure that
the buyer also receives this manual.
Our products are subject to a process of continuous development. Thus, they are subject to
change.
General information
PicoBeam 30 Quad LED
5

1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the
following points:
Download This manual is also available as PDF file for you to download.
Keyword search Use the search function in the electronic version to find the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
moving head
6

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’, ‘OFF’.
Text inputs that are carried out on the device are indicated by typewriter font.
Example: 2323
Letterings
Displays
Text input
General information
PicoBeam 30 Quad LED
7

References to other locations in this manual are identified by an arrow and the specified page
number. In the electronic version of the manual, you can click the cross-reference to jump to
the specified location.
Example: See
Ä
‘Cross-references’ on page 7.
1.3 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are
used in this manual.
Cross-references
General information
moving head
8

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates a pos-
sible dangerous situation that can result in death or serious
injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos-
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos-
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
General information
PicoBeam 30 Quad LED
9

Warning signs Type of danger
Warning – suspended load.
Warning – danger zone.
General information
moving head
10

2 Safety instructions
This device is intended to be used as moving-head spotlight. The device is designed for profes-
sional use and is not suitable for use in households. Use the device only as described in this
user manual. Any other use or use under other operating conditions is considered to be
improper and may result in personal injury or property damage. No liability will be assumed for
damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Intended use
Safety instructions
PicoBeam 30 Quad LED
11

DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Safety
Safety instructions
moving head
12

DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a pro-
tective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or fire. If in doubt, seek advice from a regis-
tered electrician.
WARNING!
Eye damage caused by high light intensity
Never look directly into the light source.
WARNING!
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons
should avoid looking at strobe lights.
Safety instructions
PicoBeam 30 Quad LED
13

CAUTION!
Risk of injury due to movements of the device
The head of the device can move quickly (pan, tilt) and can produce very bright
light. This is also valid immediately after you turn on the device, when the device
operates in automatic mode or under remote control and when you turn off a
DMX controller that is connected to the device. Persons staying near the device
could be injured or frightened.
Before you turn on the device and during the operation, always ensure that
nobody stays close to the device. If work has to be performed in the area of move-
ment or in the near vicinity of the device, it must remain turned off.
NOTICE!
Risk of fire
Do not cover the device nor any ventilation slots. Do not place the device near
any direct heat source. Keep the device away from naked flames.
Safety instructions
moving head
14

NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or fire.
Safety instructions
PicoBeam 30 Quad LED
15

3 Features
The moving head is particularly suitable for professional lighting tasks, for example at events,
on rock stages, in theatres and musicals, in nightclubs as well as for mobile DJ's and enter-
tainer.
Special features of the device:
nTwo movable axles with 8 or 16 bit resolution:
– Tilt (230°)
– Pan (540°)
nPan and Tilt invertible
n1 × 30 W High Performance RGBW QuadColour LED
nRGBW colour mixing
nVery narrow beam angle of only 4°
nControl via DMX (3, 8 or 13 channels) and via buttons and display on the unit
nAutomatic mode with 4 preprogrammed shows
nSound-to-Light with 4 built-in shows
nElectronic dimmer 0 to 100%
nShutter frequency 0…20 Hz
nOmega bracket and infrared remote control included
Features
moving head
16

4 Installation
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
WARNING!
Risk of injury by falling off
Make sure that the installation complies with the standards and rules that apply
in your country. Always secure the device with a secondary safety attachment,
such as a safety cable or a safety chain.
The carrying capacity of the truss or other mounting must be sufficient for the
intended number of devices. Note that the movement of the head may addition-
ally stress the load-bearing structures.
Installation
PicoBeam 30 Quad LED
17

CAUTION!
Risk of injury due to movements of the device
The head of the device can move quickly (pan, tilt) and can produce very bright
light. This is also valid immediately after you turn on the device, when the device
operates in automatic mode or under remote control and when you turn off a
DMX controller that is connected to the device. Persons staying near the device
could be injured or frightened.
Before you turn on the device and during the operation, always ensure that
nobody stays close to the device. If work has to be performed in the area of move-
ment or in the near vicinity of the device, it must remain turned off.
NOTICE!
Risk of overheating
Always ensure sufficient ventilation.
The ambient temperature must always be below 40 °C (104 °F).
Installation
moving head
18

NOTICE!
Possible damage caused by movements of the device
Always ensure that enough space is free around the device for the movements of
the head (pan, tilt).
NOTICE!
Possible data transmission errors
For error-free operation make use of dedicated DMX cables and do not use ordi-
nary microphone cables.
Never connect the DMX input or output to audio devices such as mixers or ampli-
fiers.
Installation
PicoBeam 30 Quad LED
19

Please note that this device must not be connected to a dimmer.
You can install the device on the wall, ceiling or floor.
The threads on the housing bottom are used to secure the supplied Omega bracket or truss
clamps.
Mounting options
