Seagull Models Seagull 2000 User manual

Specifications:
Wingspan------------------------------78.7in(200cm).
Wingarea-------------------488.3sq.in(31.5sqdm).
Weight---------------------------------------2.2lbs(1kg).
Length-------------------------------------37in(94.1cm).
Enginemotor ----------------------------------400-480.
Radio------------------------------------------4channels.
Servo-----------------3miniservos(23x12x24mm).
Propeller----------------------------------------------9x5.
Speedcontrol----------------------------------------30A.
Partslistingrequired(notincluded)
ASSEMBLY MANUAL
MS:130
“Graphics and specifications may change without notice”.

2
SEAGULL. Instruction Manual.
INTRODUCTION.
Thank you for choosing the SEAGULL 2000 ARTF by SEAGULL MODELS. The SEAGULL 2000
was designed with the sports trainer flyer in mind. It is a High-wing aeroplane which is easy to fly
andquicktoassemble.Theairframeisconventionallybuiltusingbalsa,plywoodandveneertomake
itstrongerthantheaverageARTF,yetthedesignallowstheaeroplanetobekeptlight.Youwillfind
that most of the work has been done for you already. The pushrods are pre-made to the correct
lengths, the motor mount has been fitted and the hinges are pre-installed and pinned for security.
Flying the SEAGULL 2000 is simply a joy.
This instruction manual is designed to help you build a great flying aeroplane. Please read this
manual throughly before starting assembly of your SEAGULL 2000. Use the parts listing below to
identify all parts.
WARNING.
Please be aware that this aeroplane is not a toy and if assembled or used incorrectly it is capable
of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU ASSUME ALL
RISK & RESPONSIBILITY.
IfyouareinexperiencedwithbasicR/CflightwestronglyrecommendyoucontactyourR/Csupplier
and join your local R/C Model Flying Club. R/C Model Flying Clubs offer a variety of training
proceduresdesignedtohelpthenew pilotonhisway tosuccessfulR/C flight.Theywillalso beable
to advise on any insurance and safety regulations that may apply.
ADDITIONAL ITEMS REQUIRED.
- motor 400 - 480
- 4 channel radio with 3 servos.
- Glow plug to suit engine.
- Propeller to suit engine.
- Protective foam rubber for radio
system.
- Silicone fuel line.
- Stick-on weights for balance
(If necessary).
TOOLS & SUPPLIES NEEDED.
- Thick cyanoacrylate glue.
- 30 minute epoxy.
- 5 minute epoxy.
- Hand or electric drill.
- Assorted drill bits.
-Modellingknife.
- Straight edge ruler.
- 2mm ball driver.
- Phillips head screwdriver.
- 220 grit sandpaper.
- 90° square or builder’s triangle.
- Wire cutters.
- Masking tape & T-pins.
- Thread-lock.
- Paper towels.
PARTS LISTING.
FUSELAGE ASSEMBLY
1) Fuselage.
WING ASSEMBLY
1) Right wing half with pre-installed
aileron.
2) Left winghalf withpre-installedaileron.
TAIL SECTION ASSEMBLY
1) Vertical stabilizer with pre-installed
rudder.
2) Horizontal stabilizer withpre-installed
elevartor halves.

3
Instruction Manual.
ELECTRIC POWER CONVERSION.
1) Locate the items neccessary to install the
electric power conversion included with your
model.
3.2mm.
3.2mm.

4
SEAGULL. Instruction Manual.
ELEVATOR SERVO.
Install the spinner backplate, propeller and
spinner cone.
The propeller should not touch any part
of the spinner cone. If it does, use a sharp
modeling knife and carefully trim away the
spinner cone where the propeller comes in
contact with it.
INSTALLING THE SPINNER.
Ply of wood.

5
Instruction Manual.
AILERON SERVO INSTALLATION.
Servos.
String.
Small weight.
1) Usingasmallweight(Weightedfuel pick-up
workswell)andstring, feedthestring through
the wing as indicated.
Because the size of servos differ, you
mayneedtoadjustthesizeoftheprecutopen-
ing in the mount. The notch in the sides of
themountallowtheservoleadtopassthrough.
C/Aglue.
Micro control connector.

6
SEAGULL. Instruction Manual.
3) Set the aileron hatch in place and use a
Phillips screw driver to install it with four wood
screws.
AILERONPUSHROD HORN INSTALLATION
2) A string has been provided in the wing to
pull the aileron lead through to the wing root.
Remove the string from the wing at the servo
location and use the tape to attach it to the
servoextensionlead.Pulltheleadthrough the
wing and remove the string.
Attach the string to the servo lead and carefully thread it though the wing.
M2x10mm.
M2x6mm.
Wing rib.
Wing.
Small weight.
String.

7
Instruction Manual.
3mm.
Cut.
WING ASSEMBLY.
Repeat the procedure for the other
aileron servo.
M2x10mm.

8
SEAGULL. Instruction Manual.
AILERON PUSHROD INSTALLATION.
VERTICAL STABILIZER
INSTALLATION.
M3x15mm.
12mm.

9
Instruction Manual.
3mm.
Cut.
M3x15mm.

10
SEAGULL. Instruction Manual.
ATTACHMENT WING-FUSELAGE.
INSTALLING THE BATTERY. Receiver.
1) Plugthefiveservoleads and the switch
lead into the receiver. Plug the battery pack
lead into the switch also.
 3) Route the antennain the antenna tube
insidethefuselageandsecure it to the bottom
of fuselage using a plastic tape.
2) Wrap the receiver and battery pack in
the protective foam rubber to protect them
from vibration.
Battery.
Speed control.
Cut.
C/Aglue.
INSTALLING THE RECEIVER.

11
Instruction Manual.
BALANCING.
 1) It is critical that your airplane be
balanced correctly. Improper balance will
cause your plane to lose control and crash.
THE CENTER OF GRAVITY IS LOCATED
60 MM BACK FROM THE LEADING EDGE
OF THE WINGAT THE WING ROOT.
 3) Turn the airplane upside down. Place
yourfingersonthemaskingtape and carefully
lift the plane .
 2)Mountthewingtothe fuselage. Using a
couple of pieces of masking tape, place them
on the top side of the wing 60 mm back from
the leading edge of the wing at the wing root.
Accurately mark the balance point on the top
of the wing on both sides of the fuselage. The
balance point is located 60 mm back from
the leading edge of the wing at the wing root.
This is the balance point at which your model
should balance for your first flights. Later, you
maywishto experiment byshiftingthebalance
up to 10mm forward or back to change the
flying characteristics. Moving the balance
forward may improve the smoothness and
arrow- like tracking, but it may then require
more speed for take off and make it more
difficult to slow down for landing. Moving the
balance aft makes the model more agile with
alighterandsnappier”feel”. Inanycase,please
start at the location we recommend .
*Ifpossible,firstattempt to balance the model
bychangingthe positionofthereceiverbattery
and receiver. If you are unable to obtain good
balance by doing so, then it will be necessary
toadd weight to the nose or tail toachieve the
proper balance point.
Withthewing attachedtothefuselage,allparts
ofthemodelinstalled( ready to fly),andempty
fuel tanks, hold the model at the
markedbalancepointwiththestabilizerlevel..
Lift the model. If the tail drops when you lift,
the model is “tail heavy” and you must add
weight* to the nose. If the nose drops, it is
“nose heavy” and you must add weight* to
the tail to balance.
Wing bolt.
CONTROL THROWS.
Ailerons: 12mm up 12mm down
Elevator: 10mm up 10mm down
60mm.

12
SEAGULL. Instruction Manual.
PREFLIGHT CHECK.
1) Completely charge your transmitter
and receiver batteries before your first day of
flying.
2) Check every bolt and every glue joint
in the SEAGULL 2000 to ensure that every-
thing is tight and well bonded.
5) If your radio transmitter is equipped
withdualrateswitchesdoublecheckthatthey
are on the low rate setting for your first few
flights.
6) Check to ensure the control surfaces
are moving the proper amount for both low
and high rate settings.
7) Check the receiver antenna. It should
be fully extended and not coiled up inside the
fuselage.
We wish you many safe and enjoyable
flights with your SEAGULL 2000.
8) Properlybalancethepropeller. Anout
of balance propeller will cause excessive vi-
bration which could lead to engine and/or air-
frame failure.
3) Double check the balance of the air-
plane. Do this with the fuel tank empty.
4) Checkthecontrolsurfaces. Allshould
move in the correct direction and not bind in
any way.
E) Check the throttle. Moving the
throttle stick forward should open the carbu-
retor barrel. If it does not, flip the servo re-
versing switch on your transmitter to change
the direction.
FLIGHT PREPARATION.
C) Check the elevator first. Pull back
on the elevator stick. The elevator halves
shouldmoveup. Ifittheydonot,fliptheservo
reversingswitchonyourtransmitter to change
the direction.
D) Check the rudder. Looking from
behind the airplane, move the rudder stick to
theright. Theruddershouldmovetotheright.
Ifitdoesnot,fliptheservoreversingswitchon
your transmitter to change the direction.
A) Check the operation and direction
of the elevator, rudder, ailerons and throttle.
B) Plug in your radio system per the
manufacture’sinstructionsandturneverything
on.
F) From behind the airplane, look at
the aileron on the right wing half. Move the
aileron stick to the right. The right aileron
should move up and the other aileron should
move down. If it does not, flip the servo re-
versing switch on your transmitter to change
the direction.
