SD Force Impulse Gundam User manual

http://yobee.tistory.com
SD Force Impulse Gundam (Craft Manual)
Brief of figure
Guide of Manual
- Total 10 pages (image files)
- Arranged with colors (for color paper user)
- Cutting lines is thicker than folding lines
- Paste ( ), Punch out ( )
- Marked with L(Left Part), R(Right Part), F(Front Part), R(Rear Part),
I(Inside Part), O(Outside Part)
- : Please make a craft in good order of these number
- Just explained one of the left part or right part (L & R)
- Please refer the ‘Attention’ before you make a each part
- The color of this manual is different with the real figure
* Height 13~14 cm
* Over 10 movable angles (Cockpit, Shield and etc.)
1

HEAD PART
Attention
Attention
Attention
1
2
3
1
2
2
34
5
6
6
1
2
3
4
1
2
3
4
A-1
A-13
A-14
A-7
A-8
A-12
H-3
A-9
H-2
A-2
A-4
A-5
A-6
D-2
A-3
A-15
A-15
1
Part
2
Part
1
Part
* Please make in order from to
* Important!! To make more fittable
joint, you have to decide the thickness
of A-6 & A-4. After you make up to ,
test the thickness A-4 with them.
If you make them tight as much as you
can, you will make the better joint even
thought it is paper.
* Important!! Please make A-6 & A-3
first. And then insert that part in D-2
before you make D-2 part.
* For A-7 & A-8, please refer the tips
of following web pages.
http://yobee.tistory.com/9
http://yobee.tistory.com/10
* Please make A-14 tightly in order to
be inserted in Part1.
* You can stick the paste part of A-14
at outside of A-13.
* Be careful of the craft order
1
6

Attention
Attention
Attention
Attention
4
5
6
7
1
12
3
1
1
2
3
4
4
1
1
2
2
3
A-26
A-18
A-19
A-20
A-11
A-10
A-21
A-22
A-16
A-17
A-34
A-24
A-31
H-16
H-1
A-28
A-25
4
Part
3
Part
6
Part
5
Part
6
Part
4
Part
* Craft like image.
* Craft like image.
* Craft like image.
* Craft like image.
Final

BODY PART
1
2
3
3
4
5
1
1
2
2
3
3
4
4
5
5
1
1
2
2
3
3
D-5
H-13
D-1
D-7 L
D-8
D-3
D-6
D-20 R
D-20 L
D-9 L
F-1 L
D-9 R
F-1 R
D-8
D-7 R
H-12 R J-6 R
H-12 L
J-6 L
D-4
2
Part
1
Part
2
Part
Attention
Attention
Attention
* Important!! Please make F-1, D-8 &
D-7 first. And then insert those parts
in D-9 before you make D-9 part.
Stick D-8 inside D-9.
* Stick H-12 behind J-6 not to be seen
outside.
* Craft like image.
* Attach Part 1 and 2 each other
* Stick D-6, 20 with D-3 and then put
it in the holes of Part 1 and 2.

LEFT LEG (R parts for Right side)
Attention
Attention
Attention
4
5
1
1
2
3
4
1
2
3
4
1
2
3
4
5
5
J-3
A-33
A-35
A-29
A-37
A-36
A-32 B-1
B-7
B-7
F-2 F-3
H-9
J-5
J-4
H-4
H-5
J-2
J-1
3
Part
4
Part
4
Part
* Make A-35 to be connected with H-5
tightly.
* Craft like image.
* Craft like image.
Final

Attention
Attention
Attention
2
3
4
1
2
2
3
4
4
5
1
2
3
45
6
78
1
2
B-2
B-15 B-14 B-11
B-10
B-6
B-8
B-9
F-4
F-5
D-10
B-3
B-5
B-4
B-5
F-10
F-11
F-11
F-6
3
Part
2
Part
1
Part
* Make F-10 to be connected with B-4
tightly.
* Craft like image.
* Craft like image.

WAIST PART
Attention
Attention
Attention
1
2
3
1
1
2
3
4
5
6
7
7
1
2
2
3
3
4
4
1
1
C-4 R
C-10 R
C-12 R
C-12 L
B-17
J-11
G-4
C-5
G-5
J-12 L
C-22 L
J-12 R
C-22 R
C-6
C-4 L
C-10 L
1
Part
1
Part
1
Part
* Important!! Please make C-6, C-10,
C-5, B-17 first. And then insert them
in J-11 before you make J-11 part.
* Craft like image.
* Craft like image.
Final

LEFT ARM (R parts for Right side)
Attention
Attention
Attention
1
2
3
1
2
3
4
1
2
3
4
5
1
2
2
3
4
4
F-17
F-16
F-18
F-25
F-27
F-29
F-23
F-24
C-1
C-3
F-19
F-19
F-15
F-28
F-26
F-28
B-12
1
Part
1
Part
2
Part
* Important!! Before you make F-27,
please make and insert the other parts
inside them.
* Please make F-29 tightly in order to
be inserted in F-16.
* Beofre you conplete F-17, please
make a next process.
Refer http://yobee.tistory.com/10
* Refer http://yobee.tistory.com/10
* Craft like image.

Attention
Attention
Attention
Attention
4
5
6
7
1
2
2
3
1
2
3
4
4
1
1
2
3
1
2
2
A-30
A-23
C-11
F-7
F-8
F-12
F-12
F-13
F-14
F-9
F-21
E-1
C-2 F E-2 F
C-2 R
E-2 R
I-26
A-30
B-13
3
Part
4
Part
5
Part
6
Part
6
Part
6
Part
* Make A-23 to be connected with
Part 3 tightly.
* Important!! Please make F-7 & F-8
first. And then insert that part in F-14
before you make F-14 part.
* Make F-9 to be connected with
Part 4 tightly.
* Craft like image.
* Craft like image.

COCKPIT PART
Attention
Attention
Attention
8
9
1
2
1
2
2
3
4
5
1
1
1
2
34
5
11
2
2
2
2
A-38
D-13
D-14 D-19
D-15
D-17
D-11 J-14 D-12
D-11
J-20
D-16
F-22
F-20
G-1
G-1
G-2
G-3
7
Part
8
Part
* Important!! Please make D-19,15,14,
16 first. And then insert them in D-13
before you make D-13 part.
Stick D-19 inside and D-14 outside.
* D-15 is different with real part.
* Insert D-12 across with J-14 & J-20.
And the stick with D-11.
* Craft like image.
Final

FORCE PACK PART
Attention
Attention
Attention
Attention
Final
3
4
5
1
1
1
2
23
3
4
4
1
2
3
1
2
3
4
5
5
1
223
3
4
C-14
J-13 R
D-18
J-17 R
J-17 L
C-13
I-9
I-10
J-9
J-10
C-7
C-8
I-2
I-13
I-14
I-28
I-27
I-11 R
I-11 L
I-12 L
H-10 L
I-12 R
H-10 R
C-9
H-6
J-13 L
C-14
1
Part
3
Part
2
Part
* Make D-18 to be connected with Part
2 tightly.
* Insert D-18 to Part 2, and then stick
J-13 with D-18 first. After that stick
C-14 to J-13 and D-18.
* Craft like image.
* Craft like image.
* Important!! Make C-7, 8 first, and
then insert them in J-10 before make
J-10.
* C-8 is outside
of J-10.
Final

3
4
1
2
1
2
3
4
5
5
6
I-1
C-18
C-17 L
C-19 L
I-17 L
I-30 L
I-18 L
I-29 L
C-16 L
H-11 L
B-16 L
2
Part
1
Part
Attention
Attention
Attention
* Important!! Please make I parts first.
And then insert them in I-5 before you
make I-5 part.
* I-19 is outside of I-5 and I-6 is inside
of I-5.
* Craft like image.
* Important!! Please make C-18 & C-19
first. And then insert that part in C-17
before you make C-17 part.
* Make C-19 to be connected with
Part 3 tightly.
2
1
1
2
2
3
3
4
5
6
6
7
7
8
8
9
9
10
10
I-3
I-4
I-6
I-5
I-6
I-31 R I-32 R I-31 L I-32 L
J-8 L
J-7 L
I-19 L
I-7 L
I-8 L
I-19 R
I-7 R
I-8 R
J-8 R
J-7 R

SHIELD PART
Attention
Attention
Attention
5
1
2
1
1
2
2
3
3
1
1
22
3
3
4
4
5
5
6
6
7
7
1
I-16 L I-15 L
C-25
C-24
C-24
C-21
C-20
G-11
G-12
C-25
C-23 L
C-23 R
I-15 R I-16 R
1
Part
3
Part
4
Part
4
Part
* Craft like image.
* Insert C-20, C-21 cross with C-23 &
G-11, and then stick C-25, C-24.
* Do not stick with G-11.
* Important!! Just use glue at the start
and end of arrows.
Final

Attention
Attention
Attention
3
4
5
1
2
1
2
34
5
6
7
8
1
2
3
5
6
G-15
H-14
H-15
I-21
I-22
I-23
G-14
G-13
G-13 G-10
G-10
G-9
G-9
G-7
G-6
G-8
G-10 G-14
I-20
H-7
H-8
2
Part
4
Part
3
Part
4
Part
4
Part
* Craft like image.
* Important!! Make I-20~23, H-7~8.
After that, make G-9, 10, 14 and insert
in I-20~23, H-7~8 without glue.
* Important!! Please make G-8, 7 first.
And then insert them in G-6 before you
make G-6 part.
* Connect Part 4 and Part 3 and stick
with G-10, 13.
* Important!! Totally stick for upside
G-13, but in case of downside G-13, Do
not stick with Part 3 (movable).
Final

Gun and Sword PART
Attention
Attention
Attention
Attention
1
2
3
4
1
2
345
6
1
2
3
4
5
6
6
7
8
9
1
1
1
G-18
G-19
G-24
G-30
I-24
G-26 G-21
G-25
G-20
I-25
G-16
G-17
J-19 R
J-19 L
J-15 J-16
J-18
G-22
G-23
G-28
G-29
G-27
1
Part
2
Part
* Craft like image.
* Make J-18 first to fit with Force Pack.
And then make J-15, 16 to fit with J-18.
* Craft like image.
* Important!! Please make other parts
first. and then insert them in G-18, 19
before you make G-18, 19 part.
* Stick iside G-23, G-24.
Final
Final
