Dynam P-51D Mustang User manual

Instruction Manual
Wingspan:
Overall Length:
Flying weight:
Servo:
Battery:
Speed Control:
Motor Size:
Charger :
47 in (1200mm)
41 in (1045mm)
38.8oz (1100 g)
9g 4pcs include
3S 11.1V 2200mAh Li-Po ,20c
30A brushless
850Kv Brushless Outrunner
3-cell Li-Po balancing

1

2

RTF INCLUDING
3
RTF including: fuselage
wing
elevator
landing gear
Vertical stabilizer
Push rod
Propeller
glue
decal
balance charger
LI-Po battery (11.1V 2200mAh 20C)
transmitter
Adaptor
Spinner
ESC

4
Apply the foam glue on the joiner of
the left and right landing gear, push
them in the position.
Fix the wing on fuselage with
PA2.3*20mm screw.
Insert the horizontal stabilizer and
vertical stabilizer in place.
Insert ¢8x406mm glass fiber tube into
left and right wing, and connect the
wings together.
Fix the rear landing gear on fuselage
with 1.5mm hexangular screwdriver.
Fix the stabilizers with PA 2.3*20mm
screw.

5
Install spinner with PA2.5*8mm screws.
Insert the pushrod into elevator
quick-controller and tighten the
screw(the servo should be in center
position).
Connect the aileron servos with Y wires.
Repeat the steps for the rudder.
Install the propeller.
Put the battery in position.

THROTTLE
RUDDER
ELEVATOR
AILERONS
airplane action
airplane action
airplane action
airplane action
control plane
movement
control plane
movement
Aileron
movement
6
STICK OPERATION
MODE 1 MODE 2 MOVEMENT

75
70
70 75 70 75
1107x3
7

8
1
25
11
7
8
13
12
23
25
20
14 15
18
19
11
3
34
22
24
2
5
6
Open the canopy

9
Wire lead shorts can cause fire! If you accidentally short the wires, the battery must be
placed in a safe area for observation for approximately 15 minutes.
After flight, the battery cool down to ambient temperature before charging.
observation

10

11
Once you have connected the charger to a power source,The red LED will turn on.
Connect the Li-Po battery pack to the charger.When the park is full charged.The
green LED will turn on.

Parts List
Fuselagep51d-01
TransmitterDYT-2002
p51d-02 wing
p51d-04 Elevator p51d-05 canopy
p51d-03 Vertical stabilizer
DY-1007 9g Servo
DY-3001 quick-controller
DY-6006 11.1V 2200mAh 20C Li-Po Battery
DYA-000X Adaptor
DYC-1002 Balance Charger
DYR-2001 2.4G Receiver
DY-3003 Glue
DECAL
12
p51d-08 Blade folderp51d-07 Propeller
p51d-11 Push rod
DYE-1003 30A ESC
p51d-10 Brushless Motor DYAT-008 Servo Horn
p51d-06 spinner
p51d-09 Landing gears
p51d-12 Bolt Pipe
p51d-13
