Seiki SC-45AU6DR User manual

4.5KG CLOTHES
DRYER
INSTRUCTION
MANUAL
MODEL: SC-45AU6DR
Please read this manual carefully before using, and keep it for future reference.

General Safety 4
Product Overview 8
Getting Started 10
Instructions 13
Operation 14
Other Useful Information 15
FAQS 16
Specifications 17
Customer Helpline 20
CONTENTS

4
Read this manual thoroughly before you start using the Clothes Dryers.
The safety precautions instructions reduces the risk of fire, electric shock and injury when
correctly complied to.
Please follow all instructions and take notice of all warnings.
ELECTRICAL SAFETY
• Voltage: Plug the appliance to a 220-240V, 50Hz, properly earthed power
outlet, it must be in good working order.
• Power connection: Do not use an adaptor or an extension cord.
Plug the power plug directly into a separate power point that cannot be
accidentally turned o, and that is easily accessible so you can switch it o
if needed.
• Power cord: Do not kink or damage the power supply cord. Make sure it is
behind the appliance so no one can step on or place anything on the power
supply cord or against it. A damaged power plug may overheat and cause a fire.
• Damaged cord: Do not use a cord that shows cracks or damage. Any damage
to the cord may cause a short circuit, fire and/or electric shock.
Contact our support centre on 1300 296 699 for advice
•Disconnection: Never pull the power cord to unplug appliance. Grip the plug and
pull straight out from the power point. After turning the device o, wait at least 2
minutes before turning the appliance back on again.
• Electrical work: If the installation of this appliance requires any electrical work,
make sure it is carried out by an electrician.
WARNING
Make sure your home is fitted with a residual current device (Safety Switch).
Pay close attention to messages that follow this safety alert symbol or the words
DANGER, WARNING or CAUTION. These words will be used to alert you of
potential hazards that and injure you and others. Following these instruction will
tell you how to reduce the chance of injury and the possible dangers if
instructions aren’t followed.
IMPORTANT INFORMATION
GENERAL SAFETY INSTRUCTIONS

5
To reduce risk of fire, electric shock or injury, always follow these basic precautions
and accident prevention measures when using this appliance, including the below:
INSTALLATION
• The product is heavy, be careful when moving it. To avoid back or other
injury, have 2 people lift or mechanical aid when installing.
• When unboxing, thoroughly inspect the appliance carefully for any
damage. If there is any damage, do not install the appliance. Contact our
support centre on 1300 296 699 for advice.
• While installing the appliance make sure that the power cord is not bent
or flattened.
• Install appliance on a flat level and stable ground.
• Do not install appliance in a tight fitted cabinet.
• Do not install appliance near other heat sources such as radiators, heaters or
direct sunlight.
• If not wall mounted, be sure that the appliance is not placed on any soft
materials such as plastics or foams.
GENERAL SAFETY INSTRUCTIONS (Cont.)
WARNING
Make sure that transport packaging is removed from the rear of the dryer. Do not
overload the dryer with too many clothes.

6
GENERAL SAFETY INSTRUCTIONS (Cont.)
USAGE CONDITIONS AND RESTRICTIONS
• Supervision over children is to ensure that they do not play with the
appliance. Never allow them to use, play with or crawl inside the appliance.
Cleaning and maintenance must not be done by children.
• This appliance is not to be used by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they are being supervised or been given instructions on how to use of the
appliance in a safe way and understand the hazards with using this
appliance incorrectly.
• Do not block any ventilation openings. Ensure that vents are not covered
by anything.
• Do not use this product for anything other than its intended purpose, and only
use it as described in this manual. Do not attempt to alter or modify
this appliance.
• Only load items that are suitable for the clothes dryer.
• Do not place any open source flames on the dryer such as candles, etc..
• The door/window will be hot after a long cycle, be sure not to touch the window
and to keep children away from the appliance.
• Never stop the clothes dryer before the cycle finishes, the last stage of the cycle
is a drying mode without heat to ensure items are left at a temperature that will
not damage them.
• The only part that can be changed is the filter, other than this nothing else in the
dryer contains user serviceable parts. Do not open, disasseble or try to repair the
appliance yourself. Only have this appliance serviced by a qualified technician.
• Incorrect use can result in property damage, injury or death. We assume no
liability for misuse of the appliance or noncompliance with these instructions.
WARNING
Never try to repair, modify or replace any part of the appliance, unless this manual
says you can do so. All other servicing is to be done by a qualified technician, or
contact our support centre on 1300 296 699 for advice.

7
GENERAL SAFETY INSTRUCTIONS (Cont.)
CAUTION
ITEMS BELOW ARE NOT SUITABLE FOR DRYING. IT CAN CAUSE FIRE IN
THE APPLIANCE OR EXTENSIVE DAMAGE. DO NOT PLACE FOLLOWING
IN THE APPLIANCE
• Items containing rubber or foam like rubber or any other similar
textured materials.
• Items that are spotted or soaked with cooking oil or any other flammable items.
These other items include kerosene, stain removers, dry-cleaning solvents,
alcohol, petrol, turpentine, waxes, hair care products, wax removers.
• Washing the items vigoursly beforehand in hot water with extra detergent will
reduce, but not completely eliminate the hazard.
• Undergarments that contain metal reinforcements (such as underwire bras).
Plastic articles such shower caps and waterproof bibs.
• Rubber-backed articles, clothes with foam rubber pads, pillows, galoshes and
rubber coated tennis shoes.
• Fabric softeners or similar products unless recommended by product
manufacturer for use in a clothes dryer.
• WARNING: Never stop a dryer before the end of the drying cycle unless all items
are quickly removed and spread out so that the heat is dissipated.
CAUTION
• Do not use the tumble dryer if industrial chemicals have been used for cleaning.
• Do not dry unwashed items in the dryer.
• Do not allow lint to accumulate around the tumble dryer. Clean the Lint Trap and
Filter after every use.
• Enough ventilation has to be provided to avoid the backflow of gases into the
room from appliances burning other fuels including open fires.
• Remove all objects from pockets such as lighters and matches.
If it is unavoidable that fabrics that contain vegetable or cooking oil or have been
contaminated by hair care products be placed in a tumble dryer they should first
be washed in hot water with extra detergent - this will reduce, but not eliminate
the hazard.
This symbol alerts you to take care as oil-aected items can ignite,
especially when exposed to heat, such as in a clothes dryer. The items
become warm, causing an oxidation reaction in the oil. Oxidation causes
heat. If the heat cannot escape, the items can become hot enough to
catch fire. Piling, stacking or storing oil-aected items can prevent heat
from escaping and so it will create a fire hazard.

8
PRODUCT OVERVIEW

9
PRODUCT OVERVIEW (Cont.)
CONTROL PANEL
AIR DRY: This function runs with cool air, primarily to air items that require
freshening i.e.: clothes that have been stored for a long time.
OFF: When the “Drying Timer” is on the “Off” position no power is supplied to
the unit. As soon as the dial is turned clockwise to the desired program the dryer
will start.
COOL: This function is generally used to cool the items that have just been dried.
This helps to prevent creasing. Instead of the motor pushing heat into the drum of
the dryer it will generate cool air.
WARM: Anti-Wrinkle function: This is used for items that are difficult to iron i.e.:
cotton shirts and linen. Using the heat selector knob choose “Half Heat”. Set the
drying timer to knob between 30-60 minutes depending the amount of items in
the dryer. Once the timer stops the items will still contain moisture, making the
ironing process easier.
HOT: For drying large quantities or bulky items (dryer drum is more than 1/2 full).
Select the “Full Heat” option and set the timer for more than 150 minutes.

10
Before installing your appliance, read all safety instructions in this manual,
especially the sections on electrical safety and installation.
INSTALLATION
• This clothes dryer can be installed on the floor (as supplied), or wall mounted.
• This appliance can not be installed behind a lockable door, sliding or a door
with a hinge on the opposite of the clothes dryer. In all ways that full opening of
clothes dryer door is strictly not allowed.
• Make sure that all electrical connections are made by qualified technicians and
all instructions in this manual are observed.
• Place the dryer in a dry, well ventilated area, away heat and direct sunlight.
• Exhaust air must not be discharged into the flue which is used for exhausting
fumes from appliances burning gas or other fuels.
• Make sure to allow 10cm of spacing behind the dryer to the wall.
GETTING STARTED
NOTE: The Dryer will not work correctly unless it is positioned perfectly level.
• Do not install the dryer in a place that can easily be reached by rain
• Do not place the back of the dryer near curtains.
• Do not place the dryer near gas or flammable areas.

11
Do not fix brackets to
plasterboard directly
Ensure brackets are
securely fastened. Fit
timber slats if necessary.
**Wall mounting continues on next page.
GETTING STARTED (Cont.)
WALL MOUNTING INSTRUCTIONS
• Ensure that the wall can adequately support the weight of the dryer.
• Ensure all fasteners used for wall mounted are of the correct type and can
support the weight of the dryer and load.
• If wall mounting above a washing machine make sure there is enough room for
the lid to open.
• Allows 5-10cm ontop of the dryer for ease of installation if you are installing the
appliance near the ceiling.
• If wall mounting dryer onto a plasterboard wall, make sure the brackets are
securely fitted to a timer stud, if the space between the studs is too wide,
fit a timber slat between the studs. (if using a timber slat, ensure you fit a
secondary slat at the bottom to align bottom spaces of the wall).
• If mounting to a masonry wall, use the correct anchoring bolts of a least a
minimum size of 8 x 40 mm.
The below instruction will guide you on the measurements needed to drill the
holes, the positioning of the hooks and support parts.
1. Determine dryer position on the wall and mark required bracket position. The
distance to mark between each bracket hole is 554 mm. (refer to figure 1)
2. Fix the wall hanging brackets (2 supplied) to the wall securely (into the stud/
timber slat). Fit a timber slat between the studs to mount the brackets onto the
stud if position is too wide.
12G x 8
Distance between
mounting holes
Fig. 1
Bottom Slat
Timber Slat

12
GETTING STARTED (Cont.)
3. Install exhaust pipe: Adjust the direction of the exhaust outlet either vertically or
horizontally. Use the small screws to secure the exhaust duct. As per fig.2.
4. Fix the 2 bottom spacers. 5. With assistance, mount dryer on the wall
by aligning the hooks of the brackets with the
slots on the top rear of the dryer.
Fig. 2
Fig. 3

13
LOADING THE DRYER
• Before loading the dryer, check that none of the clothes you are inserting into
the dryer have any symbols anywhere on them. These symbbols indicate that
there are not suitable for clothes drying.
• Make sure none of the items you are putting into the dryer have no combustible
materials or foreign objects (such as coins, hair pins or lighters). Be sure to
empty pockets of everything before putting into the dryer.
• Clean the filter before each use and make sure its properly back in palce.
• To avoid items getting tangled in the dryer which can reduce drying
performance, please insert items into the dryer one at a time.
• Turn items with cippers inside out and fasten buckles, as this will help to reduce
impact noise with items hitting the drum while spinning.
• Make sure to check items for stains before inserting into the dryer, as drying
can permenantly set stains.
• As you dry large blankets or sheets from time to time open the dryer door take
out the blanket or sheet and give it a shake then place back into the dryer. This
will help larger items with drying process.
WARNING: Do not overload the dryer, maximum amount of items that can be
dried in one load is 4.5kg.
• Make sure only items that have been washed and are still we are placed in
the dryer, no items that are dry are to be placed in.
• Be sure when closing the dryer door that not items are jammed in the door.
• Do not add items to the dryer while it is operating.
CAUTION!
Make sure you read all safety precaution in this manual that cause a hazard if
placed in the clothes dryer.
INSTRUCTIONS

14
OPERATION
DRYING CLOTHES
Drying times is affected by many different factors, such as the type of materials
used in the clothing, bulkiness of the items and how full the dryer is, etc...

15
OTHER USEFUL INFORMATION
REMOVING THE FILTERS
Remove by pulling outwards, inserted into the four holes around the
exhaust vent shroud. The filter is in 3 parts: Exhaust vent Shroud, lint filter
and exhaust filter.
CLEANING THE FILTERS
Seperate the 3 filters, Clean the lint on the lint filter and exhaust filter with a soft
brush of vacuum cleaner. becareful to not damage the filters.
RE-INSTALLING THE FILTERS
After cleaning, assemble in the exact order as below to go back into the dryer,
align the recesses in the centre with centre of the drum. Make sure it is firmly
inserted as shown in the figure below)
NOTE:
The filter fixed in the
bottom of the drum
should also be cleaned
with a soft brush.

16
FAQS
TROUBLESHOOTINTING GUIDE
Use the below list to identify if your clothes dryer is having any issues and to
identify and solve any problems. If you cannot solve the problem, contact our call
centre on 1300 296 699.
PROBLEM POSSIBLE CAUSE SOLUTION
No response from
buttons
Power plug
inserted correctly?
Ensure that the power plug
is firmly connecting into the
power socket.
The drum is not
turning
Is the door closed correctly?
Is the power plug firmly
connected?
Does the power socket have power?
Close the door.
Insert the plug correctly.
Check with another
appliance to see if power is
running to socket.
The load did not
dry correctly
Too much washing in the dryer?
Were the items added mid
drying cycle?
Has the washing been twisted while
drying?
Check and clean the filters
Reduce the amount of
washing in the dryer.
Untwist the items and dry
them for a little longer.
The Dryer isnt
starting
No power?
Is the power plug in correctly?
Is the door closed?
Have you selected a program?
Is the power switched on at the wall?
Check and try again when
the power is back.
Insert the power plug firmly.
Closed the door correctly.
Set a drying program.
Switch on power at the wall.

17
NOTE: The rated capacity is maximum capacity, make sure that the dry clothes
which are loaded in to the appliance do not exceed the rated capacity each time.
SPECIFICATIONS
Dimensions 595 x 438 x 671 mm
Weight 20kg
Rated Input Power 220-240V ~ 50Hz / 1200W
Rated Volume of Dryer 4.5kg (dry clothes)

18

19

20
CUSTOMER HELPLINE:
1300 296 699
DISTRIBUTED BY:
Ayonz Pty Ltd
