W10849532D
DRYER INSTALLATION INSTRUCTIONS
737 mm (29") Wide Models – Gas & Electric
INSTRUCTIONS D’INSTALLATION DU SECHE-LINGE
Modèles de 737 mm (29") de largeur – À gaz et Électrique
INSTRUCCIONES DE INSTALACIÓN DE LA SECADORA
Modelos de 737 mm (29") – A gas y eléctrica
ISTRUZIONI DI INSTALLAZIONE DELL’ASCIUGATRICE
Modelli da 737 mm (29") – A gas ed elettrici
TROCKNER – INSTALLATIONSANWEISUNGEN
737 mm (29 Zoll) breite Modelle – Gas und Elektro
TABLE OF CONTENTS (Original Instructions)
TABLE DES MATIÈRES (Instructions d’origine)
DRYER SAFETY ........................................................................................ 2
SPECIFICATIONS...................................................................................... 4
INSTALLATION REQUIREMENTS............................................................ 5
ELECTRIC DRYER POWER HOOKUP..................................................... 7
INSTALL LEVELING LEGS........................................................................ 8
GAS DRYER POWER HOOKUP ............................................................... 8
ELECTRICAL REQUIREMENTS............................................................. 10
ELECTRICAL CONNECTION ................................................................. 10
ÍNDICE (Instrucciones originales)
SÉCURITÉ DU SECHE-LINGE ............................................................... 22
CARACTERISTIQUES............................................................................. 24
EXIGENCES D’INSTALLATION .............................................................. 25
RACCORDEMENT À L’ALIMENTATION ÉLECTRIQUE
DU SECHE-LINGE ÉLECTRIQUE........................................................... 28
INSTALLATION DES PIEDS DE NIVELLEMENT ................................... 29
RACCORDEMENT D’UN SECHE-LINGE À GAZ................................... 29
SPÉCIFICATIONS ÉLECTRIQUES.......................................................... 31
RACCORDEMENT ÉLECTRIQUE........................................................... 31
SEGURIDAD DE LA SECADORA ........................................................... 44
ESPECIFICACIONES .............................................................................. 46
REQUISITOS DE INSTALACIÓN ............................................................ 47
CONEXIÓN DE ENERGÍA DE LA SECADORA ÉLECTRICA................. 50
INSTALACIÓN DE LAS PATAS NIVELADORAS..................................... 51
CONEXIÓN DE ENERGÍA DE LA SECADORA A GAS .......................... 52
REQUISITOS ELÉCTRICOS ................................................................... 53
CONEXIÓN ÉLECTRICA......................................................................... 54
VENTILACIÓN ......................................................................................... 57
VENTING.................................................................................................. 13
MAKE GAS CONNECTION..................................................................... 16
CONNECT VENT ..................................................................................... 17
LEVEL DRYER......................................................................................... 17
POWER CORD INSTALLATION.............................................................. 18
COMPLETE INSTALLATION CHECKLIST ............................................. 18
REVERSE DOOR SWING (OPTIONAL) .................................................. 19
TROUBLESHOOTING............................................................................. 21
L’ÉVACUATION........................................................................................ 34
RACCORDEMENT AU GAZ.................................................................... 38
RACCORDEMENT DU CONDUIT D’ÉVACUATION .............................. 38
RÉGLAGE DE L’APLOMB DU SECHE-LINGE....................................... 39
INSTALLATION DU CORDON D’ALIMENTATION................................. 39
ACHEVER L’INSTALLATION – LISTE DE VÉRIFICATION..................... 40
INVERSION DU SENS DE L’OUVERTURE
DE LA PORTE
(FACULTATIF)
.................................................................. 41
DÉPANNAGE ........................................................................................... 43
CONEXIÓN DEL SUMINISTRO DE GAS................................................ 60
CONEXIÓN DEL DUCTO DE ESCAPE................................................... 61
NIVELACIÓN DE LA SECADORA........................................................... 61
INSTALACIÓN DEL CABLE ELÉCTRICO .............................................. 62
LISTA DE CONTROL DE LA INSTALACIÓN TERMINADA ................... 63
CAMBIO DEL SENTIDO DE ABERTURA
DE LA PUERTA (OPCIONAL).................................................................. 63
SOLUCIÓN DE PROBLEMAS................................................................. 66
SOMMARIO (Istruzioni originali)
SICUREZZA DELL’ASCIUGATRICE....................................................... 67
SPECIFICHE............................................................................................ 69
REQUISITI PER L’INSTALLAZIONE....................................................... 70
ALLACCIAMENTO DELL’ASCIUGATRICE ELETTRICA
ALL’ALIMENTAZIONE ............................................................................ 72
INSTALLAZIONE DEI PIEDINI DI MESSA IN PIANO ............................ 73
ALLACCIAMENTO DELL’ASCIUGATRICE A GAS
ALL’ALIMENTAZIONE............................................................................. 73
REQUISITI ELETTRICI............................................................................ 75
COLLEGAMENTO ELETTRICO.............................................................. 75
SISTEMA DI SFIATO ............................................................................... 78
COLLEGAMENTO ALL’IMPIANTO A GAS............................................. 81
COLLEGAMENTO ALLO SFIATO........................................................... 82
MESSA IN PIANO DELL’ASCIUGATRICE.............................................. 82
INSTALLAZIONE DEL CAVO DI ALIMENTAZIONE............................... 83
COMPILAZIONE DELLA CHECKLIST DI INSTALLAZIONE ................. 83
INVERSIONE DELL’APERTURA DELLO SPORTELLO (OPZIONALE)
................ 84
RISOLUZIONE DEI PROBLEMI.............................................................. 86
INHALTSVERZEICHNIS (Originalanweisungen)
SICHERHEIT DES TROCKNERS............................................................ 87
SPEZIFIKATIONEN ................................................................................. 89
INSTALLATIONSANFORDERUNGEN .................................................... 90
ELEKTROTROCKNER – ELEKTRISCHER ANSCHLUSS ..................... 92
STELLFÜSSE INSTALLIEREN................................................................ 93
GASTROCKNER – ELEKTRISCHER ANSCHLUSS............................... 93
ELEKTRISCHE ANFORDERUNGEN...................................................... 95
ELEKTRISCHER ANSCHLUSS .............................................................. 95
ENTLÜFTUNGSSYSTEM........................................................................ 98
GASANSCHLUSS HERSTELLEN......................................................... 101
ENTLÜFTUNGS ANSCHLIESSEN........................................................ 102
TROCKNER NIVELLIEREN................................................................... 102
INSTALLATION DES NETZKABELS..................................................... 103
KOMPLETTE INSTALLATIONS-CHECKLISTE.................................... 103
TÜRANSCHLAG WECHSELN (OPTIONAL)......................................... 104
FEHLERBEHEBUNG............................................................................. 106
2
DRYER SAFETY
CAUTION – RISK OF FIRE/FLAMMABLE MATERIALS
This is an additional safety alert symbol that alerts you to the risk of re.
3
FOR YOUR SAFETY
1. DO NOT USE OR STORE PETROL OR OTHER FLAMMABLE MATERIALS IN THIS APPLIANCE OR
NEAR THIS APPLIANCE.
2. DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN OPERATION.
3. DO NOT MODIFY THIS APPLIANCE.
n
Remove all objects from pockets, such as lighters and
matches, before placing items in the dryer.
nBefore the dryer is removed from service or discarded,
remove the doors to the drying compartment.
nDo not reach into the dryer if the drum is moving.
A door switch is tted for your safety.
nDo not install or store the dryer where it will be exposed
to the weather.
nDo not tamper with controls.
nDo not continue to use this appliance if it appears
to be faulty.
nDo not repair or replace any part of the dryer or attempt
any maintenance unless specically recommended in the
Use and Care Guide. Repairs and servicing should only
be carried out by competent service personnel.
nDo not use fabric softeners or products to eliminate static
unless recommended by the manufacturer of the fabric
softener or product. Follow their instructions.
nClean dryer lint screen before or after each load.
Do not operate dryer without lint screen in place.
nKeep area around the exhaust and inlet openings and
adjacent surrounding areas free from the accumulation
of lint, dust, and dirt.
nThe interior of the dryer and exhaust vent should be
cleaned periodically by qualied service personnel.
nSee “Electrical Requirements” for earthing instructions.
nDo not dry unwashed items in this dryer.
nThe nal part of a tumble dryer cycle occurs without heat
(cool down cycle) to ensure that the items are left at a
temperature that ensures the items will not be damaged.
nItems such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles, and clothes
or pillows tted with foam rubber pads must only be dried
on a clothesline.
nIf the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualied
person in order to avoid a hazard.
WARNING: Never stop a tumble dryer cycle before the
end of the drying cycle unless all items are quickly removed
and spread out so that the heat is dissipated.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of re, electric shock, or injury to persons when using the dryer, follow basic precautions,
including the following:
SAVE THESE INSTRUCTIONS
nRead all instructions before using the dryer.
nKeep a minimum clearance of 100 mm (4 in.) between
the rear of the dryer and any wall.
nThe operation of this appliance may affect the operation
of other types of appliances which take their air supply
for safe combustion from the same room. There has to
be adequate ventilation to replace exhausted air and
thus avoid the back-ow of gases into the room from
appliances burning other fuels, including open res,
when operating the tumble dryer. If in doubt, consult
the appliance manufacturers.
nDo not obstruct the air supply to the dryer (see
Installation Instructions for minimum clearances).
nDo not place items exposed to cooking oils in your dryer.
Oil-affected items can ignite spontaneously, especially
when exposed to heat sources such as in a tumble dryer.
The items become warm causing an oxidation reaction in
the oil. Oxidation creates heat. If the heat cannot escape,
the items can become hot enough to catch re. Piling,
stacking or storing oil-affected items can prevent heat
from escaping and so create a re hazard.
nIf it is unavoidable to dry in the dryer items that have
been soiled with substances such as cooking oil,
acetone, alcohol, petrol, kerosene, spot removers,
turpentine, waxes and wax removers, or that have
been contaminated by hair care products, they should be
washed in hot water with an extra amount of detergent
before being dried in the dryer. These items may give off
vapours that could ignite or explode. Such washing will
reduce, but not eliminate, the hazard.
nThis appliance is not intended for use by persons
(including children under 8 years of age) with reduced
physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been
given supervision or instructions concerning use of
the appliance by persons responsible for their safety.
nCleaning and user maintenance by children must be
supervised.
nChildren should be supervised to ensure that they do not
play with the appliance.
nChildren less than 3 years of age should be kept away
from the appliance unless continuously supervised.
nThe dryer should not be used if industrial chemicals have
been used for cleaning.
4
IMPORTANT SAFETY INSTRUCTIONS
precautions, including the following:
WARNING:
Read all instructions before using the dryer.
Keep a minimum clearance of 100 mm (4 in.) between the
rear of the dryer and any wall.
The operation of this appliance may affect the operation of
other types of appliances which take their air supply for safe
combustion from the same room. There has to be adequate
ventilation to replace exhausted air and thus avoid the
back-ow of gases into the room from appliances burning
other fuels, including open res, when operating the tumble
dryer. If in doubt, consult the appliance manufacturers.
Do not obstruct the air supply to the dryer (see Installation
Instructions for minimum clearances).
Do not place items exposed to cooking oils in your dryer.
Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer. The
items become warm causing an oxidation reaction in the oil.
Oxidation creates heat. If the heat cannot escape, the items
can become hot enough to catch re. Piling, stacking or
storing oil-affected items can prevent heat from escaping
and so create a re hazard.
If it is unavoidable to dry in the dryer items that have been
soiled with substances such as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers, turpentine, waxes and wax
removers, or that have been contaminated by hair care
products, should be washed in hot water with an extra
amount of detergent before being dried in the dryer. These
items may give off vapours that could ignite or explode. Such
washing will reduce, but not eliminate, the hazard.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instructions concerning
use of the appliance by persons responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
The dryer should not be used if industrial chemicals have
been used for cleaning.
Before the dryer is removed from service or discarded,
remove the doors to the drying compartment.
Do not reach into the dryer if the drum is moving. A door
switch is tted for your safety.
Do not install or store the dryer where it will be exposed
to the weather.
Do not tamper with controls.
Do not continue to use this appliance if it appears to be
faulty.
Do not repair or replace any part of the dryer or attempt
any maintenance unless specically recommended in this
Use and Care Guide. Repairs and servicing should only
be carried out by competent service personnel.
Do not use fabric softeners or products to eliminate static
unless recommended by the manufacturer of the fabric
softener or product. Follow their instructions.
Clean dryer lint screen before or after each load. Do not
operate dryer without lint screen in place.
Keep area around the exhaust and inlet openings and
adjacent surrounding areas free from the accumulation of
lint, dust, and dirt.
The interior of the dryer and exhaust vent should be
cleaned periodically by qualied service personnel.
See Installation Instructions for earthing instructions.
Do not dry unwashed items in this dryer.
Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes or
pillows tted with foam rubber pads must only be dried
on a clothesline.
SAVE THESE INSTRUCTIONS
WARNING: Never stop a tumble dryer cycle before the
end of the drying cycle unless all items are quickly removed
and spread out so that the heat is dissipated.
To reduce the risk of re, electric shock, or injury to persons when using the dryer, follow basic
The nal part of a tumble dryer cycle occurs without heat
(cool down cycle) to ensure that the items are left at a
temperature that ensures the items will not be damaged.
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualied
person in order to avoid a hazard.
4
This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment
(WEEE).
By ensuring this product is disposed of correctly, you will help avoid potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of this product.
The symbol on the product, or on the documents accompanying the product, indicates that this appliance may not be
treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical
and electronic equipment.
Disposal must be carried out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please contact your local city ofce,
your household waste disposal service or the shop where you purchased the product.
SPECIFICATIONS
These units are sold in multiple regions with different
requirements for measuring capacity. Below are a few
of the valid forms of measure posted on this product:
Dry Linen Capacity: A weight measure that reects
a maximum load size that can be loaded into the dryer.
IEC Capacity: The capacity measure that represents the
maximum capacity of dry linens and textiles which the
manufacturer declares can be treated in a specic cycle.
Dry Linen Capacity
15 kg (33 lb)
IEC Capacity
7 kg (15 lb)
5
Tools and Parts
Gather the required tools and parts before starting installation.
Tools needed for all installations:
Level
Tape measure
Pliers
Parts package is located in dryer drum. Check that all parts
are included.
Parts needed:
Check local codes. Check existing electrical supply and venting.
See “Electrical Requirements” and “Venting Requirements”
before purchasing parts.
Check code requirements. Some codes limit, or do not permit,
installing dryer in garages, closets, mobile homes, or sleeping
quarters. Contact your local building inspector.
Optional Equipment: (Not supplied with dryer)
Refer to your Use and Care Guide for information about
accessories available for your dryer.
Parts supplied:
Flat-blade screwdriver #2 Phillips screwdriver
Adjustable wrench that
opens to 25 mm (1") or
hex-head socket wrench
Tin snips (new vent
installations)
Caulking gun and
compound (for installing
new exhaust vent)
Vent clamps
6 mm (1/4") nut driver
or socket wrench
(recommended)
Leveling legs (4)
Tools needed for gas installations:
203 mm or 254 mm
(8" or 10") pipe wrench 203 mm or 254 mm
(8" or 10") adjustable wrench
(for gas connections)
Pipe-joint compound
resistant to propane gas
Utility knife
INSTALLATION REQUIREMENTS
Putty knife
Plugs and cord lock cover
(supplied with some
models only)
6
Dryer Dimensions
Location Requirements
You will need:
nA location allowing for proper exhaust installation.
See “Venting Requirements.”
nA separate 30-amp circuit for electric dryers.
nA separate 15- or 20-amp circuit for gas dryers.
nIf you are using power supply cord, a earthed electrical outlet
located within 610 mm (2 ft.) of either side of dryer.
See “Electrical Requirements.”
nA sturdy oor to support dryer and a total weight
(dryer and load) of 90.7 kg. (200 lbs). The combined weight
of a companion appliance should also be considered.
nLevel oor with maximum slope of 25 mm (1") under entire
dryer. If slope is greater than 25 mm (1"), install Extended
Dryer Feet Kit, Part Number 279810. If not level, clothes
may not tumble properly and automatic sensor cycles
may not operate correctly.
Do not operate your dryer at temperatures below 7°C (45°F).
At lower temperatures, the dryer might not shut off at the end
of an automatic cycle. Drying times can be extended.
The dryer must not be installed or stored in an area where
it will be exposed to water and/or weather.
Check code requirements. Some codes limit, or do not permit,
installation of the dryer in garages, closets, mobile homes,
or sleeping quarters. Contact your local building inspector.
NOTE: No other fuel-burning appliance can be installed
in the same closet as a dryer.
Installation clearances:
The location must be large enough to allow the dryer door
to open fully.
Do not install behind a lockable door, a sliding door, or a door
with a hinge on the side opposite to that of the dryer in a way
that will restrict the full opening of the dryer door.
Most installations require a minimum 140 mm (5½") clearance
behind the dryer for the exhaust vent with elbow. See “Venting
Requirements.”
A. Wide-opening side-swing door
B. Wide-opening hamper door
NOTE: Leveling legs should be 13 mm (1/2") (to match height
of 0.102 m3 [3.6 cu. ft.] capacity washer) or 38 mm (1½")
(to match height of 0.108 m3 [3.8 cu. ft.] capacity washer).
29"
(737 mm)
433/8"
(1102 mm)
1/2"
(13 mm)
29"
(737 mm)
11/2"
(38 mm)
433/8"
(1102 mm)
13 mm
(1⁄2")
737 mm
(29")
1102 mm
(433⁄8")
737 mm
(29")
1102 mm
(433⁄8")
38 mm
(11⁄2")
A B
223/4"
(578 mm) 273/4"
(705 mm) 273/4"
(705 mm)
133/4"
(349 mm)
1/2"
(13 mm)
578 mm
(223⁄4") 705 mm
(273⁄4")
349 mm
(133⁄4") 705 mm
(273⁄4")
13 mm
(1⁄2")
Installation Spacing
A. Recessed area
B. Side view—closet or conned area
C. Closet door with vents
*Required spacing
ABC
18"*
(457 mm)
1"
(25 mm)
29"
(737 mm) 1"
(25 mm)
1"*
(25 mm)
14" max.*
(356 mm)
27¾"
(705 mm)
48 in.
(310 cm )
2*2
3"*
(76 mm)
3"*
(76 mm)
24 in.
(155 cm )
2 *
2
457 mm*
(18")
25 mm
(1") 25 mm
(1")
356 mm*
(14" max.)
25 mm*
(1") 140 mm
(51⁄2")
310 cm2*
(48 in.2)
155 cm2*
(24 in.2)
76 mm*
(3")
76 mm*
(3")
737 mm
(29")
705 mm
(273⁄4")
A B C
7
ELECTRIC DRYER
POWER HOOKUP
Electrical Requirements
Installation spacing for recessed area or closet
The dimensions shown are for the minimum spacing allowed.
n Additional spacing should be considered for ease of
installation and servicing.
n Additional clearances might be required for wall, door,
and oor moldings.
n Additional spacing of 25 mm (1") on all sides of the dryer
is recommended to reduce noise transfer.
n For closet installation, with a door, minimum ventilation
openings in the top and bottom of the door are required.
Louvered doors with equivalent ventilation openings are
acceptable.
n Companion appliance spacing should also be considered.
Mobile home – Additional installation requirements
This dryer is suitable for mobile home installations. The
installation must conform with local codes and ordinances.
n Metal exhaust system hardware, available for purchase.
n Special provisions must be made in mobile homes to
introduce outside air into the dryer. The opening (such
as a nearby window) should be at least twice as large
as the dryer exhaust opening.
This dryer is supplied without an electric cord and plug.
It must be connected by a competent electrician to a single-
phase electricity supply at the voltage shown on the dataplate,
using a suitable xed wiring installation in accordance with local
and national wiring regulations.
nA 3-wire circular cord of minimum conductor size 4 mm2
cross-section area should be used.
nA 30A supply fuse should be used, and a switch having
a contact separation in both poles that provides full
disconnection under over-voltage category III conditions
must be incorporated into the xed wiring in accordance
with local wiring regulations. The dryer should be positioned
so that the disconnection switch is clearly visible and easily
accessible to the user. This disconnection switch also
provides the function of an emergency stop control
for the user.
nA cord clamp bush is provided on the dryer and should
be tightened on completion of wiring. The electrical mains
terminals are located behind the small rear access panel
(terminal block cover), and connections should be made
in accordance with the terminal markings. Remember to
replace the terminal access panel (terminal block cover).
NOTE: In accordance with the European EMC Directive
(2014/30/EU), the maximum electricity supply system impedance
to which the electric dryer should be connected is declared
to be 0.191 + j0.119 Ohms.
NOTE: Electrical safety standards: The manufacturer has
chosen compliance with IEC/EN.60335 standards as the most
appropriate for this product.
This is 3-wire appliance which must be earthed.
If codes permit and an additional earth bond wire is used,
it is recommended that a qualied electrician determine that
the earth bond path is adequate.
Recommended earthing method
It is your responsibility to contact a qualied electrical installer
to ensure that the electrical installation is adequate and in
conformance with all local codes and ordinances.
8
INSTALL LEVELING LEGS
1. Prepare dryer for leveling legs
To avoid damaging oor, use a large at piece of cardboard
from dryer carton; place under entire back edge of dryer.
Firmly grasp dryer body (not console panel) and gently lay
dryer down on cardboard.
GAS DRYER POWER HOOKUP
Gas Supply Requirements
Gas type
Natural gas:
This dryer is equipped for use with Natural Gas. It is design-
certied by CSA International for propane or butane gases with
appropriate conversion.
nYour dryer must have the correct burner for the type of gas
in your home. Burner information is located on the rating
plate in the door well of your dryer.
Propane gas conversion:
Conversion must be made by a qualied technician.
No attempt shall be made to convert the dryer from the gas
specied on the model/serial rating plate for use with a different
gas without consulting the serving gas supplier.
IMPORTANT: The gas installation must conform with local codes.
2. Screw in leveling legs
Using a wrench and tape measure, screw legs into leg
holes until bottom of foot is approximately 13 mm (1/2")
(to match height of 0.102 m3 [3.6 cu. ft.] capacity washer) or
38 mm (1½") (to match height of 0.108 m3 [3.8 cu. ft.] capacity
washer) from bottom of dryer.
Now stand the dryer on its legs. Slide the dryer until it is
close to its nal location. Leave enough room for electrical
connection and to connect the exhaust vent.
For mobile home use
Gas dryers must be securely fastened to the oor.
Mobile home installations require a Mobile Home Installation
Hold-down Kit. For ordering information, please reference
the Use and Care Guide.
9
Gas supply line
n13 mm (1/2") NPT pipe is recommended.
n9.5 mm (3/8") approved tubing is acceptable for lengths
under 6.1 m (20 ft.) if local codes and gas supplier permit.
nMust include 3.2 mm (1/8") NPT minimum plugged tapping
accessible for test gauge connection, immediately upstream
of the gas connection to the dryer (see illustration).
nMust include a shut-off valve.
The shut-off valve location should be easy to reach for opening
and closing.
A
B
E
D
C
A. 9.5 mm (3/8") exible gas connector
B. 9.5 mm (3/8") pipe to are adapter tting
C.3.2 mm (1/8") NPT minimum plugged tapping
D. 13 mm (1/2") NPT gas supply line
E. Gas shut-off valve
Gas supply connection requirements
There are many methods by which your gas dryer can be
connected to the gas supply. Listed here are some guidelines
for two different methods of connection.
This dryer must be connected to the gas supply line with
a listed exible gas connector that complies with the standard
for connectors for gas appliances, CSA 6.10.
Option 1 (Recommended Method)
Flexible stainless steel gas connector:
nIf local codes permit, use a new exible stainless steel gas
connector (Design Certied by CSA International) to connect
your dryer to the rigid gas supply line. Use an elbow and
a 9.5 mm (3/8") are x 9.5 mm (3/8") NPT adapter tting
between the stainless steel gas connector and the dryer
gas pipe, as needed, to prevent kinking.
Option 2 (Alternate Method)
Approved aluminum or copper tubing:
nLengths over 6.1 m (20 ft.) can use 9.5 mm (3/8") approved
tubing (if codes and gas supplier permit).
nIf you are using Natural Gas, do not use copper tubing.
n9.5 mm (3/8") are x 9.5 mm (3/8") NPT adapter tting
between dryer pipe and 9.5 mm (3/8") approved tubing.
nLengths over 6.1 m (20 ft.) should use larger tubing and
a different size adapter tting.
nIf your dryer has been converted to use propane gas, 9.5 mm
(3/8") propane compatible copper tubing can be used. If the
total length of the supply line is more than 6.1 m (20 ft.), use
larger pipe.
NOTE: Pipe joint compounds that resist the action of
propane gas must be used. Do not use TEFLON®† tape.
Dryer gas pipe
nThe gas pipe that comes out through the rear of your dryer
has a 9.5 mm (3/8") male pipe thread.
A
1¼"
(32 mm)
9¼"
(235 mm)
A. 9.5 mm (3/8") NPT dryer pipe
Burner input requirements
Elevations up to 3,048 m (10,000 ft.):
nThe design of this dryer is certied by CSA International for
use at altitudes up to 3,048 m (10,000 ft.) above sea level at
the BTU rating indicated on the model/serial number plate.
Burner input adjustments are not required when the dryer is
operated up to this elevation.
Elevations above 3,048 m (10,000 ft.):
nWhen installed above 3,048 m (10,000 ft.), a 4% reduction
of the burner BTU rating shown on the model/serial
number plate is required for each 305 m (1,000 ft.)
increase in elevation.
Gas supply pressure testing
nThe dryer must be disconnected from the gas supply piping
system during pressure testing at pressures greater than
352 kg/m2(1/2 psi).
†®TEFLON is a registered trademark of Chemours.
32 mm
(11⁄4")
235 mm
(91⁄4")
10
ELECTRICAL REQUIREMENTS
EARTHING INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Electrical Connection Options
1. Choose electrical connection type
Direct wire connection: Go to steps 1–2
on page 11 for direct wire strain relief, then
steps 3–7 in “Direct Wire Connection”
section. Then go to “Venting Requirements.”
Power supply cord: Go to steps 1–2 on
page 11 for power supply cord strain relief,
then steps 3–5 in “Power Supply Cord
Connection” section. Then go to “Venting
Requirements.”
A
BCD
E
2. Remove terminal block cover
Before you start, disconnect power. Remove terminal block
cover (A).
A. Terminal block cover
B. Active screw
C. Ground screw
D. Neutral screw
E. Strain relief hole
ELECTRICAL CONNECTION
