Select CHARLES E9543 User manual

EAN CODE: 5412025095438
Montage handleiding
Plan de montage
Assembly manual
Montageanleitung
CHARLES
E9543

2220
3036
1605
3708
4608
810 810
4780
4480
2220
3036
600
4780
3880
CHARLES - E9543

R E F E R E N C E L E N G T H QTY. C O N T E N T
A WW040x118-STPT-000-0-
B WW040x118-S1IF-000-0-
4780 2
400 34
I M A G E
PO_ _ _ _ _ _ _ _ _ _ _ _ _ _
SAV
REF.
C1 1550 2
C2 1550 2
D 400 34
E3880 36
F1 4480 2
F2 4480 1
F3 4480 1
G 4780 19
I 3880 2
J 2660 80
K4480 9
M 2675 4
O1 2597 10
WW040x118-SB1H-000-0-
WW040x118-SB1F-000-0-
WW040x118-PRF-000-0-
WW040x118-S2IF-000-0-
WW040x118-SA69-000-0-
WW040x064-SA69-BIG-0-
WW040x064-SA69-BID-0-
WW040x118-S2IF-000-0-
WW040x073-SDEM-000-0-
WW019x123-PRF-000-0-
WW040x145-PT7-000-0-
WW016x145-VOL-070-0-
CHARLES - E9543
P1
Plank milled on 1 side
Triangle top
Plank milled on 1 side, recess at the bottom
Plank milled on 1 side, recess at the top
Profile plank
Plank milled on 2 sides
Plank milled on 2 sides with extension
Plank milled on 2 sides with extension, chamfered left
Plank milled on 2 sides with extension, chamfered right
Plank milled on 2 sides, cut in half lengthwise
Plank milled on 2 sides
Roof beam with extension
Roof finishing plank with angled corner
Bacacier roof plates
Door wing
Profile plank
S5300
O2
O3
O4
Roof plates corners
Ridge plate
Self-perforating screws
S5301
S5302
S5303
2750
2400
4
2
4
E9901
Door Frame E9901-K40
Lock
S6744
Glass
S647
ALU profile
E9951
E9901-ALU
Flush bolt
P2
P3
P4
P5
P6 1725
List of parts / After sales service |
O5Ridge plate corner S5304 2
2
1
2
1
2
1

R E F E R E N C E L E N G T H QTY. C O N T E N T I M A G E
PO_ _ _ _ _ _ _ _ _ _ _ _ _ _
SAV
REF.
Gutter
Gutter board
Window
T1
UWW016x095-4FA-000-0- 2240 4
Q1
CHARLES - E9543
YAnti storm kit S522 1
R1Bag of nails S637 2.8 X 50 10
R2
Bag of screws S626 4.0 X 45 2
R3Bag of screws S617 3.5 X 35 2
Ground beam S WW028x070-CS0-040-0- 6000 4
ZVentilation kit S6746 1
E9931-40
S5900 24400
Pipe piece
Gutter hook
Roof clamp 20°
Spout
End piece Left and Right
Bend 67°
End bend 67°
S5901
S5902
S5903
S5904
S5905
S5906
S5907
Pipe bracket S5908
T2
T3
T4
T6
T7
T8
T5
T9
2
20
20
2
4
4
2
4
2000
List of parts / After sales service |

01
S = 4
45°
S
3580
1380 1380
4486
CHARLES - E9543

01.1
G
I
I
I = 2
C2 = 2
C2
C2
1680
G = 1
CHARLES - E9543

02
B = 18
D = 18
QQ
D
D
B
E
E = 18
Q
G = 9
Q = 2
E
G
B
CHARLES - E9543
Advice:
Measure that the diagonals have the same length to ensure that the
walls are perpendicular to each other

03
B = 16
E = 18
F1 = 2 G E
G = 9
F1
C1
C1
D = 16
F1
D
B
D
E
B
C1 = 2
CHARLES - E9543

04
A
F2
A
A = 2
F2 = 1
F3
F3 = 1
CHARLES - E9543

05
K = 9
K
R1 = 1 - #36
CHARLES - E9543

06
J = 80
R2
R1 = 1 - #880
CHARLES - E9543

07
M = 4
R2
R2 = 4 - #48
CHARLES - E9543

08
T = 2
T
R3 = 1 - #42
CHARLES - E9543

08.1
U
R2
+/-1m

08.2
30
+/-1m
T4

08.3
T3

08.4
T1

08.5
T6

08.6
T5

08.7
