Sendai CD789 User manual

CD789
CD/MP3 PLAYER WITH FM/AM TUNER
OPERATING INSTRUCTION

2
Safety Information
PRECAUTIONS
Use only in a 12-volt DC negative-ground
electrical system.
Disconnect the vehicle's negative battery
terminal while mounting and connecting
the unit.
When replacing the fuse, be sure to use
one with an identical amperage rating.
Using a fuse with a higher amperage rating
may cause serious damage to the unit.
DO NOT attempt to disassemble the unit.
Laser beams from the optical pickup are
dangerous to the eyes.
Make sure that pins or other foreign
objects do not get inside the unit, they
may cause malfunctions, or create safety
hazards such as electrical shock or laser
beam exposure.
If you have parked the car for a long
time in hot or cold weather, wait until the
temperature in the car becomes normal
before operating the unit.
Keep the volume at a level at which you
can hear outside warning sounds (horns
sirens, etc.).
CD Notes
Playing a defective or dusty CD
can cause dropouts in sound.
Hold CDs as illustrated.
Do not touch the unlabeled side.
Do not attach any seal, label or
data protection sheet to either side of a
disc.
Do not expose a CD to direct sunlight or
excessive heat.
Wipe a dirty CD from the center outward
with a cleaning cloth.
Never use solvents such as benzine or
alcohol.
This unit cannot play 3-inch ( 8cm ) CDs.
NEVER insert a 3-inch CD contained in the
adapter or an irregularly shaped CD. The
unit may not be able to eject it, resulting in
a malfunction.
Before Operation
Do not raise the volume level too much,
as this will block outside sounds, making
driving dangerous.
Stop the car before performing any
complicated operation.
CAUTION
DO NOT open covers and do not repair
yourself. Consult the dealer or an
experienced technician for help.
* In addition to ordinary CDs, this unit can
playback a CD-R or CD-RW, MP3.
Contents
Safety Information ........................................ 2
Panel Controls .............................................. 3
Button Tips ................................................... 4
MP3 Overview .............................................. 4
MP3 Playback............................................... 5
RDS (Radio Data System)............................ 6
Menu Function.............................................. 7
Electrical Connections .................................. 8
Installation Guide.......................................... 9
Anti-Theft System ....................................... 10
Trouble Shooting ................................... 10-11
Specications ............................................. 11

3
Panel Controls
Power on : Press any button on the panel except and to turn on the unit.
1. - Disc eject
2. - Power on
- Mute
- When on, hold it to power off.
3. Press the button to select a
mode from:
- Radio
- Disc play (when disc inserted)
- Aux-in
4. - Panel release
5. - Aux-in jack
6. - Time display/adjust
7. - Band switch:
FM1 - FM2 - FM3 - AM1 - AM2
8. - Button 1: Play/Pause
Top play (press more than 2 sec.)
9. - Button 2: Intro play (10 sec.)
10. - Button 3: Track repeat play
11. - Button 4: Track random play
12. - Button 5: MP3 track -10 down
13. - Button 6: MP3 track +10 up
14. - AMS
Radio preset scan/Radio auto
preset
- SEARCH
MP3track/le/charactersearch
15. - Program type
16.- Traffic announcements
identication
17. - Radio tune
- Track seek
18. - Alternative frequency
- REG on/off
19. - Disc slot
20. - Rotate the knob to adjust
volume level.
- Push to select VOL/BAS/
TRE/BAL/FAD, rotate the
knob to adjust level.
- Press more than 2 seconds
to enter menu mode.
21. - Radio preset button 1~6,
press to tune in a preset
station.
- H o l d f o r m o r e t h a n 2
seconds to store station.

4
Button Tips
AMS : Auto Memory Store
Pressbrieytoscanthepresetstation1-6 for
5 seconds each. Hold more than 2 seconds,
the 6 strongest available station will be
automatically saved in the memory of preset
button 1-6.
BUTTON SKIP
Radio: Press |<< / >>| button to tune in the
station that you have known its frequency.
Hold |<< / >>| more than 2 seconds, tuning
will automatically activate and stop when
signals of the next station are received.
Disc playback: Press |<< / >>| button to go to
the next or previous track. Hold |<< / >>| to
reverse back or fast forward the track.
SET CLOCK
Press DISP button, time displays. Press again
more than 2 seconds, time display blinks.
Rotate the knob to set time.
MP3 Overview
MP3 Overview
MP3 is short for MPEG Audio Layer 3 and
refers to an audio compression technology
standard.
Thisproductallowsplayback ofMP3les
on CD-ROM CD-R or CD-RW discs.
Theunit canreadMP3leswritteninthe
format compliant with ISO 9660. However
it does not support the MP3 data written by
the method of packet write.
TheunitcannotreadanMP3lethathas
aleextensionotherthan".mp3".
If you play a non-MP3 file that has the
".mp3"extension,youmayhearsome
noise.
In this manual, we refer to what are called
"MP3file"and"folder"inPCterminology
as"Track"and"Album",respectively.
Maximum number of directory level is 8,
including the root directory. Maximum
number of files and folders per disc is
1000.
The unit may not play tracks in the order of
track numbers.
The unit plays only the audio tracks if a
disc contains both audio tracks and MP3
les.
When playing a disc of 8kbps or VBR*, the
elapsed playing time in the display window
will not be correct and also the intro play
may not function properly. *VBR: Variable
Bit Rate.
Note on creating your own CD-Rs or
CD-RWs containing MP3 les
To enjoy high quality sound, we
recommend converting to MP3 files with
a sampling frequency of 44.1 kHz and a
xedbitrateof128kbps.
DONOTstoremorethan1000MP3les
per disc.
For ISO 9660-compliant format, the
maximum allowable depth of nested folders
is 8, including the root directory(folder).
When CD-R disc is used, playback is
possible only for discs which have been
nalized.
Make sure that when MP3 CD-R is burned
that it is formatted as a data disc and NOT
as an audio disc.
You should not write non-MP3 files or
unneededfoldersalongwithMP3leson
the CD-R otherwise it takes a long time
until the unit starts
toplayMP3les.
With some CD-R media, data may not
be properly written depending on their
manufacturing quality. In this case, data
may not be reproduced correctly. High
quality CD-R disc is recommended.
Up to 16 characters are displayed for the
name of an Album or a Track. ID3 TAG
version 1.x is required.
Note that the unit may not play tracks in
the order that you wrote them to the disc.

5
RDS (Radio Data System)
RDS service availability varies with areas.
Please understand if RDS service is not
available in you area, the following service is
not available, either. The following functions
are available when receiving RDS stations.
RDS Basics
AF (Alternative Frequency list)
When reception is poor, an RDS station
broadcasting the same program is tuned in
automatically.
PS Display (Program Service name)
The name of station is displayed instead of
frequency.
AF Mode: Press AF button less than 1
second to switch AF mode on and off.
AFindicationonLCDwillashuntilRDS
information is received.
REG Mode: Press AF button more than 1
second to switch REG mode on and off.
The frequency is changed only for
programs within the region.
The frequency is changed also for
programs outside the region.
During FM mode when AF is on, radio
seek, scan and AMS functions can only
receive and save RDS program.
MP3 Playback
WhileplayingMP3disc,thefolder/lenameandID3tag(Songtitle,AlbumandArtist)canscroll
entirely across the LCD.
Elapsed playing time & Track number -> Folder name & number -> File name & number -> Song
title -> Album title -> Artist name ->
MP3 Track Search
PressAMSbuttontoselect"TRACKSCH"
mode. Press the knob and LCD display will
show"001".
If your desired track number is less than
100,rotatetheknobtoselecttherstdigit
and press the knob once again and rotate
the knob to set the tens digit of the track
number. Press the knob again more than
0.5 second to play the track.
If your desired track number is more than
100,rotatetheknobtoselecttherstdigit
andpresstheknobtoconrm,rotatethe
knob to select the tens digit and press the
knobtoconrm,rotatetheknobtoselect
the hundreds digit and press the knob to
play the track.
If the track number you enter is beyond
themaximumlenumber,lastsongwillbe
played.
MP3 File Search
PressAMS buttontwicetoselect"FILE
SCH" mode. Press the knob to enter.
Rotate the knob to select folder.
If you just want to play songs of this folder,
press the knob more than 0.5 second to
playthersttrackofthefolder.
If you want to play desired track of the
folder, press the knob and rotate to select
the track you want. Press the knob again
to play the track.
MP3 Character Playback
Press AMS button three times to select
"CHARSCH"mode.
Presstheknoband"A"displayed.
Rotate the knob to select the 1st character
of the desired track name and press the
knobtoconrm.
Then"A"blinksatthenext place,select
2nd and other character of the desired
track name as steps above.
Press the knob more than 0.5 second to
play the track of the select name.
For example: To search character
"ECHO".

6
CT Service ( Clock Time )
When receiving an RDS station, the CT (Clock
Time) service automatically adjusts the time.
NO CT is displayed in areas where CT service
is not available.
Trafc Announcements
Some RDS FM stations periodically provide
trafcinformation.
TP(TrafcProgramIdentication)
Broadcastingoftrafcinformation
TA(TrafcAnnouncementsIdentication)
Radioannouncementsontrafcconditions
TA Mode: Press TA button to turn on / off
TA.
When TA mode is on and TA indicator on
LCD is displayed.
When traffic announcement is transmitted,
regardless of the mode, reception will begin at
volume level 20 if volume level is below 20.
After the traffic announcement is over, it will
return to previous mode and volume level.
When TA is turned on, SEEK, SCAN, AMS
functioncanbereceivedorsavedwhentrafc
programidentication(TP)codeisreceived.
EON ( Enhanced Other Networks )
When EON data is received, the EON indicator
lights and the TA and AF functions are
expanded as follows.
TA:Trafcinformationfromthecurrentand
other network stations can be received.
AF: The frequency list of preset RDS
stations is updated by EON data. EON
enables the radio to make fuller use of
RDS information.
It constantly updates the AF list of preset
stations, including that currently tuned in
to.
If you preset a station for from home,
you will later be able to receive the same
station at an alternative frequency, or any
other station serving the same program,
EON also keeps track of locally available
TP stations for quick receptions.
PTY Reception ( Program Type )
RDS FM stations provide a program type
identicationsignal.
Example: news, rock, info, sport, etc.
PTY Mode: Press PTY button to turn PTY
on, previous PTY type is displayed and
searched if no button is pressed for 2
seconds.
If there is no correspond program type.
NO PTY is displayed.
PTY Type Preset
Press PTY once to enter MUSIC type or
press PTY twice to enter SPEECH type.
Then use buttons 1-6 to select the desired
program type.
PRESET
NO . MUSIC TYPE SPEECH TYPE
1
POP M NEWS
AFFAIRS
ROCK M INFO
2
M.O.R. M SPORT
EDUCATE
LIGHT M DRAMA
3
CLASSICS M CULTURE
SCIENCE
OTHER M VARIED
4
JAZZ M WEATHER
FINANCE
COUNTRY CHILDREN
5
NATIONAL M SOCIAL
RELIGION
OLDIES M PHONE IN
6FOLK M TRAVEL
LEISURE
FOLK DOCUMENT
RDS (continued)

7
TA VOL:
Rotate the knob to adjust TA volume.
RETUNE mode:
Rotate the knob to choose RETUNE-S or
RETUNE-L.
RETUNE-S or RETUNE-L is time length
selection of TA SEEK retune interval.
RETUNE-S: Short, TA SEEK retune
interval is 45 seconds.
RETUNE-L: Long, TA SEEK r etu ne
interval is 180 seconds.
Remark: RETUNE mode functions for TA
during TA SEEK mode only.
DSP mode:
Rotate the knob to choose DSP sound effect:
POP->ROCK->CLASSIC->FLAT-> DSP OFF
EPS mode:
ESP 12s: Sel ec ted a s CD- ESP t im e 12
second s, MP3-ES P time >100
seconds.
ESP 45s: Sel ec ted a s CD- ESP t im e 45
second s, MP3-ES P time >100
seconds.
MULT ON/OFF:
Multi Session ON/OFF. (Multi session OFF:
mixed CD, ONE session CD; Multi session
ON: Mixed, Extra, multi session CD)
LOUD ON/OFF :
Rotate the knob to select loudness on or off.
BEEP ON/OFF:
Rotate the knob to choose beep sound on or
off.
SEEK 1/2 mode:
Rotate the knob to choose radio seek
mode 1 or 2 .
SEEK 1: Searching station will stop when
next station is received.
SEEK 2: Searching station will stop when
or button is released and next
station is received.
STEREO/MONO mode:
Rotate the knob to select FM stereo/mono
mode.
LOCAL/DX mode:
Rotate the knob to select radio local/distant
mode.
VOL mode:
VOL LAST: the turn-on volume level is the
volume level of latest power off.
VOL ADJ: At volume adjust mode, press
the knob to enter A-VOL mode, then rotate
the knob to set the turn-on volume level.
Menu Function
Press the knob more than 2 seconds to enter
menu mode , then each press changes the
mode as follows:
TA mode -> MASK mode -> TA VOL ->
RETUNE mode -> DSP mode -> ESP mode
-> MULT ON/OFF -> LOUD ON/OFF -> BEEP
ON/OFF -> SEEK1/2 mode (only in tuner
mode) -> STEREO / MONO mode -> LOCAL /
DX mode -> VOL mode
TA mode:
Rotate the knob to choose TA ALARM or
TA SEEK mode, When TA is turned on
and no traffic program identification code
has been received during the specified
time, no TA/TP is displayed and according
to the MENU SELECT, alarm is set off, or
TA SEEK is activated.
TA ALARM mode: NO TA/TP is displayed
and alarm is set off.
TA SEEK mode: TA SEEK is activated.
MASK mode:
Rotate the knob to choose MASK DPI or
MASK ALL mode.
MASK DPI mode: Only the AF which has
differentprogramidenticationismasked.
MASK ALL mode:
The AF which has different program
identicationandNORDSsignalwithhigh
eldstrengthismasked.

8
Electrical Connections
Wiring Diagram
Loation Function
Connector A Connector B
1 Rear Right (+) / Purple
2 Rear Right (-) / Purple with Black Stripe
3 Front Right (+) / Gray
4 Battery 12V(+) / Yellow Front Right (-) / Gray with Black Stripe
5ANT/AMP control / Blue
with white stripe Front Left(+) / White
6 Front Left(-) / White with Black Stripe
7 ACC+ / Red Rear Left (+) / Green
8 Ground / Black Rear Left (-) / Green with Black Stripe

9
Installation Guide
Installation Procedures
First complete the electrical connections, and then check them for
correctness.
Reset
Press the RESET button with a pointed object to reset the unit to
the original status.
Note: Press the RESET button will erase the clock setting and
stored stations.
Installation Opening
This unit can be installed in any dashboard having an opening as
shown below. The dashboard should be 4.75mm - 5.56mm thick
in order to be able to support the unit.
Important:
Remove these two screws before installation. Otherwise, the
player will not work.
1. Insert mounting collar into the dashboard, and bend the mounting
tabs out with a screwdriver.
Make sure that lock lever isushwiththemounting
collar. (Not projecting outward)
2. Secure the rear of the unit.
Afterxingmountingbolt andpower connector, xthe
rear of the unit to the car body by rubber cushion.
3. Insert trim plate.
Lock lever

10
Anti-Theft System
This unit is equipped with a detachable panel. Removing this panel makes the radio totally
inoperable.
Troubleshooting
If you suspect something is wrong,
immediately switch power off. Do not use the
unit in abnormal condition, for example without
sound, or with smoke or foul smell can cause
re orelectricshock, Immediatelystopusing
it and call the store where you purchased it.
Never try to repair the unit yourself because it
is dangerous to do so.
General
No power or no sound
Car's engine switch is not on. Turn your
car's key to ACC or ON.
Cable is not correctly connected. Check
connection.
Fuse is burnt. Replace fuse.
Check volume or mute on / off.
If the above solutions cannot help, press
the RESET button.
Disc
Disc is inside but no sound.
Disc is upside down.
Place disc in the correct direction, and the
label side up.
Disc is dirty or damaged.
Clean disc or change another disc.
Disc sound skips, tone quality is low.
Disc is dirty or damaged.
Clean CD or change another CD.
Remove the detachable Panel
1. Switch off the power of the unit.
2. Remove the detachable panel.
3. Gently press the button of the case and open the
cover. Place the panel into the case and take it
with you when you leave the car.
Install detachable panel
1. Fix right part of face plate in the right part of panel
slot of the unit.
2. Press down the left side of the face plate until if
clicks into the panel slot of the unit.
Remove the unit
1. Switch off the power of the unit.
1. Remove the panel and the trim plate.
2. Insert both L-Keys into the hole on the front of the
set until they lock.
3. Pull out the unit.

11
Sound skips due to vibration.
Mounting angle is over 30 .
Adjust mounting angle to less than 30 .
Unstable mounting.
Mount the unit securely with the mounting
parts.
Radio
Much noise in broadcasts.
Station is too far, or signals are too weak.
Select other stations of higher signal level.
Preset station lost.
Battery cable is not correctly connected.
Connect the battery cable to the terminal
that is always live.
Error Display Messages
Display show NO FILE: Disc is not CD or
containsnoMP3les.
Display show ERR-7: Disc upside down.
Display show ERR-11: MP3 error, check
the disc.
Display show ERR-3 or ERR-4:
Disc mechanism error.
Press button to eject the disc.
In case that the disc cannot be ejected
by pressing button, press the RESET
switch and press the button again.
If still not ejecting, consult your dealer.
Specifications
General
Power supply: 12V DC(11V-16V)
Test voltage 14.4V,
negative ground
Maximum power output: 40Wx4 channels
Continuous power output: 20Wx4 channels (4
,10% T.H.D.)
Suitable speaker
impedance: 4-8 ohm
Pre-Amp output voltage:
2.0V (CD play mode:
1KHz, 0 dB, 10 K load)
Fuse: 15A
Dimensions(WxHxD): 178x50x155mm
Weight: 1.8kg
Aux-in ≥300mV
FM Stereo Radio
Frequency range:
87.5-108.0 MHz
(EUROPE )
87.5-107.9 MHz
(USA)
Usable sensitivity: 8 dBμ
Quieting sensitivity
(S/N=50dB): 12 dBμ
Frequency response: 30Hz-15kHz
Stereo separation: 30dB(1kHz)
Image response ratio: 50dB
IF response ratio: 70dB
Signal/noise ratio: 55dB
Note:Specicationsandthedesignaresubjecttochangewithoutnoticeduetoimprovementsin
technology.
MW(AM) Radio
Frequency range: 5 2 2 - 1 6 2 0 K H z
(EUROPE)
530-1710 KHz (USA)
Usable sensitivity
(S/N=20dB): 30 dBμ
Disc Player
System: Disc dig ital audio
system
Frequency response: 20Hz-20kHz
Signal/noise ratio: >80 dB
Total harmonic distortion: L e s s t h a n 0 . 2 0 %
(1kHz)
Wow and flutter: Below measurable
limits
Channel separation: >55 dB
Components
Mounting collar 1
Machine screws M5x6mm 4
Mounting bolt (50mm) 1
Wire connector 1
Removable face plate case 1
Trim plate 1
L-key 2
Operating instructions 1
Rubber cushion 1
Troubleshooting (continued)

PN: 127075001829
Table of contents
Other Sendai Car Receiver manuals
