Sense SE-XLR-USB User manual

1
Connect directly to a microphone.
Installation
XLR connection
2
Connect to a powered USB port
using a standard USB cable.
USB connection
3
The microphone is now ready to be
used with any program as a USB device.
Ready to Record
Overview
The SE-XLR-USB adapter is a great way to convert any
microphone into a USB device for us with microphones
in web conferencing and digital recording applications.
Use the USB audio connection with Skype, Lync,
Webex, Google Hangouts, and more.
Features
• Provides 48V of phantom power for use with con-
denser microphones.
• Manual gain adjustment, headphone output, and LED
power indicator.
Installation
Quick Start Guide
XLR to USB Adapter

www.snapav.com | Support: 866.838.5052
USB
PHANTOM
MONITOR
HEADPHONE
LEVEL
+48V
1
2
3
4
5
6
7
8
10
9
Features and Manual Controls

1. XLR Connector
1 - Ground, 2 - Positive, 3 - Negative
2. Peak Level LED
Green: Signal
Red: Peak
3. Mic Level
Adjusts microphone input level
4. Phantom Power Switches
Switch o for microphones not requiring
phantom power. Switch on for condenser
microphones.
5. Phantom Power Indicator
6. Monitor Gain
Blends pre-recorded playback from a
computer with live audio from the microphone
7. Headphone Gain
Adjusts the headphone volume
8. USB Indicator
Illuminates blue when USB connected to a
powered computer USB port
9. USB Connector
10. Headphone Jack

SE-XLR-USB
Input 3-pin XLR (F)
Input Impedance 1.2KΩ
Input Gain Range 35dB
USB connector USB-B Female
Headphone Jack 3.5mm Stereo Mini
Output: 50mW (16Ω)
Indicator USB: Blue
Phantom: Red
Peak Level: Green: Signal
Red: Peak
Phantom Power 48V ± 2V, 15mA
Frequency Response 25 ~ 20000Hz
Power consumption 5V USB, 2.2W
Specifications
Rev: 140910-0800
www.snapav.com | Support: 866.838.5052
