Serengeti Motorsports Badger E 450 User manual

Read Instructions Before Using Your New Badger E 450

DO NOT RETURN STORE. For questions regarding assembly and u
se,
NOTICE!
NOTICE!NOTICE!
NOTICE!
Before using your new Badger E 450 Mini Bi e the first time,
Charge the battery a minimum of 8 hours
Always recharge the battery before the power indicator shows no power.
Failure to follow these instructions nullifies any warranty, whether stated or implied.
Before operating your Badger E 450 Mini Bi e
Warning!
This product does not conform to Federal Motor Vehicles Standards and
is not intended for operation on public streets, roads or highways. Serious injury
can result from the unsafe operations of this vehicle.
This product is not designed to be jumped. If jumped, even from the curb,
the Mini ike Frame could break causing serious injury or death.
If jumped, the warranty is void.
Do not operate this product in traffic, on wet, frozen, oily or
unpaved surfaces or under the influence of drugs and/or alcohol.
Avoid uneven surfaces, potholes, surface cracks and obstacles.
It is recommended that the rider wear leather gloves, kneepads
and leather boots. Always wear a DOT approved helmet.
Never carry passengers on your adger E 450 Mini ike.
Minimum age is 16 years.
Weight Limit 150 lbs
Check your state and local laws governing the use
of motorized vehicles in your area.
Universal Product Concepts, Inc. is not responsible for your
failure to comply with state and local ordinances
relating to the use of the adger E 450 Mini ike.
Failure to follow these operation instructions
can result in serious injury or death.

CHARGING THE ADGER E 450 MINI IKE ATTERY
1. To avoid damage to the battery when charging, use only the charger provided with
your adger E 450 Mini ike. Mini ike should be off when charging.
2. Plug the supplied 24V battery charger into a 110V AC power source. Use only 110V AC
outlet when charging the adger E 450 Mini ike battery.
3. The CHARGER INDICATOR LIGHT will illuminate confirming that power is connected.
4. Plug the POWER INPUT CORD to the charging port on your adger E 450 Mini ike,
located on battery box.
5. When the battery is fully charged, Indicator Light will turn Green.
6. Disconnect the Input Cord from the Charging Port.
7. Disconnect the charger from the 110V power source.
8. Never leave the battery charger connected to the 110V power source when not
charging the battery. This will shorten the life of the charger.
9. When storing your adger E 450 Mini ike, the battery should be charged monthly.
Warning!
FAILURE TO KEEP THE ADGER E 450 MINI IKE ATTERY CHARGED WILL CAUSE
TOTAL ATTERY FAILURE. DO NOT ALLOW ATTERY TO FULLY DISCHARGE.
ATTERY DISPOSAL
When maintained properly, the Lead Acid attery in this product has a normal life of
many years. When the battery expires, it should be removed from the adger E 450 Mini
ike and recycled. Please contact your local solid waste authority for recycling
information in your area.
NOTICE: AFTER REMOVAL. COVER ATTERY TERMINALS WITH ELECTRICAL TAPE TO PRE-
VENT SPARK HAZARD FROM SHORTING OF THE TERMINALS.
ATTERY OX REMOVAL AND ASSEM LY
1. Unplug the cord from socket, and turn the key to unlock the battery box.

2. Pull out the battery box along the rail & remove, the battery can now be charged
separately.
3. Push the battery box into the compartment along the rail, turn the key to lock the box
and plug the cord.
MINI IKE SPECIFICATIONS
SPECIFICATIONS
Maximum Speed 16 MPH
Minimum Distance 10 Miles
Recharge Time 8 Hours
Load Capacity 150 lbs
Tires 145/70-6 Pneumatic
Dimensions 51.6 x 24.4 x 34.3in
Motor 450W
Transmission Chain Drive
attery 12V 16Ahx2
Ignition
On/Off
Key
Switch

DO NOT RETURN STORE. For questions regarding assembly and use,
LOCATION OF PARTS
Hand rake
Seat Cushion attery ox
Front Fender
Key Switch Rear Fender
DC Motor
Tension
Controller
Chain Cover Chain Sprocket Cover Sprocket
Throttle Handle
Number Plate
attery ox Lock
Fuse
Charging Port
rake Caliper Footrest
Rear Wheel Kickstand Front Wheel

DO NOT
RETURN STORE. For questions regarding assembly and use,
MAINTENANCE AND INSPECTION
1. Check brake and throttle cables before each use to insure proper adjustment. Check
to ensure that brake and throttle cables are flexible and that the inner cable moves
freely within the outer sleeve. Check end of cable to be sure that they are tightly
secured to the terminal connections.
2. Check brake pads weekly for wear or damage. Replace immediately at first sign of
wear or damage.
3. Check tires pressure as noted on side walls and inspect tires for tread wear
4. Lubricate wheel bearings regularly.
5. It is recommended that you use Lock tight on screws to prevent them from coming
loose due to motor vibration.
PARTS LIST
1 Front Fender 33 Rear Wheel Assembly olt
2 Rubber Washer 34 Rear Wheel ushing (Middle)
3 Number Plate 35 Wheel 145/70-6
4 Front Fork 36 Rear Rim
5 Throttle Lever 37 Chain
6 Nut M10×1.25 38 rake Wire
7 Frame 39 Adaptor
8 Steering Column ushing 40 Sprocket Cover
9 earing 6900 41 Chain Adjustor olt
10 Front Fork Assembly olt 42 Tension Pin
11 raking Lever 43 earing 6901
12 Left Grip 44 Tension
13 Seat 45 Motor
14 Rubber Cap 46 rake Disc ody
15 Nut M12×1.25 47 Controller
16 attery ox Lock 48 ottom Protector oard (Rear)
17 Rear Wheel ushing (Right) 49 Footrest (Left)
18 earing 6201 50 Spring (Right Screw)
19 rake Disc 51 ottom Protector oard (Front)
20 Cord Sleeve 52 Key Switch ase
21 Rear Fender 53 Cable Ring
22 Cord 54 Key Switch
23 Fuse ox 55 Front Wheel Assembly olt
24 Charging Port 56 Spring
25 Power Socket 57 Rubber Ring
26 attery ox Rail 58 Front Wheel ushing (Side)
27 attery ox (Right) 59 Kickstand
28 attery 60 Front Wheel ushing (Middle)
29 attery ox (Left) 61 Front Rim
30 Chain Cover 62 Kickstand Assembly olt
31 Sprocket 63 Spring (Left Screw)
32 Rear Wheel ushing (Left) 64 Footrest (Right)

DO NOT RETURN STORE. For questions regarding assembly and use,
Shipments will be made COD
CALL REPLACEMENT PARTS ORDERS TO:
Toll Free: 888-896-6881
ALLOW 2 WEEKS FOR SHIPPING

DO NOT RETURN STORE. For questions regarding assembly an
d use,
TROU LESHOOTING
Number Problem Possible Cause Solution
1 The Mini ike motor
does not operate.
1. Power switch is off.
2. Fuse has burned out.
3. attery is undercharged or
drained.
Check and/or
replace with 20
amp fuse. Charge
or replace the
battery
2 The speed control
is out of order or
the adjustable speed
is lower than rated.
1. attery is undercharged.
2. Check the throttle cable.
1. Fully charge
the battery.
2. Tighten
throttle cable.
3 The electric motor
stops functioning.
1. The battery wire is loose.
2. Fuse is burned out.
3. Lead wire of the battery is
broken.
Repair and
reconnect;
Replace the blown
fuse. Reconnect.
4
The driving distance is
less than the rated
distance.
1. Tires have resistance.
2. Failure of the charger.
3. Failure of the controller.
4. The battery is aged or
damaged.
5. Other factors, low
temperature, heavy wind,
the condition of the road
surface, overweight or
overuse of brake.
Lubricate wheels.
Repair the
charger. Change
the controller.
Change the
battery.
5 The battery does not
hold charge.
1. The charging socket is
loose.
2. Fuse is burned out.
3.
The lead wire of the battery
has poor connection.
Tighten the
connection
socket. Change
the blown fuse.
Reconnect.

SAFETY
This product should not be used by pregnant women, persons impaired vision, balance,
coordination, reflex, muscle and bone
strength and good decision-making capabilities
Operators Only! – No passengers
This product should not be used by minors without adult supervision
This product should not be used by persons unwilling or unable
to take responsibility for their own actions.
The user of this product assumes ALL risks associated with its use.
High speed jumps and trick maneuvers may result in
loss of control, accidents, serious injury or death.
This is the safety alert symbol. When
you see this symbol on your machine or in
this manual, be alert to the potential for
personal injury.
Read and follow all instructions in this
Owner’s/Operator’s manual, any
accompanying supplements before
attempting to operate this Mini Bike.
WARNING: Indicates a potential hazard
which could result in severe personal
injury or death.
CAUTION: Indicates a potential hazard
may result in severe personal injury or
damage to the vehicle
NOTE: Use the word “NOTE” will alert you to
key information or instructions.
Important Rules for Safe Operation
WARNING: NEVER operate / charge this Mini
Bike indoor or in an enclosed area without
adequate ventilation.
WARNING: This Mini Bike is not licensable.
DO NOT operate it on any public road, street,
highway, sidewalk or alley.
This Mini Bike may be operated only on
private property and areas approved by local
law.
WARNING: This Mini Bike may have been
supplied to you completely assembled. To
prevent possible injury or death read and
follow the assembly instructions to make sure
the Mini Bike was assembled properly.
WARNING: Always perform Daily Pre-Ride
inspections as outlined in this manual.
WARNING: Check tire pressure before each
use.
Prior to operating the Mini Bike check and adjust tire
pressure to the proper operating pressure as
indicated on the sidewall of each tire. A tire pressure
gauge is required to obtain accurate readings.
WARNING: Mini Bike modification or removal
of original equipment or safety decals can render
the vehicle unsafe for operation.
WARNING: Safety decals must be replaced if
they become unreadable or detached from the
Mini Bike.
If decals are unreadable or missing, warning of
potential hazards or safety requirements may
be lacking.
WARNING: This Mini Bike is not designed or
intended for stunt riding, spinouts, donuts,
racing, or any form of competition.

DO NOT RETURN STORE. For questions regarding assembly and use,
WARNING: This Mini Bike is not designed
to be used on rental tracks of any kind.
WARNING: The safe operation of this Mini
Bike is dependent upon the operator’s ability
to exercise proper judgment.
Operator must not be too small or too large
for controlled operation.
Operator must be of sufficient age,
understanding, mental capacity and physical
capability to safely operate this Mini Bike
Mini Bike should only be operated after
understanding instructions and sufficient
practice in an uncongested area.
WARNING: Operator of this Mini Bike
MUST always wear a properly fitting Safety
Helmet approved by agencies such as the
Department of transportation (DOT).
Most accident fatalities are due to head
inquires.
Operator should also wear helmet, boots,
gloves and other appropriate protective
clothing
WARNING: Long hair, loose clothes, or
jewelry can get caught in moving parts below
and behind the seat or surrounding
environment.
Remove anything loose that can reach below
and behind the seat before riding.
WARNING: NEVER place hands, feet, any
body parts or clothing near the wheels, chain
and other rotating parts of the Mini Bike while
riding.
Use caution in performing required
maintenance on or near motor.
Use caution after the motor has been
running, since the motor and other drive
components may be extremely hot.
WARNING: All screws, nuts and bolts must
be properly tightened to make sure the Mini Bike
is in safe operating condition.
Note: Over tightening hardware where parts are
required to move, such as front wheels, spindles,
a-arm pivots, etc, can restrict movement and cause a
loss of control and possible injury.
WARNING: prevailing-torque-type locknuts
must be replaced with new after the old locknuts
have been removed.
Replace with the same type of locknut to make sure
they function properly.
WARNING: Read and keep all supplied
printed material.
Supplements to this Operator’s Manual contain
updated information relative to your specific
Mini Bike model. It is important to keep all of
these documents for reference.
NEVER store the Mini Bike in close proximity to
appliances such as hot water heaters of
furnaces.
CAUTION: NEVER operate Mini Bike while
under the influence of alcohol, drugs or
medication of any kind.
Such operation is dangerous to yourself and/or
others.
CAUTION: If the Mini Bike should start
making unusual noise or vibrating abnormally,
the motor should be switched off and the Battery
wire disconnected. The Mini Bike should then be
checked for damage. Excessive noise or
vibration is generally a warning of loose or worn
parts.
WARNING: Excessive speed is potentially
dangerous to operator.
WARNING: Wet, slippery, rough or sloped
terrain is potentially dangerous and may result in
injury if proper caution is not observed.
ALWAYS SLOW DOWN.
Operator must use mature judgment, skill and
experience in choosing suitable terrain for
individual operational capabilities.

Instructions for Safe Use and Maintenance of Mini Bike
WARNING: When turning on pavement,
loose gravel, or similar surfaces, there is an
increased risk in loss of control.
ALWAYS SLOW DOWN!
WARNING: ALWAYS SLOW DOWN when
turning.
High-speed turning can cause loss of control,
possible vehicle turn-over and/or possible
operator and/or passenger injury.
Turning on a slope increases the risk of
rollover.
Practice operation is required to coordinate
turning skill.
Failure to operate this Mini Bike at a safe
speed while turning can result in a strong
possibility of severe personal injury.
1. Mini Bike shall not be modified from the
manufacturer’s original design and configuration.
2. Mini Bike shall not be used to perform racing,
stunt riding, jumps, spin-outs, donuts or other
maneuvers as they may cause loss of control of
the Mini Bike or may cause uncontrolled operator
or Mini Bike actions or reactions, As such, these
activities are likely to result in possible injury to the
operator, bystanders or a combination thereof.
3. Prior to each cycle of operation, a supervisor
shall perform the preparation checks specified by
the manufacture, and further verify;
a. Smooth throttle operation and positive return of
the throttle linkage to a closed throttle position
when released;
b .The steering linkage is adjusted and operates
properly;
c. All guards and pads originally supplied by the
manufacturer are in proper place on the Mini Bike
and in serviceable condition;
d. The area where the Mini Bike is operated is
safe and suitable for Mini Bike operation;
f. The braking system on the Mini Bike is
functioning properly;
g. All safety labels are in place, legible and
understood by the operator.
h. Any and all axle guards, chain guards, or other
covers or guards supplied by the manufacturer are
in place and in serviceable condition;
i. Tires are in good condition, inflated property, and
have sufficient tread remaining.
j. All fasteners are in place and tightened securely.
4. Mini Bike motor shall not be started unless the
operator is seated in the proper position for Mini Bike
operations with the operator’s hands on the Handle
Bars and the brake fully engaged.
5. Long hair, loose clothes, or jewelry can get caught
in moving parts below the seat or surrounding
environment, Remove or the back anything loose
that can reach below or behind the seat before riding.
6. A supervisor shall verify personally that everyone
operating or riding is knowledgeable, capable, and
has the cognitive capacity to operate the Mini Bike
safely, including those items specified in 1 through 5.
a. The supervisor only shall allow the use and
operation of the Mini Bike after a demonstration that
each operator can understand and operate all
components of the Mini Bike prior to use.
b. The supervisor shall provide continuous
supervision during Mini Bike use.
c. The supervisor shall not allow anyone to ride in
or operate Mini Bike with long hair, loose clothes, or
jewelry which can get caught in moving parts
below the seat or tie back anything loose that can
reach below or behind the seat before riding.
8. Badger E 450 Mini Bike operators shall adhere to
all manufacturer’s recommendations and
instructions, as well as comply with all laws and
ordinances.
a. Operators shall stay seated with both hands on the
Handle Bars and both feet in the Mini Bike at all
times, whether moving or stationary, unless the Mini
Bike is stopped completely.
b. Shall observe minimum age restrictions ；

WARRANTY REGISTRATION
RETURN THE
ADGER E 450
MINI IKE
PRODUCT REGISTRATION
WITH A COPY OF YOUR SALES RECEIPT TO :
Universal Product Concepts, Inc. 730 Epperson Drive, City of Industry, CA 91748
Name: ______________________________________________________________
Address: ____________________________________________________________
City: __________________ State: ________________Zip____________________
Phone: __________________________ E-mail: ____________________________
Date Purchased: _____________________ Model#: _________________________
Store Where Purchased: ________________________________________________
Store Address: ________________________________________________________
Receipt or Transaction #: ________________________________________________
The registration must be returned to Universal Product Concepts, Inc. within 10days of purchase. It is the only
information Universal Product concepts will have for notification to you of any information regarding this product.
This information is for the sole purpose of product/registration and will not be sold or used for any other purpose.
A COPY OF THE SALES RECEIPT AND UPC AR CODE MUST E INCLUDED WITH THIS REGISTRATION CARD.
Thank you for purchasing an Universal Product Concepts, Inc.
adger E 450
Mini ike
.
If there are parts missing or if your adger E 450 Mini ike does not run properly,
do not return your adger E 450 Mini ike to the place of purchase.
Please call Universal Product Concepts., Customer Service at 888-896-6881
PLEASE DO NOT RETURN PRODUCT TO RETAILER FOR WARRANTY OR REPLACEMENT PARTS.
*or register online at www.UPCintl.com using the warranty link or fax to 951-340-0251
c. Shall not ride the Mini Bike if long hair, loose
clothes, or jewelry reach below or behind the seat;
WARNING: Risk of death or serious injury!
Long hair, loose clothes, or jewelry can get
caught in moving parts below and behind the
seat or surrounding environment,
Remove or tie back anything loose that can
reach below or behind the seat before riding.
d. Shall not allow smoking in vehicle
e. Persons under the influence of drugs, alcohol, or
intoxicants shall not supervise, operate, or ride in a
Mini Bike
f. Mini Bike shall operate only on surface or terrain
as recommended by the manufacturer;
g. Mini Bike shall not be operated on roads, streets,
highways ,or at any other location where road
vehicle are intended to travel;
9. persons with the following conditions shall not
operate a Mini Bike
a. Those with heart conditions;
b. Pregnant women
c. Persons with head, back, or neck ailments, or
prior surgeries to those areas of the body;
d. Persons with any mental of physical conditions,
which may make them susceptible to injury or impair
their physical dexterity or mental capacities to
recognize, understand, and perform all safety
instructions, and be able to assume the hazards
inherent in Mini Bike use.
10. Vehicle operators always shall use appropriate
protective clothing, including but not limited to helmet
and eye protection, with appropriate certification,
and any other equipment recommended by the
manufacturer including gloves, footwear, long
sleeve shirts and long pants.
11. No operator or other person shall contact any
portion of the wheels, or drive train
for any purpose including maintenance until
the motor has been turned off, and the Mini Bike is
in a stable and stationary position.
13. Mini Bike components shall be maintained and
repaired in accordance with the manufacturer’s
specifications an utilizing only the manufacturer’s
authorized replacement parts with installation
preformed by designated dealer or other skilled
persons.

Universal Product Concepts, Inc.
Universal Product Concepts, Inc.Universal Product Concepts, Inc.
Universal Product Concepts, Inc.
LIMITED WARRANTY
LIMITED WARRANTYLIMITED WARRANTY
LIMITED WARRANTY
Your adger E 450 Mini ike is warranted to be free of manufacturing defects in
material or workmanship for a period of 90 days. During the warranty period
Universal Product Concepts, Inc. will at its option, repair, provide replacement parts
or replace your adger E 450 Mini ike at no charge. This warranty does not cover
normal wear and tear, or damage caused by neglect, or misuse of the product.
Should you experience a problem or need to return your adger E 450 Mini ike
for repair, please call the Universal Product Concepts customer service department
TOLL FREE AT 888-896-6881 between the hours of 9AM and 4PM PST Monday thru Friday.
You will be instructed how to proceed. A copy of receipt is required.
You may also contact Universal Product Concepts, Inc. by writing.
Universal Product Concepts, Inc.
City of Industry, CA 91748
Or
[e-mail]
Made in China
