SERRES NEMO Manual

SERRES NEMO®
Serres Suction bag emptying device
Installation, Operation and
Maintenance Instructions
SERRES NEMO® is a registered trademark of Serres OY.
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com2
Contents
INTRODUCTION 3
SERRES NEMO® Use Overview 3
Transportation and storage 3
Disposal and Recycling 3
WARRANTY 4
Accesories and Replacement Part 6
SAFETY INSTRUCTIONS AND BIOHAZARD WARNINGS 6
Chemical Safety 7
Electrical Safety 7
Guidance and manufacturer’s declaration
— electromagnetic emissions 8
INSTALLATION 9
Facility requirements 9
Unpacking the device 9
Regulatory and Building Code Requirements and Permits 10
Installation STEPS 10
After installation, test SERRES NEMO® 11
USE AND OPERATION OF SERRES NEMO® 12
Opening and closing the lid 12
Placing the suction bag in SERRES NEMO® 13
Emptying the suction bag 13
Operating Switches 14
TROUBLESHOOTING 16
Cleaning SERRES NEMO® 18
Chemical Safety 18
Cleaning emptying container with the washing tray 19
Maintenance program 19
Usage Counter 20
TECHNICAL SPECIFICATIONS AND DRAWNINGS 21
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com3
INTRODUCTION
Serres Oy (“SERRES OY”, “we”, “us”, or the “Manufacturer”), the manufacturer of the
SERRES NEMO® Suction Bag Emptying Device (“SERRES NEMO®”) has prepared these
installation, operation and maintenance instructions to ensure that the SERRES NEMO®
is installed, used, and maintained correctly and safely.
Read these instructions carefully before installing, using or maintaining SERRES
NEMO®. Failure to follow these instructions will void the Manufacturer’s Warranty and
may result in serious injury to persons or property.
SERRES NEMO® Use Overview
SERRES NEMO® is designed to be used exclusively with SERRES standard 2000 and
3000 ml suction bags. SERRES NEMO® is intended for the disposal of medical liquid
collected into SERRES standard 2000 and 3000 ml suction bags. SERRES NEMO®
empties and rinses the content of SERRES standard 2000 and 3000 ml suction bags
into the sewer system using the water nozzle in the SERRES NEMO® which penetrates
the suction bag lid, while the water pressure punctures and rinses the suction bag.
Transportation and storage
· SERRES NEMO® should be stored indoors in a warm place +15°C to +35°C. The
device must be protected from moisture, dirt and dust during transport and storage.
· To ensure the longevity, performance and safety of SERRES NEMO® use of original
packaging material is recommended when storing or transporting.
Disposal and Recycling
· Contamination of and / or injury to environment, persons and property may result
from improper disposal when SERRES NEMO® is decommissioned at the end of its
useful lifecycle. Prior to disposal contact Serres Oy Technical Support or your local
Serres Distributor for disinfection instructions of SERRES NEMO® and review local, and
state laws and codes regarding disposal and recycling.
· DO NOT DISPOSE OF AS UNSORTED MUNICIPAL WASTE.
WARNING! SERRES NEMO® SUCTION BAG MAY CONTAIN
RESIDUAL FLUIDS AFTER EMPTYING AND RINSING CYCLE.
SERRES NEMO® DOES NOT DISINFECT THE SUCTION BAG.
NOR THE CONTENT OF THE SUCTION BAG. SEE SAFETY
INSTRUCTIONS – BIOHAZARD WARNINGS.
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com4
WARRANTY
SERRES OY warrants that the SERRES NEMO® will be free from defects in material
and workmanship under normal use for a period of one (1) year from the date of
purchase (the “Warranty Period”). The device warranty is valid on the country where
it is purchased. The purchaser must examine and inspect SERRES NEMO® for defects,
damage or missing parts promptly after the delivery and shall promptly install and test
the SERRES NEMO®. A warranty claim must be made to SERRES OY or your local Serres
distributor at the latest within thirty (30) days following the end of the Warranty Period.
If we receive a valid warranty claim we will, repair or replace, in our sole discretion,
the SERRES NEMO® subject to the exclusions and limitations below. SERRES OY’s sole
responsibility under this warranty is to either repair or replace the SERRES NEMO®
with the same or reasonably similar product. When the SERRES NEMO®, or a part or
component is replaced, purchaser must provide us (or SERRES OY’s local distributor or
their authorized service partner) with the replaced SERRES NEMO®, part or component.
The exchanged item becomes purchaser’s property and the replaced SERRES NEMO®,
part or component becomes our property.
This warranty does not apply and SERRES OY will not be responsible for any loss,
data loss, damage, or other liabilities arising from: (a) damage from failure to follow
instructions relating to SERRES NEMO®’s installation, use, operation, maintenance or
disposal; (b) damage cause by improper daily use of SERRES NEMO® washing tray;
(c) damage caused by use with non- SERRES OY products or from the use of parts,
components or accessories that are not manufactured or recommended by SERRES OY;
(d) damage caused by normal wear and tear, abuse, misuse, intentional or deliberate
damage to the product, or force majeure; (e) damage or defect of a nonfunction part
which does not affect SERRES NEMO®’s operation, such as scratches, dents or color
differences; (f) damage to SERRES NEMO®, a part or component of SERRES NEMO® that
has been repaired or modified by persons other than SERRES OY authorized personnel,
including local Serres distributor or their authorized service partners, or without the
written permission of SERRES OY; or (g) if any SERRES OY serial number has been
altered, removed or defaced.
The remedies provided for in the above warranty are expressly in lieu of any other
liability SERRES OY may have. SERRES OY’s cumulative liability to any party for any loss
or damage resulting from any claims, demands, or actions arising out of or relating
to the SERRES NEMO® will not exceed the purchase price paid by purchaser for the
SERRES NEMO®. IN NO EVENT WILL SERRES OY BE LIABLE FOR ANY DIRECT, SPECIAL,
INDIRECT, INCIDENTAL, EXEMPLARY, PUNITIVE OR CONSEQUENTIAL DAMAGES, HOWEVER
CAUSED, WHETHER FOR BREACH OF WARRANTY, BREACH OF CONTRACT, NEGLIGENCE,
STRICT LIABILITY, TORT OR UNDER ANY OTHER LEGAL THEORY, EVEN IF SERRES OY HAS
BEEN ADVISED OF THE POSSIBILITY OF THOSE DAMAGES OR IF THOSE DAMAGES COULD
HAVE BEEN REASONABLY FORESEEN, AND NOTWITHSTANDING ANY FAILURE OF ESSENTIAL
PURPOSE OF ANY EXCLUSIVE REMEDY PROVIDED IN THIS WARRANTY. SOME LOCAL LAWS
DO NOT ALLOW FOR THE LIMITATION OR EXCLUSION OF LIABILITY FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY
TO YOU.
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com5
TO THE FULLEST EXTENT PERMITTED BY LAW, THIS WARRANTY AND THE REMEDIES SET
FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, REMEDIES,
AND CONDITIONS, WHETHER ORAL OR WRITTEN, STATUTORY, EXPRESS OR IMPLIED, AS
PERMITTED BY APPLICABLE LAW. SERRES OY SPECIFICALLY DISCLAIMS ANY AND ALL
STATUTORY OR IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION, WARRANTIES
OF MERCHANTABILITY, DESIGN, FITNESS FOR A PARTICULAR PURPOSE, ARISING FROM A
COURSE OF DEALING, USAGE OR TRADE PRACTICE, WARRANTIES AGAINST HIDDEN OR
LATENT DEFECTS, AND WARRANTIES AGAINST PATENT INFRINGEMENT. IF STATUTORY OR
IMPLIED WARRANTIES CANNOT BE LAWFULLY DISCLAIMED, THEN ALL SUCH WARRANTIES
ARE LIMITED TO THE DURATION OF THE EXPRESS WARRANTY DESCRIBED ABOVE AND
LIMITED BY THE OTHER PROVISIONS CONTAINED IN THIS WARRANTY DOCUMENT.
This warranty is non-transferrable and may only be exercised by the original purchaser
of the SERRES NEMO®.
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com6
Accesories and Replacement Part
We maintain replacement parts for several SERRES NEMO® components that may
be purchased to replace a component that is damaged or worn. Use of non-SERRES
OY products, replacements parts or components will void the Warranty, and the
manufacturer cannot guarantee the safety of SERRES NEMO
DESCRIPTION REF #
Washing Tray Country specific codes
Inner Seal 5798713
Outer Seal 5798714
SAFETY INSTRUCTIONS AND BIOHAZARD WARNINGS
General
Before installing, using or maintaining SERRES NEMO® it is important that you read and
understand the instructions and how SERRES NEMO® operates and how to minimize
risks, including the risk of contamination with blood borne pathogens and infectious
agents. SERRES NEMO® has been exclusively designed to empty and rinse only Serres
2000 and 3000 ml standard suction bags. Use of non-Serres 2000 or 3000 ml standard
suction bags may increase the risk of injury to people and property. Only medical staff
and maintenance staff trained in the use and to maintenance of SERRES NEMO® and
your facility’s blood borne pathogens policy should install, use or maintain the SERRES
NEMO®. If SERRES NEMO® has been damaged or parts are missing do not install or
use SERRES NEMO®. Contact Serres Oy, your local Serres Distributor or their authorized
service partners.
· ONLY USE SERRES 2000 and 3000 ml Standard Suction Bags with SERRES NEMO®.
· DO NOT USE SERRES NEMO® as a trash can or trash disposal device.
· DO NOT USE SERRES NEMO® to empty Serres pre-gelled Suction Bags
WARNING! BLOODBORNE PATHOGEN HAZARD. INFECTIOUS
AGENT HAZARD. USE UNIVERSAL PREAUTIONS. SERRES
NEMO® DOES NOT DISINFECT THE SUCTION BAG. SUCTION
BAG MAY CONTAIN RESIDUAL FLUIDS AND INFECTIOUS
AGENTS AFTER EMPTYING AND RINSING CYCLE. ALWAYS
WEAR PERSONAL PROTECTIVE EQUIPMENT.
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com7
· SERRES NEMO® SUCTION BAG MAY CONTAIN RESIDUAL FLUIDS AFTER EMPTYING AND
· RINSING CYCLE. SERRES NEMO® DOES NOT DISINFECT THE SUCTION BAG.
· ALWAYS wear personal protective equipment (PPE) when handling SERRES NEMO®
or suction bags.
· Purchaser is responsible for obtaining all required local, state, permits for the
installation, use and maintenance of SERRES NEMO® and for the collection and
disposal of medical waste and body fluids.
· Contamination of environment may result from improper storage or disposal of
medical waste and body fluids.
Chemical Safety
· SERRES NEMO® washing tray contains neutral detergent with pH 7.5 (14 ml).
· ALWAYS USE Personal Protective Equipment (PPE) suitable gloves/protective
clothing/eye protection/face protection
· ALWAYS FOLLOW directions and recommendations provided by detergent
manufacturer.
· RINSE EYES IMMEDIATELY if exposed to detergent; REMOVE contact lenses if possible;
CONTINUE RINSING and CALL POISON CENTER or health care provider promptly for
further instructions.
WARNING! BLOODBORNE PATHOGEN HAZARD. INFECTIOUS
AGENT HAZARD. USE UNIVERSAL PREAUTIONS. SERRES
NEMO® DOES NOT DISINFECT THE SUCTION BAG. SUCTION
BAG MAY CONTAIN RESIDUAL FLUIDS AND INFECTIOUS
AGENTS AFTER EMPTYING AND RINSING CYCLE. ALWAYS
WEAR PERSONAL PROTECTIVE EQUIPMENT.
Electrical Safety
· ALWAYS connect SERRES NEMO® within it’s own electrical cord to a safety
receptacle with a protective earth ground (e.g. 3-prong receptacle). We recommend
using a ground fault circuit interrupter (GFCI)
· DO NOT USE an extension cable or extension cord with SERRES NEMO®.
· ALWAYS disconnect SERRES NEMO® from the main current before maintenance.
· ALWAYS disconnect SERRES NEMO® power plug from the outlet if power cord is
damaged; then, contact Serres Oy Technical Support, your local Serres Distributor or
their authorized service partners
· Place SERRES NEMO® close to wall electrical socket so users are able to quickly
and easily detach the power plug from wall electrical socket.
· Disconnect the power plug by pulling the plug, not the cable.
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com8
Guidance and manufacturer’s declaration
— electromagnetic emissions
SERRES NEMO® suction bag emptying device is intended for use in the electromagnetic
environment specified below. The customer or the user of the device should assure
that the device is used in such an environment.
Guidance and manufacturer’s declaration— electromagnetic immunity
SERRES NEMO® suction bag emptying device is intended to be used in professional
healthcare facility environment.
Test Compliance Electromagnetic environment—guidance
RF emissions
CISPR 11
Group 1 The device uses RF energy only for its in-
ternal function. Therefore, its RF emissions
are very low and are not likely to cause any
interference in nearby electronic equipment.
RF emissions
CISPR 11
Class A SERRES NEMO® suction bag emptying device
is suitable for use in all establishments other
than domestic and those directly connect-
ed to a low voltage power supply network
which supplies buildings used for domestic
purposes.
WARNING! ELECTRICAL SHOCK HAZARD.
RISK OF ELECTRICAL SHOCK.
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com9
Facility requirements
For proper performance and installation SERRES NEMO® requires:
· An open area meeting the specifications described in the Technical Specifications
and Drawings.
· A cold water source, water pressure between 1 to 8 bar (800 kPa), the device has a
connecting hose to cold water supply with a G1/2 connector.
· A minimum DN50 sanitary waste line, solid connection with SERRES NEMO® and
the sanitary waste line. The connection to the sanitary waste line must be done
according to the local regulations, using a pipe with a diameter of at least DN50 at
a slope. The sanitary waste line must be always on a lower level than the sewer
connection of SERRES NEMO®. There should be no air gaps in the connection.
DO NOT USE an open floor drain
· Electrical power 220-240 V / 50Hz, facility power receptacle with protective earth
(ground). We recommend using a ground fault circuit interrupter (GFCI).
Tool requirements
· SERRES NEMO® can be installed using standard plumbing tools.
Unpacking the device
· SERRES NEMO® has lifting handles on the side covers.
· Only use the lifting handles to lift the SERRES NEMO® from the shipping pallet.
· ALWAYS have more than one person lift this equipment from the shipping pallet.
INSTALLATION
SERRES NEMO® is designed to be installed in a wet room, such as a sluice room. We
recommend having a floor drain in a room where SERRES NEMO® is installed.
WARNING! DO NOT INSTALL OR USE SERRES NEMO®
WHERE PATIENTS ARE BEING TREATED.
WARNING! HEAVY EQUIPTMENT.
USE LIFTING AID OR MULTIPLE PERSONS.
RISK OF MUSCLE STRAIN OR BACK INJURY.
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com10
WARNING! DO NOT CONNECT SERRES NEMO®
TO THE HOT WATER SUPPLY.
Regulatory and Building Code Requirements and Permits
Prior to installation, Purchaser should review local and state laws and code regarding
collection and disposal of medical waste, infectious agents and body fluids. Purchaser
is responsible for obtaining all required local and state permits and following
applicable laws, regulations and codes for the installation, use and maintenance of
SERRES NEMO® and for the collection and disposal of medical waste, infectious agents
and body fluids.
Contamination of and / or injury to environment, persons and property may result
from improper installation, use, and maintenance of SERRES NEMO® and the storage
or disposal of medical waste, infectious agents and body fluids.
Installation STEPS
· STEP ONE: Connect to the cold water supply network
First insert the water filter attached to the hose into the hose coupling as shown in the
picture. Then connect the appliance to the water supply network with its connecting
hose. A G1/2 connector is used to connect the device to the cold water supply. Only
the set of hoses supplied with the device can be used.
SERRES NEMO® has an AB-type air gap (SFS-EN 13077) as back-siphonage protection
for the water supply network. If the local regulations require other types of backflow
protection in addition to air gap, purchaser must install such additional required
protections before installing SERRES NEMO®.
· STEP TWO: Connect to the sanitary waste line
SERRES NEMO® is connected to the sewer network with a DN 50 pipe. The sewer pipe
is connected to the bend of SERRES NEMO®’s backside; the bend can be rotated 180º.
This connection must be made according to the local regulations, using a pipe with
a diameter of at least 50 mm at slope. The sanitary waste line must be always on a
lower level than the sewer connection of SERRES NEMO®. SERRES NEMO® must not be
connected to a sewer via an open sink or open floor drain. There should be no air gaps
in the drain connection.
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com11
After installation, test SERRES NEMO®
· STEP FIVE: Connect to the electrical network
Connect SERRES NEMO® with its power cord to a facility power receptacle
with protective earth (ground). We recommend using a ground fault circuit interrupter
(GFCI). DO NOT use power extension cable.
· STEP SIX: Bleed the internal water pump
· Test SERRES NEMO® operation by emptying five (5) of 3000 ml Serres suction bags
· STEP THREE: Level SERRES NEMO®
After making the water and sewer connections, use a level to ensure SERRES NEMO®
standing model is level and straight. To do this, place a level at the back of SERRES
NEMO® to ensure that it is standing straight. If necessary, adjust its legs. Do not measure
straightness from the lid at the top of SERRES NEMO®. Remove protective plastic
· STEP FOUR: Fix SERRES NEMO®
to wall with the wall bracket
Use the wall bracket to fix SERRES
NEMO® to the wall. Use appropriate
wall mount screws required for your
wall surface. Mount SERRES NEMO® to
the wall with four screws.
- Turn ON the main switch
- Open the cold-water tap
- Vent the air from the internal water pump by pressing
the Play/Pause button on the user interface.
- Run five, first emptying cycles without suction bag.
- Water leakage is not allowed
- The SERRES 3000 ml suction bag will break inside SERRES NEMO®
in less than 13 seconds – this is normal and a sign that SERRES NEMO®
is operating correctly.
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com12
Opening and closing the lid
SERRES NEMO® lid is opened and closed by lifting or lowering the handle on the lid. For
safety reasons, the device lid cannot be opened while the program is running.
USE AND OPERATION OF SERRES NEMO®
SERRES NEMO® is designed to be used exclusively with SERRES standard 2000 and
3000 ml suction bags. SERRES NEMO is intended for the disposal of medical liquid
collected into SERRES standard 2000 and 3000 ml suction bags.
WARNING! DO NOT USE SERRES NEMO® TO EMPTY
PRE-GELLED SUCTION BAGS! USER TRAINING
REQUIRED BEFORE USE TO REDUCE RISK OF INJURY
TO PERSONS OR PROPERTY.
WARNING! RISK OF CRUSH INJURY. WATCH OUT FOR YOUR
FINGERS WHEN OPENING AND CLOSING LID.
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com13
Placing the suction bag in SERRES NEMO®
· The suction bag to be emptied is
placed in SERRES NEMO® with the
bag’s lid on top of the set collar. The
suction bag can be installed in any
position.
· The spill basin around the emptying
container collects any liquid that
may have leaked outside the suction
bag in case of a fault.
· The suction bag’s angled connector and a possible serial connector must be
removed. The connections in the suction bag must be plugged before using the
emptying device!
Emptying the suction bag
· Make sure that the angled and serial connectors in the suction bag to be emptied
have been removed and that the connectors have been plugged.
· Open SERRES NEMO® lid (see above).
· Place the suction bag to be emptied into the emptying device (see above).
· Close SERRES NEMO® lid by pressing the handle on the lid, until the lid locks (see
above). A GREEN light blinks for five seconds.
· Start the emptying program by pressing the play/pause button on the front panel of
the lid. A YELLOW light will be on.
· SERRES NEMO® will run an emptying program that lasts for approximately 20
seconds.
· When the emptying program is finished, and the GREEN light is on, the lid can be
opened and the empty suction bag can be removed from SERRES NEMO®.
· The emptied, rinsed suction bag must disposed of in accordance with your facilities
specific instructions for disposing of medical waste and waste containing infectious
agents and body fluids.
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com14
WARNING! BLOODBORNE PATHOGEN HAZARD.
INFECTIOUS AGENT HAZARD. USE UNIVERSAL – BLOOD
BORNE PATHOGEN PRECAUTIONS. SERRES NEMO® DOES
NOT DISINFECT THE SUCTION BAG. SUCTION BAG MAY
CONTAIN RESIDUAL FLUIDS AND INFECTIOUS AGENTS
AFTER EMPTYING AND RINSING CYCLE. ALWAYS WEAR
PERSONAL PROTECTIVE EQUIPMENT.
Operating Switches
· SERRES NEMO® has a main on/off switch on the back of the lid. It is not necessary
to turn off SERRES NEMO® during normal usage. The indicator LED shows when
the power is on.
Nemo
The front panel of SERRES NEMO® has a play/pause button and four (4) LED lights.
SERRES NEMO® is started by pressing the play/pause button and paused by pressing
the same button.
· The bright LED light is ON
means the power is on.
· GREEN light is BLINKING
When the suction bag has been installed on the collar set and the lid is closed (safety
lock is on) the GREEN light blinks for 5 seconds, showing the lid is properlyclosed.
· GREEN light is ON
means the 20 second cycle is finished.
· YELLOW light is ON for 20 seconds
means the program cycle is running.
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com15
· YELLOW light is BLINKING
SERRES NEMO® fills the water tank, when the water tank is full the cycle will start
automatically; filling the water tank can take few seconds. SERRES NEMO® water tank
must be full in order for SERRES NEMO® to start. If several suction bags are emptied,
one after another, the water tank may not have had time to fill between bags. Yellow
blinking light will stop when water tank is full. If the problem continues, contact Serres
Oy, your local Serres distributor or their authorized service partners
· RED light is ON
This indicates the following has occurred –
- The play/pause button was pressed during program cycle
- SERRES NEMO® handle was lifted during program cycle
- Power failure occurred during program cycle
- Water tap is closed
PRESS the play/pause button again to restart the cycle
- If water tank is not filled up in two minutes, red light turns on and
water intake shuts off automatically
Contact Serres Oy, your local Serres distributor or
their authorized service partners
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com16
PROBLEM: Power indicator light is not ON
CAUSE:
Power cord is not connected
or is loosely connected
SOLUTION:
Make sure power cord is
connected securely.
CAUSE:
Power switch is in OFF position
at the back of the equipment
SOLUTION:
Make sure the power switch
is in ON position
PROBLEM: Emptying cycle did not start. RED light is ON
CAUSE:
Water supply breakdown
SOLUTION:
Check that cold water connection
is functional, and facility water
tap is open. Restart by playing
start button, if water tap was closed.
PROBLEM: Emptying cycle did not start.
CAUSE:
Lid is not closed properly
SOLUTION:
Place the lid handle in down position.
Then press down firmly with two
hands until green LED starts blinking
(for five seconds) and electronic lock
has clicked. Press the play button
to start the cycle
PROBLEM: Liquid leakage
SOLUTION:
If there is liquid leaking, stop the program cycle by pressing the Play/Pause
button and disconnect power cord. Contact Serres Oy Technical support,
your local Serres Distributor or their authorized service partners.
TROUBLESHOOTING
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com17
PROBLEM: Lid cannot be opened. RED light is ON.
CAUSE:
There has been power interruption
during the emptying cycle
SOLUTION:
Press the Play/pause button and
wait until emptying cycle is finished
and green light is on
CAUSE:
SERRES NEMO® lid handle
has been lifted up before
the emptying cycle has ended
and green light is on
SOLUTION:
Press the Play/pause button and
wait until emptying cycle is
finished and green light is on
CAUSE:
User has pressed the Play/Pause
button during the emptying cycle
SOLUTION:
Press the Play/pause button and
wait until emptying cycle is finished
and green light is lit
PROBLEM: Suction bag rinsing result is poor
SOLUTION:
Restart program cycle by pressing the play/pause button. If the fault
persists, contact Serres Oy Technical support, your local Serres Distributor
or their authorized service partners.
PROBLEM: Suction bag does not empty
SOLUTION:
Restart program cycle by pressing the play/pause button. If the fault
persists, contact Serres Oy Technical support, your local Serres Distributor
or their authorized service partners.
Other problems:
Contact Serres Oy Technical support, your local Serres Distributor or their
authorized service partners.
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com18
Cleaning SERRES NEMO®
· CLEAN exterior of SERRES NEMO® by wiping it with a cleaning agent intended for
disinfecting hospital equipment.
· CLEAN DAILY. The emptying chamber must be cleaned daily by running program
cycle with a washing tray. The washing tray is disposable.
· DO NOT use abrasive detergents or solvents to clean the device.
· DO NOT immerse any system component in liquid.
· DO NOT rinse SERRES NEMO® with a hose.
· DO NOT allow liquids or moisture to enter any electrical connection.
· DO NOT sterilize any system component.
Chemical Safety
· SERRES NEMO® washing tray contains neutral detergent with pH 7.5 (14 ml).
· ALWAYS USE Personal Protective Equipment (PPE) suitable gloves/protective
clothing/eye protection/face protection
· ALWAYS FOLLOW directions and recommendations provided by detergent
manufacturer.
· RINSE EYES IMMEDIATELY if exposed to detergent; REMOVE contact lenses if possible;
CONTINUE RINSING and CALL POISON CENTER or health care provider promptly for
further instructions.
WARNING! CAUSES SERIOUS EYE DAMAGE. CAUSES
SKIN IRRITATION. DO NOT GET IN EYES, ON SKIN, OR
ON CLOTHING. IF IN EYES: RINSE CAUTIOUSLY WITH
WATER FOR SEVERAL MINUTES. REMOVE CONTACT
LENSES, IF PRESENT AND EASY TO DO. CONTINUE
RINSING. GET MEDICAL ADVICE/ATTENTION. USE PP
WHEN HANDLING WASHING TRAY DETERGENT
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com19
Cleaning emptying container with the washing tray
The daily use of disposable washing trays ensures that emptying container is hygienic
and is required for SERRES NEMO® to function as intended. Place washing tray into
SERRES NEMO® with enough detergent for cleaning the emptying container. PLEASE
NOTICE - SERRES NEMO® washing tray does not disinfect the emptying container of
SERRES NEMO®. The washing tray also seals the emptying container, preventing water
and contaminants from splashing outside SERRES NEMO® during the program cycle.
Follow these steps to clean emptying container:
· STEP ONE: Open lid (see instructions Opening and Closing Lid)
· STEP TWO: Place the disposable washing tray on the set collar of the emptying
device.
· STEP THREE: Close lid by pressing the handle on the lid until the lid locks, and start
the program by pressing the play/pause button on the front panel of the lid. SERRES
NEMO® will run a 20 second program cycle
· STEP FOUR: When the program cycle has ended, the lid can be opened and the
used washing tray can be removed.
Maintenance program
Follow the maintenance and inspection schedule below for SERRES NEMO® to operate
as intended. DO NOT use any equipment if damaged or the inspection criteria not met.
EVERY SIX (6) MONTHS: CHANGE inner seal of the lid (Order #5798713). If inner seal
shows signs of wear and tear before six months change inner seal sooner.
WARNING! SUCTION BAG MAY CONTAIN RESIDUAL FLUIDS
AFTER EMPTYING AND RINSING CYCLE. SERRES NEMO®
DOES NOT DISINFECT THE SUCTION BAG. BLOODBORNE
PATHOGEN HAZARD. INFECTIOUS AGENT HAZARD.
USE UNIVERSAL – BLOOD BORNE PATHOGEN PRECAUTIONS.
ALWAYS WEAR PERSONAL PROTECTIVE EQUIPMENT.
WARNING! ELECTRICAL SHOCK HAZARD. RISK OF ELECTRICAL
SHOCK. Only individuals trained and experienced in the
maintenance of electrical devices should install, inspect,
and test SERRES NEMO®.
17-Dec-20196001298 /C

SERRES NEMO® www.serres.com20
EVERY TWELVE (12) MONTHS: CONDUCT periodic maintenance as follows:
· CHANGE Outer seal of the lid (Order #5798714). If outer seal shows signs of wear
and tear before twelve months change outer seal sooner.
· CHANGE Stinger seal (Order #5798704). If stinger seal shows signs of wear and tear
before twelve months change stinger seal sooner.
· INSPECT SERRES NEMO® components for wear and replace when worn.
· INSPECT plumbing connections and hoses for leaks.
· INSPECT water filter for inlet water hose
· INSPECT power cord for cuts.
· INSPECT power core receptacle for bent pins.
· RUN performance test. NEMO® should meet manufacturer’s specifications.
- Run emptying cycle with five 3000ml empty Serres suction bags
and inspect if any leakages during the cycles.
For periodic maintenance and service, contact Serres Oy Technical Support, your
local Serres Distributor or their authorized service partners.
Usage Counter
SERRES NEMO® has a counter which indicates usage count. PRESS the play/pause
button for ten (10) seconds when the lid is completely opened to see counter statistics
– indicator lights will start to blink. The blink sequence can be reactivated by pressing
the play/pause button again. PRESS the play/pause button again or just close the lid to
return the device to a normal operating state.
All blinks are counted:
· RED light indicates tens of thousands of cycles
· YELLOW light indicates thousands of cycles
· GREEN light indicates hundreds of cycles
For example: If there have been less than 100 rinse cycles, there will be no blinks. With
199 rinse cycles, there will be one blink of a green light. 11299 rinse cycles is indicated
by one red, one yellow and two green blinks.
Nemo
17-Dec-20196001298 /C
