SetPower RV Series User manual

RV Dual Zone Series
User Manual
V1.3

CONTENT
1.PACKAGE CONTENT 01
2.SPECIFICATIONS 01
3.GETTING STARTED 02
4.OPERATION 02
5.ERROR CODES & SOLUTIONS 06
6.WARRANTY & RETURN 07
7.SAFETY INSTRUCTIONS 09

1.PACKAGE CONTENT
AC Adapter×1
User Manual×1
Refrigerator×1 Basket×1
DC Cable×1 (8.2 ft, 16 AWG)
2.SPECIFICATIONS
01
External
Dimensions
25.4×16.7×17.3 in.
(645×425×440mm)
Capacity 45 Qt / 43 L
Net Weight 38 lbs (17.2 kg)
Rated Power
Consumption 60W
Power Source DC 12V / 24V
AC 110V - 240V
Rated Current 5A / 2.5A
Fuse 15A
25.4×16.7×21.1 in.
(645×425×535mm)
60 Qt / 56L
41 lbs (18.8kg)
Model RV45D RV60D
Temperature
Range -18°C to +10°C (0°F to 50°F)

3.GETTING STARTED
Some Reminders
1. If the device was not correctly in the upright position
after transit and delivery, please keep it upright for 24
hours to make sure that the compressor can work properly.
2. If the device can’t turn on or you encounter other
problems for first time use, please contact us for help.
3. Pre-cool the empty unit before using it to enhance
system efficiency.
4.OPERATION
Left-Compt
Gauge
Right-Compt
Gauge
1 Control Panel
Left-Compt Temperature
Adjustment Buttons
Right-Compt Temperature
Adjustment Buttons
MAX ECO
Power Button
Set Button
Note: Left compartment refers to the part on the left side of the
divider, while the right one is the part upon the compressor.
02
All descriptions in this manual are based on the control
panel facing right.

2 Switched-on/off
MAX ECO
Power Button
With the unit plugged in, press Power Button to switch on/off the unit.
3 Temperature Adjustment
The Default Target Temperature for Left Compartment is 0°F, while
the right one is 41°F.
Press corresponding + or – to adjust the target temperature, the
target value will flash on the gauge. The temperature will change one
degree on every press.
Holding the button can accelerate the changing process.
Left-Compt Temperature
Adjustment Buttons
Right-Compt Temperature
Adjustment Buttons
MAX ECO
03

5 Settings Menu
In Stand-by Mode (unit turned off but plugged into power),
press and hold + and – Buttons (Right-Compt) at the same time
for 3 seconds to enter into the Settings Menu, which contains two
functions, Pr(Battery Protection Settings) and CF(°C/°F Settings).
Press Power Button to toggle between Battery Protection
Settings and °C/°F Settings.
Right-Compt Temperature
Adjustment Buttons
MAX ECO
Power Button
4 Max/Eco Mode
With the unit turned on, press the Set Button to toggle between Max
(Fast Cooling) Mode and Eco (Energy Saving) Mode. The
corresponding light will be on at the same time: the blue light is for
Max mode, while green one refers to Eco Mode.
MAX ECO
Set Button
04

5.1 Battery Protection Settings
MAX ECO
When “Pr” displays on the right gauge, press + or – button(Right-Compt) to choose
protection level. There are 3 protection levels available, “ ” refers to Middle Level,
which is also the default value. “ ” means High Level, “ ” means Low Level.
What is Battery Protection Settings?
This function is designed to prevent over-discharge and battery depletion.
When the measured DC voltage is below the Cut-off value, the compressor
will shut off to prevent battery depletion. After the voltage is higher than
Start-up value, the compressor will go back to work again. Improper
protection setting or low-power battery may cause E1 error, please lower the
battery protection or recharge the battery in time.
Power
Source
Display
Mid Level is the Default Setting
HIGH MID LOW
Start-up Cut-off Start-up Cut-off Start-up Cut-off
12V
24V
12.4V
25.7V
11.1V
24.3V
11.7V
24.2V
10.4V
22.8V
10.9V
22.7V
9.6V
21.3V
5.2 Switch Between °C to °F
MAX ECO
Right-Compt Temperature
Adjustment Buttons
When “CF” displays on the right gauge, press + or –(Right-Compt) to switch between
C(Celsius) and F(Fahrenheit).
Right-Compt Temperature
Adjustment Buttons
Protection
Level
05

6 Divider Removal and Installation
If the divider is removed from the unit, it will function as a single
zone unit, and only one temperature setting will become available.
IMPORTANT!
Every time the divider is removed or installed, the target
temperature will be reset to default value and need to set it
again.
5.ERROR CODES & SOLUTIONS
Error Codes
E1 Low Input-Voltage Error
The Input DC voltage is below the protection setting and the battery protection
is activated.
E2 Fan Error
The cooling fan overloads with more than 1A Current.
E3 Motor Start Error
The motor of compressor is blocked or the pressure difference in the
refrigeration system is too high.
E4 Minimum Motor Speed Error
The compressor overloads and the motor can not maintain its minimum speed.
E5 Ambient Temperature Error
The refrigeration system overloads, or the ambient temperature is too high,
the control is overheated.
E6 Thermal Sensor Fault
Thermal Sensor is open-circuited or short-circuited.
06

Solutions
If error code appears when the fridge is operating on 12V
DC, please try to lower the battery protection setting and
see if the error is resolved.
The battery protection mode may be triggered prematurely
on certain vehicles due to small wiring imperfections,
contributing to a measured DC voltage drop at compressor
start-up. Lowering the battery protection setting may resolve
this issue.
Please also try to take a voltage reading of your battery to make sure it is not
depleted/discharged.
Please contact us directly if the error persists.
If possible, please connect the AC power cord to try if the refrigerator appears
E1 code.
6.WARRANTY & RETURN
1 Warranty
2-year Warranty for Compressor
1-year Warranty for Other Accessories
For Warranty Registration, please contact us for more
information.
07

2 Customer Service
If the product is received damaged or defective, you can
contact us via these ways:
Customer Support Email: [email protected]
Order ID
Unit Model
Phone number
Description of the Defect
Delivery Address
Videos or Photos Related to The Defect
Note:
If calling the customer service number out of working time, you can
leave a voice/text message. We will respond to you after getting back
to work.
Videos or photos is preferred, because they can help us find out the
reason causing the issue and improve the efficiency of solving
problems.
3 Return Policy
Amazon-Fulfilled Order
The postage is afforded by Amazon in Amazon return window.
If the return window is expired but still in warranty, the return policy will be same
as seller-fulfilled order.
Seller-Fulfilled Order
If the warranty is not expired, the postage is afforded when the return is
confirmed to be caused by QUALITY ISSUE of our products.
Amazon Message Service
If you email us, these information needs to be included:
08

4 Refund & Replacement
For returns or exchanges, all accessories must be
returned in the original condition and packaging.
After the unit is shipped, please provide us with the
tracking number and carrier, so we can track it and
process the refund in time.
After the package is delivered back to our warehouse,
a full refund will be initiated.
7.SAFETY INSTRUCTIONS
Please read the user manual and safety instructions
carefully before using the appliance.
The manufacturer cannot be held responsible for the damage
resulting from improper usage or incorrect operation.
The use of accessories that are not recommended by manufacturer
can cause injuries and will invalidate any warranty that you may
have.
1 Disclaimer
If you file a return request on Amazon, we will process
it in 48 hours and contact you via Amazon Message
Service, please pay attention to your Amazon
Message Box or Email in order to avoid missing
important notifications.
09

Please power off and unplug the unit before cleaning or Maintenance.
Please use non-abrasive detergent to cleaning the interior/exterior of
the fridge.
Please don't scrap the interior of the fridge to defrost/de-ice the
fridge.
Please don't pressure-wash/spray the fridge with a running water
hose.
3 Cleaning & Maintenance
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge. Unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Place the unit on a dry, secure surface, with adequate ventilation.
Please make sure the lid is closed and secure, and only open the
fridge when you need to.
Please cool down hot/warm food before put it into the unit.
Please defrost the unit when ice forms on the internal walls or lid.
Select proper target temperature according to corresponding need.
2 Energy Saving Tips
10

Do not expose the unit to moderate/heavy rain.
Do not use this appliance near direct heat sources, such as flame or
radiator.
Do not place open containers of liquid inside the fridge.
Place/arrange the content of your fridge securely before using the
refrigerator inside a moving vehicle.
Do not use electrical devices inside the food storage compartments
of the appliance, unless approved/recommended by the
manufacturer.
Do not store explosive items, such as aerosol cans with a flammable
propellant in this appliance.
Do not touch the compressor or the condenser when the fridge is
operating.
Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
Please ensure the supply cord is not trapped or damaged before
setting up the appliance.
4 Dos and Don’ts
11

Failure to obey the following warnings could result in
death or serious injury:
Do not immerse the product in water, or use it in an excessively
muddy area.
Do not use the cooler for any purpose other than as a portable
cooling device.
DANGER
FALL HAZARD
Do not stand on the cooler, which may damage the unit or injure
yourself.
RISK OF CHILD ENTRAPMENT
Before you throw the unit away:
ELECTRICAL SHOCK HAZARD.
Take off the doors.
Leave the shelves in place so that children can not easily climb into it.
This appliance is intended to be used in household and similar
applications such as:
5 INTENDED TO USE
Staff kitchen areas in shops, offices and other working environments;
Farm houses and hotels, motels and other residential type
environments;
Bed and meal environments;
Catering and similar non-retail applications.
12

OUR GUARANTEE
SetPower product comes with a 3-year warranty on the compressor
and 1 year warranty on all other parts for your peace of mind. In the
unlikely event this product fails when used according to our user
guide, we will either repair or replace it. For full warranty terms and
conditions on this product, please see the user guide.
We'd welcome you contact us [email protected] if you
have any question about the product.
This product is warranted for 3 years on the compressor and 1 year
for all other parts from the date of purchase. Our goods come with
guarantees that cannot be excluded under the Local Consumer
Law. You are entitled to a replacement or refund for a major failure
and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure. Warranty does not cover
products that have not been used in accordance with user guide
or are outside the warranty terms and conditions.
Quality Service Guarantee

offi[email protected]
[email protected]
3-YEAR WARRANTY
R
