Shakespeare Electronic Style DS-3005 User manual

Shakespeare Electronic Products Group
6111 Shakespeare Rd., Columbia, SC 29223
®
ELECTRONICS AND FIBERGLASS DIVISION
18" Portable Satellite Antenna
Style DS-3005
ANTENNA/MOUNT MADE IN U.S.A.
UNPACKING
After unpacking the system, verify that you have 25 feet
of coax. If you do not, please contact Shakespeare at
[phone]. SAVE THE CARTON. This carton is
designed to be reused to protect your system when
not in use.
ELECTRONICS AND FIBERGLASS DIVISION
®

OPERATION
STEP 1. Connect coax from LNBF to receiver.
STEP 2. Plug in the receiver and TV.
STEP 3. Turn TV and receiver ON.
STEP 4. Tune TV to ch. 3 or 4.
STEP 5. Determine azimuth and elevation required for
your position. Refer to Quick Reference Card or receiver
manual.
STEP 6. Loosen clamp knobs. Elevate reflector to the
correct elevation. Align degree of elevation required with
front of the slide bracket. Each mark indicates 5 degrees
of elevation with the first mark being 00 (mark closest to
compass/level). See Figure 1. Tighten clamp knobs.
STEP 7. Level base using bubble level recessed into the
base.
STEP 8. Using compass recessed into base, rotate the
base
slowly to the desired azimuth (direction) for the high
power satellites.
NOTE: Disregard the compass markings, the red
compass needle always points North . Rotate the
base so that the other end of the needle points at the
correct heading (direction) on the compass decal.
DO NOT USE THE DEGREE MARKINGS ON THE
COMPASS.
Clamp Knobs
0 Degrees Elevation
(Next Mark Indicates 50)
Use Front of Slide Bracket
for Proper Degree of
Elevation Required. FIGURE 1
NOTE: If you have the unit sitting on a tailgate or on
other metal items, it is recommended that you
remove the compass from the base and stand away
(15' min.) to find the correct azimuth. Compass is
attached to base with velcro.
STEP 9. Adjust azimuth (direction) and elevation (up/
down) for best picture.
NOTE: If you do not get a picture, check the
following:
1. Make sure antenna has clear view of the high
power satellites, no buildings, trees, etc.
blocking the view.
2. Make sure coax connections are good.
3. Check coax for breaks, crimps, cuts etc.
4. If base is not level, you will have to adjust the
elevation to compensate.
5. Check that TV is tuned to correct channel.
CAUTION: DO NOT DROP SYSTEM. IF ANTENNA IS
DAMAGED, IT WILL REDUCE THE GAIN (HOW MUCH
SIGNAL THE ANTENNA SENDS TO THE RECEIVER)
OF THE ANTENNA. THIS CAN RESULT IN A
DEGRADEDPICTURE.
Point Towards Satellite
Reflector

RETURNINGANTENNATOTRAVELPOSITION
STEP 1. Turn receiver and TV OFF.
STEP 2. Disconnect coax from receiver.
STEP 3. Loosen clamp knobs and put antenna in travel
position. See Figure 2.
STEP 5. Coil coax under base. See Figure 3.
NOTE: The carton the system came in is designed to
be reused. It is suggested that you store your system
in it when not in use.
NOTE: When ready to use antenna again, you must
uncoil the coax before raising antenna. The antenna
will not raise if the coax is coiled up under the base.
FIGURE 2
FIGURE 3
Coil Coax
Around
Clips
RECEIVER WARRANTY
Receiver is warranted by the manufacturer. See instruction
manual packed with receiver for warranty information.
WINEGARD MOBILE PRODUCTS LIMITED WARRANTY
(2 YEARS PARTS; 1 YEAR LABOR)
Winegard Company warrants this product against defects in materials or workmanship for a period of two (2) years from the date of original purchase. During
year one (1) of such warranty, Winegard Company will also pay authorized labor costs to an authorized Winegard dealer to repair or replace defective products.
No warranty claim will be honored unless at the time the claim is made, Customer presents proof of purchase to an authorized Winegard dealer (to locate the
nearest authorized Winegard dealer, contact Winegard Company, 3000 Kirkwood Street, Burlington, Iowa 52601, Telephone [phone] or visit
www.winegard.com). Customer must provide proof of purchase with a dated sales receipt for the Winegard product to verify the product is under warranty.
If the date of purchase cannot be verified, the warranty period shall be considered to begin thirty (30) days after the date of manufacture.
If a defect in material or workmanship is discovered, Customer may take the product to an authorized Winegard dealer for service. Customer must provide
proof of purchase to verify the product is under warranty. If the product is brought to an authorized Winegard dealer for service prior to expiration of year one
(1) of the warranty period and a defect in material or workmanship is verified by Winegard Technical Services, Winegard Company will cover the Winegard
dealer’slaborchargesforwarranty service. TheWinegard dealer mustcontact Winegard TechnicalServices in advancefor pre-approval of the service. Approval
of the service is at the sole discretion of Winegard Company.
Alternatively, Customer may ship the product prepaid to Winegard Technical Services (located at 3111 Kirkwood Street, Burlington, Iowa 52601, Telephone
800-788-4417). Customer must return the product along with a brief description of the problem and provide Winegard Technical Services with Customer’s name,
address, and phone number. Customer must also provide proof of purchase to verify the product is under warranty. If the product is returned before the expiration
of the warranty period, Winegard Company will (at its option) either repair or replace the product.
This Limited Warranty does not apply if the product has been damaged, deteriorates, malfunctions or fails from: improper installation, misuse, abuse, neglect,
accident, tampering, modification of the product as originally manufactured by Winegard in any manner whatsoever, removing or defacing any serial number,
usage not in accordance with product instructions or acts of nature such as damage caused by wind, lightning, ice or corrosive environments such as salt
spray and acid rain. This Limited Warranty also does not apply if the product becomes unable to perform its’ intended function in any way as a result of the
television signal provider making any changes in technology or service.
RETURN AUTHORIZATION POLICY
A Return Material Authorization (RMA) is required prior to returning any product to Winegard Company or Winegard Warranty Services under this
warranty policy. Please call our Technical Services Department at 800-788-4417 or send an e-mail to [email protected] to obtain the RMA
number. Please furnish the date of purchase when requesting an RMA number. Enclose the product in a prepaid package and write the RMA number in
large, clear letters on the outside of the package. To avoid confusion or misunderstanding, a shipment(s) without an RMA number(s) or an unauthorized
return(s) will be refused and returned to Customer freight collect.
WINEGARD COMPANY DOES NOT ASSUME ANY LIABILITIES FOR ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, MADE BY ANY OTHER
PERSON.
ALL OTHER WARRANTIES WHETHER EXPRESS, IMPLIED OR STATUTORY INCLUDING WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE
AND MERCHANTABILITY ARE LIMITED TO THE TWO YEAR PERIOD OF THIS WARRANTY.
In states thatdo notallow limitations on implied warranties,or theexclusion of limitationof incidentalor consequential damages,the above limitations or exclusions
do not apply.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion of limitation of incidental or consequential damages, so the above
limitations or exclusions may not apply to you.
This warranty gives Customer specific legal rights. Customer may also have other rights that may vary from state to state
SATELLITE RECEIVER WARRANTY
See manufacturer’s limited warranty policy.
WS-MOBWARREV2
Rev.1/10

ANTENNA EXPLODED PARTS VIEW
Below is the exploded parts view for the 18"/26" portable
satellite system. If you require a replacement part, call
Shakespeare at [phone].
2200816
Base
(2) 2240021
Rubber Bumper
2160691
0.312 x 2.91
Round Head Pin
2160692
0.312 x 3.36
Round Head Pin
2780258
Level
(2) 2200096
Clamp Knob
(5) 2160027
5/16" Washer
(2) 2745048
Pivot Link
2200921
Reflector Bracket 2780190
LNBF
2753065
25' Coax
2745309
46 cm Reflector
(4) 2160361
5/16-18 x 5/8" Flat Head Bolt
(4) 2160230
5/16-18 Hex Nut
(4) 2160690
0.312 x 0.660
Round Head Pin
2780257
Compass
2160821
Spring (not shown)
3201818
Slide W/Inserts
(6) 2160696
E-Clip Retainer
2744846
FEED SUPPORT
ARM
2160353
1/4-20 X 1.25 LONG
CARRIAGE BOLT
2160220
1/4-20
HEX NYLOCK NUT
Printed in U.S.A.
© 1999, 2005, 2006 Shakespeare Company Rev.2 1/10
2451154
Cable Tie
2190104
