SHANDONG KAER ELECTRIC CO.,LTD KT1000(135) User manual

User Manual
Product：
WCDMA Fixed Wireless Phone
Model Name：
KT1000(135), KT1000, HD3010
Manufacture: SHANDONG KAER ELECTRIC CO.,LTD

WCDMA Fixed Wireless Phone user manual
2
Contents
1、Brief Instruction................................................................................5
1.1 Keys location ..................................................................... 5
1.2 Keys description ................................................................ 6
2、Usage ...................................................................................................8
2.1 Make a call ........................................................................ 8
2.2 Receive a call..................................................................... 9
2.3 End a call........................................................................... 9
2.4 Reject the incoming call .................................................... 9
2.5 Operations during the call................................................. 9
2.6 Hand free functions .......................................................... 9
3、Input methods ............................................................................... 10
3.1 Input methods ............................................................................... 10
3.2 Short Message ............................................................................... 10
3.3 Call logs ............................................................................................ 11
3.4 Contacts (phonebook)..................................................... 11
3.5 Settings ........................................................................... 13
3.6 Tools................................................................................ 13
4、Dial-up Settings for Internet access........................................ 14
5、Technical Specifications.............................................................. 14
5.1 Working conditions......................................................... 14
5.2 Technology parameters .................................................. 14
6、Common problems and causes ................................................ 15
7、Package contents.......................................................................... 16

WCDMA Fixed Wireless Phone user manual
3
Thanks for buying our products, in order to make the best use
of your phone, please read the manual carefully.
Attentions:
◇Please turn off the device in the places(gas, oil and
chemical factory, and around with inflammable and
explosive objects, etc) where do not allow to use wireless
transmitting devices.
◇Please use slightly damp or anti-static dishcloth to clean the
device, other than use dry or cloth that is easily make static.
Do not use chemical cleaner to clean the surface. Please
turn off the phone when cleaning the device.
◇Do not expose the unit to the intense sun, avoid heat.
◇Do not connect with other unmatched device.
◇Our company power adapter and batteries should be used.
Improper battery replacement or use other power supply
devices will be dangerous.
◇The charging time should be 12 hours for the first using.

WCDMA Fixed Wireless Phone user manual
4
Welcome to use our fixed wireless phone, make the best
use of the wireless network resources, and realize the
wireless terminal business communication. This unit has
good style and reliable quality.
This product meets the national standard indicators, the
standards of implementation: YD/T1626-2007 fixed
wireless phone technical requirements and test methods.

WCDMA Fixed Wireless Phone user manual
5
1、Brief Instruction
1.1 Keys location
1、LCD 2、right key 3、left key 4、direction key
5、send 6、on/off 7、numerical keys
8、symbol 9、switch 10 、M1 11 、M2
12 、M4 13 、M3 14 、SMS 15 、Redial
16、hands free key

WCDMA Fixed Wireless Phone user manual
6
1.2 Keys description
·Left:
In on-hook status, press the key to enter main menu;
In menu status, press the key to carry out the function shown
in the left bottom of LCD.
Right:
In on-hook status, press the key to enter the phonebook;
In menu status, press the key to carry out the function shown
in the right bottom of LCD;
In edit status, press the key to return to last menu;
In on-hook status, press the key to reject the coming call when
calling (do not disturb function);
In dialing status, press the key to delete the last character.
·On/Off:
In menu status, press the key to quickly exit to standby state;
On-hook state, press the key to reject the coming call when
calling (do not disturb function);
In the calling status, press the key to end the current calling
and return to standby status;
In off state, press the key for a few seconds, the phone will
enter boot state.

WCDMA Fixed Wireless Phone user manual
7
In on state, press the key for a few seconds, the phone will
enter close/off condition.
·Numerical keys:
In on-hook, off-hook or hands free status，press the related
keys to dial out the phone number;
In input state, input the corresponding letter according to
different input methods.
·# Key:
In input state, press the key to enter the switch between input
methods.
·* key:
In input state, press the key to input the special symbol.
·Send key:
Enter a group of numbers, and then press the key to make a
call.
·S MS key:
Press this key to quick enter the SMS function.
·HF (Hands Free):
No need to pick up the handset to dial, press the key to have
hands free function.

WCDMA Fixed Wireless Phone user manual
8
·M1-M4 keys:
In standby status, press the key to dial the setting number
directly.
2、Usage
Before putting into use, make sure the plug or battery is
connected correctly and the SIM card has been inserted
correctly, waiting for the phone been turned on, then you can
use. The signal icon E stands for 2G network, W for 3G.
Warning: Before pulling out SIM card, phone should be
power off. Inserting or pulling out SIM card is not allowed
absolutely when external power is connected; otherwise,
SIM card maybe damaged. Please avoid touching the Metal
surface of SIM card and place the SIM card far away from
the electric and magnetic area to prevent the information
in SIM card from being lost or damaged.
2.1 Make a call
1) In standby state, press the numerical key directly and
press [Send] key to dial out;
2) Pick up the handset or press[HF] to get dial tone,
then press the numerical key and [Send] key to dial out;
3) Find your wanted records in the phone book, call log, or

WCDMA Fixed Wireless Phone user manual
9
inbox, press [Send] key to call out or select call in the menu;
2.2 Receive a call
When a call comes, pick up handset or press [HF] to
receive the call;
2.3 End a call
1) In off-hook calling status, hang up the handset to end
the current call;
2) In hands free calling status, press the [HF] key to end
the current call.
3) Press [on/off] key to end the call.
2.4 Reject the incoming call
When a call comes, press [on/off] key to reject the call.
2.5 Operations during the call
Volume adjustment：During the call, you can press
Up/Down key to adjust the volume of the handset or HF.
During the call, you can press the numerical keys to send
out DTMF signal. Also you can press left key to enter the main
menu or select the mute function.
2.6 Hand free functions
In the standby status, press HF key to enter hand free mode,
after hearing the dial tone, you can make a call.

WCDMA Fixed Wireless Phone user manual
10
3、Input methods
3.1 Input methods
There are many inputting methods: en, EN, Abc, abc, ABC, 123
etc.
Press [#] key, you can switch inputting methods.
Press [*] key, you can input special symbols.
Press [0] key, you can input blank. (In the en, EN, Abc, abc,
ABC input method).
Press [0] to [9] key to input relevant letters or numbers; For
example, the numerical [2] key prints “A”, “B”,”C”, in the abc
inputting method, press key [2] once, it will display “a”; press
key [2] twice, it will display “b”; press key [2] three times, it
will display “c”.
3.2 Short Message
Write Message
There are many input methods, you can press # to switch
input methods and press * to input symbols.
Inbox
It is to store the received messages. You can carry out the
below actions: reply, delete, call, etc.

WCDMA Fixed Wireless Phone user manual
11
Outbox
It is to store the failed sending messages. You can carry out
the below actions: edit, resend, delete, etc.
Sentbox
It is to store the received messages. You can carry out the
below actions: forward, delete, call, message, etc.
Drafts
Exit suddenly when editing text, or save into Drafts when
editing text, all the text will be saved into Drafts.
3.3 Call logs
The phone has saved the recent dialed calls, received calls and
missed calls.
Delete all: it is to help you clear all call logs.
Call timers: you can check the last call, received calls, dialed
calls and call history; also you can clear the call timers into
zero.
You can select Options to carry out the below actions:
details,dial, write message, delete, all delete, etc.
3.4 Contacts (phonebook)
In standby status, press the corresponding soft keys to enter
Contacts.

WCDMA Fixed Wireless Phone user manual
12
You can carry out the following operations: new, view, write
message, edit, call, delete, mark, copy, etc.
New
There are many ways to create the new contact in the
Contacts:
In standby status, press left sot key-find Contacts-select
Options-New, then add the contacts information;
In contacts list, message lists, press Options and add to
the Contacts according to the instructions.
Delete all
Delete all the contacts in the phone and (U) SIM card.
Copy
Copy the contacts into phone (or card): copy the contacts into
phone or card; contacts can be copied from card to phone or
from phone to card.
Others
Capacity checking: It is to check the storage capacity for (U)
SIM card and phone.
One key dial: you can set the corresponded shortcut key from
the numerical key 2 to key 9. You can press this key for some
seconds to dial out directly once you have set on this key.

WCDMA Fixed Wireless Phone user manual
13
Speed dial: you can set the shortcut key (M1-M4) here.
3.5 Settings
Call settings: You can set call divert, call waiting, call
barred, post-dialing delay, etc.
Phone settings: You can set the Time & Date; language;
restore the factory settings; shortcut settings, on/off
timing settings, etc.
Backlight: You can set the backlight here.
Security:
PIN: PIN code status, PIN code change.
Phone locked: you can set the power-on password.
Profiles: There is normal mode, mute mode, meeting
mode, outdoor mode, and indoor mode. You can set
the incoming call rings, message rings, volume
adjustment, other alert rings in the above modes.
3.6 Tools
There are calculator and alarm tools. You can set 3 alarms at
most.

WCDMA Fixed Wireless Phone user manual
14
4、Dial-up Settings for Internet access
Install the dial-up modem into the PC, inserting the 3G SIM
card into the phone and power on the phone, connect the
phone with PC, and then select the dial-up for Internet access.
5、Technical Specifications
5.1 Working conditions
Environment Temperature：-10℃~50℃
Humidity：0%~95%
Air Pressure：86kPa~106kPa
5.2 Technology parameters
GSM working mode:
Frequency Range：GSM850/1900MHz
Receiver Sensitivity：<-102dBM
Max Power: 32.53dbm
WCDMA working mode:
Frequency Range：1900MHz
Receiver Sensitivity：<-106dBM
Max Power: 22.16dbm

WCDMA Fixed Wireless Phone user manual
15
6、Common problems and causes
Malfunction
phenomenon
Possible Cause
Can not turn on
1. Battery is not installed
2. Battery is low power and
power adapter does not connect
PIN code error
1. Insert wrong SIM card
2. SIM card has been locked,
professional officer is needed to
initialize the phone
“Fall line”in
communication
1. Battery is weak
2. Signal strength is weak
Low level
Volume
Under talking status, press up/
down key to adjust volume
Can’t dial-up for
Internet access
1. The dial-up driver was not
installed into PC.
2. The USIM card didn’t
support this WCDMA
network.

WCDMA Fixed Wireless Phone user manual
16
7、Package contents
Items
Quantity (pc)
main unit
1
Handset
1
Spiral cord
1
TNC Antenna
1
Power adapter
1
User manual
1
Battery
1

FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Specific Absorption Rate (SAR) information:
This WCDMA Fixed Wireless Phone meets the government's requirements for exposure to
radio waves. The guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed to assure the safety of all persons
regardless of age or health.
FCC RF Exposure Information and Statement
The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types:
WCDMA Fixed Wireless Phone (FCC ID: ZMX3GKT1000) has also been tested against this
SAR limit. The highest SAR value reported under this standard during product certification for
use at the body is 1.015W/kg. This device was tested for typical body-worn operations with the
back of the handset kept 0mm from the body. To maintain compliance with FCC RF exposure
requirements, use accessories that maintain a 0mm separation distance between the user's body
and the back of the handset. The use of belt clips, holsters and similar accessories should not
contain metallic components in its assembly. The use of accessories that do not satisfy these
requirements may not comply with FCC RF exposure requirements, and should be avoided.
Body-worn Operation
This device was tested for typical body-worn operations. To comply with RF exposure
requirements, a minimum separation distance of 0mm must be maintained between the user’s
body and the handset, including the antenna. Third-party belt-clips, holsters, and similar
accessories used by this device should not contain any metallic components. Body-worn

accessories that do not meet these requirements may not comply with RF exposure requirements
and should be avoided. Use only the supplied or an approved antenna.
