Shark 800-00-36 User manual

Lithium Jump Starter &
Portable Power Supply
User Guide
MODEL: 800-00-36
CAPACITY: 10000mAh

FULLY CHARGE IMMEDIATELY AFTER PURCHASE.
Fully recharge after each jump starting, or every 3 months to
ensure long battery life.
Please read and understand all important safety and operating instructions before
using this item. In addition, please read and follow all vehicle and battery
manufacturers’ instructions and cautionary markings.

1
What’s In The Box.
• 800-00-36 Lithium Jump Starter & Portable Power Supply
• 100-240V AC Charging Adapter
• 15V/1A DC Charging Adapter
• Smart Jumper Clamps
• USB Cable
• User Guide
IMPORTANT SAFETY INSTRUCTIONS
1) Use the 800-00-36 for jump starting a 12V LEAD-ACID battery only. Do not
attempt to jump-start a vehicle with a non-rechargeable or defective battery.
2) Working in vicinity of a lead-acid battery is dangerous. Batteries generate
explosive gases during normal operation. Use in well-ventilated area. Battery acid
can cause permanent blindness. Avoid touching eyes while working near battery.
3) Do not smoke, strike a match, or cause a spark in vicinity of battery or engine.
Avoid explosive gas, flames and sparks.
4) Remove all personal jewelry, such as rings, bracelets, necklaces, and watches
before jumpstarting operations. These items may produce a short-circuit that can
cause severe burns.
5) To avoid damage to the vehicle’s electrical system, do not use the 800-00-36 on
a vehicle that has no battery installed.
6) Use of an accessory not recommended or sold by the manufacturer may result
in a risk of fire, electric shock or injury to persons. Do not operate with damaged
accessory(s).
7) Locate the 800-00-36 as far away from battery as jumper cables permit.

2
8) Do not expose to rain or wet conditions.
9) To reduce the risk of damage to electric plug and cord, pull by the plug rather
than the cord when disconnecting.
10) Operate with caution if the jump starter has received direct hit of force or been
dropped. Have it checked and repaired if damaged.
11) Any repair must be carried out by the manufacturer or an authorized repair
agent in order to avoid danger.
ABOUT 800-00-36 10000MAH
It features low voltage protection (for 800-00-36 itself), spark proof, reverse polarity
protection and short circuit protection. This item can instantly jump start most single
battery vehicles, up to 50+ (over 50) times on a fully charge. The 800-00-36 is also
equipped with USB power output, LED flash light, 19VDC power output and 12VDC
power output.
Technical Specification:
Battery Type
Lithium-ion Polymer
Battery Capacity
10000mAh
Starting Current
200A
Peak Current
400A
Jump Start
up to 5.0L Gas engine
USB Output
5V/1A, 5V/2A
LED Flashlight
５W

3
12V Output
10A Max
Operating Temperature
-10℃~ +50℃
Charging Temperature
10℃~ +45℃
Product Layout:
ABOUT SMART JUMPER CLAMPS
Flash Ught Button
Battery Status Indicator
Enging Start Socket
15V/1A Input Port
Power Button
12V/10A Port
USB Port
Green LED

4
“BOOST” Mandatory Operations:
1) If with correct connection between Jump Starter and vehicle battery (Red LED
keeps on and green LED is off), press and hold BOOST button for 3 seconds (after
a buzzer sound, the green LED is on and red LED is off). Usually this is because
the vehicle battery capacity is rather low.
2) Start the engine (same method as the normal operations in Page 6).
Cautions:
1) Under normal circumstances, do not use the mandatory operations.
2) The spark proof, reverse polarity protection and short circuit protection features
are disabled after Boost button is pressed. Pay very close attention to the polarity
of the battery before using this mode. Do not allow the positive and negative
battery clamps to touch or connect to each other as the item will generate sparks
EC5 Plug
Positive Clamp
Negative Clamp
BOOST Button
Red LED

5
and high heat if not used properly.
LED and Buzzer Communication:
No.
Red LED
Green LED
Buzzer
Sound
Condition
1
On
Off
One sound
Jumper cable and
EPS-204 are connected.
2
Off
On
One sound
Jumper cable and
vehicle battery are
connected. Ready to
start the engine.
3
Slow flash
Off
No buzzer
Lithium battery voltage
in EPS-204 is rather low.
4
Slow flash
Off
No buzzer
Have not turned on the
ignition switch within the
regulated time. To
resolve this, you need
remove clamps from
vehicle battery, and
connect again when
No.1 condition occurs.
5
Fast flash
Off
Fast buzzer
Red and black clamps

6
are connected with each
other.
6
Fast flash
Off
Fast buzzer
Reverse connection of
clamps.
7
Off
Fast flash
No buzzer
Engine is started.
8
Off
Fast flash
No buzzer
Vehicle’s battery voltage
is higher than Jump
Starter’s.
CONNECTING TO THE BATTERY
1) Identify polarity of battery posts. The positive battery terminal is typically marked
by these letters or symbol (POS,P,+). The negative battery terminal is typically
marked by these letters or symbol (NEG,N,-).
2) Do not make any connections to the carburetor, fuel lines, or thin metal parts.
3) Identify if you have a negative or positive grounded vehicle. This can be done by
identifying which battery post (NEG or POS) is connected to the chassis.
4) For a negative grounded vehicle (most common): connect the RED POSITIVE
jumper clamp first to the positive battery terminal, then connect the BLACK
NEGATIV jumper clamp to the negative battery terminal or vehicle chassis (if you

7
are unsure about vehicle chassis, just connect to battery terminal).
5) For a positive grounded vehicle (very uncommon): connect the BLACK
NEGATIV jumper clamp first to the negative battery terminal, then connect the RED
POSITIVE jumper clamp to the positive battery terminal or vehicle chassis (if you
are unsure about vehicle chassis, just connect to battery terminal).
6) When disconnecting, disconnect in the reverse sequence, removing the
negative first (or positive first for positive ground systems).
JUMP STARTING
1) This unit is only for emergency use, not for frequent commercial use! ENGINE
START socket is ALWAYS activated! Do not attempt to jumpstart your vehicle when
the 800-00-36 battery capacity is below 25% (battery status indicator: 1 solid LED
lit).
2) Turn off the vehicle ignition and all accessories (radios, lights, air conditioners,
etc.), and disconnect electronic devices.
3) Connect the jumper clamps to the correct polarity battery terminals.
4) Connect the EC5 plug of jumper cables to the ENGINE START socket of
800-00-36.
5) Try starting the vehicle (turn on the ignition switch). Most vehicles will
immediately start. Stop if the vehicle does not start after 5 seconds of engine
cranking. The jumpstart feature is designed for short term operation only, and more
than 5 seconds may cause damage to the unit. Allow the jump starter to cool down
for at least 3 minutes after each jumpstarting.
6) Disconnect the cable from the 800-00-36 immediately after engine starts, and
then remove from battery terminals.
CHARGING

8
This product is partially charged from the manufacturer. Fully charge the unit
immediately after purchase. In order to prolong the product life, be sure to fully
recharge the unit after each jump staring, or every 3 months even if this unit has
not been used. If battery voltage in the 800-00-36 is too low, this item will shut off to
prevent damage to itself. Recharge the unit as soon as possible to be activated and
fully charge it to ensure long battery life. In addition, we recommend not to charge
and discharge the unit at the same time.
AC Charging:
1) Insert AC charging adapter into charging jack of the unit.
2) Plug the other end of AC charging adapter into a wall socket.
3) Fully charge the unit.
4) When charging is complete, unplug the AC charging adapter from the wall
socket first, then from the charging jack on the 800-00-36.
DC Charging in Your Vehicle:
1) Turn the vehicle engine on.
2) Insert the DC charging adapter into the charging jack of the unit.
3) Plug the other end of DC charging adapter into vehicle’s cigarette lighter socket.
4) Fully charge the unit. Engine must keep running during entire charge.
5) When charging is completed, unplug the DC charging adapter from the vehicle
first, then from the charging jack on the 800-00-36.
Charging Time:
Charging time will differ based on the discharge level and the power source used. If
charging begins from 1 Flashing LED to full charge, it approximately takes 7 hours
for AC charging.
Battery Status Indicator:

9
The indicator LEDs will flash one by one during the period of charging. Different
number of indicator LEDs shows different storage level of 800-00-36.
Indicator
LEDs
Unlit
1
Flashing
1
Solid
2
Solid
3
Solid
4
Solid
Storage
Level
0%
˂5%
5% ~
25%
25%
~
50%
50%
~
75%
75%
~
100%

USB POWER
Connect the USB device to the 800-00-36 with either the original cable or the
included multi-tip cable (better use original cable of Apple® for Apple® products).
Press Power button to start USB power. When disconnected, the 800-00-36 will
automatically shut off. The number of times you can recharge a USB device will
vary between devices.
FLASHLIGHT
Press Flashlight button to start flashlight. Press once to switch lighting modes:
Steady On –Strobe –SOS –Off.
SUPPLY TO 12V DEVICES
The 800-00-36 can run/charge 12VDC appliances that draw 10 amps or less.
Connect the 800-00-36 to 12V devices with optional accessory (This item does not
include the accessory). Press Power button to start 12V power. When
disconnected, the EPS-204 will automatically shut off.
WARRANTY
1) This product is warranted to the original purchaser for a period of one (2) year
from the original shipping date, to be free of defects in material and workmanship.
2) Warranty Performance: During the above one (2) year warranty period, a
product with a defect will be replaced with a new one when the product is returned
to the manufacturer. The replacement item will be in warranty for the balance of the
original one (2) year warranty period.
3) This warranty is void if the product has been damaged by accident, in shipment,
unreasonable use, misuse, neglect, improper service, commercial use, repairs by

unauthorized personnel or other causes not arising out of defects in materials or
workmanship.
