Sharp BD-HP16U - AQUOS Blu-Ray Disc Player User manual

No. S29W8BDHP16U/
SERVICE MANUAL
BD-HP16U
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
TopPage
MODEL BD-HP16U
BLU-RAY DISC PLAYER
SAFETY PRECAUTION
IMPORTANT SERVICE NOTES......................i
Precautions for using lead-free solder ...........iii
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS ......................................1-1
CHAPTER 2. OPERATION MANUAL
[1] PARTS NAMES........................................... 2-1
CHAPTER 3. REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS................ 3-1
[2] EXTENSION CABLE CONNECTION DI-
AGRAM.......................................................3-3
[3] IMPORTANT SERVICE NOTICE................3-3
[4] UPGRADING.............................................. 3-4
CHAPTER 4. TROUBLESHOOTING TABLE
[1] TROUBLESHOOTING TABLE.................... 4-1
CHAPTER 5. BLOCK DIAGRAM
[1] MAIN BLOCK DIAGRAM............................ 5-1
[2] ANALOG/POWER/LCD/OPERATION
BLOCK DIAGRAM......................................5-2
CHAPTER 6. PRINTED WIRING BOARD ASSEM-
BLIES
[1] MAIN PWB.................................................. 6-1
[2] ANALOG PWB............................................6-5
[3] POWER PWB .............................................6-7
[4] OPERATION-L PWB................................... 6-9
[5] LCD PWB..................................................6-10
CHAPTER 7. SCHEMATIC DIAGRAMS
[1] MAIN (1) CIRCUIT SCHEMATIC DIA-
GRAM......................................................... 7-1
[2] MAIN (2) CIRCUIT SCHEMATIC DIA-
GRAM.........................................................7-2
[3] MAIN (3) CIRCUIT SCHEMATIC DIA-
GRAM.........................................................7-3
[4] MAIN (4) CIRCUIT SCHEMATIC DIA-
GRAM.........................................................7-4
[5] MAIN (5) CIRCUIT SCHEMATIC DIA-
GRAM.........................................................7-5
[6] MAIN (6) CIRCUIT SCHEMATIC DIA-
GRAM.........................................................7-6
[7] MAIN (7) CIRCUIT SCHEMATIC DIA-
GRAM.........................................................7-7
[8] MAIN (8) CIRCUIT SCHEMATIC DIA-
GRAM.........................................................7-8
[9] MAIN (9) CIRCUIT SCHEMATIC DIA-
GRAM.........................................................7-9
[10] MAIN (10) CIRCUIT SCHEMATIC DIA-
GRAM.......................................................7-10
[11] MAIN (11) CIRCUIT SCHEMATIC DIA-
GRAM....................................................... 7-11
[12] MAIN (12) CIRCUIT SCHEMATIC DIA-
GRAM.......................................................7-12
[13] POWER CIRCUIT SCHEMATIC DIA-
GRAM.......................................................7-13
[14] ANALOG CIRCUIT SCHEMATIC DIA-
GRAM.......................................................7-14
[15] LCD CIRCUIT SCHEMATIC DIAGRAM...7-15
[16] OPERATION-L CIRCUIT SCHEMATIC
DIAGRAM.................................................7-16
Parts Guide
In the interests of user-safety (Required by safety regulation in some countries) the set should be restored to its
original condition and only parts identical to those specified should be used.

BD-HP16U
i
BDHP16U ServiceManual

SAFETY PRECAUTION
IMPORTANT SERVICE NOTES
IMPORTANT SERVICE NOTES
This Player is classified as a CLASS 1 LASER product.
The CLASS 1 LASER PRODUCT label is located on
the rear cover.
This product contains a low power laser device. To
ensure continued safety do not remove any cover or
attempt to gain access to the inside of the product.
Refer all servicing to qualified personnel.

BD-HP16U
ii
IMPORTANT SERVICE SAFETY PRECAUTION
WARNING
1. For continued safety, no modification of any circuit should be
attempted.
2. Disconnect AC power before servicing.
BEFORE RETURNING THE BD PLAYER (Fire &
Shock Hazard)
Before returning the BD player to the user, perform the following
safety checks:
3. Inspect all lead dress to make certain that leads are not pinched,
and check that hardware is not lodged between the chassis and
other metal parts in the receiver.
4. Inspect all protective devices such as non-metallic control knobs,
insulation materials, cabinet backs, adjustment and compartment
covers or shields, isolation resistor-capacitor networks, mechanical
insulators, etc.
5. To be sure that no shock hazard exists, check for leakage current in
the following manner.
Plug the AC cord directly into a 120 volt AC outlet.
Using two clip leads, connect a 1.5k ohm, 10 watt resistor paral-
leled by a 0.15 F capacitor in series with all exposed metal cabinet
parts and a known earth ground, such as electrical conduit or elec-
trical ground connected to an earth ground.
Use an AC voltmeter having with 5000 ohm per volt, or higher, sen-
sitivity or measure the AC voltage drop across the resistor.
Connect the resistor connection to all exposed metal parts having a
return to the chassis (antenna, metal cabinet, screw heads, knobs
and control shafts, escutcheon, etc.) and measure the AC voltage
drop across the resistor.
All checks must be repeated with the AC cord plug connection
reversed. (If necessary, a nonpolarized adaptor plug must be used
only for the purpose of completing these checks.)
Any reading of 0.75 Vrms (this corresponds to 0.5 mA rms AC.) or
more is excessive and indicates a potential shock hazard which
must be corrected before returning the monitor to the owner.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
SAFETY NOTICE
Many electrical and mechanical parts in BD player television have
special safety-related characteristics.
These characteristics are often not evident from visual inspection, nor
can protection afforded by them be necessarily increased by using
replacement components rated for higher voltage, wattage, etc.
Replacement parts which have these special safety characteristics are
identified in this manual; electrical components having such features
are identified by " " and shaded areas in the Replacement Parts List
and Schematic Diagrams.
For continued protection, replacement parts must be identical to those
used in the original circuit.
The use of a substitute replacement parts which do not have the same
safety characteristics as the factory recommended replacement parts
shown in this service manual, may create shock, fire or other hazards.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the
servicing guidelines which follow:
CAUTION: FOR CONT I N U ED PROTECTION
AGAINST A RISK OF FIRE REPLACE ONLY WITH
SAME TYPE FUSE.
F901 (250V 3.15A)
DVM
AC SCALE
1.5k ohm
10W
TO EXPOSED
METAL PARTS
CONNECT TO
KNOWN EARTH
GROUND
0.15 µ F
TEST PROBE

BD-HP16U
iii
Precautions for using lead-free solder
Employing lead-free solder
• “All PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals.
The alphabetical character following LF shows the type of lead-free solder.
Example:
Using lead-free wire solder
• When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional lead wire solder may cause dam-
age or accident due to cracks.
As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40 °C, we recommend you to use a dedicated soldering
bit, if you are not familiar with how to obtain lead-free wire solder or soldering bit, contact our service station or service branch in your area.
Soldering
• As the melting point of lead-free solder (Sn-Ag-Cu) is about 220 °C which is higher than the conventional lead solder by 40 °C, and as it has poor
solder wettability, you may be apt to keep the soldering bit in contact with the PWB for extended period of time. However, Since the land may be
peeled off or the maximum heat-resistance temperature of parts may be exceeded, remove the bit from the PWB as soon as you confirm the
steady soldering condition.
Lead-free solder contains more tin, and the end of the soldering bit may be easily corroded. Make sure to turn on and off the power of the bit as
required.
If a different type of solder stays on the tip of the soldering bit, it is alloyed with lead-free solder. Clean the bit after every use of it.
When the tip of the soldering bit is blackened during use, file it with steel wool or fine sandpaper.
• Be careful when replacing parts with polarity indication on the PWB silk.
Lead-free wire solder for servicing
LFa
Indicates lead-free solder of tin, silver and copper.
LF a/a
Indicates lead-free solder of tin, silver and copper.
Part No. Description Code
ZHNDAi123250E J φ0.3mm 250g (1roll) BL
ZHNDAi126500E J φ0.6mm 500g (1roll) BK
ZHNDAi12801KE J φ1.0mm 1kg (1roll) BM

BD-HP16U
1 – 1
BDHP16U ServiceManual

CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
General
Power supply AC 120V, 60Hz
Power consumption (Normal) 19 W
Power consumption (Standby) 0.5 W (When "Quick Start" is set to "No")
Dimensions Approx. 17
1
/
64
x2
9
/
32
x10
1
/
4
inch (Wx H x D)
Approx. 432 mm x 58 mm x 260 mm (W x H x D)
Weight Approx. 6.4 lbs. (2.9 kg)
Operating temperature 41°F to 95°F (5°C to 35°C)
Storage temperature -4°F to 131°F (-20°C to 55°C)
Operating humidity 10 % to 80 % (no condensation)
TV systems NTSC system
Playback
Playable discs BD-ROM, BD-RE Dual Layer, BD-R Dual Layer,
DVD Video, DVD+RW/+R/-RW/-R Dual Layer (Video/VR format),
Audio CD (CD-DA), CD-RW/R (CD-DA, JPEG file format)
Input/Output
HDMI HDMI 19-pin standard connector (1080p 24Hz output)
HDMITM (V.1.3 with Deep Color, x.v.Color, Dolby TrueHD, DTS-HD Master Audio |
Essential)
Component video output Output level:
Y: 1 Vp-p (75 ohms)
P
B
/C
B
,P
R
/C
R
: 0.7 Vp-p (75 ohms)
Jacks: RCA jack
Video output Output level: 1 Vp-p (75 ohms)
Jack: RCA-pin jack
Digital audio optical output Terminal: Square Optical terminal
Audio output Output level: 2 V rms (Output impedance: 1k ohms)
Jacks: RCA jack
USB input USB 2.0 High Speed (480Mbit/s) correspondence (for Local storage/Software
update)
ETHERNET 10BASE-T/100BASE-TX
Specifications are subject to change without notice.

BD-HP16U
2 – 1
BDHP16U ServiceManual

CHAPTER 2. OPERATION MANUAL
[1] PARTS NAMES
Main Unit (Rear)
Main Unit (Front)
Major Components
85
3
6 7 94
21
10 11 12
1
2
3
6 74 5
9
810
HDMI cable holder on the rear of the main
unit
This Player comes with a dedicated cable holder so that the HDMI
cable does not place direct weight and stress on the terminal. When
connecting the HDMI cable, be sure to pass the cable through the
cable holder and secure it.
CAUTION
Do not pull on the HDMI cable when it is connected to the terminal, as
this can damage the terminal or cause a poor connection.
•
Press down on the tab and pull it towar ds you.
Pass the HDMI cable (commercially available) through the
cable holder.
Press in on the tab until it clicks into position.
1
2
3
Connect the HDMI cable to
the rear of the main unit while
providing some slack.
COMPONENT VIDEO OUT jacks
VIDEO output jack
2CH AUDIO output jacks
DIGITAL AUDIO OUT OPTICAL
terminal
ETHERNET terminal
BD STORAGE/SERVICE terminal
BD STORAGE
SERVICE for software
HDMI OUT terminal
HDMI cable holder (See below.)
Cooling fan
The cooling fan operates while the
power to the Player is on.
AC IN terminal
1
2
3
4
5
6
7
8
9
10
OPEN/CLOSE
Flap door
Disc tray
ON/STANDBY indicator
1
2
3
4
POWER
PLAY
STOP
PAUSE
5
6
7
8
AQUOS PURE MODE indicator
Remote control sensor
Front panel display
BD/DVD/CD mode indicator
9
10
11
12
HDMI cable

BD-HP16U
2 – 2
Remote Control Unit
POWER
OPEN/CLOSE
AUDIO, SUBTITLE
Number buttons
REPEAT
SKIP/
SKIP/
PAUSE
PLAY
TOP MENU/TITLE LIST
Cursor buttons ( / / / ), ENTER
EXIT
A (Red), B (Green), C (Blue), D (Yellow)
(Lock) (See below.)
COMPONENT RESET
DISPLAY
TV CONTROL buttons
FUNCTION
FWD
REV
STOP
POP-UP MENU
RETURN
HDMI
SETUP
Keylock function
You can set the keylock to prevent accidental operations.
This function allows TVs compatible with AQUOS LINK to
also perform a Key Lock on the player.
Press and hold (Lock) for more than 5 seconds.
Each time you perform this operation, the function is activated
or deactivated.
If you try to operate the Player while the keylock function is
set, “Hold” blinks on the front display panel to indicate that the
keylock function is set.
•
•
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
1
2
3
5
4
6
7
8
9
10
11
12
13
16
17
18
19
20
21
22
23
14 24
15 25

BD-HP16U
3 – 1
BDHP16U ServiceManual

CHAPTER 3. REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS
1. Removing the tray cover
1. Eject the tray by open the Front door and inserting a pin into the
compulsory eject hole, then remove the Tray cover.
2. Removing the cabinet and the panel
1. Remove two screws and three screws from the Top cabinet.
2. Unhook claws of the Front panel and remover the Front panel.
3. Removing the BD drive
1. Disconnect the BD FFC between the BD drive and Main PWB .
2. Remove three screws and two screws , remove the BD drive
(with the angle) upward.
3. Remove two screws and remove the BD drive.
4. Removing the front PWB
1. Disconnect the LCD FFC between the LCD PWB and MAIN PWB.
2. Remove three screws .
Insert
a pin
Tray cover
Front door
Top cabinet
2
1
1
Front panel
BD drive angle (Left)
BD drive
BD FFC
3
5
4
Operation-L
PWB LCD PWB
LCD FFC
6
6

BD-HP16U
3 – 2
5. Removing the fan and the rear terminal board
1. Remove two screws .
2. Remove six screws .
3. Disconnect the fan cable connector and remove the Fan.
6. Removing each PWB
1. Disconnect the board to board connector from the Main PWB and
Analog PWB, then remove two screws .
Disconnect the board to board connector between the Main PWB
and Power PWB.
2. Remove two screws .
3. Remove two screws .
4. Remove the Insulation sheet.
8
8
7
Rear terminal board
Fan
Insulation
sheet
Power PWB
11
Main PWB
10
Analog PWB
9

BD-HP16U
3 – 3
[2] EXTENSION CABLE CONNECTION DIAGRAM
[3] IMPORTANT SERVICE NOTICE
1. To replace the Main CBA, perform the items 9 - 12 of [4] Upgrading and confirm the version: it is necessary to upgrade with a disc to the latest ver-
sion if the CBA version is old.
2. The IC7201 and IC8505 cannot be replaced because they have the BD-playback key already written. Accordingly, the IC8502 that has the soft-
ware written together with the IC8505 cannot be replaced either. Keep also in mind that the IC8503 cannot be replaced either because of the
model information on it.
3. After replacing the E2PROM for front-end software (IC2505), perform Menu - Miscellaneous Settings - Reset Settings.
Parts Code Price Code Name/Description Pin
QCNW-E227WJPZ CL CN901 <=> SC9001, SC5601 <=> CN2301 23
㪪㪚㪐㪇㪇㪈
㪙㪛
㪛㪩㪠㪭㪜
㪤㪘㪠㪥
㪧㪮㪙
㪦㪧㪜㪄㪣
㪧㪮㪙
㪘
㪪㪚㪐㪇㪈
㪝㪘㪥
㪚㪥㪐㪇㪉
㪧㪦㪮㪜㪩
㪧㪮㪙
㪚㪥㪉㪌㪇㪈
㪧㪐㪇㪉
㪣㪚㪛
㪧㪮㪙
㪪㪚㪈㪈㪇㪈
㪚㪥㪊㪇㪇㪈 㪪㪚㪊㪇㪇㪈 㪪㪚㪌㪍㪇㪈
㪘㪥㪘㪣㪦㪞
㪧㪮㪙
㪚㪥㪉㪊㪇㪈
㪘
㪚㪥㪐㪇㪈
A
㪨㪚㪥㪮㪄㪜㪉㪉㪎㪮㪡㪧㪱
㪍㪇㪇
㪘
㪚㪥㪐㪇㪈㹤㪪㪚㪐㪇㪇㪈
㪪㪚㪌㪍㪇㪈㹤㪚㪥㪉㪊㪇㪈
㪬㫊㪼㪻㩷㫀㫅㩷㫋㪿㪼㩷㪸㫍㫆㪹㪼
㫋㫎㫆㩷㫇㫀㪼㪺㪼㫊㪅㩷䋨㪉㪊㪧㫀㫅䋩

BD-HP16U
3 – 4
[4] UPGRADING
1. Press [Power] button to turn the switch on, then wait till the BD_LED changes from blinking to lit.
2. Press [Tray Open/Close] button to open the Tray, put the upgrade disc on the tray and close the tray.
3. The power automatically turns off. Then it turns on again and the upgrading with the disc will start.
4. During the upgrading, the mode indicator stays blinking in white as "V-up" message keeps blinking on LCD.
"NOW UPDATING DO NOT UNPLUG AC CORD" appears on the monitor screen.
And the version updating progress is expressed in %.
5. When upgrading with the disc is completed, the Tray automatically opens.
* If the front-end software was upgraded, the standby LED lights up halfway as well as the mode indicator starts blinking alternately in white and
blue.; the Tray will open after the upgrading is completed and the power will turn off. (Go to step 8.)
6. When the upgrading is completed, the following appears on the monitor screen.:
"SOFTWARE UPDATE IS COMPLETE"
If the version updating fails, "FAILED TO COMPLETE UPDATE RETRY SOFTWARE UPDATE" is displayed. Take out the disc, turn off the power
and take the procedure again starting from [1] above.
7. Remove the disc from the Tray and press any other button of the Main Unit than [Power], then the Tray will close and the power will automatically
turn off. (Confirm the power-off by stop of the Cooling Fan.)
* If [Power] button is pressed, the power will turn off with the Tray open.
8. Press [Power] button to turn the power on, then wait till the MODE INDICATOR changes from blinking to lit.
9. Press the [SETUP] button on the remote controller, and the menu screen shows up (if the wallpaper screen is used).
* There is no need to take this step, because just after the power is turned on, the menu screen shows up.
10.Select [SETTINGS] first and then [VERSION]. (Press the ENTER button.)
11.The version of the currently installed software appears on the monitor screen. Compare with the version of this updated software, make sure the
version is just the same. If the version id not updated, take the procedure again from Step [2].
12.Press [Power] button to turn the power off. (Confirm the power-off by stop of the cooling fan.)
NOTE: Do not unplug the AC cord during version updating.
* The version updating cannot be made on the menu screen. Make the wallpaper onscreen.
Monitor: "CANNOT UPDATE. FINISH PLAYBACK OR EDIT AND SET A DISC"
Consult with your Services Company as we cannot provide the upgrading software.
Start
Turn the power on.
Open the tray,
put the upgrade disc and
close the tray
The power automatically
turns off. Then, the power
turns on automatically and
the upgrading starts.
Monitor:
"NOW UPDATING
DO NOT UNPLUG AC CORD"
ex.
غغغع  غغ 20%
The tray opens
automatically.
Upgrading completed No
Yes
Monitor:
"SOFTWARE UPDATE IS
COMPLETE"
Remove the disc and turn
the power off.
Remove the disc and turn
the power off.
Turn the power on and
confirm the version.
End Restart
Upgrading successful. Upgrading unsuccessful.
Monitor:
"FAILED TO COMPLETE
UPDATE
RETRY SOFTWARE
UPDATE"

BD-HP16U
4 – 1
BDHP16U ServiceManual

CHAPTER 4. TROUBLESHOOTING TABLE
[1] TROUBLESHOOTING TABLE
1. MAIN UNIT
The main PWB circuit doesn't function when the power is turned ON.
The power does not become ON. Is the level of pin (6) of SC9001 at Low?
The power becomes OFF. Check the peripheral circuits
of IC2503.
Check the
IC9001, 9002, 9003, and their
peripheral circuits.
YES
NO
NO
NO
Is the fan turning on when the power
is turned ON?
Check the fan, fan power and their
peripheral circuits.
YES YES NO
YES
YES
FLOW CHART No.1
NO
Are AT_12V,SUB_PC-8V supplied to
SC9001?
Check the power PWB.
YES
NO
Is 1.05V supplied to TL9016 3.3V to
TL9017, 1.8V to TL 9018 respectively?
Check the IC9001, 9002, 9003 and their
peripheral circuits.
YES
NO
Is 27MHz detected at R7260? Check X7201 and its peripheral circuits.
YES
NO
Does pin (1) of CN7205 turn to High and
Low on start-up?
Check IC7802, IC7803, IC7804, IC7805,
IC8502, IC8505 and their peripheral
circuits.
Check IC7201 and its peripheral circuits.
The drive doesn't function normally.
Are 12V and 5V supplied to the drive? Check DRIVE_12V of Q9014, DRIVE_5V of Q9012 and their
peripheral circuits.
NO
YES
Are DRIVE 3.3v to IC7201? Check IC9006 and its peripheral circuits.
NO
YES
Are DRIVE 1.5V to IC7201? Check IC9005 and its periphral circuits.
NO
YES
Check the drive.
FLOW CHART No.2

BD-HP16U
4 – 2
No video signal output from the main PWB.
Is video signal input into each terminal of SC5601?
1) S-VIDEO and COMPOSIT OUTPUT TERMINALS
࡮2 pins (SUB_YOUT), 4 pins (SUB_COUT)
2) CONPONENT-VIDEO TERMINAL
࡮6 pins (MAIN_YOUT), 8 pins (MAIN_PBOUT),
10 pins (MAIN_PROUT)
NO
YES
Is video signal input into the base of transistor for each buffer?
1) S-VIDEO and COMPOSIT OUTPUT TERMINALS
࡮Q5604, Q5605
2) CONPONENT-VIDEO TERMINAL
࡮Q5601, Q5602, Q5603
Check SUB_PC_5V line.
Check SC5601.
YES
NO
Check IC7201.
FLOW CHART No.3
No audio signal output from the main PWB
Is audio signal input into terminal of each connector?
1) 2ch analog audio connection
Pins (12) (MAIN_L) and (14) (MAIN_R) of SC5606.
YES
NO
Is there output from DAC?
1) 2ch analog audio connection
Check pins (9) and (10) of IC5606.
Check the peripheral circuits of SC5602.
Check the ANALOG pwb.
YES
NO
Is 5V supplied to pin (13) and -8V to pin (11) of IC5606
respectively?
Check the peripheral circuits of IC5602.
NO
Replace IC5606.
YES
YES
Is any digital signal input into pins (1) - (4) of the IC5606?
Check the peripheral circuits of IC7201.
NO
FLOW CHART No.4

BD-HP16U
4 – 3
No video and audio signal output from HDMI terminal.
Replace the TV set (cable) and reconfirm.
Still no video and audio output?
YES Defective TV set or cable. Or, check the contact of soldered
connector of SC4201.
NO
Are output voltages of IC4204 as 5V, IC4202 as 3.3V OK? Check the IC4204 and IC4202 or peripheral circuits.
NO
YES
Is the data line functioning (Hi/Low)?
Check IC7802, IC7803, IC7804, IC7805, IC8502, IC8505 and
their peripheral circuits.
Replace IC7201.
Or rewrite the main software.
NO
YES
FLOW CHART No.5
No audio signal output from the Optical and Coaxial terminal.
Is there digital audio signal at R2201? YES
NO
Check the IC7201 and their peripheral circuits.
Check the CN2401 and the peripheral circuits.
FLOW CHART No.6

BD-HP16U
4 – 4
2. ANALOG UNIT
No picture appears with the component or composite signal.
Is the video signal outputted from the component or
composite terminal J2401?
YES
NO
Is the HDMI output set for anything other than 1080P? Set the HDMI output for anything other than 1080P.
(If the HDMI output is set for 1080P, the component and composite
signals are not outputted.)
Mount C2301, C2306, C2313, C2317 and C2320 in place.
If no signal comes in, replace IC2301.
(When the 5V signal is fed to pins (7) and (21) of IC2301.)
Are pins (2) (composite, output mute) and (13)
(component output mute) of IC2301 at "H" level?
("H": Mute)
Disconnect the output coupling capacitors C2305, C2314, C2318
and C2321. If no signal comes out of the IC, replace this IC.
Check the connected cable and its connection tightness.
Check also the input of connected TV set.
Disconnect CN2301.
Is there the signal at each terminal of SC5601?
Check the PMUTE1, PMUTE2
and F_MUTE lines.
Check IC2301 and its
peripheral circuits.
Or replace IC2301 as required.
NO
YES
Is the video signal inputted to the component or composite
terminal J2401?
Check each terminal.
Check the line between IC2301 and each terminal.
NO
YES
Are there the following input signals at the CN2301 terminals?
ԘComponent
pin (6)࡮࡮࡮MAIN_Y
pin (8)࡮࡮࡮MAIN_PB
pin (10)࡮࡮࡮MAIN_PR
ԙComposite
pin (2)࡮࡮࡮SUB_Y
pin (4)࡮࡮࡮SUB_C
MAIN FLOW CHART No.3
NO
NO
NO
YES
YES
YES NO
YES
Are there the following input signals at the IC2301 terminals?
ԘComponent
pin (8)࡮࡮࡮CY_IN
pin (10)࡮࡮࡮CB_IN
pin (12)࡮࡮࡮CR_IN
ԙComposite
pin (1)࡮࡮࡮C_IN
pin (5)࡮࡮࡮Y_IN
Are there the following output signals at the IC2301 terminals?
ԘComponent
pin (20)࡮࡮࡮CY_OUT
pin (17)࡮࡮࡮CB_OUT
pin (15)࡮࡮࡮CR_OUT
ԚComposite
pin (25)࡮࡮࡮V_OUT
Check the line between CN2301 and IC2301.
NO
Check the SUB_PC_5V line.
Is the SUB_PC_5V signal fed to pins (7) and (21) of IC2301?
NO
YES
YES
FLOW CHART No.1

BD-HP16U
4 – 5
3. OPERATION/LCD UNIT
The reproduced audio signal does not come from each audio output terminal.
Is the audio signal outputted from J2401? YES
NO
Check the pattern up to J2401.
Check the connected cable and its connection tightness.
Check also the input of connected TV set or amplifier.
Disconnect CN2301. Is there the audio signal at SC5601?
Does the mute circuit function?
Is the audio signal inputted to J2401?
Check the mute circuit and the AUDIO_MUTE signal lines.
Muting occurs when AUDIO_MUTE signal are at "H" level.
YES
NO
Are there the following input audio signals at CN2301?
pin (16)࡮࡮࡮AUD_MAIN_L
pin (18)࡮࡮࡮AUD_MAIN_R
MAIN FLOW CHART No.4
NO
NO
YES
YES
Check the pattern up to R2212 and R2213.
NO
Check each terminal.
YES
FLOW CHART No.2
The remote controller does not function.
The main unit controls function, but the remote controller
controls fail to function.
YES
YES
Check the line between pin (1) of RMC1101 and pin (23) of IC2503.
Check the remote control codes 1, 2 and 3.
Using the remote controller, is the "L" pulse signal outputted
from pin (1) of RMC1101?
Is the "L" pulse signal inputted to pin (23) of IC2503?
Replace RMC1101 or the remote control receiver.
NO
NO
Is the remote control code as specified? NO
YES
Is the 5V voltage applied to pin (3) of the RMC1101 remote
control receiver?
Check the AT_5V line.
NO
YES
Check IC2503. Replace it as required.
YES
FLOW CHART No.1

BD-HP16U
4 – 6
The LCD display fails to light up.
Is the LCD unit cracked or otherwise damaged?
NO
NO
Check all the signal lines between SC1101 and IC1101.
Replace LCD1101.
Are there the following inputs to the following pins: 5V at pin
(37), LCD_RST at pin (36), LCD_CS at pin (42), LCD_CLK at
pin (43) and LCD_DATA at pin (44), all on IC1101?
Are there the following outputs from the following pins: 5V at
pin (1), LCD_CS at pin (10), LCD_DATA at pin (12),
LCD_CLK at pin (11) and LCD_RST at pin (7), all on SC1101?
Check IC1101 and its peripheral circuits. Or replace IC1101 as
required.
YES
YES
Check the connection between CN2501 and CN1101.
YES
Is the display-designated SEG or COM signal inputted to
LCD1101?
YES
Replace LCD1101.
YES
NO
Are the signals outputted from pins (1 thru 17, 33, 34 and 35)
of IC1101?
Check the pattern between IC1101 and LCD1101.
YES
NO
Are there the following inputs to the following pins: 5V at pin
(1), LCD_CS at pin (10), LCD_DATA at pin (12), LCD_CLK
at pin (11) and LCD_RST at pin (7), all on CN2501?
NO
Check the following signal flows:
LCD_DATA; Pin (99) of IC2503 to pin (12) of CN2501
LCD_CLK; Pin (100) of IC2503 to pin (11) of CN2501
LCD_RST; Pin (1) of IC2503 to pin (7) of CN2501
LCD_CS; Pin (45) of IC2503 to pin (10) of CN2501
Check also IC2503 and its peripheral circuits.
NO
Is the 5V signal fed to pin (1) of CN2501?
NO
Check the AT_5V line.
FLOW CHART No.2
The LCD backlight fails to light up.
Is the "H" voltage applied at the non-base-connected side of
Q1107 on R1138?
NO
NO
Check the pattern between pin (6) of SC1101 and R1138.
Is the "H" potential outputted from pin (38) (LED_BL_LCD) of
IC2503?
Check IC2503 and its peripheral circuits.
Or replace IC2503 as required.
Check the line between pin (38) of IC2503and pin (6) of CN2501.
YES
Is the "H" potential applied at pin (6) (BL_LCD) of SC1101? YES
Check Q1107, LED and the current-limiting resistor.
YES
NO
Is the "H" potential applied at pin (6) (BL_LCD) of CN2501? Check the FFC between SC1101 and CN2501.
YES
NO
FLOW CHART No.3

BD-HP16U
4 – 7
The LED power indicator fails to light up.
Is the power as specified?
YES
NO
Check each transistor, LED and the current-limiting resistor.
Is there the "H" potential at pin (4) (LED_STBY) or pin (5)
(LED_PON) of P902?
Is the "H" potential outputted from pin (51) (LED_STBY) or pin
(49) (LED_PON) of IC2503?
Check the connector between SC1201 and P902.
YES
Check the line between IC2503 and P902.
YES
Is the "H" potential applied at the base of Q1202 or Q1203? YES
POWER FLOW CHART No.1 or POWER FLOW CHART No.3
NO
NO
Check IC2503 and its peripheral circuits. Or replace IC2503 as
required.
NO
Is there the "H" potential at pin (4) (LED_STBY) or pin (5)
(LED_PON) of SC1201?
Check the line between SC1201 and the base of each transistor.
YES
NO
FLOW CHART No.4
The LED mode display indicator fails to light up.
* White LED: Blinking while the disc is being loaded.
Lights up when the disc has been recognized.
* Blue LED: While the disc is being played back.
Is the "H" potential applied at the base of Q1104 or Q1105?
NO
NO
Check the line between SC1101 and the base of each transistor.
Is there the "H" potential output from the following pins in each
mode: Pin (52), (LED_MODE) or pin (53) (LED_PLAY),
all on IC2503?
Check IC2503 and its peripheral circuits. Or replace IC2503
as required.
Check the line between IC2503 and CN2501.
YES
Is there the "H" potential at pin (5) (LED_MODE) or pin
(4) (LED_PLAY) of SC1101?
YES
Check each transistor, LED and the current-limiting resistor.
YES
NO
Is there the "H" potential at pin (5) (LED_MODE) or pin (4)
(LED_PLAY) of CN2501?
Check the FFC between SC1101 and CN2501.
YES
NO
FLOW CHART No.5

BD-HP16U
4 – 8
4. POWER UNIT
A button fails to work.
Is the button switch contact and tightness as specified?
YES
YES
Check the line between each button and IC2503. Or check the
pull-up resistor at pin (72) of IC2503. (R2578)
Is the control voltage properly applied at pin (72) (KEY_EJCT)
and pin (73) (KEY_STBY) of IC2503? (While the relevant
button is held down, the "H" level changes to "L" level.)
NO
Check the relevant switch. Replace it as required.
NO
Check IC2503 and its peripheral circuits. Or replace IC2503
as required.
FLOW CHART No.6
Power does not come ON.
Is the fuse working properly? If the fuse still blows after replacement, refer to "The fuse blows" in
the FLOW CHART No.2.
Does the power come back if the power cable is unplugged
and plugged again after several seconds?
Is a part of primary circuit causing leaks, short-circuit or open circuit
(L901, L902, D901, T901, IC901, C911 and their peripheries)?
Check D952, L951, C955, C958 and C961 of the AT_12V line.
YES
NO
Check the power failure detection circuit (IC2508 and its periphery).
NO
NO
NO
Is AT_12Vline working normally?
Is voltage normal at lines AT_-12V and SUB_PC_-8V? Check each rectifier circuit and SW circuit of the secondary circuit.
YES
YES
YES
Is pin (17) of IC2503 at "H" level?
YES
Check or replace the peripheral circuits of IC2503.
NO
FLOW CHART No.1
The fuse blows.
Is a part of primary circuit causing leaks, short-circuit or open
circuit (L902, L901, D901, T901, IC901, C911 and their
peripheries)?
Check if the rectifier diode and the circuit are causing short-circuit in
each rectifier circuit of the secondary circuit. (D952)
Case(1) Case(2)
FLOW CHART No.2

BD-HP16U
4 – 9
The power does not come ON from power OFF status.
Is AT_5V line working normally? Check the circuit of AT_5V.
Check the function of Microcomputer in IC2503 and its peripheral
circuits.
When the Power key (S1201) is pressed, is pin (73) of IC2503
at "L" level?
YES
NO
NO
NO
Is pin (57) of IC2503 (STANBY_CTL) at "H" level?
Is pin (74) of IC2503 (MAIN_P-CON) at "H" level?
Check the line between S1201 and IC2503.
NO Check the peripheral circuits of IC2503.
YES
YES
Is pin (59) of IC2503 (DRIVE_P-CON) at "H" level? NO Check the peripheral circuits of IC2503.
YES
Are DRIVE_12V and DRIVE_5V output? NO Check the DRIVE_12V and DRIVE_5V circuits
(Q9014, Q9012, etc.).
YES
Check or replace the peripheral circuits of IC2503.
YES
FLOW CHART No.3
