Sharp ViewCam VL-MC500S User manual

VIDEOKAMERA MED FLYTANDE KRISTALLSKÄRM
CAMCORDER COM VISOR DE CRISTAL LÍQUIDO
LIQUID CRYSTAL DISPLAY CAMCORDER
MANUAL DE OPERAÇÃO
BRUKSANVISNING
OPERATION MANUAL
VL-MC500S/hyou3; 02/8/28/18:00
BRUKSANVISNING MANUAL DE OPERAÇÃOOPERATION MANUAL
Tryckt i Japan
Impresso no Japão
Printed in Japan
TINSLA016WJZZ
02P07-JKG
SHARP CORPORATION
VL-MC500S
SVENSKA ENGLISH
VL-MC500S
PORTUGUÊS

VL-MC500S-CE1; 02/5/17/18:00

i
ENGLISH
ENGLISH
OPERATION MANUAL
WARNING
TO PREVENT SHOCK
HAZARD, DO NOT EXPOSE
THIS APPLIANCE TO RAIN
OR MOISTURE.
This equipment should be used with
the recommended AC adapter, battery
charger or battery pack.
CAUTION
To prevent electric shocks and fire
hazards, do NOT use any other power
source.
CAUTION
To prevent shock, do not open the
cabinet. No user serviceable parts
inside. Refer servicing to qualified
dealer or service centre.
Important:
Audio-visual material may consist of
copyrighted works which must not be
recorded without the authority of the
owner of the copyright. Please refer to
relevant laws in your country.
Power supply:
This unit can be operated by
connecting it to either the AC adapter,
battery charger or battery pack. The
AC adapter incorporates the AUTO
VOLTAGE (AC 110–240 V, 50/60 Hz)
function.
NOTE
The LCD panel of this camcorder is a very high technology product with more than
120,000 thin-film transistors*, giving you fine picture detail. Occasionally, a pixel may
appear on the screen as a fixed point of blue, green, red, or black. Please note that
this does not affect the performance of your camcorder.
Trademarks
• Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
• DPOF is a trademark of CANON INC., Eastman Kodak Company, Fuji Photo Film Co., Ltd. and
Matsushita Electric Industrial Co., Ltd.
• All other brand or product names are registered trademarks or trademarks of their respective
holders.
*Specifications are subject to change without notice.
Before using the camcorder, please read this operation manual carefully,
especially page vi.
VL-MC500S-GB-*i-viii 02.7.16, 3:20 PM1

ii
Part Names .................................................................... 1
On-screen Display Index ............................................... 4
Warning Indicators ......................................................... 6
Contents
Operation References
Preparation
Basic Operations
Charging the Battery Pack ............................................. 8
Attaching and Removing the Battery Pack .................... 9
Powering the Camcorder from an AC Outlet ............... 10
Inserting and Removing a Cassette ............................ 11
Inserting and Removing a Card ................................... 12
Installing the Lithium Batteries ..................................... 13
Setting the Date and Time ........................................... 14
Attaching the Lens Hood ............................................. 15
Using the Hand Grip .................................................... 15
Using the Hand Strap and the Lens Cap .................... 15
Tips on Recording Positions ........................................ 16
Camera Recording
Selecting the Camcorder Mode ................................... 17
Easy Camera Recording on Tape
in Full Auto Mode ....................................................... 18
Zooming ....................................................................... 19
Auto Focus ................................................................... 19
Macro Shots ................................................................. 19
Remaining Recording Time Display ............................ 20
Remaining Battery Power Display ............................... 20
Playback
Tape Playback ............................................................. 21
Using Earphones (Commercially Available) ................ 21
Volume Control ............................................................. 22
Still ............................................................................... 22
Video Search ................................................................ 22
Watching Playback on a TV ......................................... 23
Charging the battery pack (p. 8)
Attaching the battery pack (p. 9)
Inserting a cassette (p. 11) Inserting a card (p. 12)
Tape recording (p. 18) Card recording (p. 65)
Tape playback (p. 21) Card playback (p. 70)
Quick Start
VL-MC500S-GB-*i-viii 02.7.16, 3:20 PM2

iii
Useful Features
Playback
Using the Remote Control ............................................ 38
Tape Playback Functions with the Remote Control...... 39
Playback Zoom ............................................................ 40
Selecting the Date and Time of Recording Display ..... 41
Gamma Playback ........................................................ 42
Picture Effect Playback ................................................ 43
Multiple Strobe Playback ............................................. 44
Copying an Image from Tape to Card ......................... 45
Advanced Features Camera Recording
Manual Focus .............................................................. 46
Displaying Manual Setting Screen ............................... 47
Adjusting White Balance .............................................. 48
Manual Iris ................................................................... 49
Manual Gain ................................................................. 50
Setting the Shutter Speed ............................................ 51
Setting the Camcorder to Full Auto Mode .................... 52
Scene Menu (Program AE) .......................................... 53
Digital Picture Effects ................................................... 54
Playback
Using the Time Code ................................................... 55
Editing .......................................................................... 56
Recording from an External Source ............................. 57
Using the Camcorder as a Converter .......................... 58
Editing with the DV Terminal (IEEE1394) ..................... 59
Audio Dubbing Feature ................................................ 60
Selecting the Audio Playback Mode ............................ 62
Control Buttons ............................................................ 24
Using the Mode Screens ............................................. 24
Using the Menu Screens .............................................. 25
Camera Recording
Displaying the Recording Guide.................................. 26
Setting the Digital Zoom .............................................. 27
Gamma Brightness Compensation .............................. 28
Gain-up ........................................................................ 29
Fade In and Fade Out .................................................. 30
Quick Return ................................................................ 31
Edit Search ................................................................... 31
Still Recording on Tape ................................................ 32
Digital Image Stabilization (DIS) .................................. 33
Attaching the Supplied Tripod Adapter ....................... 33
Self Recording ............................................................. 34
Wide Screen (16:9) ...................................................... 35
Recording in LP (Long Play Recording) Mode ............ 36
Selecting the 16-bit Audio Recording Mode................ 37
Windbreak .................................................................... 37
Appendix
Preparation Useful Features
Operation References Basic Operations Advanced Features Digital Still Camera
Features
VL-MC500S-GB-*i-viii 02.7.16, 3:20 PM3

iv
Digital Still Camera
Features
Camera Recording
Selecting the Picture Quality and Image Size .............. 63
Card Recording ........................................................... 65
Using the Flash ............................................................ 66
Red-eye Reduction ...................................................... 67
Recording with the Self-timer ....................................... 68
Formatting a Card ........................................................ 69
Playback
Card Playback ............................................................. 70
Delete Protection.......................................................... 71
Deleting Stored Images ............................................... 72
Print Order .................................................................... 74
Transferring Data on Card to Computer ...................... 76
Installing the USB driver ......................................... 76
Slide Show Playback ................................................... 78
Picture/Backlight Adjustments ..................................... 79
Turning off the Confirmation Sound ............................. 80
Setting the Camcorder to Factory Presettings ............. 80
Demonstration Mode ................................................... 81
Setting the Guidance Level ......................................... 81
Useful Information ........................................................ 82
Troubleshooting ........................................................... 88
Specifications .............................................................. 91
Appendix
Note:
• Before requesting service, please read “Troubleshooting” carefully. (See pages 88–90.)
Contents
VL-MC500S-GB-*i-viii 02.7.16, 3:20 PM4

v
Supplied Accessories
Battery pack
BT-L225 AC adapter
Audio/video/S-video
cable
Lens cap Lens hood Tripod adapter
USB driver USB cable
8 MB SD Memory Card
CR2025 type
lithium battery
for remote control Remote control
Battery charger
CR1616 type
lithium battery
for camcorder
Power cord
Standard-life
battery pack
BT-L225
Extended-life
battery pack
BT-L445
Optional Accessories
VL-MC500S-GB-*i-viii 02.7.16, 3:20 PM5

vi
Precautions
•Before recording an important scene,
please perform the recording test, then
playback to check if the scene was re-
corded properly.
If noise occurs, use a commercially avail-
able cleaning tape to clean the video
heads. (See page viii.)
•When the camcorder is not in use, remem-
ber to remove the cassette tape, turn off
the power, and disconnect the camcorder
from the power source.
•Do not aim the lens at the sun.
Do not allow direct sunlight to strike the
camcorder lens or LCD monitor screen,
whether or not recording is in progress, as it
may damage the CCD sensor or LCD screen
surface. Be particularly careful when record-
ing outside.
•Avoid magnetic sources.
Using the camcorder near
strong fluorescent lights,
motors, televisions, or other
magnetic sources may ad-
versely affect recorded im-
ages.
•Using the camcorder near a broadcasting
station or other powerful transmission
source may cause buzzing or picture dete-
rioration.
•Avoid shocks and drop-
ping.
Do not drop or otherwise
subject the camcorder to
hard shocks or strong vibra-
tions. Bumping or striking the
unit during recording will
generate noise in the re-
corded image.
•Avoid placing the
camcorder in close
proximity to lighting
equipment.
The heat from incan-
descent lights may de-
form the camcorder, or
cause it to malfunction.
•Always respect prohibitions or restrictions
on the use of electronic equipment on
commercial flights or in other sensitive ar-
eas.
•Be aware of the temperature and humidity.
You can use your camcorder at 0°C to
L40°C, and at 30% to 80% relative humidity.
Do not store the unit in
an unventilated car in
the summer, in direct
sunlight, or near strong
heat sources; this can
result in severe damage
to the unit casing and
circuitry.
•Avoid situations where water, sand, dust or
other foreign matter could get on or inside
the camcorder, and do not use or leave
your camcorder in areas with excessive
smoke, steam or moisture.
Such environments can cause malfunctions
or cause mil-
dew to form on
the lenses. Be
sure to keep the
unit in a well-
ventilated loca-
tion.
•Some small, portable tri-
pods may be difficult to at-
tach and may not be sturdy
enough to support your
camcorder. Be sure to use
only a strong, stable tripod.
•When using your
camcorder in a cold envi-
ronment, the LCD monitor screen often ap-
pears less bright immediately after the
power is turned on. This is not a malfunc-
tion. To prevent the camcorder from be-
coming too cold, wrap it in a thick cloth (a
blanket, etc.).
VL-MC500S-GB-*i-viii 02.7.16, 3:20 PM6

vii
Dew Formation
•What is “dew formation”?
When cold water is poured into a glass, dew
drops form on the glass. This clinging of
water drops is called dew formation.
•When dew forms in your camcorder.
Dew will gradually form on the head drum of
your camcorder and make the video tape
stick to the head. This causes damage both
to the head and the tape. When dew forms,
recording and playback may not function
properly.
Dew is likely to form in the following circum-
stances:
—When moving the camcorder from a cold
place to a warm place.
—When placing the camcorder in a cold
room which is then heated rapidly.
—When moving the camcorder outdoors from
an air conditioned room or car.
—When placing the
camcorder in the direct
path of air blowing from
an air conditioner.
—When placing the
camcorder in a humid
room.
•“Dew” warning feature
If dew forms, the word “DEW” flashes on the
screen, and the power will automatically turn
off in approximately 10 seconds.
1If “DEW” flashes, remove the cassette,
leave the cassette compartment open, and
wait for a few hours to allow the camcorder
to acclimatize to the surrounding tempera-
ture.
2To use the camcorder again, turn on the
power after waiting for a few hours. Be sure
that “DEW” has disappeared.
3Do not insert a cassette while “DEW” is
flashing; this may result in damage to the
tape.
4Since dew forms gradually, it may take 10
to 15 minutes before the dew warning
feature engages.
•How to prevent trouble.
When using the camcorder in a place where
dew is likely to form, allow the camcorder and
the video tape to acclimatize to the surround-
ings for about one hour.
For example, when bringing the camcorder
indoors after skiing, place it in a plastic bag.
1Be sure to tightly seal the plastic bag
containing the camcorder.
2Remove the bag when the air temperature
inside it reaches the temperature of the
room.
;;
;;
;;
;;
;
;
;;
;;
Plastic bag
VL-MC500S-GB-*i-viii 02.7.16, 3:20 PM7

viii
Dirty Video Heads
When the video heads have become clogged
with dirt (dust and tape coating particles),
• mosaic-like noise appears on the playback
picture. (see illustrations above)
• playback pictures do not move.
• during playback, the whole screen becomes
blue.
Using a Cleaning Tape (Commercially
Available)
Available mode:
Tape Playback
You can clean the video head with a commer-
cially available cleaning tape.
Notes:
•Excessive use of the cleaning tape may cause
damage to the video heads. Please read the
instructions accompanying the cleaning tape
carefully before using it.
• The fast forward and rewind functions cannot be
used when the cleaning tape is in the
camcorder.
• If the video heads again become clogged with
dirt soon after cleaning, this might be caused by
a damaged tape. In this case, stop using that
cassette immediately.
1Insert a cleaning tape into the
camcorder.
2Set the camcorder to Tape Playback
mode.
• The video head cleaning screen
appears.
3Press mon the Operation button to
begin video head cleaning.
• “NOW CLEANING” flashes during
cleaning.
• After about 20 seconds, video head
cleaning automatically finishes, and
“EJECT THE CASSETTE.” displays.
4Remove the cleaning tape.
To cancel cleaning, press l.
Causes of video head clogging
• High-temperature and high-humidity environ-
ment
• A lot of dust in the air
• Damaged tape
• Worn tape
• Long-time use
• Dew formation
If the video heads become clogged, the
vindicator appears on the screen. Contact
the nearest SHARP service centre or your
dealer for further advice.
CLEANING
CLEANINGNOW
STOPSTART
Mosaic noise
Precautions
Striped noise
VL-MC500S-GB-*i-viii 02.7.16, 3:20 PM8

Operation References
1
Operation References
Part Names
For details on the use of each part, refer to the page number indicated in brackets.
Front view
Zoom lens
Cassette holder [p. 11]
Cassette compartment door [p. 11]
Cassette compartment door release [p. 11]
Flash [p. 66]
Speaker
Stereo microphone
Hand strap [p. 15]
Hand grip [p. 15]
Light adjustment sensor
VL-MC500S-GB-001-007 02.7.16, 3:22 PM1

Operation References
Operation References
2
Rear view
USB terminal
[pp. 76, 77]
DV terminal
[pp. 58, 59]
AV terminal
[pp. 23, 56–58]
Operation button [p. 24]
Terminal cover
[pp. 23,
56–59, 76]
Power Zoom Wide angle/
Telephoto control [p. 19]/
VOLume control [p. 22]
LCD monitor
Power switch (vCamera
Recording mode/w
Playback mode select
switch) [p. 17]
Earphones jack [p. 21]
VL-MC500S-GB-001-007 02.7.16, 3:22 PM2

Operation References
3
Rear view
Bottom view
Battery release [p. 9]
Battery mounting surfaceTripod adapter socket [p. 33]
Remote sensor [p. 38]
PHOTO button [pp. 32, 45, 65]
Card slot cover [p. 12]
Start/Stop
button [p. 18]
DISPLAY button [pp. 24, 47]
Media Selection
switch (VTape
mode/uCard
mode selection
switch) [p. 17]
Flash cover release [p. 66]
Card slot cover
release [p. 12]
VL-MC500S-GB-001-007 02.7.16, 3:22 PM3

Operation References
Operation References
4
+21 +21
AU D I OAUDIO
+21 +21
AU D I OAUDIO
3
AU T O
30 min
min
AUTO
TAPE
1. 2002
1. 12 : 00
1. 2002
1. 12 : 00
TAPE TAPE
TAPE
0
min 3
AU T O
30 min
min
AUTO
0
min
G AMMA OF F
FADE
M ENU
SNAP EF F.
GAMMA
FADE
M ENU
SCENE MENU
SNAP EFF.
M ANUAL SET
FOCUS
DATE DI SP.
SETT ING 1
QK.
DGTL
RETURN
ZOOM
TAPE SPEED
RETURN
EFFECTPIC.
SETT ING 2
REC GU I DE
DIS
16 9:
AUD I O MODE
RETURN
W IND
OTHERS
BEEP
DEFAULT
T IME CODE
TC OUT
DEMO
RETURN
MOD E
LCD SET
BACKL I GHT
LCD BRI GHT
LCD COLOUR
GUI DANCE
GUI DANCE
RETURN
LCD SET
BACKL I GHT
LCD BRI GHT
L C D COL OUR
RETURN
CLOCK SET
SETT ING
12H 24H/
RETURN
3
AU T O
0 min
min
PLAY STOP
G AMMA OFF
AUD I O DUB
MENU
MULTI F RAME
GAMMA
AUDIO DUB
M ENU
M ULTI FRAME
DATE DI SP.
OTHERS
BEEP
REMOTE
DEFAULT
T IME CODE
TC OUT
RETURN
S
- VIDEO IN
EFFECT
PLAYBACK
PIC.
AUDI O
ANLG DGTL
RETURN
SET
SETSELECT
REW FF SETSELECT
On-screen Display Index
For details on the use of each function, refer to the page number indicated.
pp. 18, 47
p. 20
p. 33
p. 20
p. 62
p. 20
pp. 81, 82
Tape Camera mode
Tape Playback mode
pp. 28, 29
p. 30
p. 25
p. 32
p. 53
p. 47
p. 46
p. 41
p. 54
p. 31
p. 27
p. 36
p. 26
p. 33
p. 35
p. 37
p. 37
p. 80
p. 80
p. 55
p. 55
p. 81
p. 79
p. 79
p. 79
p. 82
p. 15
p. 14
p. 42
p. 61
p. 25
p. 44
p. 41
p. 43
p. 62
p. 58
p. 80
p. 38
p. 80
p. 55
p. 55
p. 57
p. 79
p. 79
p. 79
p. 82
VL-MC500S-GB-001-007 02.7.16, 3:22 PM4

Operation References
5
GAMMA OFF
EXECUTE
EXECUTE
M ENU
SCENE MENU
SELF T IMER
GAMMA
M ENU
SCENE MENU
M ANUAL SET
FOCUS
DATE DI SP.
LCD SET
BACKL I GHT
LCD BRI GHT
LCD COLOUR
RETURN
LCD SET
BACKL I GHT
LCD BRI GHT
LCD COLOUR
RETURN
CLOCK SET
SETT ING
12H 24H/
RETURN
F U L L MULTI
DELETE ONE
DELETE ALL
M ENU
OTHERS
BEEP
REMOTE
DEFAULT
RETURN
SELF TIMER
SETT ING 1
RE TURN
FLASH
GU I DEREC
REC MODE
IMAGE S I ZE
RED E YE
OTHERS
DEFAULT
DEMO
RETURN
MOD E
FORMAT
BEEP
7
01
89
0100
- 00 2/2PAGE 10100 - 001
NORMAL
0100 - 001
NORMA L
01/3
00 - 001
NORMAL
01/01
EFFECT
PLAYBACK
PIC.
SL IDE SHO
W
PR I .
RETURN
ORDER
SET
GUI DANCE
GUI DANCE
AUTO AUTO
NORMAL
CARD
/911
CARD
CARD
][ 1280
][ 1280 01/3 01/01
CARD
][ 1280
/911
][ 1280
ss
1. 2002
1. 12 : 00
1. 2002
12 : 00
SETSELECT
SETSELECT
F U L L MULTI
DELETE ONE
DELETE ALL
M ENU
0100 - 001
SETSELECT
SELECTIMGFULL SELECT IMG FULL
SELECTIMGFUL
UL
L
SELECT IMG FULL
F U L L MULTI
M ENU
ALL
DEL ETE
DEL ETE
PROTECT
ONE
DATE DI SP.
1 .1.
MULTI
MULTIMULTI
Note:
• See pages 24 and 25 for procedures on how to display the desired screen.
pp. 81, 82
p. 26
p. 63
p. 64
p. 66
p. 67
p. 20
pp. 28, 29
p. 68
p. 25
p. 53
p. 47
p. 46
p. 41
Card Camera mode
Card Playback mode
p. 47
p. 67
p. 65 p. 64
p. 80
p. 69
p. 80
p. 81
p. 79
p. 79
p. 79
p. 82
p. 15
p. 14
p. 70
p. 20
p. 70
p. 70
p. 25
p. 72
p. 73
p. 71
p. 41
p. 43
p. 78
p. 74
p. 80
p. 38
p. 80
p. 79
p. 79
p. 79
p. 82
p. 64
VL-MC500S-GB-001-007 02.7.16, 3:22 PM5

Operation References
Operation References
6
Warning Indicators
If a warning indicator appears on the screen, follow the specified instructions.
Displayed for the first
3 seconds
Displayed after
3 seconds Description of warning
There is no video cassette in the camcorder.
Insert a cassette (see page 11).
INSERT
A CASSETTE.
BAT TERY I S
TOO LOW.
PROTECT. TAB
CHANGE THE
CASSETTE.
EJECT THE
CASSETTE.
EJECT THE
CASSETTE.
CASSETTE NOT
RECORDABLE.
The video cassette is defective and should be
removed (see page 11).
The erasure protect tab on the video cassette
has been slid to the record-protect position,
preventing recording (see page 83).
The tape is about to end. Prepare a new
cassette (see page 11).
THE
ENDS SOON.
TAPE
DEW
LAMP LAMP
DEW
The tape has reached the end. Replace it with a
new cassette (see page 11).
The battery is almost depleted. Replace it with a
fully charged battery pack (see page 9).
Dew has formed inside the camcorder. Wait a
few hours for the dew to dry away (see
page vii).
About 10 seconds after this warning appears,
the camcorder automatically turns off.
The video heads are clogged and should be
cleaned (see page viii).
The fluorescent lamp behind the LCD monitor is
close to the end of its service life. Call your local
authorized Sharp dealer to have it replaced.
TAPE END
TAPE END
The battery is almost depleted when the
camcorder transfers data through the USB
cable. Use the AC adapter and battery charger
or fully charged battery pack as the power
source (see pages 8–10, 77).
USB USB
VL-MC500S-GB-001-007 02.7.16, 3:22 PM6

Operation References
7
Note:
•Nindicates a flashing display.
Displayed for
5 seconds Description of warning
The card is not inserted or is inserted improperly. Check that it is
properly inserted (see page 12).
The capacity of the card is full and cannot store any more images.
Delete unnecessary images (see page 72) or replace the card with a
new one (see page 12).
The card has no images recorded in the format the camcorder can
recognize.
The images in the card are corrupted or recorded in a format which is
not compatible with this camcorder. Format the card to use it with this
camcorder (see page 69).
The card has not been formatted with this camcorder. Format the card
(see page 69).
The card is write-protected (see pages 12, 84).
You are trying to delete a protected image. Cancel the protection
setting (see page 71).
The selected image cannot be read by this camcorder. Format the
card to use it with this camcorder (see page 69).
The card cannot record any data due to a problem with the card or
data on the card. Replace the card (see page 12).
NO
MEMORY CARD
MEMORY
FULL
CARD
NO DATA ON
MEMORY CARD
MEMORY CARD
ERROR
FORMAT
MEMORY CARD
MEMORY CARD
PROTECTED
PROTECTED
DATA
MEMORY CARD
READ ERROR
CANNOT
STORE DATA
The camcorder cannot record with the Start/Stop button in Card
Recording mode. Press the PHOTO button (see page 65).
PLEASE USE
PHOTO BUT TON
The print order cannot be set to more than 999 images.
MA X I MUM
9 99 IMAGE S
VL-MC500S-GB-001-007 02.7.16, 3:22 PM7

Preparation
Preparation
8
Charging the Battery Pack
Charge the battery pack with the supplied AC
adapter and battery charger before use.
1Connect the supplied power cord to the
AC power socket on the AC adapter, and
insert the AC plug into a power outlet.
2Insert the DC plug into the DC input jack
of the battery charger.
3Align the =mark on the side of the
battery pack with the =mark on the
charger (1), and slide the battery pack
in the direction of the arrow completely
until it locks into place (2).
• The CHARGE indicator lights up.
• The CHARGE indicator turns off when
the battery is charged.
4Slide the battery pack in the direction of
the arrow (1), and remove it (2). Then
remove the AC plug of the AC adapter
from the power outlet.
Notes:
•Charge the battery pack between 10°C and
30°C. The battery pack may not charge
properly at temperatures too low or too high.
•The battery pack and charger become warm
during charging. This is not a malfunction.
•Using the zoom (see page 19) and other
functions or turning the power on and off
frequently will increase power consumption.
This may result in a decrease in the actual
recording time compared to the maximum
continuous recording time listed above.
•The charging time and recording time may
vary depending on the ambient temperature
and the condition of the battery pack.
• See page 86 for more information on using the
battery pack.
Caution:
• Charge only SHARP model BT-L225 or BT-L445
battery packs. Other types of battery packs may
burst, causing personal injury and damage.
Extending battery pack life
Even when the battery pack is not used, the
capacity of the battery pack will naturally
deteriorate over time. To limit the deterioration
of the capacity, it is recommended to perform
the following procedure at least once every six
months:
1Charge the battery pack until the CHARGE
indicator of the charger turns off.
2Attach the battery pack to the camcorder,
and set the Power switch to vwithout
inserting a cassette. Allow the battery
power to fully discharge by leaving it on the
camcorder until the camcorder power
automatically turns off.
3Remove the battery pack and store it
between 10°C and 20°C.
BT-L225
Charging
time
Battery
pack
Max. continuous
recording time
Max. continuous
playback time
BT-L445
approx.
2 hr.
approx.
3 hr. 30 min.
approx.
1 hr. 20 min.
approx.
1 hr. 20 min.
approx.
2 hr. 40 min.
approx.
2 hr. 40 min.
Charging time and maximum continu-
ous recording and playback times in
Tape modes
Preparation
To power
outlet
CHARGE indicator
DC input jack
DC plug
AC power socket
VL-MC500S-GB-008-016 02.7.16, 3:23 PM8

Preparation
9
Attaching and Removing
the Battery Pack
Attaching
1Make sure that the Power
switch is set to OFF.
2Align the =mark on the side of the
battery pack with the =mark on the
camcorder (1), and slide the battery
pack in the direction of the arrow
completely until it locks into place (2).
Removing
1Make sure that the Power switch is set
to OFF.
2Rotate the monitor section of the
camcorder (1), then press and hold the
battery release (2) as you slide the
battery pack in the direction of the arrow
and take it out (3).
Cautions:
•BEFORE REMOVING THE BATTERY PACK,
ALWAYS STOP RECORDING OR PLAYBACK
AND TURN THE POWER OFF. Removing the
battery pack while shooting or during playback
may damage the tape by causing it to wrap
around the video head drum or destroy the card,
rendering it unreadable and unwritable.
• Remove the battery pack from the camcorder if
you will not use the camcorder for a long period
of time.
• Make sure that the battery pack is firmly
attached during operation. If it is not, the battery
pack may come off or camcorder operation may
fall because of the poor contact pressure.
• To prevent damage to the battery pack when
removing, be sure to firmly hold the battery pack
while pressing the release.
• Use only SHARP model BT-L225 or BT-L445
battery packs with this camcorder. Use of other
batteries may create a risk of fire or explosion.
Battery release
Power switch
=mark
VL-MC500S-GB-008-016 02.7.16, 3:23 PM9

Preparation
Preparation
10
Powering the
Camcorder from an AC
Outlet
You can also power the camcorder from a
power outlet by using the supplied AC adapter
and battery charger.
Caution:
• The supplied AC adapter and battery charger
are specially designed for use with this
camcorder, and should not be used as a power
supply for other camcorders.
1Make sure that the Power
switch is set to OFF.
2Connect the supplied power cord to the
AC power socket on the AC adapter, and
insert the AC plug into a power outlet.
3Align the =mark on the side of the
battery charger with the =mark on the
camcorder (1), and slide the battery
charger in the direction of the arrow
completely until it locks into place (2).
4Insert the DC plug into the DC input jack
of the battery charger.
• Power is supplied into the camcorder.
5Hold down the Lock button and set the
Power switch to vor w.
Note:
• When using the AC adapter and battery charger
to power the camcorder, the battery pack is not
charged.
Cautions:
•BEFORE REMOVING THE DC PLUG, ALWAYS
STOP RECORDING OR PLAYBACK AND TURN
THE POWER OFF. Removing the DC plug while
shooting or during playback may damage the
tape by causing it to wrap around the video
head drum or destroy the card, rendering it
unreadable and unwritable.
• Disconnect the battery charger from the
camcorder if you will not use the camcorder for a
long period of time.
To power
outlet
DC input jack
AC power socket
=mark
VL-MC500S-GB-008-016 02.7.16, 3:23 PM10
