Sharp LC-13E2U User manual

LC-13E2U
LC-15E2U/20E2U
LC-13E2U
LC-15E2U
LC-20E2U
SERVICE MANUAL
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored
to its original condition and only parts identical to those specified should be used.
MODELS
CONTENTS
»IMPORTANT SERVICE SAFETY PRECAUTION ................................................................................... 2
»SPECIFICATIONS ................................................................................................................................... 5
»OPERATION MANUAL ............................................................................................................................ 6
»DIMENSIONS .......................................................................................................................................... 9
»ADJUSTING PROCEDURE OF EACHSECTION ................................................................................. 12
»REPLACEMENT PARTS LIST............................................................................................................... 13
»PACKING OFTHE SET ......................................................................................................................... 19
Page
LCD COLORTELEVISION
OUTLINE
The above models are based on the LC-13E1U/UB/UW, LC-15E1U/UB/UW and LC-20E1U/UB/UW.Their
desktop stand has been redesigned.This Service Manual covers the modifications only. For other technical
data, refer to the Service Manuals for LC-13E1U/UB/UW and LC-15E1U/UB/UW (S72N2LC-13E1U) as well
as for LC-20E1U and LC-20E1UB/UW (S72M5LC-20E1U).
SHARP CORPORATION This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
S13W6LC-13E2U

2
LC-13E2U
LC-15E2U/20E2U
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
2
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
2
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
SAFETY NOTICE
Many electrical and mechanical parts in LCD television
have special safety-related characteristics.
These characteristics are often not evident from visual
inspection, nor can protection afforded by them be
necessarily increased by using replacement components
rated for higher voltage, wattage, etc.
Replacement parts which have these special safety
characteristics are identified in this manual; electrical
components having such features are identified by“ å”
IMPORTANT SERVICE SAFETY PRECAUTION
ËService work should be perfomed only by qualified service technicians who are thor-
oughly familiar with all safety checks and the servicing guidelines which follow:
and shaded areas in the Replacement Parts Lists and
Schematic Diagrams .
For continued protection, replacement parts must be
identical to those used in the original circuit.
The use of a substitute replacement parts which do not
have the same safety characteristics as the factory
recommended replacement parts shown in this service
manual, may create shock, fire or other hazards.
WARNING
1. For continued safety, no modification of any circuit
should be attempted.
2. Disconnect AC power before servicing.
BEFORE RETURNINGTHE RECEIVER
(Fire & Shock Hazard)
Before returning the receiver to the user, perform
the following safety checks:
1. Inspect all lead dress to make certain that leads are
not pinched, and check that hardware is not lodged
between the chassis and other metal parts in the
receiver.
2. Inspect all protective devices such as non-metallic
control knobs, insulation materials, cabinet backs,
adjustment and compartment covers or shields,
isolation resistor-capacitor networks, mechanical
insulators, etc.
3. To be sure that no shock hazard exists, check for
leakage current in the following manner.
•Plug the AC cord directly into a 110~240 volt AC outlet,
and connect the DC power cable into the receiver's
DC jack.(Do not use an isolation transformer for this
test).
•Using two clip leads, connect a 1.5k ohm, 10 watt
resistor paralleled by a 0.15µF capacitor in series with
all exposed metal cabinet parts and a known earth
ground, such as electrical conduit or electrical ground
connected to an earth ground.
•Use an AC voltmeter having with 5000 ohm per volt, or
higher, sensitivity or measure the AC voltage drop
across the resisor.
•Connect the resistor connection to all exposed metal
parts having a return to the chassis (antenna, metal
cabinet, screw heads, knobs and control shafts,
escutcheon, etc.) and measure the AC voltage drop
across the resistor.
All checks must be repeated with the AC cord plug
connection reversed. (If necessary, a nonpolarized
adaptor plug must be used only for the purpose of
completing these checks.)
Any reading of 0.75V peak (this corresponds to 0.5
milliamp.peak AC.) or more is excessive and indicates
a potential shock hazard which must be corrected
before returning the monitor to the owner.
DVM
AC SCALE
1.5k ohm
10W
0.15 µF
TEST PROBE
TO EXPOSED
METAL PARTS CONNECT TO
KNOWN EARTH
GROUND
CAUTION: FOR CONTINUED
PROTECTION AGAINST A RISK OF
FIRE REPLACE ONLY WITH SAME
TYPE F3701 (2.0A, 125V), F6500 (1.6A,
125V) AND F6501 (1.6A, 125V) FUSE.
A V
LC-13/15E2U
LC-20E2U
CAUTION: FOR CONTINUED
PROTECTION AGAINST A RISK OF
FIREREPLACEONLYWITHSAMETYPE
F3701 (2.0A, 125V), F3702 (1.6A, 125V),
F6700 (1.0A, 125V), F6701 (1.0A, 125V),
F6702 (1.0A, 125V), F6703 (1.0A, 125V)
AND F6704 (1.0A, 125V) FUSE.
A V

3
LC-13E2U
LC-15E2U/20E2U
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
2
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
2
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
2
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
AVIS POUR LA SECURITE
De nombreuses pièces, électriques et mécaniques, dans
les téléviseurs présentent des caractéristiques spéciales
relatives àla sécurité, qui ne sont souvent pas évidentes
àvue. Le degréde protection ne peut pas être
nécessairement augmentée en utilisant des pièces de
remplacement étalonnées pour haute tension,
puissance, etc.
Les pièces de remplacement qui présentent ces
caractéristiques sont identifiées dans ce manuel; les
pièces électriques qui présentent ces particularités sont
PRECAUTIONS A PRENDRE LORS DE LA REPARATION
ËNe peut effectuer la réparation qu' un technicien spécialisé qui s'est parfaitement
accoutumé à toute vérification de sécurité et aux conseils suivants.
identifiées par la marque " å" et hachurées dans la
liste des pièces de remplacement et les diagrammes
schématiques.
Pour assurer la protection, ces pièces doivent être
identiques àcelles utilisées dans le circuit d'origine.
L'utilisation de pièces qui n'ont pas les mêmes
caractéristiques que les pièces recommandées par
l'usine, indiquées dans ce manuel, peut provoquer des
électrocutions, incendies, radiations X ou autres
accidents.
AVERTISSEMENT
1. N'entreprendre aucune modification de tout circuit.
C'est dangereux.
2. Débrancher le récepteur avant toute réparation.
VERIFICATIONS CONTRE L'INCEN-DIE ET
LE CHOC ELECTRIQUE
Avant de rendre le récepteur à l'utilisateur, effectuer
les vérifications suivantes.
1. Inspecter tous les faisceaux de câbles pour s'assurer
que les fils ne soient pas pincés ou qu'un outil ne soit
pas placéentre le châssis et les autres pièces
métalliques du récepteur.
2. Inspecter tous les dispositifs de protection comme les
boutons de commande non-métalliques, les isolants,
ledosducoffret,lescouverclesoublindagesde réglage
et de compartiment, les réseaux de résistance-
capacité, les isolateurs mécaniques, etc.
3. S'assurer qu'il n'y ait pas de danger d'électrocution en
vérifiant la fuite de courant, de la facon suivante:
•Brancher le cordon d'alimentation directem-ent àune
prise de courant de 110-240V. (Ne pas utiliser de
transformateur d'isolation pour cet essai).
•A l'aide de deux fils àpinces, brancher une résistance
de 1.5kΩ10 watts en parallèle avec un condensateur
de 0,15µF en série avec toutes les pièces métalliques
exposées du coffret et une terre connue comme une
conduite électrique ou une prise de terre branchée à
la terre.
•Utiliser un voltmètre CA d'une sensibilitéd'au moins
5000Ω/V pour mesurer la chute de tension en travers
de la résistance.
•Toucher avec la sonde d'essai les pièces métalliques
exposées qui présentent une voie de retour au châssis
(antenne, coffret métallique, tête des vis, arbres de
commande et des boutons, écusson, etc.) et mesurer
la chute de tension CA en-travers de la résistance.
Toutes les vérifications doivent être refaites après avoir
inverséla fiche ducordond'alimentation.(Sinécessaire,
une prise d'adpatation non polarisée peut être utilisée
dans le but de terminer ces vérifications.)
Tous les courants mesurés ne doivent pas dépasser
0,5 mA.
Dans le cas contraire, il y a une possibilitéde choc
électrique qui doit être supprimée avant de rendre le
récepteur au client.
VTVM
ECHELLE CA
1.5k ohm
10W
0.15 µF
SONDE D'ESSAI
AUX PIECES
METALLIQUES
EXPOSEES
BRANCHER A UNE
TERRE CONNUE
PRECAUTION: POUR LA PROTECTION
CONTINUE CONTRE LES RISQUES
D'INCENDIE, REMPLACER LE FUSIBLE
PARUNFUSIBLEDE MEMETYPE F3701
(2.0A, 125V), F6500 (1.6A, 125V),
F6501(1.6A, 125V).
A V
LC-13/15E2U
LC-20E2U
PRECAUTION:POUR LA PROTECTION
CONTINUE CONTRE LES RISQUES
D'INCENDIE, REMPLACER LE FUSIBLE
PARUNFUSIBLEDE MEMETYPE F3701
(2.0A, 125V), F3702 (1.6A, 125V),
F6700(1.0A, 125V), F6701(1.0A, 125V),
F6702(1.0A, 125V), F6703(1.0A, 125V),
F6704(1.0A, 125V).
A V

4
LC-13E2U
LC-15E2U/20E2U
Precautions for using lead-free solder
1 Employing lead-free solder
"All PWBs" of this model employs lead-free solder.The LF symbol indicates lead-free solder, and is attached on
the PWBs and service manuals.The alphabetical character following LF shows the type of lead-free solder.
Example:
2 Using lead-free wire solder
When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional
lead wire solder may cause damage or accident due to cracks.
As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40ºC, we recommend
you to use a dedicated soldering bit, if you are not familiar with how to obtain lead-free wire solder or soldening
bit, contact our service station or service ranch in your area.
3 Soldering
As the melting point of lead-free solder (Sn-Ag-Cu) is about 220°C which is higher than the conventional lead
solder by 40°C, and as it has poor solder wettabillty, you may be apt to keep the soldering bit in contact with the
PWB for extended period of time. However, Since the land may be peeled off or the maximum heat-resistance
temperature of parts may be excoeded, remove the bit from the PWB as soon as you conurm the steady soldering
condition.
Lead-free solder contains more tin, and the end of the soldering bit may be easily corroded.Make sure to tum on
and off the power of the bit as required.
if a different type of solder stays on the tip of the soldering bit, it is alloyed with lead-free solder.Clean the bit after
every use of it.
When the tip of the soldering bit is blackened during use, file it with steel wool or fine sandpaper.
Becareful when replacing parts with polarity indication on the PWB silk.
Indicates lead-free solder of tin, silver and copper.
Lead-free wire solder for servicing
Part No, ★Description Code
ZHNDAi123250E J φ0.3mm 250g(1roll) BL
ZHNDAi126500E J φ0.6mm 500g(1roll) BK
ZHNDAi12801KE J φ1.0mm 1kg(1roll) BM
LFa

5
LC-13E2U
LC-15E2U/20E2U
SPECIFICATIONS
Items
LCD panel
Number of dots 921,600 dots VGA
Video color systems N358, N443, PAL, PAL-M, PAL-N, SECAM, PAL-60
Destination USA/Latin America/Taiwan
TV Standard (CCIR) NTSC/PAL-M/PAL-N
TV function TV Tuning System PLL 181 ch.
STEREO MTS+SAP
CATV 125 ch.
Y/C FILTER 4-LINE COMB FILTER
Brightness 430 cd/m2
Lamp life (Fluorescent lamp) 60,000 hours
Viewing angles H: 170°V: 170°
Audio amplifier 2.1 W ×2
Speakers 13/16 ×2 15/16 7.5 cm), 2 pcs.
AV-IN1 AV-IN1, S-VIDEO-IN
AV-IN2 AV-IN2/AV-OUT
Terminals COMPONENT COMPONENT-IN, AUDIO-IN
Antenna F-Type
Headphone Mini-jack for stereo (ø3.5 mm)
OSD language English/French/Spanish
Power supply DC 12 V, AC 110–240 V, 50/60 Hz
Weight 9.3 lbs. (4.2 kg),
w/o accessories
Accessories Remote control, Batteries (x2), Antenna cable, AC adapter,
AC cord, Cable clamps (x2), Operation manual
LC-13E2U LC-15E2U
13” Advanced Super View
& BLACK TFT LCD
Model LC-20E2U
15” Advanced Super View
& BLACK TFT LCD 19.7” Advanced Super View & BLACK TFT LCD
3D Y/C FILTER
1 37/64 ×2 3/4in.
(4 ×7 cm), 2 pcs.
DC 13V, AC 110-240V, 50/60Hz
10.8 lbs. (4.9 kg),
w/o accessories 17.2 lbs. (7.8 kg), w/o accessories
2.5 W × 2
Specifications are subject to change without prior notice.
in. (3 ×

6
LC-13E2U
LC-15E2U/20E2U
OPERATION MANUAL
DISPLAY AND CONTROL OVERVIEW
Controls
CHVOL
MENU
TV/VIDEO MAIN POWER
CHVOL
MENU
TV/VIDEO MAIN POWER
•TV/VIDEO, CH ( )/( ), VOL (–)/(+), and MENU on the main unit have the same functions as the same buttons
on the remote control. Basically, this operation manual provides a description based on operation with the remote
control.
•The LC-13E2U, LC-15E2U and LC-20E2U have different external dimensions and the positions where the names
of the buttons are displayed also differ but the same operating procedures are followed for all three models.
MAIN POWER
TV/VIDEO
MENU
CH ( )/( )
VOL (–)/(+)
Speaker
SLEEP indicator
The SLEEP indicator lights up red when the
SLEEP TIMER is set.
Upper control panel
To change the vertical
angle of the LCD TV set,
tilt the screen up to 2.5
degrees forward or 10
degrees backward. The
TV set can also be
rotated 25 degrees
horizontally. Adjust the
angle so that the TV set
can be watched most
comfortably.
POWER indicator
A green indicator lights when the power is on and a
red indicator lights when in the standby mode (the
indicator will not light when the main power is off).
* The examples used throughout this manual are based
on the LC-20E2U model.
LC-20E2U
LC-13E2U
LC-15E2U
Remote control sensor
Y
P
B
COMPONENT
P
R
L
L
R
AV-IN2/OUT
VIDEO
AUDIO
R
AUDIO
AV-IN1
L
R
AUDIO
S-VIDEO
ANT.
VIDEO
POWER
INPUT
DC13V
HEAD
PHONE
VIDEO
AUDIO
L
Y
P
B
P
R
R
AUDIO
L
R
COMPONENT
AV-IN2/OUT
ANT.
VIDEO
S-VIDEO
AUDIO
L
R
HEAD
PHONE
POWER
INPUT
DC13V
AV-IN1
ANT. (Antenna terminal)
AUDIO (L)
AUDIO (R)
HEADPHONE
POWER INPUT
(DC12V: LC-13E2U
LC-15E2U
DC13V: LC-20E2U)
AUDIO (L)
AUDIO (R)
VIDEO
Y
P
R
P
B
AV-IN2/OUT
COMPONENT
AUDIO (L)
AUDIO (R)
VIDEO
S-VIDEO
AV-IN1
Carrying handle
Terminals
Hold the carrying handle and tilt the
screen while steadying the stand with
your other hand.
»Adjusting the screen view angle

7
LC-13E2U
LC-15E2U/20E2U
Listening with Headphones
DISPLAY AND CONTROL OVERVIEW (Continued)
Ë
Ë
Ë
Before connecting cables and cords to the rear terminals, remove the
back covers. Push in the tabs and pull out the back covers carefully.
To mount the cover, insert the 2 hooks on the bottom of the cover
into the cabinet and press on the upper part of the back cover until
the tab locks in place with a click.
Removing the Back Cover
Plug the headphone mini-plug into the HEADPHONE jack located on the rear of the TV set.
Headphones
•Headphones are not included in the supplied accessories.
•No sound will be heard from the main unit speakers when a headphone mini-plug is connected into the
HEADPHONE jack.
\Rear terminal
AV-IN1
L
R
AUDIO
S-VIDEO
ANT.
VIDEO
POWER
INPUT
DC13V
HEAD
PHONE
Y
P
B
COMPONENT
P
R
L
L
R
AV-IN2/OUT
VIDEO
AUDIO
R
AUDIO
AV-IN1
L
R
AUDIO
S-VIDEO
ANT.
VIDEO
POWER
INPUT
DC13V
HEAD
PHONE
"On-screen display
20
VOLUME
Adjust the sound volume
using VOL (+)/(–) on the
remote control.
CHVOL
POWER
MENU
DISPLAY
MUTE
SLEEP PIC. FLIP
BRIGHT CC TV/VIDEO
FLASHBACK
REMOTE CONTROL
MENU/
'/"/\/|
(Cursor control)
TV/VIDEO
POWER
DISPLAY*
1
SLEEP
BRIGHT
VOL(+)/(–)
MTS*
3
PIC. FLIP
FLASHBACK*
2
CH ( )/( )
Channel Select
*
1
Displays the receiving chan-
nel for 10 seconds.
*
2
Returns to the previous
channel.
*
3
Selects audio settings.
CC (CLOSED
CAPTION)
MUTE

8
LC-13E2U
LC-15E2U/20E2U
CONNECTING WITH EXTERNAL DEVICES
You can enjoy picture and sound by connecting a VCR or a home video game system to the terminals
located on the rear of the TV set.
When connecting an external device, turn off the power of the main unit first to prevent any possible
damage.
<Example>
•Video camera
•Home video game system
External devices that can be connected
to COMPONENT terminal
•PC connection is not possible.
•For the cable, use a commercially available audio/video cable.
•Only connect audio/video signals to AV-IN1 and 2 terminals. Connecting other signals may result in a malfunction.
•AV-IN1 has 2 video input terminals: VIDEO and S-VIDEO. When you connect external devices to both terminals
(and if you select AV-IN1), you can only view pictures from the S-VIDEO terminal. To view the picture from the
VIDEO terminal, do not connect any external device to the S-VIDEO terminal.
•For more information about external device connections, see the manuals of your external devices.
Y
P
B
COMPONENT
P
R
L
L
R
AV-IN2/OUT
VIDEO
AUDIO
R
AUDIO
AV-IN1
L
R
AUDIO
S-VIDEO
ANT.
VIDEO
POWER
INPUT
DC13V
HEAD
PHONE
Example of external devices that can be connected
External devices that can be connected
to AV-IN2 terminal
* If your external device has a component
terminal, COMPONENT connection is
recommended (you can view high-quality
pictures).
<Example>
•DVD Player, etc.
<Example>
•VCR
•Laser disc player
* If your external device has an S-Video terminal,
S-VIDEO connection is recommended.
External devices that can be connected
to AV-IN1 terminal
M
ENU
SLEEP TI
M
ER
VIDEO ADJUST
PRESET
CLOSED CAPTION
V–CHIP BLOCK
SET UP
SELECT: ENTER: EXIT:
MENU
SLEEP T I
M
ER
SELECT: ADJUST : EXIT:
MENU
RETURN
SLEEP T I
M
ER [––– RE
M
AIN]
PICTURE [ 30]
TINT
COLOR
BLACK LEVEL
SHARPNESS
SELECT: ENTER: EXIT:
MENU
VIDEO ADJUST(TV)
RETURN
[ 0]
[ 0]
[ 0]
[ 0]
BRIGHTNESS [BRIGHT]
AUTO PO
W
ER OFF
PICTURE FLIP
AV2 IN/OUT
SELECT: EXIT:
MENU
RETURN
[OFF ]
[NOR
M
AL ]
[IN ]
PRESET
ADJUST :
CC/ TEXT [OFF]
SELECT: EXIT:
MENU
RETURN
ADJUST :
CLOSED CAPT ION
INPUT SECRET NO.
– – – –
EXIT:
MENU
BLUE SCREEN [OFF]
LANGUAGE
SELECT: EXIT:
MENU
RETURN
ADJUST :
SET UP
CH–SETT ING
COLOR SYSTEM
RESET [ N358]
SELECTING MENU ITEMS
•This LCD TV set allows you to adjust the various settings using the menu screen.Select the desired
menu item by following the steps below and then refer to the indicated page for details.
1
Press MENU to display the MENU
screen.
2
Press '/"to select the desired
menu item.
3
Press \/|to enter.
4
Press MENU to exit.
•The TINT display only appears when
the color system is set to N358 or
N443.
•The displayed items differ depending
on the setting conditions.
•The selected item changes to yellow.
•Items in magenta cannot be se-
lected.
•TV mode
This product is factory set to comply
with the color system in the United
States (NTSC-N358). For Brazil
(PAL-M), Argentina (PAL-N) and
Uruguay (PAL-N), set the color
system before using this product.
•To return to the previous screen,
select RETURN.
•You can adjust some settings with
the special buttons: SLEEP,
BRIGHT, PIC. FLIP and CC
ËLC-13E2U/LC-15E2U
•COLOR SYSTEM
When you set COLOR SYSTEM to
AUTO, the AUTO mode
automatically detects the receiving
signal system and adjusts the
reception system of the TV set.
When the picture or sound is not
stable, set a specific COLOR
SYSTEM (not AUTO). The picture
and sound may be improved.
Selecting Menu Items
CHVOL
POWER
MENU
DISPLAY
MUTE
SLEEP PIC. FLIP
BRIGHT CC TV/VIDEO
FLASHBACK
* The screen indications shown above are larger than actual for easy reading.
MENU/
///

9
LC-13E2U
LC-15E2U/20E2U
ËLC-13E2U
DIMENSIONS
Unit: inch (mm)
POWER SLEEP
VOL CH MENU TV/VIDEO MAIN POWER
VIDEO
L
AUDIO
R
Y
P
B
P R
AV-IN 2/OUT
COMPONENT
L
AUDIO
R
VIDEO
S-VIDEO
L
AUDIO
R
HEAD
PHONE
ANT.
POWER
INPUT
DC12V
AV-IN 1
81/16 (205)
91/8 (232)
1317/64 (337)313/16 (97)
8(203)
315/16 (100)
221/64 (59)1219/32 (320)
1413/32 (366)
1441/64 (372)
221/64 (59)
315/16 (100)
119/64 (33)
7
5
/
64
(180)
03/16 (5)

10
LC-13E2U
LC-15E2U/20E2U
ËLC-15E2U
Unit: inch (mm)
VOL CH MENU TV/VIDEO MAIN POWER
VIDEO
L
AUDIO
R
Y
P
B
P R
AV-IN2/OUT
COMPONENT
L
AUDIO
R
VIDEO
S-VIDEO
L
AUDIO
R
HEAD
PHONE
ANT.
POWER
INPUT
DC12V
AV-IN1
POWER SLEEP
8
1
/ 16 (205)
9
1
/ 8 (232)
14
59
/ 64 (379)3
13
/ 16 (97)
8
(203)
3
15
/ 16 (100)
2
21
/
64
(59)13
55
/
64
(352)
14
23
/
64
(365)
15
7
/
64
(384)
2
21
/ 64 (59)
3
15
/
16
(100)
1
3
/
8
(35.2)
7
51
/
64
(198)
0
3
/
16
(5)

11
LC-13E2U
LC-15E2U/20E2U
ËLC-20E2U Unit: inch (mm)
VOL CH MENU TV/VIDEO MAIN POWER
POWER SLEEP
VIDEO
L
AUDIO
R
Y
P
B
P R
AV-IN2/OUT
COMPONENT
L
AUDIO
R
VIDEO
S-VIDEO
L
AUDIO
R
HEAD
PHONE
ANT.
POWER
INPUT
DC13V
AV-IN1
949/64 (248)
119/64 (283)
1913/32 (493)43/64 (103)
821/32 (220)
315/16 (100)
243/64 (68)1721/64 (440)
1837/64 (472)
1847/64 (476)
243/64 (68)
315/16 (100)
21/64 (51.5)
939/64 (244)03/16 (5)

12
LC-13E2U
LC-15E2U/20E2U
ADJUSTING PROCEDURE OF EACH SECTION
Change the initial settings of the following items on the LC-13/15/20E1U adjustment process mode menus.
Page Item Initial Setting
10 N358 AVO START Change from “152”to “156”.
N358 SCIN1 Change from “1623”to “1601”.
11 N443 AVO START Change from “152”to “156”.
N443 SCIN1 Change from “1623”to “1601”.
12 PAL AVO START Change from “152”to “156”.
PAL SCIN1 Change from “1623”to “1601”.
13 SECAM AVO START Change from “152”to “156”.
SECAM SCIN1 Change from “1623”to “1601”.
14 PAL-M AVO START Change from “152”to “156”.
PAL-M SCIN1 Change from “1623”to “1601”.
15 PAL-N AVO START Change from “152”to “156”.
PAL-N SCIN1 Change from “1623”to “1601”.
16 PAL60 AVO START Change from “152”to “156”.
PAL60 SCIN1 Change from “1623”to “1601”.

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
13
LC-13E2U
LC-15E2U/20E2U
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual;electrical components having such features
are identified by åand shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOWTO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3.PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
★ MARK: SPARE PARTS-DELIVERY SECTION
LISTE DES PIECES
CHANGE DES PIECES
Les pi`eces de rechange qui pr élelesentent ces caract éleristiques
sp éleciales de s élecurit éle, sont identifi élees dans ce manuel :les
pi`eces élelectriques qui pr élesentent ces particularit éles, sont rep
éler élee par la marque ået sont hachur élees dans les listes de
pi`eces et dans les diagrammes sch élematiques.
La substitution d'une pi`ece de rechange par une autre qui ne pr
éLesente pas les m éoemes caract éLeristiques de s élecurit éle que
la pi`ece recommand élee parl'usine et dans ce manuel de service,
peut provoquer une éLelectrocution, un incendie ou toutautre sinistre.
"COMMENT COMMANDER LES PIECES DE RECHANGE"
Pour que votre commande soit rapidement et correctement remplie,
veuillez fournir les renseignements suivants.
1. NUMERO DU MODELE 2.NO.DE REF
3. NO. DE PIECE 4. DESCRIPTION
in CANADA: Contact SHARP Electronics of Canada Limited
Phone [phone]
★MARQUE: SECTION LIVRAISON DES PIECES DE RECHANGE
CABINET AND MECHANICAL PARTS
MODEL : LC-13E2U
1 CCABAA092WJ01 J Cabinet A Ass’y BG
1-1 Not Available – Cabinet A —
1-2 GCOVA2020CEZZ J R/C, LED Cover AF
1-3 Not Available – "SHARP" Badge —
1-4 PSPAGA031WJZZ J Spacer, x4 AA
1-5 PSPAGA033WJZZ J Spacer, x4 AA
1-6 PSPAH0719CEZZ J Spacer, x2 AC
1-7 PSPAH0606CEZZ J Spacer, x2 AD
1-9 PSPAHA073WJZZ J Spacer, x2 AB
1-10 QEARZ0047CEZZ J Grounding Part AC
1-11 VSP7530PB588B J Speaker(L) AS
1-12 VSP7530PB598B J Speaker(R) AS
1-13 XEBSD30P08000 J Screw, x6 AA
1-15 PSPAH0623CEZZ J Spacer, x1 AB
2 CCABBA058WJ11 J Cabinet B Ass’y BA
2-1 Not Available – Cabinet B —
2-2 GLEGGA009WJSA J Leg, x2 AG
2-3 HiNDPA365WJSA J Model Label AG
2-4 LANGTA013WJFW J Reinforcement Angle AL
2-5 PSPAGA043WJZZ J Spacer, x2 AC
2-6 XEBSD30P08000 J Screw, x1 AA
3 CDAi-A031WJ01 J Stand Ass’y BN
3-1 GDAi-A031WJSA J Stand Base AX
3-2 Not Available – Stand Joint —
3-3 GCOVA1945CESA J Stand Grip AK
3-4 JHNDP0105CESA J Stand Handle AW
3-5 PSPAZ0415CEZZ J Spacer, x2 AB
3-6 XESSN40P10000 J Screw, x8 AB
3-7 LX-NZ3185CEFE J Nut, x1 AC
3-8 MHNG-3051CEFW J Swivel Hinge AV
3-9 LANGG1196CEFW J Swivel Base AF
3-10 LANGG1198CEFW J Fixing Metal, Spacer-A AE
3-11 LANGG1199CEFW J Fixing Metal, Spacer-B AD
3-12 XUSSD40P20000 J Screw, x4 AB
3-13 XESSE40P14000 J Screw, x4 AA
3-14 GLEGG9093CEZZ J Leg Cushion, x8 AC
4 CCOVAA127WJ01 J Top Cover Ass’y AR
4-1 Not Available – Top Cover —
4-2 GCOVA1943CEKA J Button Cover(VOL) AD
4-3 GCOVA1943CEKB J Button Cover(CH) AD
4-4 JBTN-2076CEKA J Operation Button AE
4-5 JBTN-A012WJKA J Power Button AE
4-6 LHLDZA027WJKZ J Power Button Holder AE
4-7 MSPRCA014WJFW J Power Button Spring AB
4-8 XEBSD30P08000 J Screw, x2 AA
5 Not Available – 13" LCD Panel Unit Ass’y —
5-1 RLCDTA012WJZZ J 13" LCD Panel Unit CV
å5-2 KLMP-0120CEZZ J Lamp Unit BD
5-3 PGiDM0069CEZZ J Light Guide Panel AZ
5-4 PMiR-0292CEZZ J Reflection Mirror, x2 AG
5-5 PMiR-0293CEZZ J Reflection Mirror, x2 AF
5-6 PSHEP0276CEZZ J Reflection/Deflection Sheet BB
5-7 PSHEP0277CEZZ J Prism Sheet AV
5-8 PSHEP0278CEZZ J Diffusion Sheet AL
5-9 PSHEP0279CEZZ J Reflection Sheet-1 AG
5-10 PSHEP0280CEZZ J Reflection Sheet-2 AG
5-11 PSHEP0306CEZZ J Lamp Reflection Sheet AC
(Cover), x2
5-12 PSLDMA024WJFW J Back Shield Panel AP
5-13 QCNW-6064CEZZ J Connecting Cord AD
5-14 QCNW-6065CEZZ J Connecting Cord AC
5-15 QCNW-6066CEZZ J Connecting Cord AE
5-16 XBBSD30P05000 J Screw, x2 AA
6 GCOVAA129WJKA J Chassis Frame AP
7 GCOVA2103CEKA J Chassis Frame Cover AG
8 GCOVAA078WJKA J Terminal Cover(L) AL
9 GCOVAA079WJKA J Terminal Cover(S) AH
10 Not Available – Serial No. Label —
11 QCNW-6068CEZZ J Connecting Cord AD
12 QCNW-A699WJZZ J Connecting Cord AE
13 QCNW-A267WJZZ J Connecting Cord AK
14 LX-BZ3442CEFF J Screw, x4 AB
15 XBBSF30P05000 J Screw, x2 AB
16 XBPSN30P09JS0 J Screw, x3 AB
17 XEBSD30P06000 J Screw, x1 AA
18 XEBSD30P08000 J Screw, x10 AA
19 XEBSD30P12000 J Screw, x2 AA
20 XEBSF30P20000 J Screw, x6 AB

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
14
LC-13E2U
LC-15E2U/20E2U
CABINET AND MECHANICAL PARTS
MODEL : LC-15E2U
1 CCABAA090WJ01 J Cabinet A Ass’y BG
1-1 Not Available – Cabinet A —
1-2 GCOVA2020CEZZ J R/C LED Cover AF
1-3 Not Available – "SHARP" Badge —
1-4 PSPAGA034WJZZ J Spacer, x4 AB
1-5 PSPAGA035WJZZ J Spacer, x4 AB
1-6 PSPAHA050WJZZ J Spacer, x2 AC
1-7 PSPAHA051WJZZ J Spacer, x2 AC
1-8 PSPAHA073WJZZ J Spacer, x1 AB
1-10 QEARZ0047CEZZ J Grounding Strap AC
1-11 VSP7530PB588B J Speaker(L) AS
1-12 VSP7530PB598B J Speaker(R) AS
1-13 XEBSD30P08000 J Screw, x6 AA
1-14 XEBSD30P08000 J Screw, x2 AA
2 CCABBA056WJ11 J Cabinet B Ass’y BB
2-1 Not Available – Cabinet B —
2-2 GLEGGA008WJSA J Leg, x2 AF
2-3 HiNDPA374WJSA J Model Label AG
2-4 LANGT9061CEFW J Reinforcement Angle BD
2-5 PSPAGA043WJZZ J Spacer, x2 AC
2-6 XEBSD30P08000 J Screw, x1 AA
2-7 PMLT-A039WJZZ J Spacer, x4
2-8 PSPAHA060WJKZ J Spacer, x1 AB
3 CDAi-A031WJ01 J Stand Ass’y BN
3-1 GDAi-A031WJSA J Stand Base AX
3-2
Not Available – Stand Joint —
3-3 GCOVA1945CESA J Stand Grip AK
3-4 JHNDP0105CESA J Stand Handle AW
3-5 PSPAZ0415CEZZ J Spacer, x2 AB
3-6 XESSN40P10000 J Screw, x8 AB
3-7 LX-NZ3185CEFE J Nut, x1 AC
3-8 MHNG-3051CEFW J Swivel Hinge AV
3-9 LANGG1196CEFW J Swivel Base AF
3-10 LANGG1198CEFW J Fixing Metal, Spacer-A AE
3-11 LANGG1199CEFW J Fixing Metal, Spacer-B AD
3-12 XUSSD40P20000 J Screw, x4 AB
3-13 XESSE40P14000 J Screw, x4 AA
3-14 GLEGG9093CEZZ J Leg Cushion, x8 AC
4 CCOVAA127WJ01 J Top Cover Ass’y AR
4-1 Not Available – Top Cover —
4-2 GCOVA1943CEKA J Button Cover(VOL) AD
4-3 GCOVA1943CEKB J Button Cover(CH) AD
4-4 JBTN-2076CEKA J Operation Button AE
4-5 JBTN-A012WJKA J Power Button AE
4-6 LHLDZA027WJKZ J Power Button Holder AE
4-7 MSPRCA014WJFW J Power Button Spring AB
4-8 XEBSD30P08000 J Screw, x2 AA
5 Not Available – 15" LCD Panel Unit Ass’y —
5-1 RLCDTA013WJZZ J 15" LCD Panel Unit DB
å5-2 KLMP-0122CEZZ J Lamp Unit BD
5-3 PGiDM0070CEZZ J Light Guide Panel BA
5-4 PMiR-0294CEZZ J Reflection Mirror, x2 AG
5-5 PMiR-0295CEZZ J Reflection Mirror, x2 AF
5-6 PSHEP0281CEZZ J Reflection/Deflection Sheet BE
5-7 PSHEP0282CEZZ J Prism Sheet AY
5-8 PSHEP0283CEZZ J Diffusion Sheet AL
5-9 PSHEP0284CEZZ J Reflection Sheet-1 AG
5-10 PSHEP0285CEZZ J Reflection Sheet-2 AG
5-11 PSHEP0307CEZZ J Lamp Reflectin Sheet AC
(Cover), x2
5-12 PSLDM4689CEFW J Back Shield Panel AR
5-13 QCNW-6064CEZZ J Connecting Cord AD
5-14 QCNW-6065CEZZ J Connecting Cord AC
5-15 QCNW-A069WJZZ J Connecting Cord AF
5-16 XBBSD30P05000 J Screw, x2 AA
5-17 XBBSD30P05000 J Screw, x2 AA
6 GCOVA2105CEKA J Chassis Frame AP
7 GCOVA2103CEKA J Chassis Frame Cover AG
8 GCOVAA083WJKA J Terminal Cover(L) AK
9 GCOVAA082WJKA J Terminal Cover(S) AH
10 Not Available – Serial No. Label —
11 QCNW-A070WJZZ J Connecting Cord AD
12 QCNW-A699WJZZ J Connecting Cord AE
13 QCNW-A267WJZZ J Connecting Cord AK
14 LX-BZ3442CEFF J Screw, x4 AB
15 XBBSF30P05000 J Screw, x2 AB
16 XBPSN30P09JS0 J Screw, x3 AB
17 XEBSD30P06000 J Screw, x1 AA
18 XEBSD30P08000 J Screw, x10 AA
19 XEBSD30P12000 J Screw, x2 AA
20 XEBSF30P20000 J Screw, x6 AB
21 XEBSD30P06000 J Screw, x1 AA
22 PSPAHA077WJZZ J Spacer, x3 AB

15
LC-13E2U
LC-15E2U/20E2U
654321
A
B
C
D
E
F
G
H
CABINET AND MECHANICAL PARTS (LC-13/15E2U)
2-2
2-2
2
A
20
20
10
8
2-3
9
15
2-5 2-1
2-5
2-7
G
20
2-4
2-6
2-8
L
H
5-13
5-14
5-10
5-11
5-11
5-12
5-1
5-2
5-3 5-9
5-5
5-4
5-4
5-16
5-7 5-8
5-15
5-6
BL
C
CF
D
5
18
22
22
11
6
16 21
16 18
16
5-5
F
19
I
5-16
5-17
5-17
7
17
13
INVERTER PWB
DIGITAL PWB
ANALOG PWB
1-7
1-6
1-13
1-14
H
1-2
1-10
1-13
1-14
1-11
1-5
1-5
1-4
1-9
K
D
G
1-3
1-12
1-4
1-9
1-5
1-4
1-1
18
12
1
I
K
4
18
18
4-2
4-1
4-5
4-6
4-7
4-3
4-4
4-8
1-4
1-5
COTROL PWB
R/C,LED PWB
1-15
1-8
3-3
3-4
3-6
3-5
3-2
14
3
3-7
3-14
3-13
3-8
3-12
3-11
3-9
3-10
3-1

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
16
LC-13E2U
LC-15E2U/20E2U
CABINET AND MECHANICAL PARTS
MODEL : LC-20E2U
1 CCABAA072WJ01 J Cabinet A Ass'y BG
1-1 Not Available – Cabinet A —
1-2 GCOVA2020CEZZ J R/C LED Cover AF
1-3 Not Available – "SHARP" Badge —
1-4 PSPAGA027WJZZ J Spacer, x2 AC
1-5 PSPAGA028WJZZ J Spacer, x2 AB
1-6 PSPAGA029WJZZ J Spacer, x2 AB
1-7 PSPAGA030WJZZ J Spacer, x4 AB
1-8 PSPAHA040WJZZ J Spacer, x2 AD
1-9 PSPAHA041WJZZ J Spacer, x2 AD
1-10 PSPAH0678CEZZ J Spacer, x2 AA
1-11 QCNW-A543WJZZ Connecting Cord AE
1-12 VSP7040PB578S J Speaker, x2 AR
1-13 XETSD40P12000 J Screw, x8 AB
2 CCABBA040WJ10 J Cabinet B Ass'y BC
2-1 Not Available – Cabinet B —
2-2 GLEGGA007WJSA J Leg, x2 AG
2-3 HiNDPA370WJSA J Model Label AG
2-4 PSPAGA043WJZZ J Spacer, x2 AC
3 CDAi-A030WJ01 J Stand Ass’y BQ
3-1 GDAi-A030WJSA J Stand Base BB
3-2
Not Available – Stand Joint —
3-3 GCOVA1945CESA J Stand Grip AK
3-4 JHNDP0103CESA J Stand Handle AX
3-5 PSPAZ0415CEZZ J Spacer, x2 AB
3-6 XESSN40P10000 J Screw, x8 AB
3-7 LX-NZA001WJFE J Nut, x1 AD
3-8 MHNG-A004WJFW J Swivel Hinge AU
3-9 LANGGA004WJFW J Fixing Metal AE
3-10 LANGFA007WJFW J Spacer for Swivel Hinge AD
3-11 XUSSD40P20000 J Screw, x4 AB
3-12 XESSE40P14000 J Screw, x4 AA
3-13 GLEGG9093CEZZ J Leg Cushion, x8 AC
4 CCOVAA084WJ01 J Top Cover Ass'y AR
4-1 Not Available – Top Cover —
4-2 GCOVA1943CEKA J Button Cover(VOL) AD
4-3 GCOVA1943CEKB J Button Cover(CH) AD
4-4 JBTN-A012WJKA J Operation Button AE
4-5 JBTN-2076CEKA J Power Button AE
4-6 LHLDZA027WJKZ J Power Button Holder AE
4-7 MSPRCA014WJFW J Power Button Spring AB
4-8 XEBSD30P08000 J Screw, x2 AA
5 Not Available – 20" LCD Panel Unit Ass'y —
5-1 RLCDTA014WJZZ J 20" LCD Panel Unit DT
5-2 LHLDW1173CEZZ J Wire Holder, x1 AD
5-3 PMLT-0402CEZZ J Spacer, x1 AC
5-4 PSLDM4685CEFW J Back Shield Panel AX
å5-5 KLMP-0124CEZZ J Lamp Unit-A BH
å5-6 KLMP-0125CEZZ J Lamp Unit-B BD
5-7 LHLDZ2176CEZZ J Lamp Fixing Holder, x2 AL
5-8 MSPRP1220CEFW J ITO Earth Spring AC
5-9 PCOVU0107CEZZ J Diffusion Plate AY
5-10 PMiR-0296CEZZ J Reflection Mirror AX
5-11 PMLT-0377CEZZ J Spacer AD
5-12 PSHEP0286CEZZ J Reflection/Deflection Sheet BP
5-13 PSHEP0287CEZZ J Prism Sheet BC
5-14 PSHEP0288CEZZ J Diffusion Sheet AQ
5-15 PSHEP0289CEZZ J ITO Sheet AY
5-16 QCNW-6054CEZZ J Connecting Cord AD
5-17 QCNW-6055CEZZ J Connecting Cord AD
5-18 QCNW-6056CEZZ J Connecting Cord AF
5-19 XBBSD30P08000 J Screw, x10 AA
5-20 XEBSD20P05000 J Screw, x6 AA
5-21 XEBSD30P08000 J Screw, x1 AA
6 GCOVA2106CEKA J Chassis Frame AU
7 GCOVA2103CEKA J Chassis Frame Cover AG
8 GCOVAA069WJKA J Terminal Cover(S) AL
9 GCOVAA070WJKA J Terminal Cover(L) AK
10 LANGT9032CEFW J Reinforcement Angle AR
11 QCNW-A695WJZZ J Connecting Cord AG
12 QCNW-6058CEZZ J Connecting Cord AE
13 PMLT-0404CEZZ J Spacer, x1 AD
14 PMLT-0405CEZZ J Spacer, x1 AD
15 Not Available – Serial No. Label —
16 LX-BZ3442CEFF J Screw, x4 AB
17 QCNW-A267WJZZ J Connecting Cord AK
18 XBBSD40P06000 J Screw, x4 AA
19 XBBSF30P06000 J Screw, x2 AA
20 XBPSD30P10JS0 J Screw, x8 AA
21 XEBSD30P08000 J Screw, x1 AA
22 XEBSD30P12000 J Screw, x6 AA
23 XEBSF40P12000 J Screw, x1 AB
24 XEBSF40P20000 J Screw, x9 AB

17
LC-13E2U
LC-15E2U/20E2U
654321
A
B
C
D
E
F
G
H
CABINET AND MECHANICAL PARTS (LC-20E2U)
2-2
2-2
2
A
24
23
24
15
9
2-3
8
19
2-4
2-1
2-4
G
20
17
I J
A
B
A
J
I
B
D
H
B
C
5
B
5-3
14
10
18
20
20
12
20
21
6
7
5-2
5-20
5-20
5-10
5-4
5-5
5-6
5-7
5-8
5-9
5-1
5-19
5-21
5-14 5-15
5-13
5-12
5-17
5-16
5-18
5-19
5-19
5-7
5-19
13
5-11
C
Inverter-B
PWB
Inverter-A PWB
Digital PWB
Analog PWB
1-13
1-12
1-9
1-6 1-6
1-6
1-4 1-8
1-7 1-7
K
D
G
1-13
1-11
1-2
1-3
1-12
1-4
1-8
1-6
1-5
1-1
22
11
1
H
L
L
K
4
22
22
4-2
4-1
4-5
4-6
4-7
4-3
4-4 4-8
1-5
1-6
1-6
1-10
Control PWB
R/C, LED PWB
1-7
1-7
3-7
3-13
3
3-12
3-10
3-8
3-11
3-9
3-1
3-3
3-4
3-6
3-5
3-2
16

Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
18
LC-13E2U
LC-15E2U/20E2U
SUPPLIED ACCESSORIES
LHLDWA002WJSA J Cable Clamp, x1 AD
åQACCD3097CEPA J AC Cord AQ
QCNWG0003CEPA J Antenna Cable AM
RRMCGA077WJSA J Infrared R/C Unit AT
TiNS-A652WJZZ J Operation Manual AR
åUADP-A009WJPZ J AC Adapter(LC-13/15E2U) BG
åUADP-0243CEPZ J AC Adapter(LC-20E2U) BL
PACKING PARTS
(NOT REPLACEMENT ITEM)
LC-13E2U
SPAKCA569WJZZ – Packing Case —
SPAKFA269WJZZ – Buffer Material (Accessories) —
SPAKPA138WJZZ – Wrapping Paper —
SPAKXA128WJZZ – Buffer Material —
SSAKA0160CEZZ – Polyethylene Bag —
TLABK0001TAZZ – No. Label —
LC-15E2U
SPAKCA568WJZZ – Packing Case —
SPAKFA268WJZZ – Buffer Material (Accessories) —
SPAKPA139WJZZ – Wrapping Paper —
SPAKXA132WJZZ – Buffer Material —
SSAKA0160CEZZ – Polyethylene Bag —
TLABK0001TAZZ – No. Label —
LC-20E2U
SPAKCA567WJZZ – Packing Case —
SPAKFA267WJZZ – Buffer Material (Accessories) —
SPAKPA140WJZZ – Wrapping Paper —
SPAKXA252WJZZ – Buffer Material —
SSAKA0160CEZZ – Polyethylene Bag —
TLABK0001TAZZ – No. Label —
SERVICE JIGS
(USE FOR SERVICING)
LC-13/15E2U
QCNW-A323WJZZ J Extention Cable, 5-pin AD
(P2004-P3702)
QCNW-A324WJZZ J Extention Cable, 50-pin AE
(SC2001-SC3100)
QCNW-A553WJZZ J Extention Cable, 30-pin BA
(SC1203-LCD)
QCNW-A555WJZZ J Extention Cable, 20-pin AU
(SC1201-LCD)
QCNW-A556WJZZ J Extention Cable, 50-pin AU
(SC1202-LCD)
LC-20E2U
QCNW-A552WJZZ J Extention Cable 5-pin AG
(P2004-P3702)
QCNW-A553WJZZ J Extention Cable 30-pin BA
(SC1203-LCD)
QCNW-A555WJZZ J Extention Cable 20-pin AU
(SC1201-LCD)
QCNW-A556WJZZ J Extention Cable 50-pin, x2 AU
(SC2001-SC3403)
(SC1202-LCD)

19
LC-13E2U
LC-15E2U/20E2U
PACKING OF THE SET
Operation Manual
(TiNS-A652WJZZ)
Cable Clamp
(LHLDWA002WJSA)
★"AAA" size Battery (2pcs)
★Wrapping Paper
(SPAKPA140WJZZ)
★Buffer Material
(SPAKXA252WJZZ)
★Buffer Material
(SPAKXA252WJZZ)
★Packing Case
(SPAKCA567WJZZ)
★Polyethylene Bag
(SSAKA0160CEZZ)
★Buffer Material (Accessories)
(SPAKFA267WJZZ)
★
Not Replacement Item
MODEL:LC-20E2U
★ No. Label
(TLABK0001TAZZ)
L
R
AC Adapter
(UADP-0243CEPZ)
Antenna Cable
(QCNWG0003CEPA)
AC Cord
(QACCD3097CEPA)
Infrared R/C Unit
(RRMCGA077WJSA)
Operation Manual
(TiNS-A652WJZZ)
Cable Clamp
(LHLDWA002WJSA)
★"AAA" size Battery (2pcs)
★Wrapping Paper
(SPAKPA138WJZZ:LC-13E2U)
(SPAKPA139WJZZ:LC-15E2U)
★Buffer Material
(SPAKXA128WJZZ:LC-13E2U)
(SPAKXA132WJZZ:LC-15E2U)
★Buffer Material
(SPAKXA128WJZZ:LC-13E2U)
(SPAKXA132WJZZ:LC-15E2U)
★Packing Case
(SPAKCA569WJZZ:LC-13E2U)
(SPAKCA568WJZZ:LC-15E2U)
★Buffer Material (Accessories)
(SPAKFA269WJZZ:LC-13E2U)
(SPAKFA268WJZZ:LC-15E2U)
AC Adapter
(UADP-A009WJPZ)
Antenna Cable
(QCNWG0003CEPA)
AC Cord
(QACCD3097CEPZ)
Infrared R/C Unit
(RRMCGA077WJSA)
L
R
★
Not Replacement Item
MODELS:LC-13/15E2U
★No. Label
(TLABK0001TAZZ)
★Polyethylene Bag
(SSAKA0160CEZZ)

LC-13E2U
LC-15E2U/20E2U
COPYRIGHT © 2003 BY SHARP CORPORATION
ALL RIGHTS RESERVED.
No part of this publication may be reproduced,
stored in a retrieval system, or transmitted in
any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without
prior written permission of the publisher.
SHARP CORPORATION
AV Systems Group
Quality & Reliability Control Center
Yaita, Tochigi 329-2193, Japan
TQ1507-S
Mar. 2003 Printed in Japan
MI. KG
Design and Production Information
Design : Japan
Production : Japan
