SERVICE MANUAL
LC-19D1E/S-RD, LC-19D1RU-BK/WH/RD
No. S19W4LC19D1RU
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
SAFETY PRECAUTION
IMPORTANT SERVICE SAFETY PRE-
CAUTION ............................................................i
Precautions for using lead-free solder ...............ii
OUTLINE AND MODIFIED PARTS LIST
OUTLINE........................................................... iii
MODIFIED PARTS LIST ................................... iii
Parts Guide
TopPage
CONTENTS
LCD COLOUR TELEVISION
LC-19D1E-RD
LC-19D1S-RD
LC-19D1RU-BK/WH/RD
MODELS
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig-
inal condition and only parts identical to those specified should be used.
This Service Manual covers the differences from LC-19D1E/S-BK/WH. For other technical information, refer to the LC-
19D1E/S-BK/WH (No. S58J9LC19D1ES) Service Manual.
OUTLINE

LC-19D1E/S-RD, LC-19D1RU-BK/WH/RD
i
LC19D1RU-BK Service Manual
SAFETY PRECAUTION
IMPORTANT SERVICE SAFETY PRECAUTION
WARNING
1. For continued safety, no modification of any circuit should be
attempted.
2. Disconnect AC power before servicing.
BEFORE RETURNING THE RECEIVER
(Fire & Shock Hazard)
Before returning the receiver to the user, perform the following
safety checks:
3. Inspect all lead dress to make certain that leads are not pinched,
and check that hardware is not lodged between the chassis and
other metal parts in the receiver.
4. Inspect all protective devices such as non-metallic control knobs,
insulation materials, cabinet backs, adjustment and compartment
covers or shields, isolation resistor-capacitor networks, mechanical
insulators, etc.
5. To be sure that no shock hazard exists, check for leakage current in
the following manner.
• Plug the AC cord directly into a 220~240 volt AC outlet.
• Using two clip leads, connect a 1.5k ohm, 10 watt resistor paral-
leled by a 0.15µF capacitor in series with all exposed metal cabinet
parts and a known earth ground, such as electrical conduit or elec-
trical ground connected to an earth ground.
• Use an AC voltmeter having with 5000 ohm per volt, or higher, sen-
sitivity or measure the AC voltage drop across the resistor.
• Connect the resistor connection to all exposed metal parts having a
return to the chassis (antenna, metal cabinet, screw heads, knobs
and control shafts, escutcheon, etc.) and measure the AC voltage
drop across the resistor.
All checks must be repeated with the AC cord plug connection
reversed. (If necessary, a nonpolarized adaptor plug must be used
only for the purpose of completing these checks.)
Any reading of 1.05 V peak (this corresponds to 0.7 mA peak AC.)
or more is excessive and indicates a potential shock hazard which
must be corrected before returning the monitor to the owner.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
SAFETY NOTICE
Many electrical and mechanical parts in LCD color television have
special safety-related characteristics.
These characteristics are often not evident from visual inspection, nor
can protection afforded by them be necessarily increased by using
replacement components rated for higher voltage, wattage, etc.
Replacement parts which have these special safety characteristics are
identified in this manual; electrical components having such features
are identified by “ ” and shaded areas in the Replacement Parts
List and Schematic Diagrams.
For continued protection, replacement parts must be identical to those
used in the original circuit.
The use of a substitute replacement parts which do not have the same
safety characteristics as the factory recommended replacement parts
shown in this service manual, may create shock, fire or other hazards.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the
servicing guidelines which follow:
CAUTION:
FOR CONTINUED PROTECTION AGAINST A
RISK OF FIRE REPLACE ONLY WITH SAME
TYPE FUSE.
FS1 (2.5A/250V)
DVM
AC SCALE
1.5k ohm
10W
TO EXPOSED
METAL PARTS
CONNECT TO
KNOWN EARTH
GROUND
0.15 µ F
TEST PROBE

LC-19D1E/S-RD, LC-19D1RU-BK/WH/RD
ii
Precautions for using lead-free solder
Employing lead-free solder
• “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The
alphabetical character following LF shows the type of lead-free solder.
Example:
Using lead-free wire solder
• When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional lead wire solder may cause dam-
age or accident due to cracks.
As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40 °C, we recommend you to use a dedicated soldering
bit, if you are not familiar with how to obtain lead-free wire solder or soldering bit, contact our service station or service branch in your area.
Soldering
• As the melting point of lead-free solder (Sn-Ag-Cu) is about 220 °C which is higher than the conventional lead solder by 40 °C, and as it has poor
solder wettability, you may be apt to keep the soldering bit in contact with the PWB for extended period of time. However, Since the land may be
peeled off or the maximum heat-resistance temperature of parts may be exceeded, remove the bit from the PWB as soon as you confirm the
steady soldering condition.
Lead-free solder contains more tin, and the end of the soldering bit may be easily corroded. Make sure to turn on and off the power of the bit as
required.
If a different type of solder stays on the tip of the soldering bit, it is alloyed with lead-free solder. Clean the bit after every use of it.
When the tip of the soldering bit is blackened during use, file it with steel wool or fine sandpaper.
• Be careful when replacing parts with polarity indication on the PWB silk.
Lead-free wire solder for servicing
LFa
Indicates lead-free solder of tin, silver and copper.
LF a/a
Indicates lead-free solder of tin, silver and copper.
Part No. Description Code
ZHNDAi123250E J φ0.3mm 250g (1roll) BL
ZHNDAi126500E J φ0.6mm 500g (1roll) BK
ZHNDAi12801KE J φ1.0mm 1kg (1roll) BM

LC-19D1E/S-RD, LC-19D1RU-BK/WH/RD
iii
LC19D1RU-BK Service Manual
OUTLINE AND MODIFIED PARTS LIST
OUTLINE
This Service Manual covers the differences from LC-19D1E/S-BK/WH.
For other technical information, refer to the LC-19D1E/S-BK/WH (No. S58J9LC19D1ES) Service Manual.
MODIFIED PARTS LIST
Ref. No. Description LC-19D1E/S-BK/WH
(Base Models)
LC-19D1E/S-RD, LC-19D1RU-BK/WH/RD
(These Models) Remarks
PRINTED WIRING BOARD ASSEMBLIES
N MAIN Unit DUNTKE683FM07 DUNTKE683FM07 No Change
N DIGITAL TUNER Unit DUNTKE243FM02 DUNTKE243FM02 No Change
N DIGITAL Unit DUNTKE523FM01 DUNTKE523FM01 No Change
N R/C LED Unit DUNTKE248WE01 DUNTKE248WE01 No Change
N KEY Unit DUNTKE249WE01 DUNTKE249WE01 No Change
N POWER Unit RDENCA242WJQ1 RDENCA242WJQ1 No Change
LCD PANEL
N 18.5" WXGA LCD Panel Module R1LK185T3GW10W R1LK185T3GW10W No Change
CABINET PARTS
Refer to Parts List.
SUPPLIED ACCESSORIES
Refer to Parts List.
PACKING PARTS
Refer to Parts List.
Service Jigs
No Change

PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-19D1E/S-RD, LC-19D1RU-BK/WH/RD
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLY
[2] LCD PANEL
[3] CABINET PARTS
[4] SUPPLIED ACCESSORIES
[5] PACKING PARTS
CONTENTS
No. S19W4LC19D1RU
LCD COLOUR TELEVISION
LC-19D1E-RD
LC-19D1S-RD
LC-19D1RU-BK/WH/RD
MODELS

LC-19D1E/S-RD, LC-19D1RU-BK/WH/RD
2
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLY
NDUNTKE683FM07 CG N V MAIN Unit
NDUNTKE243FM02 BK N V DIGITAL TUNER Unit
NDUNTKE523FM01 BP N V DIGITAL Unit
NDUNTKE248WE01 AQ N V R/C LED Unit
NDUNTKE249WE01 AL N V KEY Unit
NRDENCA242WJQ1 BE N J POWER Unit (Unit Replacement Item)
[2] LCD PANEL
NR1LK185T3GW10W CH N J 18.5" WXGA LCD Panel Module

LC-19D1E/S-RD, LC-19D1RU-BK/WH/RD
3
[3] CABINET PARTS
1-1
1-4
1-4
1-2
1-5
4-1
1-5
1-3
15
22
26
54
54
37
15
1
40
40
42
42
43
43
43
16
3-1
3-3
3-2
2
9
28
5-1
5-3
5-4
4-2
5-2
4
4-3
518
36
36
18
44
15
20
19
23
45
57
12
2-2
2-1
2-4
2-2
2-3
13
29
14
31
3
8
30
6
11 10
7
34
38
57
25
57
57
26
27
24
41
21
35
32
43
43
57
57
57
17
57
4-4
47
53
51
47
48
52
49
56
50 55

LC-19D1E/S-RD, LC-19D1RU-BK/WH/RD
4
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[3] CABINET PARTS
1CCABAB811WJ29 AY N S Cabinet A Ass'y (LC-19D1E/S/RU-RD)
1CCABAB811WJ30 AY N S Cabinet A Ass'y (LC-19D1RU-BK)
1CCABAB811WJ31 AY N S Cabinet A Ass'y (LC-19D1RU-WH)
1-1 Not Available - N - Cabinet A
1-2 GCOVAD046WJ4B AR J SP Net (LC-19D1E/S/RU-RD, LC-19D1RU-BK)
1-2 GCOVAD046WJ4C AR J SP Net (LC-19D1RU-WH)
1-3 HDECQA765WJ4A AD J LED Dec. Cover
1-4 PSPAHB419WJ00 AB J Mask Himelon-S, x2
1-5 PSPAHB420WJ00 AC J Mask Himelon-L, x2
2CCABBB152WJ03 AY N S Cabinet B Ass'y (LC-19D1E/S/RU-RD)
2CCABBB152WJ04 AY N S Cabinet B Ass'y (LC-19D1RU-BK)
2CCABBB152WJ05 AY N S Cabinet B Ass'y (LC-19D1RU-WH)
2-1 Not Available - N - Cabinet B
2-2 PSPAHB507WJZZ AB J Himelon, x2
2-3 PSPAHB508WJZZ AB J Himelon, x2
2-4 PSHEZA066WJZZ BX J Protect Sheet
3CANGTA465WJ03 AT J VESA Angle Ass'y
3-1 LANGTA465WJ4W - - VESA Angle
3-2 PSPAHB418WJ00 AB N J Himelon
3-3 PZETKA237WJKZ AE J Barrier (VESA)
4CHLDZA867WJ02 AF J SP Holder R Ass'y
4-1 LHLDZA867WJ4Z - - SP Holder R
4-2 PSPAGA378WJZZ AB J Gum Bush, x2
4-3 PSPAHB326WJ00 AC N J Himelon
4-4 PSPAZB608WJZZ AC J SP Spacer
5CHLDZA874WJ02 AF J SP Holder L Ass'y
5-1 LHLDZA874WJ4Z - - SP Holder L
5-2 PSPAGA378WJZZ AB J Gum Bush, x2
5-3 PSPAHB326WJ00 AC N J Himelon
5-4 PSPAZB608WJZZ AC J SP Spacer
6DUNTKE683FM07 CG N V MAIN Unit
7DUNTKE523FM01 BP N V DIGITAL Unit
8DUNTKE248WE01 AQ N V R/C, LED Unit
9DUNTKE249WE01 AL N V KEY Unit
10 RDENCA242WJQ1 BE N J POWER Unit (Unit Replacement Item)
11 DUNTKE243FM02 BK N V DIGITAL TUNER Unit
12 GCOVAC327WJ4F AD J BAS CONE Cover (LC-19D1E/S/RU-RD)
12 GCOVAC327WJ4A AD J BAS CONE Cover (LC-19D1RU-BK)
12 GCOVAC327WJ4B AD J BAS CONE Cover (LC-19D1RU-WH)
13 GCOVAC613WJ4C AC N S RS232C Cover (LC-19D1E/S/RU-RD)
13 GCOVAC613WJ4A AC N S RS232C Cover (LC-19D1RU-BK)
13 GCOVAC613WJ4B AC N S RS232C Cover (LC-19D1RU-WH)
14 JBTN-A675WJ4B AF J Control Button (LC-19D1E/S/RU-RD, LC-19D1RU-WH)
14 JBTN-A675WJ4A AG J Control Button (LC-19D1RU-BK)
15 LHLDW1173CEZZ AD J Wire Holder, x4 (FOR LAMP LED SP)
16 LHLDWA092WJZZ AB J Wire Holder, x4
17 LX-BZA202WJF7 AA J Screw, x4 (PWB)
18 LX-HZA011WJFN AB J Screw, x2 (FOR SP HOLDER)
19 MHNG-A166WJ2Z AV J Hinge
20 NSFTZ0134CEFW AD J Shaft, x2 (FOR PC TANSI)
21 NSFTZ0135CEFW AD J Shaft, x2 (FOR RS232C)
22 PSLDMA340WJZZ AG J EMC Sheet (50*50)
23 PSLDMB535WJ4W AP N S Main Shield
24 PSLDMB536WJ4W AG N S Source Shield
25 PSPAGA367WJZZ AB J Spacer
26 PSPAZB626WJZZ AB J SHAKOU Spacer
27 PZETKA236WJKZ AL J Barrier (Power)
28 PZETKA238WJKZ AD J Barrier (LCD Control PWB)
29 TLABNC117WJZZ AC N S Model Label
30 QCNW-H485WJQZ AH N J Connecting Cord (MAIN-LED)
31 QCNW-H486WJQZ AF N J Connecting Cord (MAIN-KEY)
32 QCNW-G141WJQZ AG J Connecting Cord (MAIN-SP)
34 QPWBM0242TPZZ AG J FPC (MAIN-FPC-LCD)
35 LANGKB183WJ4A AF S Card Angle (LC-19D1E/S/RU-RD, LC-19D1RU-BK)
35 LANGKB183WJ4B AF S Card Angle (LC-19D1RU-WH)
36 VSP7530PA128B AK N J Speaker (2W/75*30)
37 R1LK185T3GW10W CH N J 18.5" WXGA LCD Panel Module
!
38 RTUDAA019WJQZ AY S Tuner
40 XBBS940P10000 AB J Screw, x5 (FOR HINGE) (LC-19D1E/S/RU-RD, LC-19D1RU-BK)
40 XBBS740P10000 AA N S Screw, x5 (HINJI/HINJI COV) (LC-19D1RU-WH)
41 XBPS830P06000 AA J Screw (FOR HDMI) (LC-19D1E/S/RU-RD, LC-19D1RU-BK)
41 XBPS730P06000 AA J Screw (FOR HDMI) (LC-19D1RU-WH)
42 XEBS930P14000 AA J Screw, x11 (CAB-A/B4 TANSI7) (LC-19D1E/S/RU-RD, LC-19D1RU-BK)
42 XEBSN30P14000 AA J Screw, x11 (CAB-A/B4 TANSI7) (LC-19D1RU-WH)
43 XEBSN30P10000 AA J Screw, x8 (SP PNL BTN LED)
44 XEBSN40P10000 AB J Screw, x3 (FOR VESA)
45 GCOVAC326WJ4F AF J Stand Cover (LC-19D1E/S/RU-RD)
45 GCOVAC326WJ4A AG J Stand Cover (LC-19D1RU-BK)
45 GCOVAC326WJ4B AF J Stand Cover (LC-19D1RU-WH)
47 PSLDMB427WJZZ AC N S Shield (20*30MM), x2
48 PSLDMB428WJZZ AC N S Shield (40*30MM)
49 PSLDMB431WJZZ AC N S Shield
50 PSLDMB449WJZZ AF N J Shield (for RAC Jack)
51 PSLDMB450WJZZ AE N S Shield

LC-19D1E/S-RD, LC-19D1RU-BK/WH/RD
5
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[4] SUPPLIED ACCESSORIES
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
52 PSLDMB451WJZZ AC N S Shield
53 PSLDMB524WJZZ AB N S Shield (10*10mm)
54 PSPAHB156WJ4Z AB J Spacer for (LCD) (LC-19D1E/S/RU)
55 QCNW-H693WJQZ AH N S Connecting Cord
56 RCORF2020TPZZ AG N S Core (for FPC)
57 XBPS730P06WS0 AA J Screw, x12 (PWB8,ANG4)
[4] SUPPLIED ACCESSORIES
X1 RRMCGA608WJSA AQ J Remote Control Unit (LC-19D1E/S/RU-RD, LC-19D1RU-BK)
X1 RRMCGA608WJSB AQ N J Remote Control Unit (LC-19D1RU-WH)
!
X2 QACCKA004WJPZ AM J AC Cord for Europe without U.K. and Ireland
!
X2 QACCBA054WJPZ AN J AC Cord for U.K. and Ireland
X3 LHLDWA149WJSA AE J Cable Clamp (LC-19D1E/S/RU-RD, LC-19D1RU-WH)
X3 LHLDWA149WJSB AE J Cable Clamp (LC-19D1RU-BK)
X4 CDAI-A375WJ13 AW J Stand Unit(LC-19D1E/S/RU-RD)
X4 CDAI-A375WJ03 AX J Stand Unit(LC-19D1RU-BK)
X4 CDAI-A375WJ04 AX J Stand Unit(LC-19D1RU-WH)
X5 LX-BZA198WJF7 AB J Screw, x3 (for Stand)
X6 UKOGLA009WJZZ AC J Hexagon Wrench
X7 TINS-D222WJZZ AL N S Operation Manual (EN/G/F...) (LC-19D1E/S-RD)
X7 TINS-D223WJZZ AL N S Operation Manual (SW/FI...) (LC-19D1E/S-RD) (except for U.K. and Ireland)
X7 TINS-D224WJZZ AM N S Operation Manual (PL/CZ...) (LC-19D1E) (except for U.K. and Ireland)
X7 TINS-E064WJZZ AD N S Operation Manual (RU) (LC-19D1RU-BK/WH/RD)
X8 TGAN-A801WJZZ AD N S Guarantee Card (LC-19D1E) (for U.K.)
X9 TGAN-A802WJZZ AD N S AQUOS Care Plan (LC-19D1E) (for U.K.)
X10 TGAN-A077WJZZ AE J Guarantee Card (LC-19D1RU) (for Russia)
X11 Not Available - - Batteries
[3] CABINET PARTS
X10
X11
X7
X8
X9
X1
X2
X4 X5
X6
X3

LC-19D1E/S-RD, LC-19D1RU-BK/WH/RD
6
[5] PACKING PARTS
S3
S1
S4
S10
S5
S9
S8
S7

LC-19D1E/S-RD, LC-19D1RU-BK/WH/RD
7
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[5] PACKING PARTS
S1 SPAKCE772WJZZ - - Packing Case
S3 SPAKPA903WJZZ - - Wrapping Paper
S4 SPAKXB742WJ1Z - - Buffer Material (Bottom)
S5 SPAKXB741WJ1Z - - Buffer Material (Top)
S7 SSAKAA072WJZZ - - Polyethylene Bag
S8 SPAKPA909WJZZ - - Wrapping Paper (Stand)
S9 SSAKAA111WJZZ - - Polyethylene Bag
S10 TLABM5584BMZZ - - Pack Case Label

LC-19D1E/S-RD, LC-19D1RU-BK/WH/RD
COPYRIGHT © 2009 BY SHARP CORPORATION
ALL RIGHTS RESERVED.
No Part of this publication may be reproduced,
stored in a retrieval system, or transmitted in
any from or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without
prior written permission of the publisher.
SHARP CORPORATION
AV Systems Group
CS Promotion Center
Yaita,Tochigi 329-2193, Japan
Jan. 2009
TQ2700-S SH. DS
