SERVICE MANUAL
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
OUTLINE AND DIFFERENCES FROM BASE MODEL
OUTLINE.............................................................i
DIFFERENCES FROM BASE MODEL...............i
SAFETY PRECAUTION
IMPORTANT SERVICE SAFETY PRE-
CAUTION...........................................................ii
Precautions for using lead-free solder ..............iii
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS .........................................1-1
CHAPTER 2. OPERATION MANUAL
[1] OPERATION MANUAL..................................2-1
CHAPTER 3. DIMENSIONS
[1] DIMENSIONS................................................3-1
CHAPTER 4. OVERALL WIRING DIAGRAM
[1] LC-42D63X....................................................4-1
[2] LC-46D63X....................................................4-2
Parts Guide
TopPage
CONTENTS
LC-42D63X/LC-46D63X
No. S97R2LC46D63X
MODELS LC-42D63X
LC-46D63X
LCD COLOR TELEVISION
In the interests of user safety (required by safety regulations in some countries) the set should be restored to its
original condition and only parts identical to those specified should be used.
This model is based on the LC-42D83X, LC-46D83X and partially modified.
For the contents not covered in this Service Manual, accordingly, please refer to the LC-42D83X, LC-46D83X
(S97R1LC52D83X) Service Manual.
OUTLINE

LC-42D63X/LC-46D63X
i
LC42D63X ServiceManual

OUTLINE AND DIFFERENCES FROM BASE MODEL
OUTLINE
This model is based on the LC-42D83X, LC-46D83X and partially modified.
For the contents not covered in this Service Manual, accordingly, please refer to the LC-42D83X, LC-46D83X (S97R1LC52D83X)
Service Manual.
DIFFERENCES FROM BASE MODEL
LIST OF CHANGED PARTS (LC-42D63X)
LIST OF CHANGED PARTS (LC-46D63X)
Ref. No. Description LC-42D83X LC-42D63X Note
PRINTED WIRING BOARD ASSEMBLIES (NOT REPLECEMENT ITEM)
MINI-AV Unit DUNTKE188FM05 DUNTKE188FM05 No Changes
KEY Unit DUNTKE266FM03 DUNTKE266FM03 No Changes
MAIN Unit DUNTKE186FM11 DUNTKE186FM11 No Changes
SUB Unit DUNTKE183FM01 DUNTKE183FM01 No Changes
LED, R/C Unit DUNTKE264FM03 DUNTKE264FM03 No Changes
POWER Unit RDENCA237WJQZ RDENCA237WJQZ No Changes
AC INLET Unit RUNTKA341WJQZ RUNTKA341WJQZ No Changes
LCD PANEL (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPENDENTLY.)
R1LK420D3LZ60W R1LK420D3LZ50W Changes
Ref. No. Description LC-46D83X LC-46D63X Note
PRINTED WIRING BOARD ASSEMBLIES (NOT REPLECEMENT ITEM)
MINI-AV Unit DUNTKE188FM05 DUNTKE188FM05 No Changes
KEY Unit DUNTKE266FM03 DUNTKE266FM03 No Changes
MAIN Unit DUNTKE186FM11 DUNTKE186FM11 No Changes
SUB Unit DUNTKE183FM01 DUNTKE183FM01 No Changes
LED, R/C Unit DUNTKE264FM03 DUNTKE264FM03 No Changes
POWER Unit RDENCA237WJQZ RDENCA237WJQZ No Changes
AC INLET Unit RUNTKA341WJQZ RUNTKA341WJQZ No Changes
LCD PANEL (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPENDENTLY.)
R1LK460D3LZ60W R1LK460D3LZ50W Changes

LC-42D63X/LC-46D63X
ii
LC42D63X ServiceManual

SAFETY PRECAUTION
IMPORTANT SERVICE SAFETY PRECAUTION
WARNING
1. For continued safety, no modification of any circuits should be
attempted.
2. Disconnect AC power before servicing.
BEFORE RETURNING THE RECEIVER
(Fire & Shock Hazard)
Before returning the receiver to the user, perform the following
safety checks:
3. Inspect all lead dress to make certain that leads are not pinched,
and check that hardware is not lodged between the chassis and
other metal parts in the receiver.
4. Inspect all protective devices such as non-metallic control knobs,
insulation materials, cabinet backs, adjustment and compartment
covers or shields, isolation resistor-capacitor networks, mechanical
insulators, etc.
5. To be sure that no shock hazard exists, check for leakage current in
the following manner.
• Plug the AC cord directly into a 110 ~ 240 volt AC outlet.
• Using two clip leads, connect a 1.5k ohm, 10 watt resistor paral-
leled by a 0.15µF capacitor in series with all exposed metal cabinet
parts and a known earth ground, such as electrical conduit or elec-
trical ground connected to an earth ground.
• Use an AC voltmeter having with 5000 ohm per volt, or higher, sen-
sitivity or measure the AC voltage drop across the resistor.
• Connect the resistor connection to all exposed metal parts having a
return to the chassis (antenna, metal cabinet, screw heads, knobs
and control shafts, escutcheon, etc.) and measure the AC voltage
drop across the resistor.
All checks must be repeated with the AC cord plug connection
reversed. (If necessary, a non polarized adaptor plug must be used
only for the purpose of completing these checks.)
Any reading of 0.74 V rms (this corresponds to 0.5 milliamp. rms
AC.) or more is excessive and indicates a potential shock hazard
which must be corrected before returning the monitor to the owner.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
SAFETY NOTICE
Many electrical and mechanical parts in LCD color television have
special safety-related characteristics.
These characteristics are often not evident from visual inspection, nor
can protection afforded by them be necessarily increased by using
replacement components rated for higher voltage, wattage, etc.
Replacement parts which have these special safety characteristics are
identified in this manual; electrical components having such features
are identified by " " and shaded areas in the Replacement Parts
Lists and Schematic Diagrams.
For continued protection, replacement parts must be identical to those
used in the original circuit.
The use of a substitute replacement parts which do not have the same
safety characteristics as the factory recommended replacement parts
shown in this service manual, may create shock, fire or other hazards.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the
servicing guidelines which follow:
DVM
AC SCALE
1.5k ohm
10W
TO EXPOSED
METAL PARTS
CONNECT TO
KNOWN EARTH
GROUND
0.15 µ F
TEST PROBE

LC-42D63X/LC-46D63X
iii
Precautions for using lead-free solder
Employing lead-free solder
• “All PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals.
The alphabetical character following LF shows the type of lead-free solder.
Example:
Using lead-free wire solder
• When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional lead wire solder may cause dam-
age or accident due to cracks.
As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40 °C, we recommend you to use a dedicated soldering
bit, if you are not familiar with how to obtain lead-free wire solder or soldering bit, contact our service station or service branch in your area.
Soldering
• As the melting point of lead-free solder (Sn-Ag-Cu) is about 220 °C which is higher than the conventional lead solder by 40 °C, and as it has poor
solder wettability, you may be apt to keep the soldering bit in contact with the PWB for extended period of time. However, Since the land may be
peeled off or the maximum heat-resistance temperature of parts may be exceeded, remove the bit from the PWB as soon as you confirm the
steady soldering condition.
Lead-free solder contains more tin, and the end of the soldering bit may be easily corroded. Make sure to turn on and off the power of the bit as
required.
If a different type of solder stays on the tip of the soldering bit, it is alloyed with lead-free solder. Clean the bit after every use of it.
When the tip of the soldering bit is blackened during use, file it with steel wool or fine sandpaper.
• Be careful when replacing parts with polarity indication on the PWB silk.
Lead-free wire solder for servicing
LFa
Indicates lead-free solder of tin, silver and copper.
LF a/a
Indicates lead-free solder of tin, silver and copper.
Part No. Description Code
ZHNDAi123250E J φ0.3mm 250g (1roll) BL
ZHNDAi126500E J φ0.6mm 500g (1roll) BK
ZHNDAi12801KE J φ1.0mm 1kg (1roll) BM

LC-42D63X/LC-46D63X
1 – 1
LC42D63X ServiceManual

CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
LCD panel
Item LC-42D63X
42"(1070 mm) Advanced Super View &
BLACK TFT LCD
Model
INPUT 5 HDMI (HDMI input) (480I, 576I, 480P, 576P, 720P/50Hz, 720P/60Hz, 1080I/50Hz,
1080I/60Hz, 1080P/50Hz, 1080P/60Hz, 1080P/24Hz)
Viewing angles H : 176º V : 176º
Audio amplifier 15W x2
Speakers 10 x4cm 4pcs
Video Colour System
TV
Function
TV-Standard
Receiving
Channel
VHF/UHF
CATV
TV-Tuning System
Brightness
Terminals Rear ANTENNA IN
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 6
INPUT 7 (PC input)
PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
PAL: B/G, D/K, I SECAM: B/G, D/K, K/K
44.25 - 863.25 MHz
S1 - S41ch (including Hyperband)
Auto Preset 99 ch
450 cd/m2
UHF/VHF 75 DIN type
VIDEO in, AUDIO in, COMPONENT in (480I, 576I, 480P, 576P, 720P/50Hz, 720P/60Hz, 1080I/50Hz, 1080I/60Hz)
VIDEO in, AUDIO in, COMPONENT in (480I, 576I, 480P, 576P, 720P/50Hz, 720P/60Hz, 1080I/50Hz, 1080I/60Hz)
S-VIDEO in, VIDEO in, AUDIO in
HDMI (HDMI input) (480I, 576I, 480P, 576P, 720P/50Hz, 720P/60Hz, 1080I/50Hz,
1080I/60Hz, 1080P/50Hz, 1080P/60Hz, 1080P/24Hz)
HDMI (HDMI input) (480I, 576I, 480P, 576P, 720P/50Hz, 720P/60Hz, 1080I/50Hz,
1080I/60Hz, 1080P/50Hz, 1080P/60Hz, 1080P/24Hz), AUDIO in
15 pin mini D-sub, AUDIO in (Ø 3.5 mm jack)
STEREO/BILINGUAL NICAM: B/G, I, D/K A2 stereo: B/G
Number of dots 6,220,800 dots (1920 x1080 x3dots)
As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for
product improvement without prior notice. The performance specification figures indicated are nominal values of production
units. There may be some deviations from these values in individual units.
LC-46D63X
46"(1170 mm) Advanced Super View &
BLACK TFT LCD
OSD language
Power Requirement
English/Simplified Chinese/Traditional Chinese/Arabic
AC 110 - 240 V, 50/60 Hz
Power Consumption 227 W (0.8 W Standby)
Weight
Operating Temperature 0°C - 40°C
with stand
without stand 21.5 kg
26.0 kg
267 W (0.8 W Standby)
24.5 kg
29.5 kg
RS-232C 9 pin D-sub male connector
MONITOR OUT
DIGITAL AUDIO OUTPUT
VIDEO out, AUDIO out
Optical Digital Audio output

LC-42D63X/LC-46D63X
2 – 1
LC42D63X ServiceManual

CHAPTER 2. OPERATION MANUAL
[1] OPERATION MANUAL
Part names
Volume up ( )/down ( ) buttons
Channel up ( )/down ( ) buttons
OPC indicator*
POWER (On/Off) button
MENU button
*OPC: Optical Picture Control
TV/VIDEO button
OPC sensor
Remote control sensor
POWER indicator
TV (Front/Side)
SLEEP timer indicator

LC-42D63X/LC-46D63X
2 – 2
TV (Rear)
RS-232C terminal
INPUT 4 (HDMI)
terminals
INPUT 7 (PC) terminals
INPUT 2 terminals
INPUT 1 terminals
Antenna input terminal
AC INPUT terminal
Headphone jack
INPUT 5 (HDMI)
terminals
INPUT 6 (HDMI)
terminals
INPUT 3 terminals
MONITOR OUTPUT terminal
DIGITAL AUDIO
OUTPUT terminal

LC-42D63X/LC-46D63X
2 – 3
Remote control unit
1 POWER (STANDBY/ON)
To switch the power on and off.
20-9
Set the channel.
TELETEXT mode: Set the page.
3 (Flashback)
Press to return to the previous selected channel or external input
mode.
4ATV
Press to access ANALOG mode.
5DTV
Press to access DTV mode.
6 MPX
Select the sound multiplex mode.
7 VOL /VOL
Set the volume.
8 (Mute)
Mute the sound.
9GUIDE
DTV mode: Dis
p
la
y
the
p
ro
g
ramme list.
10 EPG
DTV mode: To display EPG (Electronic Programme Guide) screen.
11 EXIT
Turn off the On-Screen Display.
12 OPC
To switch the Optical Picture Control on and off.
AV MODE
Select a video setting.
WIDE
Change the wide image mode.
FREEZE
Freeze a motion picture on the screen.
13 (TELETEXT)
Select the TELETEXT mode. (all TV image, all TEXT image, TV/
TEXT image)
(Reveal hidden for TELETEXT)
TELETEXT mode: Display hidden characters.
(SUBTITLE for TELETEXT)
To turn the subtitles on and off.
(Hold)
TELETEXT mode: Stop updating Teletext pages automatically.
Press again to release the hold mode.
(Subpage)
Display the Teletext subpage directly.
(Top/Bottom/Full)
TELETEXT mode: Set the area of magnification.
14 TV/VIDEO (INPUT SOURCE)
Select an input source. (TV, INPUT 1, INPUT 2, INPUT 3, INPUT 4,
INPUT 5, INPUT6, INPUT7 (PC))
15 FAV.
Display the favourite channel setting.
16 RADIO
Press to access RADIO mode.
17 DISPLAY
Displays the channel or input information.
DTV mode: Displays the time information included in the DTV
broadcast.
TELETEXT mode: Displays the time information included in the
Teletext broadcast.
18 CH /CH
TV input mode: Select the channel.
TELETEXT mode: Select the page.
19 SLEEP
Set the Sleep timer.
20 INFO
DTV mode: Display the programme information.
21 MENU
Display the menu screen.
22 / / / (Cursor)
Select a desired item on the setting screen.
ENTER
Execute a command.
23 RETURN
MENU mode: Return to the previous menu screen.
24 Colour (Red/Green/Yellow/Blue)
TELETEXT mode: Select a page.
25 AQUOS LINK buttons
TV mode: If external equipment such as a AQUOS BD Player is
connected via HDMI cables and is AQUOS LINK compatible, you
can use these AQUOS LINK buttons.
DVD/VCR mode: Press OPTION to pause the picture.
The buttons except OPTION are correspondingly used to
select the items on the screen.
STB mode: Only the button can be used to operate on STB.
2
6
11
12
1
8
7
10
5
9
17
18
23
21
20
14
15
19
16
24
25
22
13
4
3

LC-42D63X/LC-46D63X
2 – 4
Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT terminal.
Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being
damaged.
CAUTION
Attach the stand in the correct direction.
Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
Attaching the stand
1 3 1Insert the stand into the openings on the
bottom of the TV.
2Insert and tighten the 4 short screws into
the 4 holes on the rear of the TV.
Hex ke
y
Short
screw
Soft
cushion
NOTE
To detach the stand, perform the steps in reverse order.
2
Hex
key
Long screw
Attach the supporting post for the stand unit
onto the base as shown below.
Confirm the 8 screws supplied with the TV.
Short screws ( x4)
(usedinstep3) Long screws ( x4)
(used in step 2)
LC-42D63X
LC-46D63X
Hex
key
Long screw
LC-42D63X
CAUTION
Adjust the screen with both hands. Put one hand on
the TV and rotate the screen while steadying the stand
with your other hand.
The TV can be rotated up to 15 degrees to the right or left.
15°
15°

LC-42D63X/LC-46D63X
3 – 1
LC42D63X ServiceManual

CHAPTER 3. DIMENSIONS
[1] DIMENSIONS
400
550
400
200
933.2
526.2
114 95
305
1004
409
708
64662
Unit: mm
LC-42D63X
550
400
400
1023.4
1101
575.6
62
434
124 95
325
175
760
698
LC-46D63X

LC-42D63X/LC-46D63X
4 – 1
LC42D63X ServiceManual

CHAPTER 4. OVERALL WIRING DIAGRAM
[1] LC-42D63X

LC-42D63X/LC-46D63X
4 – 2
[2] LC-46D63X

PARTS GUIDE
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-42D63X/LC-46D63X
No. S97R2LC46D63X
MODELS LC-42D63X
LC-46D63X
LCD COLOR TELEVISION
Note:
The reference numbers on the PWB
are arranged in alphabetical order.
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLY (NOT RELPACEMENT
ITEM)
[2] LCD PANEL (NOTE: THE PARTS
HERE SHOWN ARE SUPPLIED AS
AN ASSEMBLY BUT NOT
INDEPENDENTLY.)
[3] CABINET PARTS (LC-42D63X)
[4] CABINET PARTS (LC-46D63X)
[5] SUPPLIED ACCESSORIES
[6] PACKING PARTS (NOT
REPLACEMENT ITEM)

LC-42D63X/LC-46D63X
2
NO. PARTS CODE PRICE
RANK NEW MARK PART
DELIVERY DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLY (NOT RELPACEMENT ITEM)
NDUNTKE183FM01 N V SUB Unit
NDUNTKE186FM11 N V MAIN Unit
NDUNTKE188FM05 N V MINI-AV Unit
NDUNTKE264FM03 AP V LED Unit
NDUNTKE266FM03 AG N V KEY Unit
NRDENCA237WJQZ BT N V POWER Unit
NRUNTKA341WJQZ AY N V AC-INLET Unit
[2] LCD PANEL (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPEN-
DENTLY.)
NR1LK420D3LZ50W EZ N J 42 PANEL ASSY (LC-42D63X)
NR1LK460D3LZ50W FD N J 46 PANEL ASSY (LC-46D63X)

LC-42D63X/LC-46D63X
3
[3] CABINET PARTS (LC-42D63X)
2-4
㧭
㧳
㧿
㧿
㧿㧿
㧭
25
2-1
2-2
3-1
3-2
3-3
11
45
6
3
8
9
7
5
57
54
17 18
15
16
71
37
68
19
22
20
67
1-12
1-7
1-11
1-11
1-11
1-11
1-11
1-7
1-7
1-8
1-7
1-7
1-7
1-3
1-2
1-5
1-6
1-9
1-10
1-10
1-4
1
1-1
2-3
53 33
27
14
14
13
58
63
63
48
㧷
68
78
19
28
73
74
36
40
31
24
22
21
20
20 52
23
62
30
62
32
29
62
62
62
62
62
62
65
25
66
55
49
56
42
44
41
50
51
㧯
㧰
㧲
㧴
㨀
㧵
ȡ
㧯
㧽
㧰
㧱
2
㧲
46
47
㧳
㧴
㧸
㧷
㧸
ȡ
62
59
62
62
62
㧻
㧵
59
67
64
㧺
㧺
㧼
43
㧽
㧮
㧻
㧮
35
4-1
4-3
4-2
4
62
62
72
62
26
26
60
㨄㧡
㧼
㧼
㧱
㨀
78 75
77
70
22
22
22
22
22
20
19
19
1-13
2-5
69 76

LC-42D63X/LC-46D63X
4
NO. PARTS CODE PRICE
RANK NEW MARK PART
DELIVERY DESCRIPTION
[3] CABINET PARTS (LC-42D63X)
1CCABAB825WJ44 N V KS CAB-A
1-1 Not Available - N - FRONT CAB
1-2 GCOVAC438WJ4A N V FRONT COVER
1-3 HBDGBA061WJSA AH J SHARP BDGB
1-4 HDECQA777WJ1A AC J LED DECRATION
1-5 HDECSA028WJ1A AM J SHIN TR
1-6 HPNLSA147WJ4A AY N J SP-SHEET
1-7 PSPAHB223WJ4Z AC N J MASK HIMERON x6
1-8 PSPAZB541WJ4Z AB N V FRONT COV TAPE
1-9 PSPAZB542WJ4Z AB N V FROT COV TAPE
1-10 PSPAZB543WJ4Z AC N J FRONT COV TAPE x2
1-11 PSPAZB544WJ4Z AD N J FRONT COV TAPE x6
1-12 XJPS730P08WS0 AA J SCREW x3
1-13 PSPAHB392WJ4Z N V HIMERON FOR CAB x2
2CCABBB127WJ42 S V KS BACK CABI
2-1 Not Available - N - BACK CABNET
2-2 HINDPC551WJ4A V TRM LABEL BTM
2-3 GCOVAC518WJ4Z AE J HOLE COVER x4
2-4 PSPAHB362WJ4Z N V FOR CAB-B x2
2-5 PRDARA523WJ4W AD N V RADIATOR
3CCOVAC392WJ42 N V KS SIDE KEY COV
3-1 Not Available - N - SIDE KEY COVER
3-2 HINDPC563WJ4A AD N J MINI TRM LABEL
3-3 JBTN-A676WJ4A AE N J OPERATION BUTN
4CANGKB173WJ41 AP N V KS SIDE KEY ANG
4-1 Not Available - N - TRM ANG SIDE
4-2 HINDPC550WJ4A AD N V TRM LABEL SIDE
4-3 HINDPC627WJ4A AC N J TRM LAB SIDE_A
5DUNTKE188FM05 N V MINI-AV Unit
6DUNTKE264FM03 AP N V LED Unit
7DUNTKE266FM03 AG N V KEY Unit
8DUNTKE186FM11 N V MAIN Unit
9DUNTKE183FM01 N V SUB Unit
11 GCOVAC336WJ4A AL N J BTOM COVER F
13 HINDPC547WJ4A N V MODEL LABEL
14 LANGKB187WJ4W AU N J PNL SUP ANG x2
15 LANGKB216WJ4W AF J MINI AV ANG
16 LANGKB238WJ4A N V TRM ANG BTM
17 LCHSMA386WJ4W V CHS TRAY
18 LHLDFA036WJKZ AB J WH FRO TRAY x3
19 LHLDWA133WJKZ AC J WH x4
20 LHLDWA143WJKZ AC J WH x7
21 LHLDWA151WJKZ AB J WH FRO TRAY x5
22 LHLDWA163WJKZ AC J WH x11
23 LHLDWA164WJKZ AD J WH
24 LHLDWA172WJKZ AD J WH FRO TRAY
25 LX-HZA003WJFN AC J FOR-SP x4
26 NSFTZ0001DMZZ N V Screw x4
27 PCOVP2609WJZZ AH N J CONTROL SHIELD
28 PRDARA482WJ4W V MAIN PWB RADIAT
29 PSLDMB159WJ4W AK J AV SHILED
30 PSLDMB179WJ4W AD J MINI AV SHILD
31 PSPAZB313WJKZ AC N J 20*20_t2.0
32 PSLDMB158WJ4W V MAIN SHILED
33 PSPAZB597WJKZ AG J SPACER x2
35 QCNW-G183WJQZ V FR
36 QCNCMA673WJZZ AG N J 80PIN
37 QCNW-G419WJQZ AP N V FE
40 QCNW-F946WJQZ AH N J AC
41 QCNW-G181WJQZ BD V LW
42 QCNW-G020WJQZ AG N V KM
43 QCNW-G025WJQZ AH V SP
44 QCNW-G026WJQZ AH N V LA
45 QCNW-G237WJQZ AL N V RA
46 QCNW-G023WJPZ AM N V US
47 QCNW-G024WJQZ N V VD
48 QCNW-G182WJQZ AF V PL
49 QCNW-G028WJQZ V LB
50 QCNW-F947WJQZ AL N J PD
51 QCNW-F948WJQZ AK N J PE
52 QPWBHE321WJQZ AX N J HM
53 R1LK420D3LZ50W EZ N J '42 PANEL ASSY
54 RDENCA237WJQZ BT N V POWER Unit
55 RSP-ZA261WJZZ BA N J SP-L
56 RSP-ZA262WJZZ BA N J SP-R
57 RUNTKA341WJQZ AY N V AC INRET Unit
58 Not Available - N - NO.LABEL
59 XBBS740P08000 AA J SCREW x14
60 XBPS830P06000 AA J FOR HDMI x2
62 XBPS730P08WS0 AH J SCREW x49
63 XBPS940P10JS0 AB N J FOR CAB-B x8
64 XEBS940P16000 AB J FOR CAB_B x8
65 XIPSN20P04000 AA J FOR MINI HDMI x2
66 XJPS730P08WS0 AA J SCREW
67 XEBS940P20000 AB J FOR CAB-B x7

LC-42D63X/LC-46D63X
5
NO. PARTS CODE PRICE
RANK NEW MARK PART
DELIVERY DESCRIPTION
68 LHLDW1033CE00 AA J HOLDER x4
69 LHLDWA045WJZZ AD J HOLDER
70 LHLDWA186WJKZ AB V WH
71 PMLT-A443WJZZ AC J ABSORBER
72 PSLDMB105WJZZ AK J SHIELD
73 PSPAZB610WJKZ AR N V 25*25_t1.0
74 PSPAZB620WJKZ AE N V 25*25_t1.0
75 RCORF0103CEZZ AK J CORE x2
76 RCORFA012WJZZ AG J CORE
77 RCORFA023WJZZ AK J CORE x2
78 RCORFA038WJZZ AH J CORE x2
[3] CABINET PARTS (LC-42D63X)

LC-42D63X/LC-46D63X
6
[4] CABINET PARTS (LC-46D63X)
2-4
㧭
㧳
㧿
㧿
㧿㧿
㧭
24
2-1
2-2
3-1
3-2
3-3
11
45
6
3
9
7
5
57
54
17 18
15
16
19
22
20
67
1-12
1-7
1-8
1-8
1-8
1-8
1-8
1-7
1-7
1-9
1-7
1-7
1-7
1-3
1-2
1-5
1-6
1-10
1-11
1-11
1-4
1
1-1
53
26
14
14
13
58
63
63
48
44
㧷
20
21
35
39
23
22
21
20
20 52
23
62
30
62
62
62
62
62
65
24
42
66
55
49
56
41
43
40
50
51
㧮
㧯
㧰
㧾
㧲
㧽
㧵
ȡ
34
㧯
㧱
2
㧲
47
㧷
㧸
62
59
62
62
62
㧵
59
67
64
㧾
㧺
㧺
㧼
㧽
4-1
4-3
4-2
4
62
62
25
25
2-3
33
60
㨄㧡
㧼
㧼
8
36
27
74
75
31
62
32
62
㧰
㧳
㧴
㧸
ȡ
㧮
㧮
㨀
70
22
㧻
㧻
77
78
76
29
62
㧱
㧴
㨀
46
71
68 79
79
19
19 22
22
22
20
2-5
69 77

LC-42D63X/LC-46D63X
7
NO. PARTS CODE PRICE
RANK NEW MARK PART
DELIVERY DESCRIPTION
[4] CABINET PARTS (LC-46D63X)
1CCABAB822WJ44 N V KS CABI-A
1-1 Not Available - N - FRONT CABI
1-2 GCOVAC440WJ4A N V FRONT COVER
1-3 HBDGBA061WJSA AH J SHARP BDGB
1-4 HDECQA777WJ1A AC J LED DECRATION
1-5 HDECSA027WJ1A AN J SHINE TRIM
1-6 HPNLSA146WJ4A AY N J SP SHEET
1-7 PSPAHB222WJ4Z AC J MASK HIMERON x6
1-8 PSPAZB193WJ4Z V FRONT COV TAPE x6
1-9 PSPAZB541WJ4Z AB V FRONT TAPE
1-10 PSPAZB542WJ4Z AB V FRONT TAPE
1-11 PSPAZB543WJ4Z AC J FRONT TAPE x2
1-12 XJPS730P08WS0 AA J SCREW x3
2CCABBB100WJ42 N V KS BACK CABINET
2-1 Not Available - N - BACK CABNET
2-2 HINDPC551WJ4A V TRM LABEL BTM
2-3 GCOVAC518WJ4Z AE J HOLE COVER x4
2-4 PSPAHB362WJ4Z N V FOR CAB-B x2
2-5 PRDARA523WJ4W AD N V RADIATOR
3CCOVAC391WJ42 N V KS MINI AV COV
3-1 Not Available - N - MINI AV COVER
3-2 HINDPC563WJ4A AD N J MINI AV LABEL
3-3 JBTN-A676WJ4A AE N J OPERATE BTN
4CANGKB173WJ41 AP N V KS TRM ANG SIDE
4-1 Not Available - N - TRM ANG SIDE
4-2 HINDPC550WJ4A AD N V TRM LABEL SIDE
4-3 HINDPC627WJ4A AC N J TRM LAB SIDE_A
5DUNTKE188FM05 N V MINI-AV Unit
6DUNTKE264FM03 AP N J LED Unit
7DUNTKE266FM03 AG N J KEY Unit
8DUNTKE186FM11 N V MAIN Unit
9DUNTKE183FM01 N V SUB Unit
11 GCOVAC336WJ4A AL N J BTM COVER
13 HINDPC539WJ4A N V MODEL LABEL
14 LANGKB186WJ4W AU N J PNL SUP ANG x2
15 LANGKB215WJ4W AH J MINI AV ANG
16 LANGKB238WJ4A N V TRM ANG BTM
17 LCHSMA386WJ4W N V CHS TARY
18 LHLDFA036WJKZ AB J WH x3
19 LHLDWA133WJKZ AC J WH x4
20 LHLDWA143WJKZ AC J WH x12
21 LHLDWA151WJKZ AB J WH x6
22 LHLDWA163WJKZ AC J WH x8
23 LHLDWA172WJKZ AD J WH
24 LX-HZA003WJFN AC J FOR-SP x4
25 NSFTZ0001DMZZ N V Screw x4
26 PCOVP2609WJZZ AH N J CONTROL SHIELD
27 PRDARA482WJ4W V HEAT SINK
29 PSLDMB159WJ4W AK J AV SHILED
30 PSLDMB179WJ4W AD N J MINI AV SHILD
31 PSPAZB313WJKZ AC N J 20*20_t2.0
32 PSLDMB158WJ4W V MAIN SHILED
33 PSPAZB597WJKZ AG J SPACER x2
34 QCNW-G179WJQZ V FR
35 QCNCMA673WJZZ AG N J 80PIN
36 QCNW-G419WJQZ AP N V FE
39 QCNW-F946WJQZ AH N J AC
40 QCNW-G180WJQZ BE V LW
41 QCNW-G010WJQZ AG N V KM
42 QCNW-G015WJQZ AL J SP
43 QCNW-G016WJQZ AH N V LA1
44 QCNW-G017WJQZ AH N V LA2
45 QCNW-G236WJQZ AL N V RA
46 QCNW-G013WJPZ AN N V US
47 QCNW-G014WJQZ N V VD
48 QCNW-G178WJQZ AG V PL
49 QCNW-G018WJQZ V LB
50 QCNW-F947WJQZ AL N J PD
51 QCNW-F948WJQZ AK N J PE
52 QPWBHE322WJQZ AX N J HM
53 R1LK460D3LZ50W FD N J '46 PANEL ASSY
54 RDENCA237WJQZ BT N V POWER Unit
55 RSP-ZA261WJZZ BA N J SP-L
56 RSP-ZA262WJZZ BA N J SP-R
57 RUNTKA341WJQZ AY N V AC INRET Unit
58 Not Available - N - NO.LABEL
59 XBBS740P08000 AA J SCREW x14
60 XBBS830P06000 AA J SCREW
62 XBPS730P08WS0 AH J SCREW x50
63 XBPS940P10JS0 AB N J FOR CAB-B x8
64 XEBS940P16000 AB J SCREW x8
65 XIPSN20P04000 AA J SCREW x2
66 XJPS730P08WS0 AA J FOR BTM COVER
67 XEBS940P20000 AB J FOR CAB_B x7
68 LHLDW1033CE00 AA J HOLDER x4

LC-42D63X/LC-46D63X
8
NO. PARTS CODE PRICE
RANK NEW MARK PART
DELIVERY DESCRIPTION
69 LHLDWA045WJZZ AD J HOLDER
70 LHLDWA186WJKZ AB V WH
71 PMLT-A443WJZZ AC J ABSORBER
74 PSPAZB610WJKZ AR N V 25*25_t1.0
75 PSPAZB620WJKZ AE N V 25*25_t1.0
76 RCORF0103CEZZ AK J CORE x2
77 RCORFA012WJZZ AG J CORE
78 RCORFA023WJZZ AK J CORE x2
78 RCORFA023WJZZ AK J CORE
79 RCORFA038WJZZ AH J CORE x2
[4] CABINET PARTS (LC-46D63X)
