SUPPLEMENTAL SERVICE MANUAL
S9907R490CPJS
MICROWAVE OVEN
MODEL R-490C(S)
In interests of user-safety the oven should be restored to its
original condition and only parts identical to those specified
should be used.
TABLE OF CONTENTS Page
CAUTION, MICROWAVE RADIATION............................................................................................................. 1
WARNING..........................................................................................................................................................1
PRODUCT SPECIFICATIONS ......................................................................................................................... 2
GENERAL INFORMATION................................................................................................................................2
APPEARANCE VIEW ....................................................................................................................................... 3
COMPONENT REPLACEMENT AND ADJUSTMENT PROCEDURE ..............................................................4
MICROWAVE MEASUREMENT .......................................................................................................................6
WIRING DIAGRAM ............................................................................................................................................7
PICTORIAL DIAGRAM ......................................................................................................................................8
PARTS LIST ......................................................................................................................................................9
This is a supplemental Service Manual for Model R-490C(S). This model is quite similar to base model R-480C.
Use this supplemental manual together with the Base Model Service Manual (Refer No. is S6903R480CPJ/) for
complete operation, service information, etc..
Sensor
SENSOR DEFROST COOK
HELP
Info Display
Sensor Instant Reheat
Sensor Cook
DINNER
PLATE
CASSEROLE SOUP
PIZZA RICE PIE
VEGETABLES RICE/PASTA
DESSERTS MEAT
LESS
POWER
LEVEL
STOP
CLEAR
CLOCK TIMER
HELP
MORE
SLOW
COOK EASY DEFROST
1234 5
6789 0
INSTANT COOK 
START

R-490C(S)

R-490C(S)
1
SERVICE MANUAL
MICROWAVE OVEN
R-490C(S)
GENERAL IMPORTANT INFORMATION
This Manual has been prepared to provide Sharp Corp. Service engineers with Operation and Service Information.
Itisrecommended that serviceengineerscarefullystudy theentiretextof this manualandbase model's manual(Refer
No. is S6903R480CPJ/), so they will be qualified to render satisfactory customer service.
CAUTION
MICROWAVE RADIATION
DO NOT BECOME EXPOSED TO RADIATION FROM THE MICROWAVE GENERATOR OR OTHER PARTS
CONDUCTING MICROWAVE ENERGY.
Service engineers should not be exposed to the microwave energy which may radiate from the magnetron or other
microwave generating devices if it is improperly used or connected. All input and output microwave connections,
waveguides,flangesandgasketsmustbesecured.Neveroperatethedevicewithoutamicrowaveenergyabsorbing
load attached. Never look into an open waveguide or antenna while the device is energized.
WARNING
Never operate the oven until the following points are ensured.
(A) The door is tightly closed.
(B) The door brackets and hinges are not defective.
(C) The door packing is not damaged.
(D) The door is not deformed or warped.
(E) There is not any other visible damage with the oven.
Servicing and repair work must be carried out only by trained service engineers.
All the parts marked "*" on parts list are used at voltages more than 250V.
Removal of the outer wrap gives access to potentials above 250V.
All the parts marked "∆" on parts list may cause undue microwave exposure, by themselves, or when they are damaged,
loosened or removed.
SHARP CORPORATION
OSAKA, JAPAN

2
R-490C(S)
PRODUCT SPECIFICATIONS
ITEM DESCRIPTION
Power Requirements 230 - 240 Volts
50 Hertz
Single phase, 3 wire earthed
Power Consumption 1.6 kW
Power Output 1100 watts nominal of RF microwave energy (IEC 705)
Operating frequency 2450 MHz
Case Dimensions Width 550 mm
Height 315 mm
Depth 441 mm
Cooking Cavity Dimensions Width 378 mm
Height 223 mm
Depth 425 mm
Turntable diameter 360mm
Control Complement Touch Control System
Clock ( 1:00 - 12:59)
Timer (0 - 99 minutes 99 seconds)
Microwave Power for Variable Cooking
Repetition Rate;
HIGH ...............................................Full power throughout the cooking time
MEDIUM HIGH ..................................................approx. 70% of Full Power
MEDIUM .............................................................approx. 50% of Full Power
MEDIUM LOW ....................................................approx. 30% of Full Power
LOW ....................................................................approx. 10% of Full Power
HELP pad
SENSOR INSTANT REHEAT pads
SENSOR COOK pads
SLOW COOK pad
EASY DEFROST pad
MORE, LESS pads
NUMBER pads
POWER LEVEL pad
CLOCK pad
TIMER pad
STOP/CLEAR pad
INSTANT COOK/START pad
Weight Approx. 20 kg
GENERAL INFORMATION
WARNING
THIS APPLIANCE MUST BE EARTHED
IMPORTANT
THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:
GREEN-AND-YELLOW : EARTH
BLUE : NEUTRAL
BROWN : LIVE

R-490C(S)
3
APPEARANCEVIEW
1. Ventilation openings
2. Oven lamp
3. Door hinges
4. Door safety latches
5. See through door
10

3
4
2
713
5
614
4
11
8
16
9
12
15 1

SENSOR DEFROST COOK
HELP
Info Display
Sensor Instant Reheat
Sensor Cook
DINNER
PLATE
CASSEROLE SOUP
PIZZA RICE PIE
VEGETABLES RICE/PASTA
DESSERTS MEAT
LESS
POWER
LEVEL
STOP
CLEAR
CLOCK TIMER
HELP
MORE
SLOW
COOK EASY DEFROST
1234 5
6789 0
INSTANT COOK 
START
STOP/CLEAR PAD
Press to clear during programming.
Press once to stop operation of
oven during cooking; press twice to
cancel cooking programme.
POWER LEVEL PAD
Press to select microwave power
setting. If not pressed, HIGH is au-
tomatically selected.
INSTANT COOK/START PAD
Press once to cook for 1 minute on
HIGH or increase in 1 minute incre-
ments each time this pad is pressed
during cooking. Press to start the oven
after setting programmes.
HELP PAD
Press to select auto start, information
guide on/off, child lock, demonstra-
tion modes or info on pads.
Press to get cooking information.
SENSOR COOK PADS
Press to select Sensor Cook menus.
SENSOR INSTANT REHEAT PADS
Press once to reheat 1 of 6 popular
menus.
EASY DEFROST PAD
Press to defrost frozen food by en-
tering quantity.
MORE( ), LESS ( ) PADS
Press to increase/ decrease the time
in one minute increments during
cooking or alter the cooking result for
Sensor Instant Reheat, Sensor Cook
or Easy Defrost modes.
NUMBER PADS
Press to enter cooking times, clock time,
weight or quantity of food.
TIMER PAD
Press to set Timer
CLOCK PAD
Press to set Clock.
SLOW COOK PAD
Press to cook slowly and for a long
time.
Indicator
Display
6. Door seals and sealing surfaces
7. Coupling
8. Door open button
9. Touch control panel
10.Digital readout
11.Waveguide cover
12.Power supply cord
13.Rating label
14.Menu label
15.Turntable
16.Roller stay
TOUCH CONTROL PANEL

4
R-490C(S)
CONTROL PANEL ASSEMBLY REMOVAL
1. CARRY OUT 3D CHECKS.
2. Disconnect wire leads from panel components.
3. Releaseone(1)nailholdingthecontrolpanelassembly
to the oven flange.
4. Remove control panel assembly and slide upward.
5. Now, the control panel assembly is free.
NOTE: The key unit can not be exchanged by itself.
Because the control panel decoration is fixed by
the both sides adhesive tape. The Control panel
frame with key unit should be available as spare
part.
CPU UNIT AND POWER UNIT
NOTE: Handle the CPU unit carefully so that the ribbon
cabledoesnotcomeoff.Becausetheribboncable
isstickedon theLCDand theprintedwiring board
only by heated paste.
Figure C-3. CPU unit
Printed wiring board 
of CPU unit
Liquid Crystal
Display (LCD)
Ribbon cable
COMPONENT REPLACEMENT AND ADJUSTMENT PROCEDURE
WARNING: Avoid possible exposure to microwave energy. Please follow the instructions below before
operating the oven.
1. Disconnect the oven from the power supply.
2. Makesure thatadefinite“click”canbeheardwhenthe
microwave oven door is unlatched. (Hold the door in a
closedpositionwithonehand,thenpushthedooropen
buttonwiththeother,thiscausesthelatchleadstorise,
itisthenpossible to hear a “click”asthedoor switches
operate.)
3. Visuallycheckthedoorandcavityfaceplatefordamage
(dents, cracks, signs of arcing etc.).
Carry out any remedial work that is necessary before
operating the oven.
Do not operate the oven if any of the following conditions
exist;
1. Door does not close firmly.
2. Door hinge, support or latch hook is damaged.
3. The door gasket or seal or damaged.
4. The door is bent or warped.
5. There are defective parts in the door interlock system.
6. Therearedefective partsinthemicrowavegenerating
and transmission assembly.
7. There is visible damage to the oven.
Do not operate the oven:
1. Without the RF gasket (Magnetron).
2. If the wave guide or oven cavity are not intact.
3. If the door is not closed.
4. If the outer case (cabinet) is not fitted.
Please refer to ‘OVEN PARTS, CABINET PARTS, CONTROL PANEL PARTS, DOOR PARTS’, when carrying out any
of the following removal procedures:
WARNING FOR WIRING
To prevent an electric shock, take the following
manners.
1. Before wiring,
1) Disconnect the power supply.
2) Open the door and wedge the door open.
3) Dischargethehighvoltagecapacitorandwaitfor
60 seconds.
2. Don't let the wire leads touch to the following parts;
1) High voltage parts:
Magnetron, High voltage transformer, High
voltagecapacitor,Highvoltagerectifierassembly
and High voltage fuse.
2) Hot parts:
Ovenlamp,Magnetron,Highvoltagetransformer
and Oven cavity.
3) Sharp edge:
Bottom plate, Oven cavity, Waveguide flange,
Chassis support and other metallic plate.
4) Movable parts (to prevent a fault)
Fan blade, Fan motor, Switch, Switch lever,
Open button.
3. Donotcatchthewireleadsintheoutercasecabinet.
4. Insert the positive lock connector certainly until its
pin is locked. And make sure that the wire leads
should not come off even if the wire leads is pulled.
5. To prevent an error function, connect the wire leads
correctly, referring to the Pictorial Diagram.

R-490C(S)
5
DOOR REPLACEMENT
REMOVAL
1. Disconnect the power supply cord.
2. Push the open button and open the door slightly.
3. Insertaputtyknife (thickness ofabout0.5mm) into the
gapbetweenthechokecoveranddoorframeasshown
in Figure C-6 to free engaging parts.
4. Prythechokecoverbyinsertingaputtyknifeasshown
Figure C-6.
5. Release choke cover from door panel.
6. Now choke cover is free.
7. Release two (2) pins of door panel from two (2) holes
of upper and lower oven hinges by lifting up.
8. Now, door panel with door frame is free from oven
cavity.
Figure C-6. Door Disassembly
9. Remove the two (2) screws holding the door panel to
the door frame.
10.Release door panel from nine (9) tabs of door frame.
11.Now, door panel with sealer film is free.
12.Tear sealer film from door panel.
13.Now, door panel is free.
14.Slidelatchheadupwardandremoveitfromdoorframe
with releasing latch spring from door frame and latch
head.
15.Now, latch head and latch spring are free.
16.Now, the door frame assembly is free.
NOTE: The door glass can not be exchanged by itself.
Because the door decoration is fixed by the both
sides adhesive tape. The Door frame assembly
should be available as spare part.
RE-INSTALL
1. Re-install the latch spring to the latch head. Re-install
thelatchspringtothedoorframe.Re-installlatchhead
to door frame.
2. Re-install door panel to door frame by fitting nine (9)
tabs of door frame to nine (9) holes of door panel.
3. Hold the door panel to the door frame with the two (2)
screws.
4. Put sealer film on door panel. Refer to “Sealer Film”
about how to handle new one.
5. Catchtwo(2)pinsofdoorpanelontwo(2)holeofupper
and lower oven hinges.
6. Re-install choke cover to door panel by pushing.
Note: After any service to the door;
(A) Makesurethat1st.latchswitch,2nd.latchswitch,
stop switch and monitor switch are operating
properly. (Refer to chapter “Test Procedures”.).
(B) An approved microwave survey meter should be
usedtoassurecompliancewithpropermicrowave
radiation emission limitation standards.
After any service, make sure of the following :
1. Door latch heads smoothly catch latch hook through
latch holes and that latch head goes through center of
latch hole.
2. Deviation of door alignment from horizontal line of
cavity face plate is to be less than 1.0mm.
3. Door is positioned with its face pressed toward cavity
face plate.
4. Check for microwave leakage around door with an
approvedmicrowavesurveymeter. (RefertoMicrowave
Measurement Procedure.)
Note: The door on a microwave oven is designed to act
as an electronic seal preventing the leakage of
microwave energy from oven cavity during cook
cycle. This function does not require that door be
air-tight, moisture (condensation)-tight or light-
tight. Therefore, occasional appearance of
moisture, light or sensing of gentle warm air
movement around oven door is not abnormal and
do not of themselves indicate a leakage of
microwave energy from oven cavity.
Figure C-7. Door Replacement
SEALER FILM
Installation
1. Put the adhesive tape on the backing film of the sealer
film as shown in Fig. C-8.
2. Tear the backing film by pulling the adhesive tape.
3. Putthepasted side ofthesealer film onthedoor panel
Figure C-8. Sealer film
Sealer film Backing film
Adhesive tape
Choke Cover
Door Frame
Putty Knife
Pin
Pin
Upper 
Oven Hinge Upper Oven 
Hinge
Lower Oven
Hinge
Lower 
Oven Hinge
Choke Cover
Door Panel

6
R-490C(S)
mW cm 2
mW cm 2
Microwave leakage measurement at 5 cm distance
SHARP
MICROWAVE MEASUREMENT
After adjustment of door latch switches, monitor switch
and door are completed individually or collectively, the
following leakage test must be performed with a survey
instrument and it must be confirmed that the result meets
the requirements of the performance standard for micro-
wave oven.
REQUIREMENT
Thesafetyswitchmustpreventmicrowaveradiationemis-
sion in excess of 5mW/cm2at any point 5cm or more from
external surface of the oven.
PREPARATION FOR TESTING:
Before beginning the actual test for leakage, proceed as
follows;
1. Makesurethatthetestinstrumentisoperatingnormally
as specified in its instruction booklet.
Important:
Survey instruments that comply with the requirement
forinstrumentationsasprescribedby theperformance
standardformicrowaveovensmustbeusedfortesting.
Recommended instruments are:
NARDA 8100
NARDA 8200
HOLADAY HI 1500
SIMPSON 380M
2. Place the oven tray into the oven cavity.
3. Place the load of 275 ±15ml of water initially at 20
±5˚C in the centre of the oven tray. The water
containershouldbealowformof600mlbeakerwith
inside diameter of approx. 8.5cm and made of an
electrically non-conductive material such as glass
or plastic.
Theplacingofthisstandardloadintheovenisimportant
not only to protect the oven, but also to insure that any
leakage is measured accurately.
4. Closethedoorand turn the oven ONwiththetimer set
for several minutes. If the water begins to boil before
the survey is completed, replace it with 275ml of cool
water.
5. Move the probe slowly (not faster that 2.5cm/sec.)
along the gap.
6. Themicrowaveradiationemissionshouldbemeasured
at any point of 5cm or more from the external surface
of the oven.

R-490C(S)
7
SCHEMATIC
NOTE: CONDITION OF OVEN
1.DOOR CLOSED.
2.CLOCK APPEARS ON DISPLAY. NOTE: " " indicates components with potentials above 250V.
Figure O-1. Oven Schematic-OFF Condition
SCHEMATIC
NOTE: CONDITION OF OVEN
1. DOOR CLOSED.
2. COOKING TIME PROGRAMMED.
3. START KEY TOUCHED.
Figure O-2. Oven Schematic-Cooking Condition
POWER TRANSFORMER
MAGNETRON
H.V. RECTIFIER
H. V. FUSE
0.75A
CAPACITOR
1.13µ
AC2300V
TURNTABLE MOTOR
FAN MOTOR
OVEN LAMP
STOP
SWITCH
MONITOR SWITCH
CONTROL
UNIT
MAGNETRON
TEMPERATURE
FUSE
1ST. LATCH
SWITCH
B1
B2
A2
OL
FM
TTM
N.O.
N.O.
RY-1
COM. COM.
A1
THERMAL
CUT-OUT
145˚C (OVEN)
RY-2
2ND. LATCH 
SWITCH
MONITOR RESISTOR 0.8/20W
EARTH
BLU BRN
230-240V/50Hz
G-Y
FUSE
M10A
NL
LINE CROSS CAPACITOR
0.068µ/AC250V
NOISE SUPPRESSION COIL
LINE BYPASS CAPACITOR 0.0022µ/AC250V
LINE BYPASS CAPACITOR 0.0022µ/AC250V
F1
F2
F3 AH 
SENSOR
POWER TRANSFORMER
MAGNETRON
H.V. RECTIFIER
H. V. FUSE
0.75A
CAPACITOR
1.13µ
AC2300V
TURNTABLE MOTOR
FAN MOTOR
OVEN LAMP
STOP
SWITCH
MONITOR SWITCH
CONTROL
UNIT
MAGNETRON
TEMPERATURE
FUSE
1ST. LATCH
SWITCH
B1
B2
A2
OL
FM
TTM
N.O.
N.O.
RY-1
COM. COM.
A1
THERMAL
CUT-OUT
145˚C (OVEN)
RY-2
2ND. LATCH 
SWITCH
MONITOR RESISTOR 0.8/20W
EARTH
BLU BRN
230-240V/50Hz
G-Y
FUSE
M10A
NL
LINE CROSS CAPACITOR
0.068µ/AC250V
NOISE SUPPRESSION COIL
LINE BYPASS CAPACITOR 0.0022µ/AC250V
LINE BYPASS CAPACITOR 0.0022µ/AC250V
F1
F2
F3 AH 
SENSOR

8
R-490C(S)
6
45
123
6
45
123
A
B
C
D
E
F
G
H
A
B
C
D
E
F
G
H
Figure S-1. Pictorial Diagram
COM.
MONITOR SWITCH
COM.
N.O.
N.C.
1ST.  LATCH SWITCH
2ND.  LATCH SWITCH
STOP SWITCH
(CABINET SIDE)
(OVEN SIDE)
TURNTABLE MOTOR
COM.
N.O.
BLK
GRY
GRY
WHT
GRN
WHT
WHT
BLU
BLK
WHT
WHT WHT
RED
WHT
WHT
THERMAL  CUT-OUT (OVEN)
NOISE FILTER
GRN
GRY
COM.
N.O.
BLK
RED
GRN
ORG
BLK
ORG
RED RED
GRY
2 1CN-A
GRN
GRY
2 1CN-B
BLU
BRN
POWER SUPPLY CORD
EARTH
NEUTRAL
LIVE G
/
Y
N
L
WHT
RED
M10A
CONTROL PANEL
RY1
N.O.
N.O.
COM.
COM.
RY2
CN-A
CN-B
T1
1
1
2
2
(CPU UNIT)
(POWER UNIT)
CN-F
CN-C
CN-G
RED
ORG ORG
W
H
T
OVEN LAMP  AND SOCKET
BLACK  MARK
NOTE: Neutral (WHT) wire must be connected to the terminal with black mark on the oven light socket.
ORGWHT
ORG
RED
MAGNETRON TEMPERATURE FUSE
(OVEN SIDE)
BLK
ORG
MONITOR RESISTOR H.V.RECTIFIER
H.V. FUSE
HIGH VOLTAGE  CAPACITOR
HIGH VOLTAGE COMPONENTS
MAGNETRON
POWER  TRANSFORMER
ORG
BLK
BLU
GRY
BLK AH SENSOR RED
WHT
1 2 3
CN-F

R-490C(S)
9
PARTS LIST
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
*
*
*
*
∆*
*
ELECTRICAL PARTS
1- 1 QFS-TA014WRE0 Temp. fuse 150˚C (MG) 1 AG
1- 2 FPWBFA331WRK0 Noise filter 1 AU
1- 3 QSW-MA131WRE0 1st. latch switch, 2nd. latch switch, Stop switch 3 AG
1- 4 QSW-MA132WRE0 Monitor switch 1 AH
1- 5 RTHM-A075WRE0 Thermal cut-out 145˚C (OVEN) 1 AN
1- 6 QACCAA047WRE0 Power supply cord 1 AP
1- 7 FH-DZA069WRK0 H.V. rectifier assembly 1 AP
1- 7 FH-DZA067WRK0 H.V. rectifier assembly (Interchangeable) 1 AQ
1- 8 RC-QZA258WRE0 High Voltage capacitor 1 AW
1- 9 RMOTEA328WRE0 Fan motor 1 AX
1- 9 RMOTEA342WRE0 Fan motor (Interchangeable) 1 AX
1-10 QFS-CQ001YBE0 Fuse M10A 1 AE
1-11 QSOCLA022WRE0 Oven lamp socket 1 AG
1-12 RLMPTA069WRE0 Oven lamp 1 AK
1-12 RLMPTA029WRE0 Oven lamp (Interchangeable) 1 AL
1-13 RMOTDA173WRE0 Turntable motor 1 AX
1-13 RMOTDA226WRE0 Turntable motor (Interchangeable) 1 AT
1-14 RTRN-A585WRE0 Power transformer 1 BQ
1-15 RV-MZA295WRE0 Magnetron 1 BF
1-16 RR-WZA022WRE0 Monitor resistor 0.8 ohm 20W 1 AK
1-17 FDTCTA179WRK0 AH sensor assembly 1 BA
1-18 QFS-IA002WRE0 H.V. fuse 1 AQ
CABINET PARTS
2- 1 GCABUA732WRP0 Outer case cabinet 1 BF
2- 2 GDAI-A266WRW0 Bottom plate 1 AL
2- 3 GLEGPA074WRE0 Foot 4 AC
CONTROL PANEL PARTS
3- 1 CPWBFA835WRK0 Power unit (New Zealand only) 1 BB
3- 1A QCNCMA446DRE0 2-pin connector(CN-A) 1 AC
3- 1B QCNCMA275DRE0 2-pin connector(CN-B) 1 AB
3- 1C FW-VZA232DRE0 12-pin harness (CN-C) 1 AE
C1 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AA
C2 VCEAB31VW108M Capacitor 1000µF 35V 1 AF
C3 RC-KZA087DRE0 Capacitor 0.1µF 50V 1 AA
C4-5 VCEAB31VW106M Capacitor 10µF 35V 2 AA
D1-4 VHD11ES1///-1 Diode (11ES1) 4 AB
D5-8 VHD1SS270A/-1 Diode (1SS270ATA) 4 AA
Q1-2 VS2SB1238//-3 Transistor (2SB1238) 2 AA
Q3 VSKRC243M//-3 Transistor (KRC243M) 1 AB
R1 VRD-B12EF242J Resistor 2.4k ohm 1/4W 1 AA
R2 VRS-B12HF681J Resistor 680 ohm 1/2W 1 AA
R3 VRD-B12HF511J Resistor 510 ohm 1/2W 1 AB
R4 VRD-B12EF270J Resistor 27 ohm 1/4W 1 AB
R5 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R6 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
RY1 RRLY-A076DRE0 Relay (OMIF-S-124LM) 1 AK
RY2 RRLY-A081DRE0 Relay (VRB24) 1 AL
SP1 RALM-A014DRE0 Buzzer (PKM22EPT-THAI) 1 AG
T1 RTRNPA112DRE0 Transformer 1 AS
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
ZD1 VHEHZ161///-1 Zenor diode (HZ16-1) 1 AA
3- 2 DPWBFB965WRK0 CPU unit 1 BH
3- 3 FPNLCB467WRK0 Control panel frame with key unit 1 BP
3- 3-1 HDECAA205WR10 C/P decoration 1 BF
3- 3-2 JBTN-B091MRF0 Open button 1 AN
3- 3-3 MSPRCA050WRE0 Open button spring 1 AB
3- 4 LHLD-B010MRF0 LCD holder 1 AQ
3- 5 PSHEPA672WRE0 LED sheet 1 AK
3- 6 XEPSD30P08XS0 Screw ; 3mm x 8mm 4 AA
OVEN PARTS
4- 1 PHOK-A095WRF0 Latch hook 1 AN
4- 2 LBNDKA132WRP0 Capacitor holder 1 AD
4- 3 PCOVPA312WRE0 High voltage cover 1 AF
4- 4 NFANJA020WRE0 Fan blade 1 AG
4- 5 FOVN-A387WRT0 Oven cavity 1 BL
∆
∆

10
R-490C(S)
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER
2. REF. NO.
3. PART NO.
4. DESCRIPTION
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
∆
∆
4- 6 LANGTA316WRP0 Chassis support 1 AH
4- 7 MLEVPA194WRF0 Switch lever 1 AG
4- 8 NCPL-A052WRF0 Turntable coupling 1 AF
4- 9 PCOVPA311WRE0 Waveguide cover 1 AG
4-10 PCUSUA191WRP0 Cushion 1 AC
4-11 PDUC-A610WRF0 Fan duct 1 AR
4-12 PDUC-A611WRW0 Magnetron air duct 1 AC
4-13 PPACGA119WRE0 Waterproof packing 1 AC
4-14 PCUSUA410WRP0 Cushion 1 AB
4-15 PCUSUA455WRP0 Cushion 1 AD
4-16 PPACGA073WRE0 Cushion 1 AP
4-17 PCUSUA452WRP0 Cushion 1 AB
4-18 PCUSGA531WRP0 Cushion 1 AF
4-19 PCUSUA237WRP0 Cushion 1 AF
4-20 PSKR-A319WRF0 MG air guide 1 AE
4-21 PSKR-A321WRP0 Air guide 1 AY
4-22 PCUSGA532WRP0 Cushion 1 AF
4-23 PDUC-A661WRP0 AH sensor duct 1 BC
4-24 PCUSGA534WRP0 Cushion 1 AF
DOOR PARTS
5- 1 FDORFA290WRT0 Door panel 1 BA
5- 2 FWAKPA234WRK0 Door frame assembly 1 BQ
5-2-1 HDECAB081MRP0 Door decoration 1 AX
5- 3 LSTPPA139WRF0 Latch head 1 AF
5- 4 MSPRTA084WRE0 Latch spring 1 AD
5- 5 XEPSD30P08XS0 Screw; M3 x 8 2 AA
5- 6 GCOVHA414WR10 Choke cover 1 AM
5- 7 PSHEPA336WRP0 Sealer film 1 AF
MISCELLANEOUS
6- 1 TSPCNC816WRR0 Rating label 1 AC
6- 2 FW-VZB122WRE0 Switch harness 1 AP
6- 3 FW-VZB745WRE0 Main wire harness 1 AU
6- 4 FROLPA092WRK0 Turntable support 1 AE
6- 5 TLABMA539WRR0 Menu label 1 AF
6- 6 PZET-A012WRE0 Terminal insulator 1 AB
6- 7 TCAUHA214WRR0 K caution label 1 AC
6- 8 TINSEA817WRR0 Operation manual 1 AR
6- 9 NTNT-A095WRE0 Turntable tray 1 AX
SCREWS, NUTS AND WASHERS
7- 1 XHTSD40P08RV0 Screw; M4 x 8 11 AA
7- 2 LX-CZ0052WRE0 Special screw 2 AA
7- 3 LX-EZA042WRE0 Special screw 2 AB
7- 4 XHPSD30P06000 Screw; M3 x 6 3 AA
7- 5 XHPSD40P08K00 Screw; M4 x 8 9 AA
7- 6 XHPSD30P08XS0 Screw; M3 x 8 1 AA
7- 7 LX-EZA050WRE0 Special screw; 1 AB
7- 8 XOTSD40P12RV0 Screw; M4 x 12 12 AB
7- 9 XOTSD40P12000 Screw; M4 x 12 2 AA

R-490C(S)
11
6
45
123
6
45
123
A
B
C
D
E
F
G
H
A
B
C
D
E
F
G
H
OVEN AND CABINET PARTS
7-8
7-8
7-8
7-8
2-1
6-9
1-5
4-5
4-23
7-1
4-11
7-1
7-4 7-1
4-6
7-5
1-15
7-1
4-21
7-2
4-9
1-13
7-5 4-1
4-7 1-9
4-4
1-3
1-4
1-3
1-14
1-1
1-11
1-12
7-9
2-3
7-8
2-2
4-15
7-8
2-3
2-3
6-4
6-5
4-8
4-19
7-1 1-7
1-8
7-1
4-16
4-2 4-17
A
A
4-3
1-18
7-5 4-24
4-12 4-18 4-20
4-10
6-7
1-3
1-6
7-7
7-5 1-10
1-2
7-5
7-8 7-1
7-8 7-8
7-1
1-16
4-14
4-13
7-1
7-6
7-3
7-1
7-4
1-17
4-22

12
R-490C(S)
6
45
123
6
45
123
A
B
C
D
E
F
G
H
A
B
C
D
E
F
G
H
CONTROL PANEL PARTS
MISCELLANEOUS
6-2
6-6 Actual wire harness may be different from illustration.
6-3
5-6
5-5
5-5
5-7
5-3
5-1
5-4
5-2-1
5-2
3-1
3-6
3-6
3-6
3-6
3-2
3-3
6-1
3-4
3-5
3-3-3
3-3-2
3-3-1
DOOR PARTS

R-490C(S)
13
6
45
123
6
45
123
A
B
C
D
E
F
G
H
A
B
C
D
E
F
G
H
PACKING AND ACCESSORIES
DOOR PROTECTION SHEET
SPADPA204WRE0
TOP PAD ASSEMBLY
FPADBA317WRK0
PLASTIC BAG
SSAKHA032WRE0
Not replaceable items.
PACKING CASE
SPAKCD305WRE0
BOTTOM PAD ASSEMBLY
FPADBA318WRK0
6-9 TURNTABLE TRAY
6- 8 OPERATION MANUAL
6-4 TURNTABLE SUPPORT
TRAY PACK
SPADFA389WRE0
INTO THE
OVEN CAVITY

14
R-490C(S)
'99SHARP CORP. (09S0.720E) Printed in Australia
