Sharp R930AK - 1.5 CF 900 Watts Convection Sensor Interactive;... User manual

R-930AK
R-930AW
Intheinterestofuser-safetytheovenshouldberestoredtoitsoriginal
condition and only parts identical to those specified should be used.
TABLE OF CONTENTS
CONVECTION
MICROWAVE OVEN
Page
PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICE TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY ...................INSIDE FRONT COVER
BEFORE SERVICING ...........................................................................................................................................1
MICROWAVE MEASUREMENT PROCEDURE ...................................................................................................2
FOREWORD..........................................................................................................................................................3
PRODUCT SPECIFICATIONS ..............................................................................................................................4
GENERAL INFORMATION...................................................................................................................................4
OPERATION..........................................................................................................................................................6
TROUBLESHOOTING GUIDE ............................................................................................................................13
TEST PROCEDURE ............................................................................................................................................14
TOUCH CONTROL PANEL .................................................................................................................................21
COMPONENT REPLACEMENT AND ADJUSTMENT PROCEDURE ................................................................27
PICTORIAL DIAGRAM ........................................................................................................................................33
CONTROL PANEL CIRCUIT ...............................................................................................................................34
PRINTED WIRING BOARD .................................................................................................................................35
PARTS LIST ........................................................................................................................................................36
PACKING AND ACCESSORIES .........................................................................................................................39
R-930AK
R-930AW
S6710R930APW/
MODELS
R-930AW
SERVICE MANUAL
SHARP ELECTRONICS CORPORATION
Service Headquarters: Sharp Plaza, Mahwah, New Jersey 07430-2135
MIXCONV
DEFROST
SENSOR COOK LBS OZ KG HELP
Interactive
Convection
CUSTOM
HELP
MINUTE
PLUS
COMPU
DEFROST
SENSOR
COOKT
COMPU
BROIL
COMPU
ROAST
COMPU
BAKE
PREHEAT CONVEC BROIL
SLOW
COOK
KITCHEN
TIMER
POWER
LEVEL
STOP
TCLEAR
START
TOUCHON
CLOCK
LOWMIX
BAKE HIGHMIX

ROAST
POPCORN
ELEVATEPKG
SENSOR
REHEAT
12345
1 Baked potatoes
2 Frozen vegetables
3 Fresh veg-soft
4 Fresh veg-hard
5 Frozen entrees
6 Hot dogs
7 Bacon
8 Fish, seafood
1 Hamburgers
2 Chicken pieces
3 Steaks
4 Fish steaks
1 Chicken
2 Turkey
3 Turkey breast
4 Pork
1 Bundt cake
2 Cookies
3 Muffins
4 French fries
100˚F 150˚F 275˚F 300˚F 325˚F
67890
350˚F 375˚F 400˚F 425˚F 150˚F
SMART& EASY
CONVECTION

R-930AK
R-930AW
PRECAUTIONSTO BE OBSERVED BEFORE AND
DURING SERVICINGTO AVOID POSSIBLE
EXPOSURETO EXCESSIVE MICROWAVE
ENERGY
(a) Do not operate or allow the oven to be operated with the door open.
(b) Make the following safety checks on all ovens to be serviced before activating the magnetron or other
microwave source, and make repairs as necessary: (1) interlock operation, (2) proper door closing, (3)
seal and sealing surfaces (arcing, wear, and other damage), (4) damage to or loosening of hinges and
latches, (5) evidence of dropping or abuse.
(c) Before turning on microwave power for any service test or inspection within the microwave generating
compartments, check the magnetron, wave guide or transmission line, and cavity for proper alignment,
integrity, and connections.
(d) Any defective or misadjusted components in the interlock, monitor, door seal, and microwave
generation and transmission systems shall be repaired, replaced, or adjusted by procedures described
in this manual before the oven is released to the owner.
(e) A microwave leakage check to verify compliance with the Federal Performance Standard should be
performed on each oven prior to release to the owner.

1
R-930AK
R-930AW
BEFORE SERVICING
Before servicing an operative unit, perform a microwave emission check as per the Microwave
Measurement Procedure outlined in this service manual.
If microwave emissions level is in excess of the specified limit, contact SHARP ELECTRONICS
CORPORATION immediately 1- [phone].
If the unit operates with the door open, service person should 1) tell the user not to operate the oven
and 2) contact SHARP ELECTRONICS CORPORATION and Food and Drug Administration's
Center for Devices and Radiological Health immediately.
ServicepersonnelshouldinformSHARPELECTRONICSCORPORATIONofanycertifiedunitfound
with emissions in excess of 4mW/cm2. The owner of the unit should be instructed not to use the unit
until the oven has been brought into compliance.

2
R-930AK
R-930AW
MICROWAVE MEASUREMENT PROCEDURE
A. Requirements:
1) Microwave leakage limit (Power density limit): The power density of microwave radiation emitted by a microwave oven
shouldnotexceed1mW/cm2atanypoint5cmormorefromtheexternalsurfaceoftheoven,measuredpriortoacquisition
bya purchaser,and thereafter(throughthe usefullifeof theoven),5 mW/cm2atany point5cm ormorefrom theexternal
surface of the oven.
2) Safety interlock switches
Primaryinterlockrelayanddoorsensingswitchshallpreventmicrowaveradiationemissioninexcessoftherequirement
as above mentioned, secondary interlock switch shall prevent microwave radiation emission in excess of 5 mW/cm2at
any point 5cm or more from the external surface of the oven.
B. Preparation for testing:
Before beginning the actual measurement of leakage, proceed as follows:
1) Make sure that the actual instrument is operating normally as specified in its instruction booklet.
Important:
Surveyinstruments thatcomply withthe requirementfor instrumentationas prescribedby the performancestandard
for microwave ovens, 21 CFR 1030.10(c)(3)(i), must be used for testing.
2) Place the oven tray in the oven cavity.
3) Place the load of 275±15 ml (9.8 oz) of tap water initially at 20±5˚C (68˚F) in the center of the oven cavity.
The water container shall be a low form of 600 ml (20 oz) beaker with an inside diameter of approx. 8.5 cm (3-1/2 in.)
and made of an electrically nonconductive material such as glass or plastic.
Theplacingofthisstandardloadintheovenisimportantnotonlytoprotecttheoven,butalsotoinsurethatanyleakage
is measured accurately.
4) Set the cooking control on Full Power Cooking Mode
5) Close the door and select a cook cycle of several minutes. If the water begins to boil before the survey is completed,
replace it with 275 ml of cool water.
C. Leakage test:
Closed-door leakage test (microwave measurement)
1) Grasptheprobeofthesurveyinstrumentandholditperpendiculartothegapbetweenthedoorandthebodyoftheoven.
2) Move the probe slowly, not faster than 1 in./sec. (2.5 cm/sec.) along the gap, watching for the maximum indication on
the meter.
3) Checkforleakageatthedoorscreen,sheetmetalseamsandotheraccessiblepositionswherethecontinuityofthemetal
has been breached (eg., around the switches, indicator, and vents).
Whiletestingforleakagearoundthedoorpullthedoorawayfromthefrontoftheovenasfarasispermittedbytheclosed
latch assembly.
4) Measure carefully at the point of highest leakage and make sure that the highest leakage is no greater than 4mW/cm2,
and that the secondary interlock switch does turn the oven OFF before any door movement.
NOTE: After servicing, record data on service invoice and microwave leakage report.

3
R-930AK
R-930AW
SERVICE MANUAL
CONVECTION
MICROWAVE OVEN
R-930AK / R-930AW
FOREWORD
This Manual has been prepared to provide Sharp Electronics
Corp. Service Personnel with Operation and Service Informa-
tion for the SHARP CONVECTION MICROWAVE OVENS R-
930AK / R-930AW.
It is recommended that service personnel carefully study the
entire text of this manual so that they will be qualified to render
satisfactory customer service.
Check the interlock switches and the door seal carefully.
Special attention should be given to avoid electrical shock and
microwave radiation hazard.
SHARP ELECTRONICS CORPORATION
SHARP PLAZA, MAHWAH,
NEW JERSEY 07430-2135
PRODUCT DESCRIPTION
GENERAL INFORMATION
OPERATION
TROUBLESHOOTING GUIDE
AND TEST PROCEDURE
TOUCH CONTROL PANEL
COMPONENT REPLACEMENT AND
ADJUSTMENT PROCEDURE
WIRING DIAGRAM
PARTS LIST

4
R-930AK
R-930AW
SPECIFICATION
ITEM DESCRIPTION
Power Requirements 120 Volts
13.0 Amperes (Microwave) / 13.0 Amperes (Convection)
60 Hertz / Single phase, 3 wire grounded
Power Output 900 watts (IEC 705 Test Procedure)
Operating frequency of 2450MHz
Convection Power Output 1450 Watts
Case Dimensions Width 24-5/8" Height 14-7/8" Depth 19-1/8"
Cooking Cavity Dimensions
(1.5 Cubic Feet ) Width 16-1/8" Height 9-5/8" Depth 16-1/8"
Control Complement Touch Control System
Timer (0 - 99 min. 99 seconds)
Microwave Power for Variable Cooking
Repetition Rate;
P-HI...........................................Full power throughout the cooking time
P-90 .............................................................approx. 90% of Full Power
P-80 .............................................................approx. 80% of Full Power
P-70 .............................................................approx. 70% of Full Power
P-60 .............................................................approx. 60% of Full Power
P-50 .............................................................approx. 50% of Full Power
P-40 ..............................................................approx. 40% of Full Power
P-30 ..............................................................approx. 30% of Full Power
P-20 .............................................................approx. 20% of Full Power
P-10 ..............................................................approx. 10% of Full Power
P-0 ............................................. No power throughout the cooking time
Convection Temperature for Variable Cooking
CONVECTION.............................................. 100 - 450˚F Temp. control
LOW MIX. BAKE...............................350˚F with 10% microwave power
HIGH MIX. ROAST...........................300˚F with 30% microwave power
SLOW COOK..........................................300˚F for 4 hours (no preheat)
BROIL............................................................................450˚F (preheat)
CUSTOM HELP pad, SENSOR REHEAT pad, MINUTE PLUS pad, POPCORN pad
COMPU DEFROST pad, SENSOR COOK pad, COMPU BROIL pad
COMPU ROAST pad, COMPU BAKE pad, REHEAT pad, CONVEC pad
BROIL pad, SLOW COOK pad, HIGH MIX / ROAST pad, LOW MIX / BAKE pad
Number and temperature selection pads, KITCHEN TIMER pad, CLOCK pad
STOP/CLEAR pad, POWER LEVEL pad, START / TOUCH ON pad
Oven Cavity Light Yes
Safety Standard UL Listed FCC Authorized
DHHS Rules, CFR, Title 21, Chapter 1, Subchapter J
GENERAL INFORMATION
GROUNDING INSTRUCTIONS
This oven is equipped with a three prong grounding plug. It must be plugged into a wall receptacle that is properly installed
and grounded in accordance with the National Electrical Code and local codes and ordinances.
In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the
electric current.
WARNING: Improper use of the grounding plug can result in a risk of electric shock.

5
R-930AK
R-930AW
Electrical Requirements
The electrical requirements are a 115 -120 volt 60 Hz, AC only,
15or20amp.fusedelectricalsupply.Itisrecommendedthataseparate
circuit serving only this appliance be provided. When installing this
appliance, observe all applicable codes and ordinances.
A short power-supply cord is provided to reduce risks of becoming
entangled in or tripping over a longer cord.
Where a two-pronged wall-receptacle is encountered, it is the personal
responsibility and obligation of the customer to contact a qualified
electricianandhaveitreplacedwithaproperlygroundedthree-pronged
wall receptacle or have a grounding adapter properly grounded and
polarized. If an extension cord must be used, it should be a 3-wire, 15
amp.ormore cord.Donotdrape overacountertop ortable whereit can
be pulled on by children or tripped over accidentally.
3-Pronged Plug Grounded
Receptacle Box
Grounding Pin
3-Pronged Receptacle
CAUTION: DO NOT UNDER ANY CIRCUMSTANCES CUT OR REMOVE THE ROUND GROUNDING PRONG FROM
THIS PLUG. OVEN DIAGRAM
1. Ventilation openings. (Rear side)
2. Oven door with see-through window.
3. Oven lamp.
4. Turntable support.
5. Removable turntable.
The turntable will rotate clockwise or
counterclockwise.
6. Safety door latches.
The oven will not operate unless the door is
securely closed.
TOUCH CONTROL PANEL
MIX CONV
DEFROST
SENSOR
COOK LBS OZ KG HELP
7. Wave guide cover.
8. Door open button.
9. Auto-Touch control panel.
10. Lighted digital display.
11. Convection air openings.
12. Removable low rack. (Broiling trivet)
13. Removable low rack. (Baking rack)
14. Turntable motor shaft.
15. Power supply cord.

173
10
9
8
2
5
4
12
13
14
15
11 6
6
Interactive
Convection
CUSTOM
HELP
MINUTE
PLUS
COMPU
DEFROST
SENSOR
COOKT
COMPU
BROIL
COMPU
ROAST
COMPU
BAKE
PREHEAT CONVEC BROIL
SLOW
COOK
KITCHEN
TIMER
POWER
LEVEL
STOP
TCLEAR
START
TOUCHON
CLOCK
LOWMIX
BAKE HIGHMIX

ROAST
POPCORN
ELEVATEPKG
SENSOR
REHEAT
12345
1 Baked potatoes
2 Frozen vegetables
3 Fresh veg-soft
4 Fresh veg-hard
5 Frozen entrees
6 Hot dogs
7 Bacon
8 Fish, seafood
1 Hamburgers
2 Chicken pieces
3 Steaks
4 Fish steaks
1 Chicken
2 Turkey
3 Turkey breast
4 Pork
1 Bundt cake
2 Cookies
3 Muffins
4 French fries
100˚F 150˚F 275˚F 300˚F 325˚F
67890
350˚F 375˚F 400˚F 425˚F 150˚F

6
R-930AK
R-930AW
OPERATION
DESCRIPTION OF OPERATING SEQUENCE
Thefollowingisadescriptionofcomponentfunctionsduring
oven operation.
OFF CONDITION
Closing the door activates the door sensing switch and
secondary interlock switch. (In this condition, the monitor
switch contacts are opened.)
When oven is plugged in, 120 volts A.C. is supplied to the
control unit. (Figure O-1).
1. The display will show "SHARP SIMPLY THE BEST
PRESS CLEAR AND PRESS CLOCK".
Toset anyprogram orset theclock, youmust firsttouch
the STOP/CLEAR pad. The display will clear, and " : "
will appear.
NOTE:When thedoor isopened, theoven lampcomes on.
2. A signal is input to the control unit, energizing the coil of
shut-off relay (RY-4). RY4 contacts close, completing a
circuit to the damper motor. The damper motor now
operatesmovingthedampertotheopenposition,thereby
closingthecontactsofthe damperswitchinputsasignal
tothecontrolunit. ThecoilofrelayRY-4isde-energized,
opening its contacts, thereby turning off the damper
motor.
COOKING CONDITION
Programdesired cookingtime VariableCooking Controlby
touchingtheNUMBERpadsandthepowerlevelpad.When
the START pad is touched, the following operations occur:
1. The contacts of relays are closed and components
connected to the relays are turned on as follows.
(For details, refer to Figure O-2)
RELAY CONNECTED COMPONENTS
RY-1 Oven lamp/Turntable motor
RY-2 Power transformer
RY-3 Heating element
RY-4 Damper motor
RY-5 Convevtion motor
RY-6 Fan motor
2. 120 volts A.C. is supplied to the primary winding of the
powertransformerandisconvertedtoabout3voltsA.C.
output on the filament winding, and approximately 2360
volts A.C. on the high voltage winding.
3. The filament winding voltage heats the magnetron
filamentandtheH.V.windingvoltageissenttoavoltage
doubler circuit.
4. The microwave energy produced by the magnetron is
channelled through the waveguide into the cavity feed-
box, and then into the cavity where the food is placed to
be cooked.
5. Upon completion of the cooking time, the power
transformer, oven lamp, etc. are turned off, and the
generation of microwave energy is stopped. The oven
will revert to the OFF condition.
6. When the door is opened during a cook cycle, monitor
switch, door sensing switch, the primary interlock relay
andthesecondaryinterlockswitchareactivatedwiththe
following results. The circuits to the turntable motor, the
coolingfan motor,and thehigh voltagecomponents are
de-energized,the ovenlamp remainson, andthe digital
read-out displays the time still remaining in the cook
cycle when the door was opened.
7. Themonitorswitchiselectricallymonitoringtheoperation
of theprimaryinterlockrelayandthesecondaryinterlock
switch and is mechanically associated with the door so
that it will function in the following sequence.
(1)Whenthedooropensfromaclosedposition,theprimary
interlock relay and the secondary interlock switch open
their contacts, and then the monitor switch contacts
close.
(2)When the door is closed from the open position, the
monitorswitchcontactsfirstopen,andthenthecontacts
oftheprimaryinterlockrelayandthesecondaryinterlock
switch close.
If the primary interlock relay and the secondary interlock
switch fail with their contacts closed when the door is
opened, the closing of the monitor switch contacts will form
a short circuit through the monitor fuse, primary interlock
relayandthe secondaryinterlock switch,causingthemoni-
tor fuse to blow.
POWER LEVEL P-0 TO P-90 COOKING
When Variable Cooking Power is programmed, the 120
voltsA.C.issuppliedtothepowertransformerintermittently
through the contacts of relay (RY-2). RY-2 is operated by
the control unit within an varying time base. Microwave
power operation is as follows:
VARI-MODE ON TIME OFF TIME
Power 10(P-HI) 32 sec. 0 sec.
(100% power)
Power 9(P-90) 30 sec. 2 sec.
(approx. 90% power)
Power 8(P-80) 26 sec. 6 sec.
(approx. 80% power)
Power 7(P-70) 24 sec. 8 sec.
(approx. 70% power)
Power 6(P-60) 22 sec. 10 sec.
(approx. 60% power)
Power 5(P-50) 18 sec. 14 sec.
(approx. 50% power)
Power 4(P-40) 16 sec. 16 sec.
(approx. 40% power)
Power 3(P-30) 12 sec. 20 sec.
(approx. 30% power)
Power 2(P-20) 8 sec. 24 sec.
(approx. 20% power)
Power 1(P-10) 6 sec. 26 sec.
(approx. 10% power)
Power 0(P-0) 0 sec. 32 sec.
(0% power)
Note: The ON/OFF time ratio does not correspond with
the percentage of microwave power, because
approx. 2 seconds are needed for heating of the
magnetron filament.

7
R-930AK
R-930AW
CONVECTION COOKING CONDITION
PREHEATING CONDITION
Program desired convection temperature by touching the
CONVECTION pad and the Temperature pad.
When the START pad is touched, the following operations
occur:
1. The coil of shut-off relays (RY1, RY3,RY5 and RY6) are
energized, the oven lamp, cooling fan motor, turntable
motor and convection motor are turned on.
2. The coil of relay (RY4) is energized by the control unit.
Thedamperismovedtotheclosedposition,openingthe
damper switch contacts. The opening of the damper
switch contacts sends a signal to the LSI on the control
unit de-energizing the relay (RY4) and opening the
circuit to the damper motor.
3. Thecoilofheaterrelay(RY3)isenergizedbythecontrol
unitandthemainsupplyvoltageisappliedtotheheating
element.
4. Whentheoventemperaturereachestheselectedpreheat
temperature, the following operations occur:
4-1 The heater relay is de-energized by the control unit
temperature circuit and thermistor, opening the
circuit to the heating element.
4-2. The oven will continue to function for 30 minutes,
turningtheheateronandoff,asneededtomaintain
the selected preheat temperature. The oven will
shut-down completely after 30 minutes
CONVECTION COOKING CONDITION
Whenthepreheattemperatureisreached,abeepsignalwill
sound indicating that the holding temperature has been
reached in the oven cavity. Open the door and place the
food to be cooked in the oven.
Touch the CONVEC pad first and then touch the Tempera-
turepad.Andprogramdesiredcookingtimebytouchingthe
Number pads.
When the START pad is touched, the following operations
occur:
1. Thenumbers onthe digitalread-out starttocount down
to zero.
2. The oven lamp, turntable motor, cooling fan motor and
convection motor are energized.
3. Heaterrelay(RY3)isenergized(ifthecavitytemperature
is lower than the selected temperature) and the main
supplyvoltageisappliedtotheheatingelementtoreturn
to the selected cooking temperature.
4. Uponcompletion ofthecooking time,the audiblesignal
will sound, and oven lamp, turntable motor, cooling fan
motor and convection motor are de-energized. At the
end of the convection cycle, if the cavity air temperature
is above 275˚F, the circuit to RY6 will be maintained (by
thethermistorcircuit)tocontinueoperationofthecooling
fan motor until the temperature drops below 245˚F, at
which time the relay will be de-energized, turning off the
fanmotor. RelayRY5 willhowever, openassoon asthe
convection cycle has ended, turning off the convection
fan motor.
5. At the end of the convection cook cycle, shut-off relay
(RY4) is energized turning on the damper motor. The
damper is returned to the open position, closing the
damper switch contacts which send a signal to the
control unit, de-energizing shut-off relay (RY4).
AUTOMATIC MIX COOKING CONDITION
Touch the HIGH MIX/ROAST or the LOW MIX/BAKE pad
first.Andthenprogramdesiredcookingtimebytouchingthe
Numberpads.TheLOWMIX/BAKEpadispreprogrammed
for 350˚F with 10% microwave power, while the HIGH MIX/
ROAST pad is preprogrammed for 300˚F with 30% micro-
wavepower.WhentheSTARTpadistouched,thefollowing
operations occur:
1. The numbers on the digital read-out start to count down
to zero.
2. The shut-off relays (RY1,RY2,RY3,RY5 and RY6) are
energized, turning on the oven lamp, turntable motor,
cooling fan motor and convection fan motor.
3. The shut-off relay (RY4) is energized.
The damper door is closed from the open position.
4. The heater relay (RY3) is energized, applying the main
supply voltage to the heating element.
5. Now, the oven is in the convection cooking condition.
6. When the oven temperature reaches the selected
temperature, the following operations occur:
6-1. Thepowersupplyvoltageisalternatedtotheheating
element and power transformer.
6-2. The heating element operates through the heater
relay (RY3) contacts and the power transformer
operates through the primary interlock relay (RY2)
contacts.
6-3. These are operated by the control unit to supply
alternatelywithina32secondtimebase,convection
heat and microwave energy.
The relationship between the convection and microwave
power operations are as follows.
Note: The ON and OFF time ratio does not correspond
with the percentage of microwave power, because
approx. 2 seconds are needed for heating of the
magnetron filament.
12 SEC. 20 SEC.
32 SEC.
LOW MIX
BAKE
HIGH MIX
ROAST
MICROWAVE POWER
= APPROX. 30%
CONVECTION
TEMPERATUE
= 300˚F
MICROWAVE POWER
= APPROX. 10%
CONVECTION
TEMPERATUE
= 350˚F (180˚C)
26 SEC.6 SEC.
ON
ON
OFF
OFF
OFF
ON
(MICRO.)
(CONVEC.)
(MICRO.)
(CONVEC.)
Note: During alternate Microwave/Convection operation,
the convection heater is energized only if the cavity
temperature drops below the set temperature.
SENSOR COOKING CONDITION
Using the SENSOR COOK function, the foods are cooked
withoutfiguringtime,powerlevelorquantity.Whentheoven
senses enough steam from the food, it relays the informa-
tiontoits microprocessorwhichwillcalculate theremaining
cooking time and power level needed for best results.
When the food is cooked, water vapor is developed.

8
R-930AK
R-930AW
Thesensor“senses” thevapor anditsresistanceincreases
gradually. When the resistance reaches the value set ac-
cording to the menu, supplementary cooking is started.
Thetimeofsupplementarycookingisdeterminedbyexperi-
ment with each food category and inputted into the LSI.
An example of how sensor works:
1. Potatoesatroomtemperature.
Vapor is emitted very slowly.
2. Heat potatoes. Moisture and
humidity is emitted rapidly.
Youcan smell thearoma asit
cooks.
3. Sensor detects moisture and
humidity and calculates
cooking time and variable
power.
Cooking Sequence.
1. Touch SENSOR COOK pad.
NOTE: The oven should not be operated on SENSOR
COOK immediately after plugging in the unit. Wait
two minutes before cooking on SENSOR COOK.
2. Select desired Sensor setting.
3. Touch START pad.
The coil of shut-off relay (RY1, RY6) is energized, the
oven lamp and cooling fan motor are turned on, but the
power transformer is not turned on.
4. After about 16 seconds, the cook relay (RY-2) is
energized. The power transformer is turned on,
microwaveenergy isproduced andfirststage isstarted.
The 16 seconds is the cooling time required to remove
any vapor from the oven cavity and sensor.
NOTE: Duringthisfirststage,donotopenthedoorortouch
STOP/CLEAR pad.
5. When the sensor detects the vapor emitted from the
food,thedisplayswitches overto theremainingcooking
time and the timer counts down to zero. At this time, the
door may be opened to stir food, turn it or season, etc.
6. Whenthe timerreaches zero,an audiblesignal sounds.
The shut-off relay and cook relay are de-energized and
the power transformer, oven lamp, etc. are turned off.
7. OpeningthedoorortouchingtheSTOP/CLEARpad,the
timeofday willreappear onthedisplayand theoven will
revert to an OFF condition.
COMPU BROIL/ COMPU ROAST/ COMPU BAKE
COMPUBROIL/ROAST/BAKEwillautomaticallycompute
the oven temperature, microwave power and cooking time
forbaking,roastingandbroiling.Setthedesiredprogramby
touching the COMPU BROIL/ ROAST/ BAKE pad, and
numberpad.EntertheweightbytouchingtheNumberpads.
When the START pad is touched, the following operations
occur:
1. The COOK indicator will light and the Convection Fan
Symbol will rotate.
2. The cooking time will appear on the display and start
counting down to zero. The cooking time is adjusted
automatically according to the weight of the food.
3. The shut-off relays (RY1, RY5 and RY6) are energized,
turning on the oven lamp, turntable motor, cooling fan
motor and convection motor. The power supply voltage
is applied to the heating element.
4. Now, the oven is in the convection cooking mode.
5. Whentheoventemperaturehasreachedtheprogrammed
convection temperature, the oven goes into the
programmed cooking mode.
6. At the end of the COMPU BROIL/ ROAST/ BAKE cycle,
thedamperisreturnedtotheopenpositionandtheoven
willgoto theoff condition.Thecoolingfan willremain on
until the oven has cooled.
COMPU DEFROST COOKING
The COMPU DEFROST key is a special function key to
defrost meats and poultry faster and better. COMPU DE-
FROST automatically defrosts roast beef, etc.. When the
COMPU DEFROST is selected and the food weight is
entered by using the COMPU DEFROST pad, the oven will
cook according to the special cooking sequence.
FIRE SENSING FEATURE (MICROWAVE MODE)
This model incorporates a sensing feature which will stop
theoven'soperationifthereisafireintheovencavityduring
microwave cooking.
This is accomplished by the LSI repeatedly measuring the
voltage across the temperature measurement circuit (ther-
mistor) during it's 32-seconds time base comparing the
obtainedvoltagemeasurements.Ifthemostrecent voltage
measured is 300mV greater than the previous voltage
measured, the LSI judges it as a fire in the oven cavity and
switches off the relays to the power transformer, fan motor
and convection motor. The LSI also stops counting down
andclosesthedamperdoorsothatnofreshairwillenterthe
oven cavity. Please refer to the following section for a more
detailed description.
Operation
Please refer to the timing diagrams below.
1. The thermistor operates within a 32-seconds time base
and it is energized for three (3) seconds and off for 29
seconds. Two (2) seconds after the thermistor is
energized, the voltage across the temperature
measurement circuit is sampled by the LSI and twenty
one (21) seconds after the thermistor is cut off the LSI
turns on the cooling fan for six (6) seconds.
2. The above procedure is repeated. If the difference
between the first voltage measured (in step 1) and the
voltagemeasuredwhentheprocedureisrepeated(step
2) is greater than 300mV the LSI makes the judgment
thatthereisafireintheovencavityandwillswitchoffthe
relaystothepowertransformer,fanmotorandconvection
motor.TheLSI alsostops countingdownandcloses the
damper door so that no fresh air will enter the oven
cavity.
3. Once the fire sensor feature has shut the unit down, the
programmedcookingcyclemayberesumedby pressing
the"START"padortheunitmayberesetbypressingthe
"CLEAR" pad.
MICROWAVE
MICROWAVE
AH SENSOR
CONVECTION
MOTOR
THERMISTOR
Sensing 
Voltage
ON
OFF
ON
OFF
ON
OFF
0 2 24 30 64 (sec.)
3 sec.
Sensing the voltage across the temperature measurement circuit.
6 sec.
332 (sec.)

9
R-930AK
R-930AW
Figure O-2. Oven Schematic-Microwave Cooking Condition
IMPORTANT:
During sensor cooking operation, the fire sensing op-
erationsequencewillnotbegin until the AH sensor has
SCHEMATIC
1. DOOR CLOSED.
2. COOKING TIME PROGRAMMED.
3. “START” PAD TOUCHED.
Figure O-1. Oven Schematic-OFF Condition
SCHEMATIC
NOTE: CONDITION OF OVEN
1. DOOR CLOSED.
2. CLOCK APPEARS ON DISPLAY.
detected vapors and initiated a sensor cooking cycle.
This is because the operation of the convection fan
would interfere with the AH sensor's vapor detection.
SCHEMATIC DIAGRAM
CONV.
THERMAL
CUT-OUT
MONITOR SWITCH
OVEN LAMP
FAN MOTOR
A-5
A-3
A-1
E-6
CONTROL UNIT
DAMPER
SWITCH
THER-
MISTOR
DOOR
SENSING
SWITCH
AH SENSOR
DAMPER MOTOR
CONVECTION MOTOR
TURNTABLE MOTOR
HEATIMG ELEMENT
MAGNETRON
POWER 
TRANSFORMER
H.V. RECTIFIER
CAPACITOR
0.94µ
RY4 RY5
RY6
RY1
SECONDARY
INTERLOCK
SWITCH
OUTER
CASE
SWITCH
OUTER
CASE
SWITCH
120V
60Hz
TTM
FM
COM.
(RY1)
E-5E-4E-3E-2E-1F-3F-2F-1
RY3
RY2
PRIMARY 
INTERLOCK
RERAY
N.O.
(RY1)
COM.
(RY3)
COM.
(RY2)
N.O.
(RY2)
N.O.
(RY3)
A-9
A-7
CM DM
OL
MAGNETRON 
TEMPERATURE
FUSE
FUSE
RY2
CONV.
THERMAL
CUT-OUT
MONITOR SWITCH
OVEN LAMP
FAN MOTOR
A-5
A-3
A-1
E-6
CONTROL UNIT
DAMPER
SWITCH
THER-
MISTOR
DOOR
SENSING
SWITCH
AH SENSOR
DAMPER MOTOR
CONVECTION MOTOR
TURNTABLE MOTOR
HEATIMG ELEMENT
MAGNETRON
POWER 
TRANSFORMER
H.V. RECTIFIER
CAPACITOR
0.94µ
RY4 RY5
RY6
RY1
SECONDARY
INTERLOCK
SWITCH
OUTER
CASE
SWITCH
OUTER
CASE
SWITCH
120V
60Hz
TTM
FM
COM.
(RY1)
E-5E-4E-3E-2E-1F-3F-2F-1
RY3
RY2
PRIMARY 
INTERLOCK
RERAY
N.O.
(RY1)
COM.
(RY3)
COM.
(RY2)
N.O.
(RY2)
N.O.
(RY3)
A-9
A-7
CM DM
OL
MAGNETRON 
TEMPERATURE
FUSE
FUSE
RY2

10
R-930AK
R-930AW
SCHEMATIC
1. DOOR CLOSED.
2. CONVECTION PAD TOUCHED.
3. DESIRED TEMP. TOUCHED.
4. COOKINGTIMEPROGRAMMED.
5. “START” PAD TOUCHED.
SCHEMATIC
1. DOOR CLOSED.
2. MIX COOKING PAD TOUCHED.
3. COOKING TIME PROGRAMMED.
4. “START” PAD TOUCHED.
5. RY2 AND RY3 WILL ALTERNATELY CLOSE.
DURING COOK CYCLE.
Figure O-4. Oven Schematic-Convection Cooking Condition
Figure O-3. Oven Schematic-Automatic Mix Cooking Condition
CONV.
THERMAL
CUT-OUT
MONITOR SWITCH
OVEN LAMP
FAN MOTOR
A-5
A-3
A-1
E-6
CONTROL UNIT
DAMPER
SWITCH
THER-
MISTOR
DOOR
SENSING
SWITCH
AH SENSOR
DAMPER MOTOR
CONVECTION MOTOR
TURNTABLE MOTOR
HEATIMG ELEMENT
MAGNETRON
POWER 
TRANSFORMER
H.V. RECTIFIER
CAPACITOR
0.94µ
RY4 RY5
RY6
RY1
SECONDARY
INTERLOCK
SWITCH
OUTER
CASE
SWITCH
OUTER
CASE
SWITCH
120V
60Hz
TTM
FM
COM.
(RY1)
E-5E-4E-3E-2E-1F-3F-2F-1
RY3
RY2
PRIMARY 
INTERLOCK
RERAY
N.O.
(RY1)
COM.
(RY3)
COM.
(RY2)
N.O.
(RY2)
N.O.
(RY3)
A-9
A-7
CM DM
OL
MAGNETRON 
TEMPERATURE
FUSE
FUSE
RY2
CONV.
THERMAL
CUT-OUT
MONITOR SWITCH
OVEN LAMP
FAN MOTOR
A-5
A-3
A-1
E-6
CONTROL UNIT
DAMPER
SWITCH
THER-
MISTOR
DOOR
SENSING
SWITCH
AH SENSOR
DAMPER MOTOR
CONVECTION MOTOR
TURNTABLE MOTOR
HEATIMG ELEMENT
MAGNETRON
POWER 
TRANSFORMER
H.V. RECTIFIER
CAPACITOR
0.94µ
RY4 RY5
RY6
RY1
SECONDARY
INTERLOCK
SWITCH
OUTER
CASE
SWITCH
OUTER
CASE
SWITCH
120V
60Hz
TTM
FM
COM.
(RY1)
E-5E-4E-3E-2E-1F-3F-2F-1
RY3
RY2
PRIMARY 
INTERLOCK
RERAY
N.O.
(RY1)
COM.
(RY3)
COM.
(RY2)
N.O.
(RY2)
N.O.
(RY3)
A-9
A-7
CM DM
OL
MAGNETRON 
TEMPERATURE
FUSE
FUSE
RY2

11
R-930AK
R-930AW
OUTER CASE SWITCHES
The two outer case switches are mounted near the power
supply cord at the oven cavity rear plate. When the outer
case cabinet is installed with the screws, one of the screws
pushes the actuator and then the actuator pushes each
plungers of the two outer case switches and their contacts
are closed. When a cabinet mounting screw which is push-
ing the actuator is removed, the two outer case switches
interrupt the circuit to the all components.
WARNING
The circuit to all components can be connected to the
power supply without the outer case cabinet by reinstall-
ing the cabinet mounting screw. BUT AT THAT TIME,
NEVERTOUCHANYPARTS OFTHEHIGHVOLTAGE
CIRCUIT TO AVOID ELECTROCUTION.
OUTER CASE 
CABINET
OUTER CASE
SWITCHES
ACTUATOR
This outer case mounting screw is
pushing the actuator.
THERMISTOR
The thermistor is a negative temperature coefficient type.
The temperature in the oven cavity is detected through the
resistance of the thermistor, and then the control unit
causes the heater relay to operate, thus the current to the
heating element is turned ON/OFF.
MAGNETRON TEMPERATURE FUSE.
Thetemperaturefuselocatedonthewaveguideisdesigned
to prevent damage to the magnetron if an over heated
condition develops in the megnetron due to cooling fan
failure, obstructed air guide, dirty or blocked air intake, etc.
Under normal operation, the temperature fuse remains
closed. However, when abnormally high temperatures are
reached within the magnetron, the temperature fuse will
open at 302˚F(150˚C) causing the oven to shut down.
CONV. THERMAL CUT-OUT
The thermal cut-out located on the left side of the thermal
protection plate (left) is designed to prevent damage to the
heater unit if an over heated condition develops in the
heatingunitduetoconvectionfanfailure,thermistor failure,
obstructed air ducts, dirty or blocked air intake, etc.
Undernormaloperation,thethermalcut-outremainsclosed.
However,whenabnormally hightemperaturesarereached
within the heater unit, the thermal cut-out will open at
302˚F(150˚C) causing the oven to shut down.
When the thermal cut-out has cooled, the thermal cut-out
closes at 266˚F(130˚C).
DOOR SENSING AND SECONDARY INTERLOCK
SWITCHES
The door sensing switch in the primary interlock system is
mounted in the upper position on the latch hook, the
secondary interlock switch is mounted in the lower position
on the latch hook. They are activated by the latch heads on
the door. When the door is opened, the switches interrupt
thecircuittoallcomponents.Acookcyclecannottakeplace
until the door is firmly closed thereby activating both inter-
lock switches. The primary interlock system consists of the
door sensing switch and primary interlock relay located on
the control circuit board.
DESCRIPTION AND FUNCTION OF COMPONENTS
Figure D-1. Door sensing switch, monitor switch and
secondary interlock switches
MONITOR SWITCH
The monitor switch is mounted on the middle position of
latchhook.Itisactivated(thecontactsopened)bythelower
latch head while the door is closed. The switch is intended
to render the oven inoperative by means of blowing the
monitorfusewhenthecontactsoftheprimaryinterlockrelay
andsecondaryinterlockswitchfail toopenwhen thedooris
opened.
Functions:
1. When the door is opened, the monitor switch contact
close (to the ON condition) due to their being normally
closed. At this time the door sensing and secondary
interlock switches are in the OFF condition (contacts
open)duetotheirbeingnormallyopencontactswitches.
2. Asthedoorgoestoaclosedposition,themonitorswitch
contacts are first opened and then the door sensing
switchandthesecondaryinterlockswitchcontactsclose.
(On opening the door, each of these switches operate
inversely.)
3. Ifthedoorisopened,andtheprimaryinterlockrelayand
secondary interlock switch contacts fail to open, the
monitor fuse blows simultaneously with closing of the
monitor switch contacts.
CAUTION: BEFORE REPLACING A BLOWN MONITOR
FUSE TEST THE DOOR SENSING SWITCH,
PRIMARYINTERLOCKRELAY,SECONDARY
INTERLOCK SWITCH AND MONITOR
SWITCH FOR PROPER OPERATION. (RE-
FER TO CHAPTER “TEST PROCEDURE”).
NOTE: MONITOR FUSE AND MONITOR SWITCH ARE
REPLACED AS AN ASSEMBLY.
DOOR SENSING
SWITCH
MONITOR FUSE
MONITOR SWITCH
SECONDARY
INTERLOCK
SWITCH

12
R-930AK
R-930AW
TROUBLESHOOTING GUIDE
Whentroubleshootingthe microwaveoven, itis helpfulto followthe Sequenceof Operationin performingthe checks.Many
ofthepossiblecausesoftroublewillrequirethataspecifictestbeperformed.Thesetestsaregivenaprocedureletterwhich
will be found in the “Test Procedure”section.
IMPORTANT: Iftheovenbecomesinoperativebecauseofablownmonitorfuse,checkthemonitorswitch,primaryinterlock
relay, door sensing switch and secondary interlock switch before replacing the monitor fuse. If monitor fuse
is replaced, the mintor switch must olso be replaced at the same time. Use part FFS-BA012WRK0 as an
assembly.
HEATING ELEMENT
The heating element is located at the left side of the oven
cavity.Itisintendedtoheatairdrivenbytheconvection fan.
The heated air is kept in the oven and force-circulated and
reheated by the heating element.
CONVECTION COOKING SYSTEM
This oven is designed with a hot air heating system where
food is not directly heated by the heating element, but is
heated by forced circulation of the hot air produced by the
heating element.
The air heated by the heating element is circulated through
theconvection passageprovided onthe outercasingof the
oven cavity by means of the convection fan which is driven
bytheconvectionmotor.Itthenenterstheinsideoftheoven
throughthe ventholes providedon theleft sideof theoven.
Next, the hot air heats the food on the turntable and leaves
the oven cavity through the vent in the center of the oven
cavity left side wall.
Without leaving the oven, this hot air is reheated by the
heating element, passes through the convection passage
and enters the inside of the oven cavity again, in a continu-
ing cycle.
In this way, the hot air circulates inside the oven cavity to
raise its temperature and, at the same time, comes into
contact with the food being cooked.
When the temperature inside the oven cavity reaches the
selectedtemperature,theheatingelementisde-energized.
When the temperature inside the oven cavity drops below
theselected temperature,the heatingelementis energized
again.Inthisway,theinsideoftheovencavityismaintained
at approximately the selected temperature.
Whentheconvectiontimereaches0,theheatingelementis
de-energized and the convection fan stops operating and
the oven shuts off.
DAMPER OPEN-CLOSE MECHANISM
Usually, the damper is in the open position except during
convectioncooking.Damperpositionissetautomaticallyby
damper motor, damper switch, motor cam and damper
shaft. These components are operated by a signal that
judges if microwave cooking or convection cooking opera-
tion is selected by the control unit.
Microwave Cooking:
Damperisintheopenposition,becauseaportionofcooling
air is channelled through the cavity to remove steam and
vapors given off from the heating foods.
It is then exhausted at the top of the oven cavity into a
condensation compartment.
Convection Cooking:
Damper is in the closed position, so that no hot air will be
allowed to leak out the oven cavity.
Damper Operation
1. When power supply cord is plugged in:
1-1. When power supply cord is plugged in, a signal is
sensed in the control unit, and operates shut-off
relay (RY4).
1-2. Contacts of shut-off relay (RY4) close, the damper
motor is energized, opening the damper door.
1-3. When the damper is moved to the open position by
the damper cam the damper switch is closed (ON
position).
1-4. The signal from damper switch is re-sensed in the
control unit and shut-off relay (RY4) is turned off.
1-5. The120 voltsA.C.tothe dampermotor isremoved
and the motor turns off.
2. When oven is microwave cooking:
Damper is in the open position.
3. When oven is convection cooking:
3-1. Damper motor is energized by touching the
convection, temperature and START pads.
3-2. When damper is in the closed position (damper
switch is OFF), its signal is sensed by the control
unit, and shut-off relay (RY4) is de-energized.
3-3. Thedamperisheld intheclosed positionduringthe
convection cooking operation.
3-4. At the end of the convection cooking, shut-off relay
(RY4) is energized, and the damper is returned to
the open position.
NOTE: If the damper door is not in the proper position,
closedduringconvectionoropenduringmicrowave,
the control unit will stop oven operation after 1
minute.
DAMPER DUCT
DAMPER
DAMPER CAM
DAMPER MOTOR
DAMPER SWITCH
DAMPER SHAFT
Figure D-2. Damper Mechanism

13
R-930AK
R-930AW
A MAGNETRON
B POWER TRANSFORMER
C H.V. RECTIFIER ASSEMBLY
D HIGH VOLTAGE CAPACITOR
E SECONDARY INTERLOCK SWITCH
F PRIMARY INTERLOCK SYSTEM
G MONITOR SWITCH
H MONITOR FUSE
I MAGNETRON TEMPERATURE FUSE
J CONV. THERMAL CUT-OUT
K CONVECTION HEATER
L THERMISTOR
M DAMPER MOTOR
N DAMPER SWITCH
P OUTER CASE SWITCH
Q TOUCH CONTROL PANEL
R KEY UNIT
S RELAY RY-1
S RELAY RY-2
S RELAY RY-3
S RELAY RY-4
S RELAY RY-5
S RELAY RY-6
U FOIL PATERN ON PWB.
V AH SENSOR
Replace OVEN LAMP OR SOCKET
Replace FAN MOTOR
Replace TURNTABLE MOTOR
Replace CONVECTION MOTOR
Check LOOSE WIRING
Check SHORTED IN POWER CORD
Check NO POWER AT OUTLET
Check LOW VOLTAGE
POSSIBLE CAUSE
AND
DEFECTIVE PARTS
TEST PROCEDURE
CONDITION COOKING CONDITION (MICROWAVE) (CONVECTION)
(SENSOR
COOKING)
OFF CONDITION
Home fuse blows when power cord is plugged into wall receptacle. Monitor fuse blows when power cord is plugged into wall receptacle 88:88 does not appear in display when power cord is first plugged into wall receptacle. Display does not operate properly when STOP/CLEAR pad is touched. (The time of day should appear on the display with beep sound.) Oven lamp does not light with door opened. Oven lamp does not light in cook cycle. (It light when door is opened). Cooking cycle runs 1 minute then shuts down. Oven lamp light, but turntable motor does not operate. Turntable motor operates normally but cooling fan motor does not operate. Oven does not go into a cook cycle, when START pad is touched. Low or no power is produced during microwave cooking (The food is heated incompletely or not heated at all) Extremely uneven heating is produced in oven load (food). Function of variable cooking does not operate properly except HIGH power. Function of COMPU DEFROST does not operate properly. CONV indicator lights, but oven does not go into cook cycle when START pad is touched. CONV indicator lights, but heating element does not heat. Temperature in the oven cavity is lower or higher than preset. Cooling fan motor runs intermittently or all the time. Convection cycle runs 4 minutes and 15 seconds then shuts down. Oveninthesensor cookingconditionbutAHsensor doesnotendorAH sensor turns off about max. 30 min. after start.
PROBLEM

14
R-930AK
R-930AW
TEST PROCEDURES
PROCEDURE
LETTER COMPONENT TEST
HIGH VOLTAGES ARE PRESENT DURING THE COOK CYCLE, SO EXTREME CAUTION SHOULD
BE OBSERVED.
DISCHARGE THE HIGH VOLTAGE CAPACITOR BEFORE TOUCHING ANY OVEN COMPONENTS
OR WIRING.
Totestforanopenfilament,isolatethemagnetronfromthehighvoltagecircuit.Acontinuitycheckacross
the magnetron filament leads should indicate less than 1 ohm.
Totestforashortedmagnetron,connecttheohmmeterleadsbetweenthemagnetronfilamentleadsand
chassis ground. This test should indicate an infinite resistance. If there is little or no resistance the
magnetron is grounded and must be replaced.
Power output of the magnetron can be measured by performing a water temperature rise test. This test
shouldonlybeusedifabovetestsdonotindicateafaultymagnetronandthereisnodefectinthefollowing
componentsorwiring:siliconrectifier,highvoltagecapacitorandpowertransformer.Thistestwillrequire
a 16 ounce (453cc) measuring cup and an accurate mercury thermometer or thermocouple type
temperature tester. For accurate results, the following procedure must be followed carefully:
1. Fillthemeasuringcupwith16oz.(453cc)oftapwaterandmeasurethetemperatureofthewaterwith
a thermometer or thermocouple temperature tester. Stir the thermometer or thermocouple through
the water until the temperature stabilizes. Record the temperature of the water.
2. Place the cup of water in the oven. Operate oven at POWER HI(HIGH) selecting more than 60
secondscooktime.Allowthewatertoheatfor60seconds,measuringwithastopwatch,secondhand
of a watch or the digital read-out countdown.
3. Remove the cup from the oven and again measure the temperature, making sure to stir the
thermometer or thermocouple through the water until the maximum temperature is recorded.
4. Subtractthe coldwater temperaturefrom thehot watertemperature.The normalresult shouldbe22
to 43˚F(12.2 to 23.8˚C) rise in temperature. If the water temperatures are accurately measured and
tested for the required time period the test results will indicate if the magnetron tube has low power
output (low rise in water temperature) which would extend cooking time or high power output (high
rise in water temperature) which would reduce cooking time. Because cooking time can be adjusted
to compensate for power output, the magnetron tube assembly should be replaced only if the water
temperaturerisetestindicatesapoweroutputwellbeyondthenormallimits.Thetestisonlyaccurate
if the power supply line voltage is 120 volts and the oven cavity is clean.
A MAGNETRON ASSEMBLY TEST
B POWER TRANSFORMER TEST
DISCHARGE THE HIGH VOLTAGE CAPACITOR BEFORE TOUCHING ANY OVEN COMPONENTS
OR WIRING.
Disconnecttheprimaryinputterminalsandmeasuretheresistanceofthetransformerwithanohmmeter.
Check for continuity of the coils with an ohmmeter. On the R x 1 scale, the resistance of the primary coil
shouldbelessthan1ohmandtheresistanceofthehighvoltagecoilshouldbeapproximately84.4ohms;
the resistance of the filament coil should be less than 1 ohm.
(HIGHVOLTAGESARE PRESENTATTHEHIGH VOLTAGETERMINAL,SO DONOT ATTEMPTTO
MEASURE THE FILAMENT AND HIGH VOLTAGE.)
C HIGH VOLTAGE RECTIFIER TEST
DISCHARGE THE HIGH VOLTAGE CAPACITOR BEFORE TOUCHING ANY OVEN COMPONENTS
OR WIRING.
Isolatetherectifierfromthecircuit. Usingthehighestohm scaleofthemeter, readtheresistanceacross
the terminals and observe, reverse the leads to the rectifier terminals and observe meter reading. If a
short is indicated in both directions, or if an infinite resistance is read in both directions, the rectifier is
probably defective and should be replaced.
D HIGH VOLTAGE CAPACITOR TEST
DISCHARGE THE HIGH VOLTAGE CAPACITOR BEFORE TOUCHING ANY OVEN COMPONENTS
OR WIRING.

15
R-930AK
R-930AW
If the capacitor is open, no high voltage will be available to the magnetron. Disconnect input leads and
check for short or open between the terminals using an ohmmeter.
Checkingwith ahigh ohmscale, ifthe highvoltagecapacitor isnormal, themeterwill indicatecontinuity
for a short time and should indicate approximately 10 MΩonce the capacitor is charged. If the above is
notthe case,checkthe capacitorwith anohmmeter tosee ifitis shortedbetweeneither ofthe terminals
and case. If it is shorted, replace the capacitor.
ESECONDARY INTERLOCK SWITCH TEST
Isolate the switch and connect the ohmmeter to the common (COM.) and normally open (NO) terminal
ofthe switch.The metershouldindicated anopencircuit withthedoor openanda closedcircuitwith the
door closed. If improper operation is indicated, replace the secondary interlock switch.
FPRIMARY INTERLOCK SYSTEM TEST
DOOR SENSING SWITCH
Isolate the switch and connect the ohmmeter to the common (COM.) and normally open (NO) terminal
of the switch, the meter should indicated an open circuit with the door open and a closed circuit with the
door closed. If improper operation is indicated, replace the door sensing switch.
PRIMARY INTERLOCK RELAY
Disconnecttwo(2) wireleads fromthecommon(COM.) andnormally open(NO)terminalof theprimary
Interlockrelay(RY2).Checkthestateoftherelaycontactsusingaohmmeter.Therelaycontactsshould
be open. If the relay contacts are closed, replace the relay itself.
G MONITOR SWITCH
Disconnect the oven from power supply.
Beforeperformingthistest,makesurethatthesecondaryinterlockswitchandtheprimaryinterlockrelay
are operating properly, according to the above Test Procedures. Disconnect the wire lead from the
monitor switch (NC) terminal. Check the monitor switch operation by using the ohmmeter as follows.
When the door is open, the meter should indicate a closed circuit. When the monitor switch actuator is
pushed by a screw driver through the lower latch hole on the front plate of the oven cavity with the door
opened(inthisconditiontheplungerof
the monitor switch is pushed in), the
meter should indicate an open circuit.
If improper operation is indicated, the
switch may be defective. After testing
themonitorswitch,re-connectthewire
lead to the monitor switch (NC) termi-
nal and check for continuity of monitor
circuit.
SCREW DRIVER
MONITOR SWITCH
OHMMETER
SECONDARY
INTERLOCK
SWITCH
COM.
N.C.
H BLOWN MONITOR FUSE
If the monitor fuse is blown when the door is opened, check the primary interlock relay, secondary
interlock switch, door sensing switch and monitor switch according to the "TEST PROCEDURE" for
those switches before replacing the blown monitor fuse.
CAUTION: BEFORE REPLACING A BLOWN MONITOR FUSE, TEST THE PRIMARY INTERLOCK
RELAY,SECONDARYINTERLOCKSWITCH,DOORSENSINGSWITCHANDMONITOR
SWITCH FOR PROPER OPERATION.
Ifthe monitorfuse isblown byimproperswitch operation,themonitor fuseandswitch mustbe replaced
with "monitor fuse and switch assembly" part number FFS-BA012WRK0, even if the monitor switch
operates normally. The monitor fuse and switch assembly is packed with 20 ampere fuse and switch.
ITEMPERATURE FUSE TEST
A continuity check across the temperature fuse terminals should indicate a closed circuit unless the
temperature of the magnetron reaches approximately 302˚F (150˚C). If the temperature fuse has
opened, replace the temperature fuse.
TEST PROCEDURES
PROCEDURE
LETTER COMPONENT TEST

16
R-930AK
R-930AW
JTHERMAL CUT-OUT TEST
A continuity check across the thermal cut-out terminals should indicate a closed circuit unless the
temperature of thermal cut-out reaches 302˚F(150˚C). The thermal cut-out resets automatically at
approximately 266˚F(130˚C). If the thermal cut-out has opened under the normal condition,
replace the same item as in the parts list. An open thermal cut-out indicates overheating of heater
unit.
Check for restricted air flow to the heater unit through the vent hole of the oven cavity, especially the
heater duct and convection fan.
Make sure the heating element is fully cooled and test as follows;
a. Disconnect wire leads and measure the resistance with an ohmmeter. On the R x 1 scale, the
resistance between the heating element terminals should be approximately 10.2Ω.
b. Disconnect wire leads and measure the insulation resistance with 500V - 100MΩinsulation
resistance meter. The insulation resistance between heating element terminal and cavity should be
more than 0.5MΩ.
K HEATING ELEMENT TEST
Disconnect connector-E from the control unit. Measure the resistance of the thermistor with an
ohmmeter. Connect the ohmmeter leads to Pin No’s E-3 and E-4.
L THERMISTOR TEST
M DAMPER MOTOR TEST
If the meter does not indicate above resistance, replace the thermistor
Room Temperature Resistance
68˚F(20˚C) - 86˚F(30˚C) Approx. 350kΩ- 155KΩ
When the power cord is plugged into the wall receptacle and 120 volts A.C. is supplied to the damper
motor, the motor operates until the damper is opened and the damper switch closes. Then the damper
motor stops operation.
If the damper motor does not operate, check for A.C. voltage with a voltmeter at the motor.
1. Disconnect the power cord from the wall receptacle.
2. Disconnectthewireleadsofmotorandconnectthemeterleadstothewireleadsofmainwireharness.
3. Re-connect the power cord into the wall receptacle.
If120voltsA.C.isindicated atthewireleads, replacethemotorand if 120voltsA.C.isnotindicated,
check the wire harness and control unit.
Disconnectthewireleadsfromtheswitchterminalsandconnectohmmeterleadstothecommon(COM.)
and normally open (N.O.) terminals of the switch.
1. When switch actuator is pushed by the damper motor cam, the meter should be indicated a closed
circuit.
2. When power cord is plugged into the wall receptacle, the damper motor operates and damper cam
willstarttorotate.Whentheswitchactuatorisreleased,themetershouldbeindicatedanopencircuit.
If improper operation is indicated, replace the damper switch.
N DAMPER SWITCH TEST
O CHECKING TEMPERATURE IN THE CONVECTION MODE
It is difficult to measure the exact temperature in the convection oven. An accurate thermocouple type
temperature tester must be used. A low priced bi-metal type thermometer is not reliable or accurate.
The temperature should be checked with outer case cabinet installed, approx. 5 minutes after preheat
TEST PROCEDURES
PROCEDURE
LETTER COMPONENT TEST
Anopentemperaturefuseindicatesoverheatingofthemagnetronassembly,checkforrestrictedairflow
to the magnetron through the opening in the chassis, especially the cooling duct and cooling fan.

17
R-930AK
R-930AW
If the display fails to clear when the STOP/CLEAR pad is depressed, first verify the flat ribbon cable is
making good contact, verify that the door sensing switch (stop switch) operates properly; that is the
contacts are closed when the door is closed and open when the door is open. If the door sensing switch
(stop switch) is good, disconnect the flat ribbon cable that connects the key unit to the control unit and
make sure the door sensing switch is closed (either close the door or short the door sensing switch
connecter). Use the key unit matrix indicated on the control panel schematic and place a jumper wire
between the pins that correspond to the STOP/CLEAR pad making momentary contact.
Q TOUCH CONTROL PANEL ASSEMBLY TEST
The touch control panel consists of circuits including semiconductors such as LSI, ICs, etc. Therefore,
unlike conventional microwave ovens, proper maintenance cannot be performed with only a voltmeter
and ohmmeter.
In this service manual, the touch control panel assembly is divided into two units, Control Unit and Key
Unit and troubleshooting by unit replacement is described according to the symptoms indicated.
1. Key Unit. Note : Check key unit ribbon connection before replacement.
The following symptoms indicate a defective key unit. Replace the key unit.
a) When touching the pads, a certain pad produces no signal at all.
b) When touching a number pad, two figures or more are displayed.
c) When touching the pads, sometimes a pad produces no signal.
2. Control Unit
The following symptoms indicate a defective control unit. Replace the control unit.
2-1 In connection with pads.
a) When touching the pads, a certain group of pads do not produce a signal.
b) When touching the pads, no pads produce a signal.
2-2 In connection with indicators
a) At a certain digit, all or some segments do not light up.
b) At a certain digit, brightness is low.
c) Only one indicator does not light.
d) The corresponding segments of all digits do not light up; or they continue to light up.
e) Wrong figure appears.
f) A certain group of indicators do not light up.
g) All digits in the figure flicker.
2-3 Other possible troubles caused by defective control unit.
a) Buzzer does not sound or continues to sound.
b) Clock does not operate properly.
c) Cooking is not possible.
d) Proper temperature measurement is not obtained.
Note:Whendefectivecomponents,theControlUnitorKeyUnitarereplaced,thedefectivepartorparts
must be properly packed for return in the shipping carton, with its cushion material, in which the
new replacement part was shipped to you.
R KEY UNIT TEST
P OUTER CASE SWITCH TEST
Isolate the switch and connect the ohmmeter to the common (COM.) and normally open (NO) terminal
oftheswitch.Themetershouldindicatedanopencircuitwhenitsplungerisrelease,andaclosedcircuit
when its plunger is pushed. If improper operation is indicated, replace the outer case switch.
TEST PROCEDURES
PROCEDURE
LETTER COMPONENT TEST
temperature is reached (audible signal sounds four times). The temperature experienced may be
approx.30˚Fmoreorlessthanindicatedonthedisplay,however,inmostcasesthefoodcookingresults
will be satisfactory.
Difference in power supply voltage will also affect the oven temperature. The Household power supply
voltage may sometimes become lower than the rated voltage (120 V) and cause under-cooking. If the
powersupplyvoltageis10%lowerthantheratedvoltage,longercookingtimeisrequiredby10%to20%.

18
R-930AK
R-930AW
TCOMPU DEFROST TEST
(1) Place one cup of water in the center of the turntable tray in the oven cavity.
(2)Closethedoor,touch the"COMPUDEFROST"pad twiceandtouchtheNumberpad"5".Andthentouch
the "START" pad.
(3) After 2 sec. Now the oven is in COMPU DEFROST cooking condition.
(4) The oven will operate as follows.
WEIGHT 1ST STAGE 2ND STAGE 3RD STAGE 4TH STAGE
LEVEL TIME LEVEL TIME LEVEL TIME LEVEL TIME
0.5lbs 70% 47sec. 0% 52sec. 50% 32sec. 30% 40sec.
(5) If improper operation is indicated, the control unit is probably defective and should be checked.
S RELAY TEST
Remove the outer case and check voltage between Pin Nos. 7 and 9 of the 9- pin connector (A) on the
control unit an A.C. voltmeter. The meter should indicate 120 volts, if not check the oven circuitry.
Shut-off, Cook and Heater Relay Test
These relays are operated by D.C. voltage
CheckvoltageattherelaycoilwithaD.C.voltmeterduringthemicrowavecookingoperationorconvection
cooking operation.
DC. voltage indicated ............. Defective relay.
DC.voltagenot indicated ........Check diodewhich is connectedto the relaycoil. Ifdiode is good,control
unit is defective.
RELAY SYMBOL OPERATIONAL VOLTAGE CONNECTED COMPONENTS
RY1 Approx. 19.0V D.C. Oven lamp / Turntable motor
RY2(COOK) Approx. 18.0V D.C. Power transformer
RY3(HEATER) Approx. 18.0V D.C. Heating element
RY4 Approx. 19.0V D.C. Damper motor
RY5 Approx. 19.0V D.C. Convection motor
RY6 Approx. 19.0V D.C. Cooling fan motor
TEST PROCEDURES
PROCEDURE
LETTER COMPONENT TEST
Ifthecontrolunitrespondsbyclearingwithabeepthekeyunitisfaultyandmustbereplaced.Ifthecontrol
unit does not respond, it is a faulty and must be replaced. If a specific pad does not respond, the above
method may be used (after clearing the control unit) to determine if the control unit or key pad is at fault.
G 1
G 2
G 3
G 4
G 5 G 6 G 7 G 8 G 9 G10 G11 G12
STOP
CLEAR
SENSOR
REHEAT LOW MIX BAKE
SLOW
COOK
CUSTOM
HELP KITCHEN TIMER POWER LEVEL CLOCK
MINUTE
PLUS COMPU
DEFROST COMPU
BROIL COMPU ROAST COMPU BAKE BROIL
SENSOR
COOK
POPCORN
350˚F 375˚C 400˚F 425˚F 450˚F
67890
100˚F 150˚F 275˚F 300˚F 325˚F
12345
CONVEC
PREHEAT
START
TOUCH ON
HIGH MIX
ROAST
o protect the electronic circuits, this model is provided with a fine foil pattern added to the primary on
the PWB, this foil pattern acts as a fuse. If the foil pattern is open, follow the troubleshooting guide
given below for repair.
U PROCEDURES TO BE TAKEN WHEN THE FOIL PATTERN ON THE PRINTED WIRING BOARD
(PWB) IS OPEN.
