Sharp Notevision PG-M17X User manual

English
This equipment complies with the requirements of Directives 89/336/EEC
and 73/23/EEC as amended y 93/68/EEC.
Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/
EWG und 73/23/EWG mit Änderung 93/68/EWG.
Ce matériel répond aux exigences contenues dans les directives 89/336/
CEE et 73/23/CEE modifiées par la directive 93/68/CEE.
Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/EEG en 73/
23/EEG, gewijzigd door 93/68/EEG.
Dette udstyr overholder kravene i direktiv nr. 89/336/EEC og 73/23/EEC
med tillæg nr. 93/68/EEC.
Quest apparecchio è conforme ai requisiti delle direttive 89/336/EEC e
73/23/EEC, come emendata dalla direttiva 93/68/EEC.
Este equipamento o edece às exigências das directivas 89/336/CEE e 73/
23/CEE, na sua versão corrigida pela directiva 93/68/CEE.
Este aparato satisface las exigencias de las Directivas 89/336/CEE y 73/
23/CEE, modificadas por medio de la 93/68/CEE.
Denna utrustning uppfyller kraven enligt riktlinjerna 89/336/EEC och 73/
23/EEC så som kompletteras av 93/68/EEC.
Dette produktet oppfyller etingelsene i direktivene 89/336/EEC og 73/
23/EEC i endringen 93/68/EEC.
Tämä laite täyttää direktiivien 89/336/EEC ja 73/23/EEC vaatimukset,
joita on muutettu direktiivillä 93/68/EEC.
Downloaded from: http://www.usersmanualguide.com/

English
SPECIAL NOTE FOR USERS IN THE U.K.
The mains lead of this product is fitted with a non-rewirea le (moulded) plug incorpo-
rating a 3A fuse. Should the fuse need to e replaced, a BSI or ASTA approved BS 1362
fuse marked or and of the same rating as a ove, which is also indicated on the pin
face of the plug, must e used.
Always refit the fuse cover after replacing the fuse. Never use the plug without the fuse
cover fitted.
In the unlikely event of the socket outlet in your home not eing compati le with the
plug supplied, cut off the mains plug and fit an appropriate type.
DANGER:
The fuse from the cut-off plug should e removed and the cut-off plug destroyed
immediately and disposed of in a safe manner.
Under no circumstances should the cut-off plug e inserted elsewhere into a 3A socket
outlet, as a serious electric shock may occur.
To fit an appropriate plug to the mains lead, follow the instructions elow:
IMPORTANT:
The wires in this mains lead are coloured in accordance with the following code:
Green-and-yellow: Earth
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead of this apparatus may not correspond with
the coloured markings identifying the terminals in your plug, proceed as follows:
lThe wire which is coloured green-and-yellow must e connected to the terminal in the
plug which is marked y the letter E or y the safety earth sym ol or coloured green
or green-and-yellow.
lThe wire which is coloured lue must e connected to the terminal which is marked
with the letter N or coloured lack.
lThe wire which is coloured rown must e connected to the terminal which is marked
with the letter L or coloured red.
IF YOU HAVE ANY DOUBT, CONSULT A QUALIFIED ELECTRICIAN.
PRODUCT DISPOSAL
This projector utilizes tin-lead solder, and a pressurized lamp containing a small amount
of mercury. Disposal of these materials may e regulated due to environmental
considerations. For disposal or recycling information, please contact your local authori-
ties or, if you are located in the United States of America, the Electronic Industries
Alliance: www.eiae.org .
WARNING:
This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may e required to take adequate measures.
Downloaded from: http://www.usersmanualguide.com/

1
English
Usage Notice
Precautions ........................................................................................................ 2
Important Safeguards ......................................................................................... 4
Introduction
Product Features ................................................................................................ 5
Package Overview .............................................................................................. 6
Product Overview ............................................................................................... 7
Main nit ....................................................................................................... 7
Panel Control ................................................................................................. 8
Connection Ports .......................................................................................... 8
Remote Control with Mouse Function & Laser Pointer ................................... 9
Installation
Connecting the Projector .................................................................................... 10
Powering On/Off the Projector ............................................................................. 11
Powering On the Projector ............................................................................. 11
Powering Off the Projector ............................................................................. 12
Adjusting the Projected Image ............................................................................ 13
Adjusting the Projector Height ....................................................................... 13
Adjusting the Projector Zoom/Focus ............................................................. 14
Adjusting Projection Image Size .................................................................... 14
User Controls
Panel Control & Remote Control ......................................................................... 15
On-Screen Display Menus ................................................................................. 18
How to Operate ............................................................................................. 18
Image-I (Computer mode) ............................................................................. 19
Image-I (Video mode) ................................................................................... 20
Image-II (Computer mode) ............................................................................ 22
Image-II (Video mode) .................................................................................. 23
Audio ............................................................................................................. 24
Language ...................................................................................................... 25
Management ................................................................................................. 26
PIP (Computer mode) ................................................................................... 27
Appendices
Troubleshooting .................................................................................................. 28
Specifications ..................................................................................................... 31
Compatibility Modes ........................................................................................... 32
Table of Contents
Downloaded from: http://www.usersmanualguide.com/

2
English
Usage Notice



 Do not look into the lens. The bright light may hurt
your eyes.
 To reduce the risk of fire or electric shock, do not
expose this product to rain or moisture.
 Please do not open or disassemble the product as this
may cause electric shock.
 This product will detect the life of the lamp itself.
Please be sure to change the lamp when it shows
warning messages.
 Before switching off the product, please keep the
cooling fan running for a few minutes.
 When connecting the projector to computer, please turn
on the projector first.
 To reduce the risk of injury to the eyes, do not look
directly into the laser light on the remote control and do
not point the laser light into anyone s eyes. This remote
control is equipped with a Class II laser that emits
radiation.
 When the lamp reaches the end of its life, it will burn
out and may make a loud popping sound. If this
happens, the projector will not turn back on until the
lamp module has been replaced. To replace the lamp,
please contact Sharp Authorized Projector Dealer or
Service Center.
 Do not connect any cable longer than 3 meter.
Downloaded from: http://www.usersmanualguide.com/

3
English
Do:
vTurn off the product before cleaning.
vUse a soft cloth moistened with mild detergent to clean the
display housing.
vDisconnect the power plug from AC outlet if the product is not
being used for a long period of time.
Dont:
vBlock the slots and openings on the unit provided for
ventilation.
vUse abrasive cleaners, waxes or solvents to clean the unit.
vUse under the following conditions:
- Extremely hot, cold or humid environment.
- In areas susceptible to excessive dust and dirt.
- Near any appliance generating a strong magnetic field.
- Place in direct sunlight.
- Allow at least 20cm of space between the exhaust vent and
the nearest wall or obstruction.
Usage Notice
Downloaded from: http://www.usersmanualguide.com/

4
English
Important Safeguards
Be sure to read the following safeguards when setting up
your projector.
Caution concerning the setup of the
projector.
nFor minimal servicing and to maintain high
image quality, SHARP recommends that this
projector be installed in an area free from
humidity, dust and cigarette smoke When the
projector is subjected to these environments, the
lens must be cleaned more often As long as the
projector is regularly cleaned, use in these
environments will not reduce the overall
operation life of the unit Internal cleaning
should only be performed by a Sharp
Authorized Projector Dealer or Service Center
Do not set up the projector in places
exposed to direct sunlight or bright light.
nPosition the screen so that it is not in direct
sunlight or room light Light falling directly on
the screen washes out the colors, making
viewing difficult Close the curtains and dim
the lights when setting up the screen in a
sunny or bright room
The projector may be safely tilted to a
maximum angle of ± 2 degrees.
nPlacement should be within ±12 degrees of
horizontal
Do not subject the projector to hard
impact and/or vibration.
nTake care with the lens so as not to hit or
damage the surface of the lens
Rest your eyes occasionally.
nContinuously watching the screen for long
hours will cause eye strain Be sure to
occasionally rest your eyes
Avoid locations with extremes of
temperature.
nThe operating temperature of the projector is
from 41oF~95oF (+5oC~ +35oC)
nThe storage temperature of the projector is from
-4oF~140oF (-20oC~ +60oC)
Do not block the exhaust and intake
vents.
nAllow at least 7 7/8 inches (20cm) of space
between the exhaust vent and the nearest wall
or obstruction
nBe sure that the intake vent and the exhaust
vent are not obstructed
nIf the cooling fan becomes obstructed, a
protection circuit will automatically turn off the
projector This does not indicate a malfunction
Remove the projector power cord from the wall
outlet and wait at least 10 minutes Place the
projector where the intake and exhaust vents
are not blocked, plug the power cord back in
and turn on the projector This will return the
projector to the normal operating condition
Caution regarding transportation of the
projector.
nWhen transporting the projector, be sure not to
subject it to hard impact and/or vibration, as
this can result in damage Take extra care with
the lens Before moving the projector, be sure to
unplug the power cord from the wall outlet,
and disconnect any other cables connected to it
Other connected equipment
nWhen connecting a computer or other audio-
visual equipment to the projector, make the
connections AFTER turning off the projector
and the equipment to be connected
nPlease read the operation manuals of the
projector and the equipment to be connected for
instructions on how to make the connections
Using the projector in other countries
nThe power supply voltage and the shape of the
plug may vary depending on the region or
country you are using the projector in When
using the projector overseas, be sure to use an
appropriate power cord for the country you are
in
Usage Notice
Downloaded from: http://www.usersmanualguide.com/

5
English
Product Features
This product is an XGA single chip 0.7 DLPTM projector. The
outstanding features of it are listed as follows
uTrue XGA, 1024 x 768 addressable pixels
u3.97 lbs (1.8 kgs) ompa t design
uSingle hip DLPTM te hnology
uPureProgressiveTM pro essing te hnology for artifa t-
free film materials.
uHDTV ompatible (480i, 480P, 580i, 580P, 720P/1080i/
60Hz)
uNTSC/NTSC4.43/PAL/PAL-M/PAL-N/SECAM and
HDTV ompatible
uHigh-te h DVI onne tion for digital and analog video
onne tivity
uFull fun tion remote with mouse ontrol and laser
pointer
uMultimedia audio integration
uUser friendly multilingual on-s reen display menu
uAdvan ed ele troni keystone orre tion and high quality
full s reen re-s aling image
uUser friendly ontrol panel
uLuxurious arrying ase in luded
uSXGA ompression and VGA, SVGA re-sizing
u150 Watts P-VIP lamp
uMa ompatible
Introduction
Downloaded from: http://www.usersmanualguide.com/

6
English
Introduction
S-Video Cable (1.8m)
Power Cord (1.8m)
Remote Control
Audio Cable
(1.8m, with two cores )
M1-A to VGA and USB
cable (1.8m, with one core)
Battery x 2User s Guide
Composite Video Cable
(1.8m)
Projector with lens cap
&'##
')*+
+*

Carrying Case Quick Start Card Operation Manual
%+Do not
connect any cable
longer than 3 meter.
Downloaded from: http://www.usersmanualguide.com/

7
English
,)
'##
1. Panel Control
2. Power Connector
3. Connection Ports
4. Focus Ring
5. Zoom Lens
6. Zoom Ring
7. Speaker
8. Remote Control Receiver
9. Elevator Button
10. Elevator Foot
-
.
/
0
1
2
3
45
-6
Introduction
Downloaded from: http://www.usersmanualguide.com/

8
English
Introduction

1
0
4
3
2
.
5
1. Lamp Warning LED
2. Temperature Warning LED
3. Power Indicator Light
4. Power /Standby
5. Menu (On/Off)
6. Four Directional Select Keys
7. Enter
8. Re-sync
9. Source
-
/

./ -0 1 3 4
1. KensingtonTM Lock Hole
2. Monitor Loop-Through Connector
3. RS232 Input Connector (RS232 is for after service purpose only)
4. Composite Video Input Connector
5. Audio Input
6. S-Video Input Connector
7. VESA M1-DA Analog RGB/Digital/HDTV/Component
Video/USB Mouse Input Connector
Downloaded from: http://www.usersmanualguide.com/

9
English
$,*78

Source
Re-sync
Freeze
Keystone Correction
Power / Standby
Volume ( + / - )
Mute
Multi-Directional
Selector
Menu
Laser
Pointer
Zoom In /
Zoom Out
Page Up
LED
Cover
Page Down
vClose the cover of the
remote control when
you want to use the
remote mouse.
Enter Key
+To
reduce the risk of
injury to the eyes, do
not look directly into
the laser light on the
remote control and do
not point the laser light
into anyone s eyes.
This remote control is
equipped with a Class
II laser that emits
radiation.
+Use of
controls or adjustments,
or performance of
procedures other than
those specified herein
may result in hazard-
ous radiation exposure.
Introduction
Downloaded from: http://www.usersmanualguide.com/

10
English
Installation

v'+
+
,- ./!01&+
)'2
3*)&"4.
S-Video Output
Video Output
-
.
/
3
1
Digital Tuner Output
Antenna
RGB
0
1. Power Cord
2. S-Video Cable
3. Audio Cable
4. Composite Video Cable
5. M1-A to VGA and USB Cable
6. M1-A to HDTV and USB Cable
(optional)
7. M1-D to DVI-D and USB Cable
(optional)
DVI
4
Downloaded from: http://www.usersmanualguide.com/

11
English
Lens cap
Power / Standby
'
- Remove the lens cap.
. Ensure that the power cord and signal cable are securely
connected.
/ Turn on the lamp by pressing Power/Standby button on
the control panel. 
The startup screen will be displayed for 20 seconds and the
Power/Standby indicator will light solid green.
0 Turn on your source (computer, notebook, video player,
etc...) The projector will detect your source automatically.
v5367"+
)
v537"
)2*%*
'"'
vTurn on the projector
first and then the
computer.
-
.
Installation
Downloaded from: http://www.usersmanualguide.com/

12
English
Installation
'
- Press the Power/Standby button to turn off the projector
lamp.
. After pressing the Power/Standby button, you will see a
message Power off the lamp? on the on-screen display.
Press the Power/Standby button again to confirm. Other
wise the message will disappear after 5 seconds.
/ Power/Standby indicator flashes red for about 2 minutes.
The projector will automatically shut itself down.
0 Disconnect the power cord from the electrical outlet and
the projector.
v839&%")- 
3":
3%;7)").
'
%<
v839&%")- 
')<=
3><":
3%;7)").
'
%<
v83$&%"3%;
7)").'
%
<
v8%*
39&%")
3%;7)")%
3%;7)")39&%"

Downloaded from: http://www.usersmanualguide.com/

13
English
Elevator Button
Elevator Foot
',<'
'
To raise the projector:
- Press the elevator button .
. Raise the projector to the desired display angle , then
release the button to lock the elevator foot into position.
/ Use  to fine-tune tilt-adjustment.
To lower the projector:
- Press the elevator button.
. Lower down the projector, then release the button to lock the
elevator foot into position.
/ Use  to fine-tune tilt-adjustment.
%
%9
-
.
/
Installation
Downloaded from: http://www.usersmanualguide.com/

14
English
.xaM "1.82 "4.89 "0.321 "9.691 "1.642 "3.592
.niM"4.32"0.28"5.201"0.461"1.502"1.642
)HxW(.xaM "68.61x"84.22 "40.95x"27.87 "08.37x"04.89 "41.811x"25.751 "66.741x"88.691 "81.771x"42.632
)HxW(.niM"40.41x"27.81"02.94x"06.56"05.16x"00.28"04.89x"02.131"60.321x"80.461"66.741x"88.691
'47.3 '21.31 '04.61 '52.62 '18.23 '73.93
Focus Ring
Zoom Ring
%:"*
You may adjust zoom ring to zoom in / out. Rotate the zoom ring
counter-clockwise to zoom in and clockwise to zoom out. To
focus the image, rotate the focus ring until the image is clear. The
projector will focus at distances from 3.74 feet to 39.37 feet (1.14m
to 12m)
%;
Screen
(Diagonal)
Screen
Size
Distance
vThis graph is for user s reference only.
Installation
Downloaded from: http://www.usersmanualguide.com/

15
English
User Controls
Remote ControlPanel Control
7$
(2
*%*
)$
" 
4Refer to the Power On/Off the Projector section on page
11~12.

4Press Source to choose RGB, DVI-Digital, DVI-Analog,
S-Video, Composite, Component and HDTV sources.
$
4Automatically synchronizes the projector to the input source,
when you press this button while the remote control cover is
opened.
4If the remote control cover is closed, the Mouse/Re-Sync button
functions like the right mouse button.
Downloaded from: http://www.usersmanualguide.com/

16
English
User Controls
,
4When you close the cover of remote control, this key can be used
as a mouse to control direction.
v! # 
 ) 
4When the cover of remote control is opened, this key can be
used for the operation for OSD display.
)<=
4Use this button to page up.
<=
4Use this button to page down.
8
4Aim the remote at the viewing screen, press and hold this button
to activate the laser pointer.
,
4Press Menu to open the on-screen display (OSD) menus and
press  key to select menu items. To exit OSD, press the
Menu button again. The projector will save any change you
made automatically.
*;
4Press the Freeze button to still the screen image.
,
4Use to mute sound.
>?"
4Increases/decreases speaker volume.
@?"
4Adjust image distortion caused by tilting the projector. (±16
degrees)
:
4Press in button of zoom function to magnifies an image up to
a factor of 32 times on the projection screen.
:'
4Press out button of zoom function to diminishes the zoom in
image.
v )"+
Under remote mouse
connected status only.
Downloaded from: http://www.usersmanualguide.com/

17
English
A
4Confirm your selection of items, when you open the front cover
of remote control.
4If the remote control cover is closed, the Enter button functions
like the left mouse button.
)
" 
4Refer to the Power On/Off the Projector section on page
11~12.

4Press Source to choose RGB, DVI-Digital, DVI-Analog,
S-Video, Composite, Component and HDTV sources.
$
4Automatically synchronizes the projector to the input source.
*@
4Use to select items or make adjustments for
your selection.
A
4Confirm your selection of items.
,
4Press Menu to open the on-screen display (OSD) menus and
press  key to select menu items . To exit OSD, press the
Menu button again. The projector will save any change you
made automatically.
User Controls
Downloaded from: http://www.usersmanualguide.com/
