Show Tec 43161 User manual

Magician LED V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 43161
MANUAL
ENGLISH

1
Ordercode: 43161
Magician LED
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................5
Laser safety for a Class 3B Laser Product .................................................................................................................5
Rigging ............................................................................................................................................................................7
Connection with the mains.........................................................................................................................................7
Return Procedure..........................................................................................................................................................8
Claims..............................................................................................................................................................................8
Description of the device.................................................................................................................................................9
Optional accessories....................................................................................................................................................9
Overview ......................................................................................................................................................................10
Backside .......................................................................................................................................................................11
Installation.........................................................................................................................................................................11
Set Up and Operation .....................................................................................................................................................11
Control Modes.............................................................................................................................................................13
One Magician (Auto Program and Static Color Mode)..................................................................................13
One Magician (Sound-controlled).......................................................................................................................13
Multiple Magicians (Master/Slave control).........................................................................................................13
Multiple Magicians (DMX Control) .......................................................................................................................14
Fixture Linking ...............................................................................................................................................................15
Data Cabling...............................................................................................................................................................15
Control Panel ...............................................................................................................................................................16
Control Mode ..............................................................................................................................................................16
DMX Addressing ..........................................................................................................................................................16
Menu Overview...........................................................................................................................................................17
Main Menu Options ....................................................................................................................................................17
1. Auto Run Programs..............................................................................................................................................18
2. Sound-controlled Mode .....................................................................................................................................18
3. Static Control Mode............................................................................................................................................19
4. Slave mode...........................................................................................................................................................19
5. DMX Channels / DMX Address..........................................................................................................................19
6. System Settings.....................................................................................................................................................20
Remote Control...........................................................................................................................................................21
DMX Channels .............................................................................................................................................................22
3 channels .................................................................................................................................................................22
5 channels .................................................................................................................................................................24
11 channels...............................................................................................................................................................25
28 channels...............................................................................................................................................................26
Maintenance...............................................................................................................................................................32
Replacing the Fuse.....................................................................................................................................................32
Troubleshooting ...............................................................................................................................................................33
No Light.........................................................................................................................................................................33
No Response to DMX..................................................................................................................................................33
Product Specifications....................................................................................................................................................35
Dimensions........................................................................................................................................................................36
Notes ..................................................................................................................................................................................37

2
Ordercode: 43161
Magician LED
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Showtec Magician LED
IEC Power cable (1,5 m)
2 keys for the interlock
Remote control plug
IR Remote control
User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual

3
Ordercode: 43161
Magician LED
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never lift the fixture holding it by the projector-head, as the mechanics may be damaged. Always
hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Never aim the laser beam at people or animals!
•Never use the device during thunderstorms, unplug the device immediately.
•Never point a laser at aircraft, this is a federal offense.
•Never point unterminated laser beams into the sky.
•Never open the laser housing. The high laser power levels inside of the protective housing can start
fires, burn skin and will cause instant eye injury.
•Do not insert objects into air vents.
•Do not connect this device to a dimmerpack.
•Do not open the device and do not modify the device.
•Do not point lasers at highly reflective surfaces such as windows, mirrors and shiny metal. Even laser
reflections can be hazardous.
•Do not expose the output optic (aperture) to cleaning chemicals
•Do not use laser if the laser appears to be emitting only one or two beams
•Do not use laser if housing is damaged or open, or if optics appear damaged in any way.
•Do not operate laser without first reading and understanding all safety and technical data in this
manual. Never look into the laser aperture or laser beams
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•After set up and prior to public use, test laser to ensure proper function. Do not use the laser if any
defect is detected. Do not use, if the laser emits only one or two laser beams rather than
dozens/hundreds, as this could indicate damage to the diffraction grating optic, and could allow
emission of higher laser levels.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.

4
Ordercode: 43161
Magician LED
•Always check the regulations when using a class 3B laser product.
•Always check and position the laser before anybody enters the room, when the laser is facing an
area with people.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the external cable is damaged, it has to be replaced by a qualified technician.
•If the lens is obviously damaged, it has to be replaced. So that its functions are not impaired, due to
cracks or deep scratches.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. The fixture must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.
•The operation of a class 3B laser show laser is only allowed if the show is controlled by a skilled and
well-trained operator familiar with the data included in this manual.
•The user is responsible for correct positioning and operating of the Magician LED. The manufacturer
will not accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•The laser will only work between 10-40ºC.
•After 3 hours working, you must shut off the laser and let the laser diode cool off for 30 minutes,
otherwise the laser could be damaged and the warranty becomes void.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.

5
Ordercode: 43161
Magician LED
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Laser safety for a Class 3B Laser Product
Laser Light is different from any other light source with which you may be familiar with. The light from this
product can potentially cause instant eye injury if not set up and used properly.
Laser light is thousands of times more concentrated than light from any other kind of light source. This
concentration of light power can cause instant eye injuries, primarily by burning the retina (the light
sensitive portion at the back of the eye). Even if you cannot feel “heat” from a laser beam, it can still
potentially injure or blind you or your audience.
Even very small amounts of laser light are potentially hazardous even at long distances. Laser eye injuries
can happen quicker than you can blink.
It is incorrect to think that because these laser products split the laser into hundreds of beams or the laser
beam is scanned out in high speed, that an individual laser beam is safe for eye exposure. This laser
product uses dozens of milliwatts of laser power (Class 3B levels internally). Many of the individual beams
are potentially hazardous to the eyes.
It is also incorrect to assume that because the laser light is moving, it is safe. This is not true. Nor, do the
laser beams always move. Since eye injuries can occur instantly, it is critical to prevent the possibility of
any direct eye exposure. According to the laser safety regulation, it is not legal to aim Class 3B lasers in
areas which people can get exposed. This is true even if it is aimed below people’s faces, such as on a
dance floor.
CAUTION! Only Laser Safety Officers who are officially certified by a regulatory body or authorized
training organization are allowed to use class 3B lasers in public. The Laser Safety Officer is responsible for
all aspects when using this laser, including following all locally applicable safety laws and regulations.
The manufacturer will not accept liability for damages caused by the misuse or incorrect installation of
this laser.
CAUTION: AVOID EXPOSURE TO BEAM: Avoid direct eye contact with laser
light. Never intentionally expose your eyes or others to direct laser
radiation.
Compliance Statement
Your Galactic Laser has been designed to comply with FDA and IEC Standards for its classification.
The Galactic is a Class 3B laser product.
Laser Safety and Compliance Information
The Galactic is manufactured to comply with the IEC 60825-1 and in accordance with U.S. Food and
Drug Administration (FDA) Standards Listed under FDA Document 21 CFR 1040 and subsequent laser
notices.

6
Ordercode: 43161
Magician LED
Product Classification and Manufacturing Label Identification
Laser Classification
Class 3B
Cooling
Cooling fans and TE Cooling
Laser medium
wavelength 650 nm / Red (Laser Diode GaAIAs) ; Output >100mW
wavelength 532 nm / Green (DPSS Nd: YVO4); Output >30mW
Output
130mW
Beam Diameter
<5mm at aperture
Pulse Data All pulses
< 4Hz (>0.25sec)
Divergence (each beam)
<2 mrad
Divergence (total light)
<160 degrees
The legal requirements for using laser entertainment products vary from country to country. The user is
responsible for the legal requirements at the location/country of use.
Further guidelines and safety programs for safe use of lasers can be found in the ANSI Z136.1 Standard
“For Safe Use of Lasers”, available from www.laserinstitute.org. Many local governments, corporations,
agencies, military and others, require all lasers to be used under the guidelines of ANSI Z136.1. Laser
Display guidance can be obtained via the International Laser Display Association, www.laserist.org.
CAUTION: The use of corrective eye wear or optics for viewing at distances such as telescopes or
binoculars within a distance of 100mm may pose an eye hazard.
This laser product is a Class 3B laser and has an interlocked
housing.
There are no user serviceable parts inside. Tampering or
removing warranty seals will void your products limited
warranty.
Combo label with the Product Model Number, Serial
Number, Date of Manufacturing, Laser Light Warning Label,
Warranty Void Label and Interlocked Housing Label
Proper Usage Safety and Compliance Information
According to FDA Regulations you should
operate this product as stated on the left.

7
Ordercode: 43161
Magician LED
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the Magician is lowered from the ceiling or high joists, professional trussing systems have to be used.
•Use a clamp to mount the Magician, with the mounting bracket, to the trussing system.
•The Magician must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the Magician, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.
The Magician LED can be placed on a flat stage floor or mounted to any kind of truss with a clamp.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE
GROUND

8
Ordercode: 43161
Magician LED
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause of the
return. Be sure to properly pack fixture as any shipping damage resulting from inadequate packaging is
the customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name.
02) Your address.
03) Your phone number.
04) A brief description of the symptoms.
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that the fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period, complaints will not be handled anymore.
Complaints will only be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

9
Ordercode: 43161
Magician LED
Description of the device
Features
The Magician LED is a multifunctional light effect with high output and great effects. It combines laser
effects, strobe effects and LED effects in one device.
Multifunctional device
IR remote and DMX control
RGB-UV Wash LEDs
RGBA Beam LEDs
Input voltage: 100-240V AC, 50/60Hz
Power consumption: 90W
DMX channels: 3, 5, 11 or 28 channels
4-digit LED display for easy setup
Control modes: Auto, Sound-controlled, Static color, Master/Slave, DMX
Control protocol: DMX-512
Protection rate: IP-20
Housing: Die-cast black aluminum
Cooling: Fans/Convection
Connections: IEC connectors (IN/OUT), 3-pin XLR (IN/OUT)
Fuse: T1.6L/250V
Dimensions: 350 x 320 x 185 mm (LxWxH) (incl. bracket)
Weight: 3,1 kg
Wash LED effect
Light source: 9 x 4W RGB-UV LEDs
Beam LED effect
Light source:3 x Beam LEDs (8 x 0,75W Red, 6 x 0,75W Green, 6 x 0,75W Blue, 8 x 0,75W Amber)
Laser effect
Laser Color: Red, Green
Laser Power: 130mW (100mW 650nm Red, 30mW 532nm Green)
Laser Class: 3B
Safety Features: Key switch, Interlock, Safety eye
Laser Safety: EN/IEC 60825-1 Ed 2, 2007-03
Strobe effect
Light source: 12 x 0,5W White 5730 LEDs
Note: Knowledge of DMX is required to fully utilize this unit.
Optional accessories
51316 Remote Interlock

10
Ordercode: 43161
Magician LED
Overview
Fig. 01
01) Fan
02) Mounting bracket
03) Adjustment screw
04) 9 x 4W RGB-UV Wash LEDs
05) 3 x Beam LEDs (8 x 0,75W Red, 6 x 0,75W Green, 6 x 0,75W Blue, 8 x 0,75W Amber)
06) IR sensor
07) 12 x 0,5W White 5730 LEDs
08) Laser lens

11
Ordercode: 43161
Magician LED
Backside
Fig. 02
09) LED display + menu buttons + Function LED indicators
10) Safety eye
11) IEC Power connector IN + Fuse T1.6L/250V
12) IEC Power connector OUT
13) Ground/earth connection
14) 3-pin DMX signal connector OUT
15) 3-pin DMX signal connector IN
16) Remote control plug
17) Interlock
18) Built-in microphone
19) Sound sensitivity control
Installation
Remove all packing materials from the Magician LED. Check if all foam and plastic padding is removed.
Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply. The device can be sound-controlled as it is equipped
with a built-in microphone.

12
Ordercode: 43161
Magician LED
The Interlock plug/remote plug and safety keys are included in the box.
The interlock is the “included-in-the-box” successor for the optional remote interlock (51316).
They should be kept with the Magician !!!
The following safety precautions should be followed:
●The remote control plug should be placed on the backside (16)
of your Magician.
●The keys should be put into the lock (17) of your Magician.
Warning
If the plug is not connected, your laser will not function.
If the key is not set to ON, your laser will not function.
Fig. 03
Exclusion of liability
Be aware that in some countries, there are additional regulations, regarding the use of laser devices.
Therefore, we strongly advise you to verify your national laws with your authorities: We do not take any
responsibility for eventual discrepancies, changes or adaptions regarding lawful use of laser devices.
Fig. 04

13
Ordercode: 43161
Magician LED
Control Modes
There are 5 modes:
•Auto Program
•Static Color (manual)
•Sound-controlled
•Master/slave
•DMX-512 (3CH, 5CH, 11CH or 28CH)
One Magician (Auto Program and Static Color Mode)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Magician is not connected with a DMX cable, it functions as a stand-alone device.
Please see pages 18 and 19 for more information about Auto Program and Static Color Mode.
One Magician (Sound-controlled)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Turn on the music. If the device is set to sound-control, then the Magician will react to the beat of
the music. Please see page 18 for more information about the sound-control options.
Multiple Magicians (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-p XLR cable to connect the Magician and other devices.
The pins:
1. Earth
2. Signal (-)
3. Signal (+)
04) Link the units as shown in Fig. 05, connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third and fourth units. You can
use the same functions on the master device as described on pages 18 and 19 (Auto, Static color).
This means you can set your desired operation mode on the master device and all slave devices will
react the same as the master device.
Multiple Magicians (Master/Slave control)
Fig. 05

14
Ordercode: 43161
Magician LED
Multiple Magicians (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the Magicians and other devices.
04) Link the units as shown in Fig. 06. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
Multiple Magicians DMX Set Up
Fig. 06
Note: Link all cables before connecting electric power

15
Ordercode: 43161
Magician LED
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX
optically isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Maximum recommended number of fixtures on a power link @ 110V: 10 fixtures
Maximum recommended number of fixtures on a power link @ 240V: 20 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin. Ordercode
FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
•DAP Audio DMX adapter: 3-pin/5-pin. Ordercode FLA30.
The Magician LED can be operated with a controller in control mode or without the controller in stand-
alone mode.

16
Ordercode: 43161
Magician LED
Control Panel
A) DMX LED
B) LED display
C) AUTO LED
D) SOUND LED
E) Mode button
F) Up button
G) Down button
H) Enter button
I) SLAVE LED
Fig. 07
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the back side of the device allows you to assign DMX fixture addresses, which is the
first channel with which the Magician will respond to the controller.
Please note, when you use the controller, the unit has 28 channels.
When using multiple Magicians, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Magician should be 1(d001); the DMX address of the second
Magician should be 1+28=29 (d029); the DMX address of the third Magician should be 29+28=57 (d057),
etc. Please, be sure that you do not have any overlapping channels in order to control each Magician
correctly. If two or more Magicians are addressed similarly, they will work similarly.
Controlling:
After having addressed all Magician fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the Magician will automatically detect whether DMX 512 data is received or
not. If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the Magician.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 60 seconds
When no button is pressed for 60 seconds, the display will turn off.
To light up the display, you have to press the Mode, Enter, Up or Down button.
Once you have pressed the button, the display will light up.

17
Ordercode: 43161
Magician LED
Menu Overview
The Magician LED will only show its version number at start-up !
Main Menu Options
Auto Run Programs
Sound-controlled Mode
Static Color Mode
Slave Mode
DMX Channels / DMX Address
System Settings

18
Ordercode: 43161
Magician LED
1. Auto Run Programs
With this menu you can start several Auto run programs.
01) Press the Mode button until the display shows .
02) Press the Enter button to open this menu.
03) Press the Up and Down buttons to choose between 5 types of built-in programs:
Auto run mix programs (Wash/Beam/Laser/Strobe)
Auto run wash programs
Auto run beam programs
Auto run laser programs
Auto run strobe programs
04) Choose the desired type and press the Enter button again to open the submenu.
05) Press the Up and Down buttons to choose between:
mix programs
wash programs
beam programs
laser programs
strobe programs
06) Press the Enter button again to set the speed of the desired Auto run program.
07) Press the Up and Down buttons to adjust the speed between , from slow to fast.
08) The Magician will immediately start the desired Auto run program.
2. Sound-controlled Mode
With this menu you can set several Sound-controlled programs.
01) Press the Mode button until the display shows .
02) Press the Enter button to open this menu.
03) Press the Up and Down buttons to choose between 5 types of Sound-controlled programs:
Sound-controlled mix programs (Wash/Beam/Laser/Strobe)
Sound-controlled wash programs
Sound-controlled beam programs
Sound-controlled laser programs
Sound-controlled strobe programs
04) Choose the desired type and press the Enter button again to open the submenu.
05) Press the Up and Down buttons to choose between:
mix programs
wash programs
beam programs
laser programs
strobe programs
06) Turn on the music and the Magician will immediately start the desired Sound-controlled program.

19
Ordercode: 43161
Magician LED
3. Static Control Mode
With this menu you can manually set a desired color and set the strobe function.
01) Press the Mode button until the display shows .
02) Press the Enter button to open this menu.
Gradual adjustment red intensity(0-255)
Gradual adjustment green intensity (0-255)
Gradual adjustment blue intensity (0-255)
Gradual adjustment UV intensity (0-255)
Strobe speed from slow to fast
03) Repeatedly press the Enter button to scroll through the 4 color options and the strobe function.
04) Press the Up and Down buttons to change the values.
You can combine Red, Green, Blue and UV to create an infinite range of colors (0-255).
4. Slave mode
With this menu you can set the device as a Slave.
01) Press the Mode button until the display shows .
02) Press the Enter button to activate the slave mode, the display shows .
03) If the device has not been set to slave, it is automatically classified as a master device. All slave
devices will follow the master movement. If the device has been set to slave, it will react the same as
its master device.
5. DMX Channels / DMX Address
With this menu you can choose a DMX configuration and set the DMX address.
01) Press the Mode button until the display shows .
02) Press the Enter button to open this menu.
03) Press the Up and Down buttons to choose the desired DMX configuration.
04) Once you have chosen the desired DMX configuration press the Enter button to set the DMX
address.
05) Press the Up and Down buttons to select the required address.
06) Each DMX configuration has a different maximum number of DMX addresses.
