SIA D0102 User manual

BUILT-IN DOUBLE OVEN
Cod:0040303245
D0102

Safety instructions......................................................................................................4
How to save energy.............................................................................................................5
Disposal of the appliance....................................................................................................6
Unpacking.............................................................................................................................5
Description of the appliance..................................................................................7
Installation......................................................................................................................8
Operation.......................................................................................................................11
Control panels........................................................................................................................11
Electronic programmer.......................................................................................................19
Oven..................................................................................................................................24
Cleaning and maintenance...................................................................................24
Operation in case of emergency........................................................................27
Baking in the oven....................................................................................................28
Technical information..............................................................................................34
Prior first use........................................................................................................................19
Top natural convection..............................................................................................................12
Bottom main fan oven........................................................................................................15
Cooking advice...................................................................................................................18

centers for used devices can be provided
by your local authority.
DISPOSAL OF THE APPLIANCE
Old appliances should not
simply be disposed of with
normal household waste,
but should be delivered to
a collection and recycling
centre for electric and
electronic equipment.
A symbol shown on the product, the
instruction manual or the packaging shows
that it is suitable for recycling.
Materials used inside the appliance are
recyclable and are labeled with information
concerning this. By recycling materials or
other parts from used devices you are
making a significant contribution to the
protection of our environment.
Information on appropriate disposal

Top oven door
Bottom mains
oven door
Top oven
door handle
Bottom mains
oven door handle
Oven temperature
Function selector
knob(Top oven)
Oven temperature knob
(Bottom mains oven)
knob(Top oven)
Function selector knob
(Bottom mains oven)
Clock and timer with keys
(Bottom mains oven only)
Top oven temperature
indicator light
Bottom mains oven
temperature indicator light

To avoid damage to the lower trim please note the following instructions.
The lower trim is designed to allow for good air circulation and the correct opeening of
To ensure the trim is not damaged due to the appliance being placed on the floor. the
After installation the appliance door should be slowly opened to ensure no damage has
No responsiblity for lower trim damage will be accepted if these instructions have not
the oven door.
appliance should be suitably supported as in above illustrations.
occured.
been followed.
IMPORTANT:

Before attempting the connection,
check whether the voltage indicated
on the rating plate corresponds to
the actual mains voltage.
Mains lead should be minimum1.5m
long.
Earthing wire should be installed in
such manner to be the last one pulled
out in case the safety relief device of
the mains lead should fail.
Mains lead behind the oven must be
placed in such manner to avoid
touching the back panel of the oven
because of the heat it develops
during operation.
The cable of correct size rating please
oven
CONNECTION DIAGRAM
Caution! Voltage of heating elements 220-240V
Caution! In the event of any connection the safety
Wire must be connected to the E terminal.
Recommended
type of
connection
lead
1 For 220-240V earthed one-phase
connection, bridges connect 1-2-3
terminals and 4-5 terminals, safety
wire to
L1
N
PE
H05VV-F3G4
L1=R, L2=s, L3=T, N=earth terminal, PE=safety wire terminal
12 3
4
.
The connection cable must be secured in a strain-
relief clamp.For the connection leads,
the grounding wire must be longer than the other wires.
Caution!
Remember to connect the safety circuit to the connection box terminal marked with . The
electricity supply for the cooker must have an all-pole disconnection switch which enab-
les the power to be cut off in case of emergency. The distance between the working
contacts of the safety switch must be at least 3 mm.
Before connecting the cooker to the power supply it is important to read the information on
the manual.
follow the below diagram.
10 11
Control Panels

850 W
1150 W
1100 W
12

14 15
Bottom Main Multifunction Oven

16
Fig.3.1 Fig.3.2
fig.3.2
fig.3.1
17

End of cooking time
position and cancellation
To decrease the numbers
of the set cooking programme
on the digital display
To increase the numbers
on the digital display
(Only for Bottom Main Oven）
18 19
remanent
and set time to 0:00.

20
Switch off time=current time+cooking
time
and alarm signal will go off.if
signal is not turned off
be turned off
minutes.
the
alarm
manually,it will
automatically after 7 Press button1.2.3,the alarm signal will
go off,if press button 4,the alarm signal
and signal will all go off.Or if the alarm
signal is not turned off manually,it will be
turned off automatically after 7 minutes.
21
Press button1.2.3,the alarm signal will
go off,if press button 4,the alarm signal
and signal will all go off.Or if the alarm
signal is not turned off manually,it will be
turned off automatically after 7 minutes.
cooking

22
5 or 6.
5 or 6.
23
set time to
0:00, 5seconds later,the timer is
cancelled.
If the cooking time set to be 0 or the
1
2
4
3
5
Top Oven guide levels
Bottom main Oven guide levels

24
Before any maintenance is started
involving electrical parts, the
appliance must be disconnected
from the power supply.
If the oven has been in use, let the
oven cavity and the heating elements
cool down before attempting any
maintenance.
Changing the bulb
Unscrew the protective cover. We
recommend that you wash and dry the
glass cover at this point.
Carefully remove the old bulb and
insert the new bulb suitable for high
temperatures (300ºC) having the
following specifications: 230-240V,
50Hz, 25W, G9 fitting.
Refit the protective cover.
IMPORTANT
Never use screwdrivers or other
utensils to remove the light cover.
This could damage the enamel of the
oven or the lampholder. Remove only
by hand.
IMPORTANT
Never replace the bulb with bare
hands as contamination from your
fingers can cause premature failure.
Always use a clean cloth or gloves.
Please note:
The bulb replacement is not covered
by your guarantee
l
l
25
Install door

26
Models With Wire Racks
Assemble the wire racks to the oven walls using the2 screws(fig.4.1-4.2)
Slide in ,on the guides, the shelf and the tray(fig.4.3-4.4).
To dismantle, operate in reverse order.
Top oven Bottom main oven
The shelf must be fitted so that the safety catch,which stops it sliding out,
faces the inside of the oven.
27
Fig.4.1 Fig.4.2
Fig.4.3 Fig.4.4
Catalytic liners
These models contain:
2 catalytic side liners(to be fitted
by you)
Operation
The catalytic liners are coated with
a specially formulated enamel
coating,over a base of regular
enamel.This enamel coatinghas a
rough surface which is also
porous.During normal cooking,fats
and other food spatter is partially
absorbed into the surface and then
oxidised away.This oxidisation of
the fat works best if the oven is set
at high temperatures.If you do a lot
of lower temperaturebaking,say
around the normal180℃ ,then the
cleaning process may not be
complete.Every now and then you
should turn the oven on to 260℃ for
around one hour to completely
remove the soil.
Cleaning
Should the panels become heavily,
they will need to be taken out of the
oven and cleaned by hand.They
should be soaked in warm ,soapy
water for at least 2 hour sand then
rinsed with clean water ,last
NOTE: Solid cleaning powders,
creamy cleaners,caustic oven
cleaners,steel wool or other
scourers will ruin the catalytic
surface and must NEVER
BE USED.
wiped clean with a soft cloth.
TIPS INFORMATION
CAUTION
The oven must be awitched off before
removing the fan baffle,and the baffle
must be replaced in accordance with
instructions.
. Remove the 2 retaining screws on
the top edge of the fan baffle.
.Pull the top edge towards you and
then disengage to bottom tabs from
the oven back.
Note: The fan baffle must be replaced
after cleaning.into their corresponding
slots in the oven back.
.Push the top home and insert screws
firmly into appropriate holes.
.The fan baffle must not be loose.The
fan baffle must be flush with the back
wall of the oven.

28 29
● Switch off all working units of the oven
● Call the service centre
● Some minor faults can be fixed by referring to the instructions given in the table
Knob are
.

30 31

32 33

34 35
220-240V~
Z
Model
Top oven
1100W
Grill element
850W
Top element
1150W
Bottom element
Top oven power 2000W
Bottom mains
oven
/
Grill element
/
Top element
/
Bottom element
Bottom mains 2000W
2000W
Circular element
Fan
oven power
Voltage rating
D0102
