Siemens SX67ZX06CE User manual

SX67ZX06CE
Dishwasher
EN Instructions for use
Siemens Home Appliances
Register your appliance on My Siemens and
discover exclusive services and offers.

Further information and explanations can be
found online:
Table of contents
1 Security ................................... 4
1.1 General information .................... 4
7 additional functions ........................ 23
8 Equipment ................................ 24
8.1 Upper dish rack ............24
8.2 Cake stand ................................... 25
8.3 Lower dish rack ............ 25
8.4 Folding spines................................ 25
8.5 Cutlery drawer................... 26
8.6 glassZone................................ 27
1.2 Intended
use ........................................... 4
1.3 Restriction of the user
group ........................................... 4
1.4 Safe installation .................... 4
1.5 Safe use .................... 6
1.6 Damaged device.................... 8
1.7 Dangers for children................... 9 9 Before first use ............28
2 Avoid material damage .......... 11
2.1 Safe installation .................... 11
2.2 Safe use .................... 11
9.1 Initial
commissioning.................................... 28
10 Softening system................... 28
3 Environmental protection and saving ....... 12
3.1 Dispose of packaging............12
3.2 Saving energy ....................... 12
10.1 Overview of the water hardness
settings ........................... 29
10.2 Setting the softening
system................................................. 29
3.3 Zeolite drying. . . . . . . . . . . . . . 12
3.4 Sensors ................................. 13 10.3 Special salt................................ 29
10.4 Switching off the softening
system ........................... 30
4 Setting up and connecting ..... 13
4.1 Scope of delivery................................. 13 10.5 Regenerating the softening
system ........................................... 31
4.2 Setting up and connecting the
device ........................... 14 11 Rinse aid system .................... 31
11.1 Rinse aid .......................... 31
4.3 Waste water connection................. 14
4.4 Drinking water connection ............. 14
4.5 Electrical connection ............ 14 11.2 Setting the amount of rinse aid
added ............................ 32
11.3 Switching off the rinse aid
system................................................ 32
5 Getting to know each other .......................... 16
5.1 Device.................................................. 16
5.2 Controls .......................... 18 12 Cleaners ................................... 32
12.1 Suitable cleaners ............32
12.2 Unsuitable cleaners............ 33
12.3 Notes on cleaners......... 34
12.4 Filling with cleaner.................... 34
6 programs ................................ 20
6.1 Information for test institutes......... 21
6.2 Favorites
6.3 Intelligent
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2
Translated from German to English - www.onlinedoctranslator.com

13 Tableware ................................... 35 20 Customer service .......................... 57
13.1 Damage to glass and
dishes................................. 35
20.1 Product number (E-No.),
production number (FD)
and counting number (Z-No.)........ 57
13.2 Putting away the dishes.................... 36
13.3 Clearing out the dishes.............. 37 20.2 AQUA-STOP guarantee............ 57
14 Basic Operation......37
14.1 Switching on the device .................... 37
14.2 Setting the program ............. 37
14.3 Setting additional functions ......... 37
14.4 Setting the time delay ............ 38
14.5 Start the program................... 38
14.6 Interrupting the program ....... 38
14.7 Cancel program ........... 38
14.8 Switching off the device .................... 38
21 Technical data ................... 58
21.1 Information about free and open
source software .......... 58
22 Declaration of Conformity ........... 59
15 Basic settings ................ 40
15.1 Overview of the basic
settings ........................... 40
15.2 Changing basic settings... 42
15.3 Setting the time ................... 42
16 Home Connect .......................... 43
16.1 Home Connect quick start .. 43
16.2 Remote start .......................... 44
16.3 Data protection................................ 44
17 Cleaning and care ............. 45
17.1 Cleaning the rinsing container ............ 45
17.2 Cleaning agents ................... 45
17.3 Tips for device care.........45
17.4 Machine care. . . . . . . . . . . . . . . 45
17.5 Sieve system ........................... 46
17.6 Cleaning the spray arms................... 48
18 Troubleshooting ................... 49
18.1 Cleaning the waste water pump ..... 55
19 Transport, storage and
Dispose of ................................ 55
19.1 Dismantling the device ................ 55
19.2 Making the device frost-proof...... 56
19.3 Transporting the device ................ 56
19.4 Dispose of old device................... 56
3

Security
1 Security
Please note the following safety instructions.
1.1 General information
¡Read these instructions carefully.
¡Save the instructions and product information
later use or subsequent ownership.
¡Do not connect the device if it is damaged during transport.
1.2 Intended use
Use the device only: ¡to wash
household dishes.
¡in private households and in closed rooms of the home
chen environment.
¡up to an altitude of 2500 m above sea level.
1.3 Restriction of the user group
This device can be used by children aged 8 years and over and by
people with reduced physical, sensory or mental capabilities or lack
of experience and/or knowledge, if they are supervised or
instructed in the safe use of the device and understand the
resulting dangers have.
Children are not allowed to play with the device.
Cleaning and user maintenance must not be carried out by
children without supervision.
Keep children younger than 8 years away from the device and the connecting
cable.
1.4 Safe Installation
WARNING - Risk of injury!
Improper installations can result in injury.
▶When setting up and connecting the device, follow the instructions in
the operating instructions and assembly instructions.
4

Security
WARNING - Risk of electric shock!
Improper installations are dangerous.
▶Only connect and operate the device in accordance with the
information on the nameplate.
▶Always use the power cable supplied with the new device.
▶Only connect the device to an alternating current power supply
via a properly installed earthed socket.
▶The protective conductor system of the electrical house
installation must be installed correctly.
▶Never power the device via an external switching device,
e.g. B. timer or remote control.
▶When the device is installed, the mains plug of the mains
connection cable must be freely accessible, or if free access is not
possible, a disconnecting device must be installed in the fixed
electrical installation in accordance with the installation
regulations.
▶When setting up the device, ensure that the power cable is
not pinched or damaged.
Cutting the inlet hose or submerging the Aquastop valve in
water is dangerous.
▶Never immerse the plastic housing in water. The plastic housing
on the inlet hose contains an electric valve.
▶Never cut the inlet hose. There are electrical connection cables
in the inlet hose.
WARNING - Danger of fire!
Using an extended power cord and unauthorized adapters is
dangerous.
▶Do not use extension cables or multiple socket strips.
▶Only use adapters and power cables approved by the
manufacturer.
▶If the mains connection cable is too short and a longer mains
connection cable is not available, contact a specialist electrician
to adapt the house installation.
5

Security
Contact between the device and installation cables can lead to a
defect in the installation cables, e.g. E.g., gas pipes and power
lines. Gas from a corroded gas line can ignite. A damaged power
line can lead to a short circuit.
▶Make sure that there is at least 5 cm distance between the
device and installation cables.
WARNING - Risk of injury!
Hinges move when the appliance door is opened and closed and
can cause injury.
▶If under-counter devices or devices that can be integrated are
not located in a niche and a side wall is therefore accessible, the
hinge area must be covered on the side. The covers are available
from specialist retailers or from our customer service.
WARNING - Danger of tipping!
Improper installation may cause the device to tip over.
▶Only install under-counter devices or integrable devices under a
continuous worktop that is firmly connected to the neighboring
cabinets.
1.5 Safe use
WARNING - Danger of serious damage to health! Failure to
follow safety instructions and instructions for use on the
packaging of cleaning products and rinse aid products can lead to
serious damage to health.
▶Follow the safety instructions and instructions for use on the
packaging of cleaning products and rinse aid products.
WARNING - Danger of explosion!
Solvents in the device's flushing chamber can cause explosions.
▶Never put solvents in the cleaning compartment of the device.
6

Security
Strongly caustic-alkaline or highly acidic cleaning agents in conjunction
with aluminum parts in the washing compartment of the device can lead
to explosions.
▶Never use highly caustic-alkaline or highly acidic cleaning agents,
especially from the commercial or industrial sector, in conjunction
with aluminum parts (e.g. grease filters from extractor hoods or
aluminum pots), e.g. B. for machine care.
WARNING - Risk of injury! An open device door
can lead to injuries.
▶Only open the appliance door when loading and unloading
dishes to prevent accidents, e.g. B. by stumbling.
▶Do not sit or stand on the open appliance door. Knives and
utensils with sharp points can cause injuries.
▶Place knives and utensils with sharp tips with the pointed side
facing down in the cutlery basket, knife rack or cutlery drawer.
WARNING - Danger of scalding!
Hot water can spray out of the appliance when the appliance door is
opened while the program is running.
▶Open the device door carefully while the program is running.
WARNING - Risk of electric shock!
Penetrating moisture can cause an electric shock.
▶Only use the device in closed rooms.
▶Never expose the device to extreme heat or moisture.
▶Do not use a steam cleaner or high-pressure cleaner to clean
the device.
Damaged insulation of the mains connection cable is dangerous.
▶Never bring the power cord into contact with hot parts of the
device or heat sources.
▶Never bring the power cord into contact with sharp points or
edges.
7

Security
▶Never bend, squeeze or change the power cable.
WARNING - Danger of burns!
The blow-out opening of the zeolite container becomes hot and
can cause burns.
▶Never touch the blow-out opening of the zeolite container.
1.6 Damaged device
WARNING - Risk of electric shock!
A damaged device or a damaged power cable is dangerous.
▶Never operate a damaged device.
▶Never operate a device with a cracked or broken surface.
▶Never pull on the power cord to disconnect the device from the
power supply. Always pull on the mains plug of the mains
connection cable.
▶If the device or the mains connection cable is damaged,
immediately pull out the mains plug of the mains connection
cable or switch off the fuse in the fuse box and close the tap.
▶Call customer service. →
Page 57 Improper
repairs are dangerous.
▶Only trained specialist personnel may carry out repairs on the
device.
▶Only original spare parts may be used to repair the device.
▶If the mains connection cable or the device connection cable of
this device is damaged, it must be replaced with a special power
connection cable or special device connection cable, which is
available from the manufacturer or its customer service.
8th

Security
1.7 Dangers for children
WARNING - Danger of suffocation!
Children can pull packaging material over their heads or wrap
themselves in it and suffocate.
▶Keep packaging material away from children.
▶Do not let children play with packaging materials. Children
can inhale or swallow small parts and thereby suffocate.
▶Keep small parts away from children.
▶Do not let children play with small parts.
Children can become trapped in the device and suffocate.
▶If available, use parental controls.
▶Never let children play with or operate the device.
WARNING - Danger of damage to health!
Children can become trapped in the device and endanger their
lives.
▶For old devices, pull the power plug of the power connection
cable, then cut the power connection cable and destroy the lock
on the device door to such an extent that the device door no
longer closes.
WARNING - Danger of crushing!
With high-mounted appliances, children can squeeze between the
appliance door and the cupboard doors underneath.
▶Pay attention to children when opening and closing the appliance door.
WARNING - Danger of chemical burns!
Rinse aid and cleaners can cause burns to the mouth, throat and
eyes.
▶Keep children away from rinse aid products and cleaning products.
▶Keep children away from the open device. The water in the
dishwashing room is not drinking water. There may still be
residues of cleaner and rinse aid in it.
9

Security
WARNING - Risk of injury!
Children can get their little fingers caught in the slots in the tab
tray and injure themselves.
▶Keep children away from the open device.
10

avoid
v2
avoid Contact between the device and
water pipes may cause corrosion of
the water pipe and the water pipe
may leak.
▶Make sure there is at least 5 cm
distance between the device and
the water pipe. The supplied lines
for the drinking water connection
and the waste water connection are
not affected.
Modified or damaged water hoses
can lead to property damage and
equipment damage.
▶Never bend, squeeze, alter or cut
water hoses.
▶Only use the water hoses supplied
or original replacement hoses.
▶Never reuse used water hoses.
If the water pressure is too low or too
high, the device function can be
impaired.
▶Ensure that the water pressure at
the water supply system is at least
50 kPa (0.5 bar) and maximum
1000 kPa (10 bar).
▶If the water pressure exceeds the
specified maximum value, a
pressure reducing valve must be
installed between the drinking
water connection and the hose set
of the device.
Property damage
avoid
avoid
2.1 Safe Installation
DANGER!
Improper installation of the device
can result in damage.
▶If the dishwasher is installed under
or above other household
appliances, information on
installation in combination with the
dishwasher in the
Follow the installation instructions for the
respective household appliances.
▶If no information is available or the
installation instructions do not
contain any relevant instructions,
you must contact the manufacturer
of these household appliances to
ensure that the dishwasher can be
installed above or below other
household appliances.
▶If information is not available from
the manufacturer, the dishwasher
must not be installed above or
below these household appliances.
▶To ensure the safe operation of all
household appliances, continue to
follow the dishwasher installation
instructions.
▶Do not install the dishwasher
under a hob.
▶Do not install the dishwasher near
heat sources such as radiators, heat
accumulators, ovens or other
devices that generate heat.
2.2 Safe use
DANGER!
Escaping steam can damage built-in
furniture.
▶After the end of the program, allow the
device to cool down slightly before
opening the device door.
11

Environmental protection and saving
Special salt for dishwashers can
damage the washing container
through corrosion.
▶To ensure that overflowed special
salt is rinsed out of the rinsing
container, fill the special salt into the
special salt storage container
immediately before the program
starts.
Cleaner can damage the softening
system.
▶Only fill the storage container of
the softening system with special
salt for dishwashers.
Unsuitable cleaning agents can
damage the device.
▶Do not use a steam cleaner.
▶To avoid scratching the device
surface, do not use sponges with a
rough surface or abrasive cleaning
agents.
▶To avoid corrosion, do not use
sponge cloths on dishwashers with
stainless steel fronts or rinse them
thoroughly several times before
first use.
3.2 Save energy
If you follow these instructions, your
device will use less electricity and
water.
Use the Eco 50° program.
aThe Eco 50° program is energy-
energy-saving and environmentally friendly.
→
"Programs", page 20
Change the sensor setting to
standard.
aThe consumption values are reduced
adorned.
→
"Sensors", page 13
Zeolite drying automatically helps
save energy.
a→ "Zeolite drying ",
page 12
3.3 Zeolite drying
The device is equipped with a zeolite
container. Energy can be saved with
zeolite drying.
Zeolite is a mineral that can store
and release moisture and heat
energy.
In the cleaning step, heat energy is
used to heat the rinse water and dry
the mineral.
During the drying phase, moisture
from the washing compartment is
stored in the mineral and heat energy
is released. The heat energy is blown
out into the washing room with dry
air. This enables quick and improved
drying.
Zeolite drying is therefore very
energy-saving.
3 environmental protection and
Save
3.1 Dispose of packaging
The packaging materials are
environmentally friendly and recyclable.
▶Dispose of the individual components
separately according to type.
12

Setting up and connecting
Tip:In order not to impair the
functionality of the zeolite drying, do
not place any dishes directly in front
of the suction opening and blow-out
opening of the zeolite container.
Do not place any temperature-sensitive
dishes directly in front of the blow-out
opening of the zeolite container.
→
"Device", page 16
Sensor level description
niger or eco-cleaning
ger with low
Amounts of active ingredients.
The energy consumption
needs and water
consumption is
speaking
fits.
3.4 Sensors 4 Set up and
Connect
The sensors adapt the program
sequence and the program strength in
the auto programs depending on the
amount and type of dirt.
The sensors have different sensitivity
levels, which you can change in the
basic settings.
→
""Change basic settings", page
42
To ensure proper operation, connect
the device to electricity and water
properly. Please note the required
criteria and the assembly
instructions.
4.1 Scope of delivery
Sensor level
default
Description After unpacking, check all parts for
transport damage and that the
delivery is complete.
If you have any complaints, please
contact the retailer where you
purchased the device or our customer
service.
Optimal setting
for mixed loads
and high levels of dirt
amounts. energy saving
efficient and water saving
rend.
Sensitive Does the program
strength even with
small amounts of dirt
conditions for
effective elimination
leftover food. The
power consumption
and water consumption
needs will be
adapted accordingly.
A notice:The device was checked at the
factory to ensure that it functions
properly. This may leave water stains
on the device. The water stains
disappear after the first rinse.
The delivery consists of: ¡
dishwasher
¡Instructions for use
¡assembly Instructions
¡Further information documents ¡
Mounting material
¡Steam protection plate
¡Salt filling aid funnel ¡
Power cord
¡quick start Guide
Very recommended
findable
Does the program
strength for difficult ones
Terms of use
gen, e.g. B. very
dried food
sereste. Recommended
Setting when
use of organic rice
13

3.Make sure that the drain hose is not
kinked, crushed or twisted.
Setting up and connecting
4.2 Set up and connect the
device
You can install your under-counter
device or integrated device in the
kitchen unit between wooden walls
and plastic walls. If you subsequently
set up your device as a free-standing
device, you must secure your device
against tipping over, e.g. B. by
screwing on the wall or by installing it
under a continuous worktop that is
firmly connected to the neighboring
cabinets.
1.Follow the safety instructions.
→
page 4
4.Make sure that there is no cover in
the drain that prevents the waste
water from flowing out.
4.4 Drinking water connection
Connect your device to a drinking
water connection.
Install drinking water connection
Hints
¡Make sure you do that
Connect the device to a water inlet
with a safety device to prevent
drinking water contamination
through backflow (according to DIN
EN 1717). The connection valves/
water taps provided for this purpose
are equipped with this safety device
if the house is installed correctly.
¡If you replace the device,
you must use a new water inlet
hose.
2.Follow the instructions for electrical
connection.
3.Check the scope of delivery and
the condition of the device.
4.Take the required installation dimensions
from the assembly instructions.
5.Set up the device horizontally using
the adjustable feet.
Make sure you have a secure footing.
6.Install the waste water connection.
→
Page 14
1.Please refer to the assembly
instructions provided for the
necessary steps.
7.Install the drinking water
connection. →
Page 14
8th.Connect the device to power. 2.Connect the device to the drinking
water connection using the
included parts.
4.3 Waste water connection
Connect your device to a wastewater
connection so that water
contaminated by the rinse cycle can
drain away.
Observe the technical data.
3.Make sure that the drinking water
connection is not kinked, crushed or
twisted.
Install waste water connection
1.Please refer to the assembly
instructions provided for the
necessary steps.
4.5 Electrical connection
Connect the device electrically
2.Connect the waste water hose to
the drain connection of the siphon
using the included parts.
Hints
¡Observe the safety instructions
wise →
page 4 .
14

Setting up and connecting
¡Please note that the water
Safety system only works when
there is power supply.
1.Insert the cold appliance plug of the
mains connection cable into the
device.
2.Plug the power plug of the device's
power cord into a socket near the
device.
The connection data of the
device is on the nameplate.
3.Check that the power plug is firmly
seated.
15

Get to know
5 Getting to know each other
5.1 Device
Here you will find an overview of the components of your device.
9
8th
710
11
12
13
6
5
414
3
2
1
15
1type label Type plate with E number and FD number
→
Page 57 .
You need the data for customer service →
Page 57 .
1Depending on the device equipment
16

Get to know
2Cleaner chamber Fill the cleaner chamber with cleaner.
→
"Cleaner", page 32
3Lower dish rack Lower dish rack →
Page 25
4Storage container for special
salt
Fill the special salt storage container with
special salt.
→
"Softening system", page 28
5Lower spray arm The lower spray arm cleans the dishes in
the lower basket.
If the dishes are not being cleaned
optimally, clean the spray arms.
→
"Cleaning spray arms", page 48
6Tab drip tray During the rinsing cycle, tabs automatically
fall from the detergent chamber into the
tab collecting tray, where they can dissolve
optimally.
7Upper dish rack
Cutlery drawer
EmotionLight
Cake stand1
Upper spray arm
Upper dish rack →
Page 24
Cutlery drawer → Page 26
Interior lighting of the device.
Cake stand → Page 25
8th
9
10
11 The upper spray arm cleans the dishes in
the upper basket.
If the dishes are not being cleaned
optimally, clean the spray arms.
→
"Cleaning spray arms", page 48
12 Intake opening of the Zeo
lith container
The suction opening is for zeolite drying
→
page 12 needed.
13 Blow-out opening of the
zeolite container
The blow-out opening is used for zeolite
drying →
page 12 needed.
14 Sieve system Sieve system →
Page 46
15 Rinse aid reservoir Fill the rinse aid reservoir with rinse aid.
→
"Rinse aid system", page 31
1Depending on the device equipment
17

Get to know
5.2 Controls
You can use the control panel to set all of your device's functions and receive
information about its operating status.
Some buttons allow you to perform various functions.
1 2 3 4 5 6 7 8 9 10
16 15 14 13 12 11
1ON/OFF button
button
and reset Switch on device →
Page 37 Switch
off device →
Page 38 Cancel
program →
Page 38
2Program buttons
Info button
Programs →
Page 20
3When you press, the display shows
information about selected
programs, additional functions and
basic settings.
If you press about 3 seconds, you will
open the menu.
→
""Change basic settings", page
42
4Cl
Special salt refill indicator
Remote start display1
arsrinsing hfüac llane.gowne Ks
→
"Filling with rinse aid", page 31
lar puleranlage
5Softening
→
"Spec
ng system
ial salt egg
e
nfill", page 29
6If you have activated the function
d
c
G
U.N theres Control the device via the Home
Conpp, the indicator lights up
m device.
no t A
zei ea
7Wi-Fi display
1Depending on the device version
owne Home Connect →
Spage 43
tatdo G
18

Get to know
8th Time delay
Remote start
Set time delay →
Page 38
→ "Remote Start", page 44
9
10 Program buttons and additional
functions
programs
→
"Programs", page 20
Additional functions
→
"Additional functions", page 23
11 Start button
Keys
Start program →
Page 38
12 Use these buttons to scroll
between the basic settings.
→
""Change basic settings", page
42
13 Setting buttons Change basic settings→
""Change
basic settings", page 42
14 Door handle1
display1
Open the device door.
15 The display shows you information
about programs, additional functions
or basic settings. You can change the
basic settings using the display and the
setting buttons.
16 display The display shows you information
about programs, additional functions
or basic settings. You can change the
basic settings using the display and the
setting buttons.
→
""Change basic settings", page
42
1Depending on the device equipment
19

programs
6 programs
Here you will find an overview of the
adjustable programs. Depending on
the device configuration, various
programs are available, which you
can find on the control panel of your
device.
Depending on the program you choose,
the duration may vary. The running time
depends on the water temperature, the
amount of dishes, the degree of soiling
and the additional function selected →
Page 23 away. When off
If the rinse aid system is switched on or if
there is a lack of rinse aid, the running time
changes.
You can find the consumption values
in the quick guide. The consumption
values refer to normal conditions and
a water hardness value of 13
- 16 °dH. Different influencing factors
can lead to deviations, e.g. B. Water
temperature or line pressure.
program use Program Sequence
Dishes:
¡Pots, pans, insensitive
ches crockery and cutlery
Degree of soiling:
¡strongly sticking, burned-in,
Dried, starchy and protein-
containing leftover food
Intensive:
¡Pre-rinse
¡Clean 70°C ¡
Intermediate rinsing
¡Rinse 50 °C ¡dry
Intense 70°
Dishes:
¡mixed dishes and dishes
plug
Degree of pollution:
¡slightly dried, household
usual leftovers
Sensor-optimized:
¡Becomes dependent on
of pollution
of the rinse water
optimized by sensors
mingled.
Auto 45-65°
Dishes:
¡mixed dishes and dishes
plug
Degree of pollution:
¡slightly dried, household
usual leftovers
Most economical pro
gram:
¡Pre-rinse
¡Clean 50°C ¡
Intermediate rinsing
¡Rinse 35 °C ¡dry
Eco 50°
Dishes:
¡mixed dishes and dishes
plug
Degree of pollution:
¡slightly dried, household
usual leftovers
Noise-optimized:
¡Pre-rinse
¡Clean 50°C ¡
Intermediate rinsing
¡Rinse 35 °C ¡dry
Quiet 50
1Factory setting
20
