1 2 3 4 5 6
End of programme as soon as the \(finished/anti-crease) indicator light flas hes
Interrupting the programme Loading or removing l aundry
The drum and door m ay be hot.
The drying programme can be i nterrupted briefly for loading or removing l aundry. The selected
programme must then cont inue to run to the end.
1. Open the door; the d rying process is interrupted.
2. Load or remove laundr y and close the door.
3. If required, select a new prog ramme and additional functions.
4. Press the Start button.
Cleaning the fluff filter
Clean the fluff filter after each drying cycle.
1. Open the door and pull out th e fluff filter.
2. Remove the fluff (brush your hand o ver the fluff filter).
If the fluff filter is very dirty or blocked, wash it out with warm water and
dry thoroughly.
3. Insert the fluff filter so that you hear it engage.
4. Remove fluff from door/door area.
Switching off the dryer
Turn the programme selector to Off.
Do not leave laundry in the dryer.
Removing the laundry
Your dryer has an automatic anti-crease function. The drum is move d at set intervals for 30 minutes after
the programme has ended. Laundry remains loose and fluffy (for 90 minutes, if additional Ì(Easy-Iron)
function is selected - depending o n model).
... and adapt to individual requirements
Never operate the dryer if it is damaged.
Inform your after-sales service . Inspecting
the dryer
Sorting and loading laundry
Remove all objects from pockets.
Pay particular attention to cigarette lighters.
The drum must be em pty before filling.
Your new dryer
Congratulations - You have c hosen to buy a moder n, high-quality
Siemens domestic appliance.
A distinctive feature of your dryer is its low energy c onsumption.
Every dryer which leaves our factory is carefully chec ked to ensure
that it functions correctly and is in perfect condition.
Should you have any questions, our after-sales service will be ple ased
to help.
Environmentally responsible disposal
Dispose of packaging in an environmentally-responsible man ner.
This appliance is designa ted according to European directiv e 2002/96/EC which governs was te electrical and electronic
equipment (WEEE).
This directive provides the fr amework for the EU-wide co llection and
reuse of used appliances.
For further information about our p roducts, accessories, spare parts
and services, please visit: www .siemens-home.com
Intended use
Contents Pa ge
ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2
ʋSetting the programmes . . . . . . . . . . . . . 2
ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4
ʋNotes on laundry . . . . . . . . . . . . . . . . . . 5
ʋCare and cleaning . . . . . . . . . . . . . . . . . . 6
ʋOverview of programmes . . . . . . . . . . . . 7
ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . 8
ʋTechnical data . . . . . . . . . . . . . . . . . . . . 9
ʋOptional accessories . . . . . . . . . . . . . . . . 9
ʋWhat to do if... / After -sales service . . . . 10
ʋSafety instructions . . . . . . . . . . . . . . . . 11
Preparing for installation, see page 8
Selecting and adjusting the programme
Drying
Control panel
Care and cleaning
Dryer housing, control panel
– Wipe off with a soft, damp cloth.
– Do not use abrasi ve cleaners or solvents.
– Remove detergent a nd cleaning agent re sidue immediately.
Exhaust air duct
Check the exhaust air duct. Clean the exhaust air duct every si x months.
Do not bend the ex haust air duct.
1. Switch off the d ryer and allow it t o cool down.
2. Disconnect the mains plug.
3. Remove the exha ust air duct.
4. Clean the exhaus t air duct.
5. Refit the exhau st air duct aInstallat ion instructions for exhau st air duct.
Moisture sensors
The dryer is equipped with stainl ess steel moisture sensors.
Moisture sensors measure the m oisture level of the laundry.
After sustained, repeated ope ration, a fine layer of limescale may form
on the moisture sensors.
1. Open the door.
2. Clean the moisture sensors using a slightly damp sponge with a rough
surface.
Do not use steel wool or abrasive m aterials.
Select the drying programme ...
Press the Start button
1
2
3
Only if your hands are dry.
Only hold the plug by the plug
casing.
Connecting the
mains plug
Drying
Notes on laundry ...
Labelling of fabrics
Follow the manufacturer's care instr uctions.
(Drying at a normal te mperature.
'cDrying at a lower temp erature ain addition, select (Gentle).
)cDo not machine dry.
Be sure to follow the safety instruc tions apage 11!
For example, do not use the dryer for th e following fabrics:
– Airtight fabrics (e.g. rubber-coated fabrics).
– Delicate materials (silk, curtains made from synthetic material) athey may crease.
– Laundry contami nated with oil.
Before drying for the first time
– Do not put any laundry in the machine. Turn the programme selector to Zeitprogramm
(timer programme) (apage 7) and select Start. At the end o f the programme, turn the
programme selector to Off.
Drying tips
– To ensure a consiste nt result, sort the laundry by fabric type a nd drying programme.
– Always dry very small fabrics (e.g. baby socks) together with large items of laundry
(e.g. hand towels).
– Fasten zips, hooks and eyel ets, button covers and tie together cloth b elts, bands, etc.
– Do not overdry easy-care laundry arisk of creasing
Allow laundry to finish drying in th e air.
– Do not iron laundry immediately after drying, fold items up and leave for a while
athe remaining moisture w ill then be distributed evenl y.
– K nitted fabrics (e.g. T-shirts, jerseys) often shrink slightly the first time th ey are tumble-dried.
aDo not use the Cupbord Dry Plu s ++programme.
– Starched laun dry is not always s uitable for dryers astarch le aves behind a coating that
adversely affects the drying operation.
– When washing the laundry that is to be tumble-dried, measure the fabric softener in
accordance with the manufacture r's instructions.
– Using a timer pr ogramme with a small laundry lo ad aoptimisation of the d rying result.
Environmental protection / Energy-saving tips
– Before drying, spin the la undry thoroughly in the washing machine athe hig her the spin
speed, the shorter the drying ti me will be (consumes less energy), also spin easy-care
laundry.
– Use the maximum re commended fill level but do not ov erload with laundry
aoverview of programmes, p age 7.
– Make sure the room is well ventilated during drying.
– Clean the fluff filter a fter every drying cycle apage 4.
Only when the applianc e is
switched off.
Drum
Only operate the dryer with t he
fluff filter inserted.
Fluff filter
ʋexclusively for domestic u se,
ʋonly for drying fabrics which have been washed u sing
water.
Do not leave children unsup ervised near the dryer.
Keep pets away from the dryer.
The dryer may be oper ated by children from
8 years of age, by persons who have limited
physical, sensory or mental abilities and by
persons who have inad equate experience or
knowledge, provided they a re supervised or
have been instructed by a respon sible person.
For a detailed programme o verview, apage 7.
Before using the dryer for the first time
run the drying cycle without any la undry apage 7.
Service/Status
indicators/
Additional functions
Programme selector ˎÌ(Easy-Iron) Reduces creasin g and prolongs the anti-creasing phase after the pro gramme
has finished.
ˎ(Gentle) Reduced temperatur e for delicate fabrics ', e.g . polyacrylic, polyamide, elastane
or acetate; for longer drying times.
bfinished/anti-crease
Clean ¡°;Flashes aclean the fluff filter, check the ex haust air duct apage 6.

7
Programme overview see also page 5
Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying. After drying, laundry is to be ...
c
ironed

lightly ironed
@c
not ironed
c
mangled
PROGRAMMES TEXTILE TYPE AND INF ORMATION **ÊCottons max. 6 kg Hard-wearing fabrics, boil-pro of fabrics made of cotton o r linen.
**ÏSynthetics max. 3 kg Non-iron laundry made of syn thetic fibres and mixed fabric, easy-care cotton .
ÔIron Dry c÷@c The condition of the laundry means it is suitable for ironing (iron clothes in order to avoid creases).
+Cupboard Dry @For single-layered laundry. *++ Cupboard Dry Plus @For laundry with thick, multi-layered parts.
Timed Program
warm 60’
max. 3 kg Pre-dried, multi-layered, sensitive fabrics made of acrylic fibres, or separate small i tems of laundry. Also for subsequent drying.warm 40’
warm 20’ cold 20’ max. 3 kg All types of fabrics. For freshening up or airing of items of laundry tha th ave been worn for a short period of time.
*only for the ÊCottons programme
**Dryness levels can be s elected individually a++Cupboard Dry Plus, +Cupboard Dry and ÔüIron Dry
(depending on the mod el). Degree of dryness can be finely adjusted; mult i-layered textiles require a lo nger drying time than si ngle-layered items of clothing. Recommendation: Dry separatel y
9204 / 9000779060 *779060* Siemens Electrogeräte GmbH
Carl-Wery-Str. 34
81739 München/Germany
WT34A101IN
8
Installation
– Scope of delivery: dryer, in struction manual and installation instructio ns.
– Check dryer for transpo rt damage.
– The dryer is very heav y. Do not lift without assistance.
– Be careful to avoid sharp edges.
– Do not lift the d ryer by protruding parts (e.g . the door) - risk of break age.
– Do not install in a room whe re there is a risk of freezing.
Freezing water can cause damage.
– If in doubt, have t he appliance connected by a specialist.
Setting up the dryer
– The mains plug must alwa ys be accessible.
– Ensure that the appliance is installed on a clean,
level and firm surface.
– Install the exhaust ai r duct
a Installation
instructions for exhaust air duct.
– Keep the area ar ound the dryer clean.
– Level the drye r using the front threaded feet.
On no account remove t he threaded feet.
Mains conn ection For safety instr uctions, a page 11.
– Connect to an AC earthed socket. If in doubt ha ve the socket checked by a specialist.
– The mains voltage and th e voltage shown on the rating plate (
a page 9) must be the
same.
– The connected load and necessary fuse pro tection are specified on the ra ting plate.
1.
Remove all accessories
from the drum. The drum
must be empty.
Clean and level
2.
Do not install the dryer behind a door or
sliding door which could prev ent or
obstruct the dryer door from opening.
This will prevent children from lock ing
themselves in and risking their live s.
9
Technical data
ʠDimensions (DxWxH) 60 x 60 x 85 cm
Weight approximately 35 kg
Max. capacity 6 kg
Ambient temperature 5 - 35 °C
Connection voltage 220 - 240 V
Connected load 2200 W
Fuse protection 10 A
Product number
a Rating plate or inside of the door
Production number
You can find the rating plate on the back of the dryer.
ʠConsumption ra tes These are guide values determ ined under standard
conditions. Deviations of up to 10% are possible.
Spin speed rpm
(residual moisture)
Drying time** in
min incl. 8 min
cooling time
Energy
consumption**
in kWh
ÊCottons 6 kg
+cCupboard Dry* 1400 (approx. 50 %) 100 3.00
1000 (a pprox. 60 %) 120 3.38
800 (approx. 70 %) 140 4.00
ÔüIron Dr y* 1400 (a pprox. 50 %) 78 2.00
1000 (a pprox. 60 %) 93 2.00
800 (approx. 70 %) 108 3.00
ÏSynthetics 3 kg
+cCupboard Dry* 800 (approx. 40 %) 44 1.00
600 (approx. 50 %) 55 1.00
*Test programmes according to DIN EN 61121.
**The values may diverge from those specified dependin g on overvoltage and undervoltage,
fabric type, composition of the la undry to be dried, residual moistur e in the fabric and the
amount of the load.
Optional accessories (order from the after-sal es service using the order number)
Exhaust air duct set (according to mod el)
The exhaust air is extracted via a h ose.
Washer-dryer stack connec tion set
The dryer can be placed o n top of a suitable washin g machine with the same width a nd depth
to save space.
The dryer must be fastened to th e washing machine using this connec tion set.
WZ
20180
WZ
20311
10
What to do if ...
If you cannot rec tify a fault yourse lf (e.g. switching off/o n), please contact o ur after-sales
service. We will a lways find an a ppropriate solution an d will avoid unnece ssary visits by
engineers. Trust t he expertise of the m anufacturer and rest ass ured that the repair w ill be
carried out by t rained service tech nicians using original sp are parts. The c ontact details of your
local after-sales se rvice can be found in the enclose d after-sales service direct ory, or by
calling one of these numbers:
–GB 0844 8928999 (Calls from a B T landline w ill be charge d at up to 3 pe nce per mi nute.
A call set-u p fee of up to 6 pence may apply. )
–IE 01450 2655
When contacting the after-sales service, pleas e quote the appliance's produ ct number (E no.)
and production nu mber (FD) (see the i nside of the door).
Set the progra mme selector to Off a nd remove the applia nce plug from the sock et.
ʠStart indicator light do es not
light up.
Mains plug plugged in?
Programme selected?
Check the sock et fuse.
ʠClean ¡°;indicator ligh t flashes. C lean the fluff filter
a page 4.
Exhaust air duc t blocked or ben t?
Clean the exhau st air duct
a page 6.
If necessary, clean the insect screen on the exhaust air
pipe.
ʠDryer does not sta rt. Start button pressed?
Door closed?
Programme set?
ʠProgramme termin ated shortly after
starting.
Ambient temperatu re greater than 5 ° C?
ʠWater is leaking out. Make sure the dryer is level.
ʠThe door opens by itself. Push the door closed until you hear it enga ge.
ʠThe required degree of dryness
was not ach ieved or the drying time
was too long.
Clean the fluff filt er
a page 4.
Ambient temperatur e higher than 35 ° C
a ventilate the
room.
Unsuitable programme selecte d?
a page 7.
Dryer installed to o closely to other object s? Provide
adequate air circulation .
Mains failure
a Restart the dryer.
Fine layer of limescale on the m oisture sensors. Clean the
sensors
a page 6.
ʠLaundry damp. Use the next drying programme up or the timer
programme
a page 7.
Warm laundry f eels damper than it rea lly is!
ʠThe humidity in the room has
increased significantly.
Make sure th e room is sufficiently v entilated.
ʠOne or more indicator lights are
flashing.
Clean the fluff filt er a page 4.
Check the instal lation conditions
a page 8.
Exhaust air duc t blocked or ben t?
Clean the exhau st air duct
a page 6.
Switch off, allow t o cool, switch back o n and restart the
programme.
ʠPower cut. Remove the laun dry from the drye r immediately and
spread it out. H eat may escape.
ʠCondensation in t he exhaust air
duct.
Exhaust air duct t oo long? Check the maximum exhaus t air
duct length. Furthe r information a Installation instructions
for exhaust air duc t.
11
Safety instructions
Emergency – Pull the mains plug o ut of the socket immediately or discon nect the fuse.
ONLY use the
dryer...
– in rooms inside the hou se.
– for drying fabrics.
The dryer must
NEVER...
– be used for other purposes than those described above.
– be modified in terms of its technology o r attributes.
Dangers – The dryer must not be used by children or persons who h ave not been
instructed in its use.
– Do not l eave children unsuper vised near the drye r.
– Keep pets away f rom the dryer.
– Remove all ob jects from the pockets of garments.
Pay particular attention to cigarette lighters
a risk of explosion
– Do no t lean or sit on the door
a risk of tipping.
– Open the door w ith care. Hot steam may escap e.
Installation – Fasten down loose l eads a risk of tripping
– Do not operate the dr yer where there is a risk of frost.
– The safety informatio n in the separate installation instructions for the exhaust
air duct must be observed without fail.
Mains
connection
– Connect the dryer to an AC ear thed socket according to specifications, as
otherwise it cannot be guaranteed that the appliance is completely safe.
– The cable cross-secti on must be sufficient.
– Only use earth-leakage circuit breakers with the following symbol:
– The mains plug and socket must be compatible.
– Do not u se multiple plugs/cou plings and/or extension ca bles.
– D o not touch or hold the mains plug with wet hands
a risk of electric shock.
– Never pull the mains plug out of the soc ket by its cable.
– Do no t damage the mains l ead
a risk of electric shock.
Operation – Only load the drum with items of laundr y.
Check what has bee n loaded before switching th e dryer on.
– Do no t use the dryer if the laundry ha s been in contact with solvents, o il, wax,
grease or paint (e.g. hair setting spr ay, nail polish remover, stain remover,
cleaning solvent, etc.)
a fire/explosion hazard.
– Dust danger (e.g. coal dust or flour): do no t use the dryer
a risk of explosion.
– Do n ot put laundry containing foamed mate rial/rubber in the dryer
a elastic
material may be destroyed and th e dryer may be damaged due to pos sible
deformation of the foamed material.
– Switch off the dryer once the programme has ended.
Defect – Do not use the dryer if it is defective or if you suspect that it is.
Repairs must only be carrie d out by the after-sales service.
– Do not use the dryer w ith a faulty mains cable. In order to avoid r isk, have the
mains lead replaced on ly by our after-sales service.
Spare parts – Only use genuine spare parts and accessories for safety reasons.
Disposal – Dryer: Disconnec t the mains plug, then cut th e mains cable off the a ppliance.
Dispose of the appliance at a p ublic disposal site.
– Packaging: Do not allow children access to items of packaging
a risk of suffocation
– All materials are e nvironmentally friendly and reu sable. Dispose of in an
environmentally responsible m anner.
Installation and
operating instructions
Tumble dryer
en
Read the instruction manual a nd installation instructions
before operating the dryer.
Observe the safety
instructions on page 11.

1 2
\Ì... and adapt to individual requirements
Never operate the dryer if it is damaged.
Inform your after-sales service.
Sorting and loading laundry
Remove all objects from pockets.
Pay particular attention to cigarette lighters.
The drum must be empty before filling.
Your new dryer
Congratulations - You have chosen to buy a modern, high-quality
Siemens domestic appliance.
A distinctive feature of your dryer is its low energy consumption.
Every dryer which leaves our factory is carefully checked to ensure
that it functions correctly and is in perfect condition.
Should you have any questions, our after-sales service will be pleased
to help.
Environmentally responsible disposal
Dispose of packaging in an environmentally-responsible manner.
This appliance is designated according to European directive 2002/96/EC which governs waste electrical and electronic
equipment (WEEE).
This directive provides the framework for the EU-wide collection and
reuse of used appliances.
For further information about our products, accessories, spare parts
and services, please visit: www.siemens-home.com
Intended use
Contents Page
ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2
ʋSetting the programmes . . . . . . . . . . . . . 2
ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4
ʋNotes on laundry . . . . . . . . . . . . . . . . . . 5
ʋCare and cleaning . . . . . . . . . . . . . . . . . . 6
ʋOverview of programmes . . . . . . . . . . . . 7
ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . 8
ʋTechnical data . . . . . . . . . . . . . . . . . . . . 9
ʋOptional accessories . . . . . . . . . . . . . . . . 9
ʋWhat to do if... / After-sales service . . . . 10
ʋSafety instructions . . . . . . . . . . . . . . . . 11
Preparing for installation, see page 8
Selecting and adjusting the programme
a
Select the drying programme ...
Press the Only if your hands are dry.
Only hold the plug by the plug
casing.
Connecting the
mains plug ('ca)caaaaaa+aaaaa
Only operate the dryer with the
fluff filter inserted.
ʋexclusively for domestic use,
ʋonly for drying fabrics which have been washed using
water.
Do not leave children unsupervised near the dryer.
Keep pets away from the dryer.
The dryer may be operated by children from
8 years of age, by persons who have limited
physical, sensory or mental abilities and by
persons who have inadequate experience or
knowledge, provided they are supervised or
have been instructed by a responsible person.
For a detailed programme overview, aBefore using the dryer for the first time
run the drying cycle without any laundry a
Service/Status
indicators/
Additional functions
Programme selector ˎÌ(Easy-Iron) Reduces creasing and prolongs the anti-creasing phase after the programme
has finished.
ˎ(Gentle) Reduced temperature for delicate fabrics ', e.g. polyacrylic, polyamide, elastane
or acetate; for longer drying times.
bfinished/anti-crease
Clean ¡°;Flashes aclean the fluff filter, check the exhaust air duct a

3 4
End of programme as soon as the \(finished/anti-crease) indicator light flashes
Interrupting the programme Loading or removing laundry
The drum and door may be hot.
The drying programme can be interrupted briefly for loading or removing laundry. The selected
programme must then continue to run to the end.
1. Open the door; the drying process is interrupted.
2. Load or remove laundry and close the door.
3. If required, select a new programme and additional functions.
4. Press the Start button.
Cleaning the fluff filter
Clean the fluff filter after each drying cycle.
1. Open the door and pull out the fluff filter.
2. Remove the fluff (brush your hand over the fluff filter).
If the fluff filter is very dirty or blocked, wash it out with warm water and
dry thoroughly.
3. Insert the fluff filter so that you hear it engage.
4. Remove fluff from door/door area.
Switching off the dryer
Turn the programme selector to Off.
Do not leave laundry in the dryer.
Removing the laundry
Your dryer has an automatic anti-crease function. The drum is moved at set intervals for 30 minutes after
the programme has ended. Laundry remains loose and fluffy (for 90 minutes, if additional Ì(Easy-Iron)
function is selected - depending on model).
... and adapt to individual requirements
Inspecting
the dryer
Sorting and loading laundry
ʋʋʋʋʋʋʋʋʋʋʋSelecting and adjusting the programme
Drying
Control panel a
Select the drying programme ...
Press the Start button
1
2
3
Connecting the
mains plug
Drying ('ca)caaaaaa+aaaaa
Drum
Only operate the dryer with the
fluff filter inserted.
Fluff filter
ʋʋ
For a detailed programme overview, apage 7.
Before using the dryer for the first time
run the drying cycle without any laundry apage 7.
ˎÌse after the programme
ˎ', e.g. polyacrylic, polyamide, elastane
b¡°;aapage 6.

56
\Ì
ʋʋʋʋʋʋʋʋʋʋʋCare and cleaning
Dryer housing, control panel
– Wipe off with a soft, damp cloth.
– Do not use abrasive cleaners or solvents.
– Remove detergent and cleaning agent residue immediately.
Exhaust air duct
Check the exhaust air duct. Clean the exhaust air duct every six months.
Do not bend the exhaust air duct.
1. Switch off the dryer and allow it to cool down.
2. Disconnect the mains plug.
3. Remove the exhaust air duct.
4. Clean the exhaust air duct.
5. Refit the exhaust air duct aInstallation instructions for exhaust air duct.
Moisture sensors
The dryer is equipped with stainless steel moisture sensors.
Moisture sensors measure the moisture level of the laundry.
After sustained, repeated operation, a fine layer of limescale may form
on the moisture sensors.
1. Open the door.
2. Clean the moisture sensors using a slightly damp sponge with a rough
surface.
Do not use steel wool or abrasive materials.

1
2
3
Notes on laundry ...
Labelling of fabrics
Follow the manufacturer's care instructions.
(Drying at a normal temperature.
'cDrying at a lower temperature ain addition, select (Gentle).
)cDo not machine dry.
Be sure to follow the safety instructions apage 11!
For example, do not use the dryer for the following fabrics:
– Airtight fabrics (e.g. rubber-coated fabrics).
– Delicate materials (silk, curtains made from synthetic material) athey may crease.
– Laundry contaminated with oil.
Before drying for the first time
– Do not put any laundry in the machine. Turn the programme selector to Zeitprogramm
(timer programme) (apage 7) and select Start. At the end of the programme, turn the
programme selector to Off.
Drying tips
– To ensure a consistent result, sort the laundry by fabric type and drying programme.
– Always dry very small fabrics (e.g. baby socks) together with large items of laundry
(e.g. hand towels).
– Fasten zips, hooks and eyelets, button covers and tie together cloth belts, bands, etc.
– Do not overdry easy-care laundry arisk of creasing
Allow laundry to finish drying in the air.
– Do not iron laundry immediately after drying, fold items up and leave for a while
athe remaining moisture will then be distributed evenly.
– Knitted fabrics (e.g. T-shirts, jerseys) often shrink slightly the first time they are tumble-dried.
aDo not use the Cupbord Dry Plus ++programme.
– Starched laundry is not always suitable for dryers astarch leaves behind a coating that
adversely affects the drying operation.
– When washing the laundry that is to be tumble-dried, measure the fabric softener in
accordance with the manufacturer's instructions.
– Using a timer programme with a small laundry load aoptimisation of the drying result.
Environmental protection / Energy-saving tips
– Before drying, spin the laundry thoroughly in the washing machine athe higher the spin
speed, the shorter the drying time will be (consumes less energy), also spin easy-care
laundry.
– Use the maximum recommended fill level but do not overload with laundry
aoverview of programmes, page 7.
– Make sure the room is well ventilated during drying.
– Clean the fluff filter after every drying cycle apage 4.
Only when the appliance is
switched off.
ʋʋaaˎÌˎ'b¡°;aa

7
Programme overview see also page 5
Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying. After drying, laundry is to be ...
c
ironed

lightly ironed
@c
not ironed
c
mangled
PROGRAMMES TEXTILE TYPE AND INFORMATION **ÊCottons max. 6 kg Hard-wearing fabrics, boil-proof fabrics made of cotton or linen.
**ÏSynthetics max. 3 kg Non-iron laundry made of synthetic fibres and mixed fabric, easy-care cotton.
ÔIron Dry c÷@c The condition of the laundry means it is suitable for ironing (iron clothes in order to avoid creases).
+Cupboard Dry @For single-layered laundry. *++ Cupboard Dry Plus @For laundry with thick, multi-layered parts.
Timed Program
warm 60’
max. 3 kg Pre-dried, multi-layered, sensitive fabrics made of acrylic fibres, or separate small items of laundry. Also for subsequent drying.warm 40’
warm 20’ cold 20’ max. 3 kg All types of fabrics. For freshening up or airing of items of laundry that have been worn for a short period of time.
*only for the ÊCottons programme
**Dryness levels can be selected individually a++Cupboard Dry Plus, +Cupboard Dry and ÔüIron Dry
(depending on the model). Degree of dryness can be finely adjusted; multi-layered textiles require a longer drying time than single-layered items of clothing. Recommendation: Dry separately
9204 / 9000779060 *779060* Siemens Electrogeräte GmbH
Carl-Wery-Str. 34
81739 München/Germany
WT34A101IN
8
Installation
– Scope of delivery: dryer, instruction manual and installation instructions.
– Check dryer for transport damage.
– The dryer is very heavy. Do not lift without assistance.
– Be careful to avoid sharp edges.
– Do not lift the dryer by protruding parts (e.g. the door) - risk of breakage.
– Do not install in a room where there is a risk of freezing.
Freezing water can cause damage.
– If in doubt, have the appliance connected by a specialist.
Setting up the dryer
– The mains plug must always be accessible.
– Ensure that the appliance is installed on a clean,
level and firm surface.
– Install the exhaust air duct
a Installation
instructions for exhaust air duct.
– Keep the area around the dryer clean.
– Level the dryer using the front threaded feet.
On no account remove the threaded feet.
Mains connection For safety instructions, a page 11.
– Connect to an AC earthed socket. If in doubt have the socket checked by a specialist.
– The mains voltage and the voltage shown on the rating plate ( a page 9) must be the
same.
– The connected load and necessary fuse protection are specified on the rating plate.
1.
Remove all accessories
from the drum. The drum
must be empty.
Clean and level
2.
Do not install the dryer behind a door or
sliding door which could prevent or
obstruct the dryer door from opening.
This will prevent children from locking
themselves in and risking their lives.
ʠ
a
ʠÊ+cÔüÏ+c
ʠʠ¡°;
aa
ʠʠʠʠʠ
aaaaa
ʠ
a
ʠʠ
aaa
ʠʠ
aaaaaaaaaa

c@c c
ÊÏÔc÷@c +@+@Êa++Ôü
aaa
9
Technical data
ʠDimensions (DxWxH) 60 x 60 x 85 cm
Weight approximately 35 kg
Max. capacity 6 kg
Ambient temperature 5 - 35 °C
Connection voltage 220 - 240 V
Connected load 2200 W
Fuse protection 10 A
Product number
a Rating plate or inside of the door
Production number
You can find the rating plate on the back of the dryer.
ʠConsumption rates These are guide values determined under standard
conditions. Deviations of up to 10% are possible.
Spin speed rpm
(residual moisture)
Drying time** in
min incl. 8 min
cooling time
Energy
consumption**
in kWh
ÊCottons 6 kg
+cCupboard Dry* 1400 (approx. 50 %) 100 3.00
1000 (approx. 60 %) 120 3.38
800 (approx. 70 %) 140 4.00
ÔüIron Dry* 1400 (approx. 50 %) 78 2.00
1000 (approx. 60 %) 93 2.00
800 (approx. 70 %) 108 3.00
ÏSynthetics 3 kg
+cCupboard Dry* 800 (approx. 40 %) 44 1.00
600 (approx. 50 %) 55 1.00
*Test programmes according to DIN EN 61121.
**The values may diverge from those specified depending on overvoltage and undervoltage,
fabric type, composition of the laundry to be dried, residual moisture in the fabric and the
amount of the load.
Optional accessories (order from the after-sales service using the order number)
Exhaust air duct set (according to model)
The exhaust air is extracted via a hose.
Washer-dryer stack connection set
The dryer can be placed on top of a suitable washing machine with the same width and depth
to save space.
The dryer must be fastened to the washing machine using this connection set.
WZ
20180
WZ
20311
10
What to do if ...
If you cannot rectify a fault yourself (e.g. switching off/on), please contact our after-sales
service. We will always find an appropriate solution and will avoid unnecessary visits by
engineers. Trust the expertise of the manufacturer and rest assured that the repair will be
carried out by trained service technicians using original spare parts. The contact details of your
local after-sales service can be found in the enclosed after-sales service directory, or by
calling one of these numbers:
–GB 0844 8928999 (Calls from a BT landline will be charged at up to 3 pence per minute.
A call set-up fee of up to 6 pence may apply.)
–IE 01450 2655
When contacting the after-sales service, please quote the appliance's product number (E no.)
and production number (FD) (see the inside of the door).
Set the programme selector to Off and remove the appliance plug from the socket.
ʠStart indicator light does not
light up.
Mains plug plugged in?
Programme selected?
Check the socket fuse.
ʠClean ¡°;indicator light flashes. Clean the fluff filter
a page 4.
Exhaust air duct blocked or bent?
Clean the exhaust air duct a page 6.
If necessary, clean the insect screen on the exhaust air
pipe.
ʠDryer does not start. Start button pressed?
Door closed?
Programme set?
ʠProgramme terminated shortly after
starting.
Ambient temperature greater than 5 °C?
ʠWater is leaking out. Make sure the dryer is level.
ʠThe door opens by itself. Push the door closed until you hear it engage.
ʠThe required degree of dryness
was not achieved or the drying time
was too long.
Clean the fluff filter
a page 4.
Ambient temperature higher than 35 °C a ventilate the
room.
Unsuitable programme selected? a page 7.
Dryer installed too closely to other objects? Provide
adequate air circulation.
Mains failure a Restart the dryer.
Fine layer of limescale on the moisture sensors. Clean the
sensors a page 6.
ʠLaundry damp. Use the next drying programme up or the timer
programme a page 7.
Warm laundry feels damper than it really is!
ʠThe humidity in the room has
increased significantly.
Make sure the room is sufficiently ventilated.
ʠOne or more indicator lights are
flashing.
Clean the fluff filter a page 4.
Check the installation conditions a page 8.
Exhaust air duct blocked or bent?
Clean the exhaust air duct
a page 6.
Switch off, allow to cool, switch back on and restart the
programme.
ʠPower cut. Remove the laundry from the dryer immediately and
spread it out. Heat may escape.
ʠCondensation in the exhaust air
duct.
Exhaust air duct too long? Check the maximum exhaust air
duct length. Further information
a Installation instructions
for exhaust air duct.
aaaaaaaaa

c@c c
ÊÏÔc÷@c +@+@Êa++Ôü
aaa
ʠ
a
ʠÊ+cÔüÏ+cʠʠ¡°;
aa
ʠʠʠʠʠ
aaaaa
ʠ
a
ʠʠ
aaa
ʠʠ
a
11
Safety instructions
Emergency – Pull the mains plug out of the socket immediately or disconnect the fuse.
ONLY use the
dryer...
– in rooms inside the house.
– for drying fabrics.
The dryer must
NEVER...
– be used for other purposes than those described above.
– be modified in terms of its technology or attributes.
Dangers – The dryer must not be used by children or persons who have not been
instructed in its use.
– Do not leave children unsupervised near the dryer.
– Keep pets away from the dryer.
– Remove all objects from the pockets of garments.
Pay particular attention to cigarette lighters
a risk of explosion
– Do not lean or sit on the door a risk of tipping.
– Open the door with care. Hot steam may escape.
Installation – Fasten down loose leads a risk of tripping
– Do not operate the dryer where there is a risk of frost.
– The safety information in the separate installation instructions for the exhaust
air duct must be observed without fail.
Mains
connection
– Connect the dryer to an AC earthed socket according to specifications, as
otherwise it cannot be guaranteed that the appliance is completely safe.
– The cable cross-section must be sufficient.
– Only use earth-leakage circuit breakers with the following symbol:
– The mains plug and socket must be compatible.
– Do not use multiple plugs/couplings and/or extension cables.
– Do not touch or hold the mains plug with wet hands a risk of electric shock.
– Never pull the mains plug out of the socket by its cable.
– Do not damage the mains lead a risk of electric shock.
Operation – Only load the drum with items of laundry.
Check what has been loaded before switching the dryer on.
– Do not use the dryer if the laundry has been in contact with solvents, oil, wax,
grease or paint (e.g. hair setting spray, nail polish remover, stain remover,
cleaning solvent, etc.) a fire/explosion hazard.
– Dust danger (e.g. coal dust or flour): do not use the dryer
a risk of explosion.
– Do not put laundry containing foamed material/rubber in the dryer a elastic
material may be destroyed and the dryer may be damaged due to possible
deformation of the foamed material.
– Switch off the dryer once the programme has ended.
Defect – Do not use the dryer if it is defective or if you suspect that it is.
Repairs must only be carried out by the after-sales service.
– Do not use the dryer with a faulty mains cable. In order to avoid risk, have the
mains lead replaced only by our after-sales service.
Spare parts – Only use genuine spare parts and accessories for safety reasons.
Disposal – Dryer: Disconnect the mains plug, then cut the mains cable off the appliance.
Dispose of the appliance at a public disposal site.
– Packaging: Do not allow children access to items of packaging
a risk of suffocation
– All materials are environmentally friendly and reusable. Dispose of in an
environmentally responsible manner.
Installation and
operating instructions
Tumble dryer
en
Read the instruction manual and installation instructions
before operating the dryer.
Observe the safety
instructions on page 11.
