en Instruction manual
Built-in oven
HB173FBS0S

en
3
Table of contents
enI nst r uct i on manual
8Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(Important safety information . . . . . . . . . . . . . . . 4
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Halogen lamp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Cleaning function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
]Causes of damage . . . . . . . . . . . . . . . . . . . . . . . . 6
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5Installation and connection. . . . . . . . . . . . . . . . . 7
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Measures to be noted during transport . . . . . . . . . . . . 7
7Environmental protection . . . . . . . . . . . . . . . . . . 8
Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Environmentally-friendly disposal . . . . . . . . . . . . . . . . . 8
*Getting to know your appliance . . . . . . . . . . . . . 9
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Buttons and display . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Types of heating and functions . . . . . . . . . . . . . . . . . 10
Temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Cooking compartment . . . . . . . . . . . . . . . . . . . . . . . . 11
_Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Accessories included . . . . . . . . . . . . . . . . . . . . . . . . . 11
Inserting accessories . . . . . . . . . . . . . . . . . . . . . . . . . 11
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . 12
KBefore using for the first time. . . . . . . . . . . . . . 13
Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cleaning the cooking compartment and accessories 13
1Operating the appliance . . . . . . . . . . . . . . . . . . 13
Switching the appliance on and off . . . . . . . . . . . . . . 13
Setting the heating function and temperature . . . . . . 13
Rapid heating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
OTime-setting options . . . . . . . . . . . . . . . . . . . . . 14
Setting a cooking time . . . . . . . . . . . . . . . . . . . . . . . . 14
Setting the end time . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setting the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Changing the time . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
AChildproof lock. . . . . . . . . . . . . . . . . . . . . . . . . . 16
Activating and deactivating . . . . . . . . . . . . . . . . . . . . 16
QBasic settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 17
List of basic settings . . . . . . . . . . . . . . . . . . . . . . . . . 17
Changing the basic settings. . . . . . . . . . . . . . . . . . . . 17
DCleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Suitable cleaning agents . . . . . . . . . . . . . . . . . . . . . .18
Keeping the appliance clean . . . . . . . . . . . . . . . . . . .19
.Cleaning function. . . . . . . . . . . . . . . . . . . . . . . . 19
Before running the cleaning function . . . . . . . . . . . . .20
Setting the cleaning function . . . . . . . . . . . . . . . . . . .20
After running the cleaning function . . . . . . . . . . . . . . .20
pRails. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Detaching and refitting the rails . . . . . . . . . . . . . . . . .21
qAppliance door . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Detaching and attaching the oven door . . . . . . . . . . .21
Removing and installing the door panels . . . . . . . . . .22
Additional door safety. . . . . . . . . . . . . . . . . . . . . . . . .23
3Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . 23
Rectifying faults yourself . . . . . . . . . . . . . . . . . . . . . . .23
Maximum operating time . . . . . . . . . . . . . . . . . . . . . .24
Replacing the bulb in the oven ceiling light . . . . . . . .24
4Customer service . . . . . . . . . . . . . . . . . . . . . . . . 25
E number and FD number . . . . . . . . . . . . . . . . . . . . .25
PProgrammes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Preparing food . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Programmes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Setting the programme. . . . . . . . . . . . . . . . . . . . . . . .27
JTested for you in our cooking studio. . . . . . . . 27
General information . . . . . . . . . . . . . . . . . . . . . . . . . .27
Cakes and pastries. . . . . . . . . . . . . . . . . . . . . . . . . . .28
Bakes and gratins . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Poultry, meat and fish . . . . . . . . . . . . . . . . . . . . . . . . .32
Vegetables and side dishes . . . . . . . . . . . . . . . . . . . .35
Yoghurt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Acrylamide in foodstuffs . . . . . . . . . . . . . . . . . . . . . . .35
Drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Prove dough . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Test dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Produktinfo
Additional information on products, accessories,
replacement parts and services can be found at
www.siemens-home.bsh-group.com and in the online
shop www.siemens-home.bsh-group.com/eshops

en Intended use
4
8Intended use
Intended use Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for future
use or for subsequent owners.
The images shown in these instructions are for
guidance only.
This appliance is only intended to be fully fitted
in a kitchen. Observe the special installation
instructions.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
Only a licensed professional may connect
appliances without plugs. Damage caused by
incorrect connection is not covered under
warranty.
This appliance is intended for domestic use
only. The appliance must only be used for the
preparation of food and drink. The appliance
must be supervised during operation. Only
use this appliance indoors.
This appliance is intended for use up to a
maximum height of 4000 metres above sea
level.
This appliance may be used by children over
the age of 8 years old and by persons with
reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around the
appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 15 years old and are
being supervised.
Keep children below the age of 8 years old at
a safe distance from the appliance and power
cable.
Always slide accessories into the cooking
compartment the right way round.
~"Accessories" on page 11
(Important safety
information
Impor t ant saf et y informat i on General information
:Warning – Risk of fire!
■Combustible items stored in the cooking
compartment may catch fire. Never store
combustible items in the cooking
compartment. Never open the appliance
door if there is smoke inside. Switch off the
appliance and unplug it from the mains or
switch off the circuit breaker in the fuse box.
Risk of fire!
■Loose food remnants, fat and meat juices
may catch fire. Before using the appliance,
remove the worst of the food remnants from
the cooking compartment, heating elements
and accessories.
Risk of fire!
■A draught is created when the appliance
door is opened. Greaseproof paper may
come into contact with the heating element
and catch fire. Do not place greaseproof
paper loosely over accessories during
preheating. Always weight down the
greaseproof paper with a dish or a baking
tin. Only cover the surface required with
greaseproof paper. Greaseproof paper
must not protrude over the accessories.
:Warning – Risk of burns!
■The appliance becomes very hot. Never
touch the interior surfaces of the cooking
compartment or the heating elements.
Always allow the appliance to cool down.
Keep children at a safe distance.
Risk of serious burns!
■Accessories and ovenware become very
hot. Always use oven gloves to remove
accessories or ovenware from the cooking
compartment.
Risk of burns!
■Alcoholic vapours may catch fire in the hot
cooking compartment. Never prepare food
containing large quantities of drinks with a
high alcohol content. Only use small
quantities of drinks with a high alcohol
content. Open the appliance door with care.

Important safety information en
5
:Warning – Risk of scalding!
■The accessible parts become hot during
operation. Never touch the hot parts. Keep
children at a safe distance.
Risk of scalding!
■When you open the appliance door, hot
steam can escape. Steam may not be
visible, depending on its temperature. When
opening, do not stand too close to the
appliance. Open the appliance door
carefully. Keep children away.
Risk of scalding!
■Water in a hot cooking compartment may
create hot steam. Never pour water into the
cooking compartment when the cooking
compartment is hot.
:Warning – Risk of injury!
■Scratched glass in the appliance door may
develop into a crack. Do not use a glass
scraper, sharp or abrasive cleaning aids or
detergents.
Risk of injury!
■The hinges on the appliance door move
when opening and closing the door, and
you may be trapped. Keep your hands away
from the hinges.
Risk of injury!
■If you leave the appliance door open,
people may bump into it, resulting in injury.
The appliance door must be kept closed
both while the appliance is in operation and
when it has finished.
:Warning – Risk of electric shock!
■Incorrect repairs are dangerous. Repairs
may only be carried out and damaged
power cables replaced by one of our
trained after-sales technicians. If the
appliance is defective, unplug the appliance
from the mains or switch off the circuit
breaker in the fuse box. Contact the after-
sales service.
Risk of electric shock and serious injury!
■The cable insulation on electrical
appliances may melt when touching hot
parts of the appliance. Never bring
electrical appliance cables into contact with
hot parts of the appliance.
Risk of electric shock!
■Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
■A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
Halogen lamp
:Warning – Risk of burns!
The bulbs in the cooking compartment
become very hot. There is still a risk of burning
your skin for some time after they have been
switched off. Do not touch the glass cover.
Avoid contact with your skin when cleaning.
:Warning – Risk of electric shock!
When replacing the cooking compartment
bulb, the bulb socket contacts are live. Before
replacing the bulb, unplug the appliance from
the mains or switch off the circuit breaker in
the fuse box.
Cleaning function
:Warning – Risk of fire!
■Loose food remnants, fat and meat juices
may catch fire when the cleaning function is
in progress. Before you start the cleaning
function, always remove the worst of the
food residues and remnants from the
cooking compartment.Do not use the
cleaning function for cleaning accessories.
Risk of fire!
■The appliance will become very hot on the
outside during the cleaning function. Never
hang combustible objects, e.g. tea towels,
on the door handle. Do not place anything
against the front of the appliance. Keep
children away from the appliance.
Risk of fire!
■If the door seal is damaged, a large amount
of heat will be generated around the door.
Do not scrub or remove the seal. Never
operate the appliance if the seal is
damaged or missing.
:Warning – Risk of serious harm to health!
The appliance becomes very hot when the
cleaning function is in progress. The non-stick
coating on baking trays and tins is destroyed
and noxious gases are released. Never clean
non-stick baking trays or baking tins using the
cleaning function. In general, you must not use
the cleaning function for cleaning accessories.

en Causes of damage
6
:Warning – Risk of harm to health!
The cleaning function heats up the cooking
compartment to a very high temperature so
that food remnants left over from roasting,
grilling and baking will burn off.This process
releases vapours, which can irritate the
mucous membranes. While the cleaning
function is running, keep the kitchen well
ventilated. Do not remain in the room for long
periods. Keep children and pets away. Follow
the instructions even when using the Delayed
start function with a delayed end time.
:Warning – Risk of burns!
■The cooking compartment becomes
extremely hot during the cleaning function.
Never open the appliance door. Allow the
appliance to cool down. Keep children
away from the appliance.
Risk of burns!
■;The appliance becomes very hot on the
outside during the cleaning function. Never
touch the appliance door. Allow the
appliance to cool down. Keep children at a
safe distance.
]Causes of damage
Ca u s e s of da mage General information
Caution!
■Accessories, foil, greaseproof paper or ovenware on
the cooking compartment floor: do not place
accessories on the cooking compartment floor. Do
not cover the cooking compartment floor with any
sort of foil or greaseproof paper. Do not place
ovenware on the cooking compartment floor if a
temperature of over 50 ºC has been set. This will
cause heat to accumulate. The baking and roasting
times will no longer be correct and the enamel will
be damaged.
■Aluminium foil: Aluminium foil in the cooking
compartment must not come into contact with the
door glass. This could cause permanent
discolouration of the door glass.
■Water in a hot cooking compartment: do not pour
water into the cooking compartment when it is hot.
This will cause steam. The temperature change can
cause damage to the enamel.
■Moisture in the cooking compartment: Over an
extended period of time, moisture in the cooking
compartment may lead to corrosion. Allow the
cooking compartment to dry after use. Do not keep
moist food in the closed cooking compartment for
extended periods of time. Do not store food in the
cooking compartment.
■Cooling with the appliance door open: Following
operation at high temperatures, only allow the
cooking compartment to cool down with the door
closed. Do not trap anything in the appliance door.
Even if the door is only left open a crack, the front of
nearby furniture may become damaged over time.
Only leave the cooking compartment to dry with the
door open if a lot of moisture was produced whilst
the oven was operating.
■Fruit juice: when baking particularly juicy fruit pies,
do not pack the baking tray too generously. Fruit
juice dripping from the baking tray leaves stains that
cannot be removed. If possible, use the deeper
universal pan.
■Extremely dirty seal: If the seal is very dirty, the
appliance door will no longer close properly during
operation. The fronts of adjacent units could be
damaged. Always keep the seal clean. Never
operate the appliance if the seal is damaged or
missing. ~"Cleaning" on page 18
■Appliance door as a seat, shelf or worktop: Do not
sit on the appliance door, or place or hang anything
on it. Do not place any cookware or accessories on
the appliance door.
■Inserting accessories: depending on the appliance
model, accessories can scratch the door panel
when closing the appliance door. Always insert the
accessories into the cooking compartment as far as
they will go.
■Carrying the appliance: do not carry or hold the
appliance by the door handle. The door handle
cannot support the weight of the appliance and
could break.

Installation and connection en
7
5Installation and connection
Instal l ati on and connec t i on This appliance is only intended to be fully fitted in a
kitchen. Observe the special installation instructions.
Do not install the appliance behind a decorative door or
the door of a kitchen unit, as this may cause the
appliance to overheat.
Electrical connection
Only licensed specialists may connect the appliance.It
is important that you comply with the requirements of
your electricity supplier.
Any damage arising from the appliance being
connected incorrectly will invalidate the warranty.
Caution!
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
■The appliance must be disconnected from the power
supply whenever installation work is being carried
out.
■The appliance fulfils the requirements of protection
class I and may only be connected to an earthed
socket.
■The mains power cable must be at least type
H05 V V-F 3G, 1.5 mm².
:Warning – Danger of death!
There is a risk of electric shock if you touch live
components.
■Always make sure your hands are dry when you
touch or hold the mains plug.
■Only pull out the mains cable by taking hold of the
plug and removing the plug; never pull it out by the
mains cable itself, as this could damage it.
■Never unplug the mains plug when the appliance is
in operation.
Please note the following information and ensure that:
Notes
■The mains plug fits the socket.
■The cable cross section is adequate.
■The earthing system is properly installed.
■The mains cable is only replaced by a qualified
electrician (if this is necessary).Spare mains cables
can be ordered from our after-sales service.
■No power strips/multi-way connectors or extension
cables are used.
■If using a residual current device, only use one that
bears the mark z.
The presence of this mark is the only way to be sure
that it fulfils all the applicable regulations.
■The mains plug can be accessed at all times.
■The mains cable is not kinked, crushed, modified or
severed.
■The mains cable does not come into contact with
heat sources.
Measures to be noted during transport
Secure all mobile parts in and on the appliance using
an adhesive tape that can be removed without leaving
any traces. Push all accessories (e.g. baking tray) into
the corresponding slots with cardboard at the edges, in
order to avoid damaging the appliance. Place
cardboard or similar between the front and rear side to
prevent knocks against the inside of the glass door.
Secure the door and, if available, the top cover to the
appliance sides using adhesive tape.
Keep the original appliance packaging. Only transport
the appliance in the original packaging. Observe the
transport arrows on the packaging.
If the original packaging is no longer available
pack the appliance in protective packaging to
guarantee sufficient protection against any transport
damage.
Transport the appliance in an upright position. Do not
hold the appliance by the door handle or the
connections on the rear, as these could be damaged.
Do not place any heavy objects on the appliance.

en Environmental protection
8
7Environmental protection
Envi r onment al pr ot ec t i on Your new appliance is particularly energy-efficient.
Here you can find tips on how to save even more
energy when using the appliance, and how to dispose
of your appliance properly.
Saving energy
■Only preheat the appliance if this is specified in the
recipe or in the tables in the operating instructions.
■Leave frozen food to defrost before placing it in the
cooking compartment.
■Use baking tins that are dark-coloured, painted black
or have an enamel coating. These absorb the heat
particularly well.
■Remove any unnecessary accessories from the
cooking compartment.
■Open the appliance door as infrequently as possible
when the appliance is in use.
■It is best to bake several cakes one after the other.
The cooking compartment stays warm. This reduces
the baking time for the second cake. You can place
two cake tins next to each other in the cooking
compartment.
■For longer cooking times, you can switch the
appliance off 10 minutes before the end of the
cooking time and use the residual heat to finish
cooking.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly
manner.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning
used electrical and electronic appliances
(waste electrical and electronic equipment -
WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.

Getting to know your appliance en
9
*Getting to know your
appliance
Get t i ng to know your appl i ance In this section, we will explain the indicators and
controls. You will also find out about the various
functions of your appliance.
Note: Depending on the appliance model, individual
details and colours may differ.
Control panel
You can set your appliance's various functions on the
control panel. Below, you will see an overview of the
control panel and the layout of the controls.
Note: On some appliances, the control knobs can be
pushed in. To push the control knob in and engage it or
to release it again, turn it to the "Off" position.
Buttons and display
You can use the buttons to set various additional
functions on your appliance. You will be able to see the
values for these on the display.
--------
Display
The cooking compartment temperature you set using
the temperature selector will be shown on the display.
To use the individual time-setting options, touch the
vbutton several times.The symbol that lights up
corresponds to the value currently shown in large digits
on the display.

 

(Buttons and display
The buttons are touch keys with sensors
underneath. Simply touch a symbol to select the
function.
The display shows symbols for active functions
and the time-setting options.
0Function selector
Use the function selector to set the heating
function or other functions.
You can turn the function selector clockwise or
anti-clockwise from the "Off" position.
8Temperature selector
Use the temperature selector to set the
temperature for the heating function or select the
setting for other functions.
You can also turn the temperature selector
clockwise or anti-clockwise. It does not have an
"Off" position.
Symbol Meaning
vTime-setting options Tap the symbol repeatedly to select
the timer Q, duration x, end
time yand time v.
A
@
Minus
Plus
Reduce setting values.
Increase setting values.
kg/'Childproof lock Lock and unlock the oven functions
on the control panel.
Weight Select a weight for the programmes.

en Getting to know your appliance
10
Types of heating and functions
Use the function selector to set the types of heating and
other functions.
To make sure you always use the right type of heating
to cook your food, we have explained the differences
and applications below.
--------
Note: For each heating function, the appliance specifies
a default temperature or level. You can accept this
value or change it in the appropriate area.
Other functions
Your new oven has yet more functions; see below for a
brief description of these.
--------
Type of heating Temperature Use
:3D hot air 50-275 °C For baking and roasting on one or more levels.
The fan distributes the heat from the ring heating element in the back panel evenly
around the cooking compartment.
7Hot air gentle 125-275 °C For gently cooking selected types of food on one level without preheating.
The fan distributes the heat from the ring-shaped heating element in the back panel
around the cooking compartment.
This heating function is used to measure both the energy consumption in air recircula-
tion mode and the energy efficiency class.
(Grill, large area Grill settings:
1 = low
2 = medium
3 = high
For grilling flat items, such as steaks or sausages, for making toast, and for browning
food.
The whole area below the grill element becomes hot.
4Circulated air grilling 50-275°C For roasting poultry, whole fish and larger pieces of meat.
The grill element and the fan switch on and off alternately. The fan circulates the hot
air around the food.
%Top/bottom heating 50-275 °C For traditional baking and roasting on one level. Especially suitable for cakes with
moist toppings.
Heat is emitted evenly from above and below.
This heating function is used to measure the energy consumption in the conventional
mode.
Function Use
IRapid heating Preheats the cooking compartment rapidly without accessories.
4Interior lighting Switches on the interior lighting; all other functions remain off.
Makes it easier to clean the cooking compartment, for example.
XProgrammes For many dishes, the appliance has preprogrammed setting values that you can use.
~"Programmes" on page 25
VPyrolytic self-cleaning The pyrolytic self-cleaning function cleans the cooking compartment almost by itself.
~"Cleaning function" on page 19

Accessories en
11
Temperature
Use the temperature selector to set the temperature in
the cooking compartment. It can also be used to select
the grill and cleaning settings, for example.
The settings appear in the display.
Notes
■The temperature can be set in 1-degree increments
up to 100 °C, and in 5-degree increments thereafter.
■For grill setting 3, the appliance lowers the setting to
grill setting 1 after approx. 20 minutes.
Temperature display
When the appliance is heating, the psymbol lights up in
the display.
When you are preheating the appliance, the optimal
time to place your food in the cooking compartment is
when the symbol first goes out.
Notes
■The temperature indicator only appears for types of
heating for which a temperature is set. It does not
appear for grill settings, for example.
■Due to thermal inertia, the temperature that is
displayed may differ slightly from the actual
temperature inside the cooking compartment.
Cooking compartment
Various functions in the cooking compartment make
your appliance easier to use. For example, the cooking
compartment is well lit and a cooling fan prevents the
appliance from overheating.
Opening the appliance door
If you open the appliance door when the appliance is in
operation, the appliance will continue to operate as
before.
Interior lighting
With most heating functions and other functions, the
interior lighting in the cooking compartment will remain
lit while the oven is in operation. When the function
selector is turned to bring operation to an end, the
lighting will go out.
By turning the function selector to the interior lighting
setting, you can switch on the lighting without heating
the oven. This makes it easier to clean your appliance,
for example.
Cooling fan
The cooling fan switches on and off as required. The
hot air escapes above the door.
Caution!
Do not cover the ventilation slots. Otherwise, the
appliance may overheat.
So that the cooking compartment cools down more
quickly after operation, the cooling fan continues to run
for a certain period afterwards.
_Accessories
Ac c e s s o r i e s Your appliance is accompanied by a range of
accessories. Here, you can find an overview of the
accessories included and information on how to use
them correctly.
Accessories included
Your appliance is equipped with the following
accessories:
--------
Only use genuine accessories. They are specially
adapted for your appliance.
You can buy accessories from the after-sales service,
from specialist retailers or online.
Note: The accessories may become deformed when
they become hot. This does not affect their function.
Once they cool down again, they regain their original
shape.
Inserting accessories
The cooking compartment has five shelf positions. The
shelf positions are counted from the bottom up.
In some appliances, the highest shelf position is
marked on the cooking compartment by the grill
symbol.
Always insert accessories between the two guide rods
for the shelf position.
Accessories can be pulled out approximately halfway
without tipping.
When sliding accessories into the cooking
compartment, ensure that the kink in the side rail is at
the back. Only then will they lock in place.
Wire rack
For ovenware, cake tins and ovenproof
dishes.
For roasts, grilled items and frozen
meals.
Universal pan
For moist cakes, pastries, frozen meals
and large roasts.
It can be used to catch dripping fat when
you are grilling directly on the wire rack.






en Accessories
12
Notes
■Hold the baking tray securely at the sides with both
hands and slide it into the shelf supports, keeping it
parallel. Do not move the baking tray from side to
side as you slide it in, otherwise it will not go in easily
and the enamelled surfaces may be damaged.
■Make sure that you always insert the accessories
into the cooking compartment the right way round.
■Always insert the accessories fully into the cooking
compartment so that they do not touch the appliance
door.
■Take any accessories that you will not be using out
of the cooking compartment.
Optional accessories
You can buy optional accessories from our after-sales
service, from specialist retailers or online. You will find a
comprehensive range of products for your appliance in
our brochures and online.
Their availability and whether it is possible to order
them online varies from country to country. See your
sales brochures for more details.
Note: Not all optional accessories are suitable for every
appliance. When purchasing, always quote the exact
product number (E no.) of your appliance.
~"Customer service" on page 25
--------
Optional accessories
Wire rack
For cookware, cake tins and ovenproof dishes, and for roasts and
grilled food.
Baking tray
For tray bakes and small baked items.
Universal pan
For moist cakes, baked items, frozen food and large roasts.
It can be used to catch dripping fat when you are grilling directly on
the wire rack.
Wire insert
For meat, poultry and fish.
For inserting into the universal pan to catch dripping fat and meat
juices.
Professional pan
For preparing large quantities of food. Also ideal for moussaka, for
example.
Lid for the professional pan
The lid turns the professional pan into a professional roasting dish.
Pizza tray
For pizzas and large round cakes.
Grill tray
Use for grilling in place of the wire rack or as a splatter guard. Use in
the universal pan only.
Baking stone
For home-made bread, bread rolls and pizzas that you wish to have a
crispy base.
The baking stone must be preheated to the recommended tempera-
ture.
Glass roasting dish
For stews and bakes.
Glass pan
For bakes, vegetable dishes and baked items.
Pull-out system, one level
Fitting pull-out rails at position 2 will allow you to pull accessories out
further without them tipping.
Pull-out system, two levels
Fitting pull-out rails at positions 2 and 3 will allow you to pull accesso-
ries out further without them tipping.
Pull-out system, three levels
Fitting pull-out rails at positions 1, 2 and 3 will allow you to pull acces-
sories out further without them tipping.

Before using for the first time en
13
KBefore using for the first
time
Be f o r e usi ng for the first ti me Before you can use your new appliance, you must
make some settings. You must also clean the cooking
compartment and accessories.
Initial use
The time will appear on the display once the appliance
is connected to the power supply. Set the current time.
Setting the time
Make sure that the function selector is set to the "Off"
position.
The time starts at "12:00".
1. Use the Aor @button to set the time.
2. Touch the vbutton to confirm.
The current time will be shown on the display.
Cleaning the cooking compartment and
accessories
Before using the appliance to prepare food for the first
time, you must clean the cooking compartment and
accessories.
Cleaning the cooking compartment
To eliminate the new-appliance smell, heat up the
cooking compartment when it is empty and with the
oven door closed.
Make sure that there is no leftover packaging, such as
polystyrene pellets, in the cooking compartment and
remove the adhesive tape that is in or on the appliance.
Before heating the appliance, wipe the smooth surfaces
in the cooking compartment with a soft, damp cloth.
Keep the kitchen ventilated while the appliance is
heating.
Apply the settings indicated below. You can find out
how to set the heating function and the temperature in
the next section. ~"Operating the appliance"
on page 13
Switch off the appliance after the time indicated.
Once the cooking compartment has cooled down,
clean the smooth surfaces with soapy water and a dish
cloth.
Cleaning the accessories
Clean the accessories thoroughly using soapy water
and a dish cloth or soft brush.
1Operating the appliance
Oper at i ng the appl i ance You have already learnt about the controls and how
they work. Now we will explain how to apply settings on
your appliance.
Switching the appliance on and off
Use the function selector to switch the appliance on or
off. Turning the function selector to any position other
than the "Off" position switches on the appliance. To
switch off the appliance, always turn the function
selector to the "Off" position.
Setting the heating function and temperature
It is very easy to apply the settings you require to your
appliance using the function and temperature selector.
To find out which heating function is best for which type
of food, refer to the beginning of the instruction manual.
Example in the picture: Top/bottom heating %at
190 °C.
1. Use the function selector to set the heating function.
2. Use the temperature selector to set the temperature
or grill setting.
The appliance will start heating after a few seconds.
Once the food is cooked, turn the function selector to
the "Off" position to switch the appliance off.
Note: You can also set a cooking time or end time for
your food on the appliance. ~"Time-setting options"
on page 14
Settings
Heating function 3D Hotair :
Temperature maximum
Time 1 hour

&

en Time-setting options
14
Changing
The heating function and temperature can be changed
at any time using the relevant selector.
If you change the heating function, the temperature will
be changed to the corresponding default value.
Rapid heating
With Rapid heating, you can shorten the heat-up time.
Then, for best results, use:
■:3D hot air
■%Top/bottom heating
Only use Rapid heating when a temperature of over
100 °C has been selected.
To achieve an even cooking result, do not place your
food into the cooking compartment until Rapid heating
is complete.
1. Set the function selector to I.
2. Use the temperature selector to set the temperature.
The oven will start heating after a few seconds.
Once Rapid heating is complete, an audible signal will
sound. Place your food in the cooking compartment.
OTime-setting options
Ti me- s et t i ng opt i ons Your appliance has different time-setting options.
Before you can call up the cooking time using the
vbutton, you will need to set a heating function. Once
you have set a cooking time, the end time can be called
up.
An audible signal will sound once the cooking time or
timer duration has elapsed. You can cancel the audible
signal early by touching the vbutton.
Setting a cooking time
You can set the cooking time for your food on the
appliance. This prevents the food from accidentally
being cooked for too long, and means that you do not
have to stop what you are doing to switch off the oven.
The maximum time that can be set is 23 hours 59
minutes. The cooking time can be set in 1-minute
increments up to 1 hour, and in 5-minute increments
thereafter.
The cooking time will start at a different default value
depending on which button you touch first:
10 minutes if you touch the Abutton and 30 minutes if
you touch the @button.
Example in the picture: Cooking time of 45 minutes.
Details in the diagram may differ from what you see on
your appliance.
1. Setting the heating function and temperature or
setting
2. Touch the vbutton twice.
The cooking time xwill appear on the display.
Time-setting option Use
xCooking time Once the set cooking time has elapsed, the
appliance will automatically stop heating.
yEnd time Enter a cooking time and the required end
time. The appliance will start up automatically
so that it finishes cooking at the required time.
QTimer The timer functions like an egg timer. It runs
independently of the appliance when it is
heating and does not affect the appliance.
vTime When no other function is running in the fore-
ground, the appliance will show you the time
of day on the display.
[

Time-setting options en
15
3. Use the Aor @button to set the cooking time.
The appliance will start heating after a few seconds. The
cooking time will count down on the display.
The cooking time has elapsed
An audible signal will sound. The appliance will stop
heating. The cooking time will be zero on the display.
Once the signal stops, you can touch the @button to
set a new cooking time.
Once your food is cooked, turn the function selector to
the "Off" position to switch the appliance off.
Changing and cancelling
You can use the Aor @button to change the cooking
time at any time.After a few seconds, the change will be
applied.
To cancel, use the Abutton to reset the cooking time all
the way to zero. The appliance will continue heating
without a cooking time.
Setting the end time
You can delay the time at which cooking is due to
finish.You can, for example, put your food in the
cooking compartment in the morning and set the
cooking time so that it is ready at lunchtime.
Notes
■Make sure that food is not left in the cooking
compartment for too long as it may spoil.
■Do not adjust the end time once the appliance is
already in operation, otherwise the cooking result
may no longer be satisfactory.
The end of the cooking time can be delayed by up to
23 hours 59 minutes.
Example in the picture: The time is 10.30 a.m., a
cooking time of 45 minutes has been set and you want
the food to be ready at 12.30 p.m.
Details in the diagram may differ from what you see on
your appliance.
1. Setting the heating function and temperature or
setting
2. Touch the vbutton twice and use the Aor @button
to set the cooking time.
3. Touch the vbutton again.
The end time ywill appear on the display.
4. Use the @or Abutton to delay the end time.
The appliance will apply the settings after a few
seconds. The end time will be shown on the display.
Once the appliance starts, the cooking time will begin to
count down.
The cooking time has elapsed
An audible signal will sound. The appliance will stop
heating. The cooking time will be zero on the display.
Once the signal stops, you can touch the @button to
set a new cooking time.
Once your food is cooked, turn the function selector to
the "Off" position to switch the appliance off.
Changing and cancelling
You can use the Aor @button to change the end time.
After a few seconds, the change will be applied. The
end time cannot be changed once the cooking time has
already started to count down. Otherwise the cooking
result would no longer be satisfactory.
To cancel, use the Abutton to set the end time all the
way back to the current time plus the cooking time. The
appliance will start to heat and the cooking time will
start to count down.

en Childproof lock
16
Setting the timer
You can use the timer whether or not the appliance
itself is in use. However, it is not possible to set a
cooking time or end time.
The maximum time that can be set is 23 hours and 59
minutes. Up to 10 minutes, the timer duration can be
set in 30-second increments. Above 10 minutes, the
time increments become longer the higher the value.
The timer duration will start at a different default value,
depending on which button you touch first:
5 minutes if you touch the Abutton and 10 minutes if
you touch the @button.
1. Touch the vbutton until the timer symbol Qis
highlighted.
2. Use the Aor @button to set the timer duration.
After a few seconds, the timer duration will start to
count down.
Tip: If the set timer duration is the duration for which
you wish to cook your food, use the cooking time. The
appliance will then switch off automatically when it has
finished cooking.
The timer duration has elapsed
An audible signal will sound. The timer duration will be
zero on the display.
Touch any button to switch off the timer.
Changing and cancelling
You can use the Aor @button to change the timer
duration at any time. After a few seconds, the change
will be applied.
To cancel, use the Abutton to reset the timer duration
all the way to zero. The timer is now switched off.
Changing the time
You can change the time again when you need to, e.g.
from summer to winter time.
To do this, when the appliance is switched off, touch the
vbutton until the symbol for the time is underlined,
and use the Aor @button to change the time.
AChildproof lock
Ch i l d p r o o f lock Your appliance is equipped with a childproof lock so
that children cannot switch it on accidentally or change
any settings.
Notes
■You can go to the basic settings to specify whether
you want the option to set the childproof lock.
~"Basic settings" on page 17
■If a hob is connected, it will not be affected by the
childproof lock on the oven.
■After a power cut, the childproof lock will no longer
be active.
Activating and deactivating
To activate the childproof lock, the function selector
must be set to the "Off" position.
Press and hold the 'button for approx. 4 seconds.
The symbol for this function will appear on the display.
The childproof lock is now activated.
Note: If a timer duration Vhas been set, this will
continue to count down. While the childproof lock is
active, the timer duration cannot be changed.
To deactivate the childproof lock, press and hold the
'button again for approx. 4 seconds until the symbol
goes out on the display.

Basic settings en
17
QBasic settings
Ba s i c s et t i ngs There are various settings available to you in order to
help use your appliance effectively and simply. You can
change these settings as required.
List of basic settings
Depending on the features of your appliance, not all
basic settings will be available.
--------
Changing the basic settings
The function selector must be set to the "Off" position.
1. Press and hold the vbutton for approx. 4 seconds.
The first basic setting will appear on the display,
e.g. ™‚ ‚.
2. Use the Aor @button to change the setting if
necessary.
3. Confirm by pressing the vbutton.
The next basic setting will appear on the display.
4. Use the vbutton to scroll through all the basic
settings; use the Aor @button if you want to change
any of these settings.
5. To confirm, press and hold the vbutton again for
approx. 4 seconds.
All basic settings have now been applied.
You can change the basic settings again at any time.
Note: Your changes to the basic settings will be
retained even after a power failure.
Basic setting Options
™‚ Length of audible signal dura-
tion upon completion of a
cooking time or timer count-
down
‚= approx. 10 seconds
ƒ= approx. 30 seconds*
„= approx. 2 minutes
™ƒ Amount of time until a setting
is applied
‚= approx. 3 seconds*
ƒ= approx. 6 seconds
„= approx. 10 seconds
™„ Button tone that sounds when
a button is touched
‹= off
‚= on*
™… Brightness of the display illu-
mination
‚= dark
ƒ= medium
„= bright*
™† Display time of day? ‹= hide the time
‚= display the time*
™‡ Enable childproof lock activa-
tion?
‹= no
‚= yes*
ƒ= yes, with locked door**
™ˆ Interior lighting on when
appliance in operation?
‹= no
‚= yes*
™‰ Cooling fan run-on time ‚= short
ƒ= medium*
„= long
…= extra long
™Š Telescopic rails retrofitted?** ‹= no* (for rails and single
pull-out system)
‚= yes (for double and triple
pull-out systems)
™‘ Reset all values to factory set-
tings?
‹= no*
‚= yes
* Factory setting (factory settings may vary depending on the appli-
ance model)
** Not available for all appliance types.

en Cleaning
18
DCleaning
Cl eani ng With good care and cleaning, your appliance will retain
its appearance and remain fully functioning for a long
time to come. We will explain here how you should
correctly care for and clean your appliance.
Suitable cleaning agents
To ensure that the different surfaces are not damaged
by using the wrong cleaning agent, observe the
information in the table. Depending on the appliance
model, not all of the areas listed may be on/in your
appliance.
Caution!
Risk of surface damage
Do not use:
■Harsh or abrasive cleaning agents,
■Cleaning agents with a high alcohol content,
■Hard scouring pads or cleaning sponges,
■High-pressure cleaners or steam cleaners,
■Special cleaners for cleaning the appliance while it is
hot.
Wash new sponge cloths thoroughly before use.
Tip: Highly recommended cleaning and care products
can be purchased through the after-sales service.
Observe the respective manufacturer's instructions.
:Warning – Risk of burns!
The appliance becomes very hot. Never touch the
interior surfaces of the cooking compartment or the
heating elements. Always allow the appliance to cool
down. Keep children at a safe distance.
--------
Area Cleaning
Appliance exterior
Stainless steel
front
Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Remove flecks of limescale, grease, starch and
albumin (e.g. egg white) immediately. Corrosion
can form under such flecks.
Special stainless steel cleaning products suitable
for hot surfaces are available from our after-sales
service or from specialist retailers. Apply a very
thin layer of the cleaning product with a soft cloth.
Plastic Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Do not use glass cleaner or a glass scraper.
Painted surfaces Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Control panel Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Do not use glass cleaner or a glass scraper.
Door panels Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Do not use a glass scraper or a stainless steel
scouring pad.
Door handle Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
If descaler comes into contact with the door han-
dle, wipe it off immediately. Otherwise, any stains
will not be able to be removed.
Appliance interior
Enamelled sur-
faces
Hot soapy water or a vinegar solution:
Clean with a dish cloth and then dry with a soft
cloth.
Soften baked-on food remnants with a damp cloth
and soapy water. Use stainless steel wire wool or
oven cleaner to remove stubborn dirt.
Caution!
Never use oven cleaner in the cooking compart-
ment when it is still warm. This may damage the
enamel. Remove all food remnants from the cook-
ing compartment and the appliance door before
you next heat up the appliance.
Leave the cooking compartment open to dry after
cleaning it.
It is best to use the cleaning function.
~"Cleaning function" on page 19
Note: Food residues can cause white deposits to
form. These are harmless and do not affect how
the appliance works.
Remove using lemon juice if required.
Glass cover for
the interior light-
ing
Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
If the cooking compartment is heavily soiled, use
oven cleaner.
Door cover made from stainless steel:
Use stainless steel cleaner. Follow the manufac-
turers' instructions. Do not use stainless steel
care products.
made from plastic:
Clean using hot soapy water and a dish cloth. Dry
with a soft cloth. Do not use glass cleaner or a
glass scraper.
Remove the door cover for cleaning.
Rails Hot soapy water:
Soak and clean with a dish cloth or brush.
Pull-out system Hot soapy water:
Clean with a dish cloth or a brush.
Do not remove the lubricant while the pull-out rails
are pulled out – it is best to clean them when they
are pushed in. Do not clean in the dishwasher.
Accessories Hot soapy water:
Soak and clean using a dishcloth or brush.
If there are heavy deposits of dirt, use a stainless
steel scouring pad.
Enamelled accessories are dishwasher-safe.

Cleaning function en
19
Notes
■Slight differences in colour on the front of the
appliance are caused by the use of different
materials, such as glass, plastic and metal.
■Shadows on the door panels, which look like
streaks, are caused by reflections made by the
interior lighting.
■Enamel is baked on at very high temperatures.This
can cause some slight colour variation. This is
normal and does not affect operation.
The edges of thin trays cannot be completely
enamelled. As a result, these edges can be rough.
This does not impair the anti-corrosion protection.
Keeping the appliance clean
Always keep the appliance clean and remove dirt
immediately so that stubborn deposits of dirt do not
build up.
:Warning – Risk of fire!
Loose food remnants, fat and meat juices may catch
fire. Before using the appliance, remove the worst of the
food remnants from the cooking compartment, heating
elements and accessories.
Tips
■Clean the cooking compartment after each use. This
will ensure that dirt cannot be baked on.
■Always remove flecks of limescale, grease, starch
and albumin (e.g. egg white) immediately.
■Use the universal pan for baking very moist cakes.
■Use suitable ovenware for roasting, e.g. a roasting
dish.
.Cleaning function
Cl eani ng f unct i on Use the "Self-cleaning" function to clean the cooking
compartment.
You can choose from three cleaning cycles.
The dirtier the cooking compartment and the longer the
dirt has been there, the more powerful the cleaning
cycle should be. It is sufficient to clean the cooking
compartment every two to three months. You can clean
it more frequently if necessary. Cleaning requires
approx. 2.5-4.8 kilowatt hours.
Notes
■For safety reasons, the appliance door locks
automatically once a certain temperature is reached.
You will not be able to open it again until the lock
symbol non the display has gone out.
■The interior lighting will not come on while the
appliance is being cleaned.
:Warning
Risk of burns!
■The cooking compartment becomes extremely hot
during the cleaning function. Never open the
appliance door. Allow the appliance to cool down.
Keep children away from the appliance.
Risk of burns!
■;The appliance becomes very hot on the outside
during the cleaning function. Never touch the
appliance door. Allow the appliance to cool down.
Keep children at a safe distance.
:Warning
Risk of harm to health!
The cleaning function heats up the cooking
compartment to a very high temperature so that food
remnants left over from roasting, grilling and baking will
burn off.This process releases vapours, which can
irritate the mucous membranes. While the cleaning
function is running, keep the kitchen well ventilated. Do
not remain in the room for long periods. Keep children
and pets away. Follow the instructions even when using
the Delayed start function with a delayed end time.
Cycle Cleaning perfor-
mance
Length of cycle
1 Gentle Approx. 1 hour and 15 minutes
2 Medium Approx. 1 hour and 30 minutes
3 Intensive Approx. 2 hours

en Cleaning function
20
Before running the cleaning function
The cooking compartment must be empty. Remove any
accessories, cookware or shelf rails from the cooking
compartment. Please see the relevant section for
information on how to remove the rails. ~"Rails"
on page 21
Clean the appliance door and along the edges of the
cooking compartment in the area around the seal. Do
not scrub or remove the seal.
Clean the inner door panel using hot soapy water and a
dish cloth. Dry with a soft cloth. If the cooking
compartment is heavily soiled, use oven cleaner.
:Warning
Risk of fire!
■Loose food remnants, fat and meat juices may catch
fire when the cleaning function is in progress. Before
you start the cleaning function, always remove the
worst of the food residues and remnants from the
cooking compartment.Do not use the cleaning
function for cleaning accessories.
Risk of fire!
■The appliance will become very hot on the outside
during the cleaning function. Never hang
combustible objects, e.g. tea towels, on the door
handle. Do not place anything against the front of
the appliance. Keep children away from the
appliance.
Risk of fire!
■If the door seal is damaged, a large amount of heat
will be generated around the door. Do not scrub or
remove the seal. Never operate the appliance if the
seal is damaged or missing.
Setting the cleaning function
Make sure you follow all the preparation instructions
before setting the cleaning function.
The length of time each cleaning cycle runs for has
been preset and cannot be changed.
1. Use the function selector to set Self-cleaning V.
2. Use the temperature selector to set the cleaning
cycle.
The length of each cycle will appear on the display.
The cleaning function will start in a few seconds. The
remaining time will count down on the display.
Ventilate the kitchen while the cleaning function is
running.
The appliance door will lock shortly after the
programme starts running. The Hsymbol will appear
on the display.
An audible signal will sound when the cleaning function
has finished. The time on the display will be zero.
Switch the appliance off by turning the function selector
to the "Off" position.
You will not be able to open the appliance door again
until the cooking compartment has cooled down
sufficiently and the lock symbol Hon the display has
gone out.
Delaying the end time
You can delay the end time if required. Before starting,
touch the vbutton until the "End" symbol is highlighted
on the display. Use the @button to delay the end time.
The appliance will switch to standby after it is started.
Changing and cancelling
The power of the cleaning cycle cannot be changed
once it has started.
The end time can be changed while the appliance is on
standby.
If you would like to cancel the cleaning function, switch
the appliance off by turning the function selector to the
"Off" position.
The appliance door will remain locked until the cooking
compartment has cooled down sufficiently and the lock
symbol on the display has gone out.
After running the cleaning function
Allow the cooking compartment to cool down. Use a
damp cloth to wipe off the ash that has been left behind
in the cooking compartment and around the appliance
door.
Hook the rails back in.
Note: Very bad soiling may cause white deposits to
remain on the enamel surfaces. This is residue from the
food and is harmless. It does not affect performance.
You can remove these residues using lemon juice if
required.
