SIGMA TEK WIFI 011 User manual

WIFI 011
WiFi Adapter
Operating Manual
Date of creation: 28.01.2021
Version date: 20.09.2021
Article number: 12-640-011-E

Publisher: SIGMATEK GmbH & Co KG
A-5112 Lamprechtshausen
Tel.: [phone]
Fax: [phone]
Email: [email protected]
WWW.SIGMATEK-AUTOMATION.COM
Copyright © 2021
SIGMATEK GmbH & Co KG
Translation from German
All rights reserved. No part of this work may be reproduced, edited using an electronic system, duplicated or dis-
tributed in any form (print, photocopy, microfilm or in any other process) without the express permission.
We reserve the right to make changes in the content without notice. The SIGMATEK GmbH & Co KG is not responsible
for technical or printing errors in the handbook and assumes no responsibility for damages that occur through use
of this handbook.

WIFI ADAPTER WIFI 011
20.09.2021 Page 1
WiFi Adapter WIFI 011
•WiFi 802.11 b/g/n
•1x1 MIMO technology improves effective throughput and range over existing 802.11
b/g/n products
•Up to 150 Mbps data transfer rate
•BPSK, QPSK, 16-QAM, DBPSK, DQPSK and CCK modulation schemes
•WEP, TKIP, AES, WPA and WPA2 hardware encryption schemes

WIFI 011 WIFI ADAPTER
Page 2 20.09.2021
Contents
1Technical Data ........................................................................ 3
1.1 Performance Data.........................................................................3
1.2 Hardware........................................................................................3
1.3 RF Characteristics........................................................................3
1.4 Environmental Conditions...........................................................4
1.5 Miscellaneous ...............................................................................4
2Mechanical Dimensions......................................................... 5
3How to Use.............................................................................. 6
3.1 Client..............................................................................................6
3.2 Configuration File.........................................................................6
3.3 Class “WLAN_ClientControl” ......................................................7
3.4 Configuration File (access point)................................................7
3.5 "WLAN_APControl" Class...........................................................8
4Hotplug.................................................................................... 9

WIFI ADAPTER WIFI 011
20.09.2021 Page 3
1 Technical Data
1.1 Performance Data
Wireless standard
802.11 b/g/n
Module type
Host Controller Interface (HCI)
Tested operating systems
Salamander, Gecko OS1)
Hardware not supported
CP 102
Security
WEP 64 bit, WEP 128 bit, TKIP, AES, WPA, WPA2
Network architecture
Ad hoc mode (peer-to-peer) and infrastructure mode
1) These operating systems were tested by SIGMATEK. It can be assumed however, that the USB stick works with
all commercial operating systems.
1.2 Hardware
Chipset
Realtek
Antenna
Onboard chip antenna
Interfaces
USB 2.0
LED
Power
1.3 RF Characteristics
Tx output power
(±2 dBm): 13 dBm @ 11 n, 17 dBm @ 11 b, 15 dBm @ 11 g
Rx sensitivity
11 Mbps -80 dBm @ 8 %
54 Mbps -70 dBm @ 10 %
150 Mbps -64 dBm @ 10 %
Range (in open space)
indoor: up to 100 m
outdoor: up to 180 m
Current consumption
transmit: average 125 mA
receive: average 68 mA
transmit and receive: average 104 mA
Data transfer rate
1, 2, 5.5, 6, 11, 12, 18, 22, 24, 30, 36, 48, 54, 60, 90, 120 Mbps
to a maximum of 150 Mbps
Frequency
2.4 GHz ISM band
Modulation scheme
BPSK/QPSK/16-QAM/DBPSK/DQPSK/CCK

WIFI 011 WIFI ADAPTER
Page 4 20.09.2021
Spread spectrum
IEEE 802.11b: DSSS (Direct Sequence Spread Spectrum)
IEEE 802.11g/n: OFDM (Orthogonal Frequency Division Multiplexing)
1.4 Environmental Conditions
Storage temperature
-20 … +70 °C
Environmental temperature
-10 … +60 °C
Humidity
5-90 %, non-condensing
1.5 Miscellaneous
Article number
12-640-011
Mechanical dimensions
17.00 x 15.00 x 8.00 mm (L x W x H)
Weight
1.80 g ±0.25 g tolerance
25.36 g in retail pack
Approvals
ROHS, REACH, WEEE
(in EU, Brazil, Canada, Japan and USA)

WIFI ADAPTER WIFI 011
20.09.2021 Page 5
2 Mechanical Dimensions

WIFI 011 WIFI ADAPTER
Page 6 20.09.2021
3 How to Use
The WiFi adapter WIFI 011 can be operated either as a client or as an access point. If the
WIFI 011 is to be used as a client, unlike the HGW 1033-X, the client mode is not started
automatically (without command in the "autoexec.lsl"), since the AP mode can be activated
via an application, for example. In this case it would be necessary to deactivate the client
mode before.
With the following CLI or autoexec.lsl commands the desired mode can be selected or started
without application.
"WLANCLIENT START 10"
or
WLANAP 10 (this command was already available)
3.1 Client
There are two ways to use the WLAN Client. To handle the WiFi adapter, you can edit the
configuration file and start the client like described below. On the other hand, SIGMATEK
provides a LASAL class to be used with the WiFi adapter.
3.2 Configuration File
The configuration of the network (the access point to which the client should connect) can be
set in the configuration file:
“C:\LSLSYS\WIRELESS.CONF”
This file is located on the control and must be adapted. The entries for “ssid”and “psk”must
exist.
Important: The line with the option "update_config=1" is required so that configuration
changes are saved permanently.
Please note that when overwriting the configuration file, the comments from it are removed.
# This is the configuration file to handle the connection with
wireless networks via interface 10.
# To connect to a Wireless Access Point, use one of the methods be-
low
# (remove '#' in front of the line) depending on the security
method of the access point.
#
# NOTE: Don't touch the first line!
ctrl_interface=/var/run/wpa_supplicant
update_config=1

WIFI ADAPTER WIFI 011
20.09.2021 Page 7
# Configuration for not secure networks (no key)
#network={
# ssid="WirelessNetworkName"
# key_mgmt=NONE
#}
# Configuration for WPA/WPA2 networks
network={
ssid="sigmatek_internet"
psk="xxxpasswordxxx"
}
Starting the WLAN client:
“C:\AUTOEXEC.LSL”
e.g.
SET IP 10 HOSTADDR DHCP
3.3 Class “WLAN_ClientControl”
SIGMATEK provides a LASAL class with the functions to handle the WiFi adapter. Refer to
the online help of LASAL CLASS 2 and the documentation of the class “WLAN_ClientCon-
trol”.
With the functions in the class “WLAN_ClientControl”you can also connect to other access
points during runtime.
3.4 Configuration File (access point)
If the WiFi adapter WIFI 011 is to be operated as an access point, it must be configured
with the configuration file "C:\LSLSYS\HOSTAPD10.CONF".
The file is available in the directory "C:\LSLSYS\DEFAULT-CONFIGURATIONS" and must
be copied into the directory "C:\LSLSYS".
The basic settings in this file should be left as they are.
The setting for the password "wpa_passphrase" should be changed in any case.

WIFI 011 WIFI ADAPTER
Page 8 20.09.2021
3.5 "WLAN_APControl" Class
SIGMATEK provides a LASAL class with the functions for handling the WiFi adapter. Refer
to the online help of LASAL CLASS 2 and the documentation of the "WLAN_APControl"
class.
You can also use the functions in the "WLAN_APControl" class to start, stop and configure
the AP at runtime.

WIFI ADAPTER WIFI 011
20.09.2021 Page 9
4 Hotplug
Starting from OS version 09.03.210 hotplug is supported for the stick WIFI 011.
The following functionalities are realized:
•If the stick is configured in the "autoexec.lsl", the settings of the "autoexec.lsl" are taken
over at the start of the control, it is not relevant whether the stick is plugged in or not.
•If the stick is plugged in, the settings of "autoexec.lsl" are executed immediately. The
configured IP address is set and the client or access point is started.
•If the stick is not plugged in, the settings of "autoexec.lsl" are executed when the stick
is plugged in.
•If the stick is unplugged during operation, the current settings are restored when it is
plugged in again.
•Even if the stick was not configured or reconfigured in "autoexec.lsl" but via an applica-
tion, the last settings are always restored when the stick is plugged in and unplugged.

WIFI 011 WIFI ADAPTER
Page 10 20.09.2021
Documentation Changes
Change date
Affected
page(s)
Chapter
Note
02.03.2021
6
3.1 Configuration File
Note added
03.05.2021
Document
Name changed to WiFi adapter
6
3 How to Use
Chapter expanded
7
3.4 Configuration File
Chapter added
8
3.5 „WLAN_APControl“ Class
Chapter added
20.09.2021
9
4 Hotplug
Chapter added
