SignaMax 098-2000SX User manual

Signamax098-2000SXGigabitFiberEthernetAdapter
User’sManual
Signamax ConnectivitySystems
GigabitFiber EthernetAdapter
Model 098-2000SX
USER’S
GUIDE

Signamax098-2000SXGigabitFiberEthernetAdapter
2
User’sManual
Signamax ConnectivitySystems
GigabitFiber EthernetAdapter
Model 098-2000SX
User’sGuide

Signamax098-2000SXGigabitFiberEthernetAdapter
User’sManual
Preface
Thismanualdescribeshowtoinstall andusetheSignamax098-
2000SX GigabitFiberEthernetAdapter,ahigh-
performance
networkinterface cardfor32and64bitPCI buses.Deliveringa
fullyscalablesolution,thisadapterfullycomplieswithIEEE802.3z
1000BaseSX/LXstandards,and auto-
negotiatesduplexmodes.
Therearemoreenhancedfeaturesaddedtothisadapter,and it
certainlysatisfiesthedemandsof today’shigh-
endserversand
workstations.
Togetthemostoutof thismanual,youshouldhavean
understandingof Ethernet networkingconcepts.
In thismanual,youwill find:
•Introduction on the Signamax098-2000SX
GigabitFiberAdapter
•Productfeatures
•LEDsfunctions
•Installation instructions
•Specifications

Signamax098-2000SXGigabitFiberEthernetAdapter
4
User’sManual
TableofContents
PREFACE 1
TABLEOF CONTENTS 4
PRODUCT OVERVIEW 5
GIGABIT FIBER ETHERNET ADAPTER 5
PACKAGE CONTENTS 5
PRODUCT FEATURES 6
Enhanced Features6
DriverSupport6
LEDStatusIndicators7
INSTALLATION 8
INSTALLING ADAPTERINTO PCI SLOT 8
CONNECTINGTO YOUR NETWORK 10
LOADING NETWORK DRIVERS 11
SPECIFICATIONS 12
CONTACT INFORMATIONS 14

Signamax098-2000SXGigabitFiberEthernetAdapter
User’sManual
Product Overview
GigabitFiberEthernetAdapter
Figure1: GigabitFiberAdapterwithSCconnector,featuringtwoLEDs
PackageContents
Whenyouunpacktheproductpackage,youshallfindtheitems
listedbelow.Pleaseinspectthecontents,andreportanya
pparent
damageormissingitemsimmediatelytoyourauthorizedreseller.
PThis Adapter
PUser’sManual
PSoftwareDiskette

Signamax098-2000SXGigabitFiberEthernetAdapter
6
User’sManual
ProductFeatures
•Providesone SCport.
•ProvidesstatusLEDs.
•Supportshalf-duplexorfull-duplexoperation forup
toa2Gbpsdatatransferrate.
•SupportsPCI busclock speedsup to66MHz.
•Jumbo Framesupport booststhroughout forbulk
datatransfers.
•LowCPUutilization:
Intelligentinterrupt management and TCP/IP
checksumoff-loading reducesCPUutilization for
betterefficiency.
•Independent receiveand transmit buffersstream
datatoand frommemory.
•Supportsboth32-bit and 64-bitBusMaster
operation.
•CompliantwithPCI plug-and-play.
•CompliantwithIEEE802.3z1000BaseSX,
IEEE802.3xFlowControl,IEEE802.1p Qualityof
Service, IEEE802.1QTagged VLAN.
•CompliantwithRevision 2.2,PCISpecifications.
Enhanced Features
•SupportsIEEE 802.1QTagged VLAN.
•SupportsIEEE 802.1p Qualityof Service(QoS)
priorityqueuing.
DriverSupport
•NDISdriversforMicrosoft Windows95/98,
WindowsNT4.0, 2000, ME.
•NovellNetwareServer4.2and 5.1.
•Linuxdriver.(KERNEL2.2.xand 2.4.x)
•Year2000 compliant.

Signamax098-2000SXGigabitFiberEthernetAdapter
User’sManual
LED Status Indicators
•FDX/COL Full-duplex/Collision
‚LNK/ACT Link/Activity
LEDs Status Indication
Steady Full-duplexmode.
Off Half-duplexmode.
FDX/COL
Flashing Collision.
Steady Avalidnetworkconnectionestablished.
LNK standsforLINK.
Flashing Transmittingorreceivingdata.
ACTstandsforACTIVITY.
LNK/ACT
Off Disconnection.

Signamax098-2000SXGigabitFiberEthernetAdapter
8
User’sManual
Installation
InstallingAdapterintoPCIslot
Step 1:Turnoff thepowertothePC.
Step 2:Removeanymetal decorationsfromyourhandsandwrists.
Step 3:RemovethecoverfromyourPC.
Step 4:Locatean empty,non-sharedbusmastering32-bitand64-
bitPCI
slotandremovethecorrespondingbackplate.Savethescrewfor
useinStep 6.
i
i.
Donotinstalltheadapter inashared PCIslot.AvoidanyPCIslotnextto
anISA slotbecausethisisoftenashared slotanddoesnotsupportbus
mastering.
ii.
Ifyouhaveproblemsinidentifyingasuitable slot,checkyourPC
documentationoraskyoursystemadministratorforhelp.
Step 5:
Carefullyinserttheadapterintothechosen slotandpress firmly
withproperalignment toensureit isfullyseated in theslot.
Step 6:Securetheadapterwiththescrewyousavedin step4.
Step 7:ReplacethePCcover.
Step 8:Proceed tothe“ConnectingtoYourNetwork”section.

Signamax098-2000SXGigabitFiberEthernetAdapter
User’sManual
Insert theadapterintoPCIslot andscrewitontobackplate
Figure2: InstallingtheadapterintoasuitablePCI slot
i
Alwaysensurethepoweristurned off beforeanyinstallationtoavoid
electricshockandpossible damageto theequipment.

Signamax098-2000SXGigabitFiberEthernetAdapter
10
User’sManual
ConnectingtoYourNetwork
Thissectiondescribeshowtoconnecttheadaptertoafiberwire-
basedGigabit F
iberEthernet network,whichcontributestoits
optimalperformance.
i
Youmustconnect theadapter tothenetworkbeforeinstallingthe
networkdriver.
Step 1:Removetheprotectivecoversfromtheadapter’sconnector.
Step 2:PrepareaFibernetw
orkcablewithcorrespondingSCconnectors
forthetwoend devices,oneendtotheadapterandtheothertoa
SCportontheGigabit switch.
Step 3:Connectthefibercabletotheconnectorontheadapter.
Step 4:ConnecttheotherendofthenetworkcabletoaGigabit switch.
Step 5:
Whenthecableisproperlyconnected tothetwoenddevices, turn
on thepowertothePC.
Step 6:
Check theLNK/ACT(Link/Activity)LED.TheLEDwill comeon
when theadapterisreceivingagoodlinksignal fromthe
connected device.
Step 7:
Proceed tothenextsection forinstructionson installing the
networkdriver.

Signamax098-2000SXGigabitFiberEthernetAdapter
User’sManual
LoadingNetworkDrivers
Theadaptersupportsawiderangeof driversforcommonlyused
networkoperating systems.Thefollowingdriversareprovided
in
thedisketteenclosedintheproductpackage.
•NDISdriversforMicrosoft Windows95/98,
WindowsNT4.0, 2000, ME.
•NovellNetwareServer4.2and 5.1
•Linuxdriver.(KERNEL2.2.xand 2.4.x)
Step 1:Findthesuitablenetworkdriverfortheplatformthat youareusing.
Step 2:Followthestep-by-step instruction inthetextfiletoloadthedriver.
ForWindows95,98orNT,ittakesonlyafewmouseclicksto
completethedriverinstallation fortheadapter.

Signamax098-2000SXGigabitFiberEthernetAdapter
12
User’sManual
Specifications
ApplicableStandards IEEE 802.3z1000BaseSX/LX
IEEE 802.3xFlowControl
IEEE 802.1p Qualityof Service
IEEE 802.1QTagged VLAN
PCI SpecificationsRevision2.2
Speed
1000BaseSX/LX:
2000 Mbpsfull-duplex;1000Mbpshalf-duplex
Performance 1,488,000ppsfor1000Mbps
CableRequirements
1000BaseSX
1000BaseSX:
1000BaseLX
:
62.5/125umMulti-Modefiber-opticcable,up
to220m
50/125umMulti-Modefiber-opticcable,upto
550m
10/125umSingle-Modefiber-opticcable,upto
20km

Signamax098-2000SXGigabitFiberEthernetAdapter
User’sManual
LEDIndicators FDX(Full-duplex)/ COL(Collision)
LNK(Link)/ ACT(Activity)
Dimensions 165mm×80mm
NetWeight 70gapprox.
PowerConsumption 5VDC,900mA,5Wmax.
OperatingTemperature 0°Cto40° C(32°F to104°F)
StorageTemperature -25°Cto70°C(-13°F to158°F)
Humidity 10%-90%non-condensing
Emissions FCC part15Class B,
CEMarkClass B, VCCI Class B
