Signcomplex Sunny Series User manual

Signcomplex We bring innovation and give inspiration
Product features:
Sunny series solar street light. CE type
1. Integrated design solution has the features of light and thin, novel appearance and easy for installation;
2. Use high-efficiency monocrystalline silicon PV panel, the conversion efficiency is as high as 17% or more,
and the 10-year life attenuation is <10%;
3. Power-grade battery pack with lithium iron phosphate is of safety and stability;
4. Use MPPT controller,which better handle with complex climate changes with high conversion efficiency;
5. Integrated light control, time control, dual control, can more accurately identify the start and stop conditions
with high efficiency and energy saving;
6. Intelligent power management system with its optional sensors, Bluetooth and other smart devices,
can effectively solve energy waste and other problems.
7. Intelligent control, large-capacity PV panel and battery configuration can ensure normal lighting in 3 rainy days;
8. It can be used under the environment of 0℃ ~ +60℃;
9. IP 65 protection level;
10. 3-yeaer warranty is provided for conventional product.
CRI
>70
LED
TypeⅤ remote
controller
PIR
optional 0～60℃
WET
Location
IP65 3
Warranty
years
TypeⅡ
Tel:[phone] Fax:[phone] [e-mail]
Yijia Industrial Park, Fuqian Road, Guanlan Town, Baoan, Shenzhen, Guangdong, China
www.signcomplex.com

Signcomplex We bring innovation and give inspiration
The product is suitable for roads, sidewalks, parking lots, factories,
parks, squares, courtyards.
Tel:[phone] Fax:[phone] [e-mail]
Yijia Industrial Park, Fuqian Road, Guanlan Town, Baoan, Shenzhen, Guangdong, China
www.signcomplex.com
Application
Description
Sunny series solar street light uses an integrated design solution, which have the features of light and thin,
novel appearance and easy for installation. The product uses high-efficiency monocrystalline silicon PV
panels, with conversion efficiency of more than 17%. Built-in lithium iron phosphate power-grade battery
packs are of safety and stability. With MPPT max. power tracking technology can better handle with complex
climate changes. The product integrates the technology solutions with light control and time control,
which can more accurately control the working time of the product with complete protection mechanism,
high efficiency and energy saving. Optional sensors, Bluetooth and other devices, combined with intelligent
power system, can maximize the use of working time, and can maintain more than 3 days of working time in
cloudy and rainy environment.

SLS-040-D1-60K-SA200
SLS-040-D1-40K-SA200
SLS-040-D1-30K-SA200
5500-6500K
3700-4300K
2700-3200K
Ra＞70
SMD3030
TypeⅡ
4000
SLS-030-D1-60K-SA200
SLS-030-D1-40K-SA200
SLS-030-D1-30K-SA200
5500-6500K
3700-4300K
2700-3200K
Ra＞70
SMD3030
TypeⅡ
3000
SLS-020-D1-60K-SA200
SLS-020-D1-40K-SA200
SLS-020-D1-30K-SA200
5500-6500K
3700-4300K
2700-3200K
Ra＞70
SMD3030
TypeⅡ
2000
SLS-012-D1-60K-SA000
SLS-012-D1-40K-SA000
SLS-012-D1-30K-SA000
5500-6500K
3700-4300K
2700-3200K
Ra＞70
SMD2835
TypeⅤ
1200
40W
35W
30W
10W
Monocr ystalline
Monocr ystalline
Monocr ystalline
Monocr ystalline
LifePo4 230Wh
LifePo4 192Wh
LifePo4 160Wh
LifePo4 4Wh
SLS-100-D1-60K-CA200
SLS-100-D1-40K-CA200
SLS-100-D1-30K-CA200
5500-6500K
3700-4300K
2700-3200K
Ra＞70
SMD5050
TypeⅡ
10000
SLS-080-D1-60K-CA200
SLS-080-D1-40K-CA200
SLS-080-D1-30K-CA200
5500-6500K
3700-4300K
2700-3200K
Ra＞70
SMD5050
TypeⅡ
8000
SLS-060-D1-60K-CA200
SLS-060-D1-40K-CA200
SLS-060-D1-30K-CA200
5500-6500K
3700-4300K
2700-3200K
Ra＞70
SMD5050
TypeⅡ
6000
SLS-050-D1-60K-CA200
SLS-050-D1-40K-CA200
SLS-050-D1-30K-CA200
5500-6500K
3700-4300K
2700-3200K
Ra＞70
SMD5050
TypeⅡ
5000
120W
120W
90W
90W
Monocr ystalline
Monocr ystalline
Monocr ystalline
Monocr ystalline
LifePo4 1150Wh
LifePo4 768Wh
LifePo4 512Wh
LifePo4 432Wh
0
30
60
90
120
150
-/+180
-150
-120
-90
-60
-30
UNIT:cd
C0/180,96.4
UNIT:cd
C30/210,96.1
UNIT:cd
C60/240,95.4
UNIT:cd
C90/270,94.9
AVERAGE BEAM ANGLE(50%):95.7 DEG
0
90
180
270
360
450
INTENSITY DISTRIBUTION DIAGRAM
IN C PLANS
TypeⅤ
0
30
60
90
120
150
-/+1 80
-150
-120
-90
-60
-30
UNIT:c d
C0/180 ,127.2
UNIT:c d
C30/21 0,89.5
UNIT:c d
C60/24 0,72.1
UNIT:c d
C90/27 0,67.3
AVERAGE BEAM ANGLE(50%):89.0 DEG
0
170
340
510
680
850
IN TENSITY DISTRIBUTION DIAGRAM
IN C PLANS
MAX INTENSITY CONE SURFACE
DISTRIBUTION DIAGRAM
C0
C30
C60
C90
C120
C150
C180
C210
C240
C270
C300
C330
0
170
340
510
680
850
TypeⅡ
Technical parameters
Model CCT Battery spec
PV panel type
LEDs type
CRI
PV panel
power
Beam (angle°)
±10%
Lumen(lm)
±10%
Distribution Diagram

Net weight Gross weignt/Box
Box size QTY/Box
Model
4pcs
1pcs
1pcs
1pcs
1pcs
1pcs
1pcs
1pcs
17.5Kg
8.00Kg
9.50Kg
3.30Kg
7.00Kg
8.50Kg
585*550*232mm
575*410*190mm
620*410*190mm
11.5Kg
10.5Kg 720*410*190mm
19.0Kg
20.0Kg
24.0Kg
18.0Kg
19.0Kg
23.0Kg
1380*420*140mm
1380*420*140mm
1685*420*140mm
28.0Kg27.0Kg 1685*420*140mm
a.
c.
b.
a.
b.
c.
φ60mm
φ80mm
a.
b. c.
SLS-012
a. 534mm
b.260mm
c.106mm
SLS-020
a. 530mm
b.358mm
c.73mm
SLS-030
a. 580mm
b.358mm
c.73mm
SLS-040
a. 685mm
b.358mm
c.73mm
SLS-050/060
a. 1310mm
b.358mm
c.82mm
SLS-080/100
a. 1630mm
b.358mm
c.82mm
SLS-012
SLS-020
SLS-030
SLS-040
SLS-050
SLS-060
SLS-080
SLS-100
Remarks:
The standard mounting bracket for SLS-050 / SLS-060 / SLS-080 / SLS-100 is packaged separately, with single weight of 2.8kg,
the packing size is 370*260*190mm, each box is 2pcs, and the gross weight is 7.0Kg.
Dimension(Unit:mm/inch)
Package information

Vertical pole installation Side pole installation
1. Install the mounting bracket to the lighting lamp;
2. Pre-buried light poles that match the installation
caliber of the lighting lamp;
3. Install the lighting lamp on the light pole;
4. Adjust the light to the appropriate elevation angle;
5. Tighten all screws;
6. Activate the lighting lamp in the working state.
If the lamp is installed in the northern hemisphere, the solar panel should face south as much as possible during installation,
and if it is in the southern hemisphere, the solar panel should face north during installation.
The product is only suitable for the installation of light poles with the specified diameter, and cannot be replaced by other sizes,
otherwise it may affect the reliability of the product installation.
The product installation should have a certain elevation angle, please do not install it horizontally or vertically.
Product Installation
Equator

Turn no/off switch
Bluetooth off
Bluetooth on
Sleep mode: transport sleep mode, press this button during
transportation or storage to make the lamp enter sleep state
SOS: light will be flashing
In the test mode, it will be on during the day or at night.
It will be on for 20 seconds according to 100%, 50% and 30%,
and then exit the test mode and return to the working mode
Time setting, timed working 6 hours, 8 hours, 10 hours, cycle switching
Timed working 6 hours
Timed working 8 hours
Timed working 10 hours
Remote control and activation of product
Light ON
Light OFF
Increase brightness
Decrease brightness
SLS-012 Adaptive remote
control device(optional)
SLS-020/030/040 daptive remote
control device(optional)
SLS-050/060/080/100 uses a physical button switch
to turn on or off the light. Use the matching fake finger
to press the button switch at the mark. You can also use
other sharp objects to press. After pressing,
the indicator light will be lit, and the light will flash during
the system start-up. After that, the light goes out and enters
the working mode, press it again to enter the sleep mode,
please set the button to OFF during transportation or storage.
After the product installation is completed,
the solar PV panel will be activated after being exposed to sunlight.

1. Please read the manual carefully to understand the precautions and installation requirements;
2. It is ensured the installation environment and installation accessories meet the load-bearing requirements;
3. Check whether the delivered installation parts are damaged, and install them on the lamp reliably;
4. Different installation accessories correspond to different installation environments,
please do not use or modify at will;
5. If the installation accessories have auxiliary parts such as non-slip screws, etc.,
pay attention to its function and do not ignore it;
6. If there is vibration in the installation environment of the lamp,
a safety rope to prevent falling should be installed to ensure the reliability of the installation;
7. After completing the installation, check whether the components are reliable and effective.
1. Please read the product manual carefully to ensure that the use environment meets the requirements of the
manual before use;
2. This product should be installed by professionals;
3. Non-professionals must not maintain the product;
4. If the parts are damaged, they should be replaced by the manufacturer, service agent,
or similarly qualified personnel;
5. The use environment cannot exceed the specified anti-corrosion level.
If you have special requirements, please consult first;
6. If the lamp is installed in the northern hemisphere, the solar panel should face south as much as possible during
installation, and if it is in the southern hemisphere, the solar panel should face north during installation;
7. Please avoid buildings or trees when installing, so as not to affect the normal power generation efficiency of solar
panels, resulting in short working hours of lamps;
8. When installing, please avoid large billboards or mains lamps to to irradiate the solar panels,
which will cause the solar panels to perceive as daytime and cause the lamps not to work;
9. If the product is stored for a long time, the lamp needs to be charged at least once every six months,
and the lamp is placed outdoors during the day, with the solar panel facing the sun,
and charging is sufficient for 6-7 hours;
10. Please do not cover the light-emitting surface of the lamp with paper or cloth,
and the lamp should not be close to flammable materials.
11. It is forbidden to introduce external electrical signals into the lighting system.
External electrical signals may cause permanent damage to the equipment.
Installation requirements
Notice
