SIIG MiniTouch Plus User manual

1
Introducing Your MiniTouch Plus
The MiniTouch Plus has all the features and functions of
a standard 101-key keyboard in two-thirds the size. It
provides compact, space-saving benefits without giving
up the power and the extended functions offered by a
full-sized 101-key keyboard.
FeaturesandBenefits
• 80-key mini-keyboard with 12 function keys
• PS/2andIBMATenhanced101/102-keykeyboard
compatible
• PS/2 or AT (5-pin DIN) keyboard connector
(depending on the model purchased)
• Separate Scroll Lock, Num Lock, and Caps Lock
LED indicators
• Embedded numeric keypad with cursor and screen
control capabilities
• Special Fn key for accessing the cursor and screen
control keys, F11 and F12 key functions, and
embedded numeric keypad
• Ctrl and Alt keys, one on each side for added
convenience
• High-quality keyswitches for the click and feel that
typists prefer
• Standard QWERTY keyboard layout
• Snap-open legs for height adjustment
MiniTouch Plus
Quick Installation Guide
04-0131B

2
Specifications
Electrical characteristics:
• Input power: +5V DC
• Switch activation mechanism: Conductive rubber
Physical & mechanical characteristics:
• Connector type : PS/2 or AT (5-pin DIN)
• Number of keys: 80
• Key switch life: 20 million cycles
• Travel distance: 3.0 + 0.5 mm
• Dimensions: 11 5/8" (L) x 6" (W) x 1 1/2" (H)
• Weight: 1.6 lbs
Environmental operating conditions:
• Operating temperature: 32oF to 130o F
• Storage temperature: 10o F to 160o F
• Relative humidity: 20% to 95%, non-condensing
• Altitude: –1000 ft. to 10,000 ft.
PackageContents
•MiniTouch Plus
• Quick Installation Guide
Setting Up Your Keyboard
Turn your computer OFF before plugging the keyboard
into your computer. The keyboard's connector is keyed
for proper insertion. Use the snap-open legs on the
bottom of the keyboard to adjust the slant/height for
your comfort.

3
Keyboard Functions
The MiniTouch Plus' space-saving design requires the
dual alpha/numeric function of certain keys. Since the
numeric keypad feature is controlled by the Num Lock
key, an inconvenient situation will occur when using a
computer that automatically enables the Num Lock key
with each boot up. Refer to the following solutions:
1. If your computer's BIOS setup utility has a Num
Lock option, set it to OFF.
2. If your computer's BIOS setup utility does not have
aNumLockoption,presstheNumLockkeytoturn
off the numeric keypad after each boot up.
NumLock–EmbeddedNumericKeypad
Press the Num Lock key to enable the numeric keypad
function. The Num Lock LED at the top right corner
indicates its ON/OFF status. The shaded keys in the
following keyboard layout identify the locations of the
numeric keypad keys.
Figure 1. Embedded Numeric Keypad

4
Fn–SpecialFunctionKeys
The Fn key is used with the cursor-control (arrow) keys,
the F1 and F2 keys, and the embedded numeric keypad
to provide several functions. To execute a function
defined on a key within an outline box such as F11,
simultaneouslypresstheFnkeywiththedesiredfunction
key.
Note: Theshadedkeysinthefollowingkeyboard
layout identify the locations of the keys
associated with the use of the Fn key.
Figure 2. Fn Special Function Keys
Fn + Cursor Control Keys
Thecursorcontrol(arrow)keyswillbecomescreencontrol
keys when used with the Fnkey. The screen control keys
PgUp,PgDn,Home,Endaredefinedbyyourapplication
and typically move the screen cursor up or down, to the
beginning or end of a screen, or to the beginning or end
of a line.
Fn + F1/F2 Keys
To enable the F11 or F12 function, simultaneously press
the Fn key plus the F1 or F2 key, respectively.

5
Fn + Shift Keys + Alpha Numeric Keypad
TousethealphacharacterwhenNUMLockisturnedon:
• Press and hold the Fn key to enable the alpha
characters
• Press and hold the Fn plus the Shift key to enable
the uppercase alpha characters

6
Blank Page

7
Technical Support and Warranty
QUESTIONS? SIIG’s Online Support has answers!
Simply visit our website at www.siig.com and click on Support.
Our online support database is updated daily with new drivers
and solutions. Answers to your questions could be just a few clicks
away. Youcanalsosubmitquestionsonlineandoneofourtechnical
supportanalysts willpromptly respond.
A 5-year manufacturer warranty supplied with this product is
offered by SIIG, Inc. Please see SIIG's website for more warranty
details. If you should happen to encounter any problems with this
product,pleasefollowtheproceduresbelow.
If it is within the store's return policy period, please return the
producttothestorewhereyoupurchasedfrom.
If your purchase has passed the store's return policy period, please
followthese steps tohave the productrepaired orreplaced.
Step1: SubmityourRMArequest:
Go to www.siig.com, click Support, then RMA to submit a
request to SIIG RMA. If the product is determined to be
defective,anRMAnumberwillbeissued. SIIGRMAdepartment
can also be reached at [phone].
Step2: After obtaining an RMA number, ship theproduct.
•Properlypacktheproductforshipping. Allsoftware,cable(s)
andanyother accessoriesthatcamewiththeoriginalpackage
mustbeincluded.
•Clearly write your RMA number on the top of the returned
package. SIIGwillrefusetoacceptanyshippingpackage,and
will not be responsible for a product returned without an
RMA number posted on the outside of the shipping carton.
•YouareresponsibleforthecostofshippingtheproducttoSIIG
at the following address:
SIIG,Inc.
6078 Stewart Avenue
Fremont, CA 94538
RMA#:
•SIIG will ship the repaired or replaced product via Ground
in the U.S. and International Economy outside of the U.S. at
nocosttothecustomer.
