SIIG USB 2.0 Dual-Port PCI User manual

1
Introducing the USB 2.0 Dual-Port PCI
The USB 2.0 Dual-Port PCI adds high-speed USB 2.0
interface to your system. It supports high-speed (480
Mbps), full-speed (12 Mbps), and low-speed (1.5 Mbps)
data transfer modes.
Note: USB 1.1 devices are limited to USB 1.1 speeds
evenwhentheyareconnectedtoUSB2.0hostadapter
or USB 2.0 hubs.
FeaturesandBenefits
• Compliant with USB specifications revision 2.0
• Conforms to PCI Specifications revision 2.2
• Supports simultaneous operation of multiple
high-speed USB 2.0 and USB 1.1 devices
• User friendly hot-swapping feature allows you to
attach/remove USB devices without turning your
system off
• Supports high-speed (480 Mbps), full-speed (12
Mbps), and low-speed (1.5 Mbps) data transfer
modes
• Works with a variety of USB 2.0/USB 1.1 devices
including hubs, data storage devices, PC video
cameras,digitalcameras,CD-R/RWs,DVD-ROMs,
scanners,printers,memorycardreaders,andmore...
USB 2.0 Dual-Port PCI
Quick Installation Guide
04-0293B

2
Figure 1. Layout
USB ports
SystemRequirements
•Pentium-class computer with an available PCI slot
•Windows 98SE/ME/2000/XP/Server 2003
PackageContents
•USB 2.0 Dual-Port PCI board
•DriverCD
•This quick installation guide
Layout

3
Hardware Installation
General instructions for installing the card are provided
below. Since the design of computer cases and
motherboards vary, refer to your computer’s reference
manual for further information, if needed.
Static Electricity Discharge may permanently damage
your system. Discharge any static electricity build up in
your body by touching your computer’s case for a few
seconds. Avoid any contact with internal parts and
handle cards only by their external edges.
1. Turn OFF the power to your computer.
2. Unplugthepowercordandremoveyourcomputer's
cover.
3. Remove the slot bracket from an available PCI slot.
4. CarefullyalignthecardtotheselectedPCIslotpush
the board down firmly, but gently, until it is well
seated.
5. Replace the slot bracket's holding screw to secure
the card.
6. Replacethecomputercoverandreconnectthepower
cord.
Driver Installation
The USB 2.0 Dual-Port PCI has three built-in USB hosts.
Two hosts handle USB 1.1 devices and the third host
handlesUSB2.0devices. USB1.1andUSB2.0devicesare
automatically routed to the correct USB hosts.
Windows98SE
1. Install the board and boot up your system. At the
Add New Hardware Wizard, click Cancel three
times.

4
2. Insert the driver CD. Click Start, Run, type in
X:\setup.exe, then click OK. (Replace X: with the
drive letter of your CD-ROM)
3. Choose Yes, I want to restart my computer now,
then click Close to restart Windows.
4. When Windows restarts, a USB 1.1 host is detected.
5. At the Add New Hardware Wizard, click Next.
6. Choose Search for the best driver for your device.
(Recommended), click Next.
7. Clear all check boxes, click Next, and Next again.
8. Click Next, then Finish.
Note: If prompted for the Windows Installation
CD-ROM, click OK. Insert this CD and click OK.
9. Repeat steps 5-8 one more time when the second
USB 1.1 host is detected.
10. WindowsnowdetectstheUSB2.0hostandloadsit's
driver.
11. The board is now ready for use.
WindowsME/2000
Note: IfyouhaveWindows2000withServicePack
4 (SP4) or later, the drivers will be installed
automatically by the operating system. Otherwise,
follow the instructions below.
1. Install the board and boot up your system. At the
Add New Hardware Wizard, click Cancel.
2. Insert the driver CD. Click Start, Run, type in
X:\setup.exe, then click OK. (Replace X: with the
drive letter of your CD-ROM)
3. Restart Windows after the driver installs.

5
4. When Windows resumes, the drivers install
automatically.
5. The board is now ready for use.
WindowsXP
Note: If you have Windows XP with Service Pack
1 (SP1) or later, the drivers will be installed
automatically by the operating system. Otherwise,
follow the instructions below.
1. Install the board and boot up your system. At the
Found New Hardware Wizard, click Cancel.
2. Insert the driver CD. Click Start, Run, type in
X:\setup.exe, then click OK. (Replace X: with the
drive letter of your CD-ROM)
3. Atthe FoundNewHardwareWizard,select Install
thesoftwareautomatically(Recommended), click
Next, then click Finish.
4. If prompted, repeat step 3, otherwise go to step 5.
5. Restart Windows to complete the installation.
WindowsServer2003
Windows Server 2003 has built-in driver support for this
controller. Just install the board and Windows will
automatically detect and install the correct drivers for it.
No additional driver is necessary.
ToVerifySuccessfulDriverInstallation
1. Check Device Manager to verify successful driver
installation.
Windows 98SE/ME: From the main desktop, right
click My Computer, then click Properties. Click
Device Manager tab.

6
Windows 2000/XP/Server 2003: Right click My
Computer, then click Manage. Click Device
Manager.
2. The drivers for this controller show up differently
under different versions of Windows. Please refer
to the correct Windows version to verify.
Windows Server 2003, XP with SP1 or later, 2000
with SP4 or later:
Under Universal Serial Bus controllers:
- NEC PCI to USB Open Host Controller
- NEC PCI to USB Open Host Controller
- Standard Enhanced PCI to USB Host Controller
- USB Root Hub (USB 2.0 Root Hub in Win2K)
- USB Root Hub
- USB Root Hub
Windows XP, 2000 (sp3 or earlier), ME, 98SE:
Two Universal Serial Bus controllers are listed:
a) Under a Universal Serial Bus controllers:
- NEC PCI to USB Enhanced Host Controller
- USB 2.0 Root Hub Device
b) Under a Universal Serial Bus controllers:
- NEC ... USB Open Host Controller ...
- NEC ... USB Open Host Controller ...
- USB Root Hub
- USB Root Hub

7
Technical Support and Warranty
QUESTIONS? SIIG’s Online Support has answers!
Simply visit our website at www.siig.com and click on Support.
Our online support database is updated daily with new drivers
and solutions. Answers to your questions could be just a few clicks
away. Youcanalsosubmitquestionsonlineandoneofourtechnical
supportanalysts willpromptly respond.
A lifetime manufacturer warranty supplied with this product is
offered by SIIG, Inc. Please see SIIG website for more warranty
details. If you should happen to encounter any problems with this
product,pleasefollowtheproceduresbelow.
If it is within the store's return policy period, please return the
producttothestorewhereyoupurchasedfrom.
If your purchase has passed the store's return policy period, please
followthese steps tohave the productrepaired orreplaced.
Step1: SubmityourRMArequest.
Go to www.siig.com, click Support, then RMA to submit a
request to SIIG RMA. If the product is determined to be
defective,anRMAnumberwillbeissued. SIIGRMAdepartment
can also be reached at [phone].
Step2: After obtainingan RMAnumber, shipthe product.
•Properlypacktheproductforshipping. Allsoftware,cable(s)
andanyotheraccessoriesthatcamewiththeoriginalpackage
mustbeincluded.
•Clearly write your RMA number on the top of the returned
package. SIIGwillrefusetoacceptanyshippingpackage,and
will not be responsible for a product returned without an
RMA number posted on the outside of the shipping carton.
•YouareresponsibleforthecostofshippingtheproducttoSIIG
at the following address:
SIIG,Inc.
6078 Stewart Avenue
Fremont, CA 94538
RMA#:
•SIIG will ship the repaired or replaced product via Ground
in the U.S and International Economy outside of the U.S at
nocosttothecustomer.

USB2.0Dual-PortPCIisatrademarkofSIIG,Inc.
SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered
trademarksofMicrosoftCorporation. PentiumisaregisteredtrademarkofIntelCorporation. Other
namesused in this publication areforidentification only and may betrademarksof their respective
companies.
March, 2005 Copyright ©2005 by SIIG, Inc. All rights reserved.
