1
CONSERVATORS
USER MANUAL
Models
SYD 150 MD DC
SYD 210 MD DC
SYD 310 MD DC
SYD 410 MD DC
SYD 550 MD DC
SYD 650 MD DC

2
Dear Customer,
Thank you for choosing Simfer products. We aim to allow you to op-
timally and eciently use this environment-friendly product produced
in our modern facilities under precise conditions with respect to sense
of quality in total.
We advise you to read this user manual thoroughly before using the
freezer and keep it permanently so that the features of the Simfer
freezer you have purchased will stay the same as the rst day for a
long time and serve in an optimum ecient way.
NOTE:
This User Manual is prepared for multiple models. Your product may
not feature some functions specied in the manual. These functions
are marked by the sign *. Your product must be installed and intro-
duced by Simfer authorized service.
Our products are intended for commercial use.
"PLEASE READ THE MANUAL BEFORE INSTALLING
OR USING THIS PRODUCT."
This product has been produced in modern environment-friendly fa-
cilities without adversely aecting nature.
"Complies with AEEE Regulation"

3
CONTENTS
SECTION 1
Safety Warnings..................................................................4
SECTION 2
Overview and Technical Specications.................................9
Technical Specications ....................................................10
SECTION 3
Installation and Initial Operation.........................................12
Glass Mounting Instructions...............................................14
Castor Mounting Instructions.............................................15
SECTION 4
Installation.........................................................................18
Operation of the Freezer......................................................19
Thermostat Setting.............................................................20
SECTION 5
Cleaning, Maintenance and Transportation of Your Freezer..22
What To Do Before Calling For Authorized Service.............25
SECTION 6
Compliance With AEEE Regulations And Waste Disposal
and Packaging Information................................................26
Warranty Certicate.......................................................28

4
SAFETY WARNINGS
1. Your product is set for 220-240 V 50 Hz mains
power. Use of incompatible voltage may cause your
product to become inoperable or a re.
2. Your product is designed and manufactured
only to preserve frozen packaged foods in applicable
temperature. Do not place consumables such as bev-
erages for cooling. Please do not use other than as
indicated.
3. Electrical installation shall conform with the le-
gal regulations.
4. Do not place the your product under direct sun-
light or within the inuence area of heat sources, such
as an air conditioner, stove, radiator, furnace, oven,
heater or infrared heater. Otherwise, the freezer may
perform poorly, get damaged or become inoperable.
5. Choose a place without moisture but with air
circulation allowed.
6. Clean the inside of your product prior to rst
use.
7. Do not allow children to get into the product or
play around it.
8. If your product has a cover lock, keep its key in
a safe place. By the end-of-life of the product, deac-
tivate the cover lock of your freezer before disposing
it. It is of utmost importance that children are not left
in the freezer, doing so may result in a life endanger-
ing situation.

5
9. For your safety, in order to eliminate the risk of
electric shock and re there must be a breaker sys-
tem with a residual current device in your electrical
wiring. Our rm is not responsible for failures and
losses which may occur as a result of using the prod-
uct on an ungrounded grid.
10. Do not place explosive or ammable material in
your product.
11. Do not use any sharp, pointed objects to scrape
the icing that may occur on the inner surfaces of
your product. Only use the ice scraper that is provid-
ed with your product. Otherwise you can damage the
cooling surface of your product. Also, this improper
operation may cause gas leak and render your prod-
uct inoperable.
12. After putting your product into place, allow at
least 2 hours without moving it before rst use.
13. Your product is designed for indoor use. Do not
use your product outdoors.
14. The installation, placement, maintenance and
cleaning of your product should be performed as
prescribed in the manual. In case of damage to your
product due to misuse, the warranty of the product
will be invalidated.
15. Avoid any sharp and pointed object or over-
heated material from contacting with glass surface
of glass-cover products as this may cause the glass
to crack or break.

6
16. In order to avoid your product from sliding or
overturning, place the product on a non-tilted at
surface. Adjust the height of pre-set legs after place-
ment.
17. In case of any failure within your product, taking
measures for food preserved within the deep freeze
is fully under responsibility of the user. Our company
is not responsible for spoilt food due to any failure or
misuse.
18. Never use an extension cord or multi-plug with
your product.
19. Never use pressured water to clean. Pressured
water may damage live-current parts.
20. Place the packaging material of the product
where children cannot reach. Some packaging mate-
rial (such as nylon, styrofoam, etc.) may be danger-
ous for children.
21. The product should not be used by the phys-
ically, visually, mentally handicapped -including the
hearing impaired-, children, non-experienced or
non-informed persons without supervision of a per-
son responsible for the safety of such people.
22. Open the conservator cover only when neces-
sary. Please make sure that the lid is sealed properly
when it is not necessary.
23. In the event of a sudden power outage unplug
your product. Plug back in 20 minutes after you make
sure that the mains become normal.

7
24. Do not put domestic or wild animals inside your
product and do not allow them to enter into your
product. These kind of living creatures might damage
the electrical system and cause a re.
25. Frost shall be increased for products, of which
the doors are kept open or frequently open and
closed, and the product shall have diculty in per-
forming the cooling operation. Thus, open the door
of your product when it is required only. Ensure that
the door of your product is closed when you do not
require.
26. Do not unplug your product for saving power if
you shall not use your product or keep it empty for
a short period. Otherwise, more power shall be used
for cooling your product again. Just bring the ther-
mostat position to a lower setting.
27. Follow the instructions specied in this manual
for replacement of lamps. The rating of the lamp to
be replaced is specied on the identication plate of
the product and on the plate under the lamp.
28. Do not interfere with the product directly in case
of a fault that occurs due to the electrical system of
the product or of the installation where the product
is connected. Unplug the product and disconnect the
power of the device by turning the main switch o
and contact nearest Simfer authorized service.
29. Do not store explosive materials such as aerosol
cans with ammable propellants inside this product.

8
30. If the power supply cable is damaged, it must be
replaced by its manufacturer or authorized technical
service or any other personnel qualied at the same
level, in order to avoid any dangerous situation.
31. If the appliance will not be used for extended
periods, the glass covers shall be removed.
Attention!
• This appliance includes inammable
and explosive gas R404A, R600a,R134a, R290.
• The ventilation holes on the casing or the
body of the appliance shall be kept open to pre-
vent blocking
• Do not use mechanical tools or other mech-
anisms except the ones recommended by the
manufacturer to make defrosting quicker.
• The cooling circuit shall not be damaged.
• Except materials recommended by the man-
ufacturer, no electric appliances should be used
within food storage compartment of the appli-
ance.
• In order to decrease the risk of ignition, this
appliance shall only be installed and maintained
by Simfer services.

9
SECTION 2
OVERVIEW AND TECHNICAL SPECIFICATIONS
Aluminium Frame Prole
Glass Cover
Handle
External
Body
(Adver-
tisement
Application
Area)
Castors
Lock

10
TECHNICAL SPECIFICATIONS
Brand Simfer Simfer Simfer
Model SYD 650 MD DC SYD 550 MD DC SYD 410 MD DC
Product Category COMMERCIAL
CONSERVATORS
COMMERCIAL
CONSERVATORS
COMMERCIAL
CONSERVATORS
Refrigerant R404A R404A R404A
Total Gross Volume (lt) 640 534 416
Total Net Volume (lt) 532 443 345
Cooling System STATIC STATIC STATIC
Climate Class BC1 (35C/75% Rh) BC1 (35C/75% Rh) BC1 (35C/75% Rh)
Noise Level (dB(A)) 45-47 45-47 45-47
Height (with castor)
(mm) 919 919 919
Width (mm) 1902 1620 1314
Depth (mm) 653 653 653
Net Weight ()kg 85 75 65
Electric Input (V/Hz) 230 230 230
Total Power (W) 440 420 290

11
Brand Simfer Simfer Simfer
Model SYD 310 MD DC SYD 210 MD DC SYD 150 MD DC
Product Category COMMERCIAL
CONSERVATORS
COMMERCIAL
CONSERVATORS
COMMERCIAL
CONSERVATORS
Refrigerant R404A R404A R404A
Total Gross Volume (lt) 314 208 133
Total Net Volume (lt) 258 170 107
Cooling System STATIC STATIC STATIC
Climate Class BC1 (35C/75% Rh) BC1 (35C/75% Rh) BC1 (35C/75% Rh)
Noise Level (dB(A)) 45-47 45-47 45-47
Height (mm) 919 919 919
Width (mm) 1039 763 573
Depth (mm) 653 653 573
Net Weight ()kg 55 45 40
Electric Input (V/Hz) 230 230 230
Total Power (W) 210 180 150
Power consumption test standard for commercial type products is
prEN 16902.
Specications of the product are available on the identication
plates on the product. Simfer reserves the right to make changes
on the specications of the products without prior notice.

12
SECTION 3
INSTALLATION AND INITIAL OPERATION
Selection of Installation Places
Operating environment of the product is very important to ensure
that your product operates without any problem. When you are se-
lecting the operating environment,
• Do not place your product outdoors so that it shall be exposed to
weather conditions. (on a street, lane, etc.)
• Do not place materials such as cardboards, boxes, etc. in front of
the lower blinds to ensure proper cooling of your product.
• Place it at least one (1) meter away from heat sources. (stove, radi-
ator, electrical heater, etc.) (Figure 1)
• Do not expose to direct sunlight. Operation rate of your product will
be increased if sunlight hits the glass of your freezer. And this causes
an increase in the temperature of the products inside the product and
the power consumption shall be increased. (Figure 2)
• Do not place it against A/C exhausts, under the fans and directly in
the door and window openings. (Figure 3)
• Air entrance and exit shall always be free and easy for proper opera-
tion of the compressor section of your product.
• Make sure that there is a clearance of 150 mm (15 cm) between
the wall and the rear side of your freezer when you are bringing the
product close to the wall.
Picture 1 Picture 2 Picture 3

13
The voltage and frequency of mains power should be the
same as the values specied on the label behind your appli-
ance. If mains power is far below or above the specied values,
have the desired voltage by using a voltage regulator. You can get
help from a qualied electrician. The fuse of the mains socket should
be maximum 16A.
!
CAUTION!
On installations performed by the Simfer authorized service, custom-
er shall be informed and advised about the proper installation location,
however nal decision on the installation location shall be made by the
customer.
Simfer Authorized Service species the process mentioned above on
the relevant installation service form. Customer shall be solely respon-
sible for any damages that may occur due to the installation location
decided as per the nal decision of the customer.

14
GLASS MOUNTING INSTRUCTIONS
Figure 1 Figure 2
Place your product on a at, level ground. Mount your glass by plac-
ing it on the mounting rack below by placing one side, then placing on
the other side and x it as shown in Figure 2.
Figure 3 Figure 4
. Place the glass stoppers, tabs facing back, on the lower and upper
rack and press them to ensure that they are xed on the racks, as
shown in Figure 3. Apply the same procedure on the other side, place
the 4 stoppers on the lower and upper racks. Pull the glass to the right
side.
. Mount your glass by placing it on the mounting rack above by plac-
ing one side, then placing on the other side and pull the upper glass to
the right as shown in Figure 4.

15
Picture 5
. Place the glass stoppers, tabs facing back, on the lower and upper
rack and press them to ensure that they are xed on the racks, as
shown in Figure 5. Apply the same procedure on the other side, place
the 4 stoppers on the lower and upper racks. Complete the mounting
procedure by pulling the glass to the left side.
CASTOR MOUNTING INSTRUCTIONS
Picture 1 Picture 2 Picture 3
• Place your product as shown in Figure 2. Then, mount two cas-
tors with brakes in the to the back side of the conservator, by xing
the castors in the sockets under the conservator and ensure that the
socket centers are aligned, as shown in gure 4. Then place the U-pins
through the holes. Ensure the stability by placing the pim wedges.
•By placing the conservator as shown in gure 3, mount the two
castors in the castor box as shown in gure 5, by applying the same
procedure.

16
Figure 4 Figure 5 Figure 5
Climate Class Description
Your freezer provides best cooling performance in the conditions
specied below as per the climate class. Thus, ensure that the environ-
ment where your freezer shall be used conforms with this temperature
ranges.
Climate Class Minimum operating
ambiant temperature and
humidity
Maximum operating
temperature
ambiant temperature
and humidity
A +16 °C, 80 % 30 °C, 55 %
B +16 °C, 80 % 35 °C, 75 %
C +16 °C, 80 % 40 °C, 40 %

17
Product Climate Class Description
This is the temperature range determined by the protection temper-
ature of the product to be placed inside the freezer.
Climate Class Hottest product temperature
C1 -18,0 ºC
C2 -7,0 ºC
S Special product classication
SİMFER conservators you have purchased have the climate class of
BC1 and they are manufactured so that they shall operate in an aver-
age ambient temperature between +16ºC and +35ºC.
Operating the product out of the mentioned temperature range may
cause performance losses.

18
SECTION 4
LOCATION
Possible Installation Locations:
1- Ensure that a clearance of 150 mm (15 cm) is available between
the wall and your freezer so that solely the back of your freezer faces
the wall.
2- When you place it on the corner, leave a clearance of 150 mm (15
cm) on its back so that it faces the corner. You may lean the side on
the corner to the wall. (Figure 4)
The most important point for any kind of placement is that the venti-
lation of the compressor assembly is not blocked. Place your product
so that it is not inclined in any way and that it is standing on its legs
or castors and then operate it. (Figure 5)
Your product shall operate more eciently when the ventilation of
the compressor assembly is better.
Figure 4 Figure 5
INSTALLATION
Take o and remove all package materials and lower wooden pallet of
your product before placing it. (It may be required to lift the freezer to
remove the base bracket).
Install spare parts provided inside your product as per the installation

19
instructions. Use only genuine Simfer spare parts.
Non-genuine spare parts may cause risks for you and may damage
your product.
Place your product where you desire. Consider the placing rules spec-
ied in the manual during placement.
Level your product laterally and vertically with a spirit level. Perform
the levelling procedure with the adjustable legs on the front lower part
of your freezer.
OPERATION OF THE CONSERVATOR
Rules for Electrical Connection
Your product shall operate when you plug it to an outlet.
CAUTION!
Do not plug your product to a multi-socket or do not use an exten-
sion cord.
Your product is not equipped with an on/o switch.
Do not allow the cables of your product connected to the mains to
contact hot surfaces. Outlet that shall be used shall always be ground-
ed. It the outlet that shall be used shall also be protected with a proper
fuse with a rating of 10-16 A minimum. Always get support from our
authorized service or a qualied electrician for the fuse that shall be
installed on the electrical installation where the outlet is connected.
(Figure 6)
The voltage and frequency of mains power should be the same as the
values specied on the label on the inner surface of your product. If
mains power is far below or above the specied value, have the desired
voltage by using a voltage regulator.
You can get help from a qualied electrician.
Do not put the cable of your product on passage routes. These may
cause injury to you and damage to your freezer.

20
Figure 6
THERMOSTAT SETTING
Temperature settings of your freezer is performed in our factory for
operation in suitable conditions.
Temperature for the preservation of the food is adjusted with the
thermostat by observing it from the thermometer on your freezer (op-
tional).
Internal temperature of your freezer may be adjusted by rotating the
thermostat switch. Position “7” on the thermostat shall decrease the
internal temperature to the minimum level. Internal temperature of
your product may be set between -16°C and -24°C.
Loading Food Into Your Freezer
You may load any food you desire as per the examples provided in
this manual in your freezer when the freezer has reached the desired
temperature as empty. (If your product model is equipped with a ther-
mometer, you may control the internal temperature here.
Always consider the maximum load capacity while loading frozen
food in your product. Do not exceed the loading mark on your product.
WARNING! Operate your product three (3) hours without load be-
fore loading your food.
Do not put materials that shouldn't be cooled in your product.
The basket carriage capacities used in your product are specied be-
low.
