Simple Home WyndenHall brooklyn+max AXCBC-003-WH User manual

AVINGTON /MIA /HAYES
FLOORSTORAGECABINET
MODEL#AXCBC‐003‐WH

DONOTRETURN
FORREPLACEMENTPARTSOROTHERINQUIRIES
PLEASECONTACTUSAT:
simpli‐home.com/customer‐support
PLEASEENSURETOHAVETHEMODEL#
FROMTHEPACKAGINGOR
INSTRUCTIONBOOKLET

IMPORTANT:Pleasereadthismanualcarefullybeforebeginning
assemblyofthisproduct.Keepthismanualforfuturereference.
Identifyallthepartsandhardware. Donotdiscardofthepackaginguntilyou
havecheckedthatyouhaveallofthepartsandhardwarerequired.Hardware
packagemayhavespareparts.
WARNING:Thisitemcontainssmallpartswhichcanbeswallowedbychildren
andpets.Keepchildrenandpetsawayduringassembly.Toavoiddangerof
suffocation,alwayskeepplasticbagsawayfromchildrenandpets.
Werecommendthatyouassemblethisunitonacarpetedfloortoavoid
scratches.Wedonotrecommendtheuseofpowertoolsforassemblyasthis
coulddamagetheunit.Onlyusemanualtools.
Requires2peopleforeaseofassembly.
SAFETYINFORMATION
CAREandMAINTENANCE

Toclean,useasoftorslightlydampcloth,thenwipewithaclean,drycloth.
Dustwithasoftdrycloth.
Donotuseammonia‐basedcleaningproducts,astheywilldamagethefinish.
Donotleaveliquidsordampclothsonthisfurniture.
Toavoiddullingofthefinish,donotplacethisfurnitureindirectsunlight.
Pleaseinspectandtightenallscrewsorboltsonaregularbasistoensure
properperformanceandsafetyofyouritem.



TOOLSREQUIRED
Phillips
screwdriver Level

HARDWAREDESCRIPTION
Part Description Quantity
AA Wood Dowel 24
BB Cam Bolt 8
CC Cam Lock 8
DD Screw 10
EE Screw 2
FF Magnet 1
GG Screw 2
HH Handle 1
II Screw 1
JJ Plastic Anchor 1
KK Screw 9
LL Metal Hinge 2
MM Magnet Plate 1
NN Bracket 2
OO Screw 1
PP Cable 1
QQ Screw 4
PRE‐ASSEMBLY
NEEDHELP?Forhelpwithassemblyori
f
youaremissingapart,
Pleasecallcustomerserviceat1‐866‐518‐0120ext.262
(
9amto5
p
mEST
)

PACKAGE CONTENTS
Part Description Quantity
A
Cabinet Top 1
B Left Side Panel 1
C Right Side Panel 1
D Front Top Cross Ba
r
1
E Doo
r
1
F Middle Shelf 1
G Bottom Shelf 1
H Back Cross Ba
r
1
I Back Board 1
J Front Bottom Cross Ba
r
1
PRE‐ASSEMBLY
NEEDHELP?Forhelpwithassemblyorifyouaremissingapart,
Pleasecallcustomerserviceat1‐866‐518‐0120ext.262
(
9amto5
p
mEST
)

ASSEMBLY
1 Assembling the Left and Right Side Panel
□Lay down the left side panel (B) and screw four cam bolts (BB) into the pre-drilled holes by using a Phillips screwdriver.
□Lay down the right side panel (C) and screw four cam bolts (BB) into the pre-drilled holes by using a Phillips screwdriver.
□Attach the magnet (FF) to the right side panel (C).
□Insert two screws (EE) through holes on magnet (FF) then tighten to the right side panel (C) using a Phillips screwdriver.
2 Assembling the Door
□Lay down the door (E) and attach two metal hinges (LL) to the door (E) by inserting four screws (KK) through the holes on the metal
hinge (LL) and tighten to the door (E) using a Phillips Screwdriver.
□Attach the magnet plate (MM) to the door (E) by inserting one screw (KK) through the hole on the magnet plate (MM) and tighten to
the door (E) using a Phillips screwdriver.

ASSEMBLY
3 Assembling the Back Cross Bar, Middle Shelf, Front Top Cross Bar, Bottom
Shelf and Front Bottom Cross Bar
□Attach the front top cross bar (D), middle shelf (F), back cross bar (H), bottom shelf (G) and front bottom cross bar (J) to the right
side panel (C) by inserting cam bolts (BB) into cam lock holes and inserting wood dowels (AA) into dowel holes on the front top
cross bar (D), middle shelf (F), back cross bar (H), bottom shelf (G) and front bottom cross bar (J).
□Insert four cam locks (CC) into cam lock holes on the middle shelf (F) and bottom shelf (G) separately then rotate clockwise to
secure cam bolts in place using a Phillips screwdriver.
4 Assembling the Left Side Panel
□Insert two wood dowels (AA) into the dowel holes on the front top cross bar (D). Insert two wood dowels (AA) into dowel holes on
the middle shelf (F). Insert two wood dowels (AA) into dowel holes on the back cross bar (H). Insert two wood dowels (AA) into
dowel holes on the bottom shelf (G). Insert two wood dowels (AA) into dowel holes on the front bottom cross bar (J).
□Attach the left side panel (B) to the middle shelf (F) and bottom shelf (G) by inserting four cam locks (CC) into cam lock holes on the
middle shelf (F) and bottom shelf (G). Rotate clockwise to secure cam bolts in place using a Phillips screwdriver.

ASSEMBLY
5 Assembling the Cabinet Top
□Attach the cabinet top (A) to both pre-assembled side panels (B) and (C) by inserting four wood dowels (AA) into dowel holes in
both side panels (B) and (C).
□Insert four screws (QQ) through the holes on the top of both side panels (B) and (C), then tighten using a Phillips Screwdriver.
6 Assembling the Back Board
□Attach the back board (I) to the left side panel (B), right side panel (C), bottom shelf (G) and back cross bar (H) by inserting ten
screws (DD) through the holes on the back board (I). Then tighten into the cabinet.
□Attach the bracket (NN) to the center of the cabinet top (A).
□Insert the screw (OO) through the hole on the bracket (NN) and tighten to the cabinet top (A) using a Phillips screwdriver.

ASSEMBLY
7 Assembling the Door
□Attach the door (E) to the left side panel (B) by inserting four screws (KK) through the holes on the hinges (LL) and tighten.
□Attach the handle (HH) to the door (E) by inserting two screws (GG) through holes on the door (E), then tighten the handle (HH) using
a Phillips screwdriver.
8 Attaching to the Wall (if desired)
□According to the position of the bracket (NN) assembled to the cabinet, drill a hole on the wall.
□Insert one plastic anchor (JJ) into the hole on the wall then attach another bracket (NN) to the plastic anchor (JJ).
□Insert one screw (II) through bracket (NN) and tighten to the plastic anchor (JJ).
□Place the cabinet against the wall.
□Insert the cable (PP) through the bracket (NN) on the cabinet then through the bracket (NN) on the wall. Fasten the cable (PP) to
affix two brackets (NN) firmly.
