Simplicity ZERO TURN TP 400-2169-01-ZT-SMA User manual

Parts Manual
Rev. 6/1999
TP 400-2169-01-ZT-SMA
ZEROTURN
ZT SERIESRIDERS& MOWERDECKS
16HPRIDERS
Mfg. No.Description
1692906 16HP, ZTRider
1692908 16HP, ZTRider
1692911 16HP, ZTRider
1693143 16HP, ZTRider (Export)
1693288 16HP, ZTRider
1693292 16HP, ZTRider (Export)
1693298 16HP, ZTRider
1693302 16HP, ZTRider
14HPRIDERS
Mfg. No.Description
1692905 14HP, ZTRider
1692907 14HP, ZTRider
1692910 14HP, ZTRider
1693140 14HP, ZTRider (Export)
1693286 14HP, ZTRider
1693290 14HP, ZTRider (Export)
1693296 14HP, ZTRider
1693300 14HP, ZTRider
MOWERDECKS
1692912 38” Mower Deck
1692913 38” Mower Deck
1692914 44” Mower Deck
1692915 44” Mower Deck

© Copyright 1999 Simplicity Manufacturing, Inc.
All Rights Reserved. Printed In USA.
MANUFACTURING, INC.
500 N Spring Street / PO Box 997
Port Washington, WI 53074-0997 USA

TP 400-2169-01-ZT-SMA
Table of Contents
This Manual Covers The Following Products:
14HP RIDERS PAGES
Mfg. No. Description
1692905 14HP, ZT Rider 2, 6, 8, 10, 14, 18,
1692907 14HP, ZT Rider 20, 22, 24
1692910 14HP, ZT Rider
1693140 14HP, ZT Rider (Export)
1693286 14HP, ZT Rider 2, 6, 8, 12, 14, 18
1693290 14HP, ZT Rider (Export) 20, 22, 24
1693296 14HP, ZT Rider
1693300 14HP, ZT Rider
16HP RIDERS PAGES
Mfg. No. Description
1692906 16HP, ZT Rider 2, 6, 8, 10, 14, 18,
1692908 16HP, ZT Rider 20, 22, 24
1692911 16HP, ZT Rider
1693143 16HP, ZT Rider (Export)
1693288 16HP, ZT Rider 2, 6, 8, 12, 14, 18,
1693292 16HP, ZT Rider (Export) 20, 22, 24
1693298 16HP, ZT Rider
1693302 16HP, ZT Rider
38” MOWER DECKS PAGES
Mfg. No. Description
1692912 38” Mower Deck 22, 24, 26, 28, 30
1692913 38” Mower Deck
44” MOWER DECKS PAGES
Mfg. No. Description
1692914 44” Mower Deck 22, 24, 32, 34, 36
1692915 44” Mower Deck
TRACTOR COMPONENTS
Frame, Body & Fuel System Group . . . . . . . . . . . . . . .2
Front Column & Dash Group . . . . . . . . . . . . . . . . . . . .6
Engine Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Electrical Group With Module . . . . . . . . . . . . . . . . . .10
Electrical Group Without Module . . . . . . . . . . . . . . . .12
Transaxle & Carrier Group . . . . . . . . . . . . . . . . . . . . .14
Transaxle SERVICE PARTS - (Eaton 778-010) . . . . . .18
Wheels & Tires Group . . . . . . . . . . . . . . . . . . . . . . . .20
Decals — Safety & Common . . . . . . . . . . . . . . . . . . .22
Decals — Brand & Model . . . . . . . . . . . . . . . . . . . . .24
Drive System Update Kit — 1686752 . . . . . . . . . . . .26
MOWER DECK COMPONENTS
38” Mower Deck - Deck, Arbors & Blades . . . . . . . . .28
38” Mower Deck - Belt, Clutch & Support . . . . . . . . .30
38” Mower Deck - Height Adjustment Rollers . . . . . .32
44” Mower Deck - Housing, Arbors & Blades . . . . . .34
44” Mower Deck - Belt, Clutch & Support . . . . . . . . .36
44” Mower Deck - Height Adjustment & Rollers . . . .38
REFERENCE INFORMATION:
Part Number Index . . . . . . . . . . . . . . . . . . . . . . . . . .40
Torque Specification Chart . . . . . . . . .Inside Back Cover
© Copyright 1999 Simplicity Manufacturing, Inc. All Rights Reserved.

2
TP 400-2169-01-ZT-SMA
© Copyright 1999 Simplicity Manufacturing, Inc. All Rights Reserved.
Frame, Body & Fuel System Group
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
A-ZT42501C
The above parts group applies to the following Mfg. Nos.:
1692905 14HP, ZT Rider
1692906 16HP, ZT Rider
1692907 14HP, ZT Rider
1692908 16HP, ZT Rider
1692910 14HP, ZT Rider
1692911 16HP, ZT Rider
1693140 14HP, ZT Rider (Export)
1693143 16HP, ZT Rider (Export)
1693286 14HP, ZT Rider
1693288 16HP, ZT Rider
1693290 14HP, ZT Rider (Export)
1693292 16HP, ZT Rider (Export)
1693296 14HP, ZT Rider
1693298 16HP, ZT Rider
1693300 14HP, ZT Rider
1693302 16HP, ZT Rider
67
1
2
3
4
5
6
5
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
19
29
30
28
19
19
19
32
31
19
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56 57
58
59
60
61
62
63 64
65
66
69
67
68
69
4
19
27

3
