Simpson Dura-Vent 5"x 8" Direct Vent System User manual

1
APPLICATION
TheseinstructionsapplytotheSimpsonDura-Vent5"x8"DirectVentSystem.This
ventingsystem,incombinationwiththegasappliance,hasbeentestedandlistedas
adecorativegasappliancesystem,orasadirectventheatersystembyamajor
testingagencysuchasUL,AGA,CGA,OmniorWarnockHersey. Checkthe
manufacturer'sratingplateandinstructionmanualtoconfirmthattheSimpson
Dura-Ventdirectventsystemisapprovedforuseonthebrandnameapplianceyou
haveselected.
IMPORTANT
Readallinstructionscarefullybeforestartingtheinstallation. Failuretofollowthese
instructionsmaycreateafireorothersafetyhazard,andwillvoidthewarranty. Be
suretochecktheappliancemanufacturer'sinstallationinstructionsforspecific
ventingandclearancetocombustiblerequirements,whichmayvaryfromone
appliance to another. Do not extend the venting system vertically or
horizontally in excess of the distance prescribed in the appliance
manufacturer'sinstallationinstructions.
INSTALLATION PRECAUTIONS
TheSimpsonDura-VentDirectVentSystemisanengineeredproductthathasbeen
designedandtestedforusewithanapprovedlistofdirectventgasappliances. The
SimpsonDura-Ventwarrantywillbevoided,andseriousfire,health,orothersafety
hazardsmayresultfromanyofthefollowingactions:
•InstallationofanydamagedDirectVentcomponent.
•UnauthorizedmodificationoftheDirectVentSystem
•Installationofanycomponentpartnotmanufacturedorapprovedby
SimpsonDura-Vent.
•InstallationotherthanasinstructedbySimpsonDura-Ventandthe
appliancemanufacturer.
5"x 8" DIRECT VENT
INSTALLATION INSTRUCTIONS FOR
DECORATIVE GAS APPLIANCES
AND DIRECT VENT HEATERS

2
Consultyourlocalbuildingcodesbeforebeginningtheinstallation.
WARNING
• Always maintain required clearances (air spaces) to nearby
combustiblestopreventafirehazard. Donotfillairspaceswithinsulation.
Besuretochecktheappliancemanufacturers'sinstallationinstructionsforminimum
clearance requirements between the outer walls of the vent pipe and nearby
combustiblesurfaces. Besuretochecktheventterminationclearancerequirements
fromdecks,windows,soffits,gasregulators,airsupplyinlets,andpublicwalkways,
asspecifiedintheseinstallationinstructionsandlocalbuildingcodes.
•Thegasapplianceandventsystemmustbeventeddirectlytothe
outside of the building, and never be attached to a chimney serving a
separatesolidfuelorgas-burningappliance. Eachdirectventgasappliance
mustuseit'sownseparateventsystem. Commonventsystemsareprohibited.
SAFETY PRECAUTIONS FOR THE INSTALLER
•Wearglovesandsafetyglassesforprotection.
•Exerciseextremecautionwhenusingladdersoronrooftops.
•Beawareofelectricalwiringlocationsinwallsandceilings.
PARTS LIST
TheSimpsonDura-VentDirectVentSystemoffersacompletelineofcomponent
partsforbothhorizontalandverticalinstallations. Decorativebrassorchrometrim
kitsareavailableforbothwallthimblecoversandceilingsupportboxes. Snorkel
terminationsareavailableforapplicationswhichmayrequireverticalriseonthe
buildingexterior.

3
PARTS LIST
Number Description
1208B 6"PipeLength,BlackFinish
1207B 9"PipeLength,BlackFinish
1206B 12"PipeLength,BlackFinish
1204B 24"PipeLength,BlackFinish
1203B 36"PipeLength,BlackFinish
1202B 48"PipeLength,BlackFinish
1211B 11"to14-5/8"Pipe,Adjustable,BlackFinish
1217B 17"to24"Pipe,Adjustable,BlackFinish
1245B 45°Elbow,BlackFinish
1290B 90°Elbow,BlackFinish
1240 RoundCeilingSupport/WallThimbleCover
1241 CathedralCeilingSupportBox
1242 WallFirestop
1243 Flashing,0/12to6/12RoofPitch
1243S Flashing,7/12to12/12RoofPitch
1247 WallThimble(onlyrequiredinCanada)
1253 StormCollar
1263 CeilingFirestop
1288 WallStrap
1281 SnorkelTermination(36")
1282 SnorkelTermination(14")
1284 HorizontalSquareTermination
1285 HorizontalSquareTermination,HighWind
1280 VerticalTermination
1291 VerticalTermination,HighWind
1250 VinylSidingStandoff

4
Fig 3
APPLIANCE
ADAPTOR
Fig 2
PIPE
LENGTH
PIPE
LENGTH
90° ELBOW
Fig 1
PIPE
LENGTH
ROUND CEILING
SUPPORT / WALL
THIMBLE COVER
APPLIANCE
ADAPTOR
CEILIING
FIRESTOP
FLASHING
VERTICAL
TERMINATION
ROUND CEILING
SUPPORT/WALL
THIMBLE COVER CATHEDRAL
CEILING
SUPPORT BOX
APPLIANCE
ADAPTOR
HORIZONTAL
TERMINATION
HORIZONTAL
TERMINATION
PIPE
LENGTH
PIPE
LENGTH
STORM
COLLAR
ROUND CEILING
SUPPORT/WALL
THIMBLE COVER

5
PLANNING YOUR INSTALLATION
Therearetwobasictypesof DirectVentSysteminstallations. Checktheappliance
manufacturer'sinstallationinstructionstoconfirmwhattypesarepermitted,andalso
checkforanyventingrestrictionssuchasmaximumhorizontalrun,andminimumor
maximumverticalrise. Thetwogeneraltypesofinstallationsare:
•Horizontal Termination(Figs1and2)
•Vertical Termination(Fig3)
Whenplanningyourinstallation,itwillbenecessarytoselecttheproperlengthof
ventpipeforyourparticularrequirements. Forhorizontalinstallations,checkthe
appliancemanufacturers'sinstallationsinstructionstodeterminetheminimum
clearancefromtherearoftheappliancetothewall. Itisalsoimportanttonotethe
wallthickness. Selecttheamountofverticalrisedesiredfor"vertical-to-horizontal"
typeinstallations(verifythatitiswithintheappliancemanufacturer'sminimumor
maximum limits). To determine the length of vent pipe required for vertical
installations,measurethedistancefromtheapplianceflueoutlettotheceiling,the
ceilingthickness,theverticalriseinanatticorsecondstory, andallowforsufficient
ventheightabovetheroofline. Fortwo-storyapplications,firestopsarerequired
ateachfloorlevel. Ifanoffsetisneededintheattic,additionalpipeandelbowswill
berequired.
HORIZONTAL INSTALLATION
Step1. Setthegasapplianceinitsdesiredlocation. Checktodetermine
ifwallstudsorroofraftersareinthewaywhentheventingsystemisattached. If
thisisthecase,youmaywanttoadjustthelocationoftheappliance.
Step2. DirectVentpipeandfittingsaredesignedwithspecialtwist-lock
connections. Toconnecttheventingsystemtotheapplianceflueoutlet,atwist-lock
applianceadaptorisrequired. Withsomebrandsofappliances,theSimpsonDura-
Ventadaptorwillbebuiltintotheapplianceatthefactory. Withotherbrands, it
willbesuppliedbythe appliancemanufacturer,forinstallationinthefield. Assemble
thedesiredcombinationofblackpipeandelbowstotheapplianceadaptorwith
pipeseamsorientedtowardsthewallorfloor,asmuchoutofviewaspossible. If
the appliance adaptor is not built into the appliance at the factory, it may be
preferabletoassemblethepipeandelbowstotheadaptorpriortomountingthe
adaptorontothestove. Inthismanner,thepipeand90°elbowassemblymaybe
properlytwist-lockedandrotatedtofacethewalltermination,withfinalpositioning

6
oftheventpipeassemblydeterminedbythe
mountingorientationoftheapplianceadaptor
ontothestove. (Fig4)
Notes:(1)Twist-lockprocedure: Four
indentations,locatedonthefemaleendsof
pipesandfittings,aredesignedtoslidestraight
onto the male ends of adjacent pipes and
fittings,byorientingthefourpipeindentations
so they match and slide into the four entry
slotsonthemaleends.(Fig5) Pushthepipe
sectionscompletelytogether,thentwist-lock
onesectionclockwiseapproximatelyone-
quarterturn,untilthetwosectionsarefully
locked. Thefemalelockinglugswillnotbe
visible from the outside of the Black Pipe
sections. Theymaybelocatedbyexamining
theinsideofthefemaleends.
(2) Horizontalrunsofventmustbesupportedeverythreefeet. UseWall
StrapsorPlumber'sTape/Strappingforthispurpose.
(3) Sealantisoptional,unlessspecifiedbytheappliancemanufacturer.
Shouldyouelecttousesealant,itisonlynecessaryontheoutertubeofthePipe
Section.Runa1/8"widebeadofsealantaroundthemaleendoftheoutersleeve,
asshowninFigure5,andtwist-lockthepipesorfittingstogether.
Fig 4
Fig 5
FEMALE
LOCKING
LUGS
SEALANT
(OPTIONAL
UNLESS
SPECIFIEDBY
THE APPLIANCE
MANUFACTURER)
MALE
LOCKING
LUGS
Step3. Withtheadaptorandpipeattachedtothestove,slidethestove
intoit'scorrectlocation,andmarkthewallforasquareholeoftheappropriatesize.
Use an 11" x 11" square hole
when using 5" x 8" pipe. The
centerofthesquareholeshould
lineupwiththecenterlineofthe
horizontal pipe, as shown in
Figure 6, unless otherwise
required by the appliance
manufacturer. Cutandframethe
square opening in the exterior
wall where the vent will be
terminated. If the wall being
penetrated is constructed of

7
noncombustiblematerialonly,i.e.
masonryblockorconcreteonly,a
hole with zero clearance is
acceptable.
Notes:
(1) The horizontal run of vent
mustbelevel, orhavea1/4"rise
forevery1footofruntowardsthe
termination. Neverallowthevent
to run downward. This could
causehightemperaturesandmay
presentthepossibilityofafire.
(2)Thelocationofthehorizontal
ventterminationonanexteriorwall
mustmeet all localand national
buildingcodes, and must not be
easily blocked or obstructed.
Termination clearances are as
follows:
(a) Clearanceabovetheground,
veranda,porch,deckorbalcony: 12inchesminimum.
(b) Clearance to a window (openable or fixed closed) or door: 12
inchesminimum.
(c) Verticalclearancetoaventilatedsoffitlocatedabovethetermination
(ifsoffitextendsahorizontaldistanceof 2feetoutoverthecenterline
ofthetermination): 18inchesminimum.
(d) Clearancetoanunventilatedsoffit: 12inchesminimum.
(e) Clearancetoanoutsidecorner: astestedbyappliancemfgr.
(f) Clearancetoaninsidecorner: astestedbyappliancemfgr.
(g) Nottobeinstalledaboveameter/regulatorassemblywithin3feet
horizontallyfromthecenterlineoftheregulator.
(h) Clearancetoaserviceregulatorventoutlet: 6feetminimum.
(i) Clearancetonon-mechanicalairsupplyinlettoabuildingorthe
combustionairinlettoanyotherappliance: 12inchesminimum.
(j) Clearancetoamechanicalairsupplyinlet: 6feetminimum.
(k) Clearanceaboveapavedsidewalkorpaveddrivewaylocatedon
publicproperty: refertolocalcode.
Fig 6
CENTER
OF HOLE

8
(l) Clearance under a
veranda, porch, deck or
balcony: 12 inches
minimum.
Forinstallationsrequiringa
verticalriseontheexterior
ofthebuilding,14-inchand
36-inch tall Snorkel
Terminations,asshownin
Figure 7 are available.
Followthesameinstallation
procedures as used for
standard Horizontal
Terminations.IftheSnorkel
Termination must be
installedbelowgrade,(i.e.
basement application),
proper drainage must be
provided to prevent water
from entering the Snorkel
Termination.RefertoFigure
8. Donotattempttoenclose
theSnorkelwithinthewall,
or any other type of
enclosure.
Step 4. Position the
HorizontalVentTermination
in the center of the square
hole, and attach to the
exteriorwallwiththefour
woodscrewsprovided. Beforeattachingtheventterminationtotheexteriorwall,
runabeadofnon-hardeningsealantaroundit'soutsideedges,soastomakeaseal
between itandthewall. Thearrowontheventcapshouldbepointingup. Insure
thatproperclearancestocombustiblematerialsaremaintained. (Fig9)
Notes:
(1) Thefourwoodscrewsprovidedshouldbereplaced withappropriate
fastenersforstucco,brick,concrete,orothertypesofsidings.
12 INCHES
MINIMUM
SNORKEL
Fig 7
Fig 8
SNORKLE
12 INCHES
MINIMUM
ADEQUATE
DRAINAGE

9
Fig 10
WOOD SCREW
(4) REQ
CUTVINYLSIDINGAWAY
TO FITSTANDOFF
NUT(4)
REQ
BOLT(4)
REQ
(2) Forbuildingswithvinylsid-
ings, aVinylSidingStandoff,should
beinstalledbetweentheventcapand
theexteriorwall.(Figure10). Attach
theVinylSidingStandofftotheHori-
zontalVentTermination. TheVinyl
SidingStandoffpreventsexcessive
heatfrompossiblymelting thevinyl
sidingmaterial. NotethattheHori-
zontalVentTerminationboltsonto
the flat portion of the Vinyl Siding
Standoff,(shadedareashowninFig-
ure10),sothatanairspacewillexist
betweenthewallandtheVentTermi-
nation. FollowthelabelontheStand-
off for which side of the Standoff
faceswall.
Step 5. Before connecting the
horizontalrunofventpipetotheventtermination,slidetheBlackDecorativeWall
ThimbleCoverovertheventpipe.
Step6. Slidetheapplianceandventassemblytowardsthewall,carefully
insertingtheventpipeintotheventcapassembly. Itisimportantthattheventpipe
extendintotheventcapa
sufficientdistancesoasto
provideaminimumpipe
overlapof 1-1/4inches.
Securetheconnectionbe-
tween the vent pipe and
theventcapbyattaching
thetwosheetmetalstrips
extendingfromthevent
cap assembly into the
outerwalloftheventpipe.
Use the two sheet metal
screwsprovidedtocon-
nectthestripstothePipe
Section. Bend any re-
WOOD
SCREWS
Fig 9

10
Fig 11
Fig 12
WOOD
SCREWS
1-1/4"
SHEET
METAL
SCREW
FOLD
STRAP
HERE
maining portion of the sheet
metal strip back towards the
vent cap, so it will be con-
cealedbytheDecorativeWall
ThimbleCover. (Fig11)
Step7. SlidetheDeco-
rativeWallThimbleCover up
tothewallsurfaceandattach
to the wall with screws pro-
vided. Applyoptionaldeco-
rativebrassorchrometrimif
desired. (Fig12)
VERTICAL TERMINATION
Step 1. Check the appliance
manufacturers'sinstallationinstructionsfor
requiredclearances(airspaces)tocom-
bustibleswhenpassingthroughceilings,
walls,roofs,enclosures,atticrafters,or
othernearbycombustiblesurfaces. Do
notpackairspaceswithinsulation. Check
theappliancemanufacturer'sinstructions
formaximumverticalriseoftheventing
system,andanymaximumhorizontaloff-
setlimitations.
Step2. Setthegasappliancein
it's desired location. Drop a plum bob
downfromtheceilingtothepositionofthe
applianceflueexit,andmarkthelocation
wheretheventwillpenetratetheceiling.
Drillasmallholeatthispoint. Next,dropaplumbbobfromtherooftothehole
previouslydrilledintheceiling,andmarkthespotwheretheventwillpenetratethe
roof. (Fig13) Determineifceilingjoists,roofrafters,orotherframingwillobstruct
theventingsystem. Youmaywishtorelocatetheappliance,ortooffsetthevent
pipe toavoidcuttingload-bearing members.
Step3. ToinstalltheRoundCeilingSupport/WallThimbleCoverinaflat
STRAP
WALL
THIMBLE
COVER

11
ceiling,cutan11"x11"squareholeintheceiling,centered
ontheholedrilledinStep2(unlessotherwisespecifiedby
theappliancemanufacturer). Frametheholeasshownin
Fig 14. Step4. IftheTwist-lockApplianceAdaptorhas
notbeeninstalledontheappliancebythemanufacturer,
installitnowinaccordancewiththeapplianceinstruction
manual. Step5. AssemblethedesiredlengthsofBlack
PipeandElbowsnecessarytoreachfromtheAppliance
AdaptorupthroughtheRoundCeilingSupport. Insure
thatallPipeandElbowconnectionsareintheirfullytwist-
lockedposition.
Step6. Cutaholeintheroofcenteredonthesmall
drillholeplacedintheroofinStep2. Theholeshouldbe
ofsufficientsizetomeettheminimumrequirementsfor
clearancetocombustibles,asspecifiedbytheappliance
manufacturer. Continuetoassemblelengthsof Pipeand
ElbowsnecessarytoreachfromtheRoundCeilingSupport
upthroughtheroofline.
Notes:
(1) Ifanoffsetisnecessaryin
theattictoavoidobstructions,it
isimportanttosupportthevent
pipe every 3 feet, to avoid
excessivestressontheElbows,
and possible separation. Wall
Straps are available for this
purpose. (Fig15)
(2) Wheneverpossible,
use45°Elbows,insteadof90°
Elbows. The45°Elbowoffers
lessrestrictiontotheflowofflue
gasesandintakeair.
Step7. Sliptheflashing
over the Pipe Section(s)
protruding through the roof.
Fig 13
Fig 14
1-1/2 INCH LONG
WOOD SCREWS
FRAMING
ROUND
SUPPORT
BOX/WALL
THIMBLE
COVER
CEILING
JOISTS
PLUM
BOB
MARK
LOCATION
VENT
DRILL
HOLE

12
SecurethebaseoftheFlashingtothe
roofwithroofingnails. Useanon-
hardeningsealantbetweentheuphill
edge of the flashing and the roof.
Insuretheroofingmaterialoverlaps
thetopedgeoftheFlashingasshown
inFig17. Verifythatyouhaveatleast
the minimum clearance to
combustiblesattheroofline.
Step 8. Continue to add Pipe
Sectionsuntiltheheightofthepipe
(before adding cap) meets the
minimumbuildingcoderequirements
described in Fig 16. Note that for
steep roof pitches, the vent height
must be increased. In high wind
conditions,nearbytrees,adjoining
rooflines, steep pitched roofs, and
othersimilarfactorscanresultinpoor
draft,ordown-drafting. Inthesecases,
increasingtheventheight,orchanging
thetotheHighWindCap,maysolve
thisproblem
Step9. SliptheStormCollar
overthePipe,andpushitdowntothe
topoftheFlashing,asshowninFig17.
Usenon-hardeningsealantaroundthe
jointbetweentheStormCollarandthe
Pipe. Step10. TwistlocktheVent
Capontothelastpipesection.
DIMENSION "H"
OBTAINED
FROM TABLE 1
H


TABLE 1
ROOF PITCH MINIMUM HEIGHT
FEET METERS
FLAT TO 7/12 1 0.3
OVER 7/12 TO 8/12 1.5 0.46
OVER 8/12 TO 9/12 2 0.61
OVER 9/12 TO 10/12 2.5 0.76
OVER 10/12 TO 11/12 3.25 0.99
OVER 11/12 TO 12/12 4 1.22
OVER 12/12 TO 14/12 5 1.52
OVER 14/12 TO 16/12 6 1.83
OVER 16/12 TO 18/12 7 2.13
OVER 18/12 TO 20/12 7.5 2.29
OVER 20/12 TO 21/12 8 2.44
Fig 16
45°
ELBOW
45°
ELBOW
WALL STRAP
PLUMBER'STAPE
CONNECTEDTO
WALL STRAP
Fig 15

13
Fig 17
Notes:(1) For multi-storyverticalinstallations,aCeilingFirestopisrequiredat
thesecondfloor,andanysubsequentfloors. (Fig18). Theopeningshouldbe10.5"
x10.5"andframedsimilartotheopeninginStep3.
(2) If Vent passes through any occupied areas above the first floor,
includingclosetsandstoragespaces,itmustbeenclosed. Theenclosuremaybe
framedandsheetrockedwithstandardconstructionmaterials,howeverconsult the
appliancemanufacturer'sinstallationinstructionsfortheminimumallowableclearance
betweentheoutsideoftheventpipe,andthecombustiblesurfacesoftheenclosure.
Donotfillanyoftherequiredairspaceswithinsulation.
CATHEDRAL CEILING INSTALLATION
Step1. FollowinstallationSteps1and2 underVerticalTerminations.
Step2. Usingtheplumb-bob,markthecenterlineoftheventingsystemon
theceilinganddrillasmallholethroughtheceilingandroofatthispoint. Fromthe
roof,locatethedrillholeandmarktheoutlineoftheCathedralCeiling SupportBox.
Step3. Removeshinglesorotherroofcoveringasnecessarytocutthe
rectangularholefortheSupportBox. Cutthehole1/8-inch largerthantheSupport
Boxoutline.
Step4. LowertheSupportBoxthroughtheholeintheroofuntileachside
of thebottomoftheSupportBoxprotrudesatleast2-inchesbelowtheceiling.(Fig
19). AligntheSupportBoxbothverticallyandhorizontallywithalevel.Temporarily
ROOFING NAILS
VERTICAL
TERMINATION CAP
STORMCOLLAR
FLASHING
OPTIONAL
HIGH WIND
TERMINATION
CAP

14
Fig 18
tacktheSupportBoxinplacethrough
the inside walls and into the roof
sheathing.
Step5. Usingtinsnips,cutthe
SupportBoxfromthetopcornersdown
to the roofline, and fold the resulting
flapsovertheroofsheathing.(Fig20)
Beforenailingittotheroof,runabead
ofnon-hardeningsealantaroundthetop
edges of the Support Box, to make a
seal between the Box and the roof.
Cleanoutanycombustiblematerialfrom
insidetheSupportBox.
Step6. FollowSteps4and5of
theVerticalInstallationInstructions.
Step7. PlacetheSupportClamp
(providedwiththeSupportBox)inside
the Support Box (at the bottom), and
securetothePipeSection. TheClamp
allowstheSupportBoxtosupporttheweightofthePipeSections.
Step8. FollowSteps6through10oftheVerticalInstallationInstructions.
Step9. InstalltheblackTrimCollararoundtheoutsideoftheCathedral
Ceiling Support Box. The two
pieces of the Trim Collar slide
over one another to allow for
easy adjustment around the
SupportBox. Usingthesix(6)
screwsprovided,securethefour
corners and the overlaping
sectionsoftheTrimCollartothe
ceiling. You may want to pre-
drilltheholesfortheoverlapped
sectionsforeaseofinstallation.
SeeFigure21. CUT HOLE TO 1/8 INCH
GREATER SIZE THAN
PATTERNOFSUPPORT
BOX AS IT IS PROJECTED
ONTO ROOFLINE
LEVEL
CATHEDRAL
CEILING SUPPORT
BOX
Fig 19
2 INCHES
MINIMUM
BELOW FINISHED
CEILING
CEILING
FIRETOP
NAILS
CLEARANCES
AS DEFINED
BY APPLIANCE
MFG
CLEARANCES
AS DEFINED
BY APPLIANCE
MFG
CLEARANCES
AS DEFINED
BY APPLIANCE
MFG
CLEARANCES
AS DEFINED
BY APPLIANCE
MFG

15
GENERAL MAINTENANCE
Conductan inspectionoftheventing
systemsemi-annually. Recommended
areastoinspectareasfollows:
1. Check areas of the Venting
System which are exposed to the
elementsforcorrosion. Thesewillappear
asrustspotsorstreaks,andinextreme
cases,holes. Thesecomponentshould
immediatelybereplaced.
2. RemovetheCap, andshineaflashlightdowntheVent. Removeany
birdnests,orotherforeignmaterial.
3. Checkforevidencesofexcessive
condensate,suchaswaterdropletsforming
intheinnerliner,andsubsequentlydripping
outatjoints. Continuous condensate can
causecorrosionofcaps,pipe,andfittings. It
maybecausedbyhavingexcessivelateral
runs,toomanyelbows,andexteriorportions
ofthesystembeingexposedtocoldweather.
4. Inspectjoints,toverifythatno
PipeSectionsorFittingshavebeendisturbed,
and consequently loosened. Also check
mechanicalsupportssuchasWallStraps,or
plumbers'tapeforrigidity.
LABELS
All componentsarelabelledwiththeappropriateidentificationinformation. Pipe
andfittingswhicharepaintedblack,havethelabelplacedontheinsideoftheouter
sleevenearthemaleend.
Fig 20
SCREWS
TRIM COLLAR
CATHEDERAL
CEILING
SUPPORTBOX
Fig 21

16
SIMPSON
DURA-VENT, INC
PO Box 1510
Vacaville, CA
95688-1510
Vicksburg,MS
(800)-835-4429
(707)-446-4740(FAX)
Other products made by Simpson Dura-Vent:
Dura/Plus Chimney
Dura-Vent Gas Vent (B-Vent)
Dura-Black Single Wall Stovepipe
Dura/Liner Masonry Reliner
DVL Close Clearance Connector Pipe
Dura/Connect Single-Wall Connector for B-Vent
DuraFlex Masonry Reliner for Gas Appliances
Designer Series Accessories
Nov. 1997
L953
