Mambo Surface Prep
Operating Manual
Read before use and keep safe
[phone] [phone] Fax [phone]
6686 Merchandise Way Diamond Springs, Ca 95619
www.sineqco.com

2
Table of Contents
1.0 Technical Data Page 3
2.0 Safety Page 3
3.0 Safety Instructions Page 3
4.0 Maintenance Page 5
5.0 Use Page 7
6.0 Vacuum Unit Page 7
7.0 Trouble Shooting Page 8
8.0 Spare Parts/Schematics Page 9

1.0 Technical data/technical description
Power supply 110V 50 Hz
Power consumption 2300W
No-load speed 100 – 400 Strokes/min
Sound pressure level 56 dB(A)
Sound energy level 69 dB(A)
Hand/Arm-Vibration < 4,5 m/s²
Weight 155 lbs
Comes with: Mambo Surface Prep, safety goggles and tool kit.
2.0 Safety
The Sinclair Mambo Surface Prep is state of the art designed and meets all
standard safety requirements.
3.0 Safety Instructions
Disconnect the power supply before any maintenance is carried out. Use only recommended
mounting discs and brushes. The mounting discs must have a plain surface. Use only genuine
Sinclair discs and brushes. Other parts could affect the safety of the machine.
Always use the safety – and suction ring.
Otherwise parts of the sub-floor may be
cast out and endanger other persons.
Always lock the additional weight with the
screw nuts. Use only the genuine Sinclair
weight. DO NOT USE ANY OTHER
WEIGHTS!
Maintenance should be undertaken only by
qualified personnel. Use only genuine
Sinclair parts.
Use only appropriate detergent liquids.
Check the power cord and the plug before
starting. Both of them must be in perfect
condition, the insulation must not be damaged.
Have damaged insulation repaired at once,
before starting the machine.
Otherwise this may result in considerable
danger to the user.
Speed Control
3

4
For your won safety start work always at low speed, and then increase the speed. This is
especially important, if the sub-floor condition or the discs used are not well known.
CAUTION!!! Always wear ear and eye protectors! CAUTION!!!
Using this machine without ear and eye protectors may jeopardize or harm your health.
It may harm especially your ears and increase the risk of an accident.
The user and any person within range should always use ear protectors!
PLEASE READ DETAILED SAFETY INSTRUCTIONS ON COLORED
SHEET BEFORE USING MACHINE!
3.1 Introduction
This operating manual should be used to receive the maximum benefit from your Mambo
Surface Prep. Following these instructions will both extend the life of your machine and
reduce repair costs.
Please ensure that any user of the machine is familiar with these instructions before work
begins.
3.2 Danger while working with the machine
The Mambo Surface Prep is designed to the highest technical standards. Incorrect use can be
dangerous!
Use this machine only:
- As instructed in this operating manual.
- With the machine in perfect working order.
Disturbances that could impair safety have to be eliminated at once.
3.3 Restriction of use
The Mambo Surface Prep is exclusively for wet-cleaning and polishing of resilient and textile
floor coverings, and for grinding and milling pavement and leveling compounds in dry
environments. It should not be used for any other purpose. Sinclair Equipment Company
cannot be held responsible for any damage or loss caused by incorrect use.

3.4 Genuine Spare Parts
Spare parts and accessories are manufactured uniquely for the Mambo Surface Prep. It must be
emphasized that parts obtained from unauthorized sources must not be used.
Sinclair Equipment Company cannot be held responsible for the performance of or any damage
arising from the use of machines in which genuine spare parts have not been used.
This is particularly important with milling discs.
4.0 Maintenance
The Mambo Surface Prep is virtually maintenance free. The roller bearings and gear box
need not be lubricated.
5.0 Use
Inserting the safety and suction ring
Lay the machine down on the handle. Thus
the support of the discs is accessible.
-Insert safety ring
-Mount at once a disc to fix the
suction ring
Assembly of mounting discs, pads and brushes
Lay the machine down on the handle. Thus
the support of the discs is accessible. Put the
mounting disc on the actuation and lock it
by turning anti-clockwise.
Mounting the additional weight
Always lock the additional weight with the
screw nuts. Use only the genuine Sinclair
weight.
Do not use any other weights! This may
overstress the machine.
5

Use:
- Mount discs or brushes as described above.
- Put the handle in working position with the
big lever (1) at the back.
- We recommend to position the hand grip to
the height of the users hip.
- Lift the handle slightly, to make sure the
machine stands horizontally.
- Keep the safety switch (2) pressed.
- Switch on the machine with one of the levers
(3) located beneath the grip.
- Release switch (2).
Note: lever can only be actuated, if the handle
is not in vertical position. This is a safety
feature! The user cannot control the machine
with the vertical handle. After switching on
the machine, the handle will move shortly to
the right.
If the transportation wheels are in lifted
position, the direction in which the machine
moves, is controlled by lifting or lowering
the grip. The more you lift or lower the
grip, the faster the machine runs to the
corresponding direction.
-Lifting the machine: machine runs to the right.
-Lowering the machine: machine runs to the left.
If you feel unsafe or cannot control the machine, just release lever (3). The machine will stop
at once. If you have carried out some training, you will be able to operate the machine with
one hand.
If the transportation wheels are lowered to the floor, the machine is stabilized and easier to
control.
-Lifting and lowering of the handle is no more necessary.
-The machine has to be in a level position. The wheels have to be fixed accordingly.
By loosening the release handle (5), the wheels can be put in upper and lowered position.
Speed control:
Adjust the speed of the discs with switch (4).
Turning clock-wise increases the speed,
turning anti-clockwise decreases the speed.
The optimal speed is dependent on the disc
used and the sub-floor.
6

The table below is meant as a guiding principle for the user. Always test the optimum speed in
each case. Always start at low speed and then increase the speed.
Speed Use Recommended Disc
160–200 Grinding screed and leveling compounds Sand paper
200-300 Grinding parquet, removing leveling compounds
and adhesive residues Carbide grinding disc and Milling disc
300-400 Removing leveling compounds Milling disc
Always remove discs after work.
Always disconnect the power cord after work or when leaving the machine.
Transportation
For transportation, fold the handle forwards.
For carrying the machine, use the grips at the
front and at the back.
6.0 Vacuum Unit for the Mambo Surface Prep
Mounting the Vacuum Micropac
Assemble the vacuum unit from the front of the
Handle of the machine.
- Insert vacuum into the lower support
- Turn vacuum at the top against the handle.
Engage fixing pin.
- Fasten hose to the vacuum by turning
clockwise.
- Attach hose to the outlet spigot of the
machine.
7

Mounting or changing the paper bags of the Vacuum Micropac Unit
Paper bags are used for the vacuum unit Micropac.
Replacement paper bags, 20 piece, Item # M13498.
-Release the 2 snap fasteners (B) and
remove lid (C).
-Ensure inner cloth filter is clean.
-Ensure rubber molding (D) is firmly
fitted around top rim of container.
-Gently open new dust bag and place in
vacuum container. Slide flange (A) of
the dust bag over inlet spigot (E) until
secure.
-Replace and secure lid with 2 snap
fasteners.
To facilitate the removal of a full dust bag, tube (E) may be withdrawn from the
vacuum unit container having firstly removed elbow connector (F).
7.0 Troubleshooting
Trouble Eventual Cause Elimination
Machine does not start Power supply disconnected
Blown fuse
Defective cable or plug
Have a machine repaired by
a qualified electrician,
resp. change parts
Switch-on lever cannot be
actuated Safety lever can only be actuated, if handle not vertical Lower the handle of the machine
Machine stops Lamp flashes fast
Overload protection responds Power plug disconnect Wait some minutes
Switch the machine on again
8.0 Schematic/Parts List
Schematic # Pieces Description Part #
1 1 Housing 017830
2 1 Disc cover 037933
8

9
3 1 Back panel 037935
4 1 Support chain wheel 017872
5 1 Handle support 015404
6 1 Additional weight 038311
7 2 Cylindrical screw M10 x 70 018298
8 2 Wheel hub 017922
9 2 Square nut 017605
10 2 Counter Sink Screw M8 x 14 017698
11 1
Cylindrical screw M4 x 12 018284
12 1
Lever (handle adjustment) 014648
13 1
Handle mounting 017925
14 1
Chain wheel 016922
15 1
Recessed grip 017594
16 3
Oval head screw M4 x 10 014804
17 2
Split pin 014888
18 2
Thumb nut 016995
19 1
Power socket 014653
20 4 Washer 017637
21 2
Wheel 014645
22 4
Counter Sink Screw M4 x 16 017702
23 4
Hexagon nut 014831
24 1
Counter sunk screw M8 x 50 017631
25 2
Cylindrical screw M3 x 30 017744
26 2
Stop nut 017768
27 2
Washer 014829
28 2
Hexagon nut 014817
29 2
Dowel pin 018058
30 2
Washer M8 014860
31 2
Hexagon bolt 014775
32 1
Rubber washer 018624
33 1
Motor 037293
34 1
Chassis 037957
35 1 Electronics 038287
36 2
Handle 037940
37 3
Cylindrical screw M8x20 014734
43 1
Cable 037956
45 1
Axle 037967
46 1
Chassis 037958
49 9
Cylindrical screw M6 x 20 014730
50 6
Stop nut M6 014815
51 7
Washer 014827
52 4
Cap nut M6 017728
53 13
Washer M6 014859
54 4
Tallow-drop screw 017680
55 2
Washer 018236
56 2
Cylindrical screw M10 x 20 018301
57 2
Washer M10 014861
58 2
Locking screw M10 x 80 014789
59 1 Holding device electronics 037963 or 037962
61 1
Cylindrical screw M6 x 25 014731
64 1
Cache 016138
65 2
Nut M10 038290
66 2
Cylindrical screw M8 x 25 014735

10
67 8
Screw 5/16" 037936
68 1
Plate 038502
69 4
Cylindrical screw M4 x 20 017725
70 2
Connection 038285
71 2
Handle 037954
72 2
Clamping lever 037952
73 1
Intermediate flange 037966
74 1
Upper flange 037965
75 1
Lower flange 037964
76 6
Cache 037951
77 1
Coupling flange 015401
78 3
Distance washer 015402
79 12
Counter sunk screw M8 x 12 038423
80 3
Counter sunk screw M8 x 18 014759
150 1
Knob 014647
152 1
Two-hand switch 015000
153 1
Lever 017894
154 1
Base support 017858
155 1
Switch housing 017875
156 1
Press plate 017901
157 1 Foam grip 015421
158 1
Counter sink screw 017632
160 6
Square nut 017605
161 1
Fixing pin 015406
162 2
Clamp socket 015431
165 2
Cable hanger 015427
167 1
Towing bar 017592
168 1
Spring (handle adjustment) 014898
169 2
Starlock head D8 014880
170 2
Cylindrical screw M8 x 40 014738
172 2
Counter sink screw M8 x 18 014759
173 1
Profile rod 017843
175 4
Washer 014828
176 1
Headless Pin M8 x 30 017523
178 1
Potentiometer 014650
179 1
Control wire 038032
181 2
Cylindrical screw M4 x 8 017473
185 2
Hexagon nut M8 014810
187 2
Washer 017663
188 2
Cap nut M8 014825
190 2
Headless Pin M8 x 35 014790
191 1
Cable pit 038289
193 1
Cylindrical screw M4 x 55 017639
194 4
Cable clamp 017680
195 4
Oval head screw M4 x 25 017680
196 1
Hexagon nut M10 017013
197 1
LED lamp 038281
198 1 Wiring 039006
STANDARD WARRANTY

MAMBO HANDLE

11
SINCLAIR EQUIPMENT COMPANY’S tools are warranted to be free of defects in workmanship and
materials for a period of one year from the date of original purchase. Should any trouble develop during
this one year period, return the complete tool, freight prepaid, to SINCLAIR’S authorized Service Center.
If inspection shows the trouble is caused by defective workmanship or materials, SINCLAIR
EQUIPMENT COMPANY will repair, or, at its option, replace without charge.
•This warranty does not apply to malfunctions caused by damage, unreasonable use, faulty repairs
made by others, or failure to provide recommended maintenance.
•The warranty is void if the product is altered by the original consumer purchaser, or if it is used in a
manner not recommended by the manufacturer.
•The warranties do not cover consequential damages or transportation charges incurred with the
replacement or repair of SINCLAIR EQUIPMENT COMPANY products.
•Not responsible for lost job or down time.
In no event shall SINCLAIR be liable for any indirect, incidental, or consequential damages from the sale
or use of the product. This disclaimer applies both during and after the term of this warranty.
SINCLAIR EQUIPMENT COMPANY disclaims liability for any implied warranties, including implied
warranties of “merchantability” and “fitness for a specific purpose”, after the one year term of this
warranty.
This warranty gives you specific legal rights, and you may have other rights which vary from state to
state. Should you have any questions, contact SINCLAIR EQUIPMENT COMPANY at [phone].
To obtain warranty service, deliver or send the complete tool, prepaid, to SINCLAIR EQUIPMENT
COMPANY. Be sure to include the following information:
•Nature of failure;
•Name and address of distributor where tool was purchased;
•Application of tool when rendered defective; and
•Proof of purchase.
To obtain individual repair parts, contact SINCLAIR EQUIPMENT COMPANY with the following
information:
•Tool model number;
•Item part number; and
•Description of part.

12
