Singer 7322.7312 User manual

Parts List
S I N G E R
Model 7322.7312
029190039(1版)
(Model 995D2.996D2)
R

A

Page A Page A
No. Part No. Description No. Part No. Description No. Part No. Description
1 EJD6033210 Back cover 37 V60273006 Dialtensionspringplate 71 EJD0084210 Sewing table complete
2 V610155000 Thread guide complete 38 EAC7783210 Dial tension knob 72 E1A1823210 Sewing table body
3 004230326* Set screw (M3x12) 39 004300713* Washer (5.2x10x0.2) 73 EJD0083210 Sewing table body cover
4 E1A2065000 Bobbin winder thread guide complete 40 004500360* Washer (WW-5) 74 E1A1863210 Cord reel cover
5 E1A2053001* Bobbin winder thread guide adjusting 41 004300643* Washer (5.2x10x0.5) 75 004240046* Set screw (M4x10B)
6 H13153001 Bobbin winder thread guide spring 42 004240286* Set screw (M4x13B) 76 E4C6003210 Motor drive belt cover
7 H13133001 Bobbin winder spring disc 43 004240146* Set screw (M4x15B) 77 E1A1723003 Motor drive belt cover frame
8 V610223001 Bobbin winder thread guide 44 004240176* Set screw (M4x6D) 78 004241106* Set screw (M4x0.7A)
9 E1A2353006 Spacer 45 H11103001 Dial tension guide spring tube 79 E4A0233210 Selector dial
10 003010036 E-Ring(E-3) 46 EAC9274210 Bobbin winder frame complete (7322) 80 E1A1703210 Adjusting dial
11 004840106 Nut(ALN-4) 46 EAD9294210 Bobbin winder frame complete (7312) 81 EAD0023210 Front cover (7322)
12 E1A2043001 Thread guide 47 E1A1785000 Bobbin winder frame 81 EAD3013210 Front cover (7312)
13 004240982 Setscrew (M3) 48 003043006* Spring pin (Ø 3x8x0.6) 82 004240306* Set screw (M4x10B)
14 V61253006 Armtopcoverplate 49 V61183000 Feedregulatorgear 83 E1A1883001 Arm top cover thread guide plate
15 004240106 Setscrew (M4x8A) 50 EAC9273210 Feed regulator dial (7322) 84 F4A8763210 Zig zag width dial
16 E1A1663210 Spool rod 50 EAD929320 Feed regulator dial (7312) 85 004900063 Washer
17 004230655 Setscrew (M3x1.06B) 51 004300186* Washer (6.2x12x0.5) 86 E3A0113006 Zig zag width dial plate
18 V410123210 Plate 52 003010046* E-Ring (E-4) 87 004240056* Set screw (M4x6B)
19 E1A1763210 Handle 53 EAA0203003 Feed regulator set plate 88 004300076* Washer (4.2x9x0.5)
20 004706013 Nut(9/64x40 t=3) 54 004230215 Setscrew(M3x8.5) 89 E3A0143006 Zig zag width crank
21 E1A2393000 Bobbin winder stopper 55 V61165000 Bobbin winder crank complete 90 E3A0153003 Zig zag width crank rod
22 E1A1673002 Arm back cover set plate 56 F20213000 Bobbin winder rubber pulley 91 F4A8764210 Zig zag width dial complete
23 END0044210 Dial tension complete 57 V61563003 Bobbin winder crank spring 92 V61503210 Plate(1)
24 EJD0033210 Dial tension supporter plate cover 58 003011052* E-Ring (E-5) 93 003020053 Washer(CS-5)
25 E1A2073000 Thread guide sprig 59 E5D0073000 Pattern display frame 94 V630593000 Thread cutter
26 003020453* CS ring 60 EJD7193210 Face plate 95 004106162* Set screw (9/64x40x16)
27 V61873000 Threadguide 61 004240782* Set screw (M4x10B) 96 H10133211 Sewing table body guide
28 E1A2183006 Dial tension supporter plate 62 E1A2523000 Heat resistant plate 97 H10143005 Sewing table body guide spring
29 003043010 Springpin(Ø3x10x0.6) 63 E5D0063000 Pattern display window
30 E1A2113003 Dial tension waft plate 64 E1A1623002 Arm front cover set plate
31 003010043* E-Ring (E-4) 65 E3A0203210 Free arm base
32 J30423001 Dialtensiondisc(1) 66 004240136 Setscrew(M4x12)
33 E1A2333001 Dial tension disc 67 E1A1753210 Free arm foot bush
34 R10593000 Dial tension spring regulator 68 008465000 Sticker
35 NB1083000 Dial tension spring 69 004230746 Setscrew(M3x12)
36 K50193000 Dial tension regulator 70 E1A1843000 Sewing table body felt

B

Page B Page B
No. Part No. Description
1 E1A2683001 Thread take up lever
2 E1A2653000 Thread take up lever supporter
3 003010036* E-Ring (ETW-3)
4 V60223003 Thread take up lever supporter shaft
5 E1A2313003 Thread take up lever supporter shaft plate
6 004240106* Set screw (M4x8A)
7 E1A2663000 Arm shaft balance pin complete
8 E1A2213000 Arm shaft balance
9 004240223 Set screw (M4x6)
10 003043524* Arm shaft balance pin (Ø3.5x24)
11 003010093 E-Ring(ETW-9)
12 R10293000 Arm shaft bushing
13 E1A2623003 Arm shaft bushing holder plate
14 004400080 Endure attrition washer
15 R10313000 Arm shaft collar
16 004250203* Set screw (M5x5)
17 004250346* Set screw (M5x10)
18 V16893210 Hand wheel decorated plate
19 E1A0063000 Arm shaft worm
20 007163471 Motordrivebelt
21 E1A0083000 Motor drive belt
22 F4A0033000 Arm shaft sprocket
23 E1A0065000 Arm shaft worm complete
24 004300853* Washer (10.2x15x0.5)
25 E4A0143210 Arm shaft drive belt pulley
26 E1A0044000 Arm shaft
27 004107283* Spring pin (11/64x40x5)
28 003043018* Spring pin (Ø3x18)
29 R10393000 Arm shaft clutch annulus spring
30 R10403000 Arm shaft collar
31 E1A0073210 Hand wheel
32 004300586* Hand wheel washer (5.2x16x1.0)
33 E1A2693000 Thread take up lever spring

C

Page C Page C
No. Part No. Description No. Part No. Description No. Part No. Description
1 E1A0013000 Arm 37 E3A0253004 Needle plate 73 E1A1543006 Reverse lever
2 E1A1373003 BH selector plate 38 NB1293000 Needle plate cover 74 004240883 Reverseleversetscrew
3 E1A1393003 BH slide plate 39 004240851* Set screw (M4x6) 75 E1A1553003 Reverse rod
4 004103081 Set screw (SM3/32×56 L=5) 40 NB0233000 Needle plate cover open 76 EJD0143210 Reverse button
5 003010036* E-Ring (ETW-3) 41 E1A2593000 Needle plate cover 77 E1A2103003 BH cam plate
6 E1A2713000 Needle plate cover plate 42 004103072* Set screw (SM3/32x56 L=3) 78 V61205003 Clutch rod complete
7 E1A0603002 Rotary hook plate (2) 43 E1A0584000 Rotary hook plate complete 79 V61233003 Clutch rod plate
8 E1A2613002 Needle bar stopper plate 44 E1A0593002 Rotary hook plate 80 V61233003 Clutch rod
9 F30893000 Rotary hook plate spring (2) 45 004240056* Set screw (M4x6B) 81 E1A2603000 Needle plate spring
10 F30883000 Rotary hook plate spring (1) 46 E1A0103000 Needle bar supporter 82 H10253000 Needle bar bracket (1)
11 004220056 Set screw (M2×2.5) 47 NB0533000 Needle bar 83 H10263000 Needle bar bracket (2)
12 E1A1283003 Zig zag width regulating cam plate
48 003080052* E-Ring (BETW-5) 84 F4A3343000 Needle bar crank rod
13 003010043* E-Ring (ETW-4) 49 E1A1893000 Needle bar supporter pin 85 004240503 Set screw (M4x4)
14 E1A1333003 Zig zag width spring 50 003010046* E-Ring (ETW-4) 86 H10723003 Tension lever lifter spring
15 004300713* Washer (5.2x10x0.2) 51 V61243003 Clutchrodspring 87 EJD0193000 Micro switch supporter (1)
16 E1A1303002 Zig zag width regulating cam 52 E3A0013003 Needle bar driving rod
17 E1A1323003 Zig zag regulator crank 53 E1A2433000 Needle bar driving rod pin
18 004240633* Set screw (M4x12) 54 E1A0113000 Auto threaded shaft
19 004840106 Set Nut (ALN-4) 55 R12793003 Auto threaded shaft spring
20 E1A1343003 Rod 56 003042014* Spring pin (Ø2x14)
21 004240503* Set screw (M4x4) 57 003042006 Springpin
22 E1A0243003 Movement plate supporter (1) 58 004106233* Set screw (9/64x40x7)
23 E1A0235000 Movement plate supporter 59 E1A0123000 Auto threaded lever
24 003010036* E-Ring (ETW-3) 60 M70093000 Auto threaded lever spring
25 V620163210 Presser bar regulating screw 61 E1A2125000 Auto threaded
26 E1A0143000 Presser bar 62 E1A0193003 Needle bar supporter plate
27 E1A2493003 Presser bar spring 63 E1A0203003 Needle bar supporter plate pin
28 E1A0163003 Presser bar bracket complete 64 H10205000 Needle clamp complete
29 E1A2093003 Presser bar lifter lever shaft 65 R12573000 Needle guide plate
30 003010053* E-Ring (ETW-5) 66 H10223000 Needlebarthreadguide
31 004240353 Presser bar lifter lever shaft set 67 004103011 Setscrew
32 E1A0173000 Presser bar lifter lever 68 006046148 Needle
33 006910008 Shankcomplete 69 M70073002 Auto threaded stopper
34 004106211 Shank complete set screw 70 004230016* Set screw (M3x6A)
35 006918008 Zip zap presser foot complete 71 H10195000 Needlebarcrankrodcomplete
36 E1A2323003 Presser bar bracket spring 72 H50583003 Needlebarsupporter spring

D

Page D Page D
No. Part No. Description No. Part No. Description
1 EAD0014000 Pattern cam contact complete 37 FCA0093000 Stretch stitch release
2 E1A0673003 Pattern cam contact plate (back) 38 004240503* Set screw (M4x4)
3 E1A0653003 Pattern cam contact plate (front) 39 E1A0893003 Zig zag release plate
4 H11935000 Pattern cam shaft collar complete 40 004840106* Nut (ALN-4)
5 E1A0683003 Pattern cam shaft 41 004240633* Set screw (M4x0.7)
6 003010063* E-Ring (ETW-6) 42 E1A0843000 Zig zag cam contact supporter shaft
7 EAA0053000 Pattern cam 43 003010056* E-Ring (ETW-5)
8 EAA0153003 BH Selector cam 44 E1A0853003 Zig zag cam contact supporter
9 F4A3124000 Selector dial plate complete 45 EAA0103003 BH Feed crank
10 003042516* Spring pin (Ø2.5x16) 46 EAA0063003 Zig zag cam contact
11 E1A1243006 Selectordialshaft 47 E1A0973003 BH Feed crank spring
12 F4A3303003 Selectordialplate 48 EAA0093003 BH adjusting crank
13 F4A3113000 Selector gear 49 EAA0073003 SS cam contact supporter
14 004300676* Washer(3.2x8x0.8) 50 EAA0083003 SS cam contact
15 004241093* Set screw (M4x0.7) 51 E1A0903003 Zigzagrelease plate
16 EAA0023000 Stretch stitch selector cam 52 E1A0943003 Feed rock shaft
17 H70553003 Spring 53 E1A0983003 BH adjusting plate
18 M70093000 Autothreadedleverspring 54 E1A0993003 Stretch stitch release plate
19 E1A1133003 BH adjusting rod 55 E4D0064000 Selector dial plate
20 EAA0043000 SS cam 56 004240056* Set screw (M4x6B)
21 004300863* Washer (8.2x14x0.5) 57 E4D0033000 Pattern gear
22 EAA0033000 Feed regulator cam 58 E4D0053000 Pattern selector plate
23 004230286* Set screw (M3x8B) 59 004230215 Setscrew(M3x8.5)
24 E1A1003003 Pattern cam contact supporter shaft 60 EAD5993210 Selector plate
25 EAA0183003 Pattern selector cam shaft 61 003010036* E-Ring (ETW-3)
26 EAA0143000 Pattern selector cam 62 004300833* Washer (6.6x14x0.25)
27 004240423 Setscrew(M4) 63 E1A1113000 Adjusting shaft
28 E1A1033003 Pattern selector adjusting lever 64 003010043* E-Ring (ETW-4)
29 004240046* Set screw (M4x10B) 65 E1A1123003 BH adjusting hook holder
30 004240106* Set screw (M4x8A) 66
31 E1A1053000 Zig zag cam 67
32 E1A1223003 Feed regulating crank spring 68
33 E1A1043000 Pattern selector cam shaft 69
34 E1A1073006 Zig zag movement contact 70
35 E1A1083003 Movement plate 71
36 004230016* Set screw (M3x6A) 72

E

Page E Page E
No. Part No. Description
1 EAA0213006 BH lever plate
2 E1A2373000 Shield
3 002425118 Switchass’y
4 001251409 Foot controller (4C-316B202ZH) U.S.A.
5 004250086 Setscrew(M5x12)
6 004240056 Setscrew(M4x6B)
7 004600296 SpringWasher(5.2x9x1)
8 004300306 Washer(5.4x10x0.9)
9 003010036 E-Ring(ETW-3)
10 002145029 Motorfeedregulatorcollar
11 004240106 Setscrew(M4x8 A)
12 008059302 Cushionrubber
13 E1A1973210 Receptacle holder cover
14 002027129 Cordclip
15 004230286 Setscrew(M3x8)
16 002252129 Receptacle holder
17 002253129 Receptacle
18 002254129 Consentinsulationplate
19 004230045 Setscrew(M3x20)
20 004240066 Setscrew(M4x8B)
21 004830015 Nut(M3t=2.3)
22 AA0463000 End termind
23 002396028 Beltwheelplate
24 002511418 Lamp holder complete (for 220-240V)
25 005120021 Lamp(120V 10W E-12)
26 004230055 Setscrew(M3x5)
27 001459409 Motorcomplete(for120V3M-782JS404ZH)
28 004300966 Washer(4.2x8x2.5)
29 002503125 Motorbracket
30 004840051 Nut
31 002396029 Beltwheel

Page F Page F
No. Part No. Description No. Part No. Description No. Part No. Description
1 NB0693000 Bobbin shaft oil cloth 37 004104012* Set screw (1/18x44x5) 73 E1A1873003 Spring
2 E1A2033000 Bobbin shaft 38 E1A0443003 Feed rock crank pin (1) 74 H12883000 Steel ball
3 NB0673000 Bobbin shaft washer (2) 39 E4A0223002 Feed rock crank 75 NB0495000 Lower shaft gear plate
4 003010046* E-Ring (ETW-4) 40 E1A0453003 Feed lifting rock crank (2)
5 NB1275000 Shuttle hook complete 41 004240633 Feed back crank screw
6 NB0643000 Magnet 42 E1A0345000 Belt adjusting plate complete
7 NB1265000 Shuttle hook holder 43 E1A0353000 Belt adjusting plate
8 NB0683000 Bobbin shaft washer (3) 44 H12323000 Belt adjusting plate pulley
9 E1A0563000 Needle plate cover 45 004240585* Set screw (M4x8)
10 004230066* Set screw (M3x12) 46 F30333000 Feed regulating block
11 E1A0463000 Feed crank shaft 47 E1A0474000 Feed regulating plate complete
12 E1A0523000 Rotary hook holder 48 F30353000 Feedregulating
13 E1A0553000 Rotary hook holder positioned plate
49 004400570* Endure attrition washer
14 004240056* Set screw (M4x6B) 50 R11443000 Feed rock bushing
15 E1A0543000 Rotary hook supporter 51 004300123* Washer (6.7x12x1)
16 004240033* Set screw (M4x5) 52 003011052* E-Ring (ETW-5)
17 004240106* Set screw (M4x8A) 53 E1A0483003 Feed regulating shaft
18 K82133003 Base plate adjustment screw 54 E1A0503003 Feed regulating crank
19 H70043000 Free arm vase cushion rubber 55 E1A0493003 Feed crank
20 004840106 Adjustingnut(ALN-4) 56 E1A2503000 Free arm vase cushion rubber
21 E1A2343003 Feed regulating spring 57 004240046* Set screw (M4x10B)
22 E1A0373000 Feed rock shaft 58 E1A0283000 Lowershaft bushing
23 E1A0403003 Feed rock frame shaft (2) 59 NB0503000 Lower shaft gear
24 004240503* Set screw (M4x4) 60 003010063* E-Ring (ETW-6)
25 E1A0423003 Feed rock frame shaft (1) 61 E1A0305000 Feed lifting rock cam complete
26 E1A0383003 Feed rock bushing pin (1) 62 E1A0290000 Feed lifting rock cam
27 003010043* E-Ring (ETW-4) 63 E1A0333003 Lower shaft spring
28 004300643* Washer (5.2x10x0.5) 64 004300936* Washer (8.2x12x0.5)
29 E1A2023003 Feed shaft spring 65 E1A0325000 Feed rock cam complete
30 E1A2083210 Feed rock crank 66 E1A0273000 Lower shaft
31 F30323003 Feed rockcrankpin 67 V11553003 Lower shaft collar
32 004240223* Set screw (M4x6) 68 004400830 Endure attrition washer
33 003010036* E-Ring (ETW-3) 69 E1A0313000 Lower shaft belt pulley
34 F30284000 Feed rockshaftcollar 70 004230673* Set screw (M3x14.5)
35 E1A0413000 Feed rock frame 71 E1A2573003 Base plate adjustment screw spring
36 E3A0033001 Feed dog 72 E1A0573210 Feed lifting shaft

G
I
N G
E
R
S

Page G Page G
No. Part No. Description
1 006900008 Hemmer foot(K)
2 006918008 Zigzagfoot©
3 006914008 Button sew on foot
4 006907008 Overcastting foot (E)
5 006904008 Blindhemfoot(F)
6 006905008 Zipper foot(I)
7 006171008 Buttonhole foot (D)
8 006008001 Quilting bar
9 006051009 Anti-rusty
10 006052009 Drier
11 006011009 Accessories bag
12 006099008 Brush ＆Seam ripper complete
13 006013009 Oilier
14 006093009 Large & smallscrew drive
15 006175008 Needle
16 006015009 Feltcushion
17 006066008 Bobbin
18 TA10943209 Spool set plate (small)
19 R12373210 Spool set plate (big)
20 006172008 Satin stitchfoot
21 006185008 Walkingfoot
22 006813008 Cordingfoot
23 006917008 Gathering foot
