SIP Neo3 User manual
06/29/17 FR
12:15
GUIDE TO
INSTALLATION,
OPERATION &
PROGRAMMING
SEL
COPYRIGHT©2017 SIP TECHNOLOGIES, LLC. ALL RIGHTS RESERVED. SIP AND THE SIP LOGO ARE TRADEMARKS OF
SIP TECHNOLOGIES, LLC, REGISTERED IN THE U.S. AND OTHER COUNTRIES.
GUIDE TO
INSTALLATION,
PROGRAMMING
& OPERATION
UK VERSION
2
Copyright © 2017
CONTENTS
Important Information ....................................................................................................2
Safety Precautions ..........................................................................................................3
Neo3Component Chart ...................................................................................................3
Installation Steps ............................................................................................................3
- Guide to Installing on Bottled Water Cooler ....................................................4
- Guide to Installing on Bottleless Water Cooler ................................................5
How to Program the System ............................................................................................6
Troubleshooting .............................................................................................................8
Limited Warranty ............................................................................................................8
Please note all drawings, pictures, colors and sizes are approximate for illustrative purposes only and may not exactly
resemble the end product.
• SIP NEO3is manufactured to function on various plugs, sockets, voltage and plug types. Use appropriate power cords.
• Installation must be performed by a trained technician or experienced professional.
• Inspect the carton and SIP NEO3for evidence of rough handling and concealed damages. If content appears
damaged, ask driver or contact the carrier for damage claim form to ll out. Notify shipper immediately.
• Remove components from the shipping carton. Check that all installation parts and hardware are present.
• Make complete inspection of the SIP NEO3system to ensure that:
a) There is no physical damage to the system
b) All accessories are present
• Intended for indoor use only on water dispensers.
• Use the system on a potable, safe-to-drink, COLD water supply
• Dispenser, water dispenser or compressor are references to bottle and bottleless water coolers
Read Guide to Installation, Operating And Programming, specications,
cautions and warnings before installing and using the system.
IMPORTANT INFORMATION
i
ANNUAL MAINTENANCE
• Check and replace the lter disc.
• Check and replace check valve, if appears damaged.
• Check and replace diuser, if appears damaged.
3Guide to Installation, Programming & Operating
WARNING – To guard against injury, basic safety should be observed including the following: Read all instructions,
specications, cautions, and warnings before installing and using SIP NEO3. Learn the specic details regarding installation and
use. Failure to follow them could cause serious injuries and possible property damage.
DANGER – To avoid possible electrical shock, unplug dispenser prior to installation of SIP NEO3.
All Power cords must be three-pin plugs to be grounded. Do not use two-pin plugs.
Power supply cord must be plugged into electrical wall outlet. DO NOT plug into extension cord.
Do not stand on wet oor when installing and servicing the water dispenser.
Install check valve on silicone tubing prior to the diuser to avoid water from reservoir owing backward causing damage to
ozone generating device.
SAFETY PRECAUTIONS
!
INSTALLATION STEPS
SIP NEO3is designed to use in all brands of bottle and bottleless water coolers (dispensers). The system can be installed on the
back of the dispenser or on the wall at the back of dispenser so as to display the indicator light and screen for proper consum-
er use.
Install to back of the dispenser using zip ties to secure ozone generating device and control system device onto the back of
cooler’s condenser, or the grids, or on the wall at the back of dispenser. Control Device System should be installed to the right
of the Ozone Generating Device.
HOW TO INSTALL OZONE GENERATING DEVICE AND CONTROL SYSTEM DEVICE
WHERE TO PLUG IN POWER CORDS (FIG 1)
NEO3COMPONENT CHART
Plug the main power supply cord into the “POWER” receptacle (bottom of the control device system, left side). Plug the short
power outlet cord (converter cord) into “UNIT” receptacle (bottom of the control device system, right side). Plug the water
dispenser power cord into the opposite end of the short power outlet cord (converter cord).
Important: All oat mechanisms are not identical and the
optimal location of the down rod may vary depending on
your particular oat system.
SEL
06/29/17 FR
12:15
Display Screen
Diffuser
12 Volt Connector Cable
Power Cord to Dispenser
Power Supply Cord
Filter Disc Port
Filter Hatch
Check Valve
Silicone Tube
Mounting Tab
Indicator Light
Fuse
AB
Power Unit
Air Filter Disc
Cable Lock
(Fig 1)
HOW TO SECURE THE CONNECTOR:
1. Locate the Cable Lock Cap on the side of the unit.
2. Turn the Cap counterclockwise to loosen.
3. Firmly insert the 12 Volt Connector Cable into the
Connector Cable terminal.
4. Turn the Cap clockwise to tighten, being careful not to
overtighten.
4
Copyright © 2017
GUIDE TO INSTALLING ON BOTTLED WATER COOLER
STEPS TO INSTALLING ON BOTTLED WATER COOLER
1. Make sure unit power is unplugged from wall
socket.
2. Remove the units bottled water container.
3. Remove the cap from the units drain line.
4. Drain unit water reservoir completely.
5. Locate and remove the units locking screws
from the top lid.
6. Remove the units top lid.
7. Remove the units cold water Reservoir Lid and
Bae.
8. Remove screws from units back grate.
9. Lower back grate, and loosen units Insulation
Jacket rmly with both hands.
10. Lift up and remove units Insulation Jacket to
expose the units reservoir tank.
11. Drill a 9/32” hole into the side of the Reservoir
Tank.
12. Switch the direction of the rubber Grommet
on the Down Rod so that the neck faces
inward.
13. Place the Down Rod into a free port on the
Bae.
14. Measure the distance from hole to bottom of
Reservoir and cut Down Rod to size that will
accommodate connecting the Diuser to it
using a small piece of silicon tubing.
15. Connect the Down Rod and the Diuser with
the ¼” tubing.
×
×
×
×
16. Drill or cut a 9/32” hole into the side of the
Insulation Jacket, then place it back on the
Reservoir Tank.
17. Replace the Bae with attached Down Rod,
then secure Down Rod through the Reservoir
Tank rmly with the rubber Grommet.
18. Cut your desired length of ¼”tubing for the
Neo3, then connect the rst side of the tubing
to the inlet of the Down Rod.
19. Take the ¼” tubing connected to the Down
Rod and run through the back grate of the
unit.
20. Replace the units Reservoir Lid and locking
screws.
21. Take the ¼” tubing connected to the Down
Rod and connect it to the outlet of the Neo3.
22. Connect both Neo3Housings with the 12 Volt
Connector Cable.
23. Connect the Neo3and Unit power supplies to
the appropriate ports below the Neo3Master
Housing.
24. Use the Neo3’s Mounting Tabs to mount the
Neo3on back of the unit.
25. Plug the unit back in and turn it on.
5Guide to Installation, Programming & Operating
× ×
× ×
×
×
×
×
×
× ×
× ×
× ×
×
× ×
06/29/17 FR
12:15
SEL
SEL
06/29/17 FR
12:15
SEL
06/29/17 FR
12:15
× ×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
×
××
×
×
×
GUIDE TO INSTALLING ON BOTTLELESS WATER COOLER
STEPS TO INSTALLING ON BOTTLELESS WATER COOLER
1. Make sure unit power is unplugged from
socket.
2. Remove the cap from the units drain line.
3. Drain unit reservoir completely.
4. Locate and remove the units locking screws
from the top lid.
5. Remove the units top lid.
6. Remove the units cold water Reservoir Lid.
7. Remove the units Bae.
8. Drill a 9/32” hole into the top of the units
Reservoir Lid.
9. Locate the Neo3s Down Rod, making sure
the rubber Grommet is in place.
10. Place the Down Rod through the previously
drilled 9/32” hole, then secure the Down Rod
to the Reservoir Lid with the rubber
Grommet.
11. Place the Down Rod into a free port on the
Bae.
12. Measure the distance from hole to bottom
of Reservoir and cut Down Rod to size that
will accommodate connecting the Diuser to
it using a small piece of silicon tubing.
13. Connect the Down Rod and the Diuser with
the ¼” tubing.
14. Replace Reservoir Lid on cold water
Reservoir.
15. Cut your desired length of ¼”tubing for the
Neo3, then connect the rst side of the
tubing to the inlet of the Down Rod.
16. Take the ¼” tubing connected to the Down
Rod and run through the back grate of the
unit.
17. Replace the units Reservoir Lid and locking
screws.
18. Take the ¼” tubing connected to the Down
Rod and connect it to the outlet of the Neo3.
19. Connect both Neo3Housings with the 12
Volt Connector Cable.
20. Connect the Neo3and Unit power supplies
to the appropriate ports below the Neo3
Master Housing.
21. Use the Neo3’s Mounting Tabs to mount the
Neo3on back of the unit.
22. Plug the unit back in and turn it on.
6
Copyright © 2017
INDICATOR LIGHTS ON CONTROL SYSTEM DEVICE
• The indicator lights are to display the status of the system when the SIP NEO3is in function.
• Red light is ozone indicator and is on when O3is in operation. When red light is on, sanitization is in progress. Do not
dispense or drink water when the red light is on.
• Yellow light is air indicator and is on when the air compressor is in operation.
• Green light indicates O3treatment has been successfully performed and dispenser has resumed operation. Green
Light is also a power indicator which is on when power is on. It is o when power is not connected.
HOW TO PROGRAM THE SYSTEM
SIP NEO3Display Window
The screen is an LCD backlight for clear data display. It displays data during programming and when stationery, when on and o,
and when programming operating time for the Ozone generator, air pump, and water dispenser compressor. During normal
operation this screen shows date, day of the week and time of day using a 24-hour clock mode.
The Function Buttons
There are three buttons below the LCD display window. They are used for:
• Up and Down (arrows). Press simultaneously to enter programming.
• Up (arrow). Allows cycling through each screen and to change input.
• SEL. Allows change of input, saves, and moves to next input.
Your SIP NEO3system has been programmed at the factory. Only the local time, date and day of week need to be adjusted to
make your SIP NEO3set-up complete. Follow the instructions to adjust these settings.
Function Settings
The following symbols used in the SIP NEO3LCD display panel indicates:
O3- Ozone Generator
AP - Air Pump
CO - Dispenser Compressor
When O3is displayed then you are programming the ozone operation. Likewise, the air pump and compressor/water dispenser
symbols indicate that you are programming the operation of these functions.
When O3is programmed, the AP is automatically programmed to turn on at the same time. It stays on for 10 minutes after O3
turns o. This allows the ozone to be dissipated and to leave no residual ozone in the reservoir after the program is completed.
The compressor display allows you to control the operation of the water dispenser. Therefore, the cooler can be shut down
during periods of inactivity to save energy. In addition, AP can be programmed to turn on independently at two separate times.
How to Enter Programming Mode
Press both UP & DOWN arrows simultaneously and hold to unlock the unit to allow programming.
Press UP key to scroll through the ve programmable elds:
• Use the SEL key to edit the selected functions.
• O3(Ozone Generator)/air pump program and cycle time. When in programming mode Press SEL
to enter O3programming screen.
• AP (Air Pump) programming and cycle time.
• CO (Compressor) programming and cycle time.
The Compressor Screen Has 5 Programmable Fields:
• Start day of the Week
• End day of the week
• Start daily on time
• End daily o time
• On all the time
These elds are programmed using the same methods – UP key to increment value, DN key to decrement value and SEL key to
accept the value. The operation will complete and the new values will be used from the next cycle on. In order to pre-empt the
current operation and use the new values immediately press and release DN and SEL keys at the same time.
7Guide to Installation, Programming & Operating
Generator Programming Instructions
O3, AP, CO and how to set date, day, and local time
During normal operation, the date and time are displayed.
To enter the Device Programming mode press the UP and DOWN keys together for about 3 seconds. The following screen is
displayed.
06/23/17 FR
11:30
Edit/View mode
Press UP key
Program Select (UP key)
Once in Edit Mode, a blinking cursor will appear on the rst input of that screen (use previously dened procedure)
Edit Mode
SEL
key
SEL
key
SEL
key
SEL
key
SEL
key
Set 03 Program 1
SEL-edit UP-skip
03 1 ON 04:00
03 1 DUR 10 mins
Set Compressor
SEL-edit UP-skip
CMP MO - FR
07:00 - 20:30
Set 03 Program 2
SEL-edit UP-skip
03 2 ON 20:00
03 2 DUR 20 mins
Set Air Pump
SEL-edit UP-skip
AP1 19:25 02m
AP2 19:29 04m
Set Date/Time
SEL-edit UP-skip
06/23/17 FR
11:30
Once in Device Programming Mode press UP to cycle through each screen. There are 5 programming screens. Any one of the
screens can be selected by pressing SEL.
8
Copyright © 2017
LIMITED WARRANTY
SIP NEO3IS WARRANTIED AGAINST DEFECTS IN MATERIALS AND WORKMANSHIP, UNDER NORMAL USE AND OPERATION, FOR A PERIOD
OF ONE YEAR FROM THE DATE OF ORIGINAL PURCHASE (“WARRANTY PERIOD”).
IF A DEFECT ARISES AND A VALID CLAIM IS RECEIVED WITHIN THE WARRANTY PERIOD, AT MANUFACTURER’S DISCRETION ONE OF THE
FOLLOWING WILL BE IMPLEMENTED: 1) REPAIRED AT NO CHARGE USING NEW OR REFURBISHED REPLACEMENT PARTS, 2) EXCHANGED
WITH A PRODUCT THAT IS NEW OR WHICH HAS BEEN MANUFACTURED FROM NEW OR SERVICEABLE USED PARTS AND IS AT LEAST
FUNCTIONALLY EQUIVALENT TO THE ORIGINAL PRODUCT, 3) CREDIT GIVEN FOR THE DEFECTIVE PRODUCT, OR 4) REPLACEMENT PARTS
SENT TO PURCHASER TO REPAIR THE PRODUCT.
REPLACEMENT PRODUCTS/PARTS ARE WARRANTIED AGAINST DEFECTS IN MATERIALS AND WORKMANSHIP FROM THE DATE OF
THE REPLACEMENT OR REPAIR FOR THIRTY (30) DAYS OR FOR THE REMAINING PORTION OF THE ORIGINAL PRODUCT’S WARRANTY,
WHICHEVER PROVIDES LONGER COVERAGE. WHEN A PRODUCT OR PART IS EXCHANGED, ANY REPLACEMENT ITEM BECOMES
PURCHASER’S PROPERTY AND THE REPLACED ITEM BECOMES PROPERTY OF MANUFACTURER. WHEN A REFUND IS GIVEN, PRODUCT
BECOMES MANUFACTURER’S PROPERTY.
EXCLUSIONS AND LIMITATIONS - THIS LIMITED WARRANTY APPLIES ONLY TO PRODUCTS MANUFACTURED BY OR FOR SIP THAT CAN BE
IDENTIFIED BY THE "SIP" TRADEMARK, TRADE NAME, OR LOGO AFFIXED TO IT. THIS LIMITED WARRANTY DOES NOT APPLY TO ANY NON-
SIP PRODUCT.
THIS WARRANTY DOES NOT APPLY: (A) TO DAMAGE CAUSED BY ACCIDENT, ABUSE, MISUSE OR MISAPPLICATION; (B) TO DAMAGE CAUSED
BY INSTALLATION NOT IN ACCORDANCE WITH THE SIP INSTALLATION MANUAL; (C) TO A PRODUCT OR A PART THAT HAS BEEN MODIFIED
WITHOUT THE WRITTEN PERMISSION OF SIP; OR (D) IF ANY SIP SERIAL NUMBER HAS BEEN REMOVED OR DEFACED.
TO THE MAXIMUM EXTENT PERMITTED BY LAW, THIS WARRANTY AND THE REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU
OF ALL OTHER WARRANTIES, REMEDIES AND CONDITIONS, WHETHER ORAL OR WRITTEN, EXPRESS, IMPLIED OR STATUTORY. SIP
SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY,
NON-INFRINGEMENT OF A THIRD PARTY’S RIGHTS AND FITNESS FOR A PARTICULAR PURPOSE. IF SIP CANNOT LAWFULLY DISCLAIM
OR EXCLUDE IMPLIED WARRANTIES UNDER APPLICABLE LAW, THEN TO THE EXTENT POSSIBLE ANY CLAIMS UNDER SUCH IMPLIED
WARRANTIES SHALL EXPIRE ON EXPIRATION OF THE WARRANTY PERIOD. EXCEPT FOR THE WARRANTY PROVIDED HEREIN, THE PRODUCT
IS PROVIDED “AS IS.” NO SIP RESELLER OR AGENT IS AUTHORIZED TO MAKE ANY MODIFICATION, EXTENSION, OR ADDITION TO THIS
WARRANTY WITHOUT THE EXPRESSED WRITTEN CONSENT OF SIP.
TO THE MAXIMUM EXTENT PERMITTED BY LAW, SIP IS NOT RESPONSIBLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES (INCLUDING BUT NOT LIMITED TO LOSS OF USE OR LOST PROFITS) RESULTING FROM ANY BREACH OF
WARRANTY OR CONDITION, OR UNDER ANY OTHER LEGAL THEORY. PURCHASER’S EXCLUSIVE REMEDY AND SIP’S SOLE LIABILITY ON
ANY CLAIM, WHETHER IN TORT, CONTRACT, WARRANTY OR OTHERWISE, SHALL BE LIMITED TO THE AMOUNT PAID FOR PURCHASE OF
THE PRODUCT FROM WHICH THE CLAIM AROSE AND IN NO EVENT SHALL SIP BE LIABLE FOR INDEMNIFICATION OF PURCHASER ON
ACCOUNT OF ANY CLAIM ASSERTED AGAINST PURCHASER OR FOR ANY OTHER FURTHER DAMAGES WHATSOEVER, WHETHER DIRECT OR
INDIRECT.
C. (C) 2017 SIP TECHNOLOGIES, LLC. ALL RIGHTS RESERVED. SIP AND THE SIP LOGO ARE TRADEMARKS OF SIP TECHNOLOGIES, LLC,
REGISTERED IN THE U.S. AND OTHER COUNTRIES.
TROUBLESHOOTING
• There is no power to dispenser.
• Check to make sure power supply cord is plugged into the electrical wall outlet.
• Check that power supply cord is plugged into the three-pin ”power” socket on the bottom side of control
system device.
• Check to make sure the male end of the converter cord is plugged into the female socket in the “UNIT”
on the bottom side of the control system device.
• Check to make sure the dispenser power cord is plugged into the female end of the converter cord.
• If no indicator light and/or display is on, check and replace the 10-amp fuse. It is located on the left side
of the control system device.
• There is no production or low production of O3.
• Check all cable connections to make sure all cords are plugged in properly.
• Check the programming to make sure ozone setting is set correctly.
• Check and replace the lter disc.
• Verify a check valve is on the silicon tubing after ozone generator device.
• Check and/or replace diuser.
Caution: Make sure to unplug the main power supply cord from electrical wall outlet prior to accessing
circuit boards and fuses.
?
Table of contents
Other SIP Inverter manuals
