SIRI SIRIMIX User manual

SIRI S.r.l.
Via R.Dalla Costa, 44 - 41122 Modena - ITALY
tel. [phone] - fax. [phone]
www.siri.mo.it - [email protected]
English version

Machine Directives 2006/42/EEC
www.siri.mo.it - www.tilestools.eu
ELECTRICAL MIXER SIRIMIX
INSTRUCTIONS FOR USE
V.230/50
V.120/60
V.240/50
English version
SIRI s.r.l.
Via R.Dalla Costa, 44 - 41122 Modena - ITALY
tel. [phone] - fax. [phone]
www.siri.mo.it - [email protected]
“ORIGINAL INSTRUCTIONS”
Rev.0 dated 17-12-2012

CONTENTS
Introduction Page 1
Chapter 1 DESCRIPTION of the MACHINE 2
1.1  Machinemanufacturingandidenticationdata  2
1.2  Intendeduse3
1.3  Detaileddescriptionofthemachine   4
1.3.1  Mainpartsofthemachine     4
1.3.2  Sparepartsreferencedrawings    5
1.3.3  Listofspareparts     6
1.4  Improperuseofthemachine    7
1.5  Safetydevicesandguards    7
1.6  Machinecontrols      7
1.6.1  Descriptionofcontrols     7
1.7  Technicaldata8
1.7.1  Noiselevels      8
1.7.2  Electricalsystemdiagram     8
1.7.3  Overalldimensions     8
Chapter 2 GENERAL NOTES on SAFETY 9
2.1  GenaralPoints      9
2.2  Correctuseofpersonalprotectivewear   9
2.3  Incorrectandprohibitedusesofthemachine  9
2.4  Informationonresidualrisksfactors   9
Chapter 3 INSTALLATION 10
3.1  Transport      10
3.2  Installation      10
3.3  Adjustingthemachine     10
3.4  Operatingprocedures     11
Chapter 4 MAINTENANCE 12
4.1  Routinemaintenance12
4.2  Majorservicing      12
4.3  Replacingthepaddle     12
4.4  Cleaningthemachine     13
4.5  Packing       13
Chapter 5 OPTIONAL EXTRAS 14
5.1  Bucketwithwheels     14
5.2  Fixingthebucketwithwheels    14
DECLARATION OF CONFORMITY 16
CONDITIONS OF WARRANTY 17

SIRI MIX
17/17
Page:
.............................................
.............................................
“SIRIMIX“Art.
GUARANTEE CONDITIONS
S.I.R.I. S.r.l.guaranteesallmachineparts,andwillreplaceanyofthe
samewhichprovedefectiveduetofaultsinmanufacturingmethodsor
materials,for12monthsfromthedateofpurchase.
Duringsaidperiodoftime,alltransportcostswillbeatthepurchaser’s
expense.S.I.R.I.willacceptgoodswithpre-paidcarriageonly.
Servicescoveredbytheguaranteewillonlybepossibleifthemachine
is accompanied by the guarantee certicate, if the machine has not
been tampered with, repaired by unauthorised persons or damaged
duetoimproperuse.
Thisguaranteedoes not coverpartssubject to wearduringroutine
applications.
This guarantee is valid provided that:
The purchase date is conrmed by the stamp and signature of an
authorisedagent.
Theguaranteecardhasbeenlledinandsentwithin10daysfromthe
dateofpurchase(freightbilldate)to“SIRI S.r.l.”.
IMPROPER OR UNAUTHORISED APPLICATIONS OF
THE MACHINE WILL RENDER THE PRESENT
GUARANTEE NULL AND VOID
GUARANTEE
COMPLETE THE GUARANTEE IN ALL PARTS AND SEND IT WITHIN
10 DAYS OF PURCHASE TO:
S.I.R.I. S.r.l. - Via Dalla Costa 44 - 41122 MODENA
COMPLETE AND SEND TO S.I.R.I. S.r.l.
CUSTOMER NAME
Serial n°: Date of purchase:
Stamp and signature
of dealer:

SIRI MIX
1.0
Page: Release:
16/17
DECLARATION OF CONFORMITY
We, S.I.R.I. S.r.l. - Via R. Dalla Costa, 44/46 - 41122 MODENA (ITALY)
Tel. [phone] - Fax [phone] - www.siri.mo.it - [email protected]
declare that the following machine:
Description: Electric mixer
Model: SIRIMIX SERIAL NUMBER ......................
is in conformity with Directives 2006/42/EC and 2004/108/EC and in
accordance with theharmonised technical standards:
UNI EN ISO 12100
CEI EN 60204-1
UNI EN 12418
It is furthermore declared that the manufacturer S.I.R.I. S.r.l. has drawn up the
technical le inaccordance with Annex VII, letter A of Directive 2006/42/EC.
Modena, ....................
Legal representative
…………………………………………………………

1.0
SIRI MIX
Page:
Release: 1/17
INTRODUCTION
Ourcomplimentsonyourpurchaseofourelectricalmixer“Sirimix”Art.13.
The“Sirimix”wasdevelopedtoensurethatmaximumreliabilityandfunctionaleffeciency
willbedeliveredovertime.
Thepresentmanualcontainsinportantadviceasregardssettingupthemachineonsite,as
wellasfullinformationonspareparts,cleaningandmaintenance.
Thismuchsaid,itisessentialthattheinstallerandtheusershouldbesuitablyexperienced
andknowledgeableintheuseandworkingsofthemachine.
Itissimilarlyessentialthattheoperatorreadcarefullyandadherescrupulouslytoalldirec-
tionsgiveninthemanual,relativebothtooperatingprocedures andtoroutineandmajor
servicingactivities.
Consequently,theOperationandMaintenancemanualshould be thought of as part of the
machine and kept handy at all times for ready reference whenever needed: indeed the manual
must stay with the machine from initial purchase through to nal destruction.
Intheeventofthemanualbeinglossordamaged,theoperatorcanobtainareplacement
copyfromS.I.R.I.
Whenreadingthemanualspecialattentionmustbepaidtoanypartwherethefollowing
symbolsappear:
WARNING
Indicatesanyoperationorpartoftheequipmentconsideredpotentiallyhazardousinterms
ofjeopardizingthesmoothoperationordurabilityofthemachineanditscomponentparts
DANGER
Indicatesanyoperationorpartofequipmentofthemachineconsideredpotentiallyhazardous
intermsofoperatorsafety.
This instruction manual describes:
TYPE OF MACHINE: Electrical mixer MODEL : SIRIMIX Art...............
SERIES AND TYPE: ........
YEAR OF MANUFACTURE: 20....
This manual contains information concerning storage, transport, installation, use, supervision
and maintenance of the machine described.
This manual is an integral part of the machine and must be kept throughout the entire service
life of the same for future consultation. If your copy of the manual becomes unreadable, ask
the maker for a new copy at the following address:
SIRI SRL
Via R.Dalla Costa, 44 - 41122 MODENA (ITALY)
Tel. [phone] - Fax [phone]
E-mail: [email protected] - http//www.siri.mo.it
MEMBER OF EXPO – MODENA CONSORTIUM
specifying the machine type and the serial or order number printed on the machine’s nameplate.
THE OFFICIAL LANGUAGE OF THE MAKER IS ITALIAN.
No responsibility is assumed for translations in other languages, which do not correspond
to the original meaning.
This manual reects the state-of-the-art the moment the machine was supplied and cannot
be considered inadequate if there have been subsequent modications according to further
experience. SIRI reserves the right to update its products and manuals without being obliged
to inform the users of machinery previously supplied of these modications. The provision
of information concerning updates of the machine and manual is to be considered as a form
of courtesy.

SIRI MIX
1.0
Page: Release:
2/17
1
Chapter:
DeScription of the machine
1.1 MACHINE MANUFACTURING AND IDENTIFICATION DATA
Twodataplatesarettedtothe“SiriMix”,positionedasillustratedinFig.1.
TherstplatebearstheCEmark,themodelandarticlenumbersofthemachine,theserial
numberandtheyearofmanufacture.
Thesecondplatecarriesthemotordata.
Noitemofdataoneitherplatemustbealteredinanyway.
Machine:SiriMixArt.13
Register:...............
Yearofproduction:............
Fig.1

1.0
SIRI MIX
Page:
Release: 15/17
5.1 BUCKET WITH WHEELS
The“SiriMix”comeswithabuckettobeplacedontothesupporttable(Pos.8;Fig.3).
Onrequest,abucketwithwheelsmaybesupplied,enablingtheusertotransportthemixture
withoutliftingthebucket.
5.2 INSTALLING THE BUCKET WITH WHEELS
Toreplacethebucketnormallysuppliedwiththebucketwithwheels,simplyunscrewthe
lockingscrewsofthebucketsupportandplacethenewpailunderthemachine(Fig.10).
Thenproceedwiththeusualoperations.
Fig.10
optional extraS
Chapter:
5

SIRI MIX
1.0
Page: Release:
14/17
4.4 CLEANING THE MACHINE
All the following operations must be carried out with the machine switched off and
disconnectedfrompowersupply
Tograntsmoothfunctioningofthemachineovertime,keeptothefollowinginstructionswhen
workhasbeencompleted:
1-Thourouglyemptythebucket;
2-Carefullycleanthepaddleandthebucket,totakeawayanyresidualmatterthatonce
driedcouldkeepthepaddlefromturning,whenresetintomotion.
Do not immerse the machine into water.
When washing the machine, take care the water is never jetted at directly on to
the motor.
PROLONGED IDLENESS:
Checktheintegrity ofelectricalcables;
Placethemachineintothecartonbox.
4.5 PACKING THE MACHINE
Beforepackingthemachinefortransport,someoperationsmustbeperformed:
Disconnectthemachinefromthepowersupply;
Carryouttheoperationsdescribedatpoint4.4;
Disconnecttheleverontheleftsideofthemachine(Fig.9)andlowerthepaddleuntilthe
levergetsconnectedinthelowestposition.Makecertainthepipeontherightsideofthe
machineblocksthehandleofthebucket(Fig.8);
Liftthemixer(NB.atleasttwopeoplearerequired);
Placeitintothesuppliedcartonbox.
Chapter: 4
maintenance

1.0
SIRI MIX
Page:
Release: 3/17
Chapter:
1
1.2 INTENDED USE
The“SiriMix”isauniversalmixersuppliedwith40lt.capacitybucketandmotorwithgear
reducer making the paddle revolve and thus mixing tile adhesives, cement, paints and
epoxiesatbest.
Developedtomeetthetilelayer’severyneed,the“SiriMix” comeswithabucketcapable
ofcontainingawholegluesackandwithwheelsallowinganeasiertransportduringlaying
operations.
Themachineisespeciallydesignedfortheprofessional,thoughmaybeusedalsobypersons
withexperienceinthetilecuttingeldorin activitiesonthebuildingsites.
PROTECTION DEVICES
Thepaddleisthesinglemovingcomponentofthemachineanditmustbesetintomotion
onlywheninsidethebucket,andprotectedfromtheriskofcontactwithanyexternalbody.
Nospecialprotectiondeviceisthereforeneeded.
Noearprotectorsneednottobeworn,sincethenoiseemmisionlevelisverylow.
ELECTRICAL COMPONENTS
The“SiriMix”isendowedwithacut-outswitchwithalowvoltagesolenoid(Fig.5)sothatinthe
eventofamomentarypowerlosstheswitchwillrevertautomaticallytothe“0”position.Once
thepowerisrestored, the“I”buttonmustbepressedtosetthemachineintomotionagain.
Similarly,theswitchcontactwillbreakintheeventofthemixerbeingoverloadedtotheextent
thatthemotorcouldoverheatseriouslyandburnout.
The“SiriMix”issuppliedwithamicroswitchmakingthemotorstallwhenthepaddle
isliftedoveragivenlevel, sothatthenowunprotectedpaddlecannotcatchonclothesor
anyotherexternalbody.
DeScription of the machine

SIRI MIX
1.0
Page: Release:
4/17
1
Chapter:
1.3 DETAILED DESCRIPTION OF THE MACHINE
The“SiriMix”isanelectricalmixerespeciallydesignedtoallowprofessionaloperators to
mixmostbuildingmaterials.
Themachinecomprisesthefollowingmainparts(Fig.2)
1-Motorwithgearreducer;
2-Supportwithwheels;
3-Bucket(withwheelsasoptionalextra);
4-Gearreducersupport
5-Switchandmicroswitchcase
6-Paddle
7-Bucketcap
1.3.1 MAIN PARTS OF THE MACHINE
Fig.2
2
3
4
5
7
6
1
DeScription of the machine

1.0
SIRI MIX
Page:
Release: 13/17
maintenance
Chapter:
4
CAUTION: All routine and major servicing operations must be performed with the
machine disconnected from the power supply.
4.1 ROUTINE MAINTENANCE
Theusermustcarryoutroutinemainenanceoperations(cleaningandlubrication)andcheck
theintegrityofthemachine’sworkingpartsatleastonceaweek.
Alimitednumberofoperationsonlycanbeperformedbytheuser:
Cleaningallpartsofthemachine,takingespeciallycaretothecleaningofthebucketand
thepaddlefromanyglueresiduesoranyothermaterialwhichmaycausescalestoform;
Checkingthestateofallelectricalcables.
CAUTION:Neverstartupthemachinebeforepositioningthebucketproperly.
NB:Alwaysreplacedamagedcableswithoriginalspareparts.
Neverperformmendingoperationswithjointsorinsulatingtape.
Alloftheseoperationsmustbecarriedoutinstrictaccordancewiththedirectionsonsafety
andprocedurescontainedinthepresentmanual.
Noothergeneralmaintenanceisrequiredbeyondthepossiblereplacementsofpartsthat
maybecomedamagedduringnormaluse;thisworkmustbeentrustedonlytoskilledtters
approvedbytheS.I.R.I.company.
4.2 MAJOR SERVICING
Inadditiontoweeklyroutinemaintenance,the“SiriMix”willrequiresomeservicingoperations,
typicallywhenworkinghasbeencompletedonsite,andespeciallyiftheequipmentisto
remainidleforanextendedperiod.Servicinginvolves:
Cleaningallpartsofthemachine(seeprevioussection);
Carefullubricationofallmovingpartsthatmayhavehadlengthyexposuretodampand
dirtyconditions;
Replacingthepaddle,ifdamagedorworn-out;
Packingintothecartonboxfortransport.
4.3 REPLACING THE PADDLE
Before performing the following operations, make certain the machine has been
disconnected from the power panel
Followthegiveninstructionstoreplaceadamagedorworn-outpaddle:
Liftthesupportforgearreducertothesecondposition(3.4,point2);
Removethebucket;
Lockthenutofthethreadedpinprotrudingfromthegearreducer;
Unscrewthepaddleclockwise;
Replacewithanoriginalsparepart;
Screwthenewpaddlecounterclockwise.

SIRI MIX
1.0
Page: Release:
12/17
3
Chapter:
inStallation
Fig.8
Fig.9

1.0
SIRI MIX
Page:
Release: 5/17
Chapter:
1
1.3.2 SPARE PARTS REFERENCE DRAWINGS
DeScription of the machine

SIRI MIX
1.0
Page: Release:
6/17
Chapter: 1
1.3.3. LIST OF SPARE PARTS
POSIZ. N° DENOMINAZIONE ART.
1 1 Motoriduttore 13-01
2 1 Supporto motoriduttore 13-03
3 1 Attacco per coperchio secchio 13-09
4 1 Coperchio secchio 13-06P
5 1 Pala mescolatore 13-05
6 1 Telaio porta secchio 13-02
7 2 Ruote D.60 13-35
8 1 Piastra porta secchio 13-07Z
9 1 Leva 30MINI
10 1 Base per interruttore 471RET
11 0,43 Guarniz. Scatola interruttore 226-01
12 1 Scatola interruttore 471MIX
13 1 Interruttore 505-17
14 1 Microinterruttore 13-04
15 1 Molla 13-08
16 1 Secchio LT 40 18-03
17 1 Condensatore 13-90
18 1 Motore 13-30
19 1 Albero motore 254
20 1 Cuscinetto 6203
21 1 Base riduttore 14-21
22 1 Inserti per base -
23 1 Spina cilindrica 243SPI
24 1 Cuscinetto 14-27
25 1 Ghiera per riduttore G12X1
26 1 Ingranaggio primario 253
27 2 Astuccio a rullini 14-26
28 1 Ingranaggio secondario 251
29 1 Piastrino ferma cuscinetto 14-51
30 1 Perno lettato 821-2
31 1 Cuscinetto 14-27
32 1 Cuscinetto 270
33 1 Anello di tenuta 14-17
34 1 Coperchio riduttore 14-022
DeScription of the machine

1.0
SIRI MIX
Page:
Release: 11/17
Chapter:
3
inStallation
POSIZ. N° DENOMINAZIONE ART.
1 1 Motoriduttore 13-01
2 1 Supporto motoriduttore 13-03
3 1 Attacco per coperchio secchio 13-09
4 1 Coperchio secchio 13-06P
5 1 Pala mescolatore 13-05
6 1 Telaio porta secchio 13-02
7 2 Ruote D.60 13-35
8 1 Piastra porta secchio 13-07Z
9 1 Leva 30MINI
10 1 Base per interruttore 471RET
11 0,43 Guarniz. Scatola interruttore 226-01
12 1 Scatola interruttore 471MIX
13 1 Interruttore 505-17
14 1 Microinterruttore 13-04
15 1 Molla 13-08
16 1 Secchio LT 40 18-03
17 1 Condensatore 13-90
18 1 Motore 13-30
19 1 Albero motore 254
20 1 Cuscinetto 6203
21 1 Base riduttore 14-21
22 1 Inserti per base -
23 1 Spina cilindrica 243SPI
24 1 Cuscinetto 14-27
25 1 Ghiera per riduttore G12X1
26 1 Ingranaggio primario 253
27 2 Astuccio a rullini 14-26
28 1 Ingranaggio secondario 251
29 1 Piastrino ferma cuscinetto 14-51
30 1 Perno lettato 821-2
31 1 Cuscinetto 14-27
32 1 Cuscinetto 270
33 1 Anello di tenuta 14-17
34 1 Coperchio riduttore 14-022
3.3 ADJUSTING THE MACHINE
The“SiriMix”leavesthefactoryfullytested;theuserhasnottoperformanyadjustments
orxingoperations,exceptforinstallingthebucketwithwheels(optionalextra)asdescri-
bedinsection5.5.
3.4 OPERATING PROCEDURES
Tocarryoutanyoperationswiththe“SiriMix”,havinginstalleditfollowingthegivenin-
structions,theuserhastoproceedasfollows:
1-Inserttheplugintothepowersocket;
2-Liftthepaddletothesecondposition,disconnectingtheleverontheleftsideofthe
machine(Fig.9);
3-Pourtheamountofwaterasindicatedonthegluesackintothebucket;
4-Pourthecontentsofasackofglueintothebucket;
5-Disconnectthepaddleasatpoint2andlowerituntilthelevergetsconnectedinthe
lowestposition.Checkthatthepipeontherightsideofthemachineblocksthehandleof
thebucket(Fig.8);
6-Pressthebutton“I”oftheswitchtosetthepaddleintomotion;
7-Checkthatthemxturehasreachedthedesiredconsistency(otherwiseaddwateror
gluethroughtheslitsonthebucketcap);
8-Reverttheswitchtothe“0”position,lettingthepaddlestopturning;
9-Repeattheoperationatpoint2tousethemixture;
Whenthemixtureinsidethepailisnished,repeatalloperationsfrompoint1toperforma
furtherworkingcycle.
NB:whenoperating:
CAUTION:Onepersononlymustoperatethemachine.
Nobodyotherthantheusershouldbeallowedinthespaceimmediatelysurrounding
themachinewhileworking.
CAUTION:Dailycheckpowercablesofthemachines.
Makecertaintheoperatorisalwaysfreefromobstacles
Any adjustments must be carried out with the machine switched off and disconnected
from the power supply.
Donotsubjectthemotortoseverestressesduetoexcessivellingofthebucket,
incorrectdilutionoftheglueorimproperuseofthemachine.

SIRI MIX
1.0
Chapter:
Page: Release:
10/17
3
inStallation
3.1 TRANSPORT
Tofacilitatetransportationthemachineispackedandstoredinsideastrongcardboardbox
toprotectitfrompossibleimpacts.
Whenrepositioningonsite,keeptothefollowinginstructions:
1-Disconnectthemachinefromthepowersupply.
2-Gripthehandleonthesideoppositetotheoperator.
3-Liftthemachineonthefrontwheelsandpositionatwill.
CAUTION
Do not move the machine before disconnecting the power supply, pressing the “0”
button of the switch and removing the plug from the panel socket.
3.2 INSTALLATION
CAUTION
It is the user’s responsability to ensure that installation is
carried out in compliance with local regulations
The machine must be installed by a skilled person who has
read carefully and understood the information given in the
present manual.
All directions given concerning installation of the
machine must be followed with care.
For any doubts regarding installation, contact
the maker without delay.
Therearecertainfundamentalrulestobeobservedwheninstallingthemachine:
Firstlytwopeoplearerequiredtoremovethemachinefromthecartonbox.
Themachinemustthenbepositionedonaatsurface,makingcertainthatthereissufcient
roomonallsidesbothfornormalfreedomofmovementandformixingoperations.
Alwayscheckthatthelinevoltageatthepanelisthesameastheratedvoltagegiven
onthemotordataplate.
Neverconnectthemachinetoapowersupplythatisnotproperlyearthed.Thiscould
resultinaSEVERE AND POTENTIALLY FATAL ELECTRIC SHOCK.
Neverusethemachineonanysurfacethatisnotlevel.Operatingthemixerinsuch
conditionscanbeverydangerous.

1.0
SIRI MIX Chapter:
Page:
Release: 7/17
1
1.4 IMPROPER USE OF THE MACHINE
CAUTION:Anyservicingoperationmustbecarriedoutwith the machine either switched
off or isolated from the power supply
CAUTION:Setthemachineintomotiononlyafterhavingcorrectlypositionedthebucket.
Themachinemustbeemployedonlyformixingmaterialsofthekindreferredtoinparagraph
1.1;anyimproperusemayshortenthelifeofthemachineandjeopardizeitssmoothfunctioning.
Themixerpresentsnoothercounterindications.
1.5 SAFETY DEVICES AND GUARDS
The“SiriMix”isequippedwithasinglesafetydevice,thecap(Fig.3;Pos.4):oncethemachi-
neisstartedupitcoversthebucketsotoavoidtheriskofcontactwiththemovingpaddle.
1.6 LIST OF CONTROLS
The“Sirimix”isextremelysimpleasregardscontrols.
Itcomeswithaself-disconnectingswitchsupplyingpowertothemotorwhenintheposition
“I”,thuslettingthepaddlerevolving.Themotorisstoppedsimplybypressingthe“0”button
(Fig.5).
Asafetymicroswitchisalsosupplied,allowingthemotortoturnonlyoncethepaddlehas
beencompletely loweredintothebucket.
Itisvitalthatthecontrolsarenevertemperedwith.
All maintenance operations must be carried out with the machine switched off or
isolated from the power supply.
Accesstotheoperatingcontrolsmustberestrictedexclusivelytoauthorisedpersons.
Theoperatormustensurethatallguardsandthatallsafetydevicesareintheirproperplace
andoperational.
1.6.1 DESCRIPTION OF CONTROLS
Themainswitchperformsadualfunction,protectingtheoperatorintheeventofamomentary
powerlossbybreakingthecircuitandpreventinganuncontrolledrestart(cut-outfunction),
and protecting the motor from overheating and burning out when subjected to a severe
overload:thismeansinpracticethatifthepaddlehappenstobecomestuckandpreventthe
motorfromturning,theswitchwillopenautomatically.
Theswitchisoperatedasfollows:
-Pressingthe“I”button,powerissuppliedtothemotorcircuit(Fig.5);
-Pressingthe“0”button,themotorcircuitisisolatedfromthepowersupply.
Fig.5
DeScription of the machine

SIRI MIX
1.0
Chapter:
Page: Release:
8/17
1
ART. 13-120 ART. 13 ART. 13-240
Power supply 120 V - 60 Hz 230 - 50 HZ 240 - 50 HZ
Power draw 10 A 3 A 3 A
RPM 1680 1400 1400
Capacitor 60 Uf 16 Uf 16 Uf
IP protection rating 55 54 54
Insulation class F F F
Bucket capacity 40 lt 40 lt 40 lt
Weight 29 kg 29 kg 29 kg
Overall dimensions 740x760x460 cm 40x760x460 cm 40x760x460 cm
1.7 TECHNICAL DATA
1.7.1 NOISE LEVELS
Acusticpressureatoperatorstationislowerthan70dBA.
EAR PROTECTORS NEED NOT TO BE WORN
WHILE OPERATING THE MIXER
1.7.2 ELECTRICAL SYSTEM DIAGRAM
The various items accompanying the machine also include the diagram of the electrical
system(g.7).Shouldthiseverbelostormislaid,contactS.I.R.I.
Fig.6
1.7.3 OVERALL DIMENSIONS
Fig.7
DeScription of the machine

1.0
SIRI MIX Chapter:
Page:
Release: 9/17
2.2 CORRECT USE OF PERSONAL SAFETY GUARDS
Nospecialprotectivedevicesneednottobeusedbytheoperator;indeedkeepingtotheregulations
mentionedbeforeissufcient.
2.3 INCORRECT AND PROHIBITED USE OF THE MACHINE
The“SiriMix”mustexclusivelybeemployedtomixthematerialsasindicatedinsection1.1.Usingthe
machineimproperlycanplacethegearreduceratriskofhalting,thuscausingthemotortoburn.
Nevermakealterationstothemachineoritsmainparts.AlterationarepermittedintheS.I.R.I.workshopsonly.
Thisruledoesnotapplytoadjustmentswhichprovenecessaryduringoperativelifeofthemachine.
Theseoperationsmust,however,beperformedbyauthorisedpersonsonly.
Any adjustments or operations involving the replacement of worn out mechanical parts must
be carried out with the machine disconnected from the power supply.
2.4 INFORMATION ON RESIDUAL RISK FACTORS
Themachinepresentsnoresidualriskfactors,since,assaidbefore,itisnotdangerous.
2
General noteS on Safety
2.1 GENERAL POINTS
Any repair or servicing operations must be carried out with the machine switched off and
disconnected from the power supply.
Do not start up the machine before installing the bucket and lowering the motor.
Readcerfullythroughthemanualbeforeerecting,startingandoperatingthemachine,andbefore
servicingoradjustinganypartoftheequipment.
Donotallowunauthorisedpersonstoworkonthemachine.
Do not wear rings, wrist watches, jewellery, or any other clothing (baggy of loose tting,
unzipped, unbuttoned or torn) that could catch on moving parts; hair should also be gathered
and tied if particularly long.
Donotoccupyorencumbertheoperatingareaaroundthemachine.
Neverattempttostartthemachinewhenaffectedbytechnicalproblems.
Makecertainthatanyconditionposingapossiblethreattosafetyiseliminatedbeforeusingthemachine.
Reportanyirregularitiesinoperationtositemanagersorappointedsupervisors.
Makecertainthatallguardsandotherprotectivepartsareproperlyinplaceandthatallsafetydevices
areinstalledandoperational.
Observeproceduresandinformationgiveninthemanualregardingmaintenanceandcustomerservice.
Donotusepetrol,solventsorotherinammablecleanersonthemachine.
Useonlyproprietarysolventscertiednon-inammableandnon-toxic.
Donotsubjectthemotorwithgearreducertoseverstressesduetoexcessivellingofthebucket
ortoimproperuse.
Onepersononlymustoperatethemachine.
Nobodyotherthantheoperatorshouldbeallowedinthespaceimmediatelysurroundingthema-
chinewhencutting.
Donotperformmendingoperationswhenthemachineisworkingorconnectedtothepowersupply.
Checkeverydaythestatusofthepowercables.
Beforeconnectingthemachinetotheswitchpanel,makecertainthepanelisttedwitharesidual
currentdevice.
Beforeconnenctingthemachine,checkthatthenominalpowersupplyvoltageisthesameasthe
ratedvoltageofthemachine.
