Univex Swing Ring SRM20 User manual

Project Item Number Quantity
_
________________________________ ______________________________ _______________
_
E
E
x
x
a
ac c
t
t
i
in n
g
g
S
S
t
t
a
an nd da a
r
r
d
ds s
,
,
J
J
u
us s
t
t
L
Li ik ke e
Y
Y
o
ou u
r
r
s
s
,
,
s
si in nc ce e
1
19 94 4
8
8
Univex Corporation 20 QT. COUNTERTOP
MIXERS
Standard Accessories
• 20 quart stainless steel bowl
• Batter beater
• Wire whip
• Ingredient chute
Optional Accessories
 20 quart dough hook
 15 minute timer
 VS9 vegetable slicer attachment
 VS9H grater/shredder attachment
 ALMFC12 meat & food grinder
 Bowl Scraper
 Splash / extension ring
 20 quart pastry knife
 12 quart for 20 quart bowl & attachments
Warranty
• Two-year, on-site parts & labor warranty
Features
• ½ HP Capacitor Start Motor
• Variable Speed Drive: Four fixed speeds
or any speed in-between
• Change speeds without having to stop the
mixer
• Two-piece, stainless steel, dishwasher
safe safety guard
• Heavy-duty stainless steel bowl
• #12 Power Take-Off (PTO) hub on SRM20
• Interlock switches protect operator from
injury if safety guard is open or bowl is
lowered
• Low voltage protection prevents
accidental start-up after power failure
• Hardened alloy gears in transmission
• Durable NSF approved hybrid epoxy /
polyester powder coat finish
• Cord and plug
WARRANTY DETAILS
The SRM20 mixer carries a two-year, on-site parts and labor warranty against any flaws in materials and workmanship. This period begins date of purchase and
provided the unit is used in accordance with our instructions, is in full effect for one year from that date. Any work performed under this warranty must be
p
erformed between the hours of 8:00 a.m. and 5:00 p.m. local time, Monday through Friday. Univex will not pay for overtime charges for work performed other than
during normal business hours. Damage incurred in transit or from installation error, accident, alteration or misuse is not covered. Univex shall not be liable for any
consequential, compensatory, incidental, or special damages. Contact the Univex service department for any warranty claims.
Models:
 SRM20 – 20 qt. Countertop Mixer
 NPH20 – 20 qt. Countertop Mixer
Without PTO Hub
20 Quart Countertop
Mixers
SRM20/NPH20
MADE IN THE USA
SRM20/NPH20
Univex Corporation
www.univexcorp.com
3 Old Rockingham Rd Salem, NH 03079 USA
Tel. [phone] Fax: [phone]
Intl Tel. [phone] Int’l Fax: [phone]

20 Quart Countertop Mixers SRM20/NPH20
E
E
x
x
a
ac c
t
t
i
in n
g
g
S
S
t
t
a
an nd da a
r
r
d
ds s
,
,
J
J
u
us s
t
t
L
Li ik ke e
Y
Y
o
ou u
r
r
s
s
,
,
s
si in nc ce e
1
19 94 4
8
8
12qt Dough Hook for 20qt mixer
12qt Pastry Knife for 20qt mixer
12qt Four-Wing Whip for 20qt mixer
Optional Accessories:
The following are available at an extra cost:
1000454 Mixer Cover: Heavy-duty clear
plastic cover for SRM20
1700800 S-3A Stand: Stainless steel mixer
stand with undershelf and locking casters.
1000950 VS9 Vegetable Slicer: 9”
vegetable slicer attachment with adjustable
knife assembly for use on a #12 PTO hub.
1001050 VS9H Grater / Shredder
Attachment: 9” vegetable / cheese
shredder attachment with plate holder and
3/16” plate for use on a #12 PTO hub.
1000550 ALMF12 Meat & Food Grinder:
Includes cylinder, ring, worm, stainless
steel pan, plunger, 3/16” plate and “x” knife.
Fits #12 PTO hub.
Printed in the USA 01/07
Speeds: The variable speed transmission
not only provides the standard 4 locked-in
speeds, but also any in-between speeds
Speed (RPM) 1 2 3 4
Beater Shaft 90 190 305 365
PTO 60 125 200 240
Bowl Lift: Ergonomic hand operated crank,
self-locking in top and bottom position.
PTO Hub: Model SRM20 comes with a
front-mounted industry standard #12 Power
Take-Off (PTO) hub for use with Univex
#12 attachments.
Optional Attachments
The following are available at an extra cost:
15 Minute Timer
20qt (22 qt capacity) stainless steel bowl
20qt Aluminum Batter Beater
20qt Aluminum Dough Hook
20qt Wire Whip
Bowl Scraper
Splash / Extension ring
20qt Pastry Knife
20qt Four-Wing whip
12qt Bowl for 20qt mixer
12qt Batter Beater for 20qt mixer
Capacity: 22 Quarts (20.8 liters)
Motor: ½ hp. Capacitor start
Electrical: 115/60/1, 9.4 amps, NEMA
plug 5-15P. Also available at an extra cost
208-240/60/1, 220-240/50/1, 230/50/1
(CE), 208-240/60/3, 220/50/3, 380/50/3,
400/50/3 (CE), 440-480/60/3.
Controls: Momentary contact STOP &
START buttons and contactor.
Transmission: Univex variable speed
transmission with hardened alloy gearing
and torque sensing pulleys.
Lubrication: Food grade grease
Finish: NSF approved hybrid epoxy /
polyester powder coat
Bowl: Die-drawn stainless steel
Bowl Guard: Heavy-duty, two-piece,
stainless steel SwingRing™ safety guards.
Swing open for full access to bowl.
Removes easily for cleaning, fits in
dishwasher. Guard must be attached and
closed for mixer to operate. Bowl support
interlock provides additional protection.
Dimensions
A) Overall height 35 9/16” (903mm)
B) Base to PTO height 31 3/8” (797mm)
C) Machine width 16 7/16” (417mm)
D) Overall width with handle 20 1/8” (512mm)
E) Depth (leg to leg) 22 1/2" (572mm)
F) Overall depth 27 5/16” (694mm)
Shipping Information
Freight Class: 85
Net Weight: 215 lb. (97 kg)
Shipping Weight: 250 lb. (114 kg)
Shipping Box Dimensions:
Height: 41” (1041mm)
Width: 36 1/2" (927mm)
Depth: 23” (584mm)
Cartons are affixed to a pallet. The pallets are heat-
treated and NELMA approved for international
shipping. The weight and dimensions of the pallet are
included in the weight and dimensions above.
