INSTALLATION INSTRUCTIONS & OWNER’S MANUAL
THANK YOU
INSTALLER:
NATURAL GAS & LIQUID PROPANE CONFIGURATIONS
SIZZLER 26”
SIZ26
SIZZLER 32”
SIZ32
SIZZLER 40”
SIZ40
Thank you for your purchase. We’d like to welcome you to the Summerset family of luxury outdoor kitchen products and
look forward to being a part of your home for years to come. As a family business with over 30 years of industry experience,
we aim to deliver exceptional quality and personal service.
Welcome to the Summerset family and we hope you love your new grill!
FOR YOUR RECORDS
Please record the following information and refer to it when contacting Summerset Professional Grills or an authorized dealer.
The serial number is located on the rating plate. The rating plate is located on the exterior basin of the grill (fire box) and on the
underneath side of the drip tray (select models only).
Serial Number:
Model:
Date of Purchase:
Place of Purchase:
Please leave this manual for the owner

3 4
SAFETY AND INSTALLATION WARNINGS
• Please read all instructions before installation or operating your gas grill to prevent injury and appliance damage
• All gas grills will get hot during use. Use extreme caution when operating the grill
• Do not touch hot surfaces. Always use the handle to open or close the grill
•Never use dented, rusty or damaged propane cylinders. Never store additional or empty propane cylinders in the grill
cabinet or in the vicinity of this or any other appliance
•Close supervision is necessary when this or any appliance is used near children. Keep children away from the grill during
operation and until the grill has cooled off
•Children should never be left alone or unattended in an area where a grill is located. Place your grill well away from areas
where children play. Do not store items that may interest children in or around the grill, in the cart, or in the masonry enclosure
• Never move the grill when hot. When in use, portions of the grill are hot enough to cause severe burns.
•Always maintain the required clearances from combustibles as detailed. The grill is designed for outdoor use only. Never
use in a garage, building, shed, breezeway, or other enclosed area. Do not use this grill under any unprotected overhead
combustible construction
•Gas grills are not designed or certified for and are not to be installed in or on recreational vehicles, portable trailers, boats
or any other moving installation
• Always have an ABC Fire Extinguisher accessible — never attempt to extinguish a grease fire with water or other liquids.
•Storing your grill: Store your grill in a well-ventilated area. If stored indoors, detach and leave L.P. cylinder outdoors in a
well-ventilated area away from heat and away from where children may tamper with it
•Keep any electrical supply cord and the fuel supply hose away from any heated surfaces. Electrical cords should be placed
away from walkways to avoid tripping hazard
•Do not repair or replace any part of the grill unless specifically recommended in this manual. Other service should be
performed by a qualified technician
•If the grill is installed by a professional installer or technician, be sure that he/she shows you where your gas supply shut-
off is located. All gas lines must have a shut-off that is readily and easily accessible. If you smell gas, check for gas leaks
immediately. Check only with a soap and water solution. Never check for gas leaks with an open flame.
• Do not twist the gas supply hose
•Inspect the L.P. gas supply hose prior to each use of the grill. If there is evidence of excessive abrasion or wear, or the hose
is cut, it must be replaced before using the grill
•The use of accessories, regulators, or components not recommend by the appliance manufacturer may cause injuries and
will void warranty
•Never light the grill with the hood closed and be certain the burners are positioned and seated over the gas valves and on
the burner support
• Never lean over the cooking surface when lighting or operating the grill
• Use barbecue tools with wood handles and insulated oven mitts when operating the grill
•Be sure the gas supplied to the grill conforms to the model you purchased. A natural gas grill requires natural gas to operate;
a liquid propane grill requires liquid propane to operate
•Never connect the appliance to an unregulated gas supply line. Grills operated without a regulator are unsafe and will not
be serviced until installed properly and safely. Unsafe operation without a gas regulator will void the warranty
•Grills operating with natural gas must be installed with the NG regulator supplied with the unit and set to 4.0” of water
column pressure
• Grills operating with liquid propane must be installed with an LP regulator and set to 11” of water column pressure
WARNING!
READ THIS MANUAL CAREFULLY
and completely before using your grill to reduce the risk of:
1. Fire
2. Burn hazard, personal injury or property damage
3. Improper installation or servicing
4. Electric Shock
WARNING!
CALIFORNIA PROPOSITION 65
1. This product can expose you to chemicals including
polycyclic aromatic hydrocarbons which is known
to the State of California to cause cancer and birth
defects or other reproductive harm.
2. California law requires businesses to warn customers
of potential exposure to such substances. To minimize
exposure to the substances, always operate this unit
according to the use and care instructions found in this
manual. Be certain to provide adequate ventilation
when cooking.
WARNING!
EXPLOSION HAZARD:
• DO NOT use the grill as a storage area for flammable
materials. Keep area clear and free from combustible
materials, gasoline, andother flammable vapors and
liquids. Failure to do so can result in death, explosion,
or fire
• An LP cylinder not connected for use shall not be stored
in the vicinity of this or any other appliance
WARNING!
•The outdoor cooking gas appliance and its dedicated
shutoff valve must be disconnected from the gas supply
piping system during pressure testing of that system at
test pressures in excess of .5 psi (3.5kPa).
•The outdoor cooking gas appliance must be isolated
from the gas supply piping system by closing its
dedicated manual shutoff valve during any pressure
testing of the gas supply piping system at test pressures
equal to or less than .5 psi (3.5kPa).
WARNING!
THIS PRODUCT IS DESIGNED FOR OUTDOOR USE
ONLY
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read this manual thoroughly before installation, use, or
servicing of this product.
WARNING!
CODE AND SUPPLY REQUIREMENTS:
This grill must be installed in accordance with local codes
and ordinances, or, in the absence of local codes, with
the latest National Fuel Gas Code (ANSI Z223.1/NFPA
54), or Natural Gas and Propane Storage and Handling
Installation Code (CSA-B149.1)
WARNING!
IF YOU SMELL GAS:
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read this manual thoroughly before installation, use, or
servicing of this product.
DANGER!
IF YOU SMELL GAS:
• Shut off all gas supply lines to the grill
• Extinguish any open flames
•Carefully open the lid. Remember, it may be extremely
hot!
•If odor continues, keep everyone away from the grill
and immediately call your gas supplier or your fire
department
DANGER!
STATE OF MASSACHUSETTS
•Massachusetts requires all gas be installed using
a plumber or gas fitter carrying the appropriate
Massachusetts license.
•All permanently-installed natural gas or propane
installations require a "T" handle type manual gas valve
be installed in the gas supply line to this appliance.
•This does not apply to portable propane installations
using a 20 pound cylinder.
WARNING!

5 6
TABLE OF CONTENTS
Before Grilling
Shipment Arriving Damaged
Important Notes
Installation
Clearances
Overhead Hood Clearances
Unpacking & Assembly
Gas Connections
Natural Gas
Liquid Propane
Connecting a Side Burner
Fixing A Leak
Lighting The Grill
Valve Ignition
Manual Ignition
Pre-heating
Low Flame Adjustment
Maintenance Tips
Cleaning Drip Tray
Stainless Steel Maintenance
Locations Near Coastal Areas & Pools
Grill Features
Installing Rotisserie Kit
Installing Drop-In Sear Burner
Using Drop-In Sear Burner
Exploded View
Replacement Parts
Warranty Information
7
8
9
16
11
13
14
15
17
18
19
20

7 8
BEFORE GRILLING
IMPORTANT NOTES:
BE MINDFUL OF WIND DIRECTION
When selecting a suitable location, consider
important factors such as exposure to the
wind and foot traffic patterns. If you have a
freestanding grill, position it so the prevailing
wind blows into the front control panel (at your
back when grilling), allowing for proper front
to rear airflow. Built-in grills located in areas
with prevailing winds should be protected by
a wind barrier, wind deflector, or wind guard.
The grill is designed to pull in air from the
front and exhaust through the rear of the unit.
Winds hitting the back of the grill directly may
cause problems. Be sure wind doesn’t blow
into the hood gap.
GAS LINE LENGTH
Keep all gas supply lines as short as possible.
Gas lines lose pressure over distance and with
each elbow or “t” fitting added. This drop in
pressure affects grill performance.
PROPER LEVELING
Proper leveling during installation is critical. A
grill that is out of level will cause erratic burner
combustion and inefficient, uneven heating.
The grill should be level in all directions.
Adjustments may need to be made each time
when moving a freestanding unit.
CONSTRUCTION ZONES
Keep all stainless steel products away from
construction zones. Construction debris such
as (but not limited to) stone dust, stucco, and
lime dust could damage or permanently
discolor stainless steel products. Keep all
caustic chemicals including chlorine and pool
cleaning products away from stainless steel at
all times.
SHIPMENT ARRIVING DAMAGED:
VISIBLE SHIPPING DAMAGES
If your shipment arrives with visible damage to
the box/carton, be sure the damage is noted
on the bill of freight or express receipt and
signed by the person making the delivery. File
claim for damages immediately, regardless of
the extent of damage.
CONCEALED DAMAGES
If damages are unnoticed until the grill is
unpacked, notify the transportation company
or carrier immediately and file a concealed
damage claim with them. This should be done
within (5) days of the delivery date. Be sure to
hold on to the box/carton for inspection. We
cannot assume responsibility for damage or
loss incurred in transit.
TESTING FOR LEAKS
Create a soapy water solution of 1 part soap
and 3 parts water. Confirm that all control
knobs are in the off position. Turn on the
fuel supply. For natural gas, turn the valve
handle ¼ turn to align with the gas flow. For
LP, turn the cylinder valve counter clockwise
one full rotation. Apply the soap solution
generously by paint brush or squirt bottle on
all connections and fittings. If bubbles appear
to grow on any of the connections, you have
a gas leak. IMMEDIATELY turn off the gas
supply. Wash off the soapy solution with
cold water and dry. Tighten the loose joint
or replace the faulty part with manufacturer-
recommended replacement parts. DO NOT
attempt to repair the L.P. cylinder valve if it is
damaged. The only way to safely resolve a
damaged cylinder is to replace it by calling an
authorized gas appliance service technician
or an LP gas dealer. Repeat the leak test to
ensure that no leaks are present. Do not use
the appliance until the leak is corrected.
INSTALLATION
IMPORTANT NOTES:
CUT OUT DIMENSIONS
OVERALL PRODUCT DIMENSIONS
NOTE:
Clearance between grill and strictly
non-combustible wall (i.e. brick wall,
Clearance Fig. 1). The grill must have a
minimum of 4” right, left and rear clearance
from any non-combustible wall. This allows
for proper ventilation and helps prevent
dangerous overheating.
Grill Model A: Width B: Depth C: Height
Sizzler 26” 23 ¾ 20 ¾ 8 ½
Sizzler 32” 30 ⅝ 20 ¾ 8 ½
Sizzler 40” 38 20 ¾ 8 ½
Grill Model A: Width B: Depth C: Height
Height-
Hood Open
Sizzler 26" 25 25 ½ 20 30
Sizzler 32" 32 ½ 25 ½ 20 30
Sizzler 40" 39 ½ 25 ½ 20 30
ALL BBQ ISLANDS MUST BE MANUFACTURED FROM
“NON-COMBUSTILBLE” MATERIAL. If combustible material is being
used, a Summerset grill liner is required.
For the minimum clearances between the grill and any
side or rear walls, your setup must fall within one (or
more) of the following:
Clearance between grill and protected
combustible wall (i.e. a non-combustible wall
in front of a combustible wall to serve as a
barrier. This can be accomplished by brick
or a metal stud finished with non-combustible
substrate. Clearance Fig. 2). The grill must
have a minimum of 14” right, left and rear
clearance from the protected combustible
wall. (The 4” non-combustible material
clearance, plus an additional 10” clearance
between the grill and protected wall.)

910
INSTALLATION
SIDE AND REAR WALL
CLEARANCES
Clearance between grill and
combustible wall (Clearance Fig. 3). The
grill must have a minimum of 18” right, left and
rear clearance from any combustible wall.
BACK SPLASH CLEARANCE
(IF APPLICABLE)
If a non-combustible backsplash exists, it must
have a minimum of a 4” clearance from the
rear of the grill (to allow for proper ventilation
and help prevent dangerous overheating.
Clearance Fig. 4).
IMPORTANT NOTES:
This 4” backsplash clearance must first be met
prior to any non-combustible walls beginning
behind it.
OVERHEAD CONSTRUCTION AND
EXHAUST HOOD REQUIREMENTS
This grill is designed for outdoor use only. DO
NOT use this grill inside a building, garage,
or enclosed area. DO NOT use this grill in or
on a recreational vehicle or boat.
When installing this grill in a combustible
surround, a Summerset insulating jacket/grill
liner must be used.
A minimum five (5) foot clearance is required
between the countertop and the overhead
construction.
When installed under combustible overhead
construction, the area above the cooking
surface of the grill must be covered with an
exhaust hood. The exhaust hood provides
the protection for the combustible overhead
construction.
IMPORTANT NOTES:
DO NOT use this appliance under
unprotected combustible overhead
construction.
When installed under overhead non-
combustible construction, an exhaust hood is
highly recommended.
INSTALLATION
EXHAUST HOOD
REQUIREMENTS
UNPACKING YOUR GRILL
Included with your Sizzler grill are the
following loose items:
Cooking Grates: SIZ26(3), SIZ32(4),
SIZ40(5)
Burner Covers: SIZ26(3), SIZ32(4), SIZ40(5)
Warming Rack: SIZ26(1), SIZ32(1),
SIZ40(40)
Drip Tray: SIZ26(1), SIZ32(1), SIZ40(1)
Conversion Kit: Set of orifices (with manual)
• If grill is factory set LP, NG orifices will be included
• If grill is factory set NG, LP orifices will be included
1. The drip tray will be at the bottom of
the unit and will slide into the drip tray
support brackets.
2. The heat shields will be above the drip
tray (already installed)
3. Above the heat shields are the stainless
steel tube burners (already installed).
NOTE: Remove the cotter pins
securing the burners prior to
installation. This is easily accessible
from the rear of the unit.
4. The burner covers or briquette trays are
above the burners and attach to the
mounting pegs located inside the firebox.
5. The cooking grates are placed above the
burner covers and finally the warming
rack is placed on the mounting tabs
When using an exhaust hood, the area
above the cooking surface of the grill must be
covered with a hood larger than the cooking
area of the grill, AND with a minimum of
600 CFM (cubic feet per minute) for proper
outdoor application
Select the proper height to mount the hood.
Take into consideration the stature of the
person or persons who will be cooking.
A height of 30" to 36" above the cooking
surface will suit most users. If mounted at a
height greater than 36" above the cooking
surface, the hood should be at least 6" wider
than the cooking appliance to provide a
proper capture of heat and grease. (Refer to
the range manufacturer's guidelines) Once
the proper height is established, draw a level
line where the bottom of the hood will rest. If
practical, mount a board equal to the width
of the hood along the line so you may rest the
hood on it while installing.

11 12
GAS REQUIREMENTS GAS REQUIREMENTS
WARNING!
GAS LINES
MINIMUM PRESSURE REQUIREMENTS
IMPORTANT
Never connect a gas line directly to the grill. A
pressure regulator must be installed on all gas
equipment. Removing or failing to install the
pressure regulator can result in fire and serious
personal injury and will void the warranty
Ensure the gas supplied meets the minimum
pressure requirements. See below table for
gas requirements measure in water column
(w.c.) pressure:
All installation and all installation parts
must conform to local codes with the
National Electrical Code, ANSI Z223.1/
NFPA 70 latest edition and the National
Fuel Gas Code ANSI Z223.1/NFPA
54 in the U.S. and CGA-B149.1/.2 in
Canada
Both the regulator and burner orifices have
been tuned for the type of gas specified on
the rating plate. Converting to a different type
of gas requires a conversion kit. Conversion
kits are included with this grill and located with
the manual. Converting gases may require
additional parts not included with this grill.
(See Gas Conversion section for details).
NOTE: DO NOT use any tape, pipe dope or
threading compound on any flare fitting. This
will cause a clog in the regulator and prevent
your grill from functioning properly.
NATURAL GAS AND LIQUID
PROPANE REQUIREMENTS
NATURAL GAS REQUIREMENTS
CONNECTING TO THE NG
REGULATOR
LIQUID PROPANE TANK
REQUIREMENTS
Turn off the gas at the supply when grill is not
in use. Please ensure:
• Summerset Professional Grills
recommends that only qualified
licensed professionals perform the
required plumbing on this product.
•Check the Rating Plate to make sure the
gas supply you are hooking up to is the
gas type the grill is manufactured for.
•To ensure satisfactory performance,
the gas supply line must be sized to
accommodate the total BTU requirements
of all the gas-fired equipment that will be
connected to that line.
• In no case should pipe less than 1/2”
inside diameter or1”outside diameter
ever be used to connect this product.
Gas Type Maximum Minimum
Natural Gas 7” w.c. 4” w.c.
Liquid
Propane
14” w.c. 11” w. c .
FILLING AND REFILLING LP
GAS CYLINDERS
CONNECTING TO THE LP TANK
All purging and refilling of LP gas
cylinders must be performed by
qualified personnel in the LP gas
industry. Never store a spare LP gas
cylinder under or near this appliance.
Never fill the LP gas cylinder beyond
80 percent full. Failure to follow these
instructions may result in explosion,
personal injury or death.
Never connect an unregulated LP gas tank
to your gas grill. The gas regulator assembly
supplied with your gas grill is adjusted to have
an outlet pressure of an estimated 11” water
column (W.C.) for connection to an LP gas tank.
LP gas grill models are designed for use with
a standard 20 lb. liquid propane gas (LP) tank
with type (1) valve connections. (Not included)
Never connect your gas grill to an LP tank that
exceeds this capacity. A tank of approximately
12 inches in diameter by 18-1/2 inches high is
the maximum size LP gas tank to use. A propane
tank with an OPD (Overfill Prevention Device)
must be used. This safety feature prevents the
tank from being over-filled which can cause
malfunction of the LP gas tank, regulator and/
or grill.
The LP cylinder must be constructed and
marked in accordance with the specifications
for LP gas cylinders of the U.S. Department of
Transportation (DOT) and designed for use
with a Type 1 system only. Be sure to read and
follow all LP connection instructions.
The hose and regulator are connected in the
following manner:
1. Use a standard 20 lbs. LP tank with QCC
– 1 fitting
2. Grills set up for LP gas come equipped
with an LP hose regulator assembly for
connection to a standard 20 lbs. LP
cylinder (Type 1)
NOTE: DO NOT use any tape, pipe dope or
threading compound on any flare fitting. This
will cause a clog in the regulator and prevent
your grill from functioning properly.
Insert the regulator inlet into the cylinder valve
and turn the black coupling nut clockwise until
the coupling nut is hand tight. DO NOT over-
tighten this connection.
To disconnect the coupling nut, first make sure
the main cylinder valve is turned off. Grasp
the coupling nut and turn counter clockwise.
The inlet will then disengage.
•The tank supply system must be arranged
for vapor withdrawal.
•The LP gas tank used must have a collar
to protect the tank valve.
•The LP gas tank has a shutoff valve,
terminating in an LP gas supply tank valve
outlet that is compatible with a Type 1
tank connection device. The LP gas tank
must also have a safety relief device that
has a direct communication with the vapor
space of the tank.

13 14
GAS REQUIREMENTS
A dented or rusty LP cylinder may be
hazardous and should be avoided. If in
doubt, have it checked by your LP supplier.
Always check for leaks after every LP cylinder
change. (See Checking For Leaks)
Cylinders must be stored outdoors in a well-
ventilated area out of the reach of children.
If your grill is stored indoors, the LP cylinder
must be stored outside, in upright position
and away from excessive heat.
IMPORTANT
All installation and all installation parts
must conform to local codes with the
National Electrical Code, ANSI Z223.1/
NFPA 70 latest edition and the National
Fuel Gas Code ANSI Z223.1/NFPA
54 in the U.S. and CGA-B149.1/.2 in
Canada
CONNECTING TO A SIDE BURNER
You will need a ‘T’ adapter fitting (not provided)
or similar connection to connect a single gas
line to both a side burner and a grill. We
recommend a licensed gas technician install
all gas lines. See below figure for installation
of a ‘T’ adapter.
LIQUID PROPANE INSTALLATION
NOTE: Ventilation is requiredin the
enclosure on opposite sides to create cross-
ventilation. Liquid propane is heavier than
natural gas and vents should be located
near the bottom of the enclosure.
LIGHTING THE GRILL
VALVE IGNITION
MANUAL IGNITION
CAUTION: Always wait five (5) minutes for
gas to clear after any unsuccessful lighting
attempt.
NOTE: Keep the hood closed during the
pre-heat period. For perfect sear marks,
pre-heat grill for at least 15 minutes.
BEFORE LIGHTING
ROTISSERIE BURNER
IMPORTANT: REMOVE THE
WARMING RACK PRIOR TO
TURNING ON THE ROTISSERIE
BURNER. Turning the rotisserie burner on
while the warming rack is installed will
cause the warming rack to warp and
void the warranty.
Follow valve ignition lighting instructions
allowing for 5-7 seconds for gas to reach
and fill rotisserie burner.
Never operate the grill unattended. DO NOT
OPERATE ROTISSERIE BURNER WITH
WARMING RACK INSTALLED
WARNING!
Before lighting the burners, inspect the gas
supply piping or hose. If there is evidence of
cuts, wear, or abrasion, it must be replaced prior
to use. Always keep your face and body as far
away from the grill as possible when lighting. 1. Follow steps 1-3
2. Place either a burning long-barrel butane
lighter or a burning long-stem match near
the manual flash tube to the right of the grill.
For back burners, hold the flame against the
surface of the back burner.
3. Hold the lighter or match flame at the top of
the manual flash tube for five (5) seconds,
or, next to the back burner. Then depress
the appropriate control knob and while
pressing turn it counterclockwise to the HI
position. Remove the lighter or match when
the burner lights and release the control
knob.
4. If the burner does not light within five
(5) seconds of turning the control knob,
immediately depress the knob and turn the
control knob to off. Wait five (5) minutes
before repeating steps 2-4 of the MANUAL
LIGHTING instructions.
1. Open the hood before lighting; do not
attempt to ignite burners while hood is
closed.
2. Make sure gas supply is turned on.
3. Make sure burner control knobs are in the
“OFF” position.
4. Press in the control knob then slightly turn the
knob counterclockwise while still pressing in.
5. Hold in the above position for 5 seconds
allowing the gas to reach the manifold.
6. Turn the knob counterclockwise past the
ignition to the high setting to ignite. You will
hear the one time clicking sound of the spark
ignition.
7. After ignition, set the knob to the desired
setting.
Your Summerset Professional Grill is equipped
with reliable, high-efficiency piezo ignition
valves. Below are instructions for valve ignition
and manual ignition lighting.
PLEASE Keep your face and body away from
the grill top when lighting
NOTE:
If the burner doesn’t ignite, wait five (5)
minutes before repeating steps 4-7.
NOTE:
DO NOT turn on more than one valve at a
time for either

15 16
MAINTENANCE TIPS MAINTENANCE TIPS
STAINLESS STEEL MAINTENANCE
IMPORTANT NOTE: FOR LOCATIONS
NEAR COASTAL AREAS AND POOLS
WARRANTY NOTE
LOW FLAME ADJUSTMENT
control knob and while pressing turn
clockwise to the “OFF” position.
2. Always close the valve from the gas
When removing stubborn stains:
1. Do not use metallic abrasives and always
rub in the direction of the grain
2. Some household cleaning products are not
suitable for stainless steel; be sure to read
the label before using on the grill
3. Always use the mildest cleaning solution
first, scrubbing in the direction of the grain
4. Specks of grease may gather in the grain
of the stainless steel and bake on to the
surface, giving the appearance of rust
5. To remove these baked-on foods use a fine
to medium grit non-metallic abrasive pad
(Scotch Brite is good) in conjunction with a
stainless-steel cleaner
6. Solutions used for cleaning concrete and
masonry can be very corrosive and will
‘attack’ stainless steel
7. Be sure your Summerset products are well
protected before using these products
After each use wipe down the exterior of the
grill to remove grease and splatters. Use a
commercially available stainless-steel cleaner
to clean and polish the exterior surfaces. Doing
these things on a regular basis minimizes the
amount of effort required
#304 stainless steel materials used in the
construction of your Summerset Professional
Grill are highly rust resistant, however, chlorine
in the air from swimming pools or the salt from
sea air may cause surface rust to appear and
even create some pitting if left on the product.
Here are a few tips to avoid this:
•Routinely wash with warm soapy water
and apply stainless steel polish to
protect grill interior.
• Burn off excess food debris and marinades
for 15 minutes after cooking
• Once the unit is cool, turn over the burner
covers and burn the top side (the burner
covers are reversible and are able to
be mounted upside down for cleaning
purposes)
• Use an approved stainless-steel oven
cleaner to remove grease build up and
wipe away
• Routinely have a professional barbecue
cleaning company detail the barbecue for
best results and longevity
PRE-HEATING THE GRILL
Pre-heating your grill every time you use it is
extremely important. Pre-heating allows the
briquettes to properly heat up, providing more
even and more consistent cooking results. Pre-
heat your grill by igniting all main burners. Then
close the hood and allow the grill to heat for 10 to
15 minutes, the hood thermometer should reach
approximately 450°. Once you’ve reached
your desired pre-heat temperature, turn off the
burners that you won’t be using to cook your
food. Remember, surface temperature can be
up to 200° higher.
SHUT OFF INSTRUCTIONS
1. To shut off the unit, depress each valve
•To Adjust the Burner to a Low Setting:
• Make sure the grill is cool and the gas is off
• Remove the racks so you can see the flames
while adjusting the flame height
• Turn the burner to “LOW”
• Pull off the control knob
• Use a flat head screw driver and adjust the
“gold flathead screw” in the valve to the
proper flame height
•Turn on the gas and light the burner
allowing it to preheat on high for 3 minutes
•Turn off gas and readjust if needed
supply after each use of the unit.
NOTE: When using a portable propane tank:
Propane tanks are equipped with a safety
shutdown device that may cause low or no gas
pressure/flame at the burners if operating and
lighting instructions are not followed exactly.
CLEANING THE DRIP TRAY
The drip tray should be cleaned after each use.
After the grill is completely cool, remove the
drip tray by pulling it out until it stops, then lifting
the front edge until the drip tray comes free.
Clean it with hot soapy water or an oven-style
cleaning product and re-install. When using an
oven-style cleaning product be sure to carefully
follow the manufacturer’s instructions. Many of
these cleaners are toxic and can damage the
stainless-steel finish if not used properly. Also,
check the tray after rain. If you’ve left the grill
uncovered, you may need to remove the drip
tray to drain the water from the tray.
MAINTENANCE TIPS
STAINLESS STEEL NEEDS TO BE
CLEANED?!? ABSOLUTELY!
Stainless steels need to be cleaned for aesthetic
considerations and to preserve corrosion
resistance. Stainless steel is protected from
corrosion by a thin layer of chromium oxide.
Oxygen from the atmosphere combines with
the chromium in the stainless steel to form
this passive chromium oxide film that protects
from further corrosion. Any contamination of
the surface by dirt, or other material, hinders
this passivation process and traps corrosive
agents reducing corrosion protection. Thus,
routine cleaning is necessary to preserve the
appearance and integrity of the surface. If you
think about it, you wash your dishes and clean
your cooking surfaces after each use in your
indoor kitchen...Why should your outdoor
cooking appliance be any different???
GRILL EXTERIOR
GRILL INTERIOR
• Regularly wipe down the exterior surfaces
with a damp cloth (micro fiber towels work
well)
• Allow the surfaces to dry before installing
the cover Do not cover a damp grill
• In extreme environments apply a rust
inhibitor which leaves a microscopic
protective layer on the grill
• For seasonal storage use the product
referred to above, ensure the grill is
dry, then cover and secure the cover to
minimize the amount of damp air getting to
the surfaces
The Summerset Lifetime Warranty
provides protection against rust
through of parts that render the
product inoperative. It does not cover
occasional surface rust or staining due to
environmental conditions.
After your first use, certain areas of the grill
may discolor from the intense heat given off
by the burners - this is normal and cannot be
cleaned off. For light and heavy food stains
there are many different stainless-steel cleaners
available.

17 18
GRILL FEATURES
DROP-IN SEAR BURNER
INSTALLATION
LIGHTING DROP-IN SEAR BURNER
IMPORTANT: : Turn the back burner to low
or off when stopping the rotisserie to prevent
over cooking
1. Remove the warming rack, cooking grates,
and burner covers (briquette trays)
2. Mount the rotisserie motor bracket on either
side of the grill nearest the outlet
3. Slide the rotisserie motor onto the rotisserie
motor bracket
4. Insert rotisserie spit (rotisserie rod) into
motor
5. Place 1st fork onto the rotisserie spit and
secure tightly
6. Position the meat onto the spit securing to
the 1st fork
7. Place 2nd fork onto the spit securing to the
meat and tighten screw
8. Insert collar onto spit
9. Screw on handle nut and handle
10. Add a drip pan beneath the meat to catch
drippings and retain moisture in the meat
11. Light back burner per lighting instructions in
this manual and close grill lid
12. Release hood heat periodically (every
10-15 min) by opening hood
ROTISSERIE INSTALLATION
CAUTION: When using the back burner,
keep the grill lid closed to prevent heat loss,
provide proper convection and provide
proper venting. This will ensure even cooking
temperatures.
Do not keep you grill lid open while cooking
on the rotisserie as this may cause personal
injury, or in some cases, in windy conditions,
damage the grill.
Do not use the rotisserie motor in the rain. Do
not leave the motor on the grill when not in use.
ROTISSERIE INSTALLATION
The preferred location to install a drop-in sear
burner is on the far left of the grill. This will
allow for a sear zone while maximizing the
main burner grilling space. To install a drop-in
sear burner:
1. Open the hood before lighting; do not
attempt to ignite burners while hood is
closed.
2. Make sure gas supply is turned on.
3. Make sure burner control knobs are in the
“OFF” position.
4. Press in the control knob then slightly
turn the knob counterclockwise while still
pressing in.
5. Hold in the above position for 5 seconds
allowing the gas to reach the manifold.
6. Turn the knob counterclockwise past the
ignition to the high setting to ignite. You
will hear the one time clicking sound of the
spark ignition.
7. After ignition, set the knob to the desired
setting.
•Remove the grate and burner covers to
access the main burner
•Remove the cotter pin securing the main
burner (if necessary)
•Remove main burner
•Remove cross tube in between main
burners allowing for drop-in sear burner
to rest flat
•Install sear burner with the center of the
orifice positioned in the center of the
burner and rest the back of sear burner
flat on the rear of the grill
EXPLODED VIEW

19 20
Item Description Sizzler 26” Qty Sizzler 32” Qty Sizzler 40” Qty
1Top Hood HOOD-SIZ26 1HOOD-SIZ32 1HOOD-SIZ30 1
2Temperature Gauge TEMP 1TEMP 1TEMP 1
3Temperature Gauge Bezel TEMP BZL 1TEMP BZL 1TEMP BZL 1
4Hood Bumper HOODBUMP-SS 2HOODBUMP-SS 2HOODBUMP-SS 2
5Hood Handle HOODHAND-SIZ26 1HOODHAND-SIZ32 1HOODHAND-SIZ40 1
6Warming Rack WARM-SIZ26 1WARM-SIZ32 1WARM-SIZ40 1
7Main Cooking Grate GRATE-SIZ 3GRATE-SIZ 4GRATE-SIZ 5
8Burner Covers/Briquette Trays BRNCOV-SIZ 3BRNCOV-SIZ 4BRNCOV-SIZ 5
9Heat Shields HEAT SHIELD-SIZ 3HEAT SHIELD-SIZ 4HEAT SHIELD-SIZ 5
10 Cross Tubes CROSS TUBE-SIZ 2CROSS-SIZ 3CROSS TUBE-SIZ 4
11 Main Burners TUBE-SIZ 3TUBE-SIZ 4TUBE-SIZ 5
12 Drip Tray DRIP-SIZ26 1DRIP-SIZ32 1DRIP-SIZ40 1
13 Rear Hood - A REAR HOOD-SIZ26 1REAR HOOD-SIZ32 1REAR HOOD-SIZ40 1
14 Rear Hood – B (comes with 13)
15 Basin/Fire Box BASIN-SIZ26 1BASIN-SIZ32 1BASIN-SIZ40 1
16 Natural Gas Regulator (NG setup only) REG-SIZ-NG 1REG-SIZ-NG 1REG-SIZ-NG 1
17 Manifold MAN-SIZ26 1MAN-SIZ32 1MAN-SIZ40 1
18 Main Valves MV-SIZ-(NG OR LP) 3MV-SIZ-(NG OR LP) 4MV-SIZ-(NG OR LP) 5
19 Back Burner Valve/Rotisserie Valve N/A 0BBV-SIZ 1BBV-SIZ 1
20 Front Panel FRONT-SIZ26 1FRONT-SIZ32 1FRONT-SIZ40 1
21 Logo Plate/ Logo Badge LOGO PLATE-SIZ 1LOGO PLATE-SIZ 1LOGO PLATE-SIZ 1
22 Knob Bezel KNOB BEZEL SIZ 3KNOB BEZEL SIZ 5KNOB BEZEL SIZ 6
23 Knob KNOB-SIZ 3KNOB SIZ 5KNOB SIZ 6
24 Back Burner Electrode Cover N/A 0BBE-COV-SIZ 1BBE-COV-SIZ 1
25 Rotisserie Burner/IR Back Burner N/A 0IR-BACKBRN-SIZ32 1IR-BACKBRN-SIZ40 1
26 Flexible Back Burner Gas Line N/A 0FLEX TUBE-BB-SIZ32 1FLEX TUBE-BB-SIZ40 1
27 Back Burner Wire N/A 0BBW-SIZ32 1BBW-SIZ40 1
28 Back Burner Electrode N/A 0BBE-SIZ 1BBE-SIZ 1
REPLACEMENT PARTS LIST WARRANTY INFORMATION
2018 SUMMERSET SIZZLER SERIES WARRANTY
• Lifetime Warranty on construction and manufacturers defects
• Lifetime Warranty on frame and housing
• Lifetime Warranty on cooking grates, burners and valves
• One year warranty on all other parts, components and electrical
Summerset Professional Grills Warranty is valid for original purchaser at original site of delivery with proof of
purchase and photo documentation only. Registration form must be submitted within 30 days of the purchase
date to validate the warranty. Warranty is void upon transfer of ownership. Warranty does not apply to products
installed in any commercial, rental, or non-residential application. Warranty covers replacement parts only.
Manufacturer is not responsible for labor or labor-related costs. Warranty does not cover discoloration, surface
rust, corrosion, or oxidation, which may occur due to harsh environments, chemicals, or overheating. Warranty
will not apply for damage resulting from improper installations, abuse, extreme environments, grease fires, or
misuse. Regular and proper maintenance is required. Coastal, humid, and/or salt environments are subject
to manufacturer review. All out-of-box claims must be made within 30 days of purchase and must be made
prior to installation. Any product installed damaged will be considered damaged during installation and not
covered under warranty. Warranty and registration forms are available at www.SummersetGrills.com. Please
be advised – all display models are sold “as is” and the warranty covers the following items only: main burners
(lifetime), grates (lifetime), burner covers (1 year). All warranties are subject to the review and approval of the
manufacturer.

21 714.966.8126 SUMMERSETGRILLS.COM 17322 GOTHARD ST., HUNTINGTON BEACH CA. 92647
