SUPPLEMENT FOR MODEL: 3350
This correction sheet must be used in conjunc-
tion with the 7990 Alpine II operator's manual
(P/N 414 6786 00)
[!]ski-doo.I
ALPINE® II
OPERATOR'S MANUAL
7
ool ... 1
--'--'--
414697400

BOMBARDIER
snowmobiles
MODEL: 1990 ALPINE® II (Military version)
VEHICLE CODE :
3350
BATTERY
1. Remove battery from vehicle.
2. Remove the sealing tube from battery vent elbow.
• WARNING : Failure
to remove the sealing tube
could result in an explosion.
3. Remove caps and fill battery to the UPPER LEVEL
line with electrolyte (specific gravity: 1.260 at 20°C
(68°F)).
4. Allow battery to stand for 30 minutes MINIMUM so
that electrolyte soak through battery cells.
5. Readjust electrolyte level to the UPPER LEVEL line.
6. Charge battery at a rate not exceeding 2.0 amperes
for 10 to
20 hours checking state of charge frequently.
.._.CAUTION : If charging rate exceeds 2.4 amps.
T reduce immediately. If cell temperature rises above
50°C (122°F) (if the casing feels hot) discontinue
charging temporarily andIor reduce the charging rate.
• WARNING : Gases given
off by a battery being
charged are highly explosive.
Always charge in
a well ventilated area. Do
not smoke or allow open
flame or spark in vicinity.
Always turn battery charger
off prior to disconnecting cables. Otherwise a spark
will occur and battery might explode.
7. After charging, allow the gas bubbles to escape by light-
ly shaking battery by hand. Let it settle for about one
hour.
8. Readjust electrolyte level to the UPPER LEVEL line if
required.
9. Reinstall battery caps and wipe off any spillage using
a solution of baking soda and water.
.._.CAUTION : Do not allow baking soda and water
T solution to enter battery cells and contaminate
electrolyte.
10. Connect one end of vent tube to the battery vent
elbow and route other end through hole
in bottom
pan.
• WARNING
:Vent tube must be free and open. A
kinked
or bent tube will restrict ventilation and
create gas accumulation
that could result in an explo-
sion.
11. Secure battery to rack and connect terminals.
.._.CAUTION : Battery negative {-) terminal must
T always be disconnected first and reconnected
last.
Litho'd in Canada
®*Trademarks
of Bombardier Inc.
All rights reserved © Bombardier Inc.
WINDSHIELD
SERVICE PROCEDURE
PRIOR TO OPERATION
Carefully peel off protective film from windshield.
Position windshield on cab, over locating slots. Push down
until tabs
are fully inserted in slots and lock, from inside
cab, using special a-rings (8) supplied.
414 6973 00
PAGE 1 OF 1

+WARNING : The engine and the corresponding components identified
in the
operator's manual should
not be utilized on product(s) other than that men-
tioned on the cover page
of the operator's manual.

CONTROLS/INSTRUMENTS ___ _
Seat compartment
Unfasten spring catch and tip seat over
from right
side. Two jacks and a spare
drive belt are hold
by brackets on left
side
of seat compartment, note their po-
sitions for proper storage.
Two spare
spark plugs are screwed on a support
on right side of seat compartment. The
storage cover
is also located in seat
compartment.
Spare
spark plugs
A017 007 086
Hour meter
Spare drive belt ,
The hour meter and its filter are locat-
ed in battery compartment at front of
seat compartment. The hour meter in-
dicates the total number of engine run-
ning hours.
Ski tie downs
On each side of rack, two ski tie downs
are riveted.
A017 007 087
Jack utilization
Install jacks as illustrated to support rear
portion of vehicle
off the ground.
!Right side
illustrated)
A017 007 088

TOOLS ____________________ __
As standard equipment each new snowmobile is supplied with basic tools such
as screwdriver, wrenches, emergency starting rope, etc.
Standard Tools
A
Cfi±S#lD
D
A001 001 119
A. Screwdriver
B. Socket 10/13 mm
C. Open end wrench 10/13 mm
D. Socket wrench handle
E. Emergency starting rope
2 -----------------------------
B c
0 i
F
H
F. Socket 21/26 mm
G. Hexagonal wrench
(adjuster blocks)
H. Emergency starter clip
I. Jack (2)

w
BULB
15·21WI
STARTER
BATTERY
151 ~I e:.~ii'
C-13
l5
HIGH BEAM
INDICATING LAMP
,.
I
-&"
:r
-
•
:a
-
--
~
2
:;
G)
DJ
..
-<
c
-
l>
G)
:a
l>
~
SPEEDOMETER

LOCATION OF CONNECTORS
C-1, C-2, C-3,
C-4 : On engine, right side
C-5, C-6, C-7, C-8, C-9, C-1
0, C-11
Underneath dashboard
C-1 2 : Near headlamp
C-13 : Near electric starter
C-14 : On taillight housing
C-15 : Under carburetor
C-16 : Near regulatorIrectifier
4
BK
WH
RD
BL
YL
COLOUR CODES
BLACK GN
GREEN
WHITE GY
GREY
RED
VI -VIOLET
BLUE
OR
ORANGE
YELLOW
BR
BROWN
