Sky viper Vector User manual

AAA (LR 03) 1.5V

(Not Included)

Install

LiPo

Battery

A B

3.7V 500mAh

LiPo BATTERY

CAUTION: Consumers should conrm the lawful use of

this product with local authorities as laws may vary.

CHARGING PLANE BATTERY

LANDING GEAR INSTALLATION

TROUBLESHOOTING

REMOTE BATTERIESFLY MORE !

INSPECTING AND REPLACING DAMAGED PROPS

Remove battery from plane and attach to

charging cable. (Use included cable only)

Landing gear is recommended when landing

on concrete or other smooth paved surfaces

to avoid damage.

Firmly insert wheels into slots as shown,

ensuring that the longer wheel is inserted in

front, with wheel pointing forward. Back

wheels should point outward.

Insert batteries as shown. Replace door and

secure with screw. Remote will beep 2x every

couple seconds when batteries run low and

need to be replaced.

Why wait for your battery to recharge.

Increase your flight time with an extra

battery on standby! (Sold separately).

Sky Viper 500mAh LiPo battery

recommended, or comparable 3.7V

LiPo battery with JST connector plug.

Skyrocket warrants to the original purchaser that this product is free of defects in materials or workmanship for

30 days from the original purchase. This warranty only applies to defects in material and workmanship and is not

valid if the product has been misused or not assembled and maintained per instructions. Proof of defect or

malfunction must be provided and verified, along with original sales receipt with date. For quickest resolution,

defective product should be returned to the original point of purchase for exchange or refund. If you have questions

or difficulties, please contact Skyrocket Toys customer service department at [email protected].

Before each use, an adult should check this product and the LiPo battery to ensure no

damage or hazards exist. Plane has rotating blades that move at high speed, posing

danger of damage and injury. Pilots are responsible for any actions that result in

damage or injury from the improper operation of plane. Do not fly near spectators or

animals. Keep spinning props away from fingers, hair, eyes and other body parts.

Never leave plane unattended while it is turned on. Read all enclosed information

before operating. Please do not remove the triangle screws for any maintenance.

SKYROCKET TOYS 30-DAY LIMITED WARRANTY

IMPACT RESISTANT DESIGN

Vector is designed to take the abuse of

learning to fly. However, if plane is damaged

from severe impact or rough extended use, it

can likely be sufficiently repaired with the

included mending tape.

For best performance, periodically inspect prop blades for

damage or debris wrapped around motor shaft. If damaged,

firmly hold motor housing and pull damaged blade from

shaft. Make note of A or B marking on prop and replace

with corresponding new prop.

Once charged, disconnect battery from cable and

reattach to plane. Tuck back into plane and secure

door with screw. Remote will beep 1x every couple

seconds when LiPo battery runs low.

• Do not use rechargeable batteries.

• Non-rechargeable batteries are not to be recharged.

• Do not mix old and new batteries and Do not mix alkaline, standard (carbon-zinc)

or rechargeable (ni-cad, ni-mh, etc.) batteries.

• Batteries are to be inserted using correct polarity.

• Remove exhausted batteries as soon as possible and discard properly.

• Remove all batteries from compartment if beacon is not used for a long period of

time.

• The supply terminals are not to be short circuited.

• Batteries should be replaced by an adult.

• Never throw batteries in a fire or attempt to open the

outer casing.

WARNING: Batteries are harmful if swallowed. Please keep away from children.

Battery Disposal: Dispose of batteries according to the local laws and regulations

of your region. Some batteries may be recycled, and may be accepted for disposal

at your local recycling center. If you are not able to identity the application rules in

your areas, please check the instructions of the battery manufacturer.

REMOTE AAA BATTERY WARNINGS & SPECIFICATIONS:

PLANE CONTAINS A LITHIUM-POLYMER BATTERY3.7V 500mAh:

LiPo batteries have a severe risk of fire and injury if they are improperly handled or misused. They may explode,

overheat or ignite.Read all following precautions and instructions regarding the care and use of LiPo batteries.

The LiPo battery is only to be used with the drone and charger included with this product.

• Keep away from flammable materials.

• Do not expose to direct sunlight.

• Do not place in a fire or leave in hot places.

• Do not drop or make subject to strong impact.

• Keep dry and away from water.

• The supply terminals are not to be short circuited.

• Never throw into a fire or attempt to open outer case.

• Do not stress, press or drop.

• Never charge unattended. When charging you should always remain in constant observation to monitor the charging

process and react to potential problems that may occur.

• Disconnect charging cable if fully charged.

• Never store or charge inside a car in extreme temperatures, since extreme temperature could ignite fire.

• Use caution to avoid puncture. Puncture of battery may cause a fire.

LiPo Battery Disposal: LiPo batteries must be recycled or disposed of properly. They should not be disposed of

with other household waste. Check your local laws and regulations for correct recycling and/or battery disposal.

This device complies with PART 15 of the FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference

that may cause undesired operation.

CAUTION: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna - Increase the

separation between the equipment and receiver - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected - Consult the dealer or an experienced radio/TV technician for help.

5V, 2A adapter

Recommended

(Sold Separately)

GREEN =

full charge

RED =

charging

Remote beeps 2x every couple seconds and/or doesn’t connect to plane.

Remote beeps 5x quickly during flight, and plane starts radial descent.

Turn plane off then on again to deactivate crash detection (auto-beep) and restore normal plane controls.

You are in danger of flying out of range. Turn back immediately to prevent losing remote connection.

Plane battery is running low. Recharge LiPo battery to full power.

- Plane cannot maintain altitude and drifts to ground.

- Plane LED is flashing.

- Remote starts to beep 1x every couple seconds.

Remote batteries are running low. Replace with fresh batteries.

Plane has flown out of range. Plane auto-lands for safety and starts auto-beeping to help you locate it.

Take-off surface may be too bumpy or plane battery may no longer have enough power to complete a runway

take-off. Try again with a freshly charged battery, or launch by hand instead.

Turn off both remote and plane. Unplug then re-attach plane battery. Ensure remote batteries are new and

plane battery is fully charged, then reattempt flight.

Plane bounces around or flips over when attempting runway take-off.

- Plane does not respond to remote.

- Plane starts to fly erratically or becomes difficult to control.

Remote beeps 5x quickly during flight, while plane is far away.

Plane is beeping after crash or landing and no longer responds to remote.

AGES

12+

Vector (model no. 18601) FCC ID: O5318601RX

Remote controller (model no. 18601TX)

FCC ID: O5318601TX

INITIAL SET-UP & MAINTENANCE

vector

30 FT. (10m)

2 3

1 2 3

LEFT

RIGHT

Beep

18601-US-G2

ADULT SUPERVISION REQUIRED TURNING ON POWER

UNDERSTANDING FLIGHT CONTROLS

SMOOTH SURFACE TAKE-OFF

LANDING

PERFORMING AEROBATIC STUNTS

LAUNCHING BY HAND

FIND MY PLANE / AUDIO TRACER

Place plane on smooth flat surface with at least 30 ft (10 m) of room for take-off.

Push full to build speed then full to take-off.

Hold remote with left hand, with and

Hold plane in right hand, gripping the underside near the

LED light. Point plane forward and away from you.

Toss and release plane slightly up and forward, then immediately push

to complete launch.

Adequate flying space is required. Keep a safe distance away from

streets, public thoroughfares and power lines. Never attempt to

retrieve plane from any location that poses a safety hazard. Never fly

plane at night. Keep plane in sight at all times during operation.

Discontinue operation immediately if plane flies out of your field of view.

slightly to slowly descend. As plane

nears ground, a little more to create

a stalling effect for a softer landing.

Tap stunt button then quickly pull

to pull up. Plane will climb

and auto-complete an upward loop.

UPWARD LOOP

Tap stunt button then quickly push or

Plane will roll in corresponding

direction and auto-complete a barrel roll.

LEFT OR RIGHT BARREL ROLL

to go faster

Throttle forward

throttle forward

Throttle back

throttle back

to go slower

Throttle back

direction back

Sky Viper flight software helps

compensate for wind, but

additional manual compensation

is normal during flight. For best

performance, avoid flying in

windy conditions.

OPTIONAL: Throttle stick is also capable of applying left

and right turning force during flight. Most pilots however,

may prefer using only the direction stick for making turns.

Throttle back full to cut power to motors Direction left to bank left

Direction right to bank right

Direction back to pull up

Direction forward to dive down

Ensure plane batteries are fully

charged and remote has fresh

batteries installed. Press and hold

remote button for 1 second to turn on

or off. Slide plane button forward to

turn on and back to turn off.

SLIDE FORWARD

THROTTLE STICK DIRECTION STICK

WARNING: Push throttle forward immediately after release, but NOT BEFORE,

to avoid possible injury to back of hand from spinning props.

Ensure plane is flying high enough

to safely complete maneuvers.

Remote will beep 5x quickly when you’re in

danger of flying out of range, allowing time to

turn back before losing connection. If plane flies

out of range, remote will continue beeping and

plane will auto-land in a radial descent. Audio

tracer will turn on and plane will start beeping to

help you find it. Turn plane off and on again to

deactivate audio tracer.

Audio tracer can be

toggled on and off with

stunt button when

plane is not flying.

PRESS & HOLD

for one second

direction back

direction left

direction right.

throttle back

throttle forward full

motors off.

Questions or comments?

Please email support@skyrockettoys.com

Other trademarks and trade names are those of their respective owners, and there is no relationship express or implied with Skyrocket LLC. MADE IN CHINA

FLYING VECTOR STUNT PLANE
