SkylinkHome Houselink SW-318R User manual
You will see 10 connectors. For connectors “1” to “9”, the
settings must match with those of the transmitter.
It is recommended to randomly set the operation code for your
remote control to avoid interference from other devices. Follow
the instructions below to change the operation code.
1. INTRODUCTION
Houselink®WirelessSwitch
Receiver Model SW-318R
2. SETUPTHEOPERATIONCODEFORRECEIVER
In this package, you will find a wireless switch receiver and a clip.
WirelessSwitch
Receiver
Clip
‘+’ ‘-’
‘0’
Remove the receiver from the electrical outlet before
changing the code.
WARNING
BATTERY
1
2
3
Connectors
1 to 9 are
thesame.
Clip
Remove the screw that holds
the connector cover, and pry
off the cover.
2. SETUPTHEOPERATIONCODEFORBOTH
TRANSMITTERANDRECEIVER(CONT)
3. INSTALLATION
Plug the receiver into a powered, 120VAC electrical outlet inside
your house. (Note: This receiver is designed to be used indoor
only. Do not use this receiver in an outdoor environment.)
Once the receiver is plugged into an
electrical outlet, the red LED on the
front of the unit will be “on” indicating
the unit is in standby mode.
Plug in the light fixture or small
appliance that you would like to
control into the receiver, as shown.
If there is a power switch on the
plugged in light fixture or small
appliance, please turn it on. The
receiver is ready to be activated.
Pressing the appropriate button will
turn on the plugged in device and
the red LED on the front will flash.
(Caution: When the red LED on the
unit is flashing, that means output
outlet is powered. Do not disconnect/
connect devices from/to the receiver’s
outlet when the red LED is flashing.)
1
2
3
4
5
You can randomly remove some of
these connectors, leaving some
connectors in place.
A connector can be removed with
the clip, as shown.
If the connector is placed on the top and middle posts, that
column is set on “ + ” . If the connector is placed on the middle
and bottom posts, that column is set on “ - ”. If the connector
is removed completely, (not placed on any posts), it is set to “ 0 ”.
(see diagram for examples of how
to set a column to the three different
positions). When removing a con-
nector to set a column to “0” posi-
tion, save the connector in case you
change the code at a later date.
Connector 10 “Removed” TRANSMITTER
Button 2- Right button
Connector 10 set to “+” TRANSMITTER
Button 1- Left Button
RECEIVER
RECEIVER
6Put the cover and screw back onto the receiver. Plug the
receiver into an electrical outlet.
Put the battery cover back onto the transmitter.
7
For connector “10” on the receiver, set the connector on “+” if
you are using button “1” to control this receiver. If you are
planning to use button “2” to control this receiver, you need to
remove this connector. See diagram below.
4.OPERATION
To activate the receiver, simply press the appropriate button on
the transmitter, it will activate the plugged in device. Pressing it
again will turn off the plugged in device.
4
5
If, within one year from date of purchase, this product should become defective
(except battery), due to faulty workmanship or materials, it will be repaired or
replaced, without charge. Proof of purchase and a Return Authorization are required.
8.WARRANTY
You can add as many additional transmitters as you want to control
the same receiver. Simply set the same operation code on all
transmitters with the same code setting on the receiver. Houselink®
offers Keychain Transmitter Model 318TN to work with your
receiver. For more information, please visit our website at
www.skylinkhome.com or contact us.
5.ADDITIONALTRANSMITTER
9.CUSTOMERSERVICE
6.CAUTION
7.FCC
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:
(1)Thisdevicemaynotcauseharmfulinterference,and(2) This device mustacceptanyinterference
received,including interferencethatmaycauseundesired operation.
WARNING:
Changesor modifications tothisunitnotexpresslyapproved by thepartyresponsibleforcompliancecould
voidthe user’sauthoritytooperate theequipment.
NOTE:
Thisequipmenthas been tested and found tocomplywiththelimitsforaClassBdigital device, pursuant
toPart15oftheFCCRules.Theselimitsaredesignedto provide reasonable protection againstharmful
interferenceinaresidentialinstallation.Thisequipment generates, uses and can radiate radio frequency
energyand,ifnotinstalledandused in accordance with the instructions, may cause harmful interference
toradiocommunications.
However,thereisnoguaranteethatinterferencewill notoccurinaparticularinstallation.Ifthisequipmentdoes
causeharmfulinterferencetoradioortelevisionreception, whichcanbedeterminedbyturning the equipment
offandon,theuserisencouragedto trytocorrecttheinterference byoneormore of thefollowingmeasures:
-Reorientorrelocatethereceiving antenna.
-Increasethe separation betweentheequipmentandreceiver.
-Connecttheequipmentintoanoutletonacircuitdifferentfromthatto which the receiver is connected.
-Consultthedealeroranexperiencedradio/TVtechnician for help.
RISKOFELECTRICALSHOCK.FORINDOORUSEONLY.
CAUTION:NOTFORUSEWITHDIMMER.
DISCONNECTPOWERBEFORECODESETTING.
REPLACECOVER AFTERCODECHANGING.
MaximumRating:
Input : 120VAC 60Hz
Resistive load : 8A (960W)
Incandescent : 300 watts
Motor Load : 1/3 HP
CUSTOMER SERVICE
http://www.skylinkhome.com
P/N.101A263 Rev.0
©2003SKYLINKGROUP
If you would like to order Skylink’s products or have difficulty getting them to work,
please :
1. visit our FAQ website at www.skylinkhome.com, or
3. call our toll free at 1-800-304-1187 from Monday to Friday, 9 am to 5 pm EST.
Fax +800 286-1320
