Slane CALEDON User manual

USER MANUAL
CALEDON/VICTORIA E-BIKE
This user’s manual explains the operation and maintenance of your E-Bike.
Diagrams in this manual may differ from actual products; refer to your local dealer’s existing products.
Slane reserves the right to change or improve their products; further notice will not be given.

TABLE OF CONTENTS
ABOUT THIS MANUAL
• Why You Should Read This Manual....................................................1
• WARNING.........................................................................................1
• Specifications.....................................................................................2
• Helmets & Reflectors.........................................................................3
OPERATING INSTRUCTIONS
• Front Wheel Assembly…………....….................................................4
• Steering Wheel Adjustment/Front Fender Assembly.........................5
• Basket Assembly/Rear Light Operation ............................................6
• Powering On…..................................................................................7
• Riding Your E-Bike/Serial Number ....................................................8
• Riding Safely.......................................................................................9
• Battery Charging..........................................................................10-11
• Inserting, Unlocking & Removing Battery.........................................11
• Pedal Installation..............................................................................12
• Pedal Assist System.............................................................. ...........12
• Throttle.............................................................................................12
• Shifter/Derailleur/Adjusting Rear Derailleur.....................................13
• Wheel Brakes....................................................................................14
• Saddle Position ...........................................................................14-15
• Maintenance and Cleaning your E-Bike......................................15-16
• Battery Storage................................................................................17
• Break In Period.................................................................................17
• Flat Tire ...........................................................................................18
• Broken Spoke ..................................................................................18
• Power-Saving Tips ...........................................................................19
• Trouble-shooting..............................................................................19
• Dealer Info/Information Card........................................BACK COVER
WHY YOU SHOULD READ
THIS MANUAL
• This manual will help you get the best performance, comfort, enjoyment and safety
when riding your new E-Bike. It describes specific care and maintenance procedures
that help protect your warranty and ensure years of trouble-free use.
Pay special attention to the section on battery charging and maintenance.
• Understanding your new E-Bike’s features and operation will help you get maximum
enjoyment and safety. By reading this manual before you go on your first ride,
you’ll know how to get the most out of your new E-Bike.
• It is also essential that your first ride on your new E-Bike be taken in a
controlled environment, away from cars, obstacles and other cyclists.
WARNING!
Follow these important safety measures to ensure safe riding.
• To ensure your safety, read the user manual carefully and check that all bike parts are
perfect before riding.
• Overloading is strictly prohibited.
• Always recharge the battery immediately after each use. Failure to do so may
damage the battery. The charger can remain plugged in for trickle-charge purposes
during long periods of storage. For storage periods over one month, the battery should
be checked and fully recharged before riding.
• There is a safety power source inside the battery box of this e-bike. Removing
the battery box will expose both jacks in the lower end ( positive pole “+” and
negative pole “- “). Please do not touch these poles with your hands at the same
time (particularly damp hands). It is prohibited to touch any metal to either pole
(i.e., a key, etc.). Doing so will produce an unlimited short-circuit current and will
cause severe burns to the body.
• Don’t detach and disassemble spare parts or rebuild this electric bicycle.
Purchase spare parts from an authorized dealer of SLANE electric bicycles.
• If you find the cut-power function doesn’t happen when using the front or rear brake,
have it repaired immediately.
• This bicycle can normally ride under wet conditions to a depth of water that doesn’t
surpass the electric hub center. Allowing the electric hub to be infiltrated by water will
cause damage.
• Those under the age of sixteen years of age are not permitted to ride this E-bicycle.
1

2
WARNING!
CHARGE THE BATTERY NO LONGER THAN EVERY 60 DAYS.
DO NOT MODIFY YOUR E-BIKE (YOU MAY LOSE YOUR WARRANTY).
RIDING IN RAINY OR SNOWY WEATHER IS AT YOUR OWN RISK.
DO NOT CHARGE THE E-BIKE WHEN UNATTENDED AND DISCONNECT
THE BATTERY FROM THE POWER SOURCE AFTER FULLY CHARGING.
CHARGING MUST ALWAYS TAKE PLACE IN A DRY AND CLEAN AREA.
DO NOT CHARGE THE BATTERY ON A CARPET.
TAKE EXTRA CAUTION TO THE BRAKES AND FRONT WHEEL
WHEN RIDING DOWNHILL.
• Always wear a properly fitted helmet that covers the forehead when riding an E-Bike.
• Many Provinces require specific safety devices. It is your responsibility to
familiarize yourself with the Province’s laws where you ride and comply with
all applicable laws, including adequately equipping yourself and your bike
as the law requires.
• It is strongly recommended that you wear a properly fitted bicycle safety helmet at
all times when riding your E-Bike.
The correct helmet should:
• Be Comfortable
• Be Lightweight
• Have Good Ventilation
• Fit Correctly
• Cover Your Forehead
REFLECTORS
Your E-Bike comes equipped with front/rear wheel reflectors and four pedal reflectors.
Reflectors are essential safety devices designed as an integral part of your E-Bike.
Provincial regulations require every bicycle to have front/rear wheel and pedal
reflectors. These reflectors pick up and reflect streetlights and car lights in a way
that helps you to be seen and recognized as a moving cyclist. Check reflectors
and their mounting brackets regularly to make sure they are clean, straight,
unbroken and securely mounted. Replace damaged reflectors and straighten
or tighten any that are bent or loose.
3
HELMETSSPECIFICATIONS
Net Weight (Kg) 25 27
Battery Charging Time (Hr) 4-6 hr 4-6 hr
Battery Capacity (Ah) 10 9
Battery Type Lithium Battery Lithium Battery
Rear Brake V Brake V Brake
Front Brake Disc Disc
Load Capacity (Kg) 110 110
Range (km) 30-45 30-45
Speed (Km/h) 32 32
Motor Rated Voltage (V) 36 36
Motor Rated Power (W) 350 350
Motor Type Brushless Motor Brushless Motor
Frame Material Aluminum Steel
CALEDON VICTORIA

4 5
WARNING!
IF THE FRONT WHEEL IS NOT
FASTENED SECURELY, IT WILL CAUSE THE FRONT
WHEEL TO COME LOOSE AND CAUSE AN ACCIDENT.
ASSEMBLING THE FRONT WHEEL ADJUSTING THE STEERING
WHEEL
FRONT FENDER ASSEMBLY
• Inserted depth of vertical tube of the wheel should be no lower than minimum
depth (red safety mark). The safety mark must be below the hexagonal nut (A).
• Stand in front of the wheel, clamp the front wheel with both legs and hold the
hand-grip with both hands to adjust the angle degree between the cross tube of
hand-grip and vehicle body (B).
• Screw down the fastening screw of the wheel core. The recommended torque should
not be less than 18N.m.
• Loosen the headlight nut with a 10mm wrench, then put the fender’s hook and front
light holder together with the suspension bracket, tighten them together.
• Fix the fender support on each side with the screws and washers provided.
THREADED STEM
• Insert the stem into the steering tube, align with
the bike’s center axis, and tighten the top cap bolt.
Make sure the minimum insertion mark is hidden
inside the steering tube.
INSTALL THE FRONT WHEEL
• Insert the front wheel into the fork
• Make sure that the wheel is seated and centered
in the fork and the brake disc fits in between
the brake linings.
• Lightly apply a thin layer of grease to the axle.
• Insert the axle through the wheel making sure the
larger diameter of the spring(s) faces outward
(see diagram C).
QUICK-RELEASE BINDER
This binder is most commonly used to attach
wheels to the frame and fork or tighten a seat post
into a frame. Binders allow for a tool-free,
quicker use than nuts and bolts but require
knowledge of proper use.
• Put the lever in an opened position (A)
• Tighten the adjustment nut (1) by small
increments until you need considerable force
to push (2) the lever to its closed position (B)
with your fingers or palm.
• Test wheel attachment by lifting the front end of
the bike and firmly hit downward on the front
wheel with your palm. There should be no play
in the connection.
• Open the box from the top, take the bike, parts and accessories box out.
• Carefully remove all protective carton pieces, foam pads, tie wraps, plastic fittings,
recycle all material that can be recycled, dispose of the rest.
C.
B.A.

BASKET ASSEMBLY
• Remove the clips and screws from the box and use a screwdriver and an open-end
wrench.
• The wire support bar will be on an upward angle.
• After completing the above steps, lock the screws again with the tool.
6
POWERING ON
POWER ON/OFF
• Turn “ON” the power switch of the battery.
• Press the power button on the LED display monitor to activate the battery/controller
system.
• When powered on, press the power button to power off.
When powered off, the LED display monitor and the controller will no longer consume
power from the battery.
Turn “ON” the power
switch of the battery Power On/Off:
Press the power button
POWER ON/OFF FRONT LIGHT
• Press the + button for 3 seconds to turn ON the front light.
• Press the + for another 3 seconds to turn OFF the front light.
When the throttle or sensor is engaged (powering the motor), and the E-Bike is
in motion, the LED on the battery gauge (on the throttle or separate unit) indicate
instantaneous line voltage as measured at the battery terminals-not the available
energy in the available power in the battery pack.
The line voltage will wing out from a dead stop or going up a steep hill, the motor will
be under a high load and may show a reduced number of LED or show the “yellow”
or even “RED” LED.
When the throttle is disengaged (i.e. no power to the motor due to the bicycle being
stationary or coasting) LED on the throttle will indicate the battery pack’s voltage.
The voltage of the battery pack will rise when no load is on the motor. The best
indication of how much battery life is remaining is to check the throttle LED, after
reaching cruising speed, on a flat straight road. By doing this, the battery voltage
will stabilize and give a more accurate reading.
7
REAR LIGHT OPERATION
The rear light is integrated with the
rear reflector. There are two
AA batteries inside the reflector.
You can find the ON/OFF switch on
the left side of the reflector.
To replace the batteries, loosen
the screw on the reflector.

RIDING YOUR E-BIKE
• Once you have completed the initial battery charge, you are ready to ride.
• It is your responsibility to know and abide by all local laws that govern and restrict
electric bicycle use.
• Before riding, familiarize yourself with all the different parts of the e-bike and always
make sure that all the electrical components are in working order.
• Ensure all the bicycle parts are in good condition, i.e. battery power level, tire pressure
and brakes.
Hold onto the handlebars with both hands. Assume a well-balanced position on
the bicycle and push off with your foot. Your right hand will control the accelerator.
Twist the accelerator slowly to avoid a sudden rush of speed forward. The speed of
the bike will increase as you twist the accelerator more. Release the accelerator and
apply the brakes to stop your bike. You will control the speed of the E-Bike by using
both the throttle and the brakes. Squeezing the brake handle cuts power to the throttle.
8
RIDING ON THE ROAD
• Obey the same road laws as all other road vehicles, including yielding to pedestrians
and stopping at red lights and stop signs.
• Ride predictably and in a straight line. Never ride against traffic.
• Use correct hand signals to indicate turning or stopping.
• Ride defensively. To other road users, you may be hard to see.
• Concentrate on the path ahead. Avoid potholes, gravel, wet road markings, oil, curbs,
speed bumps, drain grates and other obstacles.
• Expect the unexpected such as opening car doors or cars backing out of concealed
driveways.
• Be very careful at intersections and when preparing to pass other vehicles.
• Familiarize yourself with all the bike’s features: practice braking and the use of horns.
• Don’t carry packages or passengers that will interfere with your visibility or control
of the bike. Don’t use items that may restrict your hearing.
• Maintain a comfortable stopping distance from all other riders, vehicles and objects.
Safe braking distance is subject to weather conditions.
RIDING IN WET CONDITIONS
• Brake earlier; it will take a longer distance to stop.
• Decrease your riding speed, avoid sudden braking, and take corners
with additional caution.
• Be more visible on the road by wearing reflective clothing and using safety lights.
• The local standard weight is 90kg (including the rider weight); do not overload.
• Potholes and slippery surfaces such as line markings, train tracks and wood become
more hazardous when wet.
NIGHT RIDING
• Ensure that the front lights (if equipped) are on.
• Wear reflective and light coloured clothing.
• Ride at night only if necessary. Slow down and use familiar roads with street lighting.
PARKING
• Shut off the power switch after you get off to prevent an unintentional abrupt start-up
of the bicycle.
• Do not start-up E-Bike frequently while resting to ensure the battery, motor, and
electric switch’s service life.
• Shut off the power after parking and remove the key.
• When the E-Bike power is on, and a person does not sit on the saddle: do not turn the
throttle; otherwise, it will cause the E-Bike to rush forward.
SERIAL NUMBER
RIDING SAFELY
9
Your E-Bike’s Serial Number can be
found on the front stem tube.
Please take note of this number and
record it on page 20 (back cover)
of this manual.

CHARGING THE BATTERY
• Switch off power and remove the key.
• Remove (rotate to open) rubber stopper in the charging hole. Plug the output plug
of the charger to the socket of the battery box. After that, plug in the power input plug
(110-220V) to a household power socket to start charging.
• After charging is finished, pull out the power input plug (110-220V) and then pull out
the output plug.
DURATION OF CHARGING
• When the input and output terminal are connected, the charger’s red indicator light
will light up to show that the power is connected.
• It will take 5-8 hours to charge the battery for the first time. When the charger’s
indicator light turns green, showing that the battery is fully charged, it will switch to
trickle charge mode to prevent over-charging. It takes 2-8 hours for regular charging.
• This charger has a protection device for over-charging. Long-time charging should
not be more than 24 hours because it will affect the lifetime of the battery.
Check the battery pack before using it for the first time.
WARNING! USE THE ATTACHED CABLES OF THE BATTERY CHARGER
FOR THE BATTERY-CHARGER ONLY!
• The charger doesn’t need to be grounded.
• During charging, place the charger in a safe location out of the reach of children
• The battery pack is supplied partially charged. To ensure full battery pack capacity,
completely charge the battery pack before using it for the first time.
• Retailers should charge the batteries as soon as receiving the E-Bike from the supplier.
• Even with proper care, rechargeable batteries do not last forever. Every time a battery
is discharged and subsequently recharged, its relative capacity decreases by a small
percentage. You can maximize the life of your battery by following the instructions
in this manual (see PAGE 17).
• Fully charge the battery once you receive it for the full recommended charge times.
Lithium battery recommended charging time: 5-8 hours.
• For a complete, 100% charge, leave the battery on the charger for one full hour after
the charger indicator light turns green.
• Never charge batteries for longer than 24 hours.
• Li-ion batteries do not have a “memory.” Partial discharge/charge cycles will not harm
the battery’s capacity or performance.
BATTERY CHARGING
10
• Always be sure to turn the bike power switch to “OFF” after each use. If you leave
the power switch on the “ON” position or your product has not been charged for an
extended period, the battery may reach a stage when it no longer holds a charge.
• Do not use other brands to charge this battery. Do not use this battery for a different
brand of E-Bike.
• The charger has a 110V circuit; please do not dismantle.
• When the charger is being used or stored, prevent liquid or metal from entering
the charger. The charger should be free from falling over to avoid injury.
• When using the charger, it should be left unobstructed.
• The charger is for indoor use only. When in use, keep it in a dry, well-ventilated area.
• If you detect an unusual odour or the temperature is too high during charging,
please stop charging immediately and send it back to the sales department for
inspection/repair.
INSERTING, UNLOCKING AND
REMOVING THE BATTERY
BATTERY CHARGING CONTINUED
WARNING!
The attached cables of the battery charger must only be used
for the battery-charger! 11
Red Light
Indicator:
Charging
Green Light
Indicator:
Charged
You can charge the battery while it’s on the bike (during riding season) OR remove the
battery and charge it indoors (in colder weather/winter months).

13
PEDAL ASSIST SYSTEM
This E-Bike has an electric pedal-assisted driving system.
The pedal-assisted driving system consists of a driving unit, a battery, a controller,
and various electronic components (harness wires, sensors and switches).
It is essential to know that when the pedal assist system is on, the driving unit
provides power only while you are pedalling. The amount of power supplied by
the unit depends on your pedalling force and the assistance model/level you set with
the handlebar control unit at any time. When you stop pedalling, the pedal assist
system will disengage. In all models/levels, the pedal-assisted driving system reduces
progressively. It cuts off as the bike reaches 25KM/h (15.5MPH), or sooner if you stop
pedalling. The pedal-assisted driving system re-engages when speed drops below
25KM/H (15.5MPH) as long the pedals are turning.
THROTTLE
PEDAL INSTALLATION
This E-bike comes equipped with a throttle.
The throttle operates by rotating the throttle
toward the rider, much like a motorcycle.
The more you twist the throttle, the faster the
motor system will propel the bicycle.
Pedals are a pair with “R” & “L” (Picture 1): “R” for right, “L” for left.
Tighten the pedals in the direction of the threads.
Picture 1 Right Left
SHIFTER
SHIFTER
This E-bike is equipped with gears, that includes:
• A rear sprocket cluster called a freewheel or cog set
• A rear derailleur
• One shifter
• One control cable
• One front sprocket
• A drive chain
There are many different types of shifter mechanisms, each preferred for specific
applications because of their ergonomic, performance and price characteristics.
A downshift is a shift to a lower or slower gear, which makes it easier to pedal.
An up-shift is a shift to a higher or faster gear, which makes it harder to pedal.
For example, you can downshift to a lower gear to make pedalling easier on a hill.
On the other hand, you may up-shift to a higher gear when you wish to go faster.
Whether up-shifting or downshifting, the derailleur system requires that the drive chain
is moving forward and is under at least some tension. A derailleur will shift if you are
pedalling forward.
CAUTION: NEVER MOVE THE SHIFTER WHILE PEDALLING BACKWARD.
DO NOT PEDAL BACKWARDS AFTER MOVING THE SHIFTER. EITHER OF THESE
ACTIONS COULD JAM THE CHAIN AND CAUSE SEVERE
DAMAGE TO THE E-BIKE.
DERAILLEUR
The derailleur system includes the front and rear derailleur, the shift levers, and the
derailleur control cables, all of which must function correctly for smooth gear shifting
to occur. The front and rear derailleurs are adjusted in the factory. You will need to
inspect and adjust both before riding your E-Bike.
ADJUSTING THE REAR DERAILLEUR
Shift the rear shifter to the highest number indicated,
loosen the cable from the rear derailleur cable anchor bolt,
and place the chain on the smallest sprocket.
Adjust the high limit screw so that the guide pulley and
the smallest sprocket line up vertically.
Re-tighten the cable, pull out any slack and re-tighten
the anchor bolt securely. When shifting through the gears,
make sure that each gear changes quietly and without
hesitation.
It is necessary to use the barrel adjuster to fine-tune the cable
tension by turning it in the direction you want the chain to go.
For example, turning clockwise will loosen the cable tension
and move the chain away from the wheel, while turning
counter-clockwise will tighten cable tension and direct
the chain to the wheel.
12

WHEEL BRAKES
SADDLE POSITION
Correct saddle adjusted position is an essential factor to get the best performance
and comfort from your E-Bike. If you find the saddle position is not comfortable,
there are two adjustments.
UP AND DOWN SADDLE ADJUSTMENT
Your leg length determines the correct saddle height.
The saddle is at the correct height if you can reach the down pedal with one heel
when seated on the saddle, and the crank arms are parallel to the seat tube.
To check for correct saddle height, perform the following:
1. Sit on the saddle, and place one heel on a pedal.
2. Rotate the crank until the pedal with your heel on it is in the down position, and the
crank arm is parallel to the seat tube. Your leg should be completely straight and just
touching the center of the pedal. If this is not the case, your saddle height needs
to be adjusted.
This screw is used to tighten the brake line
and adjust the brake effect.
This screw is used to adjust the contact surface
between the brake block and the rim.
This screw is to adjust the distance between
the brake block and the rim. To prevent the
brake block from colliding with the rim, the
gap between the two sides is equal, 1-2mm
15
SADDLE POSITION CONTINUED
MAINTENANCE & CLEANING YOUR E-BIKE
SADDLE TILT ADJUSTMENT
Most people prefer a flat saddle, but some riders prefer
to have the saddle nose tilted slightly up or down. Adjust
the saddle tilt by loosening the saddle quick-release, tilting
the saddle to the desired position, and re-tightening the saddle
quick-release. Make sure it is tight enough so that you cannot move
or jiggle the saddle. Small changes in saddle position can have a
substantial effect on performance and comfort. Whenever
changing your saddle position, make only one directional
change at a time. Make the changes in small increments until
you have found the position at which you are most comfortable.
Technological advances have made the E-Bike and the components more complex
than ever before. The pace of innovation is increasing. This ongoing evolution makes it
impossible for this manual to provide all the information required to properly repair and
maintain your E-Bike. To help minimize the chances of an accident and possible injury,
you must have any repair or maintenance performed by your dealer, not explicitly
described in this manual.
Your maintenance requirements are determined by everything from your riding style
to geographic location. Consult your dealer for help in determining your maintenance
requirements. How much of your E-Bike service and maintenance you can do yourself
depends upon your level of skill, experience, and special tool availability.
WARNING
MANY E-BIKE SERVICE AND REPAIR TASKS REQUIRE KNOWLEDGE AND TOOLS.
DO NOT BEGIN ANY ADJUSTMENTS OR SERVICE ON YOUR E-BIKE IF YOU HAVE
THE SLIGHTEST DOUBT ABOUT YOUR ABILITY TO COMPLETE THEM CORRECTLY.
IMPROPER ADJUSTMENT OR SERVICE MAY DAMAGE THE E-BIKE
OR CAUSE AN ACCIDENT RESULTING IN SEVERE INJURY OR DEATH.
INSPECTION AND MAINTENANCE
For your safety and enjoyment and to ensure a longer life for your E-Bike,
inspect and maintain your E-Bike regularly.
You must check specific systems and components before every ride.
To ensure your safety, the proper condition and function of these systems are critical.
CLEANING YOUR E-BIKE
To avoid damage or accidents caused by wet inner electrical parts, do not wash your E-bike with
a high-pressure washer. Clean off dirt on any painted metal or plastic parts with a damp cloth
using a mild cleaning product. Dry off immediately. Use lubrication oil to maintain any metal
parts of the bike. Never apply oil to the front or back brake rubber, hand brake levers, rim, tires,
battery or controller.
14

MAINTENANCE & CLEANING YOUR E-BIKE
CONTINUED
BEFORE EVERY RIDE
• Perform the mechanical safety check
AFTER EVERY LONG OR HARD RIDE, IF THE
E-BIKE IS EXPOSED TO WATER OR GRIT OR
AT LEAST EVERY 100 MILES
• Clean the E-Bike.
• Lightly oil the chain, freewheel cogs and rear derailleur pulley bushings. Wipe off
excess oil. Lubrication is a function of climate. Talk to your dealer about the
best lubricants and the recommended lubrication frequency for your area.
AFTER EVERY LONG OR HARD RIDE
OR EVERY 10 TO 20 HRS OF RIDING
• Squeeze the front brake and rock the E-Bike forward and back. Does everything feel
solid? If you feel a clunk with each forward or backward movement of the E-Bike, you
probably have a loose headset. Take your E-bike to your Dealer for inspection.
• Lift the front wheel off the ground and swing it from the side. Does it feel smooth? If
you feel any binding or roughness in the steering, you may have a tight headset.
Take your E-bike to your Dealer for inspection.
• Make sure all bolts, nuts and mounting hardware are tight.
WARNING
LIKE ANY MECHANICAL DEVICE, AN E-BIKE AND ITS COMPONENTS ARE
SUBJECT TO WEAR AND STRESS. DIFFERENT MATERIALS AND MECHANISMS
WEAR AT DIFFERENT RATES AND HAVE DIFFERENT LIFE CYCLES. ONCE A PART
IS NO LONGER WORKING OR DAMAGED, IT CAN SUDDENLY AND
CATASTROPHICALLY FAIL, CAUSING SEVERE INJURY OR DEATH TO THE RIDER.
SCRATCHES, CRACKS, FRAYING AND DISCOLORATION ARE SIGNS OF
STRESS-CAUSED WEAR AND INDICATE THAT A PART REQUIRES REPLACING.
16
BATTERY STORAGE
STORING YOUR BATTERY FOR AN EXTENDED PERIOD
• Charge your battery every 30 days to avoid capacity loss. Batteries will slowly
self-discharge when left unused for an extended period. Your battery lifespan and
capacity will be permanently reduced if you allow the battery cells to reach a critically
low voltage.
• Always disconnect your charger from the wall outlet and battery before storing
the battery.
• Avoid storing your batteries in extreme temperatures, whether hot or cold.
• Batteries should be kept in a cool, dry place. Do not allow batteries to accumulate
condensation; this could cause shorting or corrosion.
• The recommended storage temperature for both SLA and Li-ion batteries is
between 32-77ºF (0-25ºC).
• Avoid exposing the battery to extreme heat (104ºF or higher) for long periods.
Q: Is it normal that the batteries get warm when recharging?
A: Yes, the batteries will become warm to the touch during the recharging process due
to increased internal resistance and less energy conversion efficiency from electric
energy to chemical energy.
Q: How long will my batteries last before needing replacement?
A: Average battery life depends on use and conditions. Even with proper care,
rechargeable batteries do not last forever. Conservatively, an SLA battery will come to
the end of its useful after~350full discharge charge cycles. In contrast, LI-ION batteries
will last more than 800cycles. A partial charge/discharge counts fractionally against those
numbers; running the battery down halfway then recharging it completely uses up one
half of a charge cycle. “End of useful life” refers to the point at which a battery can no
longer supply 60% of its original rated capacity in ampere-hours. After this point, the
aging process will accelerate; the battery needs replacing.
SERVICE & MAINTENANCE SCHEDULE
You can perform some service and maintenance and require no special tools or
knowledge beyond what is written in this manual. All other service maintenance
and repair should be performed in a properly equipped facility by a qualified E-Bike
mechanic using the correct tools and procedures specified by the manufacturer.
BREAK-IN PERIOD
Your E-Bike will last longer and work better if you break it in before riding it hard.
Control cables and wheel spokes may stretch or sear when a new E-Bike is first used
and may require readjustment by your dealer. Your mechanical safety check will help
you identify some things that need readjustment. Even if everything seems fine, it is
best to take your E-Bike back to the dealer for a checkup. Dealers typically suggest you
bring the E-Bike in 30 days after purchase for a checkup. Another way to judge when it’s
time for the first checkup is to service the E-Bike after 10 to 15 hours of use. If you think
something is wrong with the E-Bike, take it to your dealer before riding it again.
17

FLAT TIRE
If you get a flat tire, remove the wheel and depress the tire valve to let all the air out of the tube.
Remove one bead of the tire from the rim by grasping the tire at a point opposite the valve stem
with both hands lifting and peeling one side of the tire off the rim. If the bead is too tight to unseat
it with your hands, use tire levers to lift the bead carefully over the tire rim. Push the valve stem
through the wheel rim. Remove the inner tube. Carefully check the outside and inside of the tire
for the puncture cause and remove it. If the tire has a cut, line the inside of the tire in the area of the
cut with tape, a spare patch, a piece of an inner tube, or a dollar bill-whatever will keep the cut from
pinching the inner tube. Patch the tube (follow the instructions in your patch kit) or use a new tube.
Reinstall the tire and tube. Slip one tire bead over the rim. Insert the tube valve through its hole
in the rim, feed the tube carefully into the tire’s cavity. Inflate the tube just enough to give it some
shape. Start at the valve stem, use your thumbs to seat the tire bead inside the rim, and work your
way around both sides of the wheel until the entire bead is seated in the rim. Be careful not to pinch
the tube between the tire bead and the wheel rim. If you have trouble getting the last few inched
of bead over the edge of the rim with thumb pressure, use a tire lever and be careful not
to pinch the tube.
CAUTION
Using any tool other tool than a tire lever will likely puncture the tube. Check to make sure the tire is
evenly seated around both sides of the rim and that the tube is inside the tire beads. Push the valve
stem into the tire to ensure that its base is seated within the tire’s beads. Inflate the tube slowly to
the recommended pressure, all the while checking to make sure that the tire beads stay seated in
the rim. Replace the valve cap, and install the wheel onto the E-Bike.
WARNING:
RIDING YOUR E-BIKE WITH A FLAT OR UNDER INFLATED TIRE CAN DAMAGE
THE TIRE, TUBE, AND E-BIKE AND CAUSE YOU TO LOSE CONTROL AND FALL.
BROKEN SPOKE
A wheel with a loose or broken spoke is much weaker than a fully tensioned wheel. If you break a
spoke while riding, you will have to ride much more slowly and carefully because the weakened
wheel could break additional spokes and become useless.
WARNING:
A BROKEN SPOKE SERIOUSLY WEAKENS THE WHEEL AND MAY CAUSE IT TO
WOBBLE, STRIKING THE BRAKES OR THE FRAME. RIDING WITH A BROKEN
SPOKE CAN CAUSE YOU TO LOSE CONTROL AND FALL.
Twist the broken spoke around the spoke nest; it will keep it from flopping around and getting
caught between the wheel and the frame. Spin the wheel to see if the rim clears the brake pads.
If the wheel will not turn try turning the brake cable adjusting barrel(s) clockwise to slacken the cable
and open up the brakes. If the wheel still won’t turn, open the brake’s quick release and secure any
loose as best you can. Walk the E-Bike, or if you must, ride it with extreme caution because you
now have only one working brake.
POWER-SAVING TIPS
TROUBLE-SHOOTING
• The life of the battery depends on using it correctly
• Pedal when riding uphill.
• Charge your battery promptly and at regular intervals if you don’t ride
your E-bike for long periods.
• Rotate the throttle slowly; do not rotate it too quickly when you speed up.
• In general, riding at a consistent speed of 15-18km/h will save the most power.
• Avoid excessive braking when you ride your E-bike.
Malfunction Analysis of Malfunction Solution
E-Bike won’t start
Fails to adjust the
speed or max speed is
relatively slow
Motor doesn’t work
after switching on
Not getting enough
mileage after a charge
Charger doesn’t
charge
Electric wheel has a
strange sound
1. Low voltage of battery
2. Bad connection between battery box
and socket
3. Power lock switch is not in the
correct position
1. Low voltage of battery
2. Spring in the speed-adjusting
handle fails to work or damage
1. Wire connection is loose
2. Connectors of motor wire connection
are loose or damaged
1. Air pressure low in the tire
2. Not enough charging or charger fault
3. Too much up slope, heavy dead
wind, braking too much, big load
4. Battery has been discharged
completely for long period of time,
not charged in time, the battery is
aging or damaged
(NOTE: Low temperature in winter
affects driving miles)
1. Socket of charger falls off or loose
between plug and socket
2. Burnt fuse in battery box
1. Abrasion of motor bearing
2. Abrasion of carbon brush
3. Big deviation of the wheel
or deformed
1. Charge the battery
2. Clean the dirt on the
connection piece (*)
3. Turn to correct position
1. Charge the battery
2. Check for/remove any debris
within the drive train
1. Connect after repair (*)
2. Check for/remove any debris
within the drive train
1. Inflate tire pressure
2. Fully charge or check
all connectors (*)
3. Change the battery
4. Fully charge indoors
1. Tighten socket and connector(*)
2. Change the fuse
1. Change the bearing (*)
2. Change the carbon brush(*)
3. Adjust the rim
*Consult your dealer as needed and always use approved replacement parts,
especially the safety-critical components.
18 19

DEALER INFO &
INFORMATION CARD
PURCHASE RECORD
Fill in immediately and retain as a record of your purchase*
*please retain your sales receipt for any possible warranty claims
Your name:
Address:
Date purchased:
Place of purchase:
Model & brand information:
Wheel size:
Color:
Serial number:
THANK YOU FOR CHOOSING
HAVE FUN AND RIDE SAFE!
