Smart Wheel SMARTkick X7 Series User manual

X7 Series USER MANUAL
FOLDING E-SCOOTER
www.smartwheel.ca/smartkick
Take your journey further!

About the Manual
●Congratulations on your purchase of the Smartkick X7 Series E-scooter.
●For your riding safety, please read this user manual carefully before using scooter and ensure to be able to ride the
scooter under correct guidance. Learn all the safety warning and tips listed in this manual that will be helpful for you to
better control the scooter.
●Please note "Warnings “and "Tips" in this manual particularly.
Warnings: Improper operation may result in personal injury.
Tips: Helpful advice & clues for the usage of E-scooter.
●Should you have any inquiries, please contact us immediately.
Tips:
A. Children below 14 years old should not operate this scooter unless otherwise carefully supervised by an adult.
B. The people without experience, poor ability to accept & physical coordination, should learn to ride with accompanies.
Please read this manual carefully before you ride the electric scooter, make sure that you can ride correctly.
C. Children are prohibited from cleaning and maintenance of the product due to mechanical and moving parts.
WARNING!
IMPROPER USE OF THE SCOOTER AND/OR FAILURE TO READ THIS USER MANUAL MAY
LEAD TO SERIOUS BODILY INJURY. SELLER WILL TAKE NO RESPONSIBILITY FOR ANY INJURIES
CAUSED BY IMPROPER USE WITHOUT FOLLOWING THE MANUAL.
Content
1.Safety Notes………………………………………………………………………………………… 3-5
2.Product Introduction …………………………………………………………………………… 6-10
3.How to ride…………………………………………………………………………………………… 11-12
4.Battery Instruction………………………………………………………………………………… 13-14
5.Parameter …………………………………………………………………………………………… 15
6.Maintenance………………………………………………………………………………………… 16
7.Trouble shooting…………………………………………………………………………………… 17
8.Packing List ………………………………………………………………………………………… 17
9.Product Quality Certificate …………………………………………………………………… 18
10.Product Warranty Card………………………………………………………………………… 18
01
02

1. Safety Notes
1.1About safety
There’s risk for riding e-scooter. For your safety, please learn to ride safely and obey the local rules in your area pertaining to kick
style e-scooter regulations.
●Please inspect tire for damages as well as your scooter for loose parts. Make sure all parts are tight and secured before
riding. Please contact local dealer or service location for any unexpected situation.
●Please do not do anything that may harm other people or their properties with e-scooter.
●Any conversion of the e-scooter is prohibited as it will change its performance or damage the structure, which may bring
serious injury. It will also impact you warranty negatively.
●Please do not put the electric scooter in the water, which will not only damage the electric scooter, but may also cause a
safety issue.
1.2 Safety Precautions
Please note that you may lose balance, crash or fall when you ride an e-scooter. To avoid injury, you should be
familiar with this manual and keep the e-scooter in good maintenance condition.
03
04
Safety measurements should be taken before riding, e.g: wear
sportswear, helmet, kneecap, elbow pads .

explosive or steam, liquid, dust and fiber.
2. Product Introduction
05
06
Be Careful of the road with roadblock, sandstone,
puddles, mud, wet, ice, snow, slope (>10º), stairs,
steps, dark area when you are riding.
DO NOT use in dangerous area, where the exploding
or catching fire may be caused by something
inflammable, explosive, steam, liquid, dust, fiber.
10º
DO NOT ride on roads where other Vehicle drive
unless allowed by law. Follow your local laws for riding
in your area.

LCD
display
Instructions of Buttons
1 Switch: Long press the power button to turn on/off the power
2 Acceleration: Press the right acceleration button to start and accelerate
3 Brake: Hold the brake handle to brake (simultaneous dual brake system). Lightly step on the rear fender to assist the
rear fender brake.
4 Short press the function key to directly adjust the speed:
Beginner mode: no characters in the gear position (10 km)
Normal mode: gear characters display white (15 km)
Sports mode: gear characters display red (25 km by default) To unlock max speed to 30 km follow Instrument Function
5 Headlights: Press the function button twice shortly to turn on the headlights. Taillights feature is always on.
In the light-on state, press the function button twice shortly to turn off the headlights.
6 Cruise mode: Hold the accelerator at current speed for 6 seconds to enter the cruise mode. Exit the cruise mode when
pressing accelerator again or brake.
2.2 Pre-assembly instructions
07
08

2. Unscrew the battery
cover
3. Tighten the battery cover and
push the dashboard cover lock
down, complete the installation.
Assemble
Disassemble
2.3 Folding chart
3.Open the folder wrench and lower
the pole.
4.Align the hook with the hole of the
rear fender and press down.
2.4 Battery Disassemble and Assembly
09
10
3. Pull the battery
straight up to remove
the battery
1. Pull up and press the
dashboard cover lock to
open the cover
1. Pull up and press the
dashboard cover lock to
open the cover
2. Align the battery groove
with the groove in the pole
and slowly put the battery
inside (please pay attention
to the groove direction)

3. How to ride the scooter
2Put one foot on the pedal, 3 Balance both feet on your scooter when you
Push off the ground with your strong leg. have enough momentum
11
12
1Press the POWER button for 2 seconds. elbow-pad when
you learn to ride the scooter.
Please wear helmet, kneecap,
elbow-pad when you learn to ride the scooter.
5 Press the THROTTLE button to speed up.
Do not ride too fast.
6 Press the brake lever to brake, and gently
press the rear fender to assist the brake.
7 When the scooter stops or run at a slow speed,
you can get off.

4. Battery Instruction
The instruction shows how to charge and maintain the battery, some safety notices and the specification.
Please use the battery properly according to this instruction to prolong the battery life and its performance.
4.1 Battery Parameters
Name
Parameter
Name
Parameter
Name
Parameter
Type
Li-ion battery
Working Temperature
0℃-35℃
Store Time（-10℃-40℃）
3 months (full charge)
Charging Time
3-4 hours
Charging Temperature
0℃-35℃
Initial Volume
5Ah/6.4Ah
Voltage
36V
Max Charging Voltage
42V
Max Charging Current
2A
4.2 Battery Safety
Do not continue to use the battery when the following conditions occur:
The battery of the electric scooter should be used only with local law. Only for professionals to disassemble and maintain
the battery.
Odor or excessive heat; leak any substance; do not touch anything leaking from the battery.
Do not let children and animals touch the battery. Must unplug the charger before installing the battery or riding.
In the case of charging, it is very dangerous to do anything related to electric vehicles.
If you want the electric scooter to run most efficiently, the battery must be charged and used within the temperature range
indicated in the battery specifications.
Lithium batteries are considered dangerous and require local law to allow transportation.
The battery contains dangerous substances. Please do not open the battery. Do not insert anything into the battery. It is
forbidden to charge a lithium battery that has been over-discharged. A battery that has been over-discharged has a
safety hazard and can only be scrapped.
Tip: When the internal temperature of the battery exceeds 45 °C, the battery is protected.
Do not charge the battery at high temperature (45 ° C) or Charge the battery in a high temperature (40 ° C) environment.
Only use the original charging equipment to charge the electric scooter.
4.3 Charging step
●Open the charging port cover, make sure the charging port is clean and dry.
●Connect the charger with the battery and the other end with power(100V-240V;50/60Hz), make sure the charging
indicator is on.
●When the indicator light on the charger changes, indicating that the charging process is normal, otherwise check if the line
connection is good.
●When the indicator on the charger has color change, it indicates that the battery has been filled to 99%, Please stop
charging; long time over charge will affect the battery life.
Tips:
Remove the battery to open the silicone charging port, plug the charger DC plug into the battery charging port; plug the
power cord into the charger, then connect the other port to the socket (100V-240V; 50/60Hz), and confirm the charger
indicator is on normally
Cover the charging port with the anti-dust cap in case some metal may touch the charging port and bring short-circuit
after charging finished.
13
14

Smartkick X7 8.5”
25km/h (unlockable to 30km/h ±1km)
Smartkick X7 Pro 10”
8°
10°
5. Specification
6. Maintenance
Maintenance considerations：
•Make sure the electric scooter charger and charging line are disconnected and ensure that the electric scooter is off.
•Wipe the shell with a soft cloth to clean the electric scooter. Please don’t put more lubricating oil on bearing when you do the
maintenance for it.
Warning
•It is forbidden to clean electric scooters by using water cannon or soaking in liquid. This will cause permanent damage of
the electronic devices in the host.
Storage
•Please charge your electric scooter before storage, for preventing the battery from discharging too long time. Please ensure
charge at least once every three months.
•If the storage environment temperature is lower than 0 ℃, please don't charge electric scooter. Please put it in inside
environment temperature (above 10 ℃) and then charge, storage temperature is - 10 ℃to 35 ℃.
•Please keep the electric scooter in a suitable place indoor, dry and appropriate temperature. You can mask the electric
scooter to prevent from the dust.
Warning
•In order to protect the user's safety, the user cannot take apart the electric scooter, otherwise, the user will give up the
maintenance warranty rights of the product automatically.
15
16

7. Trouble shooting
Please contact the sales office or the dealer with no hesitate for repair when the electric scooter fails to ride normally.
Description of adverse phenomena
Solution
Unable starting up
Check to see if the battery is powered
Cannot charge
1.Check whether the plugboard has electricity；
2.Check the charger whether connect AC plug
(the light whether is on);
3.Check the plug of the charger and the charging port
of the whole scooter have been inserted correctly.
No horn、no blue tooth signal
Check the Bluetooth switch whether turn on.
8. Packing List
Electric scooter packing list：
E-scooter: 1PC
Charger: 1PC
Manual: 1PC
Screws & Wrench: 1set
Please contact us with no hesitate if there is any breakage or missing when you open package. We will replace it for you as soon
as possible.
Have a nice day!
9. Product Quality Certificate
This product is qualified by passing QC inspection and allowed to be sold on the market.
The warranty card or regular sales invoice is effective proof of purchase certificate. Please keep it safe properly.
10.Product Warranty Card
Owner First Name
Owner Last
Name
Age
Address
Telephone
Zip
Dealer Name and
Address
Purchase Price
Serial Number
Commodity and
Specifications
Owner Signature
Dealers Signature
Warranty Terms & Conditions:
1. One-year warranty to the main body including handlebar stem, motor, charger & controller.
2. Battery is 6 months warranty period, tire and tubes 3 months against manufacturing defects.
3. Plastic decorative covers, fenders, stand, rubber handles & rear wheel is not under the scope of warranty.
4.Any of damage caused by accident, rider misuse of the device, not following instructions in the manual, cosmetic damages, or
water damages are excluded from the warranty. A charged service will be performed for these defects.
