Smartbox Grid Pad 12 User manual

HeadMouse Nano
installation guide
Grid Pad 12 headmouse nano - guide - B - UK.indd 1Grid Pad 12 headmouse nano - guide - B - UK.indd 1 12/05/2021 16:2912/05/2021 16:29

thinksmartbox.com
HeadMouse Nano ©2016 Copyright by Origin Instruments
Corporation. All rights reserved. HeadMouse is a
registered trademark of Origin Instruments Corporation.
Document: Headmouse Nano Mount Grid Pad 12 - Guide - UK - B
Language: English
Date of issue: May 2021
Copyright © 2021 Smartbox Assistive Technology
Grid Pad 12 headmouse nano - guide - B - UK.indd 2Grid Pad 12 headmouse nano - guide - B - UK.indd 2 12/05/2021 16:2912/05/2021 16:29

HeadMouse Nano installation guide
The HeadMouse Nano mount enables you to access
your Grid Pad 12 communication aid with your
HeadMouse Nano pointer
Contents
1. What is included 4
2. Getting started 5
3. The HeadMouse Nano 6
4. Assembling the Nano enclosure. 8
5. Mounting the HeadMouse Nano 10
6. Device information 14
6. Safety 15
7. Warranty information 16
8. FCC and CE notice 18
9. Disclaimer 20
10. Support 21
Grid Pad 12 headmouse nano - guide - B - UK.indd 3Grid Pad 12 headmouse nano - guide - B - UK.indd 3 12/05/2021 16:2912/05/2021 16:29

4
1What is included
Your HeadMouse Nano mount may come by itself, or as part of a
bundle with with the HeadMouse Nano camera.
The HeadMouse Nano mount is provided with:
- HeadMouse Nano camera (bundle only)
- 200 x target dots (bundle only)
- HeadMouse Nano enclosure
- Right angle USB 2.0 cable
- Switch port adapter
- 2 x Cable clips for USB
- Socket screwdriver (M3 HEX)
- Socket screwdriver (M4 HEX)
- Daessy mounting screws
- Rehadapt mounting screws
- Installation guide
Grid Pad 12 headmouse nano - guide - B - UK.indd 4Grid Pad 12 headmouse nano - guide - B - UK.indd 4 12/05/2021 16:2912/05/2021 16:29

5
The HeadMouse Nano mount is designed to fit your Grid Pad 12
communication aid.
This guide covers
Assembling the HeadMouse Nano mount
Attaching the mount to your Grid Pad 12
The HeadMouse Nano mount bundle comes with the mounth pre-
assembled.
Tools required
- Socket screwdriver (M3 HEX)
- Socket screwdriver (M4 HEX)
- Flat surface
- Cloth (optional)
Getting started 2
Grid Pad 12 headmouse nano - guide - B - UK.indd 5Grid Pad 12 headmouse nano - guide - B - UK.indd 5 12/05/2021 16:2912/05/2021 16:29

6
3The HeadMouse Nano
Red and green LED
HeadMouse Nano camera
HeadMouse Nano mount
USB 2.0 Micro
Switch adapter port
DIP Switches
Optical window
Grid Pad 12 headmouse nano - guide - B - UK.indd 6Grid Pad 12 headmouse nano - guide - B - UK.indd 6 12/05/2021 16:2912/05/2021 16:29

7
HeadMouse Nano mounted to Grid Pad 12
Grid Pad 12 headmouse nano - guide - B - UK.indd 7Grid Pad 12 headmouse nano - guide - B - UK.indd 7 12/05/2021 16:2912/05/2021 16:29

8
If you already own a HeadMouse Nano, you will need to assemble
the enclosure with the camera inside before mounting to your Grid
Pad.
1. Remove the four screws using the supplied M3 screwdriver
and remove the back of the mount.
2. Configure the HeadMouse Nano cameras DIP Switches to
your preferred settings. For more information on these see
section 11.
4Assembling the Nano enclosure
DIP Switches
Grid Pad 12 headmouse nano - guide - B - UK.indd 8Grid Pad 12 headmouse nano - guide - B - UK.indd 8 12/05/2021 16:2912/05/2021 16:29

9
3. Place the camera into the mount, ensuring the LEDs are
aligned with the holes, and reassemble the enclosure.
Grid Pad 12 headmouse nano - guide - B - UK.indd 9Grid Pad 12 headmouse nano - guide - B - UK.indd 9 12/05/2021 16:2912/05/2021 16:29

10
1. Place your Grid Pad on a flat surface with the screen facing
down.
2 . Remove the top 2 screws on your Grid Pad mounting plate
with the supplied M4 screwdriver.
3. Your HeadMouse Nano is supplied with 2 new screws
for both Readapt and Daessy mounting plates. Select the
appropriate screws for your mounting plate.
Mounting the HeadMouse Nano
5
Readapt Daessy
Grid Pad 12 headmouse nano - guide - B - UK.indd 10Grid Pad 12 headmouse nano - guide - B - UK.indd 10 12/05/2021 16:2912/05/2021 16:29

11
4. If you are planning to use the HeadMouse Nano switch
ports (see section 9) plug in the 3.5mm adapter.
5. Plug the USB 2.0 cable into the HeadMouse Nano.
Switch port adapter Micro USB 2.0
Grid Pad 12 headmouse nano - guide - B - UK.indd 11Grid Pad 12 headmouse nano - guide - B - UK.indd 11 12/05/2021 16:2912/05/2021 16:29

12
5. Line the HeadMouse Nano enclosure up with your
mounting plate on the Grid Pad and use the screws
provided to attach the enclosure to your Grid Pad.
6. Run the USB 2.0 cable under the leg of the enclosure and
plug it into the USB port on the left side of your Grid Pad.
Grid Pad 12 headmouse nano - guide - B - UK.indd 12Grid Pad 12 headmouse nano - guide - B - UK.indd 12 12/05/2021 16:2912/05/2021 16:29

13
7. (Optional) Use the cable clips to fix the USB cable to the
back of your Grid Pad, to prevent it getting caught when
moving the device. We have provided 2 cable clips with
sticky adhesive backs.
8. Your Grid Pad is now ready to be used with the HeadMouse
Nano. It will take a few moments to be detected. The front
LED will light up once the HeadMouse is ready to be used.
Grid Pad 12 headmouse nano - guide - B - UK.indd 13Grid Pad 12 headmouse nano - guide - B - UK.indd 13 12/05/2021 16:2912/05/2021 16:29

14
6Device information
Product name
HeadMouse Nano and mount
Description
The HeadMouse Nano is an infrared optical sensor that tracks
side-to-side and up-and-down head movements. It then filters
and transforms these movements to control the mouse pointer
position on the screen of a computer, tablet or communication
device.
The HeadMouse Nano uses infrared light to track a tiny reflective
dot that is placed on the user’s forehead or glasses.
Switches can be connected directly to HeadMouse Nano through
a 3.5 mm stereo jack located next to the USB connector.
Technical specification
Operating wave band: Near Infrared
Power consumption: 1/2 watt (typical)
Field of view: 72 degree by 45 degree
Measurement rate: 80Hz
USB interface: Full speed
Grid Pad 12 headmouse nano - guide - B - UK.indd 14Grid Pad 12 headmouse nano - guide - B - UK.indd 14 12/05/2021 16:2912/05/2021 16:29

15
7
Safety
Durability
Do not pick up the Grid Pad by the HeadMouse Nano.
Water and liquids
The HeadMouse Nano is not protected against water ingress. Do
not get water or liquids on the device.
Transporting your Grid Pad with the HeadMouse Nano
The HeadMouse Nano can remain attached to your Grid Pad
when travelling.
Other safety
If damaged, small parts may detach from your Grid Pad and
HeadMouse Nano mount. These can present a choking hazard.
Young children and people with cognitive disabilities should be
supervised when using the device.
The HeadMouse Nano is not sterile. Do not operate with open
wounds, or whilst undergoing invasive medical treatments.
Disposal of the HeadMouse Nano and enclosure
Do not dispose of in general household or office waste. Your
HeadMouse Nano and enclosure should be disposed of in
accordance with local regulations for the disposal of electrical
and electronic equipment.
Grid Pad 12 headmouse nano - guide - B - UK.indd 15Grid Pad 12 headmouse nano - guide - B - UK.indd 15 12/05/2021 16:2912/05/2021 16:29

16
Origin Instruments warrants that HeadMouse Nano will be free
from defects in materials and workmanship for a period of two
years from the date of shipment. If the product proves defective
during this warranty period, Origin Instruments will, at its option,
repair or replace the defective product.
In order to obtain service under the foregoing warranties, the
Customer must notify Origin Instruments of the defect prior to the
expiration of the warranty period.
The foregoing warranties will not apply to any defect, failure, or
damage caused by improper use, or improper or inadequate
maintenance and care. Origin Instruments will not be obligated to
furnish service under these warranties (a) to repair damage
resulting from attempts by unauthorized personnel to install,
repair, or service the product; (b) to repair damage resulting from
improper use or connection to incompatible equipment; or (c) to
service a product that has been modified or integrated with other
products when the effect of such modification or integration
increases the time or difficulty of servicing the product.
The foregoing warranties are given by Origin Instruments with
respect to company products in lieu of any other warranties,
expressed or implied. Origin Instruments disclaims any implied
warranties of merchantability or fitness for a particular purpose.
Origin Instruments’ responsibility to repair or replace defective
products is the sole and exclusive remedy provided to the
customer for breach of any of these warranties.
Origin Instruments will not be liable for any indirect, special,
incidental or consequential damages irrespective of whether
8Warranty Information
Grid Pad 12 headmouse nano - guide - B - UK.indd 16Grid Pad 12 headmouse nano - guide - B - UK.indd 16 12/05/2021 16:2912/05/2021 16:29

17
Origin Instruments has advance notice of the possibility of such
damage.
Products no longer covered by warranty may be suitable for
repair. Contact Origin Instruments for an estimated repair fee.
Before returning a product for repair, please send an email to:
[email protected] or call 972.606.8740 to request a Return
Materials Authorization (RMA) Number. Once a RMA number is
assigned, product must be returned postage pre-paid with all
components to:
Origin Instruments Corporation
ATTN: Customer Service – RMA (insert your number)
854 Greenview Drive
Grand Prairie, TX 75050-2438 USA
For repairs during the warranty period, Origin Instruments will pay
for the return of the product to the Customer if the shipment is to
a location within the United States.
For non-warranty repairs and for warranty repairs outside of
the United States, the Customer will be responsible for paying
all shipping charges, duties, taxes, and any other charges
associated with the return of the product.
Grid Pad 12 headmouse nano - guide - B - UK.indd 17Grid Pad 12 headmouse nano - guide - B - UK.indd 17 12/05/2021 16:2912/05/2021 16:29

18
Products bearing the CE marking have been tested and are
declared by Origin Instruments Corporation of 854 Greenview
Drive, Grand Prairie, Texas 75050, USA to be in conformity with
the following standards or other normative documents and
following the provisions of the Electromagnetic Compatibility
Directive, 89/336/EEC:
- EN 55022 Class B Emissions (Radiated Emission)
- EN 61000-4-2, Electrostatic Discharge Immunity
- EN 61000-4-3, Radiated Immunity
Origin Instruments Corporation has tested the HeadMouse Nano
and found that it complies with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful
interference in a residential installation.
Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may
cause undesired operation.
If this product is suspected of causing interference to a radio or
television receiver, remove and apply power to the equipment and
determine whether it is the cause of the disturbance. If a problem
exists, the user is encouraged to try and correct the problem by
one of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and the
receiver.
9FCC and CE notice
Grid Pad 12 headmouse nano - guide - B - UK.indd 18Grid Pad 12 headmouse nano - guide - B - UK.indd 18 12/05/2021 16:2912/05/2021 16:29

19
3. Reorient the equipment cables.
4. Consult the dealer or Origin Instruments for additional
suggestions.
Information in this document is subject to change without notice
and does not represent a commitment on the part of Origin
Instruments Corporation.
Grid Pad 12 headmouse nano - guide - B - UK.indd 19Grid Pad 12 headmouse nano - guide - B - UK.indd 19 12/05/2021 16:2912/05/2021 16:29

20
HeadMouse Nano is designed for use by people who have limited
or no motor capability enabling USB mouse operations. However,
it should not be used in an application where personal injury or
property loss could occur if the HeadMouse Nano failed for some
reason.
Origin Instruments products are not authorized for
use as surgical aids or as part of a system intended to
support or sustain life. The user assumes full responsibility for
determining the suitability of the HeadMouse Nano for the
intended application.
10 Disclaimer
Grid Pad 12 headmouse nano - guide - B - UK.indd 20Grid Pad 12 headmouse nano - guide - B - UK.indd 20 12/05/2021 16:2912/05/2021 16:29
